Making Data and Fax Calls
Your mobile phone contains a modem similar to the
modems you use to connect your computer to your
home or office telephone service. Rather than connecting
to standard telephone lines, the modem in your mobile
phone allows you to connect your computer to the
mobile telephone system. In places where mobile
network operators provide the necessary support, you
can use your mobile phone to send or receive faxes,
upload or download data files, or access the Internet. An
approved cable (serial or USB) is required to connect
your mobile phone to your computer before making data
or fax calls.
Data, Fax, and Internet Calls
Your phone can handle data, fax, and Internet calls, but
each type of call requires corresponding software that
must be running on your computer.
Data Calls
Data calls are placed to exchange computer files between
two computers. While the data connection is in place,
files can be transferred between the connected
computers, according to the capabilities of the software
in use. When a data call is made, the connection remains
in place until it is closed by one of the computers
involved. To make or receive data calls with your mobile
phone, you must have a properly configured
communications program running on your computer.
Fax Calls
Fax calls are placed to send fax messages. When a fax
message has been sent, your fax software or the
originating fax machine terminates the call. To make or
receive fax calls with your mobile phone, you must have a
properly configured fax program running on your
computer.

Notforcommercialuse
2AE/LZT 123 2489 R1
Internet Calls
Internet calls are placed to Internet Service Providers
(ISP) when you want to use email or access websites on
the Internet. To make Internet calls, you must have an
account with an ISP and a properly configured Internet
access program (browser) running on your computer.
When your software is installed and set up to dial your
ISP, calls can be made using the normal dialing
procedure. Once a connection to your ISP is established,
it remains in place until either you or your ISP
disconnects the call.
There are three different services your phone can use to
connect to the Internet. The installation procedure for
each varies slightly depending on the service that is used.
Check with your service provider to determine which
services are available in your area.
•Regular speed data calls (also known as
asynchronous data calls)
•Regular speed packet-data calls
•High-speed packet data calls (also known as IS-
2000)
Note! Throughout this chapter, all regular speed data
and regular speed packet-data call will be referred
to as “regular speed data calls”. High-speed packet
data calls will be referred to as “high-speed data
calls.”
Quick Net Connect
Quick Net Connect establishes an Internet connection
quickly, easily, and economically. The digital connection
bypasses the typically-used analog modems and connects
to the Internet in a matter of seconds. Contact your
service provider for more information.
Before You Start
Before setting up your phone for data operation, do the
following:
1 You must have a cable to connect your mobile
phone to your computer. There are two types of
cable available:
•The DRS-11 attaches to a serial port on your
PC. It can be used with any operating system
and works for all types of data/fax services. If
you are using high-speed Internet service with
this cable, you may also want to install a high-
speed serial port in your PC. The high-speed

Notforcommercialuse
AE/LZT 123 2489 R1 3
serial port allows you to take full advantage of
the speeds offered with this service.
•The DCU-10 attaches to the USB port of your
computer. It is the recommended cable for high-
speed Internet service. It can only be used if
your PC uses one of the following operating
systems: Windows 98 Second Edition,
Windows ME, or Windows 2000.
2 Confirm that your mobile service provider supports
digital data services in your planned usage area and
that you have the necessary subscription.
3 Confirm that your computer has the following
hardware or software:
a An operating system that supports data access
software, such as Windows 98 or Windows
2000.
b Appropriate fax (class 2.0), Internet access, or
file transfer software. Class 2.0 is different from
Class 2.
4 Download the T60c drivers from
www.SonyEricssonMobile.com/mobileinternet. Be
sure to note where you save the file.
Note! If you are trying to connect to a 25-pin serial
interface port on your computer, you will need a
9-pin to 25-pin serial adapter. You can purchase
this adapter at most computer supply stores.
Understanding This Insert
The following instructions refer to settings in your T60c
and in your PC.
•Text that can be seen in the PC is shown in the
following typeface: Start.
•Text that can be seen in the T60c is shown in the
following typeface: Settings.
•Softkey names are shown in the following typeface:
Select.
Installation
The procedure used for the first-time setup of your
phone and computer depends on your operating system
and the type of cable being used.
•WindowsXP: DRS-11
•Windows98, ME: DRS-11

Notforcommercialuse
4AE/LZT 123 2489 R1
• Windows 2000: DRS-11
•WindowsNT4.0: DRS-11
• Windows 98 Second Edition, ME, 2000: DCU-10
Windows XP Using DRS-11
1 If you plan to use a high-speed serial port, install
and configure it now according to the
manufacturer’s directions. Make sure the speed is
set to 230400 bps.
2 Connect your computer to your phone. The cable
has a plug on one end that matches the receptacle
on the bottom of your mobile phone. The other
end of the cable has a 9-pin female connector that
matches the standard 9-pin serial interface port
connector. Connect one end of the cable to your
mobile phone and the other end to the serial port
on your computer.
3 Make sure the phone is turned on.
4 Reboot the PC. You must logon using an account
with administrator privileges. Contact your
network administrator or help desk for more
information.
5 The PC should detect your phone as “new
hardware” and automatically launch a new
hardware wizard. If it does not, you must manually
setup the T60c. See “Manually Installing T60c
Modem Drivers” on page 7.
6 Click Next to proceed. Select Install from a list or
specific location and click Next.
7 Make sure Include this location in the search is
checked.
8 Click the Browse button and navigate to the
directory where you downloaded the T60c drivers.
Click OK, then click Next to proceed.
9 A window may appear warning you that the driver
has not passed Windows Logo Testing. Click
Continue Anyway.
10 Windows installs the driver. Click Finish to close
the wizard.
11 Set up your data access software according to the
instructions supplied with it. Look for Ericsson
T60c Data Fax Modem in modem list when
configuring software which will access the handset
as a modem.

Notforcommercialuse
AE/LZT 123 2489 R1 5
Windows 98 or Windows ME Using DRS-11
1 If you plan to use a high-speed serial port, install
and configure it now according to the
manufacturer’s directions. Make sure the speed is
set to 230400 bps.
2 Shut down Windows and turn off your PC.
3 Connect your computer to your phone. The cable
has a plug on one end that matches the receptacle
on the bottom of your mobile phone. The other
end of the cable has a 9-pin female connector that
matches the standard 9-pin serial interface port
connector. Connect one end of the cable to your
mobile phone and the other end to the serial port
on your computer.
4 Make sure the phone is turned on.
5 Turn on the PC. The PC should detect your phone
as “new hardware” and automatically launch the
Add New Hardware wizard. If it does not, you
must manually setup the T60c. See “Manually
Installing T60c Modem Drivers” on page 7.
6 The next step depends on the operating system
installed on your PC.
•If you are running Windows 98 Second Edition
(SE), select Search for the best driver for your
device and click Next.
•If you are running Windows ME, select Specify
location of the driver and click Next.
7 Check Specify a location.
8 Click the Browse button and navigate to the
directory where you downloaded the T60c drivers.
Click OK to proceed.
9 Click Next. Windows displays a window indicating
that it found the (best) driver for the device. Click
Next.
10 Windows finishes installing the modem. Click
Finish when prompted.
11 Set up your data access software according to the
instructions supplied with it. Look for Ericsson
T60c Data Fax Modem in modem list when
configuring software which will access the handset
as a modem.

Notforcommercialuse
6AE/LZT 123 2489 R1
Windows 2000 Using DRS-11
1 If you plan to use a high-speed serial port, install
and configure it now according to the
manufacturer’s directions. Make sure the speed is
set to 230400 bps.
2 Connect your computer to your phone. The cable
has a plug on one end that matches the receptacle
on the bottom of your mobile phone. The other
end of the cable has a 9-pin female connector that
matches the standard 9-pin serial interface port
connector. Connect one end of the cable to your
mobile phone and the other end to the serial port
on your computer.
3 Make sure the phone is turned on.
4 Reboot the PC. You must logon using an account
with administrator privileges. Contact your
network administrator or help desk for more
information.
5 The PC should detect your phone as “new
hardware” and automatically launch a new
hardware wizard. If it does not, you must manually
setup the T60c. See “Manually Installing T60c
Modem Drivers” on page 7.
6 Click Next to proceed. Select Search for a suitable
driver and click Next. Make sure Specify a location
is checked. Click Next.
7 Click the Browse button and navigate to the
directory where you downloaded the T60c drivers.
Click Open. Click OK to proceed.
8 Windows displays a windows indicating it found
the driver. Click Next to proceed.
9 A message titled Digital Signature Not Found
appears. Click Yes to proceed.
10 Windows installs the driver. Click Finish.
11 Set up your data access software according to the
instructions supplied with it. Look for Ericsson
T60c Data Fax Modem in modem list when
configuring software which will access the handset
as a modem.
Windows NT 4.0 Using DRS-11
See “Manually Installing T60c Modem Drivers” on page
7.

Notforcommercialuse
AE/LZT 123 2489 R1 7
Windows 98, ME, or 2000 Using DCU-10
Note! If you are running Windows 2000, you must be
logged on with administrator privileges before
proceeding. Contact your network administrator
or help desk for more information.
1 Turn on your mobile phone.
2 Connect the phone to the USB cable.
3 Connect the USB cable to the PC and install it
according to the directions that came with the
cable. The PC identifies it as new hardware and
installs a new serial port named USB Cable
DCU-10.
4 Go to Start, Settings, Control Panel and double
click on System. If running ME, and Modem is not
listed, click on the blue link View All Control
Panel Options.
5 Click on the tab Device manager. Scroll down to
Ports (COM & LPT) and double-click it to
expand the tree.
6 Double-click on the port USB Cable DCU-10.
7 Click on Port Settings.Make sure Bits per second
is set to 230400 bps and Flow control is set to
Hardware.
8 Click OK to close USB port properties windows.
Click OK to close the system properties window.
9 If your PC did not detect your phone, see
“Manually Installing T60c Modem Drivers” on
page 7.
Manually Installing T60c Modem
Drivers
1 Click Start.
2 Click Settings. Note! Window XP users should
skip this step.
3 Click Control Panel.
4 When using:
Windows 98
a Double click on Modems.

Notforcommercialuse
8AE/LZT 123 2489 R1
b If you already have modems installed, Add will
appear as an option. Click Add. Otherwise
proceed to Step 5.
Windows ME
a If modem is not listed click on the blue link
View all control panel options.
b Double click on Modems.
c If you already have modems installed, Add will
appear as an option. Click Add. Otherwise,
proceed to step 5.
Windows NT
aClickonModems.
b If you already have modems installed, Add will
appear as an option. Click Add. Otherwise,
proceed to Step 5.
Windows 2000
a Double click on Phone and Modems.
bClickonModem.
cClickAdd.
Windows XP
aClickonPrinter and Other Hardware.
bClickonPhone and Modem options.
cClickonModems.
dClickAdd.
5 Click on Don’t detect my modem. Then click
Next.
6 Click on Have Disk.
7 Click on Browse. Locate the file you downloaded
from the Sony Ericsson website.
8 Select the Inf. for the T60c.
9 When using:
Windows 98 and Windows ME
Click OK.
Windows NT, Windows 2000, or Windows XP
Click Open.
10 Click OK.
11 Select Ericsson T60c Data Fax Modem and then
click Next.
12 Select the communications port. Then click Next.
13 When using:

Notforcommercialuse
AE/LZT 123 2489 R1 9
Windows 2000
A message box called Digital Signature Not Found
is displayed. Click on Yes.
Windows XP
A box titled Hardware Installation is displayed.
This box indicates the Inf. has not passed the logo
test. Click Continue Anyway.
14 If prompted, enter the dialing properties.
15 Click Finished.
16 You have installed the Inf. File/Drivers for the
T60c Phone.
High-Speed Data Setup
Note! If you are using regular speed data, fax, and
Internet service, you do not need to perform the
steps in this section.
1 Attach the phone to your PC and make sure it is
turned on.
2 In the phone, select Settings, DataFaxModem,
Modem Speed.
3 Select the appropriate speed based on the type of
cable or serial port you are using:
•If you are using a high-speed serial port or the
DCU-10 USB cable with your T60c, then select
230400 bps.
•If you are using a regular serial port with your
T60c, then select 115200 bps.
4 On your PC, navigate to the window containing
the list of installed modems:
Windows NT 4.0, Windows 98, or Windows ME
aGotoStart, Settings, Control Panel.
b Double click on Modems.
Windows 2000
aGotoStart, Settings, Control Panel, Phone and
Modem Options.
bClickModems.
Note! If the Properties button is grayed out, then
restart your PC with the phone attached and turned
on.

Notforcommercialuse
10 AE/LZT 123 2489 R1
Windows XP
aGotoStart, Control Panel, Printers and Other
Hardware, Phone and Modem Options.
bClickontheModems tab. Note: If the
Properties button is grayed out, then restart your
PC with the phone attached and turned on.
5 Select Ericsson T60c Data Fax Modem and click
the Properties button.
Note! For Windows XP, you must also have to click on
the Modem tab after clicking on the Properties
button.
6 Change the setting Maximum Speed or Maximum
Port Speed so that it matches the speed you chose
in your mobile phone:
•If you are using a high-speed serial port or the
DCU-10 USB cable with your T60c, then select
230400 bps.
•If you are using a regular serial port with your
T60c, then select
•115200 bps.
7 Accept the changes.
8 Close the window.
Operation
Making Data and Fax Calls
Review the instructions from your mobile service
provider that describe the procedures and rules for
making and receiving data calls in your area.
To avoid unnecessary airtime charges, terminate your
data calls as soon as you have finished transferring files by
pressing the right soft key.
Making Voice Calls While Connected to
Your Computer
You can originate voice calls when you are not on a data
call. You can receive voice calls if Data/Fax is set to Voice
Calls. Your mobile phone enables you to initiate voice
calls from Windows applications when connected to the
Ericsson Voice Call Dialer. This is particularly useful if
you have contact cards with phone numbers in a contact
management application. You can open a contact card,
click on the phone icon, and originate a call using your
mobile phone. Then you simply pick up your mobile

Notforcommercialuse
AE/LZT 123 2489 R1 11
phone and continue the call. The Ericsson Voice Call
Dialer is compatible with most contact manager software
packages.
To install this feature, follow the directions in “Manually
Installing T60c Modem Drivers” on page 7, except you
must select the modem labeled Ericsson T60c Voice Call
Dialer in step 11. Also, Modem Speed (under Settings,
DataFaxModem in your phone) must be set to Up to
19200 bps.
Use With Other Accessories
Charger
To charge your phone’s battery with an approved charger
during data operation, do the following:
1 Plug the charger cable into the serial or USB cable.
The charge connector is located on the end of the
cable that plugs into the phone.
2 Plug the charger cable into the wall outlet or
cigarette lighter.
Bluetooth™ Phone Adapter DBA-10
Before using the high-speed modem option and the
Bluetooth™ Phone Adapter, Modem Speed (under
Settings, DataFaxModem in your phone) must be set to
115200 bps. After use, restore the Modem Speed setting
to its previous value. Failure to do this will make the
phone adapter inoperable and may interfere with the
high-speed modem operation.
CommuniCam MCA-10 or MCA-20
Before using the high-speed modem option and the
CommuniCam MCA-10 or MCA-20, Modem Speed
(under Settings, DataFaxModem in your phone) must
be set to Up to 19200 bps before attaching the
CommuniCam. After use, restore the Modem Speed
setting to its previous value. Failure to do this will make
the CommuniCam inoperable and may interfere with
the high-speed modem operation.
Achieving Best Performance
Charging your Battery
Both your mobile phone and your laptop computer
batteries should be well-charged before starting data
operation. This will help you avoid interruptions due to
loss of power. You can charge your phone’s battery with
an approved charger during data/fax operation as
mentioned previously.

Notforcommercialuse
12 AE/LZT 123 2489 R1
Signal Strength
It is important to maintain a good signal path between
the phone and the mobile telephone system when
making data calls. Signals are generally stronger when the
phone is in an upright position and the antenna is fully
extended. If you are indoors, your signal is generally
stronger when the phone is near a window.
In a Vehicle
It is possible to receive data calls while in your vehicle.
Operation from a moving vehicle may not be satisfactory
because data may be lost when your call is transferred
from one mobile base station to another. Be sure to give
full attention to driving and pull off the road and park
before making or receiving calls, if driving conditions so
require.
Transmission Disturbances
Brief interruptions of mobile telephone signals that
would not be bothersome during a voice call may cause
problems during data operation, depending upon the
error correction capabilities of the software being used.
Such interruptions are uncommon during stationary
operation, but can be caused by vehicles or people
passing nearby, especially in areas of low signal strength.
You can use the signal strength indicator on your phone
to verify that you have a good signal path.
Troubleshooting
Your PC does not recognize the phone.
You may need to install your phone’s modem drivers. See
“Manually Installing T60c Modem Drivers” on page 7.
You cannot set up or maintain a data/fax
session.
This occurs if you are inadvertently originating a voice
call when attempting a data/fax call. To correct the
problem, do the following:
1 From the Start menu on your Windows desktop,
click on Settings, then Control Panel.
2 Double-click the Modems icon.
3 Select the General tab.
4 Select Ericsson T60c Data Fax Modem from the
pull-down list.
5 Click Properties.

Notforcommercialuse
AE/LZT 123 2489 R1 13
6 Click General. Make sure that the maximum speed
is set to 19200 bps.
7 Select the Connection tab.
8 Click Advanced.
9 In the Extra settings box, type the following:
&C1+CRM=0;
10 Click OK to return to the Connection tab.
11 Click OK to return to Modem Properties.
12 Click Close.
If you are using an application that supplies its own box
for entering extra settings, then type the following
command string into that box
as well: +COS=4,1,2,0; +ES=1,0,1; +DS=0,0,512,6;
You cannot originate voice calls from the
PC.
1 From the Start menu on your Windows desktop,
click on Settings, then Control Panel.
2 Double-click the Modems icon.
3 Select the General tab.
4 Select Ericsson T60c Voice Call Dialer from the
pull-down list.
5 Click Properties.
6 Select the Connection tab.
7 Click Advanced.
8 Type the following in the Extra Settings box of the
Advanced Connection Settings window:
*ERVNOK=1
9 Click OK to return to the Connection tab.
10 Click OK to return to Modem Properties.
11 Click Close.
You are having trouble initiating data/fax
calls from your computer.
Check to see if your COM ports are occupied. If so, you
must temporarily disable the software applications that
are using the COM port.
You cannot receive data or fax calls
1 Review the instructions from your mobile service
provider that describe the procedures and rules for
making and receiving data calls in your area.
2 Set up your phone and computer as described
above.
3 Choose DataFaxModem from the Settings menu
in your mobile phone.

Notforcommercialuse
14 AE/LZT 123 2489 R1
4 Choose Data/Fax.
5 The current selection is indicated by a filled radio
button.
6 Scroll until the call type for the next call is
highlighted. The available call types are: Voic e
Calls, Next Call Fax, Fax On, Next Call Data, and
Data On.
•Voice Calls setting is active until you choose a
different setting.
•Fax On and Data On settings apply until you
power off your phone.
•Next Call Fax and Next Call Data settings
apply only for the next incoming call.
Afterwards, the phone automatically switches
back to Voice Calls.
7 Press Select to choose the highlighted call type.
8 The call type you chose now appears in the display.
Your phone is now configured for your next
incoming call.
Error Messages
• The modem is not responding properly.
• Hardware failure in port or attached device.
Check to see if the COM ports speed in the phone is set
properly and matches the setting of the T60c modem.
Technical Assistance
•North America - +1-800 ERICSSON
(1-800-374-2776)
•Latin America - [phone]
•Other countries - [phone]
Downloading the T60c Drivers
http://www.SonyEricssonMobile.com/mobileinternet
Ordering Accessories
You can purchase accessories by:
•Visiting http://www.SonyEricssonMobile.com
•Calling [phone] (outside the U.S.)
1-800-374-2776 (inside the U.S.)
•Visiting your local Sony Ericsson retailer.
