HD Camera Adaptor
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
XDCA-53

2
To reduce the risk of fire or
electric shock, do not expose
this apparatus to rain or
moisture.
To avoid electrical shock, do
not open the cabinet. Refer
servicing to qualified
personnel only.
Important Safety Instructions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
• Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding-type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the
provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
• Only use attachments/accessories
specified by the manufacturer.
• Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
• Unplug this apparatus during lightning
storms or when unused for long periods
of time.
• Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
IMPORTANT
The nameplate is located on the bottom.
WARNING
Excessive sound pressure from a headset
can cause hearing loss.
In order to use this product safely, avoid
prolonged listening at excessive sound
pressure levels.
For the customers in the U.S.A.
This equipment has been tested and found
to comply with the limits for a Class A
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential
area is likely to cause harmful interference
in which case the user will be required to
correct the interference at his own expense.
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
WARNING

3
All interface cables used to connect
peripherals must be shielded in order to
comply with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC
Rules.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.
For the customers in Canada
This Class A digital apparatus complies
with Canadian ICES-003.
For the customers in Europe
This product with the CE marking complies
with the EMC Directive issued by the
Commission of the European Community.
Compliance with this directive implies
conformity to the following European
standards:
• EN55103-1: Electromagnetic
Interference (Emission)
• EN55103-2: Electromagnetic
Susceptibility (Immunity)
This product is intended for use in the
following Electromagnetic Environments:
E1 (residential), E2 (commercial and light
industrial), E3 (urban outdoors), E4
(controlled EMC environment, ex. TV
studio).
The manufacturer of this product is Sony
Corporation, 1-7-1 Konan, Minato-ku,
Tokyo, Japan.
The Authorized Representative for EMC
and product safety is Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Germany. For any service or
guarantee matters please refer to the
addresses given in separate service or
guarantee documents.
Afin de réduire les risques
d’incendie ou d’électrocution,
ne pas exposer cet appareil à
la pluie ou à l’humidité.
Afin d’écarter tout risque
d’électrocution, garder le
coffret fermé. Ne confier
l’entretien de l’appareil qu’à
un personnel qualifié.
IMPORTANT
La plaque signalétique se situe sous
l’appareil.
AVERTISSEMENT
Une pression acoustique excessive en
provenance du casque peut provoquer une
baisse de l’acuité auditive.
Pour utiliser ce produit en toute sécurité,
évitez l’écoute prolongée à des pressions
sonores excessives.
Pour les clients au Canada
Cet appareil numérique de la classe A est
conforme à la norme NMB-003 du Canada.
Pour les clients en Europe
Ce produit portant la marque CE est
conforme à la Directive sur la compatibilité
électromagnétique (EMC) émise par la
Commission de la Communauté
européenne.
La conformité à cette directive implique la
conformité aux normes européennes
suivantes :
• EN55103-1 : Interférences
électromagnétiques (émission)
• EN55103-2 : Sensibilité
électromagnétique (immunité)
Ce produit est prévu pour être utilisé dans
les environnements électromagnétiques
suivants : E1 (résidentiel), E2 (commercial
et industrie légère), E3 (urbain extérieur) et
AVERTISSEMENT

4
E4 (environnement EMC contrôlé, ex.
studio de télévision).
Le fabricant de ce produit est Sony
Corporation, 1-7-1 Konan, Minato-ku,
Tokyo, Japon.
Le représentant autorisé pour EMC et la
sécurité des produits est Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Allemagne. Pour toute question
concernant le service ou la garantie,
veuillez consulter les adresses indiquées
dans les documents de service ou de
garantie séparés.
Um die Gefahr von Bränden
oder elektrischen Schlägenzu
verringern, darf dieses Gerät
nicht Regen oder Feuchtigkeit
ausgesetzt werden.
Um einen elektrischen Schlag
zu vermeiden, darf das
Gehäuse nicht geöffnet
werden. Überlassen Sie
Wartungsarbeiten stets nur
qualifiziertem Fachpersonal.
WICHTIG
Das Namensschild befindet sich auf der
Unterseite des Gerätes.
WARNUNG
Zu hoher Schalldruck von Headset kann
Gehörschäden verursachen.
Um dieses Produkt sicher zu verwenden,
vermeiden Sie längeres Hören bei sehr
hohen Schalldruckpegeln.
Für Kunden in Europa
Dieses Produkt besitzt die CE-
Kennzeichnung und erfüllt die EMV-
Richtlinie der EG-Kommission.
Angewandte Normen:
• EN55103-1: Elektromagnetische
Verträglichkeit (Störaussendung)
• EN55103-2: Elektromagnetische
Verträglichkeit (Störfestigkeit)
Für die folgenden elektromagnetischen
Umgebungen: E1 (Wohnbereich), E2
(kommerzieller und in beschränktem Maße
industrieller Bereich), E3 (Stadtbereich im
Freien) und E4 (kontrollierter EMV-
Bereich, z.B. Fernsehstudio).
Der Hersteller dieses Produkts ist Sony
Corporation, 1-7-1 Konan, Minato-ku,
Tokyo, Japan.
Der autorisierte Repräsentant für EMV und
Produktsicherheit ist Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Deutschland. Bei jeglichen
Angelegenheiten in Bezug auf
Kundendienst oder Garantie wenden Sie
sich bitte an die in den separaten
Kundendienst- oder Garantiedokumenten
aufgeführten Anschriften.
WARNUNG

5
Table of Contents
Table of Contents
Overview ..................................................................................6
Features ...................................................................................6
Using the CD-ROM ................................................................7
Reading the CD-ROM Manuals ..........................................7
Names and Functions of Parts ............................................... 8
System Configuration........................................................... 12
Mounting on the Camcorder Support ................................12
Important Notes on Operation ............................................16
Specifications .........................................................................17
General ..............................................................................17
Connectors ........................................................................17
Supplied Accessories ........................................................17
Accessories Not Supplied .................................................18

6Overview / Features
Overview
The XDCA-53 HD Camera Adaptor
(referred to as “the adaptor” hereafter)
allows you to connect an XDCU-50 HD
Camera Extension Unit to supply power to
the camcorder and extend the distance over
which camcorder input and output signals
can be transmitted (maximum distance
100 m (328 feet)).
Can be installed on the following
camcorder
PMW-EX3
For details, refer to the XDCU-50 Operating
Instructions for information about how to set up a
system consisting of this adaptor, a camcorder, and
the XDCU-50, and for precautions about use of the
system.
Features
HD digital transmission
This adaptor supports bidirectional
transmission of uncompressed HD digital
signals between this adaptor and XDCU-
50.
The maximum transmission distance is
100 m (328 feet).
You can transmit high-quality video signals
regardless of cable length.
Monitor output connector
Either main line video signals from the
camcorder or return video signals from the
XDCU-50 can be output as HDSDI signals.
Return video selection button
You can switch the monitor output to return
video while the adaptor’s RET button is
held down.
Communication interfaces
• Intercom (1 line)
• Tally (red and green)
• Trunk line (1 line)

7
Using the CD-ROM
Using the
CD-ROM
The supplied CD-ROM contains PDF-
format Operating Instructions manuals (in
English, Japanese, French, German, Italian,
Spanish, and Chinese) for this adaptor, a
HD Camera Adaptor XDCA-55 and a HD
Camera Extension Unit XDCU-50.
Reading the CD-ROM
Manuals
Preparations
The following program must be installed on
your computer in order to read the
documents contained on the CD-ROM.
Adobe Reader Version 6.0 or higher
If Adobe Reader is not installed, you can
download it from the following URL:
http://www.adobe.com/
Adobe and Adobe Reader are trademarks of
Adobe Systems Incorporated in the United States
and/or other countries.
To read the documents
Do the following:
1Insert the CD-ROM in your CD-ROM
drive.
A cover page appears automatically in
your browser.
If it does not appear automatically in
the browser, double-click on the
index.htm file on the CD-ROM.
2Select and click on the manual that you
wish to read.
This opens the PDF file.
The files may not be displayed properly,
depending on the version of Adobe Reader.
In such a case, install the latest version you
can download from the URL mentioned in
“Preparations” above.
If you have lost or damaged the CD-ROM,
you can purchase a new one to replace it.
Contact a Sony service representative.
Memo
Memo
Note

8Names and Functions of Parts
Names and Functions of Parts
1TALLY switch
qjTALLY lamp (red)
wgCamera adaptor mounting screw holes
qkDC OUT 12V(2A)
connector
qhTALLY lamp (green)
qgINTERCOM MIC switch
qdAUX connector
qaPOWER indicator
q;POWER switch
2MONI. SEL switch
3CALL button
4RET button
5CEU connector
6CEU OUT
connector
7CEU IN connector
8MONI.OUT(SDI)
connector
9DC OUT 12V 1A
connector
qlREMOTE
connector
wsSDI IN connector
w;GENLOCK OUT
connector
waMONITOR OUT
connector
wfAccessory screw holes
qfINTERCOM
LEVEL knob
wdAccessory screw
holes
qsINTERCOM
connector

9
Names and Functions of Parts
aTALLY switch
Enables (on) or disables (off) the TALLY
lamps (red and green).
However, tally signals assigned to pins 14
and 15 of the AUX connector are not
affected by the setting of this switch.
ON: Lights the TALLY lamps (red and
green) according to tally signals and
the state of the CALL button.
OFF: Does not light the TALLY lamps (red
and green).
bMONI. SEL (monitor select) switch
Selects the output from the
MONI.OUT(SDI) connector or MONITOR
OUT connector.
RET: Always outputs return video signals.
CAM/RET: Outputs return video as long
as the RET button is pressed, and
outputs camcorder video signals when
the RET button is not pressed.
cCALL button
Calls the operator of an XDCU-50. When
pressed, the CALL lamp on the XDCU-50
lights. The CALL and TALLY lamps on
this uni, the camcorder, and the remote
control unit do not light.
Control over tally lamps varies depending
on the devices used in the system
(camcorder, XDCU-50, remote control
unit).
For details, refer to the instruction manuals of the
other devices.
dRET (return) button
When the MONI. SEL switch is set to
CAM/RET, you can also switch the video
signal from the MONI. OUT (SDI)
connector or MONITOR OUT connector to
return video.
eCEU (camera extension unit)
connector (26-pin)
Connect to the CA connector (26-pin) of the
XDCU-50 with the optional CCZ-A cable.
Power is supplied from the XDCU-50.
fCEU OUT (camera extension unit
output) connector
Connect to the CA IN connector of the
XDCU-50 with a BNC cable (5C-FB).
gCEU IN (camera extension unit
input) connector
Connect to the CA OUT connector of the
XDCU-50 with a BNC cable (5C-FB).
hMONI.OUT (monitor output) (SDI)
connector
Outputs HD SDI signals, either return video
signals from the XDCU-50 shooting and
output camcorder video signals from the
camcorder.
iDC OUT 12V 1A connector (XLR 4-
pin)
Supplies +12 V power to a monitor or other
external device.
The pin assignments are as follows.
jPOWER switch
Powers the unit on when pressed to the “"”
side, and powers the unit off when pressed
to the “1” side.
Note
Pin No. Signal name
1GND
2 Not used
3 Not used
4+12V

10 Names and Functions of Parts
DC power output from the adaptor is also
turned on and off by this switch.
kPOWER indicator
Lights in green when the adaptor is
powered on.
lINTERCOM connector (XLR 5-pin)
Allows you to connect an XLR 5-pin type
headset. Dynamic microphones are
supported.
The pin assignments are as follows.
Contact your dealer or a Sony service representative
for information about how to adjust the side tone
level.
mAUX connector (15-pin)
Connect to an external system to input and
output tally signals, trunk line signals, and
timecode.
Provides a trunk line connection to the
trunk line of the camera adaptor via a RS-
232C interface, for use as a
communications line with external devices.
Also equipped with general-purpose lines
between this camcorder and the XDCU-50.
The pin assignments are as follows.
Pin No. Signal name
1 INCOM MIC GND
2 INCOM MIC IN
3 INCOM RECEIVE
GND
4 INCOM RECEIVE
OUT
5 Not used
Pin
No.
Signal name Description
2 TC (X) OUT Timecode signal
output
7TC(G)OUT
3 TRUNK RX Trunk line (RS-
232C)
13 TRUNK TX
8 TRUNK (G)
4 RET CONT IN Return control
external input
On: GND
Off: Open
9 MIC CONT IN Intercom
microphone
control input
On: GND
Off: Open
5 GND Ground
10 TALLY GND TALLY output
14 R TALLY OUT Red tally output
(open collector)
15 G TALLY OUT Green tally
output (open
collector)
1 AUX VIDEO (X) General-
purpose analog
video line
between this
adaptor and
XDCU-50
6 AUX VIDEO (G)
11 AUX1 General-
purpose line 1
between this
adaptor and
XDCU-50
12 AUX2 General-
purpose line 2
between this
adaptor and
XDCU-50

11
Names and Functions of Parts
nINTERCOM LEVEL knob
Adjusts the receiving volume level of the
headset connected to the INTERCOM
connector.
oINTERCOM MIC switch
Controls the headset microphone connected
to the INTERCOM connector, turning it on
or off as required.
ON: Turns the headset microphone on.
OFF: Turns the headset microphone off.
PTT: Turns the headset microphone on for
as long as the switch is held in this
position.
pTALLY lamp (green)
When the TALLY switch is on, lights in
green when a green tally signal is input to
an XDCU-50 connected to the adaptor.
qTALLY lamp (red)
When the TALLY switch is on, lights in red
when a red tally signal is input to an
XDCU-50 connected to the adaptor, and
when a call signal is received, for example
because a CALL button was pressed on
another device.
This lamp does not light when the adaptor’s
CALL button is pressed. It does not light
either when the CALL button on the remote
control unit or other device is pressed.
rDC OUT 12V(2A) connector (4-pin
round)
Connect to the DC IN connector of the
camcorder with the supplied power cable.
sREMOTE connector (8-pin)
Connect to the REMOTE connector of the
camcorder with the supplied REMOTE
cable.
tGENLOCK OUT connector
Connect to the GENLOCK IN connector of
the camcorder with the supplied BNC
cable. Reference sync signals output from
the XDCU-50 are sent as SD black burst
signals to the camcorder via this connector.
uMONITOR OUT connector
Outputs SD analog composite video
signals, either return video signals from
XDCU-50 or the camcorder video signals.
vSDI IN connector
Connect to the SDI OUT connector of the
camcorder with the supplied BNC cable.
SDI signals output from the camcorder are
input to this connector.
wAccessory screw holes
These are accessory screw holes (4) for M4
screws to secure an HD monitor.
xAccessory screw holes
These are a screw hole for an U1/4-20
screw to secure an accessory, and eight
screw holes to secure the accessory kit.
yCamera adaptor mounting screw
holes
These are screws holes for M4 screws,
allowing you to secure the adaptor to the
optional VCT-SP2BP Camcorder Support.
Note

12 System Configuration
System Configuration
The following figure shows the
configuration of a system that includes this
adaptor.
Refer to the XDCU-50 Operating Instructions for
details about how to use the adaptor when it is
connected to the XDCU-50.
Do not connect or disconnect the cables
connecting this adaptor and XDCU-50
(CCZ-A and BNC cables) while the system
is powered on. The excessive current
protection function may be activated,
cutting off power to the power circuits of
this adaptor or the XDCU-50.
If the power should be cut off, connect the
cables again in the proper fashion and wait
for a while before starting the system again.
Mounting on the
Camcorder Support
Proceed as follows to mount the adaptor
and the camcorder on the optional VCT-
SP2BP Camera Support, and to connect the
adaptor to the camcorder.
Always power the camcorder off before
mounting it on the VCT-SP2BP.
1Remove the shoulder pad of the
camcorder.
Refer to the Operating Instructions manual of
the camcorder for information about how to
remove the shoulder pad.
2Place the adaptor on a flat surface, as
shown in the figure, align the supplied
bracket with the camera adaptor
mounting screw holes (4), and screw it
down securely.
XDCU-50
Camcorder
(mounted on the
optional VCT-SP2BP
camcorder support)
This
adaptor
a) Supplied BNC cable
b) Supplied REMOTE cable
c) Supplied power cable
d) CCZ-A cable
e) BNC cable
Note Note

13
System Configuration
3Peel off the covers from the double-
sided tapes on the rear side of the
supplied plate, and attach the plate to
the VCT-SP2BP.
4Place the camcorder on a flat surface
with the bottom panel facing up, and
insert the spacer into the tripod screw
holes.
5Place the VCT-SP2BP on the bottom
panel of the camcorder, with the rear
side facing up. Secure the VCT-SP2BP
by tightening screws into the tripod
screw holes of the camcorder.
The VCT-SP2BP cannot be attached if
your camcorder has only one tripod
screw hole.
For details, contact your dealer or a Sony
service representative.
Bracket
Plate
Double-sided tapes
VCT-SP2BP
Tripod screw holes
Spacer
Tripod screw holes
VCT-SP2BP
Camcorder

14 System Configuration
6Insert the bottom part of the bracket
that you attached to the adaptor in step
2into the groove on the camcorder
support (1), as shown by arrow in the
figure. Then slide the adaptor to mount
it on the camcorder support, and secure
the bracket with two screws (2).
7Connect the adaptor to the camcorder
with the supplied cables.

15
System Configuration
The following table shows the
connector pairs to connect.
See “Names and Functions of Parts” (page 8)
for details about the functions of each
connector.
DC IN connector
DC OUT 12V(2A) connector
REMOTE connector
GENLOCK IN connector
SDI OUT connector
SDI IN connector
GENLOCK OUT connector
REMOTE connector
Adaptor
connector
Camcorder
connector
SDI IN SDI OUT
DC OUT 12V(2A) DC IN
REMOTE REMOTE
GENLOCK OUT GENLOCK IN

16 Important Notes on Operation
Important Notes
on Operation
Use and storage locations
Store in a level, ventilated place. Avoid
using or storing the adaptor in the following
places.
• In excessive heat or cold (operating
temperature range: 0°C to 40°C (32°F to
104°F))
• Remember that in summer in warm
climates the temperature inside a car with
the windows closed can easily exceed
50°C (122°F).
• In damp or dusty locations
• Locations where the adaptor may be
exposed to rain
• Locations subject to violent vibration
• Near strong magnetic fields
• Close to radio or TV transmitters
producing strong electromagnetic fields.
• In direct sunlight or close to heaters for
extended periods
Do not subject to strong shocks
Do not drop the adaptor or subject it to
strong shocks. The adaptor may be
damaged.
Do not wrap in a cloth or other
covering during operation
Internal temperatures may rise, causing
malfunctions.
Maintenance
Clean the cabinet and panels by wiping
lightly with a soft, dry cloth. If they are very
dirty, use a cloth dampened with a small
amount of neutral detergent, then wipe dry.
Avoid the use of volatile solvents such as
thinners, alcohol, benzene, and insecticides.
They may damage the surface finish or
cause it to peel off.
Transport
When transporting the adaptor by truck,
ship, or air, or whenever it may be handled
as freight, always pack it in the original
protective packaging, after removing the
camcorder, adaptor, and cables from the
camcorder support.
Transfer
Avoid transferring the PMW-EX3
camcorder and the adaptor as mounted on
the camcorder support. Before transfer,
dismount the camcorder from the
camcorder support. Otherwise the adaptor
may fall off the camcorder support during
transfer, causing injury.

17
Specifications
Specifications
General
Power requirements
13V DC
Power consumption
Approx. 7 W
• Connect only a device with a power
consumption current of 1 A or less to
the DC OUT connector.
• Connect only a camcorder with a
power consumption current of 2 A
or less (including external
connection) to the DC OUT
connector (4-pin round).
Operating temperature
0°C to +40°C (23°F to 104°F)
Operating humidity
20% to 90%
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions
Mass Approx. 1.0kg (2 lb 35 oz)
Connectors
Camera extension input/output
connectors
CEU IN/OUT
BNC type (one each), 0.8Vp-p,
75Ω
CEU Round 26-pin, female
Camcorder input/output
connectors
SDI IN
BNC type, 0.8Vp-p, 75Ω
DC OUT(2A)
4-pin round, female
GENLOCK OUT
BNC type, black burst, 75Ω
REMOTE
8-pin round, female
Output connectors
MONI.OUT(SDI)
BNC type, 0.8Vp-p, 75Ω
MONITOR OUT
BNC type, 1.0 Vp-p, 75Ω
Other connectors
INTERCOM
XLR 5-pin, female
AUX D-Sub 15-pin, female
DC OUT 1A
XLR 4-pin, female
DC 12 V, max. rated power 1 A
Supplied Accessories
Operating Instructions
Japanese (1)
English (1)
CD-ROM (1)
Camcorder connection cables
BNC cables (2)
REMOTE cable (1)
DC Power cable (1)
Camcorder support attachment
CA bracket (1)
CA bracket screws (6)
Notes
(unit: mm (inches))

18 Specifications
Plate (1)
Spacer (1)
Cable clamp belt (1)
Belt bracket (1)
Belt bracket fixing screws (2)
Accessories Not Supplied
VCT-SP2BP Camcorder support
Design and specifications are subject to
change without notice.
Note
Always verify that the unit is operating
properly before use. SONY WILL NOT
BE LIABLE FOR DAMAGES OF ANY
KIND INCLUDING, BUT NOT
LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF
THE LOSS OF PRESENT OR
PROSPECTIVE PROFITS DUE TO
FAILURE OF THIS UNIT, EITHER
DURING THE WARRANTY PERIOD
OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER
REASON WHATSOEVER.

Printed in China
