Snugpak Journey Quad User manual

JOURNEY QUAD
FOUR PERSON TENT
Assembly Instructions
1 Orange Tipped
Pole
2Silver Tipped
Poles 20 Alloy Stakes
Lay out the footprint before
erecting the tent.
Unroll the outer tent, locate
the pole bag, separate the poles,
clip the sections together making
continuous poles. The poles are
held together by elastic.
Pole Placement
1. Insert the silver tipped
pole with silver section to
silver trim edging.
2.Insert the other silver
tipped pole with silver
section to silver trim
edging.
3.Insert the large orange
tipped pole with orange
section to orange trim
edging.
2
3
1
4.Insert the pole ends
into the grommets in the
corresponding webbing
straps.
5. When all the pole ends are
inserted into the grommets
take the ultralight alloy
stakes included with the
Journey Quad, stake down
the corners and webbing
straps with grommets. Add
additional stakes to other
stake points as required.
45

Assembly Instructions
Snugpak®products are exclusively
distributed in North & South America by:
Proforce Equipment, Inc.
3230 Executive Way - Miramar, FL 33025
Ph: 305.436.7984 / 800.259.5962
www.ProforceEquipment.com
www.SNUGPAKUSA.com
6.Unroll the inner tent and lay out. Line up the fly
to the main body matching up the door and foot
area, connect the two with the toggle and ring
attachments.
7. When the inner tent is connected with the fly by
all the toggle and ring attachments (red to the
front and yellow to the back), click all the side
release buckles together.
8. To gain access unzip the fly and inner tent zips.
9. When happy with the set-up, further stabilisation
is achieved by pegging out the guy lines. This is
essential in windy conditions.
THIS TENT MEETS THE FLAMMABILITY REQUIREMENTS OF ISO6941 / (EN5912).
6
7
JOURNEY QUAD
FOUR PERSON TENT
7
