STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 1
STRCOM
INSTALLATION AND OPERATION MANUAL
Fused String Combiners
© 2011, Solectria Renewables LLC
Subject to Change

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 2
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important instructions that shall be followed during installation and
maintenance of the STRCOM Fused String Combiners.
To reduce the risk of electrical shock, and to ensure the safe installation and operation of the
combiner, the following safety symbols are used to indicate dangerous conditions and important
safety instructions.
WARNING: This indicates a fact or feature very important for the safety of the
user and/or which can cause a serious hardware damage if not applied
appropriately.
Use extreme caution when performing this task.
NOTE: This indicates a feature that is important either for optimal system set-up or
operation.
EXAMPLE: This indicates an example.
POS: Positive connection point symbol
NEG: Negative connection point symbol
GROUND: Ground symbol
DC: DC electrical connection point symbol
SAVE THESE INSTRUCTIONS

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 3
IMPORTANT SAFETY INSTRUCTIONS
All electrical installations shall be done in accordance with the local and national electrical
codes ANSI/NFPA 70.
The STRCOM Fused String Combiner contains no user serviceable parts. Please contact
Solectria Renewables or a Solectria Renewables authorized system installer for
maintenance. (See Appendix C for Solectria Renewables contact information and
authorized system installers.)
Before installing or using the STRCOM Fused String Combiner, please read all
instructions and caution markings in this manual and on the STRCOM Fused String
Combiner unit as well as the PV modules and PV inverter (or Charge Controller).
Connection of the STRCOM Fused String Combiner with PV modules and a PV inverter to
the electric utility grid must be done after receiving prior approval from the utility company
and performed only by qualified personnel.
Disconnect all PV modules or completely cover the surface of all PV arrays with opaque
(dark) material before wiring them. PV arrays produce electrical energy when exposed to
light and could create a hazardous condition.
SAVE THESE INSTRUCTIONS

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 4
Table of Contents
1Introduction………………………………………………………………..………… 5
2Installation…………………………………………………………………..……….. 6
2.1 Checking for Shipping Damage…………………………………...………. 6
2.2 Combiner Mounting.…………………………………………..………….. 6
2.3 Electrical Connection and Connection to PV Modules, Inverter and
Surge/Lightning Protection. …………………………………………….... 9
3Operation, Tests and Commissioning the PV System ………………………..…….. 14
4Warranty Information and Liability………………………………..………………… 15
5Technical Data…………………………………………………..…………….……… 18
6Appendices…………………………………………………………………...……… 21
Appendix A: Product Datasheet……………………………………………...……… 21
Appendix B: Example String Sizing………………………………………...……….. 21
Appendix C: Contact Info and Authorized Distributors, Dealers and Installers……... 21
Appendix D: UL 1741 Listing Letter…………………………………….……………22

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 5
1 Introduction
The STRCOM String Combiner is a commercial, fused string combiner designed to be used for
combining multiple strings of PV modules for connection to an inverter or solar charge controller.
With this manual the STRCOM string combiner can be installed and operated safely. This
installation guide is used as reference for the commissioning and as a guideline on how to use the
string combiner most effectively.
In a large PV array, each string of PV modules must be fused before being paralleled and
connected to an inverter or charge controller. This string combiner is available in configurations
from 4 to 30 fuses. The combiner includes of choice of 600VDC rated fuses. Available fuses
sizes can be 8, 10, 12, 15 or 20A. Typically, the fuse size you chose is at least 1.56 x the short
circuit current rating of the PV string (or module used in the string) it protects. The fuse value
should not be more than the fuse rating listed on the module nameplate label or manual.
The STRCOM string combiner is available in either the standard version for use with negatively
grounded PV systems or an optional version for use with positively grounded systems (typically
used in conjunction with Sunpower Corp modules.) Note that neither the positive or negative
conductor is grounded in the string as this is typically done in the inverter for the system, however,
labeling is different in the negative and positive grounded string combiner versions.
The STRCOM fused string combiner is rated NEMA4 for outdoor use (NEMA4X Stainless Steel
also available as an option). It is designed and tested to be easy to mount and wire up. A flat tip
screwdriver is required to open the enclosure for typical rooftop applications and an optional lock
kit is available if access needs to be restricted farther.
Fig. 1 Fused String Combiner Application
Photovoltaic
Array
PVI 95KW
Inverter
Electrical
Grid
STRCOM
Fused String
Combiner(s)

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 6
2 Installation
WARNING: Before installing the string combiner, read all instructions and caution
markings in this manual and on the string combiner as well as on the photovoltaic
modules.
WARNING: Electrical installation shall be done in accordance with all local
electrical codes and the National Electrical Code (NEC), ANSI/NFPA 70.
2.1 Checking for Shipping Damage
The Combiners are thoroughly checked and tested rigorously before they are shipped. Even
though they are delivered boxed, in a rugged cardboard carton, shipped individually or on a pallet,
the combiners can be damaged in shipping.
Please inspect the combiner thoroughly after it is delivered. If any damage is noticed, please
immediately notify the shipping company. If there is any question about potential shipping
damage, contact Solectria Renewables. A digital photo of the damage may be very helpful.
Do not accept unit, if visibly damaged or note visible damage when signing shipping company
receipt. Report damage immediately to shipping company. Do not remove the unit from
pallet/packaging. If it is determined that the unit must be returned, an RMA# must be obtained
from Solectria Renewables.
2.2 Combiner Mounting
The combiner enclosure is rated NEMA4 (gasket sealed, rainproof) for typical mounting on a roof
with the PV array. Optional mounting tabs allow simple mounting to a wall, array racking (if
allowed) or to posts. When unpacking, remove cardboard shipping aids and tape inside enclosure.
NOTE: If the combiner is mounted outside, make sure the enclosure door remains
closed in case of rain during the installation process. The components inside the
enclosure will be damaged by exposure to rain.
Notes regarding mounting and placement of the combiner.
Criteria for device mounting:

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 7
Because the unit has a NEMA4 rating, it can be mounted outdoors.
The combiner is designed to be mounted vertically with all the conduits entering and exiting
the bottom (6 x 20”) of the unit. It can be mounted flat as well, but pay extra attention to seals.
Install the combiner in an accessible location following NEC codes for enclosure and
disconnect door clearances and proximity to other equipment. (See mounting diagram, Fig. 2a
and 2b)
Although not required, installation at waist or chest height allows easiest access and keeps the
unit above potential snow line or drifts. Installer sometimes prefer lower installation heights
for aesthetics or wind-loading reasons.
Although not required, the combiner and fuses will remain most cool if the combiner is located
in shade or partial shade from the array, roof equipment vault, walk-up or other equipment on
the roof.
CAUTION: Please follow these guidelines:
The combiner weight is 40 lbs. Be sure to verify load capacity of wall mounting area.
Allow at least 1” clearance around sides and at least ¼” space at back (the depth of the
mounting tabs) for cooling considerations in extreme conditions.
Be sure to leave ample space for conduits to enter and exit the bottom (6”x20”) of the unit.
Although less recommended for outdoor applications, if any conduits are entering or exiting
the right side for PV connections, be extra careful with the installation of the NEMA4 liquid-
tight conduit fittings to be sure that they are very well sealed.
3/8” Holes for
mounting
22.5”
24”
21.5”
23”
Nameplate label
Listing label
Country of
origin flag
Warning
Positive
ground
option label
Slotted Latch(s)

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 8
COMBINER
MOUNTING
TABS
WALL OR
STRUCTURE
UP
5/16 or 3/8”
BOLTS
CONDUITS
IN & OUT
WASHERS
Fig. 2a STRCOM Fused String Combiner Dimensional Mounting Diagram
Fig. 2b STRCOM Fused Combiner Mounting Diagram (side-view)
Mounting Details
Using the mounting diagram Fig. 2a and 2b choose whether wall, array structure or stand
mounting will be used. Be sure to allow NEC clearance for access to combiner. The units can
be mounted side-to-side if multiple combiners are being used.
It is recommended to use galvanized grade 5 or better bolts or stainless steel bolts. The correct
bolt size is 5/16” or 3/8” (or 8-10mm) diameter, SS or galvanized steel hardware is
recommended. Be sure to use flat washers and lock washers. If wall mounting is used, be sure
to verify sheer and pullout strength of anchors or other wall attachments.
WARNING: Injury could occur if the combiner mounting fails and the unit falls on a
person.
NOTE: Always use all 4 mounting tabs for mounting.
NOTE: The 40 lb. weight of the combiner will exert as much as 20 lbs. per bolt on
the 4 wall mounts. Make sure an appropriate safety margin is used for both shear
and tension of wall mounting bolts, anchors or other attachments.
NOTE: Do not leave enclosure door open when you are not actually working on
the inside the combiner.

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 9
Fig. 2c STRCOM Fused Combiner Conduit Exit Location Diagram (bottom-
view, from outside enclosure)
In order to maintain the Type 4 rating of the enclosure you must use NEMA 4 conduit
fittings. For Rigid and IMC Conduit, use the following Cooper Crouse-Hinds,
Myers Watertight Hubs or equivalent:
½” STG-1 1-1/4” STG-4 2-1/2” STG-7
¾” STG-2 1-1/2” STG-5 3” STG-8
1” STG-3 2” STG-6 3-1.2” STG-9
Install hubs per manufacturer’s instructions.
2.3 DC Electrical Connections to Fused Combiner
Fig. 3 Simplified electrical connection diagram
Array Conduit
Location(s)
Inverter Conduit
Location(s)
5.0”
6.0”
1.0”
0”
0”
4”
11”
17”
19.5”
20”
Door

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 10
Fig. 4 Fused String Combiner Features and Connections
WARNING: All electrical installations shall be done in accordance with all local
electrical codes and the National Electrical Code (NEC), ANSI/NFPA 70.
WARNING: Always be certain that all array strings are disconnected before working
on any wiring in the string combiner.
WARNING: Over-current protection for a battery circuit is to be provided by others.
Battery over-current protection is not provided by this string combiner.
Choosing correct fuse sizes for your combiner: This is done when you are ordering
the combiner. This string combiner is available in configurations from 8 to 30 fuses.
The combiner also includes your choice of 600VDC rated fuses. Fuses sizes can be
8, 10, 12, 15 or 20A. Typically, the fuse size you chose is at least 1.56 x the short
circuit current rating of the PV string (or module used in the string). The fuse value
should not be more than the fuse rating listed on the module nameplate label or
manual.
Example 1: PV module with 3.84A short circuit current rating and a 10A fuse rating.
1.56 x 3.84A = 5.990A
An 8 or 10A fuse can be selected for this module.
Example 2: PV module with 7.69A short circuit current rating and a 15A fuse rating.
1.56 x 7.69A = 11.996A
Array Fuses
(pos), 4-30
positions
Inverter
connections
(neg.)
NEMA4
Enclosure
Required conduit
exit locations
(see Fig. 2c)
PV Array
connections (neg.)
Ground Bars
PV Array
connections
(pos)
Negative
terminal block
Mounts
Tabs (4)
Inverter
connections (pos)
Door Ground
Bonding wires

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 11
A 12 or 15A fuse can be selected for this module.
Example 3: PV module with 8.12A short circuit current rating and a 15A fuse rating.
1.56 x 8.12A= 12.667A
A 15A fuse must be selected for this module.
Connection of Grounded Conductor Terminal Block (negative conductors):
The grounded connection terminal block in the standard version combiner, for array
and inverter connections is grounded by the inverter and is not to be grounded
anywhere else. In the standard version of the combiner, for negatively grounded
systems, the PV array negative and inverter negative conductors connect to this
block. (This block is used for the positive array and inverter connections in an
optional version for positively grounded systems.)
ARRAY CONNECTIONS: conductor size 8-12AWG can be used to connect to each
solar array string terminal block. Torque to 35 in-lb
INVERTER CONNECTIONS: conductor size 4AWG-400KCM can be used to
connect from the terminal block to the inverter. Torque to 375 in-lb
Connection of Ungrounded Conductors for fuses (positive conductors):
The ungrounded array conductors (positive conductors in a standard negatively
grounded system) connect to the fuses. One PV string connects to each fuse position.
ARRAY CONNECTIONS: conductor size 8-12AWG can be used to connect to each
solar array string fuse holder. Torque to 18-22 in-lb
INVERTER CONNECTIONS: conductor size 6AWG-350KCM can be used to
connect from the terminal block to the inverter depending on string combiner version:
# of wire
String Combiner Version positions Wire size Torque
4-12 fuse 1 6AWG-250KCM 275 in-lb
13-24 fuse 1 4/0 – 350KCM 340 in-lb
(or 2 1/0 – 250KCM 340 in-lb)
25-30 fuse 1 6AWG-250KCM 275 in-lb
and 1 4/0 – 350KCM 340 in-lb
(or 2 1/0 – 250KCM 340 in-lb)
Conduit Entrance locations:
It is recommended that PV array string conductor conduit(s) enter the lower right
corner of the combiner enclosure on the bottom or right wall. Array conduit(s) can
also enter anywhere on the right side or top right corner of the enclosure but to
maintain the NEMA4 rating of the combiner, NEMA4 rated, liquid-tight conduit
connectors must be used.
It is recommended that the conduit(s) to the inverter(s) exit the center of the enclosure
bottom.
Grounding Conductors:
The array frame and mounting structure equipment ground conductors should be
terminated on the ground bar provided in the combiner. There are several connection

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 12
points for array equipment ground conductors depending on the string combiner
model:
String Combiner Version positions wire size Torque
4-12 fuse 30 (2/lug) 14-12 AWG 25 in-lb
or 15 (1/lug) 12-10 AWG 20 in-lb
(1/lug) 8 AWG 25 in-lb
(1/lug) 6-4 AWG 35 in-lb
and 1 6AWG – 2/0 50 in-lb
13-30 fuse 50 (2/lug) 14-12 AWG 25 in-lb
or 25 (1/lug) 12-10 AWG 20 in-lb
(1/lug) 8 AWG 25 in-lb
(1/lug) 6-4 AWG 35 in-lb
and 1 6AWG – 2/0 50 in-lb
and 2 6AWG - 250KCM 275 in-lb
Lightning and Surge Protection:
The inverter used with the PV system must be listed to UL1741/IEEE1547 and
include required lightning and surge protection. It is a good practice to add additional
lightning and surge protection on inverter or system DC disconnects. The lightning
arrester can also be installed on the combiner but must be done in a way that
maintains the NEMA4 rating of the combiner if outdoors. Lightning arrester leads
should be connected to:
1- a ground bar terminal
2- a lug on the inverter side of the positive (+) fuse bus (you need to add an
appropriate lug for this to an available hole on the fuse bus.
3- one of the array terminal screws on the negative (-)terminal block.
Grounding Electrode Conductor:
As with all PV systems, a Grounding Electrode Conductor must be installed per
UL690.47 (and 250.166). This conductor should be sized according to these NEC
requirements.
To disconnect the inverter from the building/utility grid, turn off the DC disconnect, then the AC
disconnect. Turn off the AC 3-phase building/utility breaker if needed.

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 13
Fig. 5. STRCOM 30X__A String Combiner Wiring and
Typical Conduit Exits (open showing connection)
Representative
negative PV string
conductors, 10-8AWG
recommended.
Example negative
conductors to inverter.
Both can be 4AWG-
400KCM. Make sure
wire is NOT routed
near the ground lug.
Representative
positive PV string
conductors, 10-
8AWG
recommended.
Example positive
conductors to inverter.
Both can be 1/0AWG-
250KCM or one at
4AWG-350KCM.
Ground lugs for 25
conductors, 10-4AWG
(or 50, 14-12AWG) and
main lugs for up to
250KCM
Jumpers (2)

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 14
Fig. 6. STRCOM 15X__A String Combiner Wiring and
Typical Conduit Exits (open showing connection)
Representative
negative PV string
conductors, 10-8AWG
recommended.
Example negative
conductor to inverter.
1 or 2 wires can be
4AWG-400KCM
Representative
positive PV string
conductors, 10-
8AWG
recommended..
Example positive
conductor to inverter.
Can be 4AWG-
350KCM (or 2 wires
at 1/0-250KCM)
Ground lugs for 14
conductors, 10-4AWG
(or 28, 14-12AWG) and
main lugs for up to
250KCM
(Factory Jumper)
Representative
negative PV string
conductors, 10-8AWG
recommended.
Example negative
conductor to inverter.
Both can be 4AWG-
400KCM
Representative
positive PV string
conductors, 10-
8AWG
recommended..
Example positive
conductor to inverter.
Both can be 1/0AWG-
250KCM or one at
6AWG-250KCM.
Ground lugs for 7
conductors, 10-4AWG
(or 14, 14-12AWG) and
main lug for up to 1/0
Fig. 7. STRCOM 10X__A String Combiner Wiring and
Typical Conduit Exits (open showing connection)

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 15
WARNING: Fuses in fused combiner must only be replaced with the same make and
model fuse. KLKD8, KLKD10, KLKD12, KLKD15, KLKD20 or ATM8, ATM10,
ATM12, ATM15 or ATM20. 20A fuses not recommended for use in the 27-30 fuse
position versions.
3 Operation, Tests & Commissioning the PV System
The string combiner is mounted, all connections are made and you are ready to power it up with
the rest of the PV system.
NOTE: Make sure all tools, parts, etc. are removed from the string combiner before
connecting PV strings or uncovering modules.
WARNING: Make a final check for correctness of all AC and DC wiring to the
inverter and in the system. Fuse holders should be open at this point.
NOTE: With the PV modules connected (or uncovered) and inverter disconnects
still off, it is a good final precaution to check PV polarity once more simply by
carefully using a 600V, DC rated digital volt meter and probing the positive (+) and
negative (-) PV connections in the disconnect enclosure.
Checking Individual strings:
Checking Individual strings:
With the PV inverter still off so no current is being drawn from the array through the
combiner, you can check that each string is good by checking the voltage at each fuse
holder on the array side. It is best to open all the fuse holders BEFORE connecting the PV
strings (or uncovering the PV modules).
With all the fuses open, check each string for voltage and polarity by attaching negative
(for a neg. grounded system) lead of a 600VDC rated voltmeter to the negative terminal
block in the combiner and positive (in a pos grounded system) lead to each fuse holder on
the array side.
You should see very slightly different DC voltages from each string (assuming light no
significant shadows are on the array. The polarity should be checked to be correct on all
strings as well.
Close all the fuse holders.
Operation and tests:
Once the string voltages and polarities have all been checked, it is good to check the polarity at the
inverters DC disconnect also for correct polarity, then turn on the inverter.

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 16
- You should see the open circuit voltage of the array drop to roughly 75-80% once the inverter
starts to load the array to MPP.
- Check the current level of each string when the system is operating. This can be done with a
clamp-on amp meter (DC). Assuming constant sun intensity is on all the strings, the current output
should be similar for each string, within 5-10%, for example.
To check for an open PV string:
With the inverter on and the PV system running (producing power), open the enclosure and probe
each fuse holder on the array side and other lead of meter on negative terminal block (neg.
grounded systems). If there has been a short in a string, the fuse for that string may be blown.
You will see this because that string will sit at open circuit voltage while all the other strings are at
MPP voltage.
WARNING: The combiner should only be opened by qualified service technician.
WARNING: If the combiner is outdoors, only open it when the weather is clear and
dry and the unit is dry.
To check for a weak PV string:
With the inverter on and the PV system running (producing power), Open the enclosure and probe
each PV string on the array side with a current clamp. If there is a weak string, you will see lower
current on that string. A dead string will show no current at all. Once you find what string has a
problem, you can dig into the wiring and modules for that string to find and fix the problem.
Ground Currents:
Check ground conductors for no current flowing while system is operating. Before closing the
enclosure always check for any signs of problems such as corrosion, loose parts, insect or animal
infestation, excessive dirt/dust or over heated or deformed/aged-looking parts. Also be sure if any
wires were moved or cable ties cut, that they are replaced as new.
4 Product Warranty & RMA Policy
4.1 Warranty Policy
The Solectria Renewables Warranty Policy is stated below.
Solectria Renewables Warranty Coverage:
Solectria Renewables Limited Warranties are provided by Solectria Renewables, LLC. ("Solectria Renewables") and
cover defects in workmanship and materials..
Duration of a Solectria Renewables Warranty Period:
The warranty period is 60 months from the date of purchase of the SRTCOM Fused String Combiners by the end user
or 64 months after the delivery date from Solectria Renewables to distributor or dealer/installer, whichever is shorter.
If a warranty extension has been purchased, the term is defined as extension beyond 60 months. For example, if a 5-
year extension (to 10 years total) is purchased, the term becomes 120 months from date of purchase.
If Solectria Renewables repairs or replaces a product, its warranty continues for the remaining portion of the original
Warranty Period or 90 days from the date of the return shipment to the customer, whichever is greater.

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 17
All warranties are null and void if full payment for products and associated shipping are not received in full and in a
timely manner by Solectria Renewables.
Please contact Solectria Renewables Customer Service for further details on other products.
What will Solectria Renewables do?
Solectria Renewables will, at its option, repair or replace the defective product free of charge, provided that you notify
Solectria Renewables of the product defect within the Warranty Period for your product, and provided that Solectria
Renewables, through inspection, establishes the existence of such a defect and that it is covered by the Limited
Warranty.
Solectria Renewables will, at its option, use new and/or reconditioned parts in performing warranty repair and building
replacement products. Solectria Renewables reserves the right to use parts or products of original or improved design
in the repair or replacement. All replaced products and all parts removed from repaired products become the property
of Solectria Renewables.
Solectria Renewables will attempt to repair the unit within a reasonable time period (there is no reimbursement for lost
energy production.)
Solectria Renewables covers both parts and labor necessary to repair the product, and return shipment to the customer
via a Solectria Renewables-selected non-expedited surface freight within the contiguous United States and Canada.
Alaska and Hawaii and Rest Of The World are excluded. Contact Solectria Renewables customer service for details on
freight policy for return shipments outside of the contiguous United States and Canada.
Obtaining Service:
If your product requires troubleshooting or warranty service, contact your distributor or dealer/installer. If you are
unable to contact your distributor or dealer/installer, or the distributor or dealer/installer is unable to provide service,
contact Solectria Renewables directly at the number listed on the website in the customer service section for your
product.
Solectria Renewables may send personnel to a jobsite or contract with an area technician, installer or other authorized,
trained service personnel to service/replace components.
Direct returns may be performed according to the Solectria Renewables Return Material Authorization Policy. Call
for details.
In any warranty claim, dated proof of purchase must accompany the product and the product must not have been
disassembled or modified without prior written authorization by Solectria Renewables.
Proof of purchase may be in any one of the following forms:
- The dated purchase receipt from the original purchase of the product at point of sale to the end user, or
- The dated distributor or dealer/installer invoice or purchase receipt showing original equipment manufacturer (OEM)
status, or
- The dated invoice or purchase receipt showing the product exchanged under warranty.
Solectria Renewables provides trouble-shooting service Monday-Friday, 9am-6pm EST. Once a problem is identified,
necessary replacement component(s) will be dispatched within 1-2 days to the jobsite or the designated service
personnel's address or will be brought to the site by Solectria Renewables’ personnel.
What does the Solectria Renewables warranty not cover?
Solectria Renewables Limited Warranties do not cover normal wear and tear of the product or costs related to the
removal, installation, or troubleshooting of the customer's electrical systems. These warranties do not apply to and
Solectria Renewables will not be responsible for any defect in or damage to:
a) The product, if it has been misused, neglected, improperly installed, physically damaged or altered, either internally
or externally, or damaged from improper use or use in an unsuitable environment;
b) The product, if it has been subjected to fire, water, generalized corrosion, biological infestations, acts of God or
input voltage that creates operating conditions beyond the maximum or minimum limits listed in the Solectria
Renewables product specifications including high input voltage from generators and lightning strikes;

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 18
c) The product, if repairs have been done to it other than by Solectria Renewables or authorized, trained service
personnel;
d) The product, if it is used as a component part of a product expressly warranted by another manufacturer;
e) The product, if its original identification (trademark, serial number) markings have been defaced, altered, or
removed;
f) The product, if it has been damaged in shipping (unless approved in writing by Solectria Renewables);
g) Any installation and operation beyond the scope covered by relevant safety regulations (UL1741, NEC, etc.);
DISCLAIMER
SOLECTRIA RENEWABLES LIMITED WARRANTIES ARE THE SOLE AND EXCLUSIVE WARRANTY
PROVIDED BY SOLECTRIA RENEWABLES IN CONNECTION WITH YOUR SOLECTRIA RENEWABLES
PRODUCT AND ARE, WHERE PERMITTED BY LAW, IN LIEU OF ALL OTHER WARRANTIES, CONDITIONS,
GUARANTEES, REPRESENTATIONS, OBLIGATIONS AND LIABILITIES, EXPRESS OR IMPLIED, STATUTORY
OR OTHERWISE IN CONNECTION WITH THE PRODUCT, HOWEVER ARISING (WHETHER BY CONTRACT,
TORT, NEGLIGENCE, PRINCIPLES OF MANUFACTURER'S LIABILITY, OPERATION OF LAW, CONDUCT,
STATEMENT OR OTHERWISE), INCLUDING WITHOUT RESTRICTION ANY IMPLIED WARRANTY OR
CONDITION OF QUALITY, DISTRIBUTOR OR DEALER/INSTALLER ABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. ANY IMPLIED WARRANTY OF DISTRIBUTOR OR DEALER/INSTALLER ABILITY OR
FITNESS FOR A PARTICULAR PURPOSE TO THE EXTENT REQUIRED UNDER APPLICABLE LAW TO APPLY
TO THE PRODUCT SHALL BE LIMITED IN DURATION TO THE PERIOD STIPULATED UNDER THIS LIMITED
WARRANTY.
IN NO EVENT WILL SOLECTRIA RENEWABLES, LLC, INCLUDING ITS SUPPLIERS, MANUFACTURERS,
VENDORS, SUBCONTRACTORS, DISTRIBUTORS, DEALERS AND ANY OTHER AFFILIATES BE LIABLE FOR
ANY SPECIAL, DIRECT, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSSES, COSTS OR
EXPENSES HOWEVER ARISING WHETHER IN CONTRACT OR TORT INCLUDING WITHOUT RESTRICTION
ANY ECONOMIC LOSSES OF ANY KIND, ANY LOSS OR DAMAGE TO PROPERTY, ANY PERSONAL INJURY,
ANY DAMAGE OR INJURY ARISING FROM OR AS A RESULT OF ANY USE, MISUSE OR ABUSE, OR THE (IN-)
CORRECT INSTALLATION, INTEGRATION OR OPERATION OF THE PRODUCT.
Solectria Renewables neither assumes nor authorizes any other person to assume for it any other liability in connection
with the repair or replacement or the Product.
Exclusions of the Policy:
If your product is a consumer product, federal law does not allow an exclusion of implied warranties. To the extent
you are entitled to implied warranties under federal law, to the extent permitted by applicable law they are limited to
the duration of this Limited Warranty. Some states and provinces do not allow limitations or exclusions on implied
warranties or on the duration of an implied warranty or on the limitation or exclusion of incidental or consequential
damages, so the above limitation(s) or exclusion(s) may not apply to you. This Limited Warranty gives you specific
legal rights. You may have other rights, which may vary from state to state or province to province.
WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, UNLESS SPECIFICALLY AGREED TO BY IT IN
WRITING, SOLECTRIA RENEWABLES
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR
OTHER INFORMATION PROVIDED IN MANUALS OR OTHER DOCUMENTATION PROVIDED BY IT IN
CONNECTION WITH THE PRODUCT; AND
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE
OF SUCH INFORMATION.
THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER'S RISK.
WARNING: LIMITATIONS ON USE
Please refer to your product user manual for limitations on uses of the product. Specifically, please note that Solectria
Renewables products are not intended for use in connection with life support systems and Solectria Renewables makes
no warranty or representation in connection with any use of the product for such purposes.
Please review our Return Merchandise Authorization Policy for returning product to Solectria Renewables.

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 19
4.3 Return Material Authorization Policy
Please review our Return Merchandise Authorization Policy below after reviewing our Solectria Renewables Warranty
Policy.
Obtaining a required, Return Material Authorization:
Before returning a product directly to Solectria Renewables you must obtain a Return Material Authorization (RMA)
number and the correct factory "Ship To" address. Products must also be shipped prepaid. Product shipments will be
refused and returned at your expense if they are unauthorized, returned without an RMA number clearly marked on the
outside of the shipping box, if they are shipped collect, or if they are shipped to the wrong location.
Information Solectria Renewables needs when you are obtaining service:
1) The model names and serial number of your product
2) Information about the installation and use of the unit
3) Information about the failure and/or reason for the return
4) A copy of your dated proof of purchase.
Preparing the product for shipping:
1) Package the unit safely, preferably using the original box and packing materials. Please ensure that your product is
shipped fully insured in the original packaging or equivalent. This warranty will not apply where the product is
damaged due to improper packaging.
2) Include the following:
a. The RMA number supplied by Solectria Renewables, LLC clearly marked on the outside of the box
b. A return address to which the unit can be shipped. Post office boxes are not acceptable.
c. A contact telephone number where you can be reached during work hours.
d. A brief description of the problem.
Ship the unit prepaid to the address provided by your Solectria Renewables customer service representative.
Returning a product from outside of the USA or Canada:
In addition to the above, you MUST include return freight funds and are fully responsible for all documents, duties,
tariffs, and deposits.
5 Technical Data
Technical Information and specifications –see appendix for complete
STRCOM Fused String Combiner data sheet
Input (DC) from PV array:
Maximum open circuit voltage of PV array: 600V DC
WARNING: NEC 690-7 must be followed to calculate the maximum number of PV
modules allowed for a maximum inverter open circuit voltage (OCV) of 600V DC in
extreme cold temperatures for the installation location. (Note that some inverter
models have a lower maximum open circuit voltage than 600VDC, for example, the
PVI 15KW has a 475VDC maximum open circuit voltage.)
See PV string sizing charts in Appendix B

STRCOM Fused String Combiners Installation and Operation Manual
DOC-020040 rev 4.4 20
The open circuit voltage of PV modules depends on the cell temperature and the solar
irradiation. The highest open circuit voltage occurs when the PV modules are at the
coldest temperature and in bright sun.
Part Number scheme: STRCOM 10X15A (-P if for use with positively grounded PV systems)
STRCOM Fused String Combiner Configurations
STR-COM 4X___A
STR-COM 6X___A
STR-COM 8X___A
STR-COM 10X___A
STR-COM 12X-___A
STR-COM 13X-___A
STR-COM 14X-___A
STR-COM 15X-___A
STR-COM 16X-___A
STR-COM 17X-___A
STR-COM 18X-___A
STR-COM 19X-___A
STR-COM 20X-___A
STR-COM 21X-___A
STR-COM 22X-___A
STR-COM 23X-___A
STR-COM 24X-___A
STR-COM 25X-___A
STR-COM 26X-___A
STR-COM 27X-___A
STR-COM 28X-___A
STR-COM 29X-___A
STR-COM 30X-___A
Optional Mount Tab Kit
4 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
6 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
8 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
10 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
12 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
13 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
14 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
15 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
16 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
17 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
18 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
19 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
20 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
21 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
22 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
23 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
24 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
25 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
26 Fuse String Combiner (with 8, 10, 12, 15 or 20A fuses)
27 Fuse String Combiner (with 8, 10, 12 or 15A fuses, not for use with 20A fuses)
28 Fuse String Combiner (with 8, 10, 12 or 15A fuses, not for use with 20A fuses)
29 Fuse String Combiner (with 8, 10, 12 or 15A fuses, not for use with 20A fuses)
30 Fuse String Combiner (with 8, 10, 12 or 15A fuses, not for use with 20A fuses)
Optional mount tab kit (Four mount tabs and hardware. Mount to bottom/back of box in
existing mounting holes in enclosure)
Number of fuse positions
Current Rating of 600VDC fuses included
