Snell IW-J7 User manual

IN-WALL VERSION OF OUR J7, PERFECT FOR MUSIC AND HOME THEATER
The IW-J7 is Snell’s J7 monitor, re-engineered for flush-mount use. As you
would expect, many of the features developed by Snell over the past 30 years,
are in full use. To achieve the performance capabilities of a freestanding
monitor, this new design overcomes the three factors limiting all in-wall
speakers. First, to insure predictable response, regardless of placement or
wall type, the IW-J7 has been designed with an integrated and sealed,
aluminum enclosure, which, like all conventional loudspeakers, determines
the speaker’s bass response. Second, superior materials are used in the
IW-J7 to control resonance. Where other in-walls are open-backed and made
of plastic, we mount our J7 drivers to a specially damped MDF baffle,
constructed in three layers to enhance bass/midrange clarity and deaden wall
resonance. The baffle secures to a well-damped, heavy gauge aluminum
enclosure. Third, most flush mount speakers cannot reproduce a
proper soundstage. To assure the spatial realism found only in
high-performance monitors, the IW-J7’s low-resonance, silk dome tweeter
has incredible dispersion, well into the voice range. For enhanced
performance a new crossover was designed to “tune” the IW-J7 to its in-wall
boundary, and uniquely extend bass in a small volume cabinet.
The precision crossover is hand tuned to guarantee performance to within a
remarkable 0.5dB of the Reference Master.
Design:
Infinite Baffle, Back-Boxed,
In-Wall Monitor
Frequency Response
66Hz-20kHz ± 3dB
Sensitivity
[1 Watt (2.83v) @ 1m] 87 dB
Impedance
Nominal 8 Ohms
Maximum Output
105 dB
Recommended Power
50 Watts Minimum
150 Watts Maximum
Tweeter
1-inch SEAS silk dome
Woofer
6.5-inch poly5mm excursion
Crossover Frequency
2.5 kHz
Crossover
Discrete tweeter, and woofer
circuits. Time alignment
and coherency are achieved
through the transition region
from driver to driver. Each
crossover is individually tuned
by our technicians to ± 0.5db of
the Master Reference.
Cabinet Construction
Enclosure – Solid aluminum, acoustic
suspension cabinet with asphalt damping.
Baffle – QuietBoxTechnology™ Hi-loss
damping adhsive sandwiching two layers
of 1/4-inch MDF. Mounting system – four
"dog-leg" clamps for mounting surfaces
1/2 to 1-1/2-inch thick.
Connections
Spring loaded gold-plated terminals,
accepts twins, banana plugs and bare wire
to 12 gauge.
Grille
Perforated steel with white powder-coat paint.
Finishes
Paintable white finish. Can be ordered in
most paint finishes.
Weight
9 lbs.
Manufactured in the USA by Snell Acoustics, Peabody MA 01960 • www.snellacoustics.com • 978-538-6262 • © Snell Acoustics, Inc • All specifications subject to change without notice.
IW-J7
Premier Series
Application Alternatives: System Suggestions:
IW BASIS 150
Subwoofer
IW SR7Surround
Dimensions:
Rough in
15 7/8”High
9 3/8”Wide
Like all Snell loudspeakers, each IW-J7 is hand tuned for natural imaging and sonic depth.
J7 In Room
Dimensions:
Finish
17”High
10 1/2”Wide
3. 3/4”Deep
