Snorkel TB66J Owner's manual

September 2015
Part Number 0083734
MANUAL
REPAIR PARTS
Manufactured 02-01 and after
Models TB66J/TB66JRT
Replaces 0083734 March 2014

GENERAL INFORMATION
REPAIR PARTS
STEERING INSTALLATION 4X2 TB60 TB65J TB66J 2-1
FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER 2-2
DRIVE 4X2 4X4 INSTALLATION OCTOBER 2006 AND BEFORE 2-3
DRIVE 4X2 4X4 INSTALLATION NOVEMBER 2006 AND AFTER 2-4
CHASSIS COVER INSTALLATION 4X4 2-5
CHASSISS TURNTABLE MOUNTING 2-6
COUNTERWEIGHT SUBASSEMBLY 2-7
TURNTABLE ASSEMBLY KUBOTA 2-8
LIFT SWING COUNTERWEIGHT 2-9
ENGINE TRAY CUMMINS 3.3 65HP ASSEMBLY JANUARY 2001 AND AFTER 2-10
ENGINE TRAY CUMMINS 3.3 TIER 3 JUNE 2007 AND AFTER 2-11
ENGINE TRAY CUMMINS 3.3 TIER 3 FEBRUARY 2013 AND AFTER 2-12
ENGINE AND RADIATOR ASSEMBLY CUMMINS JULY 2008 AND BEFORE 2-13
ENGINE AND RADIATOR ASSEMBLY CUMMINS 3.3 TIER 3 AUGUST 2008 AND AFTER 2-14
RADIATOR CUMMINS 3.3 ASSEMBLY 2-15
AIR CLEANER ASSEMBLY CUMMINS FORD KUBOTA GM 2-16
ENGINE DEUTZ F4L-1011F BEFORE MARCH 2007 AND BEFORE 2-17
ENGINE DEUTZ F4L1011F ASSEMBLY APRIL 2007 AND AFTER 2-18
ENGINE SUB ASSEMBLY DEUTZ F4L1011F FEBRUARY 2009 AND AFTER 2-19
DEUTZ F4L1011F TIER 3 ENGINE MOUNTING 2-20
DEUTZ EXHAUST AND AIR CLEANER INSTALLATION MAY 2014 AND BEFORE 2-21
AIR CLEANER DEUTZ 2-22
SUPERTRAPP MUFFLER ADAPTER 2-23
ENGINE FORD LRG 425 SUB ASSEMBLY 2-24
ENGINE MOUNTING FORD LRG 425 WITH ECM 2-25
ENGINE MOUNTING FORD LRG 425 WITH EPM 2-26
EXHAUST AND AIR CLEANER INSTALLATION FORD NOVEMBER 2004 AND BEFORE 2-27
EXHAUST AND AIR CLEANER INSTALLATION FORD WITH CATALYTIC CONVERTER
DECEMBER 2004 AND AFTER 2-28
ENGINE GM TIER 3 INSTALLATION 2-29
ENGINE GM TIER 3 SUBASSEMBLY 2-30
RADIATOR GM ASSEMBLY 2-31
EXHAUST / AIR CLEANER INSTALLATION KUBOTA 2-32
AIR CLEANER INSTALLATION GM 2-33
AIR CLEANER INSTALLATION GM TIER 3 2-34
ENGINE KUBOTA V2403 SUB ASSEMBLY 2-35
V2403-M-T-E3B-KEA-2F KUBOTA ENGINE WITH RADIATOR REPLACEMENT PARTS 2-36
DRIVE LIFT SWING VALVE ASSEMBLY 2-37
RANGE VALVE SUB ASSEMBLY 2-38
HYDRAULIC OIL RESIVIOR ASSEMBLY 2-39
FUEL TANK INSTALLATION 2-40
HYDRAULIC OIL RESERVIOR ASSEMBLY INSTALLATION 2-41

PLASTIC COWLING INSTALLATION CUMMINS FORD GM TB60 TB66J 2-42
PLASTIC COWLING INSTALLATION CUMMINS FORD GM TB60 TB66J 2-43
PLASTIC COWLING DEUTZ INSTALLATION SEPTEMBER 2006 AND BEFORE 2-44
PLASTIC COWLING DEUTZ INSTALLATION OCTOBER 2006 AND AFTER 2-45
PLASTIC COWLING DEUTZ INSTALLATION OCTOBER 2014 AND AFTER 2-46
STEEL COWLING FORD CUMMINS MAY 2011 AND AFTER 2-47
STEEL COWLING FORD CUMMINS GM KUBOTA INSTALLATION APRIL 2015 AND AFTER 2-48
REAR COWLING STEEL ASSEMBLY 2-49
BOOM ASSEMBLY TB65J 2-50
STEEL COWLING SERVICE KIT GM FORD CUMMINS KUBOTA 2-51
STEEL COWLING SERVICE KIT DEUTZ 2-52
BOOM HOSE CARRIER ASSEMBLY TB65J 2-53
HOSE CARRIER ASSEMBLY TB65J 2-54
BOOM INSTALLATION TB65J 2-55
EXTENSION CYLINDER ASSEMBLY 2-56
JIB ASSEMBLY 5 FOOT 2-57
PLATFORM ROTATOR HELAC JANUARY 2018 AND BEFORE 2-58
PLATFORM ROTATOR ASSEMBLY FEBRUARY 2018 AND AFTER 2-59
PLATFORM ROTATOR ASSEMBLY HELIC WITH OVERLOAD 2-60
PLATFORM INSTALLATION WITH HELAC ROTATOR 2-61
PLATFORM ALUMINUM GRAVITY GATE CE PARKER ROTATOR INSTALLATION 2-62
PLATFORM 8 FOOT ALUMINUM ASSEMBLY WITH SWING GATE 2-63
PLATFORM 8 FOOT STEEL TRI ENTRY ASSEMBLY 2-64
SNORKEL GUARD ASSEMBLY 2-65
PLACARD AND DECALS DECEMBER 2006 AND BEFORE 2-66
PLACARDS AND DECALS AFTER JANUARY 07 AND AFTER 2-67
PLACARDS AND DECALS MAY 2008 AND AFTER 2-68
PLACARDS AND DECALS APRIL 2014 AND AFTER 2-69
HYDRAULICS
CHASSIS HYDRAULIC EQUIPMENT 4X4 NOVEMBER 2006 AND AFTER 3-1
CHASSIS HYDRAULIC EQUIPMENT 4X2 JANUARY 2001 AND BEFORE 3-2
DRIVE MOTOR FRONT WITH OUT BRAKE 4X4 3-3
DRIVE MOTOR REAR WITH INTEGRAL BRAKE 3-4
GEAR HUB HIGH TORQUE AUBURN GEAR TB60-04-000114 AND BEFORE 3-5
FLOW DIVIDER VALVE SUB ASSEMBLY 3-6
DRIVE VALVE SUB ASSEMBLY 3-7
DRIVE VALVE SUB-ASSEMBLY 4X2 3-8
DRIVE SEQUENCE VALVE LEFT HAND 3-9
DRIVE SEQUENCE VALVE RIGHT HAND 3-10
SERIES PARALLEL PACKAGE 4X4 RIGHT HAND 3-11
SERIES PARALLEL PACKAGE 4X4 LEFT HAND 3-12
FLOW DIVIDER VALVE ASSEMBLY 3-13
DRIVE LIFT SWING CONTROL VALVE 3-14
MOTION CONTROL VALVE DRIVE ASSEMBLY 3-15

SELECTOR VALVE 4X2 ASSEMBLY 3-16
SELECTOR VALVE 4X4 ASSEMBLY 3-17
SELECTOR VALVE LEFT HAND ASSEMBLY 3-18
SELECTOR VALVE RIGHT HAND ASSEMBLY 3-19
ANTI CAVITATION VALVE ASSEMBLY 3-20
ANTI CAVITATION VALVE 3-21
TURNTABLE HYDRAULIC EQUIPMENT JANUARY 2001 AND AFTER 3-22
TURNTABLE HYDRAULIC EQUIPMENT JAMUARY 2001 AND AFTER 3-23
TURNTABLE HYDRAULIC EQUIPMENT APRIL 2007 AND AFTER 3-24
EMERGENCY POWER UNIT 3-25
EMERGENCY POWER UNIT WUXI DELI APRIL 2016 AND AFTER 3-26
NON PROPORTIONAL CONTROL VALVE ASSEMBLY VICKERS JANUARY 2001 AND AFTER 3-
27
NON PROPORTIONAL CONTROL VALVE VICKERS JANUARY 2001 AND AFTER 3-28
NON PROPORTIONAL CONTROL VALVE ASSEMBLY FLUIDTECH OCTOBER 2007 AND AFTER
3-29
NON PROPORTIONAL CONTROL VALVE FLUID TECH OCTOBER 2007 AND AFTER 3-30
ACCUMULATOR ASSEMBLY 300 PSI 3-31
CHECK VALVE 3-32
HYDRAULIC PUMP ASSEMBLY MAY 2018 AND BEFORE 3-33
HYDRAULIC PUMP ASSEMBLY JUNE 2018 AND AFTER 3-34
PISTON PUMP HENGLI SEPTEMBER 2019 AND AFTER 3-35
HYDRAULIC OIL RESERVOIR AFTER JULY 2006 3-36
DUMP VALVE 3-37
SWING DRIVE ASSEMBLY MARCH 2006 AND BEFORE 3-38
SWING DRIVE ASSEMBLY APRIL 2006 AND AFTER 3-39
MOTION CONTROL VALVE TURNTABLE SWING FLUIDTECH 3-40
MOTION CONTROL VALVE TURNTABLE SWING WILLIAMS 3-41
CENTERPOST AND FITTINGS SUB ASSEMBLY NOVEMBER 2017 AND AFTER 3-42
CENTERPOST AND FITTINGS SUB ASSEMBLY OCTOBER 2017 AND BEFORE 3-43
JIB PLATFORM SELECTOR VALVE ASSEMBLY 3-44
JIB PLATFORM SELECTOR VALVE 3-45
LEVEL OR STEERING CYLINDER ROSENBOOM 3-46
JIB CYLINDER ROSENBOOM 3-47
LIFT CYLINDER ASSEMBLY 3-48
LIFT CYLINDER GBI 3-49
LIFT CYLINDER ROSENBOOM 3-50
MASTER LEVEL CYLINDER ROSENBOOM JANUARY 2001 AND AFTER 3-51
MASTER LEVEL CYLINDER ROSENBOOM 3-52
EXTENSION CYLINDER GBI 3-53
EXTENSION CYLINDER ROSENBOOM 3-54
EXTENSION CYLINDER SEABEE 3-55
SLAVE LEVEL ROSENBOOM / GREEN 3-56
DUAL CROSSOVER RELIEF VALVE 3-57
PLATFORM ROTATOR HELAC SEPTEMBER 2017 AND AFTER 3-58

ELECTRICAL
TURNTABLE ELECTRICAL INSTALLATION CUMMINS TIER 3 TB60 TB66J MAY 2008 AND
BEFORE 4-1
TURNTABLE ELECTRICAL INSTALLATION CUMMINS 3.3 JUNE 2008 AND AFTER 4-2
TURNTABLE ELECTRICAL INSTALLATION DEUTZ F4L-1011F NOVEMBER 2006 AND AFTER 4-
3
TURNTABLE ELECTRICAL INSTALLATION DEUTZ F4L-1011F FEBRUARY 2008 AND AFTER 4-4
TURNTABLE ELECTRICAL INSTALL ATION FORD JANUARY 2001 AND AFTER 4-5
TURNTABLE ELECTRICAL INSTALLATION FORD LRG-425 JANUARY 2006 AND AFTER 4-6
TURNTABLE ELECTRICAL INSTALLATION KUBOTA 4-7
PANEL SUB ASSEMBLY MARCH 2008 AND BEFORE 4-8
DIODE RESISTOR WIRE ASSEMBLY 4-9
LOWER CONTROL PANEL ASSEMBLY CUMMINS 3.3 4-10
LOWER CONTROL PANEL SUB ASSEMBLY CUMMINS 3.3 4-11
LOWER CONTROL PANEL DEUTZ F4L-1011F APRIL 2006 AND BEFORE 4-12
LOWER CONTROL PANEL DEUTZ F4L-1011F MAY 2006 AND AFTER 4-13
LOWER CONTROL PANEL FORD LRG-425 APRIL 2006 AND BEFORE 4-14
LOWER CONTROL PANEL GM TIER 3 4-15
LOWER CONTROL PANEL KUBOTA 4-16
LOWER CONTROL PANEL ASSEMBLY KUBOTA SN TB66J-04-000100 AND AFTER 4-17
LOWER CONTROL PANEL ASSEMBLY KUBOTA CE 4-18
WIRING BOX ASSEMBLY CUMMINS DEUTZ FORD ADDCO 3 SPEED JANUARY 2009 AND
BEFORE 4-19
WIRING BOX ASSEMBLY CUMMINS DEUTZ FORD ADDCO 3 SPEED FEBRUARY 2009 AND
AFTER 4-20
WIRING BOX ASSEMBLY CUMMINS DEUTZ FORD TB60 B66J NOVEMBER 2011 AND AFTER
4-21
WIRING BOX ASSEMBLY FORD LRG-425 SEPTEMBER 2006 AND AFTER 4-22
WIRING BOX ASSEMBLY GM TIER 3 JULY 2007 AND BEFORE 4-23
WIRING BOX KUBOTA ASSEMBLY JUNE 2014 AND AFTER 4-24
WIRING BOX PANEL CUMMINS DEUTZ 3 SPEED JANUARY 2001 AND AFTER 4-25
WIRING BOX PANEL CUMMINS DEUTZ AUGUST 2008 AND AFTER 4-26
WIRING BOX PANEL CUMMINS DEUTZ 3 SPEED OCTOBER 2010 AND AFTER 4-27
WIRING BOX PANEL FORD LRG-425 SEPTEMBER 2003 AND AFTER 4-28
WIRING BOX PANEL GM TIER 3 4-29
WIRING BOX PANEL KUBOTA JUNE 2015 AND AFTER 4-30
ENGINE HARNESS CUMMINS ASSEMBLY JANUARY 2001 AND AFTER 4-31
ENGINE HARNESS DEUTZ JANUARY 2001 AND AFTER 4-32
ENGINE HARNESS FORD EFI 425 APRIL 2004 AND AFTER 4-33
ENGINE HARNESS GM 2.4L TIER 3 4-34
ENGINE HARNESS KUBOTA V2403 4-35
BOOM SWITCH ASSEMBLY 4-36
BOOM ELECTRICAL TB60 TB66J INSTALLATION AUGUST 2008 AND BEFORE 4-37
BOOM ELECTRIC INSTALLATION SEPTEMBER 2008 AND AFTER 4-38
BOOM ELECTRICAL TB66J CE INSTALLATION MAY 2008 AND AFTER 4-39

PLATFORM FOOT SWITCH ASSEMBLY 4-40
UPPER CONTROL BOX ASSEMBLY VICKERS VALVE DUETZ AND CUMMINS MARCH 2008
AND BEFORE 4-41
UPPER CONTROL BOX ASSEMBLY VICKERS VALVE DUETZ AND CUMMINS APRIL 2008 AND
AFTER 4-42
UPPER CONTROL BOX ASSEMBLY VICKERS VALVE DUETZ AND CUMMINS OCTOBER 2008
AND AFTER 4-43
UPPER CONTROL BOX ASSEMBLY GM OCTOBER 2007 AND AFTER 4-44
UPPER CONTROL BOX ASSEMBLY HYDRAFORCE VALVE CUMMINS DUETZ KUBOTA MAY
2008 AND AFTER 4-45
UPPER CONTROL BOX ASSEMBLY KUBOTA S/N TB66J-04-000100 AND AFTER 4-46
UPPER CONTROL BOX ASSEMBLY KUBOTA CE 4-47
CONTROLLER 33HZ LIFT SWING 4-48
CONTROLLER 33HZ DRIVE STEER 4-49
110VAC POWER OUTLET INSTALLATION 4-50
110 220 POWER TO PLATFORM INSTALLATION 4-51
OPTIONS
TOW PACKAGE 5-1
HYDRAULIC WARM UP WITH SYMPLIFIED HYDRAULICS 5-2
GROUND CONTROL DOOR ASSEMBLY 5-3
HYDRAULIC WARM-UP VALVE 5-4
AIR INLET HEATER DEUTZ 5-5
COLD WEATHER PACKAGE DEUTZ 5-6
EXTREME COLD WEATHER PACKAGE DEUTZ 5-7
COLD WEATHER PACKAGE CUMMINS 5-8
COLD WEATHER PACKAGE GM TB60 TB66J 5-9
EXTREME COLD WEATHER PACKAGE GM 5-10
EXTREME COLD WEATHER PACKAGE KUBOTA 5-11
EXTREME ENVIROMENT PACKAGE DUETZ 5-12
EXTREME ENVIROMENT PACKAGE CUMMINS 5-13
HORN INSTALLATION 5-14
ISOLATION VALVE INSTALLATION 5-15
OIL BIODEGRADEABLE 5-16
AIR LINE TO PLATFORM 5-17
HYDRAULIC AC GENERATOR INSTALLATION 110V 5-18
HYDRAULIC AC GENERATOR ASSEMBLY 110V TB60 TB66J 5-19
220V AC GENERATOR INSTALLATION TB60/TB66J 5-20
12KW GENERATOR INSTALLATION 5-21
12 KW GENERATOR ASSEMBLY FABCO 5-22
12 KW GENERATOR ASSEMBLY TENDAIRE 5-23
12 KW GENERATOR VALVE ASSEMBLY 5-24
12 KW GENERATOR WIRING BOX ASSEMBLY 5-25
12 KW GENERATOR CIRCUIT BREAKER WIRING 5-26
12 KW GENERATOR BOOM ELECTRICAL INSTALLATION 5-27
12KW BOOM HOSE CARRIER ASSEMBLY 5-28

12 KW GENERATOR HOSE CARRIER ASSEMBLY 5-29
12 kw GENERATOR HOSE CABLE CLAMP INSTALLATION 5-30
12 KW GENERATOR PLATFORM CONTROL BOX 5-31
DUAL FUEL GM TIER 2 APRIL 2006 AND AFTER 5-32
DUAL FUEL GM TIER 3 SEPTEMBER 2007 AND AFTER 5-33
LP ONLY GM TIER 3 SEPTEMBER 2007 AND AFTER 5-34
DUAL FUEL – FORD LRG-425 5-35
DUAL FUEL FORD ENGINE SUB-ASSEMBLY LRG 425 5-36
LP FUEL ONLY FORD LRG 425 5-37
SPARK ARRESTOR MUFFLER DEUTZ 5-38
DEUTZ DIESEL SCRUBBER 5-39
SANDBLAST KIT OPTION 5-40
DRIVING AND TAIL LIGHTS JUNE 2010 AND BEFORE 5-41
DRIVING AND TAIL LIGHTS JULY 2010 AND AFTER 5-42
WARNING LIGHTS AMBER 5-43
MOTION ALARM DRIVE ONLY 5-44
LIGHT PACKAGE 5-45
ALL MOTION ALARM WITH OUT HORN 5-46
PLATFORM WORK LIGHTS 5-47
PLATFORM WORK LIGHTS 4 HALOGEN 5-48
PLATFORM WORK LIGHTS GLOBAL PLATFORM INSTALLATION 5-49
CSA PACKAGE 5-50
TILT ALARM LIGHT JULY 2005 AND AFTER 5-51
UPPER CONTROL COURTESY LIGHT 5-52
PLATFORM CONTROL BOX COVER TB ATB 5-53
PLATFORM BUMPGUARD SEPTEMBER 2003 AND BEFORE 5-54
PLATFORM BUMPGUARD OCTOBER 2003 AND AFTER 5-55
GLOBAL PLATFORM STANDARD ASSEMBLY WITH SNORKEL GUARD APRIL 2016 ABD AFTER
5-56
LANYARD MOUNT 1430080 PLATFORM ONLY 5-57
PERSONAL FALL ARREST SYSTEM 5-58
GLAZIER TRAY ASSEMBLY 5-59
GLAZIER PACKAGE PLATFORM WITH 1.7 INCH TOE BOARD INSTALLATION 5-60
GLAZIER PACKAGE WORLD PLATFORM WITH 2 INCH TOE BOARD INSTALLATION 5-61
STEEL PLATFORM WITH WELDER 5-62
ALUMINUM PLATFORM WITH WELDER AND 11KW GENERATOR 5-63
WELDER ASSEMBLY 5-64
SWING GATE SIDE MIDRAIL ALUMINUM PLATFORM OCTOBER 2007 AND AFTER 5-65
GRAVITY GATE SIDE ENTRY STEEL PLATFORM 5-66
FLOTATION TIRES 4X4 TB60 TB66J 5-67
FLOATION TIRE ASSEMBLY 5-68
NON MARKING FOAM FILLED TIRES 4X4 5-69
FOAM FILLED TIRES 4X4 TB60 TB66J 5-70
MAINTENANCE

TB66 MAINTENANCE 6-1
SCHEMATICS
TB66J ELECTRICALSCHEMATIC CUMMINS TIER 3 A08143A 7-1
TB66J ELECTRICAL SCHEMATIC CUMMINS TIER 3 A08143BA UPDATED TO REPLACE ADDCO
WITH SOLENOID 7-2
TB66J ELECTRICAL SCHEMATIC CE A08095C ADDED LOAD SENSE 7-3
TB66J ELECTRICAL SCHEMATIC CE A08095D UPDATED LOAD LENSE GROUND LAMP
CONNECTION ADD BOOM ANGLE SWITCH ADD OVERRIDE JUMPER UPDATE LOAD SENSOR
DRIVE BYPASS ENABLE RELAY POWER 7-4
TB66J ELECTRICAL SCHEMATIC CE DEUTZ A08095E 7-5
TB66J ELECTRICAL SCHEMATIC CE DEUTZ A08135A 7-6
TB66J ELECTRICAL SCHEMATIC CE CUMMINS ADDED GLOW PLUG TIMER ASSEMBLY 7-7
PRO66 TB65J TB66J HYDRAULIC SCHEMATIC A08147A 7-8
PRO65 TB65J PRO66 TB66J HYDRAULIC SCHEMATIC 0082092B 7-9
TB60 TB60P PRO65 TB65J PRO66 TB66J HYDRAULIC SCHEMATIC 4 WHEEL DRIVE 0082090A 7-
10
TB60 PRO65 TB65J PRO66 TB66J HYDRAULIC SCHEMATIC 2 WHEEL DRIVE 0082089A 7-11
TB66J HYDRAULIC SCHEMATICS 7-12
A A
B B

REPAIRPARTS
TB65J PARTS MANUAL STEERING INSTALLATION 4X2 TB60 TB65J TB66J
STEERING INSTALLATION 4X2 TB60 TB65J TB66J Wed Feb 24 09:06:05 UTC 2021 2-1

アイテム 部品番号 名前 数量 UOM
- 0080063V STEERINGTB6OTB65JTB66J
4X2INSTALLATION EA
1 0083416 WELDMENTTIEROD 2 EA
2 0083562 WELDMENTSTEERINGARM 1 EA
3 2690001 BUSHING,1INCHSPHERICAL
PLAIN 4 EA
4 0110320 WELDMTPINSTEERINGYOKE 4 EA
5 970239 BLTHEXHD.313-18.750GR5 4 EA
6 9877109 WASHERLOCK.312MDM 8 EA
7 0080348 SPACER,TIERODMOUNTING 4 EA
8 0070442 WLDMTPIN1.505.875GRIP 3 EA
9 0070033 PINLOCK2.00DIA2H 25 EA
10 0070473 BLTHEXHD.313-18.75DR 4 EA
11 9980012 .040S.S.SAFETYLOCKWIRE AR EA
12 5560688 BSHGMCHRY1.50ID2.25OD
14GA 1 EA
13 2502432 BRG1.50ID1.66OD2.00 2 EA
14 0074799 CYL3.509.501.75
LEVEL/STEER 1 EA
15 5065707 FTGADPTRSTRTHD-6B-6SSTL-
PH 2 EA
16 0080098 SPCR.565ID.850OD1.25 1 EA
17 970979 CSCREW,1/2-13X2-1/2LG
HHDGR5 1 EA
18 987139 WSHRLOCK.500 1 EA
19 984149 NUT,.500-13 1 EA
20 0081023 HUBSUB-ASSY 2 EA
21 0080182 PINKING 2 EA
22 5569836 SETSC3/4-10HSKT1-3/4LG 2 EA
23 984469 NUT,3/4-10HEXJAM 2 EA
24 0080183 PINLOCK 2 EA
25 0083571 WELDMENTSTEERINGYOKE 2 EA
TB65J PARTS MANUAL STEERING INSTALLATION 4X2 TB60 TB65J TB66J
STEERING INSTALLATION 4X2 TB60 TB65J TB66J Wed Feb 24 09:06:05 UTC 2021 2-1

画像が存在しません
TB65J PARTS MANUAL STEERING INSTALLATION 4X2 TB60 TB65J TB66J
STEERING INSTALLATION 4X2 TB60 TB65J TB66J Wed Feb 24 09:06:05 UTC 2021 2-1

アイテム 部品番号 名前 数量 UOM
26 5070026 CAPWHEELSERVICE- 2 EA
27 2580001 THRUSTBEARING 2 EA
28 7150003 GREASESEAL 2 EA
29 5560202 NUTHEXJAM1.250-12GR8 1 EA
30 2560006 INNERBEARINGCONE 2 EA
31 0083418 WELDMENTTIERODEND 2 EA
32 2560005 BEARINGCONE 2 EA
33 5560025 KEYWASHER 2 EA
34 5560026 SPINDLENUT 2 EA
35 556061 COTTERPIN,3/8DIAX2-1/2LG 2 EA
36 0080185 GASKET,HUBCAP 2 EA
37 0080186 HUBCAP 2 EA
38 970059 BLTHEXHD.25-151.25 8 EA
39 9870099 WASHERLOCK.250MDM 8 EA
40 7280010 NUTHEXLUG.750-16RH REF EA
41 2503224 BEARING REF EA
43 5570001 GREASEFITTING,1/8NPT
STRAIGHT 8 EA
44 0070328 ACCESSCOVER,CHASSIS 1 EA
45 5037005 TERMFEMF.I..25016/14 1 EA
46 986269 WSHRFLAT.313 4 EA
48 0082282 COVER,CHASSIS-4WHEEL
DRIVE 1 EA
49 970889 CAPSCREW1/2-13X1"LGH.H. 2 EA
50 986359 FLATWASHER1/2" 2 EA
51 5560039 NUTHEXLKG.500-13 2 EA
52 5560215 BOLTHEXHD.375-16.75GR5 12 EA
53 0070224 ACCESSCOVER,DRIVE 2 EA
TB65J PARTS MANUAL STEERING INSTALLATION 4X2 TB60 TB65J TB66J
STEERING INSTALLATION 4X2 TB60 TB65J TB66J Wed Feb 24 09:06:05 UTC 2021 2-1

REPAIRPARTS
TB65J PARTS MANUAL FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER
FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER Wed Feb 24 09:06:06 UTC 2021 2-2

アイテム 部品番号 名前 数量 UOM
- 0081991J FRONTWHEELDRIVE4X4
FEBRUARY2001ANDAFTER EA
1 0083573 WELDMENTSTEERYOKE 2 EA
2 0083495 GEARHUB 2 EA
3 6030018 VRFRONTDRIVEMTR4X4‒
VONRUD 2 EA
4 0080885 KINGPIN 4 EA
5 2580001 THRUSTBEARING 2 EA
6 2503220 BEARING,GARMAX#GM3236-
20 4 EA
8 5560018 SPINDLENUT 4 EA
9 5560714 PINCOT.188DIA2.50-
CP018R250 4 EA
10 5035305 FTGELB90STRTHD-6S-6SSTL 2 EA
11 5035308 ADAPTER90°ELBOW-12SAE
TO-12JIC 2 EA
13 5065714 FTGHYD-12MBTO-12MJC 2 EA
14 0080965 FOAMTIREASSY-RHLUGGED A/R EA
- 0080966 TIREANDWHEELLHDRIVE
ASSEMBLY 1 EA
15 7280001 LUGNUT A/R EA
16 7110242 O-RING,APR#DASH-242-70 2 EA
17 5560131 NUTHEXLKG.625-11GR8 16 EA
18 5560169 WSHRFLATHARD.625SP 16 EA
19 5560640 BOLTHEXHD,5/8-11X3"LG,
GR8 16 EA
20 5560078 BOLTHEXHD.500-13X1.50
GR8 4 EA
21 987139 WSHRLOCK.500 4 EA
22 5070026 CAPWHEELSERVICE- 2 EA
25 5569974 MCHRYBSHG2"ID3"OD14GA 6 EA
27 5560091 SHIM,.015INCHTHICK 2 EA
TB65J PARTS MANUAL FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER
FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER Wed Feb 24 09:06:06 UTC 2021 2-2

アイテム 部品番号 名前 数量 UOM
28 5560252 1.25X2.2514GAMACHINE
WASHER 4 EA
29 5569952 1.25X2.2510GAMACHINE
WASHER 4 EA
TB65J PARTS MANUAL FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER
FRONT WHEEL DRIVE 4X4 FEBRUARY 2001 AND AFTER Wed Feb 24 09:06:06 UTC 2021 2-2

REPAIRPARTS
TB65J PARTS MANUAL DRIVE 4X2 4X4 INSTALLATION OCTOBER 2006 AND BEFORE
DRIVE 4X2 4X4 INSTALLATION OCTOBER 2006 AND BEFORE Wed Feb 24 09:06:06 UTC 2021 2-3

アイテム 部品番号 名前 数量 UOM
* 0080058L DRIVE4X24X4INSTALLATION
OCTOBER2006ANDBEFORE EA
1 6030040 MTRW/BRAKE-VONRUDEN 2 EA
2 0081674 GEARHUB 2 EA
3 7110242 O-RING,APR#DASH-242-70 2 EA
4 5035308 ADAPTER90°ELBOW-12SAE
TO-12JIC 4 EA
5 5065707 FTGADPTRSTRTHD-6B-6SSTL-
PH 2 EA
6 5037005 TERMFEMF.I..25016/14 2 EA
7 5035303 FTGELB90STRTHD-4B-4SSTL 2 EA
8 5037003 FTGELB90SWVL-4S-4SSTL 2 EA
9 5569895 CSCR5/8-11UNCHHDGR53-
1/4LONG 16 EA
10 5560169 WSHRFLATHARD.625SP 16 EA
11 5560131 NUTHEXLKG.625-11GR8 16 EA
12 5560078 BOLTHEXHD.500-13X1.50
GR8 4 EA
13 987139 WSHRLOCK.500 4 EA
14 5080015 LASTCHANCEFILTER 4 EA
15 0070224 ACCESSCOVER,DRIVE 2 EA
16 970449 HHDBLT.375-16X.750GR5 8 EA
17 987119 WSHRLOCK.375 8 EA
TB65J PARTS MANUAL DRIVE 4X2 4X4 INSTALLATION OCTOBER 2006 AND BEFORE
DRIVE 4X2 4X4 INSTALLATION OCTOBER 2006 AND BEFORE Wed Feb 24 09:06:06 UTC 2021 2-3

REPAIRPARTS
TB65J PARTS MANUAL DRIVE 4X2 4X4 INSTALLATION NOVEMBER 2006 AND AFTER
DRIVE 4X2 4X4 INSTALLATION NOVEMBER 2006 AND AFTER Wed Feb 24 09:06:07 UTC 2021 2-4

アイテム 部品番号 名前 数量 UOM
- 0080058R DRIVE4X24X4INSTALLATION
NOVEMBER2006ANDAFTER EA
1 6030040 MTRW/BRAKE-VONRUDEN 2 EA
2 0083495 GEARHUB 2 EA
3 7110242 O-RING,APR#DASH-242-70 2 EA
4 5035308 ADAPTER90°ELBOW-12SAE
TO-12JIC 4 EA
5 5065707 FTGADPTRSTRTHD-6B-6SSTL-
PH 2 EA
6 5037005 TERMFEMF.I..25016/14 2 EA
7 5035303 FTGELB90STRTHD-4B-4SSTL 2 EA
8 5037003 FTGELB90SWVL-4S-4SSTL 2 EA
9 5560642 BLTHEXHD.625-113.25GR8 16 EA
10 5560169 WSHRFLATHARD.625SP 16 EA
11 5560131 NUTHEXLKG.625-11GR8 16 EA
12 5560078 BOLTHEXHD.500-13X1.50
GR8 4 EA
13 987139 WSHRLOCK.500 4 EA
TB65J PARTS MANUAL DRIVE 4X2 4X4 INSTALLATION NOVEMBER 2006 AND AFTER
DRIVE 4X2 4X4 INSTALLATION NOVEMBER 2006 AND AFTER Wed Feb 24 09:06:07 UTC 2021 2-4

REPAIRPARTS
TB65J PARTS MANUAL CHASSIS COVER INSTALLATION 4X4
CHASSIS COVER INSTALLATION 4X4 Wed Feb 24 09:06:07 UTC 2021 2-5
