Snapfon ez-ONE C User manual

Scroll Button
- Home Screen: Enter the
menu
- Use to scroll within the menu
items: PhoneBook/Call History/
SMS/Settings
- to move within an SMS message
Answer/OK-Key
- Make call or answer call
- Within menu: Conrm selection
- During a call press to turn ON/
OFF Speakerphone
End Call/Backspace/Delete/
Power ON/OFF
- ON/OFF: press for 5 seconds
- Hold down for 2 seconds to
return to Home Screen.
Step 9
Setting up Speed Dial Contacts
• Scroll UP 1 time using then press .
• Scroll UP 2 times using then press 2times.
• Scroll to select Speed dial location.
• Press .
• Scroll UP or DOWN using to choose contact
from phonebook
• Press to save.
Step 8
Set up SOS Button
• Scroll UP 2times using until you reach
Settings menu.
• Scroll UP 4times using until you reach SOS
Settings menu.
(This menu is for customizing how you use this feature.)
Scroll to select
• SOS Button - turn ON/OFF the SOS button.
• SOS Siren - turn ON/OFF
• SOS Number - Press to edit 1 of 4 numbers to
be set as emergency contacts.
(These numbers must rst be added to the phonebook
contacts see Step #7)
(we recommend setting 911 as #1 emergency contact)
SOS Message - Press to customize message using
the keypad. Press to save.
(This message comes formated to say
“Emergency, please help!”)
• Enter contacts name using the keypad.
Press to save.
• Number entry screen will appear.
• Enter the 10 digit phone number.
• Press to conrm.
• Press to save.
Step 7
Add a New Contact
• Scroll UP 1 time until you reach the
Phonebook menu, then press .
• Scroll DOWN 1 time until you reach New
Contact then press .
• Text entry screen will appear.
Step 10
Making a call.
Starting with the phone powered on.
• Use the keypad to dial the ten digit phone
number. Press to call.
Receiving a Call
• When the phone rings, press to accept the call.
• To send a call straight to Voicemail press .
• Adjust the call volume by the +/- switch on the left
side of the phone.
Speed dial call
• Press and hold #’s 2- 9 until the contact name
appears on the sceen.
Speaker phone call
• The speaker phone option can be switched ON or
OFF by pressing 2 times during an active call.
End a call
• To end an active call press .
TECHNICAL DATA
Quad band GSM 850/900/1800/1900MHz
Worldphone•Battery:Li-Ion3.7V/1000mAh
Dimensions:103x49x15mmStandby-Time:120h
Weight: 79.6g (With Battery) Talk time: 120min
Quick Start Guide
***Each Step starts from the Home Screen with Time
and Date showing***
Step 1
Make sure that your SIM card is active
Contactyour service providerto make sure your SIM
card has been activated.
Contact your service provider if you have problems
with your SIM card.
Step 2
Inserting SIM Card
Fig. 1 Fig. 2
Fig. 1: To remove battery cover, push down and slide.
Fig. 2:SlideSIMcardinwithgoldcontactfacingdown.
Step 3
Inserting and charging the battery
Fig. 3:Insertthebatteryatananglewiththegold
contacts to the bottom, to the gold contacts in the
battery compartment and press down. Slide cover to
closed position with a ‘click’.
Fig. 4: Insertthechargercableinthesocketonthe
underside of the handset.
During charging: Bars move on display. Full battery:
Bars are solid. (Charge battery for at least 4 hours
before making/receiving rst call!)
Fig. 3 Fig. 4
Step 4
Turning on the Phone
Press and hold the Power button for 3 to 5
seconds until you hear the phone’s start up chime,
the device turns on, and the screen and keypad light
up, then release.
Step 5
Set Time and Date
• Scroll UP 2 times using until you reach the
Settings menu, then press .
• Scroll DOWN 4 times then press .
• Use the to select either AM/PM.
• Scroll DOWN 1 time to enter time using the
keypad.
• Scroll DOWN 1 time to enter the date using the
keypad and press to save.
• Date format (MM,DD,YYYY) Month, Date, Year.
PWR
NO
PWR
NO
PWR
NO
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
#
Step 6
Set up Voicemail (only necessary if you using a newly
activated SIM card)
Hold down the #1 key for 3seconds until the
Voicemail is dialed, listen to and follow the
instructions given by your service provider to set up
Voicemail and record your personal greeting.
*Please contact your service provider for questions
concerning your voicemail.
Please Note:
The Name and Phone Number must already be saved
as a Contact before you can assign them a Speed Dial
or Emergency Contact number in the SOS Settings.
Saving a new entry directly to a Speed Dial key or SOS
contact is not possible.
The #1 is reserved for accessing your voicemail.
ez-ONE C
0 - Key
- For SMS: Space
- Press & Hold for Speakerphone
# - Key
- For SMS formating: Switch
between capital, small letters &
numerals
- Radio Seek DOWN
- Change text entry mode
- Key (Text Characters,
Radio Seek)
- Main Screen:
- Press and Hold for inserting:
+,P,W,* (ex. country prex, e.g.
“+39”forITALY)
- Radio Seek UP
-For SMS: Special characters
, . ? ; : ! “ ’@ _
1 - Key (Voicemail)
- Press and hold to dial voicemail
Volume Control + / -
Change the handset
volume (call, ringer, or
radio)
Radio
- Switch up: Radio ON
- Switch down: Radio OFF
Flashlight
- Switch up: Flashlight ON
- Switch down: Flashlight OFF
Keypad Lock
-Switchup:LockOFF
-Switchdown:LockON
Emergency call button
(S.O.S. button)
Battery door release
(Press and slide down)
PWR
NO
High intensity LED Flashlight
- Switch up: Flashlight ON
- Switch down: Flashlight OFF
Lanyard Connection
-ForusewithoptionalLanyard
Power Port
- Use only included Snapfōn Wall Charger or optional
SnapfōnCarCharger.(Input100-240VAC-50/60hz,
0.3AMAXOutput:5.0VDC/500mA)
Headphone Port
- Use only included Snapfōn earphones,
orNokia3.5mmearphones.
FM Radio Home Screen
Home Screen Status Indicators
Home Screen

RADIO
ON: Switch on the left side upwards.
OFF: Switch on the left side downwards
Channel List
Use the Auto Search below to auto ll your channel
list. To select your station use to scroll through the
stations available in your area and press to select.
Manual Entry
Ifthedesiredstationisknown,enterstationnumber
with the numeric keypad, use to enter the point.
Scroll through the frequency values using to tune
into the desired station.
Auto Search
Press then press UP to reach the Auto Search
Menu. Press twice to begin to search available
stations in your area. When the Search is complete
the stations available in your area will be saved to
the phone memory and you can scroll through the
stations using the number buttons on the keypad. The
strongest stations will be available in your Channel
List by scolling UP/DOWN and pressing to select.
When you switch your radio o and on again, you are
on the last heard station again.
Change volume: (does not function when in Auto
Search) with + / - on the left side of the telephone.
Headphones: You can use the radio with and without
headphones. (Note: you will get better radio reception
with the headphones plugged in.)
(Only Snapfōn and Nokia 3.5 mm earphones are
compatible.)
SMS MESSAGES
SMS(ShortMessageService)or“TextMessages”are
writtenmessageswithamaximumof160characters.
•Write new SMS: Press UP 3times to Messages
and then press , Press again to select Create
Message.
Entering a Phonebook contact or creating an SMS
message using the keypad.
Use the keys for the letters in the order they appear.
For example, Press 2 twice for B
To create a space between words use the 0 key
Use the * key to add characters, for example: . , !‘ “ ( )
ScrolltoselectthenpressOKtoadd.
To switch to a dierent entry mode press the # key.
The entry mode is indicated in the upper left-hand
corner of the text entry screen.
ABC =CAPITOLLETTERS
abc = lower case letters
ES =SPANISHCAPITOLLETTERS
es = spanish lower case letters
123 = Numerals
Use the to delete a character.
Use the scroll button to edit within the screen.
•After composing your message, send the message
by pressing twice, enter the number or dial from
the PhoneBook by pressing , scroll through names
to select, press to view number, press to send.
•Receive SMS: A short signal and a registration on
the display will inform you about an incoming SMS
message.
With you can read the message immediately or see
a list of messages which have already been received
in the menu by going to the SMS menu, press
press DOWN and then press to select Inbox,
use the arrow keys to scroll messages and press to
select and view.
SMS Message Tones: Press twice then press ,
on Settings menu, press the DOWN 1time to
Tone setting and press . Press DOWN 1 time
to select SMS and press , use to select the alert
tone you would like to hear for your incoming SMS
messages and press to save.
WARRANTY & RETURNS
TheSnapfōnezONE,iswarrantedagainstdefect,
malfunction, and product failure for one year
from the date of purchase. The warranty covers
problems or defects that are a result of normal
usage. The accessories are warranted to be free from
malfunction or defects for 90 days.
This warranty does not apply to damage done to the
phone by shipping, misuse, abuse, neglect, accident,
or exposure to any type of moisture. The phone
should be disconnected from its charger during
thunderstorms, or events that can cause power
surges.Itisnotwarrantedagainstdamagefrom
voltage uctuations. The battery is not covered under
this warranty, due to its expendable nature. The
battery is guaranteed to be functioning at time of
purchase only. The phone warranty is void if batteries
other than Snapfon authorized or recommended
batterieshavebeenused.Ifaproblemdevelops
due to a third party battery, or charging adapter
please contact the manufacturer of that accessory
forredressorcompensation.Ifaproblemdevelops
during the warranty period, please contact us and we
will either repair or replace it with a new/refurbished
unit,orissuearefund.Ifwechoosetorefundyour
purchase it may be prorated based on use and
condition of the returned merchandise.
The shipping charges for returning a working phone
to you are covered by the warranty. The product
should be returned with all the accessories, with
clear return shipping instructions that include your
address, phone number, and a detailed description of
the reason for the return.
All returns must be approved prior to
shipment, and an RMA (Returned Merchandise
Authorization) number should be present on
the package or the shipment may be refused.
Warranty approval and RMA’s can be requested
via email, or telephone.
Non-Defective Returns:
The product must be returned within 30 days of
purchase, in exactly the condition it was received,
“AS NEW,” with 100% of all shipping, packing,
parts, accessories, manuals, etc. in order to be
considered for a refund.There will be a minimum
restocking fee of 25% applied to all returns that
are not received in“AS NEW”condition.
SAFETY INSTRUCTIONS
Switch o mobile telephone in hospitals or near
medical devices. There should be a minimal distance
between pacemakers and switched-on telephones.
Do not operate a vehicle while holding a mobile phone
in your hand. Follow the laws and trac rules of the
country you are in. The mobile phone is to be switched
o while you are in an airplane. The telephone is to
be switched o near gas stations or other areas with
explosive materials. Never shine the LED- ashlight
intotheeyesofhumansoranimals!(Protectionclass3)
INTENDED USE
This mobile telephone is durable and intended for
mobile use. It is to be protected from moisture and
impacts. Do not expose to prolonged direct sunlight.
Improper use may lead to damage of product and
could be associated with hazards such as electrical
shock or re. The entire product may not be altered
or rebuilt, nor may the housing be opened. The power
adapter is designed for use in household wall outlets
withpublicelectricitygridsof100-240VAC-50/60Hz.
REPLACEMENT PARTS
www.snapfon.com (store) OR
www.snapfon.com/catalog/index.php
FREQUENTLY ASKED QUESTIONS
•WhatserviceproviderswillworkwithSnapfōn?
This is a quad band GSM phone, that uses these
frequencies GSM 850/900/1800/1900. You must use
anunlockedSIMcardfromaserviceproviderthat
operates with these frequencies. Snapfōn will not
work with CDMA service providers.
•Screenshows“NoSIMcard!“: Check the direction
oftheSIMcard(Gold contact facing downwards)
•Acallfailed: Check the selected telephone
number and area code again for accuracy (area code
entered?)
•Themobiletelephonedisplayisblank/black:
Telephone is in energy saving mode: press any key.
Oritisswitchedo-Holdfor5 seconds to switch
on.
•Themobilephonedoesnotreact:
Remove battery, Re-insertandswitchdeviceon.If
there is still no reaction, refer to the service center.
•Thechargingproceduredoesnot
begin: This can take severalminutes.Ifthereisno
function after 10 minutes, contact sales agent or
manufacturer.
•Whatisthepointsizeofthescreenfont?
The point size of the font is 28 points.
•Whatisthepointsizeofthecontactlist?
Thecontactlistusesa16pointfont.
•Howmanycontactsdoesthephonehold?
The phone memory can hold 200 contacts, however
thephoneusesthecontactsstoredontheSIMcard
which also holds 200 contacts, The benet of the
phone storage is that you can copy your contacts to
the phone so if you decide to switch carriers in the
future, you can copy the contacts from the phone to
theSIMcardwiththenewservice.
•WhatarethesizeofthekeysontheSnapfon?
The number keys are 5/8 inch square.
•WhatdoIdoifmyphoneshowsamissedcall?
Press to view missed call or press to save and
view later.
•WhatdoIdoifmyphonesaysIhaveavoicemail.
Press to connect to the voicemail system or press
to save voicemail and listen to it later.
•WhydoIseean!onmyscreenandhaveno
sound?
The call you were attempting to make failed. Try your
call again.
Press and hold the orange SOS button, located on
the back of the phone, for 5 seconds
A siren will sound alerting the emergency. The siren
can be turned o if desired, see Step #8
ImmediatelythephonewillsendtheEmergency
SMS Message to the Emergency Number(s) stored
previously see Step #8
Next the phone will begin dialing in stored sequence
the Emergency Number(s).Iftherstcallisnot
connected it will call the second number and so on...
When the call is connected the Speakerphone is
activated.
Very Important: This phone does not know the
dierence between a person, an answering machine
or a voicemail answering the phone. We recommend
using 911 or your local emergency center as the rst
Emergency Number. This way the person having
the emergency will speak to Emergency services and
the other Emergency Number (s) will receive an
Emergency SMS message to alert the emergency.
NOTE: If you want to save emergency numbers like
emergency services, police, re department, etc... you
must clarify this with each institution. No liability will be
assumed by Snapfōn for possible costs incurred if you
dial accidentally.
Device Disposal: When this product is eventually taken
out of service, please do not dispose in the household
trash. Take care of the environment by bringing it to
a collection area where old devices are accepted and
brought into an environmentally friendly disposal/
recycling procedure.
DISPOSAL
Disposal of packaging: Packaging and
packaging aids are recyclable and should
be entered into the recycling process.
Battery disposal: Batteries do not belong
in the household trash! As a consumer,
you are obligated to return used batteries.
These can be handed into local collection
areas or to specialty shops.
OK
OK
OK
OK
OK
OK
OK
OK
OK OK
OK
OK
OK
OK
OK OK
OK
OK
OK
OK
PWR
NO
PWR
NO
PWR
NO
#
Press and Hold for
5seconds to activate.
(NOTE: The SOS Button is not activated by default on a
new Snapfōn. To activate the SOS Button,
Please follow Steps #7 and #8)
Using the SOS Button
Snapfon
1222 Tremont Street, Suite 100
Chattanooga, TN 37405
423-535-9968
www.snapfon.com
[email protected]
PWR
NO
