INSTALLATION GUIDE FOR BLOM8405MBK,
BLOM8406MBK and 840 MBKBLOM 7
CARE AND MAINTENANCE
SAFETY INFORMATION Released Date: 2021-07-21
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
PACKAGE CONTENTS
Crossbar Assembly
x1
AA
Wire Connector
x3
CC Outlet Box Screw
x2
DD
AFixture Body
x 1
INSTALLATION
Glass Panel
x4
B
Alternate
Mounting Screw
x2
BB
MOUNTING HARDWARE
1
Install Glass Panels
2
Install Crossbar Assembly
(2) Alternative Screws
*Alternative screws are provided to
replace pre-assembled mounting
screws if necessary.
Slot
Tab

- of 2 -2
INSTALLATION
Your installation is now complete! Restore electricity and save this sheet for future reference.
34
Wiring
White wire from supply White from fixture
Black (or red) wire from supply Black from fixture
Ground wire from supply
Ground wire
from fixture
Green ground screw
5
Install Bulb
BULB BASE TYPE
Medium (E26)
BULB TYPE
TYPE A
100W
MAX
Install the correct bulb referring to
fixture markings and/or labels for
maximum wattage.
Recommended Bulb Type (not
included):
6
Apply Caulking
ECxterior aulk
ECxterior aulk
ECxterior aulk
* Note: Do NOT caulk the bottom of the backplate to
allow moisture to escape.
Install Fixture Body
