This manual describes how to install and use SMC’s EZHub 10/100. It
features 5,8 or 16 10/100 Mpbs Auto sensing ports, and provides the
flexibility to fit into your working space with network environment. The
EZ Hub 10/100 can be used to connect with PCs, servers, hubs, bridges,
other switches and routers. It can also act as a bridge between 10Mbps and
100Mbps networks segments.
This EZ Hub supports 10Mbps and 100Mbps dedicated bandwidths in
each port. The hub is built with plug & play, auto-sensing on all ports, as
well as half and full-duplex operations, store-and-forward transmission
scheme, IEEE802.3x flow control and back pressure operation for easy
installation and smooth transition from legacy 10Mbps to 100Mbps
Ethernet networks. All ports support MDI/MDI-X to facilitate your
network expansion.
Description of Hardware
SMC’s EZ Hub™ 10/100, SMC-EZ5805DS, SMC-EZ5808DS and
SMC-EZ5816DS, are compact dual-speed hubs featuring 5/8/16
10BASE-T/100BASE-TX auto-sensing ports. These hubs provide an ideal
bridge between 10 Mbps and 100 Mbps Ethernet networks.
Features and Benefits
• IEEE 802.3 and 802.3u compliance ensures compatibility with
standards-based hubs, switches and cards from any vendor
• 8/16 dual-speed 10/100 Mbps auto-sensing ports
• Plug and play—nothing to configure

I NTRODUCTION
2
• Built-in wiring crossovers on all ports allow connections to servers and
workstations to be made with straight-through cabling
• “At-a-glance” LEDs for port and system status monitoring
• Jabber lock-up function automatically stops transmission of abnormal
frames to prevent network disruption
• Automatic polarity detection and correction
• Desktop installation
Front Panel LEDs
The front panel of the hub provides status LEDs for “at-a-glance” system
monitoring. The following table details the functions of the various
indicators:
Port and Hub Status LEDs
LEDs Condition Status
Power Green Hub is receiving power.
Speed Green Indicates that the port is
transmitting or receiving data at 100
Mbps.
Off Indicates that the port is
transmitting or receiving data at 10
Mbps.
Link/Activity Green Indicates a valid network
connection between the port and
the attached device.
Off Indicates no network connection
established between the port and
the attached device.
Flashing
Green
Indicates that the port is
transmitting or receiving data.

I NTRODUCTION
3
SMC-EZ5805DS
SMC-EZ5808DS
SMC-EZ5816DS
Rear Panel
These EZ Hub 10/100 models feature 5/8/16 10BASE-T/100BASE-TX
ports with RJ-45 connectors located on the rear panel of the hub. Each
port contains a built-in wiring crossover (MDI-X) that allows for the use
of straight-through twisted-pair cable for connections to devices without
built-in crossover ports (i.e., workstations, printers, etc.).
The DC power receptacle is also located on the rear panel of the hub.

I NSTALLING THE H UB
4
I NSTALLING THE H UB
The EZ Hub 10/100 can be placed on a desktop or shelf and stacked with
other devices using the provided 4 rubber foot pads
Equipment Checklist
After unpacking the EZ Hub 10/100, check the contents of the box to be
sure you’ve received the following components:
• EZ Hub 10/100 SMC-EZ5805DS, SMC-EZ5808DS or
SMC-EZ5816DS
• Appropriate DC power adapter
• Four rubber foot pads
• SMC Warranty Registration Card
•ThisUserGuide
Selecting a Site
Be sure to follow the site selection guidelines below when choosing a
location:
• Select a suitable location for the hub:
• It should be accessible for installing, cabling and maintaining the
hub.
• The temperature and humidity should be within the ranges listed
in the specifications.
• The status LEDs should be clearly visible.

I NSTALLING THE H UB
5
• There should be adequate space (approximately two inches) on all
sides for proper air flow.
• Make sure twisted-pair cable is always routed away from power lines,
fluorescent lighting fixtures and other sources of electrical interference
such as radios, transmitters, etc.
• Make sure that a properly grounded power outlet is within 8 feet (2.44
meters) of the hub and is powered from an independent circuit
breaker. As with any equipment, using a filter or surge suppressor is
recommended.
Instructions
1. Positioning the Hub: For desktop or shelf mounting, attach the four
adhesive foot pads to the bottom of the hub.
2. Applying Power: Plug one end of the power adapter into the socket
on the hub’s rear panel, and the other end into an appropriate electrical
outlet. Check the Power LED to be sure power is on.
Note: It is not necessary to power off the hub before connecting or
disconnecting any UTP cables, as these actions will not disrupt
the operation of other devices attached to the hub.
3. Connecting PCs: Connect each PC to an RJ-45 port on the hub
using a straight-through twisted-pair cable segment, maximum 100
meters (328 ft.). The EZ Hub 10/100 will support up to 5/8/16 PCs.
4. Cascading Hubs and Other Network Devices: If you need more
ports, connect a crossover port on another device to the Uplink port
on the hub using straight-through twisted-pair cable, maximum 100
meters (328 ft.). Note for the SMC-EZ5808DS, if you are using the
Uplink port you cannot use the fixed crossover Port 8. Also for the
SMC-EZ5816DS, be sure to select the Uplink option via the
push-button switch on Port 16.

S AMPLE A PPLICATIONS
6
S AMPLE A PPLICATIONS
Some typical applications for the EZ Hub 10/100, SMC-EZ5805DS ,
SMC-EZ5808DS and SMC-EZ5816DS are illustrated below:
Standalone LAN
Desktop PC
Printer
Notebook PC
Scanner

S AMPLE A PPLICATIONS
7
Cascading Hubs
100 Mbps
Servers
100 Mbps
Server

T ROUBLESHOOTING
8
T ROUBLESHOOTING
1. Symptom
Power LED does not light after power on.
Probable Causes
Power outlet or power cord may be defective.
Possible Solutions
• Check for loose connections.
• Check the power outlet by using it for another device.
• Replace the power cord.
2. Symptom
Link LED does not light after connection is made.
Probable Causes
Hub port, network card or cable may be defective.
Possible Solutions
• Check that the hub and attached device are both powered on.
• Be sure the network cable is connected to both devices.
• Verify that Category 5 cable is used for 100 Mbps connections and
that the length of any cable does not exceed 100 meters (328 feet).
• Check the network card and cable connections for defects.
• Replace the defective card or cable if necessary.

C ABLE S PECIFICATIONS
9
C ABLE S PECIFICATIONS
Cable Type and Connector
RJ-45 Connector Pin Assignments
Caution: DO-NOT plug a phone jack connector into any RJ-45 port.
Use only twisted-pair cables with RJ-45 connectors that
conform with FCC standards.
An Ethernet or Fast Ethernet twisted-pair link segment requires two pairs
of wires. Each wire pair is identified by two different colors. For example,
one wire might be green and the other, green with a white stripe.
Each wire pair must be attached to the RJ-45 connector in a specific
orientation as detailed below.
10BASE-T Cable
Type Length Connector
Category 3, 4, 5 UTP 100 m (328 ft) RJ-45
100BASE-TX Cable
Type Length Connector
Category 5 UTP 100 m (328 ft) RJ-45

C ABLE S PECIFICATIONS
10
Note: The “+” and “-” signs are used to represent the polarity of the
wires that make up each wire pair.
RJ-45 Pin Assignments
Straight-Through Cable
RJ-45 Pin Assignments
Crossover Cable
End 1 End 2 End 1 End 2
1 (Tx+) 1 (Tx+) 1 (Tx+) 3 (Rx+)
2 (Tx-) 2 (Tx-) 2 (Tx-) 6 (Rx-)
3 (Rx+) 3 (Rx+) 3 (Rx+) 1 (Tx+)
6 (Rx-) 6 (Rx-) 6 (Rx-) 2 (Tx-)
