Sonoff SNZB-02 User manual

SNZB-02
User manual V 1.0
Temperature and Humidity Sensor
中文-------1-5 English-------6-10

使用说明
eWeLink
eWeLink
1. 下载APP
取出电池绝缘片
本设备需要连接SONOFF ZigBee网关进行智能
操作，可与其他产品互联互通。
设备支持其它同类型的网关，具体以实际产品为准。
>
1

>
打开eWeLink APP，选择要连接的网关，点击
"添加" 子设备，然后长按设备 重置按钮5秒直至
LED指示灯闪烁3下，设备进入配对状态，等待
设备连接。
ZBB ri dg e
已添加设 备:0
暂无子 设备，请添加
添加
2. 添加子设备
添加子设备前，请先连接网关。
2

SONOFF网关支持同时连接多个子
设备
ZBB ri dg e
已添加设备:0
暂无子设备，请添加
添加
添加设备
正在连接
请让设 备尽 量靠近 网关
25s
找到设 备
3个设备 已找到
>
先打开eWeLink APP网关页面，点击添加，然后
设置让所需配对的子设备进入配对状态，等待设
备连接。
3
注意：如添加失败，请将设备移近网关后再重新
添加。

产品参数
产品型号: SNZB-02
电池型号: CR2450
工作电压: 3V
无线协议: ZigBee (IEEE 802.15.4)
工作温度: -10-40℃
工作湿度:10-90%RH(无冷凝)
外壳材料: PC
产品规格: 43x43x14mm
安装方法
方法1：直接放置桌面使用。
注意：请勿安装在金属表面，否则会影响无线通讯距离。
方法2：撕下3M胶保护膜，粘贴在所需区域即可
4

产品介绍
产品特点
SNZB-02是一款低功耗的温湿度传感器，可实
时检测当时环境温湿度，通过添加场景联动设置
控制其他设备。
重置按键
LED指示灯
低功耗 电量低消息推送 场景联动
温湿度检测
删除子设备
长按子设备重置按钮5秒直到LED指示灯闪烁3
下，此时子设备已在网关中删除。
提醒：用户还可在APP子设备界面中删除子设备。
5

Operation instruction
Pull out the battery insulation sheet
eWeLink
eWeLink
1. Download APP
The device can be operated intelligently via working
with the SONOFF ZigBee Bridge to communicate with
other devices.
The device can work with other gateways supporting
ZigBee 3.0 wireless protocol. Detailed information
is in accordan ce with the final product.
>
6

2. Add sub-de vices
>
ZBB ri dg e
Add ed :0
No ch il d dev ice,p lease add.
Add
Connect the Bridge before adding the sub-device
Access eWeLink APP, select the Bridge that you want
to connect, and tap “Add” to add a sub-device. Then
lo n g press reset button on t he device for 5s u ntil the
LED indi c ator flas hes thre e t i mes, whi ch means the
device has entered the pairing mode, and be patient
until pairing completes.
If the addition failed, move the sub-device closer
to the Bridge an d try again.
7

SONOFF ZigBee Bridge supports
connecting multiple sub-devices at
the same time.
Conn ec ti ng
Kee p the dev ice c lo se
eno ug h to th e hub.
25s
>
Power the Bridge on, access the Bridge page in the
eWeLink APP, and tap “Add”. Then set the sub-device
to be pair to the pairing mode, and be patient until the
pairing completes.
ZBB ri dg e
Add ed :0
No ch il d dev ice,p lease add.
Add
Add Devic e
Loo king f or dev ice
3 devi ces Foun d
8

Installation methods
1. Placed on the desktop for use.
2. Tear off the protective film of the 3M adhesive a nd
stick the device on the desired area.
Do not install o n the metal surface, otherwise it
will affect the w ireless communication distance.
Specifications
Model: SNZB-02
Battery model: CR2450
Working voltage: 3V
Wireless con nection: ZigBee (IEEE 802.15.4)
Working temperature : -10-40℃
Working humidity: 10-90%RH (non-condensi ng)
Material: PC
Dimension: 4 3x43x14mm
9

Temperat ure
and humi dity
monito ring
Product Introduction
Reset button
LED indicat or
Features
Low-en ergy Low batt ery
notifi cati on
Smart sc enes
Delete sub-devices
Long press the reset button on the sub-device for 5s
until the LED indicator flashes three times. In this
case, the sub-device is deleted from the Bridge
successfully.
Users can dele te sub-devices directly from the
sub-device p age on APP.
SN ZB -0 2 i s a Z i g B ee l o w- en er g y te m p e ra tu re &
humidity sens o r that can be used to monitor the
environmen t temperature and humidity in real time.
Connect it with the Bridge and you can create a smart
scene to trigger other devices.
10

MADE IN CHINA
Shenzhen Sonoff Technologies Co., Ltd.
1001, BLDG8, Lianhua Industrial Park, shenzhen, GD,
China
ZIP code: 518000 Website: sonoff.tech
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
This equipment should be installed and operated with minimum distance 20cm between the
radiator& your body.
Caution
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
FCC Statement
