Socket CompactFlash Scan Card Series 5 User manual

WHICH VERSION IS RIGHT FOR YOU?
CFSC 5C
Low-cost
Entry Level
1D Imager
- Smallest, lightest and most affordable version
- For light-duty scanning up to 20” (51 cm) away
- Scans barcodes printed on labels or displayed on device screens
- Recommended for ISBN book scanning for book scouting or library apps
CFSC 5E2
Reliable,
Affordable
1D Laser
- For light-duty or general-purpose indoor scanning
- Reads all common 1D/linear and stacked barcodes up to 10.5” (27 cm) away
- Class 1 laser technology
CFSC 5P
Long-range
1D Laser
- High-performance for scanning barcodes indoors or outdoors
- Ideal for reading VIN numbers, through Mylar / thick glass or damaged barcodes
- Reads barcodes on curved or reflective surfaces
- Easy to use and can scan thousands of barcodes per day, up to 45” (114 cm) away
- Class 2 laser technology reads 1D and stacked barcodes
CFSC 5X
2D and 1D
Omni-
directional
- Xtreme peformance unit for 2D, 1D, PDF barcodes, including small barcodes
- Reads barcodes indoors in good lighting conditions up to 10.5” (27 cm) away
- Also supports stacked and postal barcodes
- CMOS imaging technology
CFSC 5XRx
Antimicrobial
2D and 1D
- Antimicrobial plastics inhibit growth of bacteria and microbes
- Xtreme peformance unit for 2D, 1D, PDF barcodes, including small barcodes
- Reads barcodes indoors in good lighting conditions up to 10.5” (27 cm) away
- CMOS imaging technology
HARDWARE FEATURES
• 2D and 1D barcode scanning
• Durable card with integrated scanner plugs into
CompactFlash (CF) slot with a snug, secure fit
• Antimicrobial version 5XRx for healthcare
• With 3rd party CF-to-PC Card adapter (not included)
also works in a PC Card (PCMCIA) slot
• Compatible with computers running:
- Windows Embedded Handheld 6.5
- Windows Mobile 6 Classic, Professional
- Windows Mobile 2003/2003SE/5.0 for Pocket PC
- Windows 7, Vista , XP
• One-handed operation with Socket SoMo® 655 or other
handheld improves efficiency by freeing the other
hand to handle materials
• Multiple performance levels available to fit your
business requirements
• Easy to pack, no extra batteries or power adapter
required
• Low power consumption maximizes the battery life of
your mobile computer
• Great to combine with Socket SoMo® 655 handheld
computer, pre-loaded with software for out-of-the-box
deployment
• One year warranty
• SocketCare extended warranty sold separately
SOFTWARE FEATURES
• SocketScan™Plug-in software enters scanned data into
any application, no custom programming needed
• Automatically add prefix and suffix functions, such as
carriage return and tab, to further eliminate manual
data entry
• Optional beep or audio file for good scan
• Easily enable / disable symbology support
• View the properties of any bar code, including
symbology, length, and decoded data, for any of the
supported symbologies
• Compatible with Windows-based development tools
for custom applications
• SDK available to application developers
• Floating Trigger for Windows Mobile adds onscreen
icon you can tap to trigger the scanner
• No license fee for standard software
WATCH VIDEOS
Retail:
http://www.youtube.com/user/socketmobile#p/
f/5/2XvLCtS7iqU
Healthcare:
http://www.youtube.com/user/socketmobile#p/f/0/
U1Vnj-nY30Q
Capture Barcodes Anywhere with a
Durable Plug-in Scanner
Increase efficiencies in your data collection applications with the CompactFlash Scan
Card (CF Scan Card) Series 5
• Performance – Advanced technology for scanning 1D and 2D barcodes in a broad
range of indoor and outdoor conditions
• One-Handed Scanning – After you insert the CF Scan Card into a PDA, you can scan
with one hand, leaving your other hand free to handle packages and materials for
increased productivity
• Modular – Works in the standard CompactFlash or PC Card slot of a wide
variety of mobile computers, so you can switch or upgrade computers and keep
using the same scanner*
CompactFlash Scan Card
Series 5

© 2012, Socket Mobile, Inc. Socket, the Socket logo, Business Mobility Now!, CompactFlash Scan Card, SocketScan, and Battery Friendly are registered trademarks or trademarks of Socket Mobile, Inc. Microsoft is
a registered trademark of Microsoft Corporation in the United States and other countries. All other brand and product names are trademarks of their respective holders. Information is subject to change. 6450-00160 S
11/2012
[email protected] EMEA [phone]
UK [phone]
Worldwide [phone] Australia [phone]
Toll-Free [phone] (USA/Canada) Japan [phone]
CF Scan Card Model 5C 5E2 5P 5X/5XRx
SKU#s IS5046-1379 IS5042-1195 IS5026-610 IS5038-894/ IS5040-1150
CF Card Dimensions 45 x 43 x 5.0 mm (1.8 x 1.7 x 0.19 inches) 46 x 43 x 3.8 mm (1.8 x 1.7 x 0.15 inches)
Scanner Head
Dimensions
40 x 51 x 20 mm (1.6 x 2.0 x 0.78 inches)
(without rubber collar)
39 x 51 x 23 mm (1.6 x 2.0 x 0.90 inches)
(without rubber collar)
Total Mass 31 g (1.1 oz) 34 g (1.2 oz) 37 g (1.3 oz)
Antimicrobial Rating
(JIS Z2801:2000 Test)
Biosafe® HM4100
EPA# 83019-1
N/A 5X: N/A
5XRx: 2.49 on MRSA
6.07 when cleaned with Sani-Cloth® Plus
disposable cloth wipes
Operating Temperature Operating: +32 to +122°F (0 to +50°C) Storage: -40 to +158°F (-40 to +70°C)
Relative Humidity 5% to 95% non-condensing
Ambient Light Sunlight: 9690ft. candles (9690 lux)
Artifical light: 450 ft. candles (4,845 lux)
Sunlight: 10,000 ft. candles (107,640 lux)
Artifical light: 450 ft. candles (4,844 lux)
0 to 100,000 lux
Operating Voltage 3.3 V
Power Consumption
(3.3 V)
Idle: 10 mA (33 mW)
Scanning: 170 mA (560 mW) typical
Idle: 10 mA (33 mW)
Scanning: 147 mA (155 mW) typical
Idle: 70 mA (231 mW)
Scanning: 460 mA (1518 mW)
Laser Power (at 650 nm) N/A 0.7 mW (±0.1 mW) 1.7 mW (±0.2 mW) N/A
Scanner Type Linear Imager (1D) Class 1 laser (1D) Class 2 laser (1D) Imager (1D, 2D)
Scan Repetition Rate 50 scans/sec 100 scans/sec bi-directional 2D mode: 56 images/sec, auto adaptive
Linear (1D) emulation mode: 200 images/sec,
adaptive
Optical Resolution 5 mil minimum 0.004 in. min./barcode element width (X Dimension) 752 (H) x 480 (V) pixels, 256 gray levels
Print Contrast Minimum 20% Minimum 25% absolute dark/light reflectance (MRD)
Measured at 650 nm
Down to 25%
Scan Angle 53.3° ±3° Wide (default): 47° ±3° Narrow: 35° ±3° Horizontal: 38.9° Vertical: 25.4°
Decode Distance
(Typical)*
5.7 to 50.8 cm (2.25 to 20 inches) 3.8 to 27 cm
(1.5 to 10.5 inches)
3.8 to 114+ cm
(1.5 to 45+ inches)
4.8 to 40.6 cm (1.9 to 16 inches)
Types of Barcodes
Decoded
Linear (1D) Linear (1D), Stacked linear composite
(GS1 DataBar/RSS)
Linear (1D), Stacked linear, 2D/Matrix, Postal
Symbologies Decoded Bookland EAN (ISBN / EAN-13), Chinese 2
of 5, Codabar, Code 11, Code 128, Code 39,
Code 93, Discrete 2 of 5, GS1 DataBar (RSS),
GS1-128 (UCC-128/EAN-128), Interleaved 2
of 5 (ITF-14), MSI, Plessey, UPC/EAN, UPC/
EAN/JAN supplemental redundancy, Cou-
pon Report, ISSN EAN, Inverse 1D, ISBT con-
catenations, Matrix 2 of 5
Chinese 2 of 5, Codabar, Code 11, Code 128, Code 39, Code 93,
D 2 of 5, GS1-128 (UCC-128/EAN-128), GS1 DataBar (RSS), I 2 of
5, MSI, UPC/EAN
Same as CFSC 5E2 (except D 2 of 5) plus: Australia
Post, Aztec, BPO4 State Code, British Post, Canada
Post, Codablock, Data Matrix, Dutch Post, EAN/
UCC Composite, ISBN, Japan Post, Matrix 2 of 5,
Maxicode, PDF 417/Macro PDF 417/Micro PDF 417,
Planet, Plessey, Postnet, QR Code, Standard 2 of 5,
Telepen, TLCode 39, 4 State Code
Operating System
Support
SoMo 655/Rx: Windows Embedded Handheld 6.5
SoMo 650/Rx: Windows Mobile 6.1
wSP9
SoMo 650/Rx: Windows Mobile 6 Classic/Professional, Windows Mobile 2003, 2003SE, 5.0 for Pocket
PC
Laptops and tablets : not supported Laptops and tablets: Windows Vista, XP
Compatibility Windows COM port, CompactFlash Spec. 2.0
Interface Standards CompactFlash Type II; PC Card (PCMCIA) with Type II CF-to-PC Card adapter, available from 3rd party
Software Installation Utility, SocketScan™ for Windows Embedded Handheld/Windows Mobile / Vista / XP, Socket Floating Trigger
For latest downloads: http://www.socketmobile.com/support/downloads/
Package Contents CompactFlash Scan Card, Retaining bracket for use with Socket SoMo®
Warranty CompactFlash Scan Card: One year Accessories: 90 days
SocketCare Service
Program
Sold separately. SocketCare Plus 2 Year SKU# SC1808-1353 3 Year SKU# SC1809-1354
http://www.socketcare.com/
Environmental RoHS, REACH
EMI/RFI FCC Part 15 Class C, RSS 210, iCES 003, C-
Tick, CISPR 22, CE EN55022, EN55024, TELE
FCC Part 15, Class B, CISPR 22, ICES-003 Class B, CE EN
55024:2003, Japan VCCI Class B, AS 3548, C-Tick s.82
FCC Part 15, Class B, CE EN 55024:2003, Japan VCCI
Class B, C-Tick s.82
Laser/LED Safety IEC60825-1 Class 1 Laser
21 CFR 1040.10
21 CFR 1040.11**
IEC60825-1 Class 2 Laser
21 CFR 1040.10
21 CFR 1040.11**
IEC60825-1 Class 1 LED
