Enterprise Switch SMC6726L3
TigerSwitchTM Standalone L3 Managed 24-Port 10/100 Switch
www.smc.com
SMC’s TigerSwitch 10/100, SMC6726L3, performs Layer
2 switching and IP-based Layer 3 routing in the same
box. It includes 24 fixed auto-MDIX 10/100BASE-TX ports
and 4 Gigabit ports, 2 SFP and 2 1000BASE-T also on
the front panel giving complete flexibility. This TigerSwitch
is designed to integrate network subnets and VLANs
seamlessly, augmenting or completely replacing slow
legacy routers, and providing the required throughput for
today’s web-based intranet traffic flow.
The SMC6726L3 also comes fully-loaded with advanced
performance-enhancing features: GMRP and IGMP
maintain available bandwidth by limiting multicast
packet transmissions to subscribers only. DVMRP
multicast routing can significantly conserve bandwidth
by minimizing packet replication across the network. QoS
priority queueing ensures a minimum delay for real-time
multimedia data across the network, while port-based
and tagged VLANs with support for GVRP are also
included to provide traffic security and efficient use of
network bandwidth. With a host of advance features and
comprehensive management capabilities, this device is a
strong solution for the network core with the flexibility to
be integrated into existing network infrastructure.
OVERVIEW
Smart
Managed
Unmanaged
Enterprise
S
w
FEATURES
High-port density and migration protection in a small footprint
Layer 3 Unicast Features
Layer 3 Multicast Features
QoS
IGMP Snooping
Trunking with LACP
Comprehensive security support
Redundant Power Supply
BENEFITS
Supports 24*10/100Mbps with 4 Gigabit ports in an 1RU chassis
Supports RIPv1,v2 and OSPF to give wirespeed IP routing
Supports DVMRP and PIM-DM to enable multicast networks
Support eight levels of priority, with weighted fair queuing
and L2/3/4 IP precedence--ensures smooth transmission of
mission critical data
Only allows IP Multicast traffic transmission to the registered
members, resulting bandwidth savings--reduce IP multicast
traffic and increase LAN performance
Can group links between switches to provide higher bandwidth
of up to 800Mbps
Supports RADIUS, IEEE802.1x, SSH, SSL,TACACS+, ACL
and SNMPv3
Provides backup power in case of power failure

TECHNICAL SPECIFICATIONS SMC6726L3
PORTS
• 24 auto-MDIX 10/100 RJ-45 ports
• 2 SFP ports
• 2 1000BASE-T ports
• Console port
• Redundant Power connector
NETWORK INTERFACE
• 10BASE-T: RJ-45 UTP CAT. 3,4,5
• 100BASE-TX: RJ-45 UTP Cat. 5
• 1000BASE-SX: SC connector
• 1000BASE-LX: SC connector
• 1000BASE-T: RJ-45 connector
• Multimode fiber cable;
62.5/125 or 50/125 microns
• Singlemode fiber cable:
LEDs
• System: Power, RPU, Diag
• Port: link/activity
SWITCH FABRIC
• 12.8Gbps
• 9.5Mpps
BUFFER ARCHITECTURE
• 32Mb shared
SWITCHING DATABASE
• 16K MAC address entries
• 4K IP address entries
WEIGHT
• 6.86 lbs
•3.1kg
TEMPERATURE
• Operating: 0oto 50oC / 32oto 122oF
• Storage: -40oto 70oC / -40oto 158oF
WARRANTY
• Limited Lifetime
DIMENSIONS
• 17.4 x 9.1 x 1.7 in
• 44.0 x 23.0 x 4.4 cm
HUMIDITY
• Operating: 5% to 95%
POWER SUPPLY
• Internal, auto-ranging transformer:
100 to 240VAC, 50 to 60 Hz
POWER CONSUMPTION
• 28.44 Watts maximum
AC INPUT
• 100 to 240 V, 50-60 Hz, 0.8A
MAXIMUM CURRENT
• 0.56 A @110 VAC
• 0.32 A @ 240 VAC
SWITCH FEATURES
LAYER 3
• IPv.4 Routing
• L2/L3 Multicasting
• GMRP (GARP Multicast
Registration Protocol)
• IGMP (Internet Group Management Protocol)
• DVMRP (Distance Vector
Multicast Routing Protocol)
• PIM-DM (Protocol Independent
Multicast-Dense Mode)
• Multi-netting
• Static IP routes
• Supernetting (CIDR)
• RIP v1, v2
• OSPF routing
• DHCP/BOOTP
• DHCP Server/client
LAYER 2:
• Spanning Tree Protocol
(802.1D, 802.1w, 802.1s)
• Spanning Tree fast start
• Forwarding Mode
• Store-and-forward
• Flow Control
• Full Duplex: IEEE802.3x
• Half Duplex: back pressure
• VLAN Support
• Up to 256 groups; port-based or with 802.1Q
• VLAN tagging, GVRP for
automatic VLAN learning
• Private VLANs
• Quality of Service
• Supports eight levels of priority
and weighted fair queuing
• Layer 3/Layer 4 priority mapping:
IP precedence, IP DSCP
• Rate limiting
• Broadcast storm control
• Link Aggregation
• Port Mirroring
MANAGEMENT FEATURES
• In-Band Management
• Telnet, SLIP, Web-based
HTTP, or SNMP manager
• Out-of-Band Management
• CLI, RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• RMON Support
• Groups 1,2,3, 9
(Statistics, History, Alarm, Event)
• SNMP (v1,v2,v3)
• NMS
• EliteView
STANDARDS
• RFC 1157 SNMP, RFC 826 ARP, RFC 791 IP,
RFC 792 ICMP, RFC 768 UDP, RFC 793 TCP,
RFC 783 TFTP, RFC 854-859 TELNET,
RFC1058 RIP I, RFC 1157 SNMP, RFC 1213
MIB-II, RFC 1215 Trap, RFC 1573 Evolution of
Interface Group MIB, RFC 1215 Traps, RFC
1493 Bridge MIB, RFC1724 RIP II MIB, RFC
1757 RMON, RFC 1866 HTML, RFC 2068
HTTP, RFC 1724 RIP2 MIB, RFC 1850 OSPF2
MIB, RFC2096 IP Forwarding Table MIB
RFC2096 RFC1213 standard MIB-II, RFC2131
DCHP server, RFC2233 Interface Group MIB,
RFC2328 OSPF, RFC2453 RIP II, RFC2674
Bridge MIB Extensions (IEEE802.1Q MIB),
RFC2737 Entity MIB, RFC2742 Extensible
SNMP Agents MIB, IP Multicast MIB (IGMP
MIB, DVMRP MIB), Private MIB (IEEE 802.1w
Rapid Reconfiguration Spanning Tree MIB)
COMPLIANCES
• CE Mark
EMISSIONS
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• VCCI A
• C-Tick – AS/NZS 3548 (1995)
Class A Immunity
• IEC 1000 – 4 –2/3/4/6
SAFETY
• CSA/NRTL (CSA22.2.2950
& UL 1950), EN60950 (TUV/GS)
OPTIONAL PLUG-IN TRANSCEIVERS
SMC1GSFP-SX
• 1000BASE-SX
• LC Multimode fiber
• Range - 220m for 62.5/125m, 850nm
• Range - 550m for 50/125m, 850nm
SMC1GSFP-LX
• 1000BASE-LX
• LC Singlemode fiber
• Range - 10Km for 9/125m, 1310nm
SMC1GSFP-ZX
• 1000BASE-ZX
• LC single mode fiber
• Range - 70 to 100Km for 9/125, 1310nm
