Sony Video Disk UnitNTSC/PAL
DSR-DU1
For
Professional
Results

i.LINK Connection
4-pin
4-pin
12x
3
CCD
DVCAM
DSR-PD150
DSR-PD100A
DSR-DU1
Video Disk Unit
with Supplied Case
Battery Pack
NP-F960/F750
AC-V700A
AC Adapter/Charger
i.LINK
Connection
(AV/C Protocol) i.LINK Connection
(AV/C Protocol)
4-pin
6-pin
DSR-2000
DSR-70A
Dubbing SystemNon-linear System
DSR-DU1
Video Disk Unit
PC
DSR-DU1
Video Disk Unit
DSR-DU1
Video Disk Unit
CA-DU1
Camera Adaptor
i.LINK Connection
(SBP2 Protocol)
i.LINK Connection
(SBP2 Protocol)
PC
DSR-DU1
Video Disk Unit
with Supplied Case
AC-V700A
AC Adaptor/Charger
AC-DN1
AC Adaptor
01 APPLICATION EXAMPLES
Application Examples
New levels of flexibility in the field and in production
The DSR-DU1 is also capable of interfacing with a variety of i.LINK(DV) interface
equipped Sony hand-held camcorders. With a single i.LINK cable connection, it is
possible to record the camera output in parallel with the recording being made on the
camcorder's tape. Since these camcorders only accommodate mini cassettes with
a maximum recording time of 40 minutes in DVCAM mode, the three-hour recording
time of the DSR-DU1 (equivalent to the maximum recording time of a standard size
DVCAM tape) can significantly expand the use of these compact, hand-held
camcorders in DVCAM-based productions.
Thanks to its VTR-like functions and the support of the AV/C protocol on its i.LINK
connector, the DSR-DU1 can be used as an independent source feeder. It can be
connected to i.LINK(DV) interface equipped compatible DVCAM recorder VTRs as a
feeder machine for making dubs. Establishing the same connection with an i.LINK
interface equipped nonlinear editor allows material on the DSR-DU1 to be uploaded
to the media drive of the editor.
The support of the SBP2 protocol on the i.LINK port of the DSR-DU1 allows
DVCAM/DV stream video and audio to be output as asynchronous files. Thus,
when connected to an SBP2-compatible, i.LINK interface equipped compatible
nonlinear editor, the files on the DSR-DU1 can be directly
transferred to the nonlinear editor's local media drive. A
maximum of twice normal transfer speed is achieved,
effectively reducing the time required for material ingestion.
Since the record start and stop time code values generated
during acquisition are stored in the DSR-DU1 and
transferred together with the material files, the burden of the
logging process common to nonlinear editing is reduced.
As a source feeder machine using the SBP2 protocol
As a source feeder machine using the AV/C protocol
In Acquisition: Longer recording and higher reliability with
i.LINK(DV) interface equipped handy camcorders
4-pin
6-pin
i.LINK Connection
DSR-570WS
DSR-370
DSR-250
DSR-DU1
Video Disk Unit
CA-DU1
Camera Adaptor BC-L50/M50
Battery Charger
Li-ion Battery
BP-L90A/L60A/L40A
Nickel Metal Hydride Battery
BP-M50/M100
The DSR-DU1 docks onto the rear of compatible camcorders by use of the
optional CA-DU1 Camera Adaptor. By connecting an i.LINK cable from the
camcorder to the camera adaptor, the camera output is recorded to the hard drive
of the DSR-DU1 in parallel with the recording on the camcorder's tape.
Additionally, the DSR-DU1 will continue to record during cassette changes,
preventing the loss of a vital scene. Since a slot-in mechanism interfaces the
DSR-DU1 to the CA-DU1 Camera Adapter, mounting and demounting the
DSR-DU1 is very quick and simple. This system provides the reliability required to
protect your important footage.
Compatible Sony camcorders are
the DSR-570WS/570WSP/370/370P/500WS/500WSP/300A/300AP/250/250P
In Acquisition: An innovative shooting style using
DVCAM shoulder-mount camcorders
The equipment in the figure above are labeled with NTSC model names.

02 Product Overview:
Loop recording
Allows video and audio signals to be buffered in an internal memory and
then recorded to the hard drive the instant the record button is pressed.
This function helps to avoid the loss of an important scene. Up to eight
seconds of video and audio are continuously buffered in the memory.
Interval recording
Allows interval recording by setting the DSR-DU1 to automatically switch
between record and standby modes. The maximum recording time is
two seconds at predetermined intervals. This allows recordings to be
made for scientific applications such as botanical observation.
525 (NTSC)/625 (PAL) switchable recording
The DSR-DU1 offers 525 (NTSC)/625 (PAL) switchable
operation, and can record and playback in either color system*1. This
function is switched from a menu.
REC Trigger
The REC On/Off function of the DSR-DU1 can be controlled from the
REC On/Off button of Sony i.LINK(DV) interface equipped compatible
DVCAM camcorders.*2
Supplied remote controller (RM-LG2)
Provides controls for Rec, Cue and Rec Tally
Can be powered by DC12 V*3or DC 8.4 V
Shooting data
During acquisition, the time codes of record in and out points are
automatically stored in the DSR-DU1. Cue points can also be marked
from the controls of the DSR-DU1 and the supplied remote controller.
Hard-drive unit for
DVCAM and DV camcorders
The DSR-DU1 incorporates a 2.5-inch, 40
GB hard drive. It can record a 25 Mb/s
DVCAM/DV stream video signal and audio
signals for up to three hours. These signals
are recorded as files.
Shock resistant
The shock resistant mechanical design and
the use of a memory to buffer data makes
the DSR-DU1 extremely durable and highly
reliable even when subjected to severe
vibration. Moreover, when the DSR-DU1 is
used with a compatible DVCAM shoulder-
mount camcorder, it is housed within the
aluminum die-cast body of the CA-DU1
Camera Adaptor for even greater protection.
Product Overview
Other Features
*1 The DSR-DU1 does not convert signals between 525 (NTSC) to 625 (PAL) video formats.
*2 To use this function with camcorders other than the DSR-570WS/570WSP/370/370P, a tape
should be loaded in the cassette compartment.
*3 An optional CA-DU1 is required for operation on DC 12 V.
VTR-like functions and operation keys
The DSR-DU1 provides controls for functions
such as Play, Stop, Next, Previous and
Recording. These controls enable the unit to be
used as an independent feeder or straight
recorder. An additional feature is that the
playback picture can be monitored* on the
viewfinder of a Sony DSR-570WS/570WSP/
370/370P camcorder, or the LCD screen of a
Sony DSR-PD150/PD150P or DSR-250/250P
camcorder.
*Not available with the DSR-500WS/500WSP/300A/300AP.
The DSR-PD150/PD150P/250/250P should be in VTR mode.
i.LINK Connector and Its protocol
The i.LINK connector of the DSR-DU1
supports two types of protocol - the AV/C
protocol and SBP2 protocol. The AV/C
protocol is used for the transfer of
DVCAM/DV stream signals such as those
used in conventional VTR to VTR dubbing.
This allows the DSR-DU1 to be connected
to Sony i.LINK(DV) interface equipped
compatible VTRs and nonlinear editors. The
SBP2 protocol further allows DVCAM/DV
stream signals to be transferred as files to
compatible i.LINK interface equipped,
compatible nonlinear systems.
Compact and lightweight
Excellent portability and mobility is achieved
with the low weight and compact body of the
DSR-DU1.
LCD MONITOR for indicating menu
JOG DIAL for searching menu
Photo shows DSR-DU1, CA-DU1 and BP-L60A.

CA-DU1 Camera Adaptor
General
Power requirements DC 11 to 17 V
Weight Approx. 14 oz (400 g)
Dimensions (W x H x D) 4 x 2 1/4x 5 3/4inches
(101 mm x 54.5 mm x 143mm)
Operating temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage temperature -4 °F to 140 °F (-20°C to 60 °C)
Operating Humidity Less than 85% (without condensation.)
Input/Output Terminals
DV IN/OUT i.LINK x 1 (IEEE1394 4-pin)
Remote 4-pin mini Jack x 1
DC IN XLR 4-pin male x 1
Supplied Accessories
Warranty card
Operation manual
i.LINK cable (4-pin to 6-pin)
DSR-570WS/570WSP
DVCAM Camcorder DSR-370/370P
DVCAM Camcorder DSR-250/250P
DVCAM Camcorder DSR-PD150/PD150P
DVCAM Camcorder DSR-PD100A/PD100AP
DVCAM Camcorder
03 PERIPHERAL EQUIPMENT AND OPTIONAL ACCESSORIES / SPECIFICATIONS
Peripheral Equipment and Optional Accessories
Camcorders
Optional Accessories
CA-DU1
Camera Adopter BP-L40A/L60A/L90A
Rechargeable Li-ion
Battery Pack
BP-M50/M100
Rechargeable Nickel Metal Hydride
Battery Pack
NP-F960/F750
infoLITHIUM Rechargeable
Battery Pack
BC-L50
Battery Charger for
BP-L40A/L60A/L90A
BC-M50
Battery Charger for
BP-L40A/L60A/L90A/M50/M100
AC-V700A
AC Adaptor/Charger for NP-F960 AC-DN1
AC Adaptor
Specifications
DSR-DU1 Video Disk Unit
General
Power requirements DC 7.2 V (Battery), DC 8.4 V (AC Adaptor)
Power consumption 8.5 W
Weight 1 lb 5 oz (600 g)
Dimensions (W x H x D) 4 x 1 3/4x 5 5/8inches
(101 mm x 44 mm x 142mm)
Operating temperature 32 °F to 104 °F (0 °C to 40 °C)
Storage temperature -4 °F to 140 °F (-20 °C to 60 °C)
Operating Humidity Less than 85% (without condensation.)
Input/Output Terminals
DV IN/OUT i.LINK x 1 (IEEE1394 4-pin)
Remote 4-pin mini Jack x 1
DC IN x 1
Supplied Accessories
Warranty card
Operation manual
i.LINK cable (4-pin to 4-pin)
Remote controller (RM-LG2)
Battery (CR2032)
Case
VMC-IL4408A/IL4415/IL4435
i.LINK Cable
(4-pin to 4-pin, 0.8m/1.5m/3.5m)
VMC-IL4615A/IL4635
i.LINK Cable
(4-pin to 6-pin, 1.5m/3.5m)

04 INTRODUCTION
Expanding DVCAMTM production
The DSR-DU1 is a compact videodisk unit that is set to bring a new level of operational versatility to DVCAM
production. Introduced for use with Sony DVCAM and Sony DV camcorders*1, it provides up to three hours
of DVCAM/DV stream recording – equivalent to the maximum recording time of a DVCAM tape. Through an
i.LINK®*2(DV) connection, the output of the camcorder's camera is simultaneously recorded to both the hard
drive of the DSR-DU1 and the camcorder's tape cassette.
The DSR-DU1 is an extremely versatile unit. When a shoot has been completed, it can be detached from
the camcorder and used for field off-line logging or EDL creation, as a player for making dubs, or as a source
feeder machine for i.LINK interface equipped nonlinear editors. The DSR-DU1 also offers many other
convenient features that include loop recording to avoid missing an important scene, and interval recording
to capture scenes over a long period.
The i.LINK IEEE 1394 interface on the DSR-DU1 supports two types of protocols which are AV/C (Audio
Video/Control) and SBP2. The DSR-DU1 receives and stores the DVCAM/DV stream from compatible
DV/DVCAM camcorders using the AV/C protocol. The DSR-DU1 can then upload the DV files into
compatible i.LINK interface equipped nonlinear editors*3using either the SBP2 or AV/C protocol. In the case
of the SBP2 protocol, the DV files stored on the DSR-DU1 can be selected on a file basis from the GUI of
the compatible nonlinear editor, and then uploaded to the editor's hard drive at up to two times faster*4than
real time. The record start and stop time code values of each scene are also transferred to the editor,
eliminating the logging process common to nonlinear editing.
The DSR-DU1 presents an outstanding workflow innovation to DVCAM users in field acquisition and in
production.
SONY Video Disk Unit
DSR-DU1
*1 Please contact your nearest Sony office or authorized dealer for compatible DV camcorders
*2 i.LINK is a Sony trademark used only to designate that a product is equipped with an IEEE 1394 connector.
All products with an i.LINK connector may not communicate with each other. Please refer to the documentation that comes with any device having
an i.LINK connector for information on compatibility, operating conditions, and proper connection. is the logo for products that implement i.LINK.
*3 Please contact your nearest Sony office or authorized dealer for compatible nonlinear products that support AV/C or SBP2 file upload from the
DSR-DU1
*4 The time required to upload DV files from the DSR-DU1 may vary depending on the nonlinear editor used.In the case of downloading DV files from
a nonlinear editor to the DSR-DU1, only the DV AV/C protocol can be used and therefore only real-time speed is supported.
Photo shows DSR-DU1 and supplied case.

© 2002 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Design, features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony, DVCAM and i.LINK are trademarks of Sony Corporation.
MK7817V1TC02MAR
V-2137 Printed in USA (5/02)
Sony Electronics Inc.
One Sony Drive
Park Ridge, NJ 07656
www.sony.com/professional
Other manuals for DSR-DU1
2
Table of contents
Other Sony Camera Accessories manuals

Sony
Sony Alpha SH-L1AM User manual

Sony
Sony TransferJet Station TJS-1 User manual

Sony
Sony XCD-V50CR User manual

Sony
Sony GP-AVT1 Parts list manual

Sony
Sony Cyber-shot Sports Pack SPK-SA User manual

Sony
Sony XC-ES50 User manual

Sony
Sony UNI-ONL7C2 User manual

Sony
Sony MPK-TR User manual

Sony
Sony HVR-MRC1 User manual

Sony
Sony VF-R25NK User manual

Sony
Sony SMAD-P5 User manual

Sony
Sony HVL-20DW2 User manual

Sony
Sony NP-F330 Operating Instructions (primary... Service manual

Sony
Sony CBK-MB01 User manual

Sony
Sony SPK-WA User manual

Sony
Sony VCT-CGR1 User manual

Sony
Sony MPK-WE User manual

Sony
Sony HKC-T1500 User manual

Sony
Sony BVF-20W User manual

Sony
Sony CCU-D50P User manual
