Sonos One User manual

SONOS USER GUIDE
One
Sonos One has Amazon Alexa and Google Assistant built right in so you can use your voice to start and
control the music on Sonos—
•Perfectfitforshelves,counters,andsnugspaces or mounted to a wall, ceiling or speaker stand.
•Touchcontrolsletyouadjustvolume,playandpause,orskipthroughsongs.
•PairtwoSonosOnesforleft-rightstereosound,oruse two Sonos Ones as rear surrounds for your home
theater.
•WorkswitheitherSonosS2 or Sonos S1 (for Android and iOS).
•SeeGetting started when you’re ready to add a Sonos One to your system.
Note: Over time we’ll add more voice services and skills. Voice control is not supported in every country
yet—this feature will be available as soon as Sonos and a voice service launch together in your region.
Join button
Ethernet port
AC power (mains) input
Microphone indicator
Status light
Volume control
Play/Pause
Volume control

SONOS USER GUIDE
Controls and lights
Note: If you don’t want anyone (like a child) to control playback or change the volume using the speaker
touch controls, you can disable them in the room’s settings.
Connector panel
Volume control • Touch and hold to quickly ch ange the volume:
• Volume up (right); Volume down (left).
Note: You can also use the So nos app, voice control,
or your TV remote.
Play/Pause • Press once to play or pause music.
• Press and hold to add the music that’s playing in
another room.
Next/Previous • Swipe right across the touch controls to skip to the
next song.
• Swipe left to go to the previous song.
Note: You can’t skip forward o r g o b a c k w h e n l i s t e n i n g
to a radio station.
Microphone
indicator
• Tap the micro p h o n e light to tur n t h e microp h o n e o n
or off.
• When the light is on, voice control is on and you can
use voice commands.
• When the light is off, voice control is off.
Note: If the light is off, you can press and hold the
Microphone indicator to talk to your voice
service. Release the button to turn voice control
off again.
Status light Indicates the status. Learn more
If the light is distracting, you can turn it off in your room’s
settings.
Join button Press to connect during setup.
Ethernet port Use an Ethernet cable if you want to connect to a router,
computer, or network-attached storage (NAS) device
(optional).
AC power (mains)
input
Use only the supplied power cord (using a third-party
power cord will void your warranty).
Note: Insert the power cord firmly until it is flush with
the bottom of the speaker.

SONOS USER GUIDE
Select a location
You c a n pu t y ou r s pe a ke r j us t a bo u t anywhere. Here’s a few guidelines:
•SonosOnesoundsgreatevenwhenplacednexttoawall or on a shelf. For best performance, leave at
least 1" (2.5 cm) space around the back of the speaker.
•It’shumidity-resistant so you can use it in the bathroom.
•It’snot water-resistant so don’t put it near water or leave it in the rain.
Speaker mounts and stands
For wall mount kits or stands, tailored to perfectly fit your Sonos products, see Accessories on our website.
Microphone on/off
Touch to tu r n t he mic roph o ne on a n d off. (If yo u don’t have a voice service installed, the microphone is
inactive.)
When the microphone light is on, voice control is on and your voice assistant is ready to respond. When the
microphone light is off, voice control is off.
Note: If you’ve installed a voice service and the microphone is off, you can still use voice commands. Just
press and hold —no need to start with a wake word. When you release the microphone button,
voice control turns off again.
Specifications
Feature Description
Audio
Amplifier Two Clas s - D d i gi t a l a m pl i f i e r s .
Tweeter One tweeter creates a crisp and accurate high frequency response.
Mid-Woofer One mid-woofer ensures the faithful playback of mid-range vocal
frequencies plus deep, rich bass.
Stereo Pair Turn two speakers into separate left and right channel speakers to create
wider, deeper sound.
Home Theater Add two speakers as surrounds for a true surround sound experience.
Microphones • Far-field microphone array.
• Microphone LED, hard-wired to the voice microphones for extra privacy
control so you’re always aware when the microphone is active.
Voice Control Integrated voice control.

SONOS USER GUIDE
* Specifications subject to change without notice.
Networking*
Wireless Connectivity Using Sonos S2: Connects to WiFi network with any 802.11a/b/g/n 2.4 or
5 GHz broadcast-capable router.
Using Sonos S1: Connects to WiFi network with any 802.11b/g 2.4 GHz
broadcast-capable router. 802.11n only network configurations are not
supported—you can either change the router settings to 802.11b/g/n or
connect a Sonos product to your router.
Ethernet Port One 10/100Mbps Ethernet port. You can plug a Sonos product directly into
your router if your WiFi is unstable.
General
Power Supply Auto-switching 100 - 240V ~ 50-60 Hz 1A AC universal input
Dimensions (H x W x D) 6.36 x 4.69 x 4.69 in. (161.45 x 119.7 X 119.7 mm)
Weight 4.08 lb (1.85 kg)
Operating Temperature 32º to 104º F (0º to 40º C)
Storage Temperature -4º to 158º F (-20º to 70º C)
Humidity Resistant Designed to withstand high-humidity, like in a bathroom with a running
shower. (It is not waterproof or water-resistant.)
Product Finish White with white grille; black with black grille
Package Contents Sonos One, power cord, and Quickstart Guide.
Feature Description

SONOS USER GUIDE
Important Safety Information
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry soft cloth. Household cleaners or solvents can damage the finish on your Sonos components.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
9.Protect the power cable from being walked on or pinched, particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10.Only use attachments/accessories specified by the manufacturer.
11.Unplug this apparatus during lightning storms or when unused for long periods of time.
12.Refer all servicing to Sonos qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cable or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
13.The Mains plug should be readily available to disconnect the equipment.
14.Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. 
15.Do not expose apparatus to dripping or splashing and do not place objects filled with liquids, such as vases, on the
apparatus.
