socomec MASTERYS GP4 Series User manual

MASTERYS GP4
60-120 kVA
EN
INSTALLATION
AND OPERATING
MANUAL
MASTERYS GP4
www.socomec.com

3EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
CONTENTS
1. CERTIFICATE AND CONDITIONS OF WARRANTY 5
2. SAFETY STANDARDS 6
2.1 DESCRIPTION OF SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. ENVIRONMENTAL REQUIREMENTS AND HANDLING 9
3.1 ENVIRONMENTAL REQUIREMENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 HANDLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. ELECTRICAL INSTALLATION 12
4.1 ELECTRICAL REQUIREMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1.1 BACKFEED PROTECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 CABLE POSITIONING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5. OVERVIEW 19
6. CONNECTIONS 23
6.1 UPS CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1.1 60-80 KVA CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1.2 100-120KVA CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 EXTERNAL BATTERY CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.3 COMPLETION OF THE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7. CONTROL PANEL 28
7.1 VERTICAL MOUNT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7.2 ANGLED MOUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8. MENU 30
8.1 DISPLAY OVERVIEW (SYSTEM) ON PARALLEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.2 DISPLAY OVERVIEW (UNIT/UPS LEVEL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.3 MENU TREE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.4 MENU FUNCTION DESCRIPTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.1 ENTERING PASSWORDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.2 ALARM MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.3 STATUS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.4 UPS EVENT LOG MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.5 UPS MEASUREMENTS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.6 UPS CONTROLS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8.4.7 UPS CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.4.8 USER PARAMETERS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.4.9 SERVICE MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9. OPERATING PROCEDURES 38
9.1 SWITCHING ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.2 SWITCHING OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.3 BYPASS OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.4 EXTENDED OUT OF SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9.5 EMERGENCY SHUTDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
10. OPERATING MODES 40
10.1 ON LINE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
10.2 HIGH EFFICIENCY MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
10.3 CONVERTER MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.4 OPERATION WITH MAINTENANCE BYPASS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.5 OPERATION WITH MOTOR GENERATOR (GENSET). . . . . . . . . . . . . . . . . . . . . . . . . 41

4EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
11. STANDARD FEATURES AND OPTION 42
11.1 ADC+SL CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
11.2 NET VISION CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.3 EMD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.4 ACS CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.5 MODBUS TCP CARD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.6 BACNET CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.7 SOFTWARE OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
11.8 INTERNAL BACKFEED PROTECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11.9 KIT FOR COMMON MAINS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11.9.1 60-80 KVA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11.9.2 100-120 KVA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11.10 EXTERNAL MAINTENANCE BYPASS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
11.11 EXTERNAL ISOLATION TRANSFORMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
11.12 IMD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
11.13 NEUTRAL KIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.13.1 60-80 KVA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.13.2 100-120 KVA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.14 GROUND NEUTRAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.15 REDUNDANT BYPASS VENTILATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.16 ANTI-INTRUSION INSTALLATION KIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
12. TROUBLESHOOTING 51
12.1 SYSTEM ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
13. PREVENTIVE MAINTENANCE 54
13.1 BATTERIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
13.2 FANS & CAPACITORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
14. SAFETY ENVIRONMENT 55
15. TECHNICAL SPECIFICATIONS 56

5EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
1. CERTIFICATE AND CONDITIONS OF WARRANTY
This SOCOMEC continuous power system is guaranteed against any manufacturing or material defects.
The warranty is valid for 12 (twelve) months from the commission date, provided activation is carried out by
SOCOMEC personnel or personnel from a support centre authorised by SOCOMEC, and no more than 15 (fifteen)
months from being shipped from SOCOMEC.
The warranty is valid throughout national territory. If the UPS is exported abroad, the warranty will only cover the parts
used to repair faults.
The warranty is valid ex-works and covers labour and parts used to repair the faults.
The warranty shall not apply in the following cases:
• Failure due to unforeseen circumstances or force majeure (lightning, floods, etc.);
• Failure due to negligence or improper use (use outside limits: temperature, humidity, ventilation, electric power
supply, applied load, batteries);
• Insufficient or inappropriate maintenance;
• When maintenance, repairs or modifications have not carried been out by SOCOMEC personnel, or personnel
from a support centre authorised by SOCOMEC.
• If the battery has not been recharged in accordance with the terms indicated on the packaging and in the manual,
in the event of long periods of storage or UPS inactivity.
SOCOMEC may, at its own discretion, opt for the repair of the product or the replacement of faulty or defective parts
with new parts, or with used parts of equivalent quality to new parts with regard to function and performance.
Defective or faulty parts replaced free of charge must to be made available to SOCOMEC, which becomes the sole
owner.
Replacement or repair of parts, or any modifications to the product during the warranty period, will not extend the
duration of the warranty.
SOCOMEC will not be responsible for damages under any circumstances (including, without limitations, damage for
loss of earnings, interruption of activity, loss of information or other financial losses) arising from the use of the prod-
uct.
These conditions are subject to Italian law. Any disputes fall under the jurisdiction of the Court of Vicenza.
SOCOMEC retains the full and exclusive ownership rights to this document. Only a personal entitlement to use the
document for the application indicated by SOCOMEC is granted to the recipient of this document. The reproduction,
modification, distribution of this document, either partially or wholly and in any manner, is strictly prohibited except
upon Socomec’s express prior written consent.
This document is not a specification. SOCOMEC reserves the right to make any changes to the information provided
without prior notice.

6EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
2. SAFETY STANDARDS
This user manual specifies installation and maintenance procedures, technical data and safety instructions for
SOCOMEC. For further information visit the Socomec website: www.socomec.com.
NOTE!
Any work carried out on the equipment must be performed by skilled, qualified technicians.
DANGER!
Failure to observe safety standards could result in fatal accidents or serious injury, and damage
equipment or the environment.
CAUTION!
If the unit is found to be damaged externally or internally, or any of the accessories are damaged
or missing, contact SOCOMEC. Do not operate the unit if it has suffered a violent mechanical
shock of any kind.
NOTE!
Install the unit in accordance with clearances in order to prevent access to handling devices and
guarantee sufficient ventilation (refer to 'Environmental requirements' chapter).
NOTE!
Only use accessories recommended or sold by the manufacturer.
NOTE!
When the equipment is transferred from a cold to a warm place wait approx. two hours before
putting the unit into operation.
NOTE!
When carrying out electrical installation, all standards applicable specified by the IEC, in particu-
lar IEC 60364, and the electricity supplier must be observed. All national standards applicable to
batteries must be observed. For further information refer to ‘Technical specification’ chapter.
WARNING!
Connect the protective earth (PE) conductor before making any other connections.
NOTE!
The installer is responsible for implementing the backfeed protection with the use of AC input
line isolation devices external to the UPS. Refer to ‘Electrical requirements’ chapter.
DANGER! RISK OF ELECTRIC SHOCK!
Before carrying out any operations on the unit (cleaning and maintenance performances,
connection of appliances, etc.) disconnect all power sources.
DANGER! RISK OF ELECTRIC SHOCK!
After disconnecting all power sources wait approx. 5 minutes for the complete discharge of the
unit.
NOTE!
The UPS may be powered from an IT distribution system with a neutral conductor.
NOTE!
Any use other than the specified purpose will be considered improper. The manufacturer/
supplier shall not be held responsible for damage resulting from this. Risk and responsibility lies
with the system manager.
NOTE! The product you have chosen is designed for commercial and industrial use only. In order to be used for
particular critical applications such as life support systems, medical applications, commercial transportation, nuclear
facilities or any other application or systemwhere product failure is likely to cause substantial harm to people or prop-
erty, the products may have to be adapted. For such uses we would advise you to contact SOCOMEC beforehand
to confirm the ability of these products to meet the requested level of safety, performance, reliability and compliance
with applicable laws, regulations and specifications.
NOTE!
This is a product for commercial and industrial application – installation restrictions or additional
measures may be needed to prevent disturbances.

7EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
2.1 DESCRIPTION OF SYMBOLS
Safety requirements for secondary batteries and battery installations.
The installer is responsible for ensuring that the battery installation and their operating environ-
ment conform to national and international codes and safety standards.

8EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
Symbols Description
Protective earth terminal (PE).
Authorised personnel only.
Only qualified personnel are permitted to work on the batteries.
Do not use naked flames or cause sparks in the vicinity of the accumulators.
No smoking.
Batteries charging!
Batteries and related parts contain lead which is dangerous to health if ingested.
Wash hands after handling!
Accumulators are heavy!
Use suitable transport and lifting equipment to work safely.
Risk of electric shock!
Connecting accumulators in series creates hazardous voltages.
Risk of explosion! Avoid short circuits!
Never place tools or metal objects on the accumulators.
Corrosive liquids (electrolyte).
Read the user instructions carefully.
Read the user manual before performing any operations.
Wear protective gloves
Wear safety shoes.
Wear protective goggles.
In the event of accidents, improper use, failure or electrolyte leakage wear a protective apron.
In the event of accidents, improper use, failure or electrolyte leakage wear a gas mask.
In the event of contact with the eyes, wash immediately with plenty of water and call a doctor.
Call a doctor immediately in the event of accidents or illness.
Do not dispose of in normal waste stream (symbol WEEE).

9EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
3. ENVIRONMENTAL REQUIREMENTS AND HANDLING
NOTE!
Before carrying out any operations on the unit read the Safety standards chapter carefully.
3.1 ENVIRONMENTAL REQUIREMENTS
The room must be:
• of a suitable size
• free from conductive, inflammable and corrosive items;
• not exposed directly to sunlight.
The floor must support the weight of the unit and guarantee its stability.The unit is designed for indoor installation
only.
ROOM POSITIONING
1
≥80cm
free area
UPS OR
OTHER
CABINET
UPS OR
OTHER
CABINET
2
free area
≥150cm
door
130°
≥20cm free area
UPS OR
OTHER
CABINET
UPS OR
OTHER
CABINET

10 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
3.2 HANDLING
• The packaging guarantees the stability of the unit during shipping and physical transfer.
• The unit must remain in a vertical position during all shipping and handling operations.
• Ensure that the floor is strong enough to support the weight of the unit.
• Carry the packaged unit as close as possible to the installation site.
WARNING! HEAVY WEIGHT!
Move the unit using a fork lift truck taking the utmost caution at all times.
The unit MUST be handled by at least two people. The people MUST take position at the sides of
the UPS with respect to the direction of movement.
Do not move the unit by putting pressure on the front door.
When moving the unit on even slightly sloping surfaces, use the locking equipment and braking
devices to ensure that the unit does not fall over.
WARNING!
The following instructions must be carried out prior to moving the unit (after initial positioning).
Failure to heed this warning could result in the unit falling over, equipment damage, injury and
even death.

11EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
UNPACKING PROCEDURES
5
1 2
3 4
M8

12 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
4. ELECTRICAL INSTALLATION
PARALLEL CONFIGURATION (up to 6 units)
25m max
D
C
A
B
E
H
G G G
MAINS AUX MAINS
up to 6
UPSs F
D
C
E
D
C
UPS1 UPS2 UPSn
OUT
KEY
A Input mains magneto-thermal switch.
B Auxiliary mains magneto-thermal switch.
C Unit Input mains magneto-thermal switch.
D Unit Auxiliary mains magneto-thermal switch.
E Parallel bus cable.
F(1) External maintenance by pass switch.
G(1) Unit output switch.
H(1) System shutdown switch.
1. Connect signal status to the parallel board.

13EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
4.1 ELECTRICAL REQUIREMENTS
NOTE!
Before carrying out any operations on the unit read the Safety standards chapter carefully.
The installation and system must comply with national plant regulations.
The electrical distribution panel must have a sectioning and protection system installed for input and auxiliary mains.
RCD is not necessary when the UPS is installed in a TN-S system.
RCD is not allowed on TN-C systems.
If a RCD is required a B-type should be used.
Size of input protection devices
Model
rating Breaker Input(1) Breaker Aux. Mains(1)
Differential
input
Input/Output
cable core size(2)
Battery cable
core size Battery protection(4)
(kVA)
(A) (A) (A) (mm2) (mm2)
(A)
C D selective type Min Max(3) Min Max(3)
60 125 160 0.5 50 70 50 70 200
80 160 200 0.5 50 70 50 70 200
100 250 250 0.5 70 2x120 70 2x120 250
120 250 250 0.5 70 2x120 70 2x120 250(5)
1. Circuit breaker switch recommended with magnetic intervention threshold ≥10 In (curve C). It is necessary to use a D curve
selective breaker if an optional external transformer is used. The min value depends on the size of the power cables in the
installation, while the max value is limited by the UPS cabinet.
2. For parallel configuration, cables shall have the same size and length for each unit (maximum length tolerance is ±5%).
Output cables should be less than 25 metres.
3. Determined by the size of the terminals.
4. Tripole protection on external battery cabinet.
Recommended Fuse aR type or magneto-thermal switch (three poles with intervention threshold = 3 In suited for DC
applications).
5. Recommended Fuse 315A aR type for a battery cabinet with capacity exceeding 90 Ah.
CAUTION: Residual Current Detection (RCD) can only be used in the case of a common input
and auxiliary mains (configuration not recommended). It has to be placed upstream of the
connection between input mains and auxiliary mains. If RCD is installed the trigger value must be
0.5 A multiplied by the number of units connected in parallel.
Use type B four-pole selective (S) residual current detectors. Load leakage currents are to be
added to those generated by the UPS and during transitory phases (power failures and power
returns) short current peaks may occur. If loads with high leakage current are present, adjust
the residual current protection. It is advisable in all cases to carry out a preliminary check on the
earth current leakage with the UPS installed and operational with the definitive load, so as to
prevent the RCD tipping over.
The phase rotation of aux mains and output cables must be the same for each unit.
NOTE:
- To ensure the integrity of the 60-80 kVA bypass thyristors, I2t must be lower than 120 kA2s and
peak current must be lower than 5 kA for 20 ms.
- To ensure the integrity of the 100-120 kVA bypass thyristors, I2t must be lower than 400 kA2s and
peak current must be lower than 9 kA for 20 ms.
Contact SOCOMEC for detailed information.
The UPS is designed for transient overvoltages in category II installations. If the UPS is part of
the building’s electrical circuit, or is likely to be subject to transient overvoltages in category
III installations, additional external protection must be provided, either on the UPS or in the AC
power supply network powering the UPS.
The UPS is designed for indoor environmental service conditions according to IEC 60721-3-3
with pollution degree lower or equal to 2 (non-conductive pollution).

14 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
WARNING: as specified in 62040-3 Appendix 3: Non-linear Load Reference, in the event of three-
phase non-linear loads connected downstream of the UPS, the neutral current on the load can
be 1.5 - 2 times higher than the phase current. This must be considered when estimating the
correct size of the output and the auxiliary neutral cables.
WARNING: protective earthing conductor (PE) must have sufficient current-carrying capacity.
The PE cable core size must be chosen according to the PROTECTIVE CURRENT RATING of the
earth circuit which depends on the provision and location of protective overcurrent devices.
NOTE: 3-Phase 4-Wire Input Power is required.
The unit can be installed in TN-C, TN-S, TT and IT AC distribution systems (IEC 60364-3).
ADDITIONAL REQUIREMENTS FOR PARALLEL CONFIGURATION
The UPS is designed for transient overvoltages in category II installations. If the UPS is part of a
parallel configuration and the total output rated current is > 400 A, additional external protection
must be provided.
System shutdown switch Hshould always be installed in the external distribution cabinet and
recognised as an emergency shutdown switch (red handle). If this switch is far from the UPS or in
another room a remote shutdown button shall be installed near the UPS.
Before turning on an individual unit ensure that the relevant unit output switch Gis closed.
Before opening unit output switch Gensure that the relevant unit is turned off.
If unit output switches Gare present it is advisable to connect an auxiliary pre-opening contact
from the switch to the parallel board.
If external maintenance bypass switch Fis present it is advisable to connect an auxiliary pre-
closing contact from the switch to the parallel board.
If system shutdown switch His present it is advisable to connect an auxiliary pre-closing
contact from the switch to the parallel board.

15EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
4.1.1 BACKFEED PROTECTION
The UPS is set up for the installation of external protection devices against the backfeed of dangerous voltages, on
both the input power supply line (MAINS SUPPLY) and on the auxiliary backup mains power supply line (AUX MAINS
SUPPLY); these devices are controlled by means of the card shown in figure.
The current rating of the switching device has to follow the instruction outlined in chapter ‘Electrical Requirements’.
DANGER! RISK OF ELECTRIC SHOCK!
The installer must attach the warning label in order to warn electrical technicians about danger-
ous backfeed situations (not caused by the UPS).
Warning label (supplied with the equipment) Backfeed electrical diagram
Before working on this circuit
- Isolate the Uninterruptible Power System (UPS)
- Then check for Hazardous Voltage between all terminals
including the protective earth
Risk of Voltage Backfeed
B
L1
L2
L3
N
UPS output
voltage
Backfeed
Card
Dry Contact
NOTE: use a 220-240 V release coil with integrated travel limit contact to pilot the input protec-
tion systems. If a trip coil without an integrated end-of-travel contact is used, an early auxiliary
contact must be added. Electrical contact data: 2 A 250 V AC.
As an option the unit can be delivered with the integrated internal backfeed switches. Refer to 'STANDARD
FEATURES AND OPTION'.

16 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
• Separate Mains
Activating UPS protection on the mimic panel: access the MAIN MENU > SERVICE > UPS SETTINGS > MAINS /
AUXILIARY and set the parameter to SEPARATE.
A UPS
MAINS X10
BKF
COM2
AUX MAINS X40
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
XB2XB3XB1
NC2
NO2
NO1
COM1
NC1
B
B
KEY
ADistribution panel
BTrip coil
X10 Mains terminal board
X40 Aux Mains terminal board
MAINS Mains switch
AUX MAINS Aux Mains switch
XB2 (COM2) - XB3 (NO2) Mains BKF connector
XB1 (COM1) - XB3 (NO1) Aux Mains BKF connector
UPS output voltage
AUX MAINS
protection MAINS protection
XB2 XB1
XB3

17EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
• Common Mains
Activating UPS protection on the mimic panel: access the MAIN MENU > SERVICE > UPS SETTINGS > MAINS /
AUXILIARY and set the parameter to COMMON.
Common Mains
protection
XB2 XB1
XB3
KEY
ADistribution panel
BTrip coil
X10 Mains terminal board
X40 Aux Mains terminal board
COMMON MAINS Mains switch
XB2 (COM2) - XB3 (NO2) Common mains BKF connec-
tor
UPS output voltage
A
UPS
COMMON MAINS X10
BKF
COM2
X40
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
XB2XB3XB1
NC2
NO2
NO1
COM1
NC1
B

18 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
4.2 CABLE POSITIONING
WARNING!
The cables must be installed on trays according to the following diagrams. The trays must be
positioned near the UPS.
WARNING!
All metal and suspended ducts or those in raised flooring MUST be connected to earth and to
the various cabinets
WARNING!
Power cables and control cables MUST NEVER be installed in the same duct.
WARNING!
Risk of electromagnetic interference between battery cables and output cables.
Common Mains Load
N N
Battery
Control
cables(1)
Mains Aux Mains
N N
Battery Load
N
Control
cables(1)
Correct installation
Common Mains Load
N N
Battery
≥10 cm ≥10 cm
Control
cables(1)
≥10 cm
Mains Aux Mains
N N
Battery Load
N
≥10 cm ≥10 cm ≥10 cm ≥10 cm
Control
cables(1)
Acceptable installation
1. Control cables: connections between the cabinets and each unit, alarm signals, remote mimic panel, connection to the BMS
(Building Management System), emergency stop, connection to generator.

19EN
MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
5. OVERVIEW
Recommended configurations
Single unit configuration
BATTERY
CABINET
BATTERY
CABINET
BATTERY
CABINET
Parallel configuration with shared battery
BATTERY
CABINET
BATTERY
CABINET
BATTERY
CABINET
Parallel configuration with distributed battery
BATTERY
CABINET
BATTERY
CABINET
BATTERY
CABINET

20 EN MASTERYS GP4 60-120 kVA - Ref.: IOMMASGPXX07-EN 01
MASTERYS GP4 front view
Control panel
UPS door
Luminous status bar
