SMC Networks HECR Series User manual

RoHS
Air-cooled
Mountable in a 19-inch rack
Saves space by mounting multiple equipment
together in a rack.
Space saving design
with reduced height
±0.018 to 0.054°F
(0.01 to 0.03°C)
Temperature
stability
50 to 140°F
(10 to 60°C)
Set temperature
range
200 w
Cooling capacity
440 w (100 V input, 4.6 A)
Power
consumption
Energy
saving
Good space utilization
Height dimension
HEC002HECR
6.9 in
(176 mm)
15.5 in
(393 mm)
Peltier-Type Chiller
Thermo-con/
Rack Mount Type
Approx. 55% reduction
Series HECR CAT.NAS40-61A

Peltier-Type Chiller
Thermo-con/Rack Mount Type Series HECR
1
Simple operation
Heat source
Temperature sensor
This function adjusts the fluid temperature
to the set value with an automatic offset
setting. Set the external temperature
sensor at the circulating fluid inlet located
just in front of the heat source, which
allows the Thermo-con to sample the fluid
temperature. This function is effective
when automatically adjusting for heat
exhaust from piping etc.
Less vibration and noise with no moving
parts such as a compressor.
Better space utilization with
reduced height and depth
compared to the current model
(HEC002).
If the external temperature sensor is installed directly on the heat source, the learning control
function may not work property due to large heat volume or large temperature difference. Be sure
to install the sensor at the circulating fluid inlet.
Circulating fluid volume can be checked.
qTurn the power ON.
wPress the SEL key, and adjust the temperature
setting with the keys.
ePress the RET key to complete.
Can precisely control the temperature of a heat source or process fluid.
Precisely control the temperature of the circulating fluid by using the Peltier device.
Refrigerant-free and environmentally friendly.
Air-cooled
Radiating method
Single-phase 100 to 240 VAC (Globally compatible power supplies)
Power supply
200 W
Coolingcapacity
600 W
Heating capacity
Learning control function
(Temperature control by external temperature sensor)
Low vibration,Low noise (49 dBA) Volume ratio reduced by 36%
Drain pan
Drain pan is equipped to avoid any
risk of fluidleakage over equipment
mounted in a lower rack.
Fluid fill port
Fluid can be supplied
without removing the
product from the rack.
Power switch
Rack mounting
bracket
Floor type is also available. (Option)
The rack mounting brackets and the handles can be removed and
rubber feet can be mounted instead. (Refer to page 11 for details.)
6.9
[176]
15.5
[393]
inch
[mm]
HEC002
HECR
11.8 [300] 17.1 [436]
19.0 [484] 8.3 [210]

Peltier-Type Chiller
Thermo-con/Rack Mount Type Series HECR
2
Circulating fluid supply port
(Tank lid)
(Also used as a fluid discharge port.)
For the rack type, a flow switch (option) is mounted on the circulating fluid OUT side.
Flow switch (Option)
Circulating fluid
Tank
Temperature
sensor
Pump
Peltier device
(Thermo-module)
Fan
T
Power switch
PE
Power supply &
Controller
Fan
Switching power supply
Controller
Circulating fluid
OUT
IN
Heat exchanger
(Circulating fluid side)
Heat exchanger
(Cooling side)
Figure 1
Target of
temperature
control
Example of circulating fluid piping
Figure 2
Electron
hole flow
Fan
Electron
flow
Circulating fluid
Current Heat generation (heating)
Heat suction (cooling)
N P
DC power supply
Cooling
Electron
hole flow
Fan
Electron
flow
Circulating fluid
Current Heat suction (cooling)
Heat generation (heating)
N P
DC power supply
Heating
Principle of Peltier Device (Thermo-module)
Construction and Principles
The Thermo-con is constructed as shown in Figure 1. It interposes
a Peltier device (thermo-module) between the heat exchangers for
the circulating fluid and facility water and controls the DC power
supply to achieve the target outlet temperature of circulating fluid
precisely.
The circulating fluid returns to the tank, and is transferred by the
pump which is built in the Thermo-con, and goes through the heat
exchangers and temperature sensor and out from the circulating
fluid outlet.
Figure 2 shows an example of circulating fluid piping.The circulating
fluid is transferred at a constant temperature by the pump.
A Peltier device (thermo-module) is a plate type
element, inside which P-type semiconductors and
N-type semiconductors are located alternately. If direct
current is supplied to the Peltier device (thermo-mod-
ule), heat is transferred inside the device, and one face
generates heat and increases temperature while the
other face absorbs heat and decreases temperature.
Therefore, changing the direction of the current supplied
to the Peltier device (thermo-module) can achieve
heating and cooling operation. This method has a fast
response and can shift quickly between heating and
cooling, so temperature can be controlled very precisely.

Peltier-Type Chiller
Thermo-con/Rack Mount Type Series HECR
3
Laser machining
X-ray (digital) instrument
Laser marker
UV curing device
(printing, painting, bonding and sealing)
Electronic microscope
Ultra sonic wave inspection machine
Cooling of laser irradiated part
Temperature control of X-ray tube and
X-ray light sensing part
Cooling of laser irradiated part
Cooling of UV lamp
Temperature control
of electron-beam
irradiated part
Temperature
control of
ultrasonic wave
laser part
X-ray tube
Light sensing part
Application Examples

4
Series HECR
CONTENTS
 Thermo-con/Rack Mount Type Series HECR
Model Selection............................................................................................Page 5
How to Order/Specifications ........................................................................Page 7
Cooling Capacity .......................................................................................... Page 8
Heating Capacity..........................................................................................Page 8
Pump Capacity (Thermo-con Outlet)............................................................Page 8
Dimensions................................................................................................... Page 9
Operation Display Panel .............................................................................Page 10
Alarm .......................................................................................................... Page 10
Maintenance...............................................................................................Page 10
 Options
With Feet and No Rack Mounting Brackets................................................ Page 11
With Flow Switch ........................................................................................Page 11
 Optional Accessories
Power Supply Cable ...................................................................................Page 12
Specific Product Precautions......................................................................Page 13
Air-cooled

5
1. How much is the temperature in degrees centigrade for the circulating fluid?
Thermo-con/Series HEC
For details, refer to the WEB catalog or the Best Pneumatics No. 7.
±0.018°F to 0.054°F
(±0.01°C to 0.03°C)
Circulating fluids that can be used in the Thermo-con: Water, Ethylene glycol 20%
When using fluorinated fluids, select the water-cooled Thermo-con HEC series.
2. What kind of the circulating fluids will be used?
Allows a safety factor of 20% over the capacity that is actually required, taking into account the changes in the operating
conditions. If a larger capacity than this Thermo-con is necessary, select the Peltier-type Thermo-con HEC series (refer to
the following.) or the refrigerated Thermo-chiller HRS/HRZ series.
3. How much cooling capacity required?
Guide to Model Selection
Cooling capacity = Considering a safety factor of 20%,
400 W x 1.2 = 480 W
Series HECR
Model Selection
Air-cooled Water-cooled
Example 1 When the heat generation amount in the user’s equipment is known.
Heat generation amount: 400 W
Temperature range which can be set with the Thermo-con: 50 to 140°F (10 to 60°C)
If a lower temperature (down to –4 °F [–20°C]) or higher temperature (up to 194°F [90°C]) than this range is necessary, select the
Thermo-chiller HRZ series.
• Cooling capacity: 140 Wto 1200 W
• Temperature stability:
High-precision temperature control type for semiconductor
manufacturing equipment, medical equipment, etc.

6
Circulating device
User’s
equipment
T2: Return temperature
T1: Outlet temperature
L
∆T = T2 – T1
Water bath
V
After 15 min, cool 30
°
C down to 20
°C.
20°C
Temperature [°C] Density ρ[kg/L] Specific heat C [J/(kg·K)]
10 1.03 3.93 x 103
20 1.03 3.95 x 103
30 1.02 3.97 x 103
40 1.02 3.98 x 103
50 1.01 4.00 x 103
60 1.01 4.02 x 103
Precautions on Model Selection
Guide to Model Selection
Circulating Fluid Typical Physical Property Values
Ethylene Glycol Solution 20%
Obtain the temperature difference between inlet and outlet by circulating the fluid inside the user’s equipment.
Heat generation amount Q
Circulating fluid temperature difference
∆T(=T2–T1)
Circulating fluid outlet temperature T1
Circulating fluid return temperature T2
Circulating fluid flow rate L
Circulating fluid
: Unknown
: 0.8°C (0.8 K)
: 25°C (298.15 K)
: 25.8°C (298.95 K)
: 3 L/min
: Water
Density γ: 1 x 103kg/m3
Specific heat C: 4.2 x 103J/(kg·K)
Q = ∆T x L x γx C
60 x 1000
0.8 x 3 x 1 x 103x 4.2 x 103
60 x 1000
= 167 W
=
200 W
Cooling capacity = Considering a safety factor of 20%,
167 W x 1.2 =
Water
Density γ: 1 x 103[kg/m3]Specific heat C: 4.2 x 103[J/(kg •K)]
Cooled substance total volume V
Cooling time h
Cooling temperature difference ∆T
Circulating fluid
Cooling capacity = Considering a safety factor of 20%,
93.3 W x 1.2 = 112 W
Q = ∆T x V x γx C
h x 60 x 1000
= 10 x 2 x 1 x 103x 4.2 x 103
15 x 60 x 1000
= 93.3 W
: 2 L
: 15 min
: Temperature difference: 10°C (10 K). Cool from 30°C (303 K) to 20°C (293 K).
: Water
Density γ: 1 x 103kg/m3
Specific heat C: 4.2 x 103J/(kg·K)
∗Refer to the information shown below for the typical
physical property values by circulating fluid.
Example 2 When the heat generation amount in the user’s equipment is not known.
Example 3 When cooling the object below a certain temperature in certain period of time.
Model Selection Series HECR
The flow rate of the circulating fluid depends on the pressure loss of the user’s equipment and the length, diameter and
resistance created by bends in the circulating fluid piping etc. Check if the required flow rate of circulating fluid can be obtained
before selecting.

7
Thermo-con/
Rack Mount Type
Series HECR
Nil None
EWith feet and no rack mounting brackets
FWith flow switch
Nil Rc
NNPT thread
AAir-cooled
5100 to 240 VAC
002 200 W
HECR 002 5A
Cooling capacity
Radiating method
Power supply
Option
Pipe thread type
How to Order
Specifications
Model HECR002-A
Cooling method Thermoelectric device (Thermo-module)
Radiating method Forced air cooling
Control method Cooling/Heating automatic shift PID control
Ambient temperature/humidity 50 to 95°F (10 to 35°C), 35 to 80%RH (No condensation)
Circulating fluid system
Circulating fluid Water, Ethylene glycol 20%
Set temperature range 50 to 140° [10 to 60°C] (No condensation)
Cooling capacity 200 W (Water) Note 1)
Heating capacity 600 W (Water) Note 1)
Temperature stability Note 2) ±0.018 to 0.054 (±0.01 to 0.03°C)
Pump capacity Refer to the performance charts. (Page 8)
Tank capacity Approx. 0.34 gal (1.3 L)
Port size Rc1/4
Wetted parts material Stainless steel, EPDM, Ceramics, PPE, Carbon, PP, PE
Electrical system
Power supply Single-phase 100 to 240 VAC ±10%, 50/60 Hz
Overcurrent protector 10 A
Current consumption 5 A (100 V) to 2.5 A (240 V)
Power consumption 440 W Note 1)
Alarm Refer to “Alarm.” (Page 10)
Communications RS232C/RS-485
Weight Approx. 14 kg
Accessories Power supply connector, Operation Manual
Power supply cable should be ordered as an option (sold separately) or prepared by the user.
Safety standards CE marking, UL (NRTL) standards
Air-cooled
Note 1) Conditions: Set temperature 77°F (25°C), Ambient temperature 77°F (25°C), Circulating flow rate 0.8 gal/min (3 L/min)
Note 2) The indicated values are with a stable load without turbulence in the operating conditions. It may be out of this range in some other operating conditions.

8
Model Selection Series HECR
800
700
600
500
400
300
200
100
0050
[1]
68
[20]
86
[30]
104
[40]
122
[50]
140
[60]
158
[70]
Circulating fluid temperature °F [°C]
Cooling capacity [W]
Circulating fluid: Water
Ambient temperature 59°F (15°C)
Ambient temperature 77°F (25°C)
Ambient temperature 95°F (35°F)
800
700
600
500
400
300
200
100
00
Circulating fluid temperature °F [°C]
Cooling capacity [W]
Circulating fluid: Ethylene glycol 20%
Ambient temperature 77°F (25°C)
Heating capacity [W]
1000
900
800
700
600
500
400
300
200
100
00
Circulating fluid: Water
Ambient temperature 59°F (15°C)
Ambient temperature 95°F (35°F)
Heating capacity [W]
1000
900
800
700
600
500
400
300
200
100
00
Circulating fluid: Ethylene glycol 20%
Ambient temperature 77°F (25°C)
Circulating fluid: Water, Ethylene glycol
Circulating fluid flow rate gal/min [L/min]
Discharge pressure psi [MPa]
0.015
[0.10]
0.011
[0.08]
00 0.26 [1] 0.5 [2] 0.8 [3] 1.05 [4]
Ethylene glycol 20%
Water
Cooling Capacity
Pump Capacity (Thermo-con Outlet)
Heating Capacity
50
[1]
68
[20]
86
[30]
104
[40]
122
[50]
140
[60]
158
[70]
50
[1]
68
[20]
86
[30]
104
[40]
122
[50]
140
[60]
158
[70]
50
[1]
68
[20]
86
[30]
104
[40]
122
[50]
140
[60]
158
[70]
0.009
[0.06]
0.006
[0.04]
0.003
[0.02]
Ambient temperature 77°F (25°C)

9
N L
E
54
321
6
7
8
9Connection diagram of
resistance temperature sensor
8765432
1
9
10
11
12
13
14
15
5
4
3
1.5 [38]
0
5.5 [139.7]
6.9 [176]
5.3 [134]
19.0 [484] 18.7 [474]
0.4
[10]
0
15.8 [403]
1.9
[49]
9.8
[250]
1.5
[38]
17.6 [447]
0
1.5 [38]
5.5 [139.7]
0.8 [21]
4.2 [107]
Air
Air
1.1 [27]
0
1.6 [40]
10.6
[270]
12.1 [309]
13.3 [339]
0
0.8 [20]
4.9 [126]
5.7 [146]
0.47 [12]
0
2.6 [68]
4.6 [118]
5.6 [144]
5.1 [131]
0
2.7
[69]
4.1
[104]
9.5
[242]
10.6 [269]
16.9 [430] 1.06 [27]
Caution label/Electricity
Warning/Caution label
11.8 [300]
(0.43 [11])
(1.3 [33])
Fluid fill port
Ventilation hole (air outlet)
Model no. label
External temperature sensor connector
Alarm output connector
Communication connector
Label
Power supply connector
Ventilation hole (air outlet)
0.27 [7]
0.39 [10]
Ventilation hole (air inlet)
Circulating fluid level gauge
Label
Display/Operation panel
Ventilation hole (air inlet) Power switch
Handle (for carrying the product)
Tank lid (with gasket)
Handle (for installing/removing the product to/from the rack)
Circulating fluid inlet
(Circulating fluid drain port)
Rc1/4
Circulating fluid outlet
Rc1/4
Dimensions
HECR002-A5
1. Power supply connector
IEC60320 C14 (or equivalent)
2. Communication connector
D-sub 9 pin (socket)
Holding screw: M2.6
3.
External temperature sensor connector/Alarm output connector
D-sub 15 pin (socket)
Holding screw: M2.6
Pin no. Signal contents
N100-240 VAC
L100-240 VAC
EPE
Pin no.
Signal contents
RS-232C RS-485
1Unused BUS+
2RD Unused
3SD Unused
4Unused Unused
5SG SG
6-8 Unused Unused
9Unused BUS–
Pin no. Signal contents
1-2 Unused
3Terminal A of resistance temperature detector
4Terminal B of resistance temperature detector
5Terminal B of resistance temperature detector
6Contact a for output cutoff alarm
(open when alarm occurs)
7Common for output cutoff alarm
8Contact b for output cutoff alarm
(closed when alarm occurs)
9Contact a for upper/lower temp. limit alarm
(open when alarm occurs)
10 Common for upper/lower temp. limit alarm
11 Contact b for upper/lower temp. limit alarm
(closed when alarm occurs)
12-14
Unused
15 FG
Series HECR
Unit: in [mm]
