Sollae Systems CSE-M53G User manual

Sollae Systems Co., Ltd.
https://www.ezTCP.com
Embedded Serial to Ethernet Module
CSE-M53G User Manual
Version 1.0

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 1 - https://www.ezTCP.com
This symbol, found on your product or on its packaging, indicates that this
product should not be treated as household waste when you wish to dispose of
it. Instead, it should be handed over to an applicable collection point for
the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences
to the environment and human health, which could otherwise be caused by inappropriate
disposal of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about the recycling of this product, please
contact your local city office, household waste disposal service or the retail store
where you purchased this product.

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 2 - https://www.ezTCP.com
Contents
1Overview ............................................................................................................................................- 5 -
1.1 Overview ................................................................................................................................................................- 5 -
1.2 Main Features ......................................................................................................................................................- 5 -
1.3 Examples of Application .................................................................................................................................- 6 -
1.4 Specification .........................................................................................................................................................- 8 -
1.4.1 Hardware ......................................................................................................................................................- 8 -
1.4.2 Software ........................................................................................................................................................- 8 -
1.4.3 Dimension ....................................................................................................................................................- 9 -
1.4.4 Pins............................................................................................................................................................... - 10 -
1.4.5 Serial Port Parameters ......................................................................................................................... - 12 -
1.4.6 Electrical characteristics ...................................................................................................................... - 12 -
1.4.7 An Application Circuit.......................................................................................................................... - 13 -
2Installation and Test ..................................................................................................................... - 14 -
2.1 IPv6 address ...................................................................................................................................................... - 14 -
2.2 Installation.......................................................................................................................................................... - 14 -
2.2.1 Setting Network Aera .......................................................................................................................... - 15 -
2.3 Simple Test......................................................................................................................................................... - 17 -
3Configuration ................................................................................................................................. - 20 -
3.1 Configuration with ezManager................................................................................................................. - 20 -
3.1.1 Configuration via LAN......................................................................................................................... - 20 -
3.1.2 Configuration via Serial ...................................................................................................................... - 21 -
3.2 AT command..................................................................................................................................................... - 22 -
4Operation Modes .......................................................................................................................... - 23 -
4.1 What is the Operation Mode?.................................................................................................................. - 23 -
4.2 How to entering each mode ..................................................................................................................... - 23 -
4.3 Comparison with each mode.................................................................................................................... - 24 -
4.4 Normal Mode ................................................................................................................................................... - 24 -
4.5 Serial Configuration Mode ......................................................................................................................... - 25 -
4.6 ISP Mode ............................................................................................................................................................ - 25 -
4.6.1 Upgrading Firmware............................................................................................................................. - 25 -
4.6.2 Revoking Serurity Options................................................................................................................. - 25 -
5Communication Modes ................................................................................................................ - 26 -
5.1 TCP Server .......................................................................................................................................................... - 26 -
5.1.1 Key parameters....................................................................................................................................... - 26 -

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 3 - https://www.ezTCP.com
5.1.2 Examples.................................................................................................................................................... - 27 -
5.2 TCP Client ........................................................................................................................................................... - 30 -
5.2.1 Key parameters....................................................................................................................................... - 30 -
5.2.2 Examples.................................................................................................................................................... - 31 -
5.3 AT Command .................................................................................................................................................... - 34 -
5.3.1 Key parameters....................................................................................................................................... - 34 -
5.3.2 Examples.................................................................................................................................................... - 35 -
5.4 UDP ....................................................................................................................................................................... - 38 -
5.4.1 Key parameters....................................................................................................................................... - 38 -
5.4.2 Examples.................................................................................................................................................... - 39 -
6System Management.................................................................................................................... - 41 -
6.1 Upgrading Firmware...................................................................................................................................... - 41 -
6.1.1 Firmware .................................................................................................................................................... - 41 -
6.1.2 Processes ................................................................................................................................................... - 41 -
6.2 Status Monitoring ........................................................................................................................................... - 43 -
6.2.1 Using TELNET .......................................................................................................................................... - 43 -
6.2.2 Using ezManager................................................................................................................................... - 46 -
7Additional Functions..................................................................................................................... - 50 -
7.1 SSL ......................................................................................................................................................................... - 50 -
7.1.1 What is the SSL(Secure Socket Layer)? ....................................................................................... - 50 -
7.1.2 How to set the SSL............................................................................................................................... - 50 -
7.1.3 Restrictions ............................................................................................................................................... - 51 -
7.2 Access Restriction (ezTCP Firewall) ......................................................................................................... - 52 -
7.2.1 Setting Password.................................................................................................................................... - 52 -
8Additional Functions..................................................................................................................... - 53 -
8.1 Notify IPv4 Change ........................................................................................................................................ - 53 -
8.2 Sending MAC Address.................................................................................................................................. - 54 -
8.3 Serial Port Tab Functions............................................................................................................................. - 55 -
8.3.1 Disable TCP Transmission Delay - ①........................................................................................... - 55 -
8.3.2 Separator - ②.......................................................................................................................................... - 55 -
8.3.3 TELNET COM port Control Option (RFC 2217) - ③.............................................................. - 56 -
8.3.4 TCP Server / Client mode - ④........................................................................................................ - 56 -
8.4 Factory Reset..................................................................................................................................................... - 57 -
9Checklist in Trouble ...................................................................................................................... - 58 -
9.1 Searching problem with ezManager...................................................................................................... - 58 -
9.2 Connection Problem over TCP/IP............................................................................................................ - 59 -
9.3 Data Communication Problem on the Serial..................................................................................... - 60 -

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 4 - https://www.ezTCP.com
10 Related Material ............................................................................................................................ - 61 -
10.1 Technical Documents .................................................................................................................................... - 61 -
10.2 Smart phone Application ............................................................................................................................ - 61 -
11 Technical Support and Warranty................................................................................................ - 62 -
11.1 Technical Support ........................................................................................................................................... - 62 -
11.2 Warranty.............................................................................................................................................................. - 62 -
11.2.1 Free Repair Services ............................................................................................................................. - 62 -
11.2.2 Charged Repair Services..................................................................................................................... - 62 -
12 Precaution and Exemption from Liability................................................................................. - 63 -
12.1 Precaution........................................................................................................................................................... - 63 -
12.2 Exemption from Liability.............................................................................................................................. - 64 -
12.2.1 English version........................................................................................................................................ - 64 -
12.2.2 French version......................................................................................................................................... - 65 -
13 History............................................................................................................................................. - 67 -

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 5 - https://www.ezTCP.com
1 Overview
1.1 Overview
Most of industrial devices support standard serial communications in which the
sender transmits the stream of bits to the receiver in order. Although serial
communication is known for its simplicity, its limitations are on the short
communication distance and the requirement of frequent maintenance, which prevent it
from being popularly used in modern computing environment.
By providing Internet connection to serial communication devices, CSE-M53G enables
them to overcome these limitations. Specifically, CSE-M53G, which has TCP/IP stack
and serial communication capability, converts serial data to TCP/IP data, and vice
versa.
1.2 Main Features
⚫Serial to Ethernet Module
⚫Super-compact module type: 20mm x 24mm
⚫Pin-compatible design with CSE-M53 and CSE-M53N
⚫IPv4 / IPv6 dual-stack
⚫High-speed UART(Up to 921.6Kbps, under certain conditions)
⚫1 x UART, available on RS232/RS422/RS485 extension
⚫Industrial temperature range (-40℃ ~ +85℃)
⚫Security options (SSL/TLS, IP filtering, Password)
⚫Separator settings for packet fragmentation
 There are differences among CSE-M53, CSE-M53N, and CSE-M53G due to MCU
functions, despite the Pin-compatible design. Therefore, be sure to test the
compatibility when using CSE-M53G as an alternative.

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 6 - https://www.ezTCP.com
1.3 Examples of Application
⚫1:1 Connection between a serial device and a PC
Figure 1-1 1:1 connection with a PC
⚫Serial device connecting to LAN (Local Area Network) via CSE-M53G
Figure 1-2 Application to LANs

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 7 - https://www.ezTCP.com
⚫Serial device connecting to the Internet via CSE-M53G and a cable modem
Figure 1-3 CSE-M53G connecting a serial device to the Internet via cable networks
⚫Serial device connecting to the Internet via CSE-M53G and an IP Share Router
Figure 1-4 CSE-M53G connecting a serial device to the Internet via IP Share Router

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 8 - https://www.ezTCP.com
1.4 Specification
1.4.1 Hardware
Power
Input Voltage
DC 3.3V (±0.3V)
Current
consumption
100M Ethernet - 100mA typical
10M Ethernet - 150mA typical
Dimension
24 mm x 20 mm x 9.1mm
Weight
About 3.2g
Interface
Serial Port
1 x UART –3.3V level with 5V tolerant input
- RS232: 300bps ~ max. 921,600bps
- RS422/485: 300bps ~ 230,400bps
Network
10 Base-T or 100 Base-TX Ethernet Auto-Sensing
Auto MDI or MDIX cable Auto-Sensing
Temperature
Operating/Storage: -40 ~ 85℃
RoHS
RoHS Compliant
Table 1-1 hardware specification
1.4.2 Software
Protocol
TCP, UDP, IPv4/IPv6 dual stack, ICMPv6/TCPv6/UDPv6, ICMP, ARP,
DHCP, PPPoE, DNS, DDNS(Dynamic DNS), Telnet, SSL, Telnet COM Port
Control Option (RFC 2217)
Operation
mode
Normal
For Normal Data Communication
ISP
For Upgrading F/W
Serial
Configuration
For Configuration via Serial
Communicati
on mode
TCP Server
TCP Passive Connection
TCP Client
TCP Active Connection
AT Command
TCP Passive / Active Connection
UDP
UDP –No Connection
Major
Utilities
ezManager
Configuration Utility for MS Windows
(Supports Downloading F/W)
ezVSP
Serial to TCP/IP Virtual driver for MS
Windows
Table 1-2 software specification

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 9 - https://www.ezTCP.com
1.4.3 Dimension
The dimension of CSE-M53G is followed. (Unit: mm)
Figure 1-5 dimensions of CSE-M53G

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 10 - https://www.ezTCP.com
1.4.4 Pins
⚫JP1 / JP2 Connector
JP1 and JP2 have headers of 2mm pitch. There are two triangle marks by the
first pin (pin number 1) of JP1 and JP2.
JP1
Name
Description
Direction
1
GND
Ground
-
2
TP_RXN
LAN IN -
Input
3
TP_RXP
LAN IN +
Input
4
GND
Ground
5
TP_TXN
LAN OUT -
Output
6
TP_TXP
LAN OUT +
Output
7
GND
Ground
-
8
RXD_LED
LAN RECEIVE LED (Data Received –Low)
Output
9
TXD_LED
LAN SEND LED (Data Transmitted –Low)
Output
10
LINK_LED
LINK LED (Connected with a LAN network –Low)
Output
Table 1-3 JP1
JP2
Name
Description
Direction
1
VDD_3.3V
DC 3.3V (±0.3V) volt power (VDD)
-
2
RST-
System Reset (Low Active)
Valid time for giving Low signal
: duration over 200us is recommended
※Normally, it is input. When reset, it
outputs low signal.
Input/
Output
※
3
ISP-
Changing modes
Input
4
GND
Ground
-
5
RXD
UART IN
Input
6
TXD
UART OUT
Output
7
CTS
UART CTS
Input
8
RTS
UART RTS (Request To Send, –Low),
TXDE in RS485 (Sending data –High)
Output
9
TCP
TCP Status LED
( Connected –Low, Not connected –High )
Output
10
STS_LED
Status LED ( It operates depending on the
state - refer to the Table 1-5)
Output
Table 1-4 JP2

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 11 - https://www.ezTCP.com
State
Wave form
In ISP mode
In Serial
Configuration mode
When any IP addresses
have not been
assigned
When IP addresses
have been assigned
but not connected
with a remote host on
TCP.
Connected with
a remote host on TCP
Table 1-5 STS_LED operation depending on the state

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 12 - https://www.ezTCP.com
1.4.5 Serial Port Parameters
Parameter
Value
Number
1
Type
3.3V level with 5V tolerant input
Baud rate
RS232 without Xon/Xoff : 300 ~ 921,600 bps
RS232 with Xon/Xoff : 300 ~ 230,400 bps
RS422 / RS485 : 300 ~ 230,400 bps
using SSL : 300 ~ 115,200 bps
Parity
NONE / EVEN / ODD / MARK / SPACE
Data bit
8 / 7
Stop bit
1 / 2
Flow control
NONE, RTS/CTS, Xon/Xoff
Table 1-6 serial port parameters
 7 data bits with NONE parity is not supported.
 A single idle bit is automatically added after every stop bit by the MCU
function.
1.4.6 Electrical characteristics
Symbol
Description
Condition
Min
Max
Unit
VIH
High-level input voltage
VDD=2.6V,
at 25℃
1.5
5.5
V
VIL
Low-level input voltage
-0.3
0.9
V
VOH
High-level output voltage
2.3
-
V
VOL
Low-level output voltage
-
0.2
V
Table 1-7 I/O ports static characteristics

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 13 - https://www.ezTCP.com
1.4.7 An Application Circuit
Figure 1-6 an Application Circuit

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 14 - https://www.ezTCP.com
2 Installation and Test
2.1 IPv6 address
With online devices increasing such as smartphones throughout the world, the
number of available IP addresses has continued to dwindle at an ever-faster rate.
This urgent problem on lack of IPv4 addresses finally led to the development of an
advanced version, IPv6, which has become a key word to effectively settle the matter.
IPv6 has a lot of merits on addressing capability, packet handling process and
security, however the devices or software for IPv4 are not allowed on IPv6 network
due to the different addressing protocol structure. For this, CSE-M53G was developed
to be available on both networks by supporting dual stack.
2.2 Installation
Before testing CSE-M53G, users should connect both serial and Ethernet port to a
PC. It will be no problem that the Ethernet connection includes network hubs. In
this document, whole processes are written assume that using it with evaluation
board.
Figure 2-1 connection between CSE-M53G and a PC
Procedures for the test are followed.

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 15 - https://www.ezTCP.com
2.2.1 Setting Network Aera
This step is for setting both CSE-M53G and users’PC to be located the same
network. If only they are, the TCP connection between them can be established.
⚫Setting of the PC
Add or change the IP address of the network adapter on your PC like following.
Get into the menu of [Windows Control Panel] >> [Network Connections] >>
[Properties of the Network Adapter –with right click of your mouse]. Then,
you can show the properties of [Internet Protocol (TCP/IP). In there, press
the [Advanced..] button for adding an IP Address like the below figure.
Figure 2-2 adding / changing the IP address of users’PC

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 16 - https://www.ezTCP.com
⚫Setting of CSE-M53G
CSE-M53G uses ezManager as it’s a configuration program. ezManager is for MS
Windows, and this is comfortable to use because it doesn’t need installation.
First, search your CSE-M53G via network. All the values of parameters are set
the default values in the factory. To apply it to your system, proper values
should be set via ezManager.
Major parameters’default values are listed on below table. To implement this
simple test, keep these values without any changes.
Name
Default Values
Network
Local IP Address
10.1.0.1
Subnet Mask
255.0.0.0
IPv6
NONE
Option
TELNET
Checked
IP Address Search
Checked
Serial Port
(COM1)
Serial Type
RS232
Baud Rate
19,200bps
Parity
NONE
Data Bits
8
Stop Bit
1
Flow Control
NONE
Communication mode
TCP Server
Local Port
1470
Table 2-1 default values of Major parameters

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 17 - https://www.ezTCP.com
2.3 Simple Test
If you press the [Simple Test] button, test program will be shown on your screen.
⚫Connecting to the CSE-M53G via LAN
Figure 2-3 settings for TCP connection
①Select [TCP Client]
②Input correct IP address and port number of CSE-M53G
③Clink the [Connect] button. (In case of TCP Server, it will be [Listen]
button)
⚫Opening RS232 Port
Figure 2-4 opening COM Port
④Select COM port which the CSE-M53G is connected to
⑤Make sure that all the parameters are the same with CSE-M53G
⑥Press the [Open] button

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 18 - https://www.ezTCP.com
⚫Confirm the TCP Connection and COM port status
Figure 2-5 TCP Connected message
⑦Check the message if the TCP connection is established
Figure 2-6 COM Port open message
⑧Check the message if the COM port has been opened

CSE-M53G User Manual Ver. 1.0
Sollae Systems Co., Ltd. - 19 - https://www.ezTCP.com
⚫Data transmission test
Figure 2-7 successful data transmission
⑨Click the [Send data] on the LAN part
⑩Check the data have been shown from the step ⑨
Figure 2-8 LAN →RS232
⑪Press the [Send data] on the RS232 part
⑫Check the data have been received from the step ⑪
Figure 2-9 RS232 →LAN
