ADTRAN Octal BRI/U User manual

2FWDOý%5,î8ý0RGXOH
8VHUý0DQXDO
3DUWý1XPEHUýìëííìåç/ë
61200186L2-1A
December 1999

901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
[phone]
© 1999 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.

iii
ADTRAN Year 2000 (Y2K) Readiness Disclosure
ADTRAN has established a Year 2000 program to ensure that our products will correctly function in
the new millennium. ADTRAN warrants that all products meet Year 2000 specifications regardless of
model or revision. Information about ADTRAN's Year 2000 compliance program is available at the fol-
lowing:
Product Matrix www.adtran.com/y2kfax.html
E-mail [e-mail]
Faxback Document Line [phone]
Y2K plans and product certifications are listed in the Product Matrix (see
above).
Y2K Project Line [phone]

iv
FCC regulations require that the following information be provided in this manual to the
customer:
1. This equipment complies with Part 68 of the FCC rules. The required label is affixed to the bottom
of the chassis.
2. An FCC-compliant telephone cord and modular plug is provided with this equipment. This equip-
ment is designed to be connected to the telephone network or premises wiring using a compatible
modular jack which is Part 68-compliant. See Chapter 2, Installation, for details.
3. If your telephone equipment (Octal BRI/U Module) causes harm to the telephone network, the tele-
phone company may discontinue your service temporarily. If possible, they will notify you in ad-
vance. But if advance notice isn’t practical, you will be notified as soon as possible. You will be
advised of your right to file a complaint with the FCC.
4. Your telephone company may make changes in its facilities, equipment, operations, or procedures
that could affect the proper operation of your equipment. If they do, you will be given advance
notice to give you an opportunity to maintain uninterrupted service.
5. If you experience trouble with this equipment (Octal BRI/U Module), please contact ADTRAN at
[phone] for repair/warranty information. The telephone company may ask you to discon-
nect this equipment from the network until the problem has been corrected or until you are sure
the equipment is not malfunctioning.
6. This unit contains no user-serviceable parts.
7. The following information may be required when applying to your local telephone company for
leased line facilities.
Federal Communications Commission (FCC) Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio frequencies. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Shielded cables must be used with this unit to ensure compliance with Class A FCC limits.
Service Type REN/SOC FIC USOC
Basic Rate ISDN 6.0N 02IS5 RJ-48C
Change or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
ý

v
Affidavit Requirements for Connection to Digital Services
• An affidavit is required tobe given to the telephone company whenever digital terminal equipment
without encoded analog content and billing protection is used to transmit digital signals contain-
ing encoded analog content which are intended for eventual conversion into voiceband analog sig-
nals and transmitted on the network.
• The affidavit shall affirm that either no encoded analog content or billing information is being
transmitted or that the output of the device meets Part 68 encoded analog content or billing protec-
tion specifications.
• End user/customer will be responsible for filing an affidavit with the local exchange carrier when
connecting unprotected customer premise equipment (CPE) to 1.544 Mbps or subrate digital ser-
vices.
• Until such time as subrate digital terminal equipment is registered for voice applications, the affi-
davit requirement for subrate services is waived.
Affidavit for Connection of Customer Premises Equipment
to 1.544 Mbps and/or Subrate Digital Services
For the work to be performed in the certified territory of ________________________(telco name)
State of ________________
County of ________________
I, _____________________________ (name), __________________________________(business address),
____________________ (telephone number) being duly sworn, state:
I have responsibility for the operation and maintenance of the terminal equipment to be connected to
1.544 Mbps and/or ________ subrate digital services. The terminal equipment to be connected com-
plies with Part 68 of the FCC rules except for the encoded analog content and billing protection speci-
fications. With respect to encoded analog content and billing protection:
( ) I attest that all operations associated with the establishment, maintenance, and adjustment of the
digital CPE with respect to analog content and encoded billing protection information continu-
ously complies with Part 68 of the FCC Rules and Regulations.
( ) The digital CPE does not transmit digital signals containing encoded analog content or billing
information which is intended to be decoded within the telecommunications network.
( ) The encoded analog content and billing protection is factory set and is not under the control of the
customer.
I attest that the operator(s)/maintainer(s) of the digital CPE responsible for the establishment, mainte-
nance, and adjustment of the encoded analog content and billing information has (have) been trained
to perform these functions by successfully having completed one of the following (check appropriate
blocks):
( ) A. A training course provided by the manufacturer/grantee of the equipment used to encode
analog signals; or
( ) B. A training course provided by the customer or authorized representative, using training mate-

vi
rials and instructions provided by the manufacturer/grantee of the equipment used to encode
analog signals; or
( ) C. An independent training course (e.g., trade school or technical institution) recognized by the
manufacturer/grantee of the equipment used to encode analog signals; or
( ) D. In lieu of the preceding training requirements, the operator(s)/maintainer(s) is (are) under the
control of a supervisor trained in accordance with _________ (circle one) above.
I agree to provide ______________________ (telco’s name) with proper documentation to demonstrate
compliance with the information as provided in the preceding paragraph, if so requested.
_________________________________Signature
_________________________________Title
_________________________________ Date
Transcribed and sworn to before me
This ________ day of ________, ________
_________________________________
Notary Public
My commission expires:
_________________________________

vii
Canadian Equipment Limitations
Before installing this equipment, users should ensure that it is permissible to be connected to the facil-
ities of the local telecommunications company. The equipment must also be installed using an accept-
able method of connection. In some cases, the company's inside wiring associated with a single line
individual service may be extended by means of a certified connector assembly (telephone extension
cord). The customer should be aware that compliance with the above conditions may not prevent deg-
radation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility desig-
nated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to request the user to disconnect the
equipment.
Users should ensure for their own protection that the electrical ground connections of the power util-
ity, telephone lines and internal metallic waterpipe system, if present, are connected together. This
precaution may be particularly important in rural areas.
The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be
connected to a telephone loop which is used by the device, to prevent overloading. The termination
on a loop may consist of any combination of devices subject only to the equipment that the total of the
LNs of all devices does not exceed 100.
The ringer equivalence number (REN) assigned to each terminal adapter is used to determine the total
number of devices that may be connected to each circuit. The sum of the RENs from all devices in the
circuit should not exceed a total of 5.0.
The Industry Canada Certification label identifies certified equipment. This certification means
that the equipment meets certain telecommunications network protective, operational, and safety
requirements. The Department of Commerce does not guarantee the equipment will operate to the
user's satisfaction.
Users should not attempt to make such connections themselves, but should contact the appropriate
electric inspection authority, or an electrician, as appropriate.

viii
Warranty and Customer Service
ADTRAN will replace or repair this product within five years from the date of shipment if the product
does not meet its published specification, or if it fails while in service. For detailed warranty, repair, and
return information, refer to the ADTRAN Equipment Warranty and Repair and Return Policy Proce-
dure (see the last page of this manual).
A return material authorization (RMA) is required prior to returning equipment to ADTRAN.
For service, RMA requests, or more information, see the last page of this manual for the toll-free con-
tact number.

61200186L2-1 Octal BRI/U Module User Manual ix
Table of Contents
List of Figures ..................................................................................................................................................... xi
List of Tables.....................................................................................................................................................xiii
Chapter 1 Introduction.............................................................................................................................. 1-1
Octal BRI/U Module Overview...................................................................................................................... 1-1
NEBS Compliance............................................................................................................................................. 1-1
Functional Description.....................................................................................................................................1-2
Features .............................................................................................................................................................. 1-2
Octal BRI/U Module Specifications...............................................................................................................1-2
Physical Description......................................................................................................................................... 1-3
Chapter 2 Installation................................................................................................................................ 2-1
Before Installing the Octal BRI/U Module....................................................................................................2-1
Shipping Contents ..................................................................................................................................... 2-1
Installing the Octal BRI/U Module................................................................................................................2-2
Wiring.................................................................................................................................................................2-3
Power Up and Initialization............................................................................................................................2-3
Failed Self-Test........................................................................................................................................... 2-3
Operation Alarms...................................................................................................................................... 2-3
Chapter 3 Operation .................................................................................................................................. 3-1
Overview............................................................................................................................................................ 3-1
Terminal Menu Structure................................................................................................................................. 3-1
Modules.............................................................................................................................................................. 3-2
Slt ................................................................................................................................................................. 3-3
Type ............................................................................................................................................................3-3
Menu ........................................................................................................................................................... 3-3
Alarm .......................................................................................................................................................... 3-3
Test .............................................................................................................................................................. 3-3
State ............................................................................................................................................................. 3-3
Status .......................................................................................................................................................... 3-4
Online .................................................................................................................................................. 3-4
No Response ....................................................................................................................................... 3-4
Empty .................................................................................................................................................. 3-4
Offline .................................................................................................................................................. 3-4
Offline/No Response ........................................................................................................................ 3-4
Rev .............................................................................................................................................................. 3-4
Modules/Menu................................................................................................................................................. 3-4
U-BRI Menus ............................................................................................................................................. 3-5
Info ....................................................................................................................................................... 3-5
Alarm ................................................................................................................................................... 3-5

Table of Contents
x Octal BRI/U Module User Manual 61200186L2-1
Channel Status ....................................................................................................................................3-5
Performance Current .........................................................................................................................3-5
Configuration .....................................................................................................................................3-5
Test .......................................................................................................................................................3-5
Module Alarms .........................................................................................................................................3-5
Test Activity ...............................................................................................................................................3-5
ATLAS Features Used with Octal BRI/U Module Options........................................................................3-5
Factory Restore..................................................................................................................................................3-6
Run Selftest.........................................................................................................................................................3-6
Appendix A Dial Plan Interface Configuration......................................................................................A-1
Index...........................................................................................................................................................Index-1

61200186L2-1 Octal BRI/U Module User Manual xi
List of Figures
Figure 1-1. Octal BRI/U System.................................................................................................................... 1-1
Figure 1-2. Octal BRI/U Option Module..................................................................................................... 1-3
Figure 2-1. Installing the Octal BRI/U Module ..........................................................................................2-2
Figure 3-1. Modules Menu............................................................................................................................. 3-2
Figure 3-2. Menu Tree for Octal BRI/U Modules Menu........................................................................... 3-2
Figure 3-3. Octal BRI/U Module Menu Options........................................................................................ 3-4
Figure A-1. Dial Plan Menus .........................................................................................................................A-1

List of Figures
xii Octal BRI/U Module User Manual 61200186L2-1

61200186L2-1 Octal BRI/U Module User Manual xiii
List of Tables
Table 2-1. Network Pinout Connection...................................................................................................... 2-3

List of Tables
xiv Octal BRI/U Module User Manual 61200186L2-1

61200186L2-1 Octal BRI/U Module User Manual 1-1
Chapter 1 Introduction
OCTAL BRI/U MODULE OVERVIEW
The Octal BRI/U Module is a member of the ATLAS family of integrated ac-
cess products, providing eight Basic Rate ISDN (BRI) U interfaces, each ca-
pable of operating in either NT or LT mode. Any port can deliver timing for
the system.
The Octal BRI/U Module combines with the ATLAS system and other
ATLAS modules to support requirements calling for multiple BRI circuits.
As many Octal BRI/U Modules can be installed in a system as can be
physically accommodated in the ATLAS chassis. Figure 1-1 shows a sample
application of the Octal BRI/U Module.
Figure 1-1. Octal BRI/U System
When combined with the ATLAS system and, optionally, one or more
Quad T1/PRI Modules (P/N 1200185L2 and 1200185L3), the Octal BRI/U
Module can implement an ISDN access switch, combining multiple BRI cir-
cuits into one or more Primary Rate ISDN (PRI) circuits.
NEBS COMPLIANCE
The ATLAS Octal BRI/U Module (P/N 1200186L2) complies with the NEBS
(Network Equipment Building System) Level III specification for
GR-1089-CORE and GR-63-CORE. This means that the ATLAS Octal BRI/U
Module will perform normally under certain electrical and physical stresses
without posing a safety hazard to its users. However, when applications re-
quire NEBS compliance, this module should be used in the ATLAS 810PLUS
(a NEBS-compliant version of the ATLAS 800PLUS).
PBX
ATLAS T1/PRI Module
BRI Module

Chapter 1. Introduction
1-2 Octal BRI/U Module User Manual 61200186L2-1
FUNCTIONAL DESCRIPTION
The Octal BRI/U Module installs in any available option slot in the ATLAS
chassis. You can view the status of the module itself, as well as the circuits
to which it interfaces, from the ATLAS front panel. Additional status infor-
mation is available via the terminal menus, accessible through either a
VT-100terminal connectedto theATLAS controlport,or via aTelnet session
established through the Base Unit’s Ethernet port. Use the terminal menu to
configure the Octal BRI/U Module and to download application software.
FEATURES
Features of the Octal BRI/U Module are listed here:
• Eight BRI U Interfaces
• Near-end and far-end block error monitoring
• Can use any port as a timing source for the entire system
• Hot swappable
• NT and LT mode support
• Maximum distance of 18,000 feet
OCTAL BRI/U MODULE SPECIFICATIONS
Each port of the Octal BRI/U Module conforms to the following specifica-
tions:
•Linerate
160 kbps data rate (80 kbaud signaling +/-5 ppm)
•Linecodes
2B1Q
• Framing options
Framing per ANSI T1.601-1992
• Clock source tests
Allows any Octal BRI/U Module port to be the master timing source
• Tests
Power-on, circuit self-test line loopback, port loopback (internal toward
system)
- Line loopback (VT-100/remote/in-band)
- BRI switch supported support for the following switches :
* AT&T 5ESS (NT or LT)
* Nortel DMS-100 (NT or LT)
* National ISDN-1
- Report line performance data via SNMP in RFC1406 format
• Connectors
RJ-45

Chapter 1. Introduction
61200186L2-1 Octal BRI/U Module User Manual 1-3
PHYSICAL DESCRIPTION
The Octal BRI/U Module (see Figure 1-2) plugs into any available option
slot in the rear of the ATLAS chassis.
Figure 1-2. Octal BRI/U Option Module
The label over each RJ-45 connector refers to the port on the Octal BRI/U
Module.

Chapter 1. Introduction
1-4 Octal BRI/U Module User Manual 61200186L2-1

61200186L2-1 Octal BRI/U Module User Manual 2-1
Chapter 2 Installation
BEFORE INSTALLING THE OCTAL BRI/U MODULE
Carefully unpack and inspect the Octal BRI/U Module for shipping damag-
es. If you suspect damage occurred during shipping, file a claim immediate-
ly with the carrier andthen contact ADTRANTechnical Support (see thelast
page of this manual for pertinent information). If possible, keep the original
shipping container for returning the Octal BRI/U Module for repair or for
verification of shipping damage.
Shipping Contents
The ADTRAN shipment includes the following items:
• Octal BRI/U Module
• Octal BRI/U Module User Manual (insert into the ATLAS User Manual)
• Eight RJ-45-to-RJ-11 cables, ADTRAN P/N: 3125M007

Chapter 2. Installation
2-2 Octal BRI/U Module User Manual 61200186L2-1
INSTALLING THE OCTAL BRI/U MODULE
Figure 2-1 represents the actions required to properly install the
Octal BRI/U Module, as described in the Step/Action table below.
Figure 2-1. Installing the Octal BRI/U Module
Instructions for Installing the Octal BRI/U Module
Step Action
1Remove the cover plate from the appropriate option slot in the
ATLAS rear panel.
2Slide the Octal BRI/U Module into the option slot until the
module is firmly positioned against the front of the chassis.
3Secure the thumbscrews at both edges of the module.
4Connect the cables to the associated device(s).
5Complete installation of remaining modules and Base Unit as
specified in the Installation chapter of the
ATLAS User Manual
.
To ensure that the thumbscrews are securely fastened, use a
screwdriver to tighten them.
