Somogyi Elektronic home FKTW 501 User manual

FKTW 501
EN -Safety and maintenance / H - Biztonság és karbantartás /
SK - Bezpečnosť a údržba / RO - Siguranță și întreținere /
SRB-MNE - Bezbednost i održavanje / CZ - Bezpečnost a údržba /
HR-BIH - Sigurnost i održavanje
4 – 21
EN -Functions / H - Funkciók / SK - Funkcie / RO - Funcții /
SRB-MNE - Funkcije / CZ - Funkce / HR-BIH - Funkcije 22 – 32
instruction manual
eredeti használati utasítás
návod na použitie
manual de utilizare
uputstvo za upotrebu
návod k použití
uputa za uporabu
návod na použitie
manual de utilizare
uputstvo za upotrebu
uputa za uporabu

figure 1. • 1. ábra • 1. obraz • figura 1. • 1. skica • 1. obrázek • 1. slika
EN HSK RO
STRUCTURE
(Figure 1.) FELÉPÍTÉS (1. ábra) ŠTRUKTÚRA (1. obrázok) STRUCTURĂ (g. 1.)
1. Towel dryer bars Törölköző szárító rudak tyče pre uteráky tije pentru uscare prosop
2. Display Kijelző displej ecran
3. OK-boost button OK-boost gomb tlačidlo OK-boost buton OK-boost
4. MENU button MENÜ gomb tlačidlo MENU buton MENIU
5. On/off button Be-/kikapcsoló gomb tlačidlo za-/vypnutia buton pornit/oprit
6. Thermostat setting buttons Termosztát állító gombok tlačidlá nastavenia termostatu butoane de reglare termostat
7. Mounting bracket – part fixed to
the wall Tartókonzol – falra rögzülő rész konzola – časť, ktorú treba upevniť na stenu suport – partea montată pe perete
8. Mounting bracket – part fixed to
the appliance Tartókonzol – készülékre rögzülő rész konzola – časť, ktorú treba upevniť na prístroj suport – partea montată pe aparat
SRB-MNE CZ HR-BIH
SASTAVNI DELOVI
(1. skica) POPIS (1. schéma) DIJELOVI UREĐAJA (Slika 1.)
1. Držač za peškire Ramena sušáku ručníků Šipke za sušilo za ručnike
2. Displej Displej Zaslon
3. OK-boost taster Tlačítko OK-boost Tipka OK-boost
4. MENI taster Tlačítko MENU Tipka MENU
5. Taster za uklj./isklj. Tlačítko pro zapínání/vypínání Tipka za uključivanje / isključivanje
6. Taster termostata Tlačítka pro nastavení termostatu Tipke za podešavanje termostata
7. Konzola koja se montira na zid Konzole – část k upevnění na stěnu Konzol - zidni dio
8. Konzola koja se montira na uređaj Konzole – část k upevnění na
spotřebič Konzol - dio koji se pričvršćuje na uređaj
3.
6.
2.
7.8.
1.
5.
4.

figure 2. • 2. ábra • 2. obraz • figura 2. • 2. skica • 2. obrázek • 2. slika
figure 3. • 3. ábra • 3. obraz • figura 3. • 3. skica • 3. obrázek • 3. slika figure 4. • 4. ábra • 4. obraz • figura 4. • 4. skica • 4. obrázek • 4. slika

4
ELECTRIC TOWEL DRYER
IMPORTANT SAFETY INSTRUCTIONS
READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USEAND RETAIN IT FOR LATER REFERENCE!
WARNINGS
1. Before using the product for the first time, please read the instructions for use below and retain them. The
original instructions were written in the Hungarian language.
2. This appliance may only be used by persons with impaired physical, sensory or mental capabilities, or lacking
in experience or knowledge, as well as children from the age of 8, if they are under supervision or have been
given instruction concerning use of the appliance and they have understood the hazards associated with use.
Children should not be allowed to play with the unit. Children may only clean or perform user maintenance on
the appliance under supervision.
3. Confirm that the appliance has not been damaged in transit.
4. Do not use this heater if it has been dropped.
5. Do not use if there are visible signs of damage to the heater.
6. Never locate the appliance directly in corners and observe the minimum installation distances indicated on
Figure 2. Always observe the health and safety regulations valid in the country of use!
7. The appliance should be used as intended for warming air, not for general heating purposes.
8. The stream of hot air should not be directed straight to curtains or other flammable materials!
9. The grille at the hot air outlet may be hot.
10. WARNING The appliance is only intended for drying laundry washed in water.
11. Do not locate near flammable materials. (min. 100 cm)
12. When installing, take into account the material and load-bearing capacity of the wall.
13. Before powering on the appliance, make sure that the heater is stable on the wall.
14. Do not use in locations where flammable vapors or explosive dust may be released.
15. Do not use near flammable materials or in potentially explosive atmospheres!
16. Can only be operated under continuous supervision.
17. Do not operate near children without supervision.
18. Only to be used in dry, indoor conditions. Protect from humid environments (e.g. bathrooms or swimming pools)!
19. It is PROHIBITED to use the appliance near bathtubs, basins, showers, swimming pools or saunas!
20. It is STRICTLY FORBIDDEN to install or use the appliance in zones 0 or 1 of rooms containing a bathtub or
shower (see Fig. 4).
21. In rooms containing a bathtub or shower, all circuits must be protected by one or more circuit breakers (RCD)
with rated tripping current of up to 30 mA.
22. When installing the appliance in rooms with a bathtub or shower, the local and special national regulations
must be observed.
23. The heater must be installed in such way that a person in the bathtub or shower cannot touch the buttons or
other controls.
24. When installing, observe the raw material and load bearing capacity of the wall concerned.
25. Before powering up to the appliance, make sure that it is firmly fixed on the wall.
26. It is prohibited to use the appliance in motor vehicles or in confined spaces (< 5 m2) such as elevators!
27. When not planning to use the appliance for an extended period of time, switch it off then remove the power
plug from the outlet.
28. Always power off the heater before relocating it.
29. Do not place the heater directly under the mains socket.
EN -Safety and maintenance / H - Biztonság és karbantartás / SK - Bezpečnosť a údržba /
RO - Siguranţă și întreţinere / SRB-MNE - Bezbednost i održavanje / CZ - Bezpečnost a údržba /
HR-BIH - Sigurnost i održavanje

5
30. If you notice any abnormality (e.g. unusual noise from the appliance or a burning smell), switch it off and
unplug it immediately.
31. Make sure that no objects or liquids can enter the appliance through the openings.
32. To reduce the risk of electric shock, do not expose this appliance to dripping or splashing water, and do not
place objects filled with liquids, such as vases on the appliance.
33. Do not place an open flame source, such as a burning candle on the appliance.
34. Protect from dust, humidity, sunlight and direct heat radiation!
35. Power off the appliance by unplugging it from the electric outlet before cleaning!
36. Do not touch the appliance or the power cable with wet hands!
37. The appliance may only be connected to properly grounded 230 V ~ / 50 Hz electric wall outlets! The circuit
must be protected by a 16 A circuit breaker.
38. Unwind the power cable completely!
39. Do not use extension cords or power strips to connect the appliance!
40. Do not lead the power cable on the appliance, or near the air inlet and outlet openings!
41. Do not lead the power cable under carpets, doormats, etc.!
42. The appliance should be located so as to allow easy access and removal of the power plug!
43. Lead the power cable so as to prevent it from being pulled out accidentally or tripped over.
44. The appliance is intended for household use. No industrial use is permitted!
45. Due to continuous improvements, the technical data and design may change without any prior notice.
46. The actual instruction manual can be downloaded from www.somogyi.hu website.
47. We don’t take the responsibility for printing errors which may occur, and apologize for them.
CAUTION: RISK OF ELECTRIC SHOCK!
Do not attempt to disassemble of modify the unit or its accessories. In case any part is damaged,
immediately power off the unit and seek the assistance of a specialist.
In the event that the power cable should become damaged, it should only be replaced by the manufacturer,
its service facility or similarly qualified personnel.
Do not cover!
Covering the unit can cause overheating, fire or electric shock!
ASSEMBLY AND INSTALLATION OF THE UNIT
1. Before installation, carefully remove packaging, and make sure not to damage the unit or the connecting cable.
If you find any damage, the unit must not be operated!
2. Take out the unit from the box.
3. To ensure proper operation, you have to arrange for the free circulation of hot air. Therefore, please, observe
the minimum clearances indicated in Figure 2.
4. Review Figure 3 and make holes in the wall appropriate to the size of the dowels you want to use, or the ones
supplied. The holes should be located at a distance of 500 mm horizontally and 740 mm vertically from each other.
5. Fix the wall mounted part of the supplied 4 bracket pairs (7) to the wall. When installing, take care that the
screw hole on the side of the wall mounted bracket must align with the slot cut in the side of the bracket mounted
on the unit.
6. Fix the other members of the bracket pairs to the back of the appliance using the supplied screws (8). When
fixing, take care that the slots on the side of the brackets mounted on the unit must align with the screw holes on
the side of the wall bracket.
7. Attach the unit to the wall, then secure the brackets with 1 screw each. If necessary, you can position the wall
mounted product by gently loosening these screws.
8. Plug the unit into a standard grounded wall socket. Now the unit is ready for operation!
