Sony TA-WR2 User manual

SERVICE MANUAL
Sony Corporation
Audio Group
Published by Sony Engineering Corporation
US Model
Canadian Model
AEP Model
UK Model
SURROUND AMPLIFIER
9-879-677-01
2005E1678-1
© 2005.05
Ver. 1.0 2005.05
SPECIFICATIONS
TA-WR2
TA-WR2 is the surround amplifier section in
DAV-FX100W/DZ700FW.
Power requirements 220 – 240 V AC, 50/60 Hz (AEP, UK, RU)
120V AC, 60 Hz (US, CND)
Power consumption 50 W
Dimensions (approx.) 260 260.5 58 mm
(w/h/d)
Mass (approx.) 1.45 kg
Design and specifications are subject to change
without notice.
××
•Abbreviation
RU : Russian model
CND : Canadian model

2
TA-WR2
TABLE OF CONTENTS
1. GENERAL ................................................................... 3
2. DIAGRAMS
2-1. Block Diagram ................................................................ 5
2-2. Printed Wiring Board — DIAT POWER Section —...... 6
2-3. Schematic Diagram — DIAT POWER Section — ........ 7
2-4. Printed Wiring Board — RX Board — .......................... 8
2-5. Schematic Diagram — RX Board (1/2) — .................... 9
2-6. Schematic Diagram — RX Board (2/2) — .................... 10
3. EXPLODEDVIEWS
3-1. Overall Section ................................................................ 17
3-2. RX Board, DIAT POWER Board Section ....................... 18
4. ELECTRICAL PARTS LIST .................................. 19
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270 °C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscou-s (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR
LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES
PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE
FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS
QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT
DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS
PUBLIÉS PAR SONY.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety check before releasing the set to the customer:
Check the antenna terminals,metal trim, “metallized” knobs,screws,
and all other exposed metal parts forAC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. Acommercial leakage tester,such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operatedAC voltmeter.The “limit” indication
is 0.75V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples
of a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2VAC range are suitable. (See
Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k Ω 0.15 µ FAC
voltmete
r
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground

3
TA-WR2
SECTION 1
GENERAL This section is extracted
from instruction manual.
Surround amplifier
APOWER/ON LINE indicator (33)
BPOWER (33)
CDIR-R2 jack (15)
DSPEAKER jacks (15)
POWER/ON LINE
POWER
SURROUND L SURROUND R
SPEAKER DIR-R2
Front panel
Rear panel

4
TA-WR2 SECTION 2
DIAGRAMS
•Waveforms
– RX Board –
Note on Schematic Diagrams:
•All capacitors are in µF unless otherwise noted. (p: pF)
50WV or less are not indicated except for electrolytics and
tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
• f: internal component.
•2: nonflammable resistor.
•C: panel designation.
•A: B+ Line.
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark: Power on
•Voltages are taken with aVOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
•Circled numbers refer to waveforms.
•Signal path.
F: AUDIO
•Abbreviation
RU : Russian model
CND : Canadian model
Note on PrintedWiring Boards:
•X: parts extracted from the component side.
•Y: parts extracted from the conductor side.
• f: internal component.
•: Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
•Indication of transistor.
• Note for PrintedWiring Boards and Schematic Diagrams
C
BThese are omitted. E
Q
Note:
The components identi-
fied by mark 0or dot-
ted line with mark 0are
critical for safety.
Replace only with part
number specified.
Note:
Les composants identifiés
par une marque 0sont cri-
tiques pour la sécurité.
Neles remplacerque par une
piéce portant le numéro
spécifié.
Caution:
Pattern face side: Parts on the pattern face side seen from
(SIDE A) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(SIDE B) the parts face are indicated.
3 IC111 rk (XFSOIN)
1 V/DIV, 10 ns/DIV
2 IC102 r; (OSCI)
1 IC107 wd (X1)
1 V/DIV, 100 ns/DIV
1 V/DIV, 40 ns/DIV
125 ns 20.3 ns
81.3 ns
3.7 Vp-p 4.8 Vp-p
3.4 Vp-p
B
These are omitted.
CE
Q

55
TA-WR2
TA-WR2
2-1. BLOCK DIAGRAM
IC111
STREAM PROCESSOR
IC109
AND GATE
19 SOFTMUTE
18 NSPMUTE
21 SCDT
20 PGMUTE
23 SCLATCH
22 SCSHIFT
34
35
DAMP_NSPMUTE
DAMP_SOFTMUTE
DAMP_SGMUTE
DAMP_SCDT
DAMP_SHIFT
DAMP_LATCH
61
33
59
XRST_INIT 26
DRIVE RST
AC CUT
37
DRIVE OCP 38
XO 22
XI 23
60
48
2 4
XFSOIN
27 INIT
4
OUTR2
6
OUTR1
30 BCK
31
6
4
5
3
1
2
11
12
13
8
9
10
DATA
9
OUTL2
11
OUTL1
29 LRCK
36 XFSIIN
IC107
SYSTEM CONTROLLER
IC114
OSC
X103
49.152MHZ
41 LED GREEN
42 LED RED
RESET
SCK2
SO2
MOD
SI2
17 AC CUT
19 /RESET
21 MOD1
(3)
(1)
(2)
(3)
(4)
(4) 62 SI2
20 MOD0
57
MAIN OFF
58
V CONT
15 CSOD
DRVALID
53 DIAT_SRDT
50 XSCEN
SCLK
SWDT
SCMODE
52 DIAT SWDT
51 DIAT SCLK
31
IC102
RF DEMODULATOR
A/D CONVERTER
J100
DIR-R2
43
OSCO
40
OSCI
13
XRST
10 ADVIN
54
BCK
60
DAOUT DATA
BCK
APX
LRCK
X101
12.288MHz
59
LRCK
31
APX
31
33
CSOB
61
DTVALID
34
SRDT
31
36
XSCEN
38
SCMODE
35
SWDT
37
SCLK
IC110
POWER AMP
T100
13 /SD
4/RST
25
26
17
2PWMBP
PWMAP
29
30
OUT B REAR RCH+
REAR RCH-
REAR LCH+
REAR LCH-
OUT B
OUT A
OUT A
13 /SD
4/RST
25
26
17
2PWMBP
PWMAP
29
30
OUT B
OUT B
OUT A
OUT A
3.3V
5V
12V
30V
2.5V
1.8V
1.5V
IC112
POWER AMP
IC106
AND GATE
IC103
AND GATE
6
4
5
8
9
10
11
12
13
14
48
LF901
31
2
4
5
9
10
12
13
6
8
11
2 1
5V
L101
Q108,109
OVER LOAD
DETECT
Q105,106
OVER LOAD
DETECT
POWER
IC108
3.3V REG
IC903
12V REG
IC104
2.5V REG
IC113
1.8V REG
IC101
1.5V REG
Q113
SWITCH
D901
MAIN RECT
IC901
SWITCHING
F901
*
Q901
LEVEL SHIFT
D921
RECT
T901
POWER TRANSFORMER
Q117 DC FAN
X102
8MHZ
12V
(1)
(2)
13
IC905
SHUNT REG PC901
TH902
PC903
1
IC904
5V REG 6
5
2
D
1
VCC
4
OCP/BD
7
SS/OLP
5
FB
6
2
3
PC902 D911
S901
AC IN
TH901
3.3V
Q110
MAIN OFF
V CONT
Q903
Q902
Q107
PRO TECT
Q104
Q103
Q102
Q112 5V
Q111
GREEN
D100
RED
VDD
3.3V
OUT
IC105
RESET
FLASH
PROGRAMING
CONNECTOR
*F901
T3.15A/250V(AEP, UK, RU)
T5A/125V(US, CND)
: AUDIO
• Signal Path

66
TA-WR2
TA-WR2
2-2. PRINTEDWIRING BOARD — DIAT POWER SECTION — :Uses unleaded solder.
1
1
1
1
1
1
6
EE
E
3
3
7
45
8
K
AC
E
K
AC
E
K
A
C
E
2
3
7
7
POWER
AC IN
AEP, UK, RU
AEP, UK, RU
A
RX BOARD
CN102
(Page 8)
B
RX BOARD
CN103
(Page 8)
IC903
IC904
IC905
IC901
• Semiconductor
Location
Ref. No. Location
D901 C-7
D902 B-5
D904 D-6
D905 D-8
D906 D-7
D907 D-7
D908 D-7
D909 D-7
D910 D-5
D911 D-8
D913 D-7
D914 D-7
D915 E-7
D921 B-3
D922 D-3
D933 C-2
D934 C-2
IC901 C-5
IC903 C-3
IC904 D-3
IC905 C-4
Q901 D-8
Q902 D-6
Q903 D-7

77
TA-WR2
TA-WR2
2-3. SCHEMATIC DIAGRAM — DIAT POWER SECTION —
10
9
L904
D901
R947
TP901
TP902
TP903
TP904
TP905
TP906
TP907
TP908
TP909
IC903
R913
TP911
TP913
TP912
TP910
TP914
TP915
R907
L903
FH901 FH902 AEP, UK, RU
EB901
EB902
D921
R923
D922
D902
D915
L901
C915
C936
C938
C941
R903
R904
C904
CN903
IC905
R902
C906
R906
R908
R917 R922
IC901
C903
C907
C908
C918
CN905
F901
C901
LF901 T901
TH901
D911 PC902
D906
D904
Q901
D907
D909
D908
D910
TH902
D913
R920
Q902
D914
Q903
PC903
R916
R915
R914
D905
C911
C914
R912
C913
R926
R921
C916
R911
C912
R909
C909
C910
R910
TP916
R919
C933
C932
C931
C925
R938
R939
R933
R932
R934
C935
R935 R948
R936
C942
R940
C940
R943
R942
R944
C937
CN904
D934
D933
R946
C934
R937
C917
R905
R924
R925
IC904
CNP901
CN901
S901
PC901
R941
R945
R931
D3SB60F3
0
30V
GND
GND
12V
5V
DGND
V-CONT
AC-CUT
MAIN-OFF
TA7812S
820
1/4W
GND
GND
VIN
VOUT
D
S/GND
0
FML-22S
11EQS04
-TA1B
SARS03
MTZJ-T-77- 33B
47
35V
100
35V
100
16V
470
10V
JW
JW
0.1
275V
2P
NJM1431AU
7P
0.22
275V
NTC8.0
10EDB60-TA1B2 PC123Y22JO0F
MTZJ-T-77-20B
11EQS10-TA1
2SD1616A-TP-LK
1SS355TE-17
1SS355TE-17
11EQS10-TE1
UDZSTE-179.1B
(POSITIVE)
UDZSTE-176.2B
4.7k
DTA114EKA-T146
UDZSTE-1710B
DTC144EKA-T146 PC123Y22JO0F
22
22
4.7k
MTZJ-T-77-33B
100p
100V
0.0033
50V
1k
1/4W
22
50V
10k
68k
0.01
1k
0.1
50V
1k
10
50V
470p
50V
100
VCC
1.5k
0.1
50V
1000
35V
4700p
1kV
0.001
250V
1k
1k
47k
4.7k 100
16V
3.9k
2.2k
0.1
50V
1
220p
50V
1.5k1.5k
1k
0.1
50V
7P
UDZSTE-1710B
UDZSTE-1710B
100
0.01
390
0.01
NJM2374AE(TE2)
2P
2P
PC123Y22JO0F
1
2.2k
3300p
630V
1M
1/2W
0
T3.15AL/
250V
43MH
0.6A
LFC
*
0
330
27k
+0.5%
*
*
*
*
*
*
*
*
*
**
*
*
AEP, UK, RU
*
C903
C906
C907
C908
IC901
LF901
R905
R906
R908
R917
R922
R924
R925
T901
0.0022uF, 250V
330uF, 200V
10000PF, 630V
3300PF, 1.2KV
STR-W6735N
1-424-930-11
15k, 1/4W
100k, 2W
0.12, 2W
33k, 1/4W
33k, 1/4W
15k, 1/4W
15k, 1/4W
1-443-744-11
440PF, 250V
100uF, 450V
3300PF, 630V
680PF, 1.5KV
STR-W6765N
1-457-083-11
22k, 1/4W
82k, 2W
0.27, 2W
47k, 1/4W
47k, 1/4W
22k, 1/4W
22k, 1/4W
1-443-743-11
US, CND AEP, UK, RU
•See page 11 for IC Block Diagrams.

88
TA-WR2
TA-WR2
2-4. PRINTEDWIRING BOARD — RX BOARD — :Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
D100 E-4
D102 F-3
D103 F-5
D104 C-6
D105 C-5
D106 C-5
D107 C-5
D115 D-5
IC101 F-1
IC102 E-1
IC103 E-2
IC104 E-1
IC105 F-2
IC106 F-2
IC107 E-2
IC108 E-5
IC109 E-2
IC110 D-2
IC111 D-2
IC112 D-2
IC113 D-3
IC114 D-2
Q102 F-3
Q103 F-4
Q104 F-4
Q105 B-2
Q106 B-5
Q107 C-3
Q108 B-1
Q109 B-6
Q110 F-4
Q111 F-3
Q112 F-3
Q113 C-1
Q117 C-6
IC110
IC111
IC104
IC109
IC103
IC107
IC102
IC106
IC101
IC105
IC113
IC114
IC112
IC108
B
DIAT POWER
BOARD
CN905
(Page 6)
A
DIAT POWER
BOARD
CN904
(Page 6)
SURROUND L
1
DIR-R2
6
6
1
13
E
E
E
DC FAN
FLASH
PROGRAMMING
CONNECTOR
EE
E
13
46
1
34
5
3
1
5
4
3
4
51
13
4
5
SURROUND R
E
E
E
E
E
E
E

99
TA-WR2
TA-WR2
2-5. SCHEMATIC DIAGRAM — RX BOARD (1/2) —
7
10
C163
L102
L103
R100
L106
R137
R108
R105
R120
R103
R119
R116
IC101
R102
R104
R117
R101
R145
R114
R253
R131
R140
R139
R144
R141
R115
X102
IC105
C150
R122
C147
C148
C140
R118
R151
R150
R149
R261
R262
TP1 TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
TP10
TP12
TP13
TP14
TP15
TP16
TP17
TP25
TP27
TP28
TP29
TP30
C107
C102
C137
FB107
R165
R123
Q103
Q104Q111
Q110
FB109
R111
R109
FB102
FB101
FB104
L101
IC104
FB103
D100
R134
R132
R130
R133
R143
R146
R147
R148
EB103 R125
R264
R265
R266
D103
D102
IC108
IC103
IC106
R284
C105
C131
C135
C142
C138
C130C119
C111
C110
C108
IC102
C113
C109
C104
C103
C101
C115
C114
C124
C127 C129
C141
C134
CN101
C157
C158
C153
C155
C154
C266
C253
C133
L104
L105
C128
C132
C120
C136
R110
C116
X101
C122
C123 C126
EB102
C125
L108
FB105
C160
C162
C159
R138
R135
CN103
C149
L107
C143
R124
C145
C146
R127
R126
R283
C156
C151
R258
R257
R152
R171
R129 R142
R252
R254
Q112
FB106
R256
L109
R106
IC107
Q102
C161
R136
J100
R259
R112
R113
100
10V
150
100
100
47k
1k
330
1k
68
XC62HR1502MR
820
3.3k
10k
10k
100
100
47k
47k
100
100
100
100
100
8MHz
PST3629NR
100
10V
10k
0.001
0.1
16V
10
50V
1k
100
100
100
100
100
47
16V
10 50V
10 50V
0UH
1k
22k
DTC114EKA-
T146
DTC114EKA-
T146
DTA114EKA-
T146
DTA114EKA-
T146
0UH
220
3.3k
0UH
0.2A
0UH
0.2A
0UH 0.2A
TK11225CMCL-G
0UH 0.2A
SPR-54MVWF
100
100
100
100
0
100
100
100
EARTH PLATE 120
4.7k
2.2k
4.7k
1SS355TE-17
1SS355TE-17
NJM2885DL1-33(TE
SN74LV08APWR
SN74LVC08APWR
0
0.01
1
0.1
0.01
0.1
0.1
0.1
0.01
0.1
0.1
CXD4017R
0.1
0.1
47
16V
0.1
0.1
0.001
0.001
10p
0.1 33p
0.1
1
7P
100p
100p
100p
100p
10p
0.1
0.22
0.1
47 16V
1
0.01
47 16V
1k
0.1
12.288MHz
100p
100p 100p
EARTH PLATE
100p
0UH
0.01
0.01
100p
100
10k
6P
0.1
0.1
47k
0.22
0.1
47k
1k
47k
100p
0.1
47k
47k
100
47k
100 100
10k
10k
DTA114EKA-T146
0UH
3.3k
100
MB89537APFM
-G-654-BNDE1
2SC2412K
-T-146-OR
100 16V
100
SKY BLUE
1k
100
100
•See page 12,14 for IC Block Diagrams. •See page 4 forWaveforms. •See page 15 for IC Pin Function Description.

1010
TA-WR2
TA-WR2
2-6. SCHEMATIC DIAGRAM — RX BOARD (2/2) —
7
9
R153
R156
R157
R158
R159
R166
R179
R184
R187
R188
R197
R199
C179
C220
C228
C229
L122
FB108
R168
R174
R176
R190
R192
R193
C166
R172
R160
R163
R162
R161
TP18
TP19
TP20
TP21
TP22
TP23
TP24
TP26
R201
R167
R186
R180
R185
R198
R203
R222
L112
L115
L118
L121
L110 L111 L116
R218
R217
R216
R219
R224
R225
IC113
EB101
CN104
EB104
EB105
Q106
Q105
Q108
Q109
IC114
C265
IC109
Q117
IC111
C167
C171
C174
C175C172
C198
C195
C204
C205
C233
C219
X103
C260R267
R270
R271
R269
R175
R181
R173
R263
R183
R212
C243
C188
R178
R213
C186
C170
C200
C181C180
C177
R164
C191C190
C197
R220 C199
C201
R214
C244
C215
R215
C211
R196
C238
C208 R189
C207
R208
R209
R210
R211
R204
R205
R206
R207
C203
D115
C235
C222
C231
C221
C184
C185
C182
R169
C183
C209
C210
R191
R195
C224
C218
C217
C216
C212
C213
C256 C259
C258
C257
L126
L125
L124
L123
CN102
C223
C227
C232
C214
SL301
R194
C206
C230
C237
C187 C196
C178 C202
C234
C226 C225
C236
T100
R154C165
C169
R155
D104
Q107
D105
D106
D107
C192
C193
C194
R177
C189
C173
C176
Q113
R200
IC112
IC110
0
0
0
0
47
16V
100 10V
100 16V
10p
0
0
100k
100k
100k
100k
100k
100k
0UH
0
0
0
0
0
0
2.2
100
100
100
100
100
100
3.3
1/4W
0
3.3
1/4W
0
3.3
1/4W
0
100
10k
10k
10k
10k
10k
10k
IC TK11118CSCL-G
EARTH PLATE
2P
EARTH PLATE
EARTH PLATE
2SA1235TP-1EF
2SA1235TP-1EF
2SA1235TP-1EF
2SA1235TP-1EF
SN74AHC1GU04DCKR
100
16V
SN74LVC08APWR
2SC3243TP-E
CXD9843AR
0.1
100p
100p
100p
100p
0.1
0.1
0.1
0.1
0.01
0.001
49.152MHz
1
50V
1.2k
1.5k
220k
2.2k
560
560
560
4.7k
560
22k
0.1
0.01
100
22k
0.1
1
1
0.220.22
0.033
0
0.220.22
0.033
100 2200
35V
1
22k
0.1
0.01
22k
0.1
100
1
0.22 3.3
1/4W
0.22
10k
10k
10k
10k
10k
10k
10k
10k
0.033
MA8027-H-TX
2200
35V
0.22
0.033
0.22
1
0.047
0.0022
2.7
0.0022
0.0022
0.0022
2.7
2.7
0.0022
0.0022
0.047
1
1
0.047
0.01 0.01
0.01
0.01
6P
0.01
0.1
0.01
100
16V
22
0.1
22 25V
5p
0.1 0.1
47 16V 47 16V
0.01
0.1 100
16V
0.1
TERMINAL BOARD
100k2.2
2.2
100k
P6SMB39AT3
2SC2412K
-T-146-OR
P6SMB39AT3
P6SMB39AT3
P6SMB39AT3
1
0.047
0.0022
2.7
0.0022
0.1
0.1
2SC2412K
-T-146-OR
1M
CXD9775M
CXD9775M
•See page 13,14 for IC Block Diagrams. •See page 4 forWaveform.

11
TA-WR2
•IC Block Diagrams
– DIAT POWER Board –
IC901 STR-W6765N (AEP, UK, RU)
IC904 NJM2374AE (TE2)
D 1
NC 2
S/GND 3
VCC 4
SS/OLP 5
FB 6
OCP/BD 7
DELAY Q
R
S
+
–
+
–
+
–
Q
S
R
+
–BOTTOM
SELECTOR
COUNTER
OSC
R
Q
S
SOFT START
+
–
OVP
REGULATOR
& ICONST
+
–
BURST
CONTROL
START/STOP
BURST
PROTECTION
LATCH
DRIVE
REGULATOR
OLP
BSD
BD
OCP
FB
CS 1
ES 2
CT 3
IN+5
QS
R
PWM
LOGIC
OSC
GND 4
V+6
VREF
+
–
+
–
+
–
ERROR AMP
PWM
COMPARATOR
SI7
CD8
IPK SENSE

12
TA-WR2
IC101 XC62HR1502MR
+
–
3OUTPUT
CONTROL REFERENCE VOLTAGE
4
1
2 5
CURRENT
LIMIT
NC
VIN
CE
VSS
VOUT
ADVRH 6
VSS 5
VDDE 4
SMCK 3
XSM 2
MST 1
ADAVS 7
ADAVD 8
ADVRL 9
ADVIN 10
VDDE 11
VSS 12
XRST 13
DIFM0 14
DIFM1 15
DTSEL 16
A/D
CONVERTER
BUFFER
RAM
ERROR
CORRECTOR
OUTPUT
INTERFACE
DEMODULATOR
PLREF
17
TESTMD
19
APVCI
20
VSS
21
APCPO
22
APAVD
23
APAVS
24
APX
31
EXTCK
32
VSS
25
VDDI
26
VDDE
27
VCOR
28
CHNUM
29
DIVCODE
30
PLVAR
18
PLL CLOCK
SELECTOR
CONTROLLER
CSOD33
SRDT34
SWDT35
XSCEN36
SCLK37
SCMODE38
OSCI40
TEST044
TEST145
TEST246
TEST347
TEST448
OSCO43
VSS
39
VDDE41
VSS
42
CLOCK
GENERATOR
XTST
64
EMPFS1
63
EMPFS0
62
DTVALID
61
DAOUT
60
LRCK
59
VDDI
58
VSS
57
VDDE
56
BCK
54
TXOUT
55
ICLK
53
SYMCLK
52
TEST7
51
TEST6
50
TEST5
49
IC102 CXD4017R
VDD 2
OUT 1
GND 3
+
–
VREF
CD5
NC
4
IC105 PST3629NR
– RX Board –

13
TA-WR2
IC110, 112 CXD9775M
RESET 4
GND 1
GND 3
PWM BP 2
DREG RTN 5
GVDD 6
M3 7
M1 10
M2 11
DVDD 12
DREG 8
DGND 9
DGND 14
GND 16
GND 18
PWM
RECEIVER TIMING
CONTROL
&
PROTECTION
SD 13
OTW 15
DIGITAL
REGULATOR
PROTECTION
LOGIC
OT
&
UVP
DVDD DREG DREG
DGND
PWM AP 17 PWM
RECEIVER
DVDD DREG
DGND
DREG
GVDD
DREG
GATE
DRIVE
GVDD B35
GVDD B36
BST B33
PVDD B
32
PVDD B
31
OUT B
30
OUT B
29
GND
28
GND
34
GATE
DRIVE
OCH
OCL
TIMING
CONTROL
&
PROTECTION
DREG
GATE
DRIVE
GVDD A
20
GVDD A
19
BST A
22
PVDD A
23
PVDD A
24
OUT A
25
OUT A
26
GND
27
GND
21
GATE
DRIVE
OCH
OCL
GVDD
GVDD
IC111 CXD9843AR
S P
Sampling Rate
Converter
DF1
DF2
Gain
Control
Filter
&
LOW
CUT
Filter
Serial Control
Liner
Interpolator
∆ ∑ Converter
XVSS
PWM
INIT/MUTE
Clock Generator
Clock Generator
(Secondary Clock System)
1
VSUBC
2
VSSR
VSSL
VSSL
VSSR
3
OUTR2
OUTL2
OUTR1
OUTL1
4
VDDR
DVDD
DVSS
VDDL
5678
XOVSS
XOVDD
9
XFSOOUT
10 11
NSPMUTE
12
SOFTMUTE
13
PGMUTE
SCSHIFT
14
SCDT
15
SCLATCH
OVF FLAGR
OVF FLAGL
16
SFLAG
INIT
17
MCKSEL
18
LRCK
19
BCK
20
DATA
BFVDD
BFVSS
TEST
DVDD
XFSIIN
21
42
43 41 40 39 38 37
XFSOIN
36
XVDD
35
HPVDDL
34
HPOUTL2
33
HPVSSL
32
31
HPVDDR
30
HPOUTR1 HPOUTL1
29
28
HPVSSR
27
2625
HPOUTR2
24
FSOI
23
FSOCKO
22
4445
46
47
48
(Primary Clock System)

14
TA-WR2
IC113 TK11118CSCL-G
1 2 3
5 4
VCONT
GND
NP
VIN VOUT
CONTROL
CIRCUIT
OVER HEAT &
OVER CURRENT
PROTECTION
BANDGAP
REFERENCE
IC114 SN74AHC1GU04DCKR
2A
3GND
1NC
4Y
5 VCC

15
TA-WR2
•IC Pin Function Description
RX BOARD IC107 MB89537APFM-G-654-BNDE1 (SYSTEM CONTROLLER)
Pin No. Pin Name I/O Description
1NC—Not used
2 MOD2 I Setting terminal for the CPU operation mode Fixed at “L” in this set
3, 4 NC — Not used
5MODEL I Setting terminal for the model
6SIMUKE I Setting terminal for the destination
7 to 10 NC — Not used
11 AVCC — Power supply terminal (+3.3V) (for A/D converter)
12 AVR I Reference voltage (+3.3V) input terminal (for A/D converter)
13 AVSS — Ground terminal (for A/D converter)
14 DTVAILD I Data valid flag input from the RF demodulator “L”: invalid, “H”: valid
15 CSOD I Captor start delay signal input from the RF demodulator “H”: active
16 NC I Ground terminal
17 AC CUT I AC cut detection signal input terminal “L”:AC cut
18 NC I Ground terminal
Reset signal input terminal “L”: reset
19 /RESET I For several hundreds msec. after the power supply rises, “L” is input, then it
changes to “H”
20, 21 MD0, MD1 I CPU operation mode setting signal input terminal
22 XO O Main system clock output terminal (8 MHz)
23 XI I Main system clock input terminal (8 MHz)
24 VSS — Ground terminal
25 FS2_EX I Not used
26 XRST_INIT O Reset signal output to the RF demodulator and stream processor “L”: reset
27, 28 NC — Not used
29 P23 I Setting terminal for the CPU operation mode Fixed at “L” in this set
30 P22 I Setting terminal for the CPU operation mode Fixed at “H” in this set
31, 32 NC — Not used
33 DAMP_PGMUTE O PG muting on/off control signal output to the stream processor “L”: muting on
34 DAMP_SOFTMUTE O Soft muting on/off control signal output to the stream processor “L”: muting on
35 DAMP_NSPMUTE O NSP muting on/off control signal output to the stream processor “L”: muting on
36 NC — Not used
37 DRIVE_RST O Reset signal output to the power driver “L”: reset
38 DRIVE_OCP I Shut down state input from the power driver “L”: shut down
39 DRIVE_OTW I Overtemperature warning signal input terminal Not used
40 P10 I Setting terminal for the CPU operation mode Fixed at “H” in this set
41 LED_GREEN O LED drive signal output of the ON LINE indicator “H”: LED on
42 LED_RED O LED drive signal output of the POWER indicator “H”: LED on
43 to 47 NC — Not used
48 SCMODE O Control mode selection signal output to the RF demodulator
“L”: pin setting, “H”: serial setting”
49 NC — Not used
50 XSCEN O Serial interface enable signal output to the RF demodulator
51 DIAT_SCLK O Serial interface data clock signal output to the RF demodulator
52 DIAT_SWDT O Serial interface data write signal output to the RF demodulator
53 DIAT_SRDT I Serial interface data read signal input from the RF demodulator
54 NC — Not used
55 T_SENSE O Not used

16
TA-WR2
Pin No. Pin Name I/O Description
56 VCC — Power supply terminal (+3.3V)
57 MAIN_OFF O Power off control signal output to the power control “H”: power off
58 V_CONT O Voltage control PWM signal output to the shunt regulator
59 DAMP_LATCH O Latch control signal output to the stream processor
60 DAMP_SHIFT O Shift clock signal output to the stream processor
61 DAMP_SCDT O Serial data output to the stream processor
62 SI2 I Serial data input terminal
63 INT24 O Not used
64 NC O Not used

17
TA-WR2
SECTION 3
EXPLODEDVIEWS
NOTE:
•-XX and -X mean standardized parts, so they
may have some difference from the original
one.
•Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
•The mechanical parts with no reference
numberin the exploded viewsarenotsupplied.
•Abbreviation
RU : Russian model
CND : Canadian model
14-244-969-01 FOOT
22-594-250-01 BOTTOM, PANEL
3X-2055-406-1 BOTTOM ASSY (AEP, UK, RU)
3X-2055-558-1 BOTTOM ASSY (US, CND)
4 2-594-248-01 TOP, CABINET (AEP, UK, RU)
42-594-248-11 TOP, CABINET (US, CND)
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
3-1. OVERALL SECTION
42-594-251-01 TOP, CABINET (DUMMY)
5X-2055-405-1 TOP CABINET ASSY (AEP, UK, RU)
5X-2055-557-1 TOP CABINET ASSY (US, CND)
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-351
#1
#1
#1
#1
#1
#1
#1
#2
#2
#2
#
2
chassis section
not
supplied
not
supplied
4
5
2
3
11

18
TA-WR2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
51 A-1111-677-A RX BOARD, COMPLETE
52 A-1111-680-A DIAT POWER BOARD, COMPLETE (AEP, UK, RU)
52 A-1111-687-A DIAT POWER BOARD, COMPLETE (US, CND)
53 1-787-331-11 FAN, D.C.
054 1-783-531-91 CORD, POWER (US, CND)
054 1-828-528-11 CORD, POWER (AEP, UK, RU)
55 4-217-350-11 STOPPER, CORD
56 4-240-812-01 HOLDER, WIRE
57 7-630-002-00 TUBE, PVC
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-351
#3 7-685-881-09 SCREW +BVTT 4X8 (S)
0F901 1-532-465-33 FUSE (T3.14AL/250V)(AEP, UK, RU)
0F901 1-533-453-12 FUSE, GLASS TUBE (DIA. 5)
(T5AL/125V)(US, CND)
3-2. RX BOARD, DIAT POWER BOARD SECTION
51
52
53
54
55
56
57
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
#2
#2
#3
a
a#2
#2
#2
#2
F901
not
supplied

19
TA-WR2
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
•Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
•RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
•-XX and -X mean standardized parts, so they
may have some difference from the original
one.
•SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
•CAPACITORS
uF: µF
•COILS
uH: µH
•Abbreviation
RU : Russian model
CND : Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference number,
please include the board name.
A-1111-680-A DIAT POWER BOARD, COMPLETE (AEP, UK, RU)
A-1111-681-A DIAT POWER BOARD, COMPLETE (US, CND)
***************************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
0C901 1-165-529-11 MYLAR 0.22uF 10 275V
0C903 1-113-900-11 CERAMIC 470PF 10% 250V
(AEP, UK, RU)
0C903 1-113-907-51 CERAMIC 0.0022uF 99% 250V
(US, CND)
0C904 1-165-528-11 MYLAR 0.1uF 10 275V
0C906 1-100-923-11 ELECT 100uF 20% 450V
(AEP, UK, RU)
0C906 1-100-922-11 ELECT 330uF 20% 200V
(US, CND)
0C907 1-165-886-11 CERAMIC CHIP 3300PF 10% 630V
(AEP, UK, RU)
0C907 1-165-883-11 CERAMIC CHIP 10000PF 10% 630V
(US, CND)
0C908 1-125-893-11 FILM 680PF 3% 1.5KV
(AEP, UK, RU)
0C908 1-117-631-31 FILM 3300PF 3% 1.2KV
(US, CND)
0C909 1-107-906-11 ELECT 10uF 20% 50V
0C910 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
0C911 1-164-162-11 CERAMIC CHIP 100PF 5% 100V
0C912 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
0C913 1-107-907-11 ELECT 22uF 20% 50V
0C914 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
0C915 1-107-909-11 ELECT 47uF 20% 35V
C916 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0C917 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
0C918 1-165-886-11 CERAMIC CHIP 3300PF 10% 630V
(AEP, UK, RU)
0C925 1-117-699-11 CERAMIC 0.001uF 99% 250V
C931 1-125-782-91 CERAMIC 4700PF 10% 1KV
C932 1-128-959-21 ELECT 1000uF 20% 35V
C933 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C934 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C935 1-126-933-11 ELECT 100uF 20% 16V
C936 1-126-948-11 ELECT 100uF 20% 35V
C937 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C938 1-126-933-11 ELECT 100uF 20% 16V
C940 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C941 1-135-372-31 ELECT 470uF 20% 10V
C942 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN903 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0D901 8-719-077-77 DIODE D3SB60F3
0D902 6-500-241-01 DIODE SARS03
0D904 8-719-200-91 DIODE 11EQS10-TA1
0D905 8-719-982-26 DIODE MTZJ-T-77-33B
0D906 8-719-110-53 DIODE MTZJ-T-77-20B
0D907 8-719-988-61 DIODE 1SS355TE-17
0D908 8-719-200-91 DIODE 11EQS10-TA1
0D909 8-719-988-61 DIODE 1SS355TE-17
0D910 8-719-069-60 DIODE UDZSTE-179.1B
0D911 6-500-593-31 DIODE 10EDB60-TA1B2
0D913 8-719-069-56 DIODE UDZSTE-176.2B
0D914 8-719-977-28 DIODE UDZSTE-1710B
0D915 8-719-982-26 DIODE MTZJ-T-77-33B
D921 8-719-313-14 DIODE FML-22S
D922 8-719-210-21 DIODE 11EQS04-TA1B
D933 8-719-977-28 DIODE UDZSTE-1710B
D934 8-719-083-66 DIODE UDZSTE-1718B
< GROUND TERMINAL BOARD >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE HOLDER >
FH901 1-533-313-11 FUSE HOLDER
FH902 1-533-313-11 FUSE HOLDER
< IC >
0IC901 6-706-347-01 IC STR-W6735N (US, CND)
0IC901 6-706-348-01 IC STR-W6765N (AEP, UK, RU)
IC903 8-759-231-58 IC TA7812S
IC904 6-703-978-01 IC NJM2374AE (TE2)
IC905 6-707-799-01 IC NJM1431AU (TE2)
< COIL >
L901 1-456-509-11 INDUCTOR 10uH
L903 1-416-040-11 INDUCTOR 220uH
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
DIAT POWER

20
TA-WR2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
L904 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0LF901 1-424-930-11 COIL, LINE FILTER (US, CND)
0LF901 1-457-083-11 COIL, LINE FILTER (AEP, UK, RU)
< PHOTO COUPLER >
0PC901 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
0PC902 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
0PC903 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
< TRANSISTOR >
0Q901 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
0Q902 8-729-027-23 TRANSISTOR DTA114EKA-T146
0Q903 1-801-806-11 TRANSISTOR DTC144EKA-T146
< RESISTOR >
0R902 1-219-759-11 METAL 1M 5% 1/2W
(AEP, UK, RU)
0R905 1-249-431-11 CARBON 15K 5% 1/4W
(US, CND)
0R905 1-249-433-11 CARBON 22K 5% 1/4W
(AEP, UK, RU)
0R906 1-215-904-11 METAL OXIDE 100K 5% 2W
(US, CND)
0R906 1-216-468-11 METAL OXIDE 82K 5% 2W
(AEP, UK, RU)
0R907 1-216-864-11 SHORT CHIP 0
0R908 1-216-362-11 METAL OXIDE 0.27 5% 2W
(AEP, UK, RU)
0R908 1-245-261-61 METAL OXIDE 0.12 5% 2W
(US, CND)
0R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R910 1-216-809-11 METAL CHIP 100 5% 1/10W
0R911 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R912 1-249-417-11 CARBON 1K 5% 1/4W
0R913 1-249-416-11 CARBON 820 5% 1/4W
0R914 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0R915 1-216-801-11 METAL CHIP 22 5% 1/10W
0R916 1-216-801-11 METAL CHIP 22 5% 1/10W
0R917 1-249-435-11 CARBON 33K 5% 1/4W
(US, CND)
0R917 1-249-437-11 CARBON 47K 5% 1/4W
(AEP, UK, RU)
0R919 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
0R920 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0R921 1-216-843-11 METAL CHIP 68K 5% 1/10W
0R922 1-249-435-11 CARBON 33K 5% 1/4W
(US, CND)
0R922 1-249-437-11 CARBON 47K 5% 1/4W
(AEP, UK, RU)
0R923 1-216-864-11 SHORT CHIP 0
0R924 1-249-431-11 CARBON 15K 5% 1/4W
(US, CND)
0R924 1-249-433-11 CARBON 22K 5% 1/4W
(AEP, UK, RU)
0R925 1-249-431-11 CARBON 15K 5% 1/4W
(US, CND)
0R925 1-249-433-11 CARBON 22K 5% 1/4W
(AEP, UK, RU)
0R926 1-216-833-11 METAL CHIP 10K 5% 1/10W
R931 1-218-726-11 METAL CHIP 27K 0.5% 1/10W
R932 1-216-864-11 SHORT CHIP 0
R933 1-216-841-11 METAL CHIP 47K 5% 1/10W
R934 1-218-708-11 METAL CHIP 4.7K 0.5% 1/10W
R935 1-218-706-11 METAL CHIP 3.9K 0.5% 1/10W
R936 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R937 1-216-816-11 METAL CHIP 390 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R939 1-216-821-11 METAL CHIP 1K 5% 1/10W
R940 1-218-446-11 METAL CHIP 1 5% 1/10W
R941 1-218-446-11 METAL CHIP 1 5% 1/10W
R942 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R943 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R944 1-216-821-11 METAL CHIP 1K 5% 1/10W
R945 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R946 1-216-809-11 METAL CHIP 100 5% 1/10W
R947 1-216-864-11 SHORT CHIP 0
R948 1-216-815-11 METAL CHIP 330 5% 1/10W
< TRANSFORMER >
0T901 1-443-743-11 TRANSFORMER, DC CONVERTER (AEP, UK, RU)
0T901 1-443-744-11 TRANSFORMER, DC CONVERTER (US, CND)
< THERMISTOR >
0TH901 1-805-799-11 THERMISTOR, NTC 8.0
TH902 1-805-553-21 THERMISTOR, POSITIVE
************************************************************
A-1111-677-A RX BOARD, COMPLETE
******************
< CAPACITOR >
C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C104 1-126-947-11 ELECT 47uF 20% 16V
C105 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C107 1-126-947-11 ELECT 47uF 20% 16V
C108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C120 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C122 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C123 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C124 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-126-947-11 ELECT 47uF 20% 16V
C129 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
RXDIAT POWER
