solamagic IR 03001 Quick guide

GB
01/2022
1
Supplement
to installation and
instruction manual
SOLAMAGIC infrared radiator:
Tripod with base
The instructions in this document must be followed in conjunction with the
instructions in the installation and instruction manual of the respective de-
vice. Keep both the manual and this document for future reference.
General instructions
• ThestandhasbeenspecicallydesignedtocarrytherespectiveSOLAMAGIC
modelandmustnotbeusedforanyotherpurpose.
• Thestandmustbeplacedoutdoorsonarm,non-ammableoor.
• Make sure that the area around the stand cannot be accessed by people or
animals (caution: risk of collision and toppling over).
• TheminimumsafetydistancesspeciedinAppendix2oftheinstallationand
instructionmanualareminimumdistancesforproperaircirculation.Makesure
thatthesedistancestootherobjectsarealwaysmaintained.
• Theinfraredradiatormustbeinstalledataheightofminimum1.80mabovethe
ground.

GB
2
Installation procedure:
a)Fixturetobasestand-ECO+modelsupto2000Wwithbracket
(models:IR03001,IR04002)
Traverse with M8x50 knurled
screwontelescopictube
Max. extended
height2.20m
Secure the bracket with the
M6x40knurledscrews,washer
6.4,lockwasherandM6nutto
thetraverse
Securetheadapterrmlytothe
telescopic tube, using the 12.5
lock washer and the M12x30
screw.Screwtheassemblyinto
thebase.

23
b)Fixture to tripod - models with slide clamp (models: IR03001,
IR03002,IR04004,IR08002,IR08003)
Part C with M8x50 knurled
screw,ontelescopictube
Max. extended
height2.20m
Securetheadapterrmlytothe
telescopic tube, using the 12.5
lock washer and the M12x30
screw.Screwtheassemblyinto
thebase.
GB

4
01/2022
WilhelmKochGmbH|Splieterstr.23|D-48231Warendorf|
Tel.:0049(0)366286910|Fax:0049(0)3662869120|
Email:[email protected]|www.SOLAMAGIC.com
c)Fixturetotripod-S1modelsupto2000Wwithadapterclamp
(models:IR05001,IR05002)
Part C with M8x50 knurled
screw,ontelescopictube
Max. extended
height2.20m
Securetheadapterrmlytothe
telescopic tube, using the 12.5
lock washer and the M12x30
screw.Screwtheassemblyinto
thebase.
Start-up / operation:
• Positionthedevicesothatheatisradiatedinthedesireddirection,takinginto
accounttheinstructionsinAppendix2oftheinstallationandinstructionmanual.
Caution: The power lead must be extended away from the device.
Caution: Before repositioning the device, shut down the radiator and let it
cool down.
