Overview
0101001100100100010010110010101010011010010
SMC8504T
Model Number::
EZ SwitchTM 10/100/1000
4-port Unmanaged Layer 2 + Gigabit Switch
Network users and applications continue to increase
the use of bandwidth intensive software programs,
graphically dense materials and desire faster speeds to
the desktop. SMC EZ Switch 10/100/1000 meets that
demand with its 4 port standards-based gigabit
switch. This 1U rack mount or desktop switch seam-
lessly integrates with the rest of the network through
its auto-negotiating, non-blocking design. Featuring
advanced technologies such as VLAN, Priority Queing,
Trunking and Failover, the SMC8504T is the most cost
effect method for brining speed and service to the
desktop.
Network Administrators will find the SMC8504T an
easy solution to integrate into a network as technolo-
gy migrates toward gigabit. It’s Store-and-Forward
architecture combined with 32k MAC Address Table
ensures data integrity as the network is optimized to
run at full wire speeds.
Gigabit Ethernet is the perfect solution to bottlenecks
at the core of the network that are the inevitable result
of data-intensive applications and the proliferation of
new users. SMC’s EZ Switch 10/100/1000 provides a
seamless migration to higher-speed networking while
solving bandwidth issues.
Switches/Hubs
38 Tesla
Irvine,CA 92618
1-800-SMC-4YOU
www.smc.com
Features
• Full and Half duplex on all 10/100 ports with
Full-duplex mode for 1000Mbps
• 32k MAC AddressTable
• Store-and-Forward mode with wire-speed
filtering and forwarding
• Auto MDI/MDIX on 1000BaseT ports
• Store-and-forward switching ensures error-
free transmission
• Half- and full-duplex flow control
• Smart function compatible for:
-Support on console port for switch
configuration change
-Support per port Port-based VLAN and L2
Trunking with link fail-over
-Support four Priority queues on each port
• Plug and play
• Built-in wiring crossovers on all ports
• "At-a-glance" LEDs for port and system
status monitoring
• Desktop and rack mountable
Benefits
• Store-and-Forward and wire-speed filtering and
forwarding rates ensures error free transmission of data
packets within the network
• ANSI/ IEEE compliance ensures compatibility with
standards-based hubs,switches and cards from any
vendor
• Half- and full-duplex flow control prevents packets from
being dropped under heavy loading
• Smart function compatible for advanced networking
procedures within the network to ensure priority settings
can still be maintained
• Plug and play for ease of installation,maintenance
and use.
• Built-in wiring crossovers on all ports allow connections
to servers and workstations to be made with straight-
through cabling
• "At-a-glance" LEDs for port and system status monitoring
• Desktop and rack mountable allowing flexibility within
your network design
Compatible
• IEEE 802.3 Ethernet
• IEEE 802.3u Fast Ethernet
• IEEE 802.3z Gigabit Ethernet
• IEEE 802.3x Flow Control
SMC8504T
Product Description
SMC8504T 4-port Unmanaged Layer 2 + Gigabit Switch
0101001100100100010010110010101010011010010
SPECIFICATIONS
Ports
SMC-EZ8504T
• 4 10/100/1000Mbps RJ-45 Auto-sensing ports
Network Interface
• RJ-45:100ohm,UTP/ STP cable
• 10/100Base – EIA/TIA Categories 3 or 5 cable
• 1000Base – EIA/TIA Categories 5,4 pairs
LEDs
• 1000Mbps – one per port
• 100Mbps – one per port
• 10Mbps – one per port
• FDX/ COL (full duplex/ collision) – one per port
• Act (activity) – two per port (TX,RX)
Switching Method
• Store – and – forward
MAC AddressTable
• 32K entries
Memory Buffer
• 8Mbyte per unit
Filtering/ Forwarding/ Learning Rates
• Full line rate
Size
• 12.99 x 8.66 x 1.73 in (33 x 22 x 4.4 cm)
Weight
• 4.18 lbs (1.9kgs)
Temperature
• Operating:32° to 122˚F (0° to 50˚C)
Humidity,non-condensing
• 5% to 90%
Power Requirements
• Universal AC input:100 to 240VAC,50 to 60 Hz
Maximum Current
• 0.2A ¢N110VAC
• 0.1A ¢N240VAC
Standards
• IEEE 802.3 Ethernet
• IEEE 802.3u Fast Ethernet
• IEEE 802.3z Gigabit Ethernet
• IEEE 802.3x Flow Control
EMC/ Safety Compliances
• CE Mark
Emissions
• FCC Class A
Safety
• UL
Warranty
• Limited Lifetime
Switches/Hubs
EZ SwitchTM 10/100/1000
4-port Unmanaged Layer 2 + Gigabit Switch
