Twin Dolly and TwinTube Unpack and Set Up instructions
Contents
TwinTube Undersleepers installation ....................................................................................................................2
Junior Stud Installation and Usage instructions ....................................................................................................3
TwinSliderBase Set Up............................................................................................................................................4
End Stop Set Up ......................................................................................................................................................5
Bowl Risers Set Up ..................................................................................................................................................6
TwinDolly ................................................................................................................................................................7
Precautions and Notes........................................................................................................................................7
General Remarks.................................................................................................................................................7
Offset Axle Adjustment Procedure ....................................................................................................................8
Set up for use on a standard Rigging Truss........................................................................................................9
BNC Arm..............................................................................................................................................................9
4 Way Leveler......................................................................................................................................................9
TwinTube Set Up examples ..................................................................................................................................10

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
TwinTube Undersleepers installation
When receiving a new set of TwinTubes without the optional Flightcase TTF300 or TTF150 you need to install the
UnderSleepers.
TwinTubes delivered with the optional FlightCase will have the UnderSleepers pre-installed.
Tools: Allen key 5mm
Instruction
Place the TwinTube upside down
Remove the pre-installed Allen key screws (4)*
Install the UnderSleepers (see picture) at both
CrossTies
* In some cases the Allen screws are not pre-installed but added
separately.
Note: Make sure to align the Undersleeper exactly as
displayed on the drawing

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
Junior Stud Installation and Usage instructions
Tools: None
Instruction
Manually insert the Junior stud in the dedicated screw
hole and fasten it hand-tight.
Note: the Junior Stud uses the 3/8 UNC camera
thread.
Insert the Junior stud in a junior receiver/Light Stand
(28mm)

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
TwinSliderBase Set Up
Tools: Allen key 5mm
Instruction
Righthand side picture shows the unmounted
TwinSlider Base.
Remove the pre-installed (angled) Allen key
screws (4) and take of the 2 clamps from the
TwinSliderBase.
Insert the 2 clamps from the top side of the
TwinTube section.
Install the TwinSliderBase from underneath
the TwinTube section and align with under the
clamps.
Install the 4 Allen screws and tighten them
equally.
Example of an installed set up.

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
End Stop Set Up
Tools: None
Instruction
Always install the End Stops at both ends before
adding the TwinDolly onto the TwinTubes.
Righthand side picture shows how the End Stops have
to installed.
Loosen the black knob a few turns and slide the End
Stop over the TwinTube CenterCross as shown.
Hand tighten the black knob and check if the End Stop
is firmly mounted onto the CenterCross by gently
pulling the End Stop.
Example of an installed set up with an End Stop at
both ends.

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
Bowl Risers Set Up
Tools: 10 mm (open) wrench
Instruction
The bowlrisers are intended to raise (or lower) the
bowl away from the fixed mounting studs of the
TwinDolly.
Righthand side picture shows the underslung option of
the bowl risers.
Remove the 4 Allen screws that hold the bowl.
Insert the bowl risers at the position of the
above mentioned 4 Allen screws.
Tighten the bowl risers with an appropriate
tool (10 mm wrench).
Mount the bowl onto the BowlRisers using the
4 Allen Screws from step 1.

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
TwinDolly
Tools: 13 mm open wrench and 5 mm Allen key
Operation Instructions
-
Precautions and Notes
Using common sense nothing can go wrong.
-
Whenever possible use Tip Protection. [1]
-
Always use clamps or junior studs as end
stoppers if our End-Stops are not available.
-
Two of the side wheels of a TwinDolly/TrussDolly
are mounted on offset axles. This makes it
possible to adjust the track width 6mm per axle,
thus 12mm per TwinTube or truss. Remember to
use the same setting for each axle, otherwise the
dolly will run obliquely along the rails.
General Remarks
All bolts that are not intended to be removed are
factory treated with Loctite 2701.
Excluded are: Brake, Tip Protection, Wheel shafts.
The top wheels have a diameter of 62mm and a
hardness of 78A.
The TWD side wheels have a hardness of 94A.
These values are the result of extensive testing.
Deviating from these values may negatively effect
the operation of the TwinDolly.
1

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
Tools: 13 mm open wrench and 5 mm Allen key
Operation Instructions
Offset Axle Adjustment Procedure
Fully release the brake.
Locate the Offset wheels opposite of the
Brake.
Loosen the Allen bolts of the wheel sets half
a turn. [2]
Use a 13mm wrench between the wheel
and the dolly to turn the axle to the desired
position. [3]
When the desired position is achieved re-
tighten the axle with an Allen key.
Check that the dolly can run freely in a
straight line without play but also without
too much pressure.
If the wheels are over tightened flat spots
can occur resulting in a bumpy dolly
movement.
If the wheels are too loose there will be play
in the dolly which will be felt at camera
pans.
2
3

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
Twin Dolly and TwinTube Unpack and Set Up instructions
Tools: 13 mm open wrench and 5 mm Allen key
Operation Instructions
-
Set up for use on a standard Rigging Truss.
When using wider truss or rigging, the offset
axles can be placed in the outer holes.[4].
Further adjustment is similar to the previous
described process.
BNC Arm
The hinged arm is intended to hold BNC or power
cables at a comfortable distance from the
dolly.[5]
4 Way Leveler
Installation of the SolidGripSystems 4-Way-
leveler goes best when following the next
suggestion:
first turn three of the leveling bolts of the leveler-
head maximum out and the remaining bolt fully
inwards before starting to assemble.
4
5

SolidGripSystems - Emrikweg 27 - 2031BT - Haarlem - The Netherlands
Phone [phone] - www.solidgripsystems.eu [e-mail]
TwinTube Set Up examples
