Smeg CSK1215FLEX User manual

CSK1215FLEX
WASHING TROLLEY
FOR WASHER DISINFECTORS
USE AND MAINTENANCE MANUAL
TRANSLATION OF THE ORIGINAL INSTRUCTIONS

CSK1215FLEX
USE AND MAINTENANCE MANUAL
2
READ CAREFULLY
This document refers to the Smeg accessory “CSK1215FLEX”.
The accessory can only be installed and used on Smeg devices.
In order for the accessory to be used properly and safely, this manual must be used in conjunction with the manual of
the instrument washer in which it is installed.
Failure to read, understand or correctly interpret the instructions contained in this manual may cause damage to the
appliance, and as well as being a source of danger for the operator, this may considerably reduce the performance of
the machine.
The manufacturer declines all liability for uses other than those indicated in this manual.
Installation, maintenance and repairs must only be carried out by personnel authorised by the
manufacturer.
The guarantee may become void if the device is used in a way other than that indicated by the
manufacturer.
This manual is for informational purposes only. The contents of this manual and the equipment described herein may
be subject to modification without prior notice.
19 390 7445 02
29/08/2019
Rev.
Date

CSK1215FLEX
USE AND MAINTENANCE MANUAL
3
Contents
1DESCRIPTION..............................................................................................................................................................4
2DIMENSIONS .............................................................................................................................................................. 5
2.1 CSK1215 FLEX .................................................................................................................................................... 5
3COMPATIBILITY BETWEEN THE ACCESSORY AND DEVICES........................................................................................6
4PACKAGE CONTENTS..................................................................................................................................................6
5INSTRUCTIONS FOR USE.............................................................................................................................................7
5.1 Preparation for use ........................................................................................................................................... 7
5.2 Using the accessory / positioning the instruments...........................................................................................8
6MAINTENANCE......................................................................................................................................................... 10
7TROUBLESHOOTING.................................................................................................................................................11
8MANUFACTURER’S DETAILS AND TECHNICAL ASSISTANCE .....................................................................................11

CSK1215FLEX
USE AND MAINTENANCE MANUAL
4
1DESCRIPTION
The “CSK1215FLEX” is a washing trolley designed to wash and thermally disinfect surgical instruments and
accessories of various shapes and sizes. It can be used exclusively with Smeg “WD” – washer disinfectors for
hospital use.
This device has been designed to house “DIN” baskets: such as the SMEG “CSKDIN” basket (CSKDIN basket
width x depth: 240 x 480 mm).
The racks can be removed, providing considerable versatility and adaptability for numerous applications.
The baskets are not included with the accessory, they must be purchased separately: please contact your
dealer for details and offers.
Figure 1 –Smeg “CSKDIN” basket 240x480x50 [mm]
The dimensions and spaces available in the trolley are indicated below.

CSK1215FLEX
USE AND MAINTENANCE MANUAL
5
2DIMENSIONS
2.1 CSK1215 FLEX
( * ) = FIXED RACK
Figure 2 –Trolley dimensions and spaces available for positioning the baskets.

CSK1215FLEX
USE AND MAINTENANCE MANUAL
6
3COMPATIBILITY BETWEEN THE ACCESSORY AND DEVICES
The accessory can be installed on the following devices:
WD RANGE –INSTRUMENT WASHERS FOR HOSPITALS
Model WD7015 (and versions based on it)
4PACKAGE CONTENTS
1 “CSK1515FLEX” trolley
The product consists of:
•1 fixed rack (made of stainless steel
wire, welded to the supporting
structure), fitted with a rotating
spray arm that can be removed for
inspection and cleaning.
•2 removable racks with spray arm
•2 rotary guillotine type outlets for
spray arm conduits
•3 water outlets for other
accessories
•1 pressure outlet for additional
testing devices

CSK1215FLEX
USE AND MAINTENANCE MANUAL
7
5INSTRUCTIONS FOR USE
5.1 Preparation for use
•Unpack the accessory.
•Remove sprayer locking plastic pies.
•Remove if present, cable ties or tapes from channels, sprayers or others.
•Place the trolley in the washing chamber.
•Carry out a preliminary cycle before using the machine, with the machine empty. Carry out a full thermal
disinfection cycle.
•Before processing surgical instruments, always consult the instrument manufacturer’s instructions to make
sure they can be treated using automatic thermal disinfection cycles and that they can withstand the
specified wash cycle temperatures.
•To prevent the dirt from drying on the instruments: allow as little time possible to elapse between the
instruments being used and them being washed in the machine.
•Please note: the trolley is fitted with a manifold for distributing the wash water to the various racks. When
looking at the machine from the front, loading side (“dirty” side), the manifold must be on the right hand
side of the chamber.
•When inserting and removing the trolley from the washing chamber, always be careful not to subject the
product to excessive force: slide the trolley along the guides provided avoiding impact and positioning it
correctly so that the water manifold is aligned with the connections in the chamber.

CSK1215FLEX
USE AND MAINTENANCE MANUAL
8
Image for illustration purposes of “DIRTY” SIDE VIEW (LOADING SIDE) of the device:
5.2 Using the accessory / positioning the instruments
The surgical instruments to be processed must be placed carefully in the instrument baskets.
The baskets must be placed inside the washing trolley making use of the racks available.
Basket “CSKDIN”
Procedure
Place the instruments in the baskets so they do not
protrude from the top.
The items to be treated must not be placed on top of
one another.
Surgical instruments with joints must be open so that
even the difficult to reach parts can be properly
cleaned.
WASHING TROLLEY WATER
MANIFOLD VIEW FROM THE
LOADING SIDE: THE MANIFOLD
MUST BE ON THE RIGHT HAND SIDE
OF THE DEVICE.
WASHING TROLLEY
GENERIC DEMONSTRATION TROLLEY

CSK1215FLEX
USE AND MAINTENANCE MANUAL
9
Illustration
Procedure
Make sure that the water outlets are closed when not
in use.
Open the water outlets in order to insert the conduits.
Insert and remove the racks by removing them from
the supports at the side.
Lift the rack and slide it to release it from the side
outlet of the manifold

CSK1215FLEX
USE AND MAINTENANCE MANUAL
10
Test outlet (M8 x 1.25).
6MAINTENANCE
To keep the product in good working order we recommend that you clean it periodically. To do this, completely
disassemble the sprayers and their ends according to the procedures indicated.
BEFORE carrying out cleaning and maintenance it is recommended that you carry out a full thermal
disinfection cycle with the machine empty (with no load inside the chamber).
Disconnect the power supply using the appropriate isolator switch and turn off the water supply tap.
Always wear personal protective equipment when carrying out cleaning and maintenance.
CLEARANCE: In order to carry out work on the machine there must be a clearance of approximately 1m2
in front of the machine.
CAUTION
The spray arms may retain biologically contaminated substances. They must be handled with care and
using protective equipment (e.g. gloves, goggles, overalls).
Recommended cleaning interval, considering a normal use of 3-5 cycles / day: once every 10 days.
Illustration
Procedure
Completely remove the sprayers for cleaning:
- The central pins can be removed: simply unscrew
them from the support. Once the central pin has been
unscrewed, the sprayer can be removed from the rack
for cleaning.
- The ends of the spray arms can be removed for
inspection and cleaning.

CSK1215FLEX
USE AND MAINTENANCE MANUAL
11
Detail of the plastic ends for cleaning:
Remove the first end by simultaneously lifting and
pulling out the tabs surrounding the screws. Use
running water to remove any dirt.
After cleaning, make sure that you reassemble all the
parts correctly. Contact the manufacturer for any
clarifications or spare parts that you may require. Use
only original Smeg spare parts.
7TROUBLESHOOTING
If washing is unsatisfactory.
A) Check that the nozzles / spray arms on the machine are clean –following the procedures described above.
B) Make sure that you follow the cleaning instructions provided by the instrument manufacturer.
C) Make sure that you have selected the correct cycle.
D) Make sure that the machine is working correctly. Check the manual.
E) Check the quantity and quality of the detergents available.
