SMC Networks TigerAccess SMC7500A/VCP User manual

Extended
Ethernet
SMC7500A/VCP
TigerAccessTM Extended Ethernet CPE
www.smc.com
SMC’s Extended Ethernet (EE) network solution provides
an alternative cost-effective solution for network/
Internet access to multi-unit buildings, or enterprise
environments such as hospitals, universities, and
manufacturing facilities. Using existing category 1, 2, or
3, SMC’s Extended Ethernet technology is able to deliver
up to 15Mbps of broadband connection for distance up to
5,000 feet. SMC’s EE solution minimize the hassles
involved in rewiring by delivering both voice and data
access on the same line as Plain Old Telephone Service
(POTS). It is also compatible with ADSL (asymmetric dig-
ital subscriber line). SMC’s EE solution is the best choice
for service providers to supply broadband access with
minimal changes to existing wiring infrastructure.
The TigerAccess Extended Ethernet Solution includes
the TigerAccess EE Switch, TigerAccess EE CPE
(Customer Premise Equipment), and TigerAccess EE
Splitter.
TigerAccess EE CPE
SMC’s TigerAccess EE CPE provides Ethernet and voice
connection to each room in the multi-unit building,
university, hospital or manufacturing facility. The CPE
provides one RJ-45 Ethernet connection and 2 RJ-11
connectors, one for plugging into the phone jack in a wall,
one for a phone. The CPE device bridges EE traffic and
Ethernet, and at the same time splits the EE traffic and
the POTS traffic over the same line. The Ethernet port
can connect to a PC, workstation, or SMC switch or
wireless access point for wireless connections
FEATURES
Easy to deploy: no rewiring required
10Base-T or 100BASE-TX for easy Ethernet connection
Ideal for desktop or shelf mountable
Support both POTS and EE line at the same time
Can be connected to a wireless access point,
switch, or a workstation
No configuration required; plug and play
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMC7500A/VCP
PORTS
• 2 RJ-11 connector; one-pair category 1, 2, 3 UTP cabling
• 1 RJ-11 to phone jack in the wall
• 1 RJ-11 for telephone connection
• 1 RJ-45 10BASE-T/100BASE-TX
• 10BASE-T: UTP category 3, 4, 5
• 100BASE-TX: UTP category 5
EXTENDED ETHERNET SPECIFICATION
• VDSL Standards:
• supports evolving ETSI, ANSI and ITU standards
• Modulation:
• 4 to 256 QAM Frequency Division Duplexing
LEDs
• Power, Link (VDSL), Link (LAN), Activity (LAN)
SPEED/DISTANCE
• Up to 15 Mbps symmetrical transmission
rate at 3500 ft/ 1000m distance
• Up to 10 Mbps symmetrical transmission
rate at 4000 ft/ 1200m distance
• Up to 5 Mbps symmetrical transmission
rate at 5000 ft/ 1500m distance
• Up to 4 Mbps downstream, 1 Mbps upstream
at 5800 ft/ 1750m distance
TEMPERATURE
• Operating: 0 °C to 50 °C / 32 °F to 122°F
• Storage: -40 °C to 70 °C / -40 °F to 158 °F
HUMIDITY
• Operating: 5% to 95% (non-condensing)
HEAT DISSIPATION
•123 BTU/hr
INPUT POWER
• 12 VDC (via AC power adapter)
• Typical 350mA Max
POWER SUPPLY
• Internal, auto-ranging transformer:
100 - 240VAC, 50 - 60 Hz
• Maximum Current:
0.5A max. @110V, 0.25A max. @240V
CURRENT CONSUMPTION
• 3.5Watts max. (350 mA x 12V = 4.2W)
WEIGHT
•4.94 oz
• 140g
DIMENSIONS
• 3.74 x 3.54 x 1.02 in
• 95 x 90 x 26 mm
COMPLIANCES
• CE Mark
EMISSIONS
• FCC Class B
• Industry Canada Class B
• EN55022 (CISPR22) Class B
• EN61000-3-2/3
• EN61000-4-2/3/4/5/6/8/11
• VCCI Class B
• IEC1000-4-2/3/4/6
SAFETY
• CSA/NRTL (CSA22.2.2.950 &UL 1950)
• EN60950 (TUV/GS)
WARRANTY
• Limited Lifetime
