THREE PHASE DIN RAIL ENERGY METER
COUNTIS M33
MANUAL V1.0

SOCOMEC CHINA CO., Ltd
SOCOMEC CHINA CO., LtdSOCOMEC CHINA CO., Ltd
SOCOMEC CHINA CO., Ltd
溯高美索克曼电气
溯高美索克曼电气溯高美索克曼电气
溯高美索克曼电气（
（（
（上海
上海上海
上海）
））
）有限公司
有限公司有限公司
有限公司
http://www.socomec.com
Statement
All rights reser ed. Without the written permission of Socomec, the contents of any passages and chapters
in this manual shall not be copied or reproduced or disseminated in any form. Otherwise, all
consequences shall be borne by the iolator.
Socomec reser es all legal rights.
Socomec reser e the right to modify the product specifications described in this manual without prior
notice. Before ordering, please contact our company or local agent for the latest specifications of this
product.

Contents
Part 1 Product overview
1.1 Brief Introduction --------------------------------------------------------------------------------------------------------------1
1.2 Product characteristics -------------------------------------------------------------------------------------------------------1
1.3 Application ----- ----------------------------------------------------------------------------------------------------------------2
Part 2 General Specifications
2.1 Specifications-----------------------------------------------------------------------------------------------------------------3
2.2 Accuracy -------------------------------------------------------------------------------------------------------------------------3
2.3 RS485 Communication-------------------------------------------------------------------------------------------------------4
2.4 En ironment--------------------------------------------------------------------------------------------------------------------4
2.5 Dimendions---------------------------------------------------------------------------------------------------------------------5
2.6 Wiring Diagram----------------------------------------------------------------------------------------------------------------6
Part 3. Operation Instructions
3.1 Display and Operation ---------------------------------------------------------------------------------------------------7
3.1.1 Button Definition -------------------------------------------------------------------------------------------------------7
3.2 Measurement ---------------------------------------------------------------------------------------------------------------7
3.2.1 Voltage & Current---------------------------------------------------------------------------------------------------------7
3.2.2 Frequency, Power Factor & Demand---------------------------------------------------------------------------------9
3.2.3 Power ------------------------------------------------------------------------------------------------------------------------10
3.2.4 Energy------------------------------------------------------------------------------------------------------------------------11
3.3 Setting by button-----------------------------------------------------------------------------------------12
3.3.1 Button Operation -------------------------------------------------------------------------------------------------------13

3.3.2 Number Entry Procedure -------------------------------------------------------------------------------------------13
3.3.3 Set Password----------------------------------------------------------------------------------------------------------------14
3.3.4 Modbus Address-----------------------------------------------------------------------------------------------------------15
3.3.5 Baud Rate--------------------------------------------------------------------------------------------------------------------15
3.3.6 Parity--------------------------------------------------------------------------------------------------------------------------16
3.3.7 Stop bit-----------------------------------------------------------------------------------------------------------------------17
3.3.8 Pule Output------------------------------------------------------------------------------------------------------------------17
3.3.9 Pulse Constant--------------------------------------------------------------------------------------------------------------18
3.3.10 Pulse Duration------------------------------------------------------------------------------------------------------------19
3.3.11 Set DIT ---------------------------------------------------------------------------------------------------------------------20
3.3.12 Set backlit lasting time--------------------------------------------------------------------------------------------------21
3.3.13 Set System------------------------------------------------------------------------------------------------------------------22
3.3.14 Clear-------------------------------------------------------------------------------------------------------------------------23
Part 4．
．．
．Modbus re ister Map------------------------------------------------------------------------------------------------24

- 1
-
Part 1 Product overview
1.1 Brief Introduction
COUNTIS M33 measures and displays the characteristics of single phase two wires (1p2w), three phase
three wires (3p3w,) and three phase four wires (3p4w) supplies, including oltage, frequency, current,
power, acti e and reacti e energy, imported or exported. Energy is measured in terms of kWh, kVArh.
Maximum demand current can be measured o er preset periods of up to 60 minutes. In order to measure
energy, the unit requires oltage and current inputs in addition to the supply required to power the
product.
COUNTIS M33 supports max. 100A direct connection, sa es the cost and a oid the trouble to connect
external CTs, gi ing the unit a cost-effecti e and easy operation. Built-in interfaces pro ides pulse and
RS485 Modbus RTU outputs. Configuration is password protected.
1.2 Product characteristics
Measures kWh, K arh, KW, K ar, KVA, P, F, PF, Hz, dmd, V, A, etc.
Bi-directional measurement IMP & EXP
Two pulse outputs
RS485 Modbus
Din rail mounting 35mm
100A direct connection
The Unit can measure and display:
Line oltage and THD% (total harmonic distortion) of all phases
Line Frequency
Currents, Current demands and current THD% of all phases
Power, maximum power demand and power factor
Acti e energy imported and exported
Reacti e energy imported and exported
The unit has password-protected set-up screens for:
Changing password

- 2
-
Supply system selection 1p2w, 3p3w,3p4w
Demand Inter al Time(DIT)
Reset for demand measurements
Pulse output duration
1.3 Application
COUNTIS M33 is a multi-functional three phase energy meter, designed for power system, public facilities,
industrial applications and residential power monitoring needs. It can also be used in AC charging piles,
solar photo oltaic and other occasions. Its complete communication function makes it ery suitable for
real-time power monitoring systems.

- 3
-
Part 2 General Specifications
2.1 Specifications
Voltage： Rated Voltage (Un):3x230(400)V
Operational oltage: 80~120%
Current： Rated Current (Ib)：10A
Max Current (Imax)： 100A
O er current withstand: 0.4% Ib~Imax
O er current withstand: 20 Imax for 0.5s
Operational frequency：Rated：50/60Hz
Range：45-65 Hz
Insulation capabilities： AC oltage withstand 4KV/1min
Impulse oltage withstand 6kV – 1.2µS wa eform
Internal Power Consumption：≤ 2W.
Pulse Output 1：Configurable
Pulse Output 2：Fixed 400imp/kWh
Display：LCD with backlit
Max reading: 999999.99 kWh / k arh
2.2 Accuracy
Voltage：0.5%
Current：0.5%
Frequency：0.2%
Power Factor：1%
Acti e Power：0.5%
Reacti e Power：±1%

- 4
-
Apparent power：±1%
Acti e energy：Class1
Reacti e energy：Class2
2.3 RS485 Communication
Bus Type：RS485
Communication Protocol：Modbus RTU
Baud rate： 2400/4800/9600/19200/38400bps
Modbus Address：1-247
Bus load：64pcs
Communication distance：1000m
Parity：EVEN /ODD/NONE
Data bit：8
Stop bit：1
2.4 En ironment
Operating humidity： ≤90%
Storage humidity： ≤95%
Operating temperature： -25℃~+55℃
Storage temperature： -40℃~+70℃
Standard： GB-T 17215/ IEC62053-21/ EN50470-1/3
Accuracy： Class 1.0
Installation category： CAT III
Protection against penetration of dust and water: IP51（indoor）

- 5
-
Insulating encased meter of protecti e class: II
Altitude： ≤2000m
2.5 Dimensions
35mm
Height: 66 mm
Width: 72 mm
Length: 100 mm

- 6
-
2.6 Wiring Diagram
3P4W 3P3W 1P2W

- 7
-
Part 3. Operation Instructions
3.1 Display and Operation
When the meter is powered on, the meter will initialize and do self-checking
Display as following:
1
Full screen
2
Software ersion
3
Self-checking finish
3.1.1 Button Definition
3.2 Measurement
3.2.1 Voltage & Current
Press button :
Selects V and A display screen.
In Set-up Mode, it is the “Left” or “Back” button
Selects Hz and PF display screen.
In Set-up Mode, it is the “Up” button
Selects power display screen.
In Set-up Mode, it is the “Down” button
Selects energy display screen.
In Set-up Mode, it is the “Enter” or "Right" button.

- 8
-
1 Phase to neutral oltages(3p4w)
1-1 Phase to neutral oltages(3p3w)
2 Current on each phase
3 Phase to neutral oltage THD%(3p4w)
4 Current THD% for each phase

- 9
-
3.2.2 Frequency, Power Factor & Demand
Press button ：
1 Frequency and Power Factor (total)
2 Power Factor of each phase
3 Maximum Current Demand
4 Maximum Power Demand

- 10
-
3.2.3 Power
Press ：
1 Instantaneous Acti e Power in kW
2 Instantaneous Reacti e Power in kVAr
3 Instantaneous Volt-amps in KVA
4 Total kW, kVAr, kVA

- 11
-
3.2.4 Energy
Press button ：
1 Total acti e energy in kWh
2 Total reacti e energy in kVArh
3 Imported acti e energy in kWh
4 Exported acti e energy in kWh

- 12
-
5 Imported reacti e energy in kVArh
6 Exported reacti e energy in kVArh
3.3 Setting by button
o enter set-up mode, pressing the button for 3 seconds, until the password screen
appears.
Setting up is password-protected so you must enter the correct password (default ‘1000’) before
processing. If an incorrect password is entered, the display will show: Err

- 13
-
To exit setting-up mode, press repeatedly until the measurement screen is restored.
3.3.1 Button Operation
1. After Entering the Setting manu, use the and buttons to select the
required item from the menu. Selection does not roll o er between bottom and top of list
2. Press to confirm your selection.
3. If an item flashes, then it can be adjusted by the and buttons. If not,
there may be a further layer.
4. Ha ing selected an option from the current layer, press to confirm your selection. The
SET indicator will appear.
5. Ha ing completed a parameter setting, press to return to a higher menu le el. The SET
indicator will be remo ed and you will be able to use the and buttons for
further menu selection.
6. On completion of all set-up, press repeatedly until the measurement screen is restored.
3.3.2Number Entry Procedure
When setting up the unit, some screens require the entering of a number. In particular, on entry to the

- 14
-
setting up section, a password must be entered. Digits are set indi idually, from left to right. The
procedure is as follows:
1. The current digit to be set flashes and is set using the and
2. Press to confirm each digit setting. The SET indicator appears after the last digit has
been set.
3. After setting the last digit, press to exit the number setting routine. The SET indicator
will be remo ed.
3.3.3 Set Password
1
Use the and
to choose the change password option
2-1
Press the to enter the
change password routine. The new
password screen will appear with the
first digit flashing
2-2
Use and to set
the first digit and press to
confirm your selection. The next digit will
flash.

- 15
-
Press to exit the number setting routine and return to the Set-up menu. SET will
be remo ed
3.3.4 Modbus Address
(The range is from 001 to 247)
1
From the Set-up menu, use
and buttons to select the
Address ID
2-1
Press button to enter the
selection routine. The current setting will
be flashing.
2-2
Use and
buttons to choose Modbus Address(001
to 247)
3.3.5 Baud Rate
Options: 2.4k. 4.8k, 9.6k, 19.2k, 38.4k.

- 16
-
1
From the Set-up menu, use
and buttons to select the
Baud Rate option.
2-1
Press to enter the selection
routine. The current setting will flash.
2-2
Use and
buttons to choose Baud rate 2.4k. 4.8k,
9.6k, 19.2k, 38.4k
3.3.6 Parity
Options: EVEN / ODD / NONE.
1
From the Set-up menu, use
and buttons to select the
Parity option.
