Overview
AdvancedFeatures
• Easy migration- 6 10/100/1000 ports
Convenient Expansion – Each unit comes
with 2 slots for GBICs for fiber or copper
connections and network expansion
• QoS expedites critical data via prioritizing
and filtering
• MultiLink Trunking creates high-speed data
paths to servers or other switches
• VLAN Support provides port VLANs and GVRP
for auto-registration
• IGMP Snooping reduces multicast traffic for
maximum performance
• Broadcast storm control allows a user-defined
threshold to limit broadcast traffic
Benefits
• EliteView,SMC’s full-features,Windows-based SNMP
management software,included free
• Manage and configure the TigerSwitch 1000
from any Web-browser
•4 group RMON support for detailed monitoring of
network performance
• RS-232 port available for out-of-band direct or
remote management
• Mirror port traffic from any port for easy
troubleshooting
• Spanning Tree protocol creates resilient links for
increased stability
• Optional redundant power unit provides
maximum uptime
Compatibility
• IEEE 802.3 Ethernet
• IEEE 803.3u Fast Ethernet
• IEEE 803.3z Gigabit Ethernet
• IEEE 802.1d Spanning Tree Protocol and
traffic priorities
• IEEE 802.1P Priority Tags
• IEEE 802.1Q VLAN
• IEEE 802.3ab Gigabit
• IEEE 802.3ac VLAN Tagging
• IEEE 802.3x Full-duplex flow control
• IEC 8802-3
• SNMP(RFC 1157),RMON (RFC 1757),ARP
(RFC 826),
• IGMP (RFC 1112),MIB II (RFC 1213),
Ethernet-like MIB
• (RFC 1643), Bridge MIB (RFC 1493)
TheTigerSwitch 1000 makes gigabit affordable by pro-
viding 6 Auto-MDIX10/100/1000 BASE-T ports,and 2
hot-swappable GBIC slots for fiber connectivity.
Without rewiring your existing network, SMC8606T
brings gigabit connections for bandwidth starved
workstations, workgroups, and servers. It is a worthy
investment for the long run.
SMC8606T delivers non-blocking switching perform-
ance, with advance features like Quality of Service,
VLAN support,MultiLinkTrunking to provide maximum
performance benefits while maintaining security and
reducing network problems. Spanning Tree support,
redundant power lower the total cost of ownership.
SNMP, RMON and a full-featured Web based the
TigerSwitch 1000 is further backed by a comprehen-
sive limited lifetime warranty and SMC’s award winning
free technical support.
Model Number::
TigerSwitchTM 1000
6-Port Gigabit 10/100/1000 Managed Standalone L2 Switch
SMC8606T
Switches/Hubs
6 H u g h e s
Irvine, CA 92618
1-800-SMC-4YOU
www.smc.com

SMC8606T
Switches/Hubs
Ports
• 6 10/100/1000BASE-T ports
• 2 GBIC slots for media expansion
NetworkInterface
• 10BASE-T:RJ-45 UTP Cat. 3,4,5
• 100BASE-TX:RJ-45 UTP Cat.5
• 1000BASE-T:RJ-45 UTP Cat.5
BufferArchitecture
• 2Mbps per 1000Mbps port
Aggregatedbandwidth
• 16Gbps
SwitchingDatabase
• 8K MAC address entries
LEDs
• System (power,RPU, Diag.)
• Port (full duplex,activity)
• Link (speed,link,disable/partition)
Weight
• 10.14 Lbs (4.6Kg)
Size
• 17.37x 11.22 x 1.69 in
Temperature
• Operating:32 – 122F
• Storage:-40 – 158 F
Humidity
• Operating 5% to 95%
(non-condensing)
ACInput
• 100 to 240V ,50-60 Hz
PowerSupply
• Internal,auto-ranging transformer:
100 to 240VAC,50-60 Hz
Redundant DC input
PowerConsumption
• 70W Max.
HeatDissipation
• 239 BTU/hr
MaximumCurrent
• 0.5A @ 110VAC,0.7 A @ 240VAC
MTBF
• 6 years (estimated)
SwitchFeatures
• Spanning Tree Protocol
• Forwarding Mode
• Store-and-forward
• Flow Control
• Full Duplex:IEEE802.3x
• Half Duplex:back pressure
• VLAN Support
• Up to 256 groups; port-based or
with 802.1Q
• VLAN tagging,GVRP for automatic
VLAN learning (future support)
• Quality of Service
• Supports two levels of priority and
weighted fair queueing
• Broadcast storm control
• Link Aggregation
• Port Mirroring
ManagementFeatures
• In-Band Management
•Telnet,SLIP,Web-based HTTP,or
SNMP manager
• Out-of-Band Management
• RS-232 DB-9 console port
• Software Loading
•TFTP in-band or Xmodem out-of-band
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC
1493),Ethernet-Like MIB (RFC 1643),
RMON MIB (RFC 1757),SMC’s private
MIB
• RMON Support
• Groups 1,2,3,9 (Statistics,History,
Alarm,Event)
Standards
• IEEE802.3 Ethernet, IEEE802.3u
Fast Ethernet,
• IEEE802.1D Spanning Tree Protocol
and traffic priorities,
• IEEE802.1Q VLAN
• IEEE802.1P priority tags
• IEEE802.3x full-duplex flow control
• IEEE802.3z Gigabit Ethernet
• IEEE802.3ab Gigabit Ethernet
• SNMP (RFC 1157),RMON (RFC 1757),
ARP (RFC826),IGMP (RFC 1112),MIB II
(RFC 1213),Ethernet-like MIB (RFC
1643),Bridge MIB (RFC 1493)
Compliances
• CE Mark
• Emissions
FCC Class A
Industry Canada Class A
EN55022 (CISPR 22) Class A
VCCI A
C-Tick – AS/NZS 3548 (1995) Class A • Immunity
• IEC 1000 – 4 –2/3/4/6
• Safety
CSA/NRTL (CSA22.2.2950 & UL
1950),EN60950 (TUV/GS)
Warranty
• Limited Lifetime
SMC8606T 6-Port Gigabit 10/100/1000 Managed Switch with GBIC’s Uplinks
SMCBGSSCX1 1-Port multi-mode 1000BASE-SX 850nm GBIC transceiver
SMCBGLSCX1 1-Port single-mode 1000BASE-LX 1310nm GBIC transceiver
SMCRPU150W Redundant Power Supply
Product Description
TigerSwitchTM 1000
6-Port Gigabit 10/100/1000 Managed Standalone L2 Switch
