solamagic IR 02004 Quick guide



500 W, (IR 02004 / IR 02016)
1000 W, (IR 02007 / IR 02010)
1400 W kompakt, (IR 02001)
2000 W Basic, (IR 03002)
2000 W RC, ECO+, (IR 04003)
2000 W IP65 ECO+, (IR 04006)
2800 W, (IR 04009)
All in one, (IR 02041)


96

Safety and operating instructions...................................97
Scope of supply ..............................................................98
Installation instructions....................................................99
Initial operation..............................................................104
Cleaning instructions.....................................................104
Troubleshooting ............................................................106
Guarantee conditions....................................................107
Additional instructions...................................................108
Appendices
• Appendix 1: Surface mounted heaters
Technical data, safety distances
• Appendix 2: Ceiling mounted heaters
Technical data, safety distances
• Radiation diagrams
AX
AX
AX


97

Please observe the following instructions:
Carefully read through the instruction manual prior to installation and store the
manual safely.
This heater can be used by children aged 8 years or older and persons with
reduced physical, sensory or mental capabilities or lack of experience and know-
ledge, provided they have been given supervision or instruction regarding the
safe use of the device and that they understand the resulting risks. Children must
not play with the heater. Cleaning and user maintenance must not be performed
by unsupervised children. Children younger than 3 years old must be kept away
from the heater unless they are continuously monitored. Children older than 3
and younger than 8 years may only switch the heater on and off if they are moni-
tored or have been taught how to use the heater safely and have understood the
resulting dangers; this provided that the heater is placed or installed in its normal
place of use. Children older than 3 and younger than 8 years must not plug the
heater into the wall socket, adjust the heater, clean the heater and/or perform any
user maintenance.


-
cordance with VDE 0100 installation instructions (if applicable, also including
Parts 559 and 701).
• When carrying out any work, always switch the system to a zero-volts state
(disconnect mains plug; circuit-breaker off). Switch on the heater only after all
cables have been completely connected.
• The heater must be protected with at least a 16A (slow) fuse.
• Do not install directly under sockets, junction boxes, switches or electrical
cabling.
• Do not mount the radiant heater close to curtains or combustible materials in
accordance with VDE 0100, Part 559.
• If being used in wet rooms, observe the installation instructions, VDE 0100,
Part 701. Heaters must be installed in bathrooms such that the switch cannot
be touched by a person in the bath or under the shower.
• Never leave the heater unattended.




98
• This heater is not equipped with a room temperature control unit and must
not be used in small rooms that are inhabited by people who cannot leave the
room independently, unless constant supervision is ensured.
• To adjust the radiation direction, switch the heater off and allow to cool.
• Do not look directly at an operating IR halogen lamp for a long period and from
a short distance.
• IR halogen lamps are sensitive to direct skin contact (do not touch with bare
-
aked cloth.
• To maintain the service life of the IR halogen lamp, it must be protected against
vibrations, impacts and contaminants such as acids, ammonia, cement dust,
etc.
• The IR halogen lamp must be protected against mechanical loading. It must be
replaced, if discolouration (dark spots, deformation) becomes apparent or the
rated life time is reached.
• Repair work (replacement of a defective power lead of a defective heating tube
or the like) must only be carried out by the customer service of the manufactu-
rer or an authorised dealer.
-
ent expertise.

IR radiant heater
Installation and Instruction Manual


99

• The heater must only be installed using suitable fastenings (e.g. use M6x60
-
• If heater and socket are not installed on the same surface, it must be ensured
it must be ensured that the socket cannot heat up to more than 70°C during
heater operation.
„bottom“ power cord arrangement.
• The safety distances given in Appendixes 1 and 2 must be observed.
• The area in which the heat acts can be estimated from the radiation diagram
(Appendix 3). The diagram shows the sizes of the irradiated areas at various
distances from the radiant heater and in each case the maximum radiation
intensity.
• Installation height: at least 1.80 m above the ground


100
  



• Fasten the bracket taking into consideration the safety distances (Appendix 1)
and safety and operating instructions.
• Unscrew the star grip nuts and hexagon nut from the threaded spindles
• Mount the heater while slightly bending the bracket
• On one side, screw the hexagon nut on to the threaded bolt and tighten against
the bracket
• Set the radiating angle as required
• Tighten the M6 nut with a 10 mm open-ended spanner.
• Screw the star grip nuts in place on both sides.


101

• Mount the T-bracket with the underlying silicone plate on the fastening surface
using 2 screws while adhering to the safety distances and safety instructions
(see Appendix 1)
• Centre the clamping slide on the heater and secure by tightening the clamping
screws.
• Position the heater on the T wall bracket using the clamping slide. Insert the
M6 screws, complete with 6.4 mm serrated washer, on the sides through the
clamping slide into the T wall bracket, then manually tighten.
• Position the heater so that it radiates in the desired direction and then tighten
the two M6 screws using a 5 mm Allen key.


102
• Determine the appropriate mounting sepa-
ration of the pivoting hinges on the heater.
• Secure the ceiling plates at the selected
separation using suitable fasteners on the
wall/ ceiling.

     
     

• Tighten the hinges on the t-nuts until they
can no longer move relative to the heater,
tighten the M3 grub screws.
• Adjust the hinges until the desired tilting di-
rection is achieved.
• Position and tighten the M5 grub screws in
the ceiling plates.

     

     




103
General instructions
• The installation must not change or impair the existing ceiling stand.
• The electrical connection must be made outside the installation frame (inspec-
tion access).
• The minimum distances given in appendix 2 indicate the free space for air circu-
lation. These must not be reduced or covered by insulation or similar.
Installation steps:
• Create a ceiling cut-out with the dimensions given in appendix 2.
• Connect the heater to the electricity.
spring (2) back at the installation frame and also insert this side in the ceiling
cut=out.
• Position the retaining springs (2) against the inside of the ceiling cut-out.

Please observe the special assembly instructions supplied with the additional ac-
cessories.


104

The heater must beconnected to the mains. For those models without a wall or pull
switch, heating starts as soon as the plug is plugged into the socket. For models
with a wall or pull switch or a wireless switch, heating starts when the switch is
turned on or via the remote control.
If necessary see also the separate operating instructions for the remote control.

• Disconnect the heater from the mains.
• Allow the casing to cool.
• Wipe the casing clean with a moist, soft cloth. Do not use any detergent.












Switch activation
1x – Light on/heat off
2x – Light off/heat on
3x – All on
4x – All off
L = Brown
N = Blue
WS = Radiant heater
EBS= Recessed downlight
„All in one“ wiring diagram


105

(„All in one“ version)
1. Hold the rotating housing on the
activation hook, turn the glass
retaining ring with glass to the
left.
2. Take out the glass and retaining
ring.
Pull out the bulb.
3. Insert new bulb and reassembly
the lamp in reverse order.


106


• In the case of switch-activated models, the switch must be switched on after
connection to the mains.
• Have you checked your fuse rating? You require a 16 amp slow fuse for troub-
le-free operation of your heater.
• Please check whether the IR halogen lamp is broken. If yes, please contact
either customer service or the manufacturer.

• Check the radiation angle. The objects to be heated must be located in the
• Check the distance to the heater and its installation height.
data.

• The average service life of IR halogen lamps is 5000 hours.
• If the useful service life has elapsed, please contact either customer service or
the manufacturer.





107


1. We will repair, free of charge, in accordance with the following provisions, dama-
ge or defects to the heater, which can be proven to be due to a factory defect, if
they are reported to us immediately upon discovery on the heater. The duration
of the guarantee for the heater is 2 years, for heaters labelled ECO+ we offer
a guarantee extended by 1 year, that is a total of 3 years. The duration of the
guarantee for the heating tube is 12 months up to a maximum 5000 operating
hours within this period.
The guarantee does not cover minor deviations from the design properties that
are irrelevant for the value and usability of the heater. Likewise the guarantee
does not cover damage caused by exceptional climatic conditions, abnormal
environmental conditions or unsuitable operating conditions. Your dealer will be
happy to advise about heater versions for use in such cases. No guarantee can
be given if the damage or defects on the heater arise from faulty installation or
failure to observe the operating instructions.
performance of guarantee is claimed with reference to this guarantee, must be to
be handed over or sent to the manufacturer or an authorized service centre. End
consumer labour and material costs are notrefunded. Proof of purchase with the
date of purchase and/or delivery date plus a detailed description of the fault must
always be presented.
3. Any guarantee claim becomes void if repairs or adjustments are made by per-
sons who are not authorisedby us orifour heaters are provided with spare parts,
supplementary parts or accessories that are not original parts, and have caused
a defect. The same applies if the name plate or the heater number has been
removed or rendered illegible.
4. Excluded from this guarantee are damage or defects from incorrect connection,
improper handling, mechanical damage, particularly to the heating tube, and fai-
lure to observe the installation and operating instructions. We accept no liability
for consequential damage.
5. Guarantee performances do not extend the guarantee period nor do they initiate
-
delayed, an equivalent replacement will be delivered, free of charge, upon the




108
request of the customer. In case of replacement, we reserve the right to enforce
a reasonable usage charge for time of use up until the time of replacement. Re-
placed heaters become our property.
6. The guarantee only comes into force when the customer has registered their
heater with the manufacturer by means of the guarantee card.




Subject to technical changes
These products are „Made in Germany“.
For more products and accessories
from ®, see:



109
Please note the following terminology in the appendix:
Appendix 1: Surface mounted heaters - technical data, safety distances
Heater type Marking
Product group Weight (kg)
Power connection Average service life (h)
Degree of protection
* IP 21 for devices with pull switch B1 Frame width
Power B2 Cut-out width
Protection rating L1 Frame length
H3 Ceiling separation L2 Cut-out length
A Distance to the side wall E
Maximum power Heated surface
Heater type Dimensions (mm)
Product group Weight (kg)
Power connection Average service life (h)
Degree of protection
* IP 21 for devices with pull switch 11 Distance (mm)
Power (W) 12 Ceiling installation
Protection rating 13 Wall installation
Marking A Distance to the side wall
C Distance to the wall behind D Distance to ceiling
E Distance to the irradiated surface
