SoftBank 820P User manual

Introduction
Thank you for purchasing SoftBank 820P.
!For proper handset use, read User Guide (this manual) and First Step Guide.
!Please keep this manual in a safe place for future reference.
!Accessible services may vary by service area, subscription, etc.
SoftBank 820P is compatible with both 3G and GSM network technologies.
Note
!Unauthorized copying of any part of this manual is prohibited.
!Manual content is subject to change without prior notice.
!Efforts have been made to ensure the accuracy and clarity of this manual. Please contact SoftBank Customer Center,
General Information (ZP.17-40) about unclear or missing information.
User Guide (Japanese), First Step Guide and Raku Raku Start Book (Japanese) are included with 820P. The function of each manual is
as follows.
!First Step Guide/Raku Raku Start Book: Basic instructions.
!User Guide: Detailed instructions.
!Tsukaikonashi Dokuhon (Japanese): Online advanced instructions.
・Tsukaikonashi Dokuhon is available for download:
http://www.softbank.jp/mb/r/support/820p/ (PC)
http://broadband.mb.softbank.jp/f/manual/820p/ (handset)
820P_Eng.book Page i Wednesday, January 30, 2008 11:00 AM

i
Settings
Internet
Entertainment
Managing Files
Tools/Bar Code Reader
Handset Security
Communication
Appendix
1
Getting Started
Basic Operations
Text Entry
Phone Book
Video Call
Camera
Connectivity
Messaging
S! Appli
Index ZP.17-32
Contents ZP.vi
Function/Service
Name Search
Objective Search ZP.ii
Index ZP.17-32
Objective Search
Overview ZP.iv
Contents ZP.vi
Function Search
Function List ZP.17-8
Display ZP.1-8
Using
Your Handset
Contents ZP.vi
Section Contents Z
Chapter Top Pages
Manual
Organization
Troubleshooting ZP.17-15
Warranty & Service ZP.17-39
Solving
Problems
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Content Search
820P_Eng.book Page i Wednesday, January 30, 2008 11:00 AM

ii
Media Player
Downloadmusic/video
files from websites via
Media Player directly.
Fun Stuff
Camera &
Video Camera
Downloading Tunes & Tones
Download music (Chaku-Uta®/Chaku
Uta Full®) files from mobile websites.
Customizing
820P Settings
Setting Ringtones
Set Chaku-Uta®, Chaku-Uta Full®or
Ringtone Flash®files as ringtones.
My Phone Number
Confirm your phone number on 820P in
Standby without navigating menus.
Confirming & Using
My Number &
My Mail Address
My Mail Address
Customized address may reduce spam.
Objective Search
Media Player: ZP.7-2
Pictures: ZP.6-6
Videos: ZP.6-8
My Number: ZP.2-11
Downloading Music: ZP.7-3
Customizing Handset Address:
ZP.12-4
Ringtones: ZP.16-2
Learning Your Handset
Learn key assignments, and navigate
menus to select & execute functions.
Making Mobile Calls
Use voice telephony or enjoy video
telephony with compatible mobiles.
Handset Menus: ZP.1-19
Parts & Functions: ZP.1-5
Voice Calls: ZP.2-2
Video Calls: ZP.5-3
Mastering Basics
820P_Eng.book Page ii Wednesday, January 30, 2008 11:00 AM

iii
Customizing Standby Display
Add wallpaper, set clock size/position
or set calendar to appear in Standby.
Wallpaper: ZP.8-9
Display: ZP.16-4
Sending My Contact Info
Save mail address and other details;
send to compatible devices wirelessly.
Messaging Multiple
Recipients
Enter multiple mail addresses/numbers
to send a message to all at one time.
Account Details: ZP.4-13
Sending Messages: ZP.12-4
Adding/Editing Recipients : ZP.12-15
Sending Files Wirelessly
Send files or your own mail address
saved in Account Details wirelessly to
other compatible devices.
Sending Account Details: ZP.4-13
Customizing User Interface
Download applications that mimic the
interface design of previously used
handsets.
S! Familiar Usability: ZP.1-21
Using Shortcuts to Functions
Access shortcuts to frequently used
functions in Standby.
Standby Window: ZP.1-17
Mastering Text Entry Methods
Enter text for Messaging functions or
to add/edit Phone Book entry items.
Using Messaging Services
Send both short or long text messages.
Attach image/sound files, etc. to S! Mail.
Text Entry: ZP.3-1
Accessing the Mobile Internet
Access Mobile Internet sites via Yahoo!
Keitai to browse sites or download files.
Yahoo! Keitai: ZP.13-2
Messaging: ZP.12-2
Feeling Mail: ZP.12-6
Arrange Mail: ZP.12-6
Playing Games
Download and install
S! Application Games
via Yahoo! Keitai.
Getting News (Japanese)
Set up S! Quick News to view a variety
of information contents.
S! Appli: ZP.14-1 S! Quick News: ZP.13-15
820P_Eng.book Page iii Wednesday, January 30, 2008 11:00 AM

iv
Simple Mode
Activate Simple Mode for easy
operation; increase font size and
Earpiece Volume.
ZP.1-22
820P Features
Bar Code Reader
Scan UPC or QR Codes. Access sites or
send messages, etc. via QR Codes.
ZP.11-11
PC Site Browser
View PC-based websites on 820P.
Select Small Screen or PC Screen.
Data Back-up/Management
Transfer data between handset and PC
for back-up and editing.
Yahoo! Keitai
Access Mobile Internet sites via Yahoo!
Keitai to browse sites or download files.
SoftBank Mobile
Features
Arrange Mail
Create HTML messages; select font
color/size, background; insert images.
ZP.13-5
Infrared: ZP.9-2
Bluetooth®: ZP.9-5
USB: ZP.9-10
ZP.13-2 ZP.12-6
S! Addressbook Back-up
Save Phone Book entries; back up
handset entries on Server, etc.
Feeling Mail
Add Pictographs, matching ringtones,
vibration and notification light to
messages.
ZP.4-10 ZP.12-6
Useful Features
PC-related
Functions
Overview
820P_Eng.book Page iv Wednesday, January 30, 2008 11:00 AM

v
S! Familiar Usability
Download applications that install
previously used handset model
interfaces.
e-Book Viewer/BookSurfing®
(Japanese)
Download e-media, like
e-books, e-comics, and
e-photobooks on 820P.
Near Chat (Japanese)
Exchange text messages with SoftBank
handsets via Bluetooth®.
ZP.7-10 ZP.9-5, P.15-4
Memory Card
Extend 820P internal memory
or back-up handset files, etc.
ZP.8-15
S! Town & S! Loop
(Japanese)
Enjoy these unique SoftBank Mobile
communication services on 820P.
ZP.15-2, P.15-3
Calendar & Alarm
Add events by time/date and set Event
Alarms to help manage your schedule.
Media Player
Play 820P/Memory Card
music/video files; stream
media via Yahoo! Keitai.
ZP.11-2, P.11-6
ZP.1-21
ZP.7-2
820P_Eng.book Page v Wednesday, January 30, 2008 11:00 AM

vi
Contents
Contents ...................................... vi
Package Contents...................... viii
Using This Manual ........................ix
Safety Precautions......................xiii
Handling Precautions...................xx
Copyrights and Others..............xxiii
Specific Absorption Rate (SAR) .xxvi
1.Getting Started
USIM Card.................................. 1-2
Parts & Functions....................... 1-5
About Battery .......................... 1-11
Handset Power On/Off............. 1-15
Information in Standby............ 1-16
Handset Menus........................ 1-19
Simple Mode............................ 1-22
Passwords................................ 1-24
2.Basic Operations
Making Voice Calls .................... 2-2
Answering Voice Calls ............... 2-5
Answer Phone............................ 2-6
Engaged Call Operations........... 2-8
Call Log...................................... 2-9
My Number .............................. 2-11
Calling while Abroad ............... 2-12
Manner Mode .......................... 2-13
3.Text Entry
Text Entry .................................. 3-2
Entering Characters................... 3-5
Conversion Methods
(Japanese).................................. 3-8
Editing Text ............................. 3-10
Advanced Features .................. 3-11
4.Phone Book
Overview ................................... 4-2
Saving to Phone Book ............... 4-3
Editing Phone Book Entries....... 4-6
Group Settings .......................... 4-7
Searching/Using Phone Book..... 4-8
S! Addressbook Back-up ......... 4-10
Account Details ....................... 4-13
Advanced Features .................. 4-14
5.Video Call
Getting Started.......................... 5-2
Making Video Calls.................... 5-3
Answering Video Calls............... 5-4
Video Call Operations................ 5-5
6.Camera
Before Using Camera................. 6-2
Pictures...................................... 6-6
Videos........................................ 6-8
Other Camera Functions.......... 6-10
Camera Settings ...................... 6-12
Viewing Saved Images ............ 6-14
Advanced Features.................. 6-14
7.Entertainment
Media Player.............................. 7-2
E-Books (Japanese).................. 7-10
8.Managing Files
Data Folder................................ 8-2
Opening Files............................. 8-5
Using Files ................................. 8-9
Editing Still Images ................. 8-10
Managing Folders & Files........ 8-12
Memory Card........................... 8-15
9.Connectivity
Infrared...................................... 9-2
Bluetooth®................................ 9-5
USB (Japanese) ........................ 9-10
Location Settings..................... 9-10
820P_Eng.book Page vi Wednesday, January 30, 2008 11:00 AM

vii
10.Handset Security
Changing Handset Code.......... 10-2
USIM PINs................................ 10-2
Security Functions ................... 10-4
Reject Incoming Calls .............. 10-5
Secret Mode Setting................ 10-7
Reset........................................ 10-7
11.Tools/Bar Code Reader
Calendar .................................. 11-2
Alarms ..................................... 11-6
Calculator ................................ 11-9
Memo Pad ............................... 11-9
Voice Recorder ...................... 11-10
Bar Code Reader.................... 11-11
Advanced Features................ 11-13
12.Messaging
Basics....................................... 12-2
Sending S! Mail & SMS............ 12-4
Receiving &
Viewing Messages................... 12-9
Incoming Mail Folder ............ 12-13
Using Messages..................... 12-14
Advanced Features................ 12-15
13.Internet
Getting Started ....................... 13-2
Using Yahoo! Keitai ................ 13-3
Using PC Site Browser............. 13-5
Basic Operations ..................... 13-7
Using Information ................... 13-9
Option Menu Items ............... 13-14
S! Quick News (Japanese) ..... 13-15
Advanced Features................ 13-17
14.S! Appli
Before Using S! Appli.............. 14-2
Using S! Appli.......................... 14-3
Advanced Features.................. 14-4
15.Communication
S! Town (Japanese) ................. 15-2
S! Loop (Japanese) .................. 15-3
Near Chat (Japanese) .............. 15-4
16.Settings
Sound & Vibration................... 16-2
Display..................................... 16-3
Date & Time ............................ 16-6
Notification Light .................... 16-7
Keypad .................................... 16-7
Call Settings ............................ 16-8
Mode Settings....................... 16-11
Phone Book ........................... 16-12
Video Call .............................. 16-12
Bluetooth®............................ 16-13
Messaging ............................. 16-14
Internet ................................. 16-18
S! Appli ................................. 16-22
17.Appendix
Optional Services .................... 17-2
Function List............................ 17-8
Troubleshooting.................... 17-15
Software Update................... 17-18
Character Code List............... 17-20
Pictograph List ...................... 17-28
Symbol List............................ 17-29
Memory List .......................... 17-30
Specifications........................ 17-31
Index ..................................... 17-32
Warranty & Service ............... 17-39
Customer Service .................. 17-40
820P_Eng.book Page vii Wednesday, January 30, 2008 11:00 AM

viii
Package Contents
Handset (820P) Battery (PMBAE1) User Guide (Japanese)
First Step Guide
Raku Raku Start Book (Japanese)
Utility Software (CD-ROM)*
* Utility Software (Japanese) updates/upgrades may be released on SOFTBANK MOBILE Corp. Website (http://www.softbank.jp) without prior
notification. Please check for the newest versions of utility applications and download if required.
!Use SoftBank specified AC Charger (sold separately) to charge battery.
!For more information about AC Charger and accessories, please contact SoftBank Customer Center, General Information
(ZP.17-40).
!Optional battery is available for separate purchase.
!820P accepts microSD Card (not included). Purchase microSD Card to use related functions.
・Use microSD Cards up to 2GB (September, 2007). Memory Card compatibility is not guaranteed.
・microSD Card is referred to as "Memory Card" in this manual.
820P_Eng.book Page viii Wednesday, January 30, 2008 11:00 AM

ix
Using This Manual
In this manual, SoftBank 820P User Guide, SoftBank 820P is abbreviated as 820P.
Press the corresponding key to execute the function or operation indicated at the bottom of Display.
Sample screenshots, etc. are provided for reference only. Actual handset windows, menus, etc. may differ in appearance.
Manual Symbols
Multi Selector
Use Multi Selector to select items, navigate
menus, etc. In this manual, Multi Selector
operations are indicated as shown below.
Basic Multi Selector Operations
!: Press or
!: Press or
!: Press , , or
Softkeys
In this manual, Softkey operations are
indicated as shown below.
![Chg.Menu] and [Back] are Softkey label
examples; Softkey labels vary by menu.
Left Softkey Right Softkey
A[Chg.Menu] S[Back]
Screenshots
820P_Eng.book Page ix Wednesday, January 30, 2008 11:00 AM

x
When "(Japanese)" appears in a title, Japanese ability is required to use full range of the function or service.
Following are examples of operation descriptions. Please note, actual operations may differ.
Japanese Functions & Services
Operation Descriptions
Basic Operations
Abbreviated Steps
Main Menu operations expressed as shown here.
!For more information, see Handset Menus (ZP.1-19).
Steps
Use to select menu items.
Example: to scroll to
ON or OFF 7
!Alternatively, use Keypad to select items (ZP.1-20).
Omitted
Refer to Chapter 16 "Settings."
Refer to "Advanced Features" at the end of each
chapter.
820P_Eng.book Page x Wednesday, January 30, 2008 11:00 AM

xi
Advanced Operations
From these windows, proceed to advanced operations.
See indicated pages for preceding steps.
Example: [Composition Window], see P.12-4
Go to indicated page(s) and follow instructions to open
window.
Example: [Composition Window]
Proceed from here.
820P_Eng.book Page xi Wednesday, January 30, 2008 11:00 AM

xii
Settings
Initial steps are described here. Follow these steps then proceed to respective steps (explained in chart, under "Operation").
fij[
Scan QR Code shown to the right and download
Tsukaikonashi Dokuhon free of charge.
Separate subscription is required for Network access
(ZP.13-2).
Tsukaikonashi Dokuhon (Japanese)
Tsukaikonashi Dokuhon provides
supplemental information for
effective use of 820P. http://broadband.mb.softbank.jp/f/manual/820p/
To download Tsukaikonashi Dokuhon to PC, enter URL below and
access the website.
http://www.softbank.jp/mb/r/support/820p/
820P_Eng.book Page xii Wednesday, January 30, 2008 11:00 AM

xiii
Safety Precautions
■Before use, read these safety precautions carefully and use
your handset properly. Keep this manual in a safe place for
future reference.
■These safety precautions contain information intended to
prevent bodily injury to the user and to surrounding
people, as well as damage to property, and must be
observed at all times.
■These symbols indicate exposure levels to bodily harm from
failure to observe cautions or improper usage:
■Symbol Explanations
Danger Great risk of death or serious injury
from improper use
Warning Risk of death or serious injury from
improper use
Caution Risk of injury or damage to
property from improper use
Prohibited Action
Disassembly Prohibited
Avoid Moisture
Always Dry Hands First
Compulsory Action
Disconnect Power Source
820P_Eng.book Page xiii Wednesday, January 30, 2008 11:00 AM

xiv
Handset, Battery & Charger (not included)
Use specified battery, charger and holder.
The use of devices other than those specified may result
in malfunction of handset or battery. Leaking,
overheating, explosion or fire may occur.
Do not get handset, battery and charger wet.
If liquids such as water or pet urine get into battery and
charger, they may cause overheating, electric shock or
malfunction. Do not use handset in damp places like
bathrooms.
Do not disassemble or modify handset.
May cause accidents such as fire, bodily injury, electric
shock or equipment malfunction.
Do not place handset, battery or charger inside
cooking appliances, such as microwave ovens or
high-pressure containers.
Battery may leak, overheat, explode or catch fire, and
handset and charger may overheat, emit smoke or catch
fire. The internal circuit may also be damaged.
Do not throw or otherwise subject to strong force or
impacts.
Battery may leak, overheat, explode, catch fire, or cause
damage to handset.
Danger
Warning
Keep handset off and charger disconnected in filling
stations or places where flammable gas is generated.
Handset use in such areas may lead to fire.
If battery does not charge after specified time, stop
charging.
Battery may leak, overheat, explode or catch fire.
Do not use or leave handset or related hardware in
locations subject to high temperatures, such as near
an open flame/heater, in sunlight or inside a car on an
extremely hot day.
Do not charge, leave, use, or be carrying handset or
related hardware in a warm place or where heat
collects, such as under a kotatsu (blanketed warming
table) or electric blanket, next to a kairo (worn
warming patch), etc.
Battery may leak, overheat, explode, or ignite. Handset
or related hardware may deform or malfunction. Part of
the casing may also become hot and cause burns.
Do not use handset in dusty places.
May hinder heat release, or cause burnout or fire.
Keep handset out of the reach of young children.
May result in electric shock or bodily injury.
Caution
for rev_B_Safetyinformation_E.fm Page xiv Tuesday, March 6, 2012 3:58 PM

xv
If for use by child, guardian should teach proper
handling and ensure handset is used as directed.
May result in bodily injury.
Battery
See battery label to confirm battery type.
Do not throw battery into fire.
Battery may leak, overheat, explode or catch fire.
Do not pierce battery with a nail or other sharp
object, hit it with a hammer, or step on it.
Battery may leak, overheat, explode or catch fire.
Do not use excessive force to attach battery to
handset even when you cannot attach it successfully.
Battery may be the wrong way around.
Battery may leak, overheat, explode or catch fire.
Do not touch terminals with metallic objects or carry/
store battery with metal jewelry, etc.
Battery may leak, overheat, explode or catch fire.
Danger
Label Battery Type
Li-ion Lithium-ion
If battery fluid gets into eyes, do not rub; flush with
clean water and see a doctor immediately.
Failure to do so may cause blindness.
If battery leaks or emits an unusual odor, immediately
stop use and move it away as far as possible from any
flame or fire.
Battery fluid is flammable and could ignite, causing fire
or explosion.
If battery leaks or emits an unusual odor, immediately
remove it away from handset.
Battery may leak, overheat, explode or catch fire.
If battery fluid comes into contact with your skin or
clothing, stop using handset immediately and rinse it
off with clean water.
Battery fluid is harmful to your skin.
Do not dispose of battery with ordinary refuse.
May cause fire and environmental damage. Place tape
over the terminals to insulate battery, and take it to a
SoftBank retailer or institution that handles used
batteries in your area.
Warning
Caution
820P_Eng.book Page xv Wednesday, January 30, 2008 11:00 AM

xvi
Handset
Do not use handset while driving a vehicle.
Doing so may interfere with safe driving and cause an
accident. Stop your vehicle to park in a safe place before
using handset. Drivers using handsets while driving are
subject to prosecution.
Turn off handset near high-precision electronic
devices or devices using weak electronic signals.
Handset may possibly cause these devices to
malfunction.
*Electronic devices that may be affected: Hearing aids,
implantable cardiac pacemakers, implantable
cardioverter defibrillators, other medical electronic
devices, fire alarms, automatic doors and other
automatically controlled devices.Persons using an
implantable cardiac pacemaker or cardioverter
defibrillator, or other electronic medical devices, should
consult the device manufacturer or vendor for advice on
possible radio wave effects.
Warning
Turn off handset where use is prohibited, such as
aboard aircraft or in hospitals.
Handset may interfere with the operation of sensitive
devices and electronic medical equipment.
Follow the instructions given by the respective medical
facilities regarding the use of mobile phones on their
premises. In addition, actions such as speaking on a
mobile phone aboard aircraft are prohibited and may be
punishable by law.
If you are using electronic medical equipment, do not
put handset in your breast pocket or in the inside
pocket of your jacket.
Using handset in close proximity to electronic medical
equipment may cause the equipment to malfunction.
If you have a weak heart, take extra precautions
when setting functions such as vibration or ringer
volume for incoming transmissions.
Do not aim the infrared port at eyes when using
infrared communication.
Doing so may affect eyes. Also, aiming it towards other
infrared devices may interfere with the operation of
these devices.
In a thunderstorm, immediately turn off handset and
seek shelter.
There is a risk of being struck by lightning and suffering
electric shock.
820P_Eng.book Page xvi Wednesday, January 30, 2008 11:00 AM

xvii
Handset may become hot while in use. Avoid
prolonged skin contact that may result in burns.
If handset affects car electronics, stop use.
Handset use may affect electronics in some models. In
this case, stop use; could impede safe driving.
Do not place your ear too close to the speaker while
ringer sounds or sound files play.
May impair hearing.
Do not turn up the volume unnecessarily high when
using headphones.
Using headphones with volume turned up for an
extended period may impair hearing or injure ears.
Handset use may cause itching, rashes, eczema or
other symptoms depending on the user's physical
condition. In this case, immediately stop use and seek
medical treatment.
Caution
Parts Materials/Surface Finish
Outer case (Main Display
side, External Display side,
including hinge panel)
PC+ABS resin/
Acrylic UV cured coating
Outer case (Keypad side,
Battery side, Battery cover)
ABS resin/
Acrylic UV cured coating
Parts Materials/Surface Finish
Screw covers
(Battery cover side, below
display - hinge side)
ABS resin/
Acrylic UV cured coating
Infrared Port Acrylic resin
Main Display Panel,
External Display Panel
Base: PC resin
Surface: Acrylic resin
External Camera Panel Acrylic resin
Keys PC resin (Outline Panel: PET resin)
Earphone Port cover,
External Port cover
PC+ABS resin, Elastomer resin/
Acrylic UV cured coating
Memory Card Slot cover PC+ABS resin, Elastomer resin/
Acrylic UV cured coating
One-push Open Button hinge PC resin/Acrylic UV cured coating
Decorative Panels of the
hinge side Aluminium/Alumite treatment
Side Key PC resin/Acrylic UV cured coating
Charging Terminals Phosphor bronze/
Gold plating on nickel plating
Stop pad Acrylic Urethane resin
Screws
(Battery compartment)
SWCH16A (Aluminium killed steel)/
Nickel plating
Battery compartment Stainless
Battery
terminals
Connector PPS resin
Battery terminals Beryllium copper/
Gold plating on nickel plating
Battery
Battery PC resin (label: PET resin)
Terminals Glass fiber reinforced epoxy board/
Gold plating on nickel plating
820P_Eng.book Page xvii Wednesday, January 30, 2008 11:00 AM

xviii
Do not place a magnetic card near or in handset.
The stored magnetic data in cash cards, credit cards,
telephone cards and floppy disks, etc. may be erased.
Do not swing handset by its strap, etc.
Handset may strike you or others resulting in injury or
damage to handset or other property.
Do not use One-push Open button to open handset
near your or another person's face.
Handset may cause accident and injury.
Avoid closing handset on fingers or objects when
opening it.
May result in injury or damage to display.
When using One-push Open button, avoid pinching
fingers or objects in hinge.
May result in injury or damage to display.
Charger (not included)
Place charger and Desktop Holder on a stable surface
during charging. Do not cover or wrap charger or
Desktop Holder.
May cause overheating, fire or malfunction.
Do not handle charger with wet hands.
May result in electric shock or malfunction.
Warning
Always use the specified power supply/voltage.
Using incorrect voltage may cause malfunction/fire.
AC Charger: AC100V-240V
In-Car Charger: DC12V, 24V
(vehicles with a negative earth only)
Do not use handset/charger in thunderstorms.
There is a risk of being struck by lightning and suffering
electric shock.
Do not short-circuit charging terminals.
May result in fire, electric shock, equipment malfunction
or bodily injury.
Use In-Car Charger in vehicles with a negative
(-) earth. Do not use In-Car Charger if vehicle has a
positive (+) earth.
May cause fire.
Unplug AC Charger during periods of disuse.
May cause electric shock, fire or malfunction.
If In-Car Charger fuse blows, always replace it with
specified fuse.
Using the incorrect fuse may cause fire or malfunction.
Refer to the respective manuals for information on the
correct fuse specifications.
If liquid such as water or pet urine get into charger,
unplug it immediately.
May cause electric shock, smoke emission or fire.
820P_Eng.book Page xviii Wednesday, January 30, 2008 11:00 AM
