Sony MV7101DS - Mobile DVD Dream System User manual

© 2003 Sony Corporation
US
MV-7101DS
For installation and connections, see the supplied installation/connections manual.
Owner’s Record
The model and serial numbers are located on the bottom of the unit.
Record these numbers in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. MV-7101DS Serial No.
3-255-990-11 (1)
Operating Instructions
Mobile Video
System

2
DANGER INVISIBLE
AVOID DIRECT EXPOSURE TO BEAM.
LASER RADIATION WHEN OPEN.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
CAUTION
Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
This is located on the drive unit's internal
chassis.
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
This symbol is intended to
alert the user to the presence of
uninsulated “dangerous
voltage” within the product’s
enclosure that may be of
sufficient magnitude to
constitute a risk of electric
shock to persons.
This symbol is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
Warning

3
Table of Contents
Welcome ! .............................................................. 4
Precautions ............................................................ 4
About this manual ............................................... 5
Quick Review
Playing a DVD ...................................................... 6
Location of controls ............................................. 8
Operation for Monitor
Opening the display monitor ........................... 12
Selecting the input source ................................. 13
Changing the display settings .......................... 14
Adjusting the volume ........................................ 16
Use of Headphones
Listening with the headphones ........................ 17
Various Playback
Playing a disc ...................................................... 18
Searching a chapter/title/track directly .......... 18
Resume playback .................................................18
Turning off the player and the monitor ............19
MP3 file playback with the menu display .......19
Displaying running time ................................... 20
Changing the subtitle language ....................... 21
Using a DVD menu ............................................ 21
Using the TOP MENU button ............................21
Using the MENU button .....................................22
Changing the audio language .......................... 22
Changing angles ................................................. 23
Changing the audio output .............................. 23
Using the PBC (playback control) function .... 24
Changing Setup
Changing the aspect ratio of screen
— TV DISPLAY ............................................. 25
Displaying the multi-angle notice
— ANGLE MARK ........................................ 26
Displaying captions for viewers with hearing
difficulties
— CAPTIONS ............................................... 26
Setting the screen saver
— SCR SAVER ............................................... 27
Selecting the speaker mode
— SPEAKER SETUP..................................... 27
Selecting the audio output mode
— AUDIO OUT ............................................. 28
Selecting the compression setting for the sound
— DYNAMIC ................................................ 28
Selecting the TV color system
— COLOR SYSTEM ..................................... 29
Selecting the audio language for DVD
— AUDIO ...................................................... 29
Displaying the subtitles for DVD
— SUBTITLE ................................................. 30
Selecting the DVD menu language
— DISC MENU ............................................. 30
Preparing for the initial parental setting ........ 31
Setting the password ........................................... 31
Selecting the desired parental setting
— PARENTAL ................................................31
Changing your password
— PASSWORD ............................................... 32
Returning this player to the factory setting
— DEFAULTS ................................................ 33
Setting the menu display for MP3 files
— SMART NAV ............................................ 33
Additional Information
Maintenance........................................................ 34
About discs the player can play ....................... 36
Notes on discs ..................................................... 38
About MP3 files .................................................. 39
Specifications ...................................................... 40
Troubleshooting.................................................. 42
Error display ....................................................... 45
Language Code List ........................................... 46

4
Precautions
To avoid the risk of serious injury or accident,
read the following precautions before
installing and operating the player and the
monitor.
For driver's safety
Comply with your local traffic rules and
regulations.
•While driving
— The driver must not watch or operate the
monitor and the player. It may lead to
distraction and cause an accident.
— The driver must not use the headphones.
It may lead to distraction and cause an
accident.
Park the car in a safe place when the
driver watch and operate the monitor, or
use headphones.
•After installing
— Do not hang onto the monitor.
— Do not insert your hands, fingers or
foreign objects into the products. It may
cause injury or damage to the products.
— Take care not to bump your head against
the monitor when getting up from the
back seat.
— Take extra care not to wind the wire of the
headphones around your neck avoiding
injury or suffocation in the event of a
sudden movement of the vehicle.
— Keep small articles out of the reach of
children.
•If the monitor and the player do not work,
check the connections first. If everything is in
order, check the fuse.
•If your car was parked in direct sunlight,
allow the products to cool off before
operating them.
•Avoid installing the products in places:
— subject to temperature below – 30 °C (– 22
°F) or above 65 °C (113 °F)
— subject to direct sunlight
— near heat sources (such as heaters)
— exposed to rain or moisture
— exposed to excessive dust or dirt
— subject to excessive vibration
— subject to heat:
Keep all products away from nearby hot
vehicle components that heat up over
time such as hoses, high current wires,
and braking systems components. Make
sure to leave enough room for ventilation
on openings and slots to protect from over
heating.
If you have any questions or problems
concerning the products, please consult your
nearest Sony dealer.
Thank you for purchasing this Sony Mobile
Video System. Before operating the system,
please read this operating instructions
thoroughly and retain it for future reference.
Copyrights
This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents, other intellectual
property rights owned by Macrovision
Corporation, and other rights owners. Use of
this copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic”, and the
double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works.
Copyright 1998-1999 Dolby Laboratories. All
rights reserved.
“DTS,” “DTS Digital Surround” and “DTS
Digital Out” are trademarks of Digital Theater
Systems, Inc.
Welcome !

5
About this manual
Conventions
•Instructions in this manual describe how to
use the player, the monitor, and the cordless
stereo headphone.
•The icons below are used in this manual:
Icon Meaning
Indicates a DVD function.
Indicates a Video CD function.
Indicates an Audio CD function.
Indicates the function of a CD
containing MP3 file.
Moisture condensation
On a rainy day or in a very damp area,
moisture condensation may occur inside the
lenses. Should this occur, the player will not
operate properly. In such a case, remove the
disc and wait for about an hour until the
moisture has evaporated.
To maintain high sound quality
Be careful not to splash juice or other soft
drinks onto the products or discs.

6
Quick Review
You can play a DVD and other discs just after
reading Quick Review.
Playing a DVD
1Press (OPEN) to open the display
monitor.
2Press (POWER) to turn on the monitor.
The monitor turns on.
Tips
•The player turns on/off in conjunction with
the monitor. To turn off just the player,
press (POWER) on the remote commander or
on the player until the green light of the
POWER button on the player is turned off.
•If the player does not turn on in conjunction
with the monitor, press (POWER) on the
remote commander or on the player until the
green light of the POWER button on the
player lights up.
3Press (INPUT) on the monitor repeatedly
to select “VIDEO 4.”
Each time you press (INPUT), the indication
changes in the following sequence:
VIDEO 1*cVIDEO 2*cVIDEO 3*c
VIDEO 4 cVIDEO 1*
*When connecting optional products, be sure
to select the proper input mode. For details,
refer to the connection diagram in the
supplied installation/connection manual.
4Open the front panel of the player.
5Insert the disc (labeled side up or the
surface you want to play down if the
disc is a DVD) into the player.
If a disc is already inserted, press uto start
playback.
Note
Even when the player is turned off, you can eject a
disc from the player, though you cannot insert a
disc.
Tip
Steps 3 to 5 are necessary only when you use this
system for the first time.
POWER
OPEN
INPUT

7
Operation for playback
To Do this
Stop playback Press x*1
Eject the disc Open the front panel,
then press Z on the
unit.
Pause Press u*2
Resume playback Press u
after pause
Go to the next chapter, Press >
track, or scene in
continuous play mode
Go back to the preceding Press .
chapter, track, or scene in
continuous play mode
Fast forward Press M/ywhile
playing*3 *4
Fast reverse Press /mwhile
playing*3 *4
Slow forward Press M/yin
(DVD/Video CD only) pause*4
Slow reverse Press /min
(DVD only) pause
*1If the resume playback function is activated, you
can resume playback later by pressing u. For
details, see “Resuming playback.”
*2DVD/Video CD
Both the picture and sound stop during pause
and “PAUSE” is displayed on the screen.
Audio CD
The sound stops and “PAUSE” is displayed on
the screen.
*3DVD/Video CD/Audio CD
Playback increases to 4 times the speed with
no sound.
*4A disc other than a DVD returns to normal
playback when a track/MP3 file finishes.
Notes
•Depending on the recording method used on the
disc, it may take a minute or more before
playing.
•Depending on the condition of the disc, it may
not play back (page 38).
• If you play a high-bit rate MP3 file such as 320
kbps, sound may be intermittent.
Returning the display monitor to its
enclosure
Close the display monitor until it clicks. The
monitor turns off automatically.
Notes
•Be careful not to catch your finger in the display
monitor when closing.
•Do not put any foreign objects between the LCD
panel and the enclosure when closing.
Adjusting the tilt and swivel
The display monitor can be adjusted within the
angles shown.
Tip
Before closing the display monitor, make sure that
the monitor is turned and facing the enclosure
(you will hear a click).
30˚
180˚
120˚
ENTER
SEARCH
POWER DISPLAY
CLEAR
SETUP
AUDIO
ANGLE
SUBTITLE
MENU
TOP MENU
INPUT MONITOR
POWER
123
456
7890
VOL
./>
u
x
/y
m/M

8
Location of controls
1OPEN button 6, 12
To open the monitor.
2Receptor for the card remote
commander/Transmitter for the
cordless headphones
3UP/DOWN (M/m) buttons 13, 14, 15
To select the desired item.
4MENU button 14
To adjust the various display settings.
Monitor XVM-R70
*The reverse position of the display monitor.
You can close with the LCD surface out after turning around 180 degrees, and images on the screen
can be turned upside down by pressing (REVERSE) on the monitor. Before closing the display
monitor, make sure that the monitor is turned and facing the enclosure (you will hear a click). Each
time you press (REVERSE) on the monitor, the reverse screen mode switches between on and off.
5REVERSE button*
To switch images upside down.
6INPUT button 6, 13
To select the input source.
7POWER button 6, 12, 13
To turn on/off the player and the
monitor.
REVERSE
180˚
c c
Warning when installing in a
car without an ACC
(accessory) position on the
ignition key switch
To turn off the player and the
monitor, after you set the power
select switch to B(the setting
without ACC position) for your
car (for details, refer to the installation/
connections manual)
There are 3 ways to turn off the
player and the monitor:
— After turning off the ignition, be
sure to press (POWER) on the
monitor.
— After turning off the ignition,
(MONITOR POWER) on the card
remote commander.
— After turning off the ignition, just
close the display panel until it
clicks.
Otherwise, the player and the
monitor do not turn off and this
causes battery drain.

9
Card remote commander RM-X135
ENTER
SEARCH
POWER DISPLAY
CLEAR
SETUP
AUDIO
ANGLE
SUBTITLE
MENU
TOP MENU
INPUT MONITOR POWER
123
456
7890
VOL
continue to next page t
Refer to the pages listed for details.
1DISPLAY button 20
To display a running time.
2Number buttons 18, 24
3TOP MENU button 21, 24
To display the top menu of a recorded
DVD or to turn on/off the PBC (Playback
control) menu of a Video CD.
4MENU button 21, 22
To display the recorded DVD menu.
5O(return) button 24
6./>(previous/next) buttons
7/m (fast/slow reverse)/
M/y(fast/slow forward) buttons
8M/,/m/<buttons
9POWER (on/off) button 10
To turn on/off the player. For details, refer
to the POWER (on/off) button (1) on the
player (page 10)
q; SEARCH button 18
To specify a desired point on a disc by
chapter, title, or track.
qa CLEAR button
qs SUBTITLE button 21
To change the subtitle language while
playing a DVD
qd ENTER button
To enter a setting.
qf ANGLE button 23
To select the multiple angles of view while
playing or pausing a DVD.
qg AUDIO button 22, 23
To change the audio output/audio
language
qh SETUP buttons 25
To enter or quit the setup menu.
qj u (play/pause) button
qk x (stop) button
ql MONITOR POWER (on/off) button*
To turn on/off the player and the monitor.
w; INPUT button*
To select the input source.
wa VOL (–/+) buttons*16
To turn up or down the volume.
*For the monitor XVM-R70.
These buttons also work for optional Sony
monitors other than XVM-R75 and XVM-H6.
The corresponding buttons of the card
remote commander control the same
functions as those on the player and
the monitor.
Instructions in this manual describe how to use
the player and the monitor by mainly using the
card remote commander.
Tip
Refer to “Replacing the lithium battery” for details
on how to replace the battery (page 34).
Cautions about the POWER (on/off) button (9)
The POWER (on/off) button (9) is only for the
player. If you want to turn off the player and the
monitor completely, press the MONITOR POWER
(ql).
Cautions about the MONITOR POWER (on/off)
button (ql)
• To turn off the player and the monitor, press the
MONITOR POWER button (ql)or press the
POWER button (7)on the monitor (page 8), or
close the display panel of the monitor until it
clicks.
• To turn on the player and the monitor again, be
sure to press the POWER button (7)on the
monitor (page 8).

10
DVD player MV-101
Refer to the pages listed for details.
DISC IN
POWER
MV-101
POWER
DISC IN
RESET
MV-101
1POWER (on/off) button 6
The player doesn't turn on, when the
monitor is turned off. Turn on the
monitor first.
To turn on/off the player, press and hold
the POWER button until the green light of
the button is turned on/off.
2DISC IN light
When a disc is in the player, the DISC IN
light glows orange.
3Receptor for the card remote
commander
4u (play/pause) button 4
5x (stop) button
6Disc slot
7Z(eject) button
Available to eject a disc from the player
even when the player is turned off.
8RESET button
9> (next) button
q; .(previous) button
Cautions
The player doesn't turn on, when the monitor
is turned off.
•To turn on the player, press (POWER) on
the monitor or (MONITOR POWER) on the
card remote commander. The player turns
on in conjunction with the monitor.
•If the player does not turn on in conjunction
with the monitor, press (POWER) on the
remote commander or on the player until
the green light of the POWER button (1)
on the player lights up.
Note
Even when the player is turned off, you can eject a
disc from the player, though you cannot insert a
disc.

11
Cordless Stereo Headphone
MDR-IF0140
1Battery compartment lid
To set a battery, open the lid.
2Ear pad 35
The ear pads are replaceable.
3Power (ON/OFF) switch 17
4POWER indicator 17
When the power switch of the headphones
is set to ON, the POWER indicator lights
up in red.
5VOL control dial 17
To adjust the volume level from 0 to 10.
Battery life
Size AAA dry battery (1) is supplied with the
headphone.
Battery Approx. hours*1
Sony alkaline battery 60 hours*2
LR03/AM-4 (N)
Sony manganese battery 28 hours*2
R03/UM-4 (NU)
*1at 1 kHz, 1 mW+1 mW output
*2Time stated above may vary, depending on the
temperature or conditions of use.
Notes on Battery
•Do not charge the dry battery.
•Do not carry the dry battery together with coins
or other metallic objects. It can generate heat if
the positive and negative terminals of the
battery are accidentally come into contact with
metallic objects.
•When you are not going to use the headphones
for a long time, remove the battery to avoid
damage from battery leakage or corrosion.
OPEN
ON
OFF
POWER
VOL
Lid (ZOPEN)
AAA dry
battery
Lid (ZOPEN)
When to replace the battery
When the battery becomes weak, the power
indicator light dims, or sound becomes
distorted or noisy. Replace the battery with
new one as soon as possible.
Inserting the battery
1Open the lid (ZOPEN) of the left
housing.
2Insert the size AAA dry battery into the
battery compartment matching 3
terminal on the battery to 3on the
compartment.
3Close the lid (ZOPEN).

12
Operation for Monitor
Opening the display
monitor
1Press (OPEN) to open the display
monitor.
2Press (POWER) to turn on the monitor.
Tip
If your car has no ACC (accessory) position on the
ignition key switch and you set the POWER SELECT
switch to the Bposition (for details, refer to the
installation/connections manual), be sure to press
(POWER) on the monitor to turn on the player and
the monitor.
Returning the display monitor to its
enclosure
Close the display monitor until it clicks. The
monitor turns off automatically.
Notes
•Be careful not to catch your finger in the display
monitor when closing.
•Do not put any foreign objects between the LCD
panel and the enclosure when closing.
POWER
OPEN
30˚
180˚
120˚
Adjusting the tilt and swivel
The display monitor can be adjusted within the
angles shown.
Tips
•Before closing the display monitor, make sure
that the monitor is turned and facing the
enclosure (you will hear a click).
•The monitor stores the input mode you set, even
if you turn off the monitor.

13
POWER
INPUT
VIDEO1
NTSC
VIDEO1
PAL
Selecting the input source
You can select the input source and color
system for the monitor. The color system
differs, depending on your country. You can
change the TV color system for the monitor.
1Press (POWER).
The monitor is turned on.
Tip
If your car has no ACC (accessory) position on the
ignition key switch and you set the POWER SELECT
switch to the Bposition (for details, refer to the
installation/connections manual), be sure to press
(POWER) on the monitor to turn on the player and
the monitor.
2Press (INPUT) repeatedly to select
“VIDEO 4.”
Each time you press (INPUT), the indication
changes in the following sequence:
VIDEO 1*cVIDEO 2*cVIDEO 3*c
VIDEO 4 cVIDEO 1*
*When connecting optional products, be sure
to select the proper input mode. For details,
refer to the connection diagram of
installation/connection manual.
3Press Mor mto select PAL or NTSC color
system.
Press either button while the source
indication “VIDEO 4” is displayed.
When NTSC Video is selected:
When PAL Video is selected:
Tip
You also have to set the same TV color system for
the player as the one you set here for the monitor.
See “Selecting the TV color system — COLOR
SYSTEM” (page 29).

14
MENU
Picture 32
or MENU.Press Vv,
Changing the display
settings
You can adjust the display settings manually if
the display is hard to see from the position
where you are seated.
1Press (MENU).
The “Picture” screen appears.
The setting value of the item
selected appears in this area.
Each time you press (MENU), the setting
screen changes in the following sequence:
Picture cBrightness cColor cHue*1c
Dimmer cVideo Adjust cMode c
Blue Back cMenu OFF
*1“Hue” appears only when the NTSC color system
is selected as the input source (page 13).
2Press Mor mto adjust to the desired
setting.
When “Picture” is selected;
Press m: to decrease the contrast.
Press M: to increase the contrast.
When “Brightness” is selected;
Press m: to darken the picture.
Press M: to brighten the contrast.
When “Color” is selected;
Press m: to decrease color intensity.
Press M: to increase color intensity.
When “Hue”*1is selected;
Press m: to decrease the saturation.
Press M: to increase the saturation.
*1“Hue” is adjustable only when the NTSC color
system is selected.
*2“CTR” appears only when is in the center of
the bar.
When “Dimmer” is selected;
Press mor Mto select “On.”
The brightness of the screen will be
adjusted automatically.
Picture 32
or MENU.Press Vv,
Brightness 32
or MENU.Press Vv,
Color
or MENU.Press
Vv,
32
Hue CTR
or MENU.Press Vv,
Dimmer; On
or MENU.Press
Vv,
*2

15
When “Video Adjust” is selected;
Press mor Mto select “Reset.”
“Picture,” “Brightness,” “Color,”
“Hue,” and “Dimmer” settings will be
reset to the factory preset level.
When “Blue Back” is selected;
Press mor Mto select “On.”
The blue background screen appears when
no signal, or a weak signal is received.
When a continuously weak video signal is
received, the blue background may flicker.
If this occurs, set to off.
When “Mode” is selected;
“Normal,” “Full,” “Zoom,” or “Widezoom”
can be set as the screen mode.
• “Normal”
An image with an
aspect ratio of 4 to
3 (regular image).
• “Full”
An image with an
aspect ratio of 4 to
3 enlarged to the
left and right
edges of the
screen.
Video Adjust;
Reset
or MENU.Press
Vv,
Blue Back; On
or MENU.Press
Vv,
Mode; Zoom
or MENU.Press
Vv,
NormalNormal
FullFull
• “Zoom”
An image with an
aspect ratio of 4 to
3 enlarged to the
left and right
edges of the
screen, with the
overflowing parts
(top and bottom)
cut off to fill the
screen.
• “Widezoom”
An image with an
aspect ratio of 4 to
3, with only the
left and right
sides of the image
being enlarged to
fill the screen.
ZoomZoom
WideWide

16
Adjusting the volume
You can adjust the volume of the wired
headphones (optional) and the connected
equipment with the supplied card remote
commander.
Press (VOL) (+) or (VOL) (–) on the card
remote commander.
Connecting the wired headphones
(optional)
For the wired headphones, there are two
output jacks (mini phono plug) on the
connection box XA-115. To adjust the volume
of the wired headphones, press (VOL) (+) or
(VOL) (–) on the card remote commander.
Using the supplied cordless
headphones MDR-IF0140.
See “Use of Headphones” (page 17).
Notes
• The volume of the cordless headphones cannot
be adjusted with the supplied card remote
commander. Use the volume control on the
cordless headphones.
• For your safety, do not use the headphones while
driving your car.
• Do not leave the headphones in a place subject
to direct sunlight, or in a high temperature.
• If the cordless headphones are used while
exposed to direct sunlight, sensitivity of the
infrared receptor may deteriorate, and inferior
quality sound may result.

17
Use of Headphones
Listening with the
headphones
Before listening
•The transmitter for the cordless headphones
is on the monitor. See the location of controls
for the monitor (page 8).
•To prevent your ears from being damaged,
first lower the volume.
1Turn on the monitor and the player.
2Set the power switch to ON on the right
housing of the headphone.
The headphones turn on and the POWER
indicator glows red.
3Put on the headphones.
Be sure to put the right housing (R) on your
right ear and the left housing (L) on your
left ear.
4Start playback on the monitor and the
player.
5Turn the VOL control dial to adjust the
volume.
If the infrared sensors of the headphones
are covered by your hands when adjusting
the volume, the attenuate function will be
activated and volume cannot be adjusted.
To adjust the volume, move nearer toward
the transmitter of the monitor, or orient the
infrared emitters on the left housing
towards the transmitter of the monitor.
Sound is automatically attenuated
if noise increases
— Attenuate function
If the infrared rays are obstructed, or the
headphones are used outside their effective
range, noise will increase and sound will
become hard to hear. To avoid potential ear
damage as a result of noise, this function
attenuates any sound in the headphones.
Sound is automatically restored when you
move nearer to the transmitter or remove the
obstruction.
After listening
Take off the headphones, and then turn off the
power (Noise may occur if you turn off the
monitor before taking off the headphones).
Power (ON/OFF)
switch
POWER indicator
VOL control dial

18
Various Playback
This chapter describes various functions for
playback.
Playing a disc
1Open the front panel of the player.
2Insert the disc (labeled side up or the
surface you want to play down if the
disc is a DVD) into the player.
If a disc is already inserted, press uto start
playback.
Note
Even when the player is turned off, you can eject a
disc from the player, though you cannot insert a
disc.
ENTER
SEARCH
POWER DISPLAY
CLEAR
SETUP
AUDIO
ANGLE
SUBTITLE
MENU
TOP MENU
INPUT MONITOR
POWER
123
456
7890
VOL
u
x
POWER
MONITOR
POWER
SEARCH
M/m
</,
Number
buttons
Searching a chapter/title/track
directly
1During playback or pause, press
(SEARCH) to display search screen.
•DVD
Each time you press (SEARCH), the
search screen toggles between Title and
Chapter.
•Video CD (only when PBC is off)/Audio
CD
The track search screen appears.
2Press the number buttons to enter the
desired chapter/title/track number.
3Press (ENTER).
Note
You cannot set “0.”
Resume playback
1During playback, press xto stop.
The player memorizes the point where
playback is stopped.
•DVD/Video CD/Audio CD
“PRESS PLAY TO CONTINUE” flashes on
the screen.
2Press uto start playback.
When resume playback is activated,
playback starts from the point where
playback is stopped. When resume
playback is deactivated, playback starts
from the beginning.
•MP3
When resume playback is activated,
playback starts from the beginning of the
MP3 file (track) during which you
stopped playback.
Notes
• To deactivate the resume function, press xagain
while playback is stopped or eject the disc from
the player.
• The player stores the point where you stopped
playback for the disc currently in the player.
• The resume function will be deactivated:
— when the disc is ejected.
• If the resume function is activated during fast/
slow forward or fast/slow reverse playback,
normal playback starts when you press u.

19
SMART NAVI
ROOT
FOLDER 1
FOLDER 2
FOLDER 3
0
1
2
3
ROOT
SMART NAVI
_ _
SCHUBERT
BACH
MOZART
CHOPIN
BRAHMS
0
1
2
3
4
5
ROOT
FOLDER 1
FOLDER 2
FOLDER 3
Turning off the player and
the monitor
There are 3 ways to turn off the player and the
monitor.
— Press (POWER) on the monitor.
— Press (MONITOR POWER) on the card
remote commander
— Close the display monitor until it
clicks.
If you set the POWER SELECT switch to B
(the setting without ACC position) for your
car
There are 3 ways to turn off the player and the
monitor:
— After turning off the ignition, be sure to
press (POWER) on the monitor.
— After turning off the ignition,
(MONITOR POWER) on the card remote
commander.
— After turning off the ignition, just close the
display panel until it clicks.
MP3 file playback with the
menu display
If you have set “SMART NAV” to “WITH
MENU” (page 33) and play a CD containing
MP3 files, the menu display for folder names
and MP3 file names will appear. You can
easily search the desired MP3 file with the
“SMART NAV” menu display.
1Insert a CD containing MP3 files in this
player.
The “SMART NAV” menu display appears.
2Press the number buttons to select the
desired folder.
M/,/m/<buttons are also available to
select the desired folder.
If you select the folder 1, the MP3 file
names in the folder 1 appear.
3Press the number buttons to select the
desired MP3 file.
M/,/m/<buttons are also available to
select the desired MP3 file.
Playback starts.
To turn off the menu display for MP3 files, set
“SMART NAV” to “NO MENU” (page 33).
Note
To deactivate the resume function, press xagain
while playback is stopped or eject the disc from
the player.

20
Displaying running time
You can display the running time of DVDs,
Video CDs and Audio CDs.
During playback, press (DISPLAY).
The running time is displayed at the upper
left.
• DVD
1Press (DISPLAY) while the running
time is displayed.
2Each time you press (DISPLAY), the
display changes as follows:
*The format of the sound source (Dolby D,
DTS, or LPCM) may appear.
To exit the display for running time, press
(DISPLAY) repeatedly to select “OFF.”
ENTER
SEARCH
POWER DISPLAY
CLEAR
SETUP
AUDIO
ANGLE
SUBTITLE
MENU
TOP MENU
INPUT MONITOR
POWER
123
456
7890
VOL
DISPLAY
TITLE 01/01 CHAPTER 02/05
00:24:50 Dolby D*
TITLE REMAIN
01:25:41
Dolby D*
CHAPTER ELAPSED
00:01:48
Dolby D*
CHAPTER REMAIN
00:03:26
Dolby D*
OFF
• Video CD (when PBC is set to OFF)/CD
1Press (DISPLAY) while the running
time is displayed.
2Each time you press (DISPLAY), the
display changes as follows:
To exit the display for running time, press
(DISPLAY) repeatedly to select “OFF.”
SINGLE ELAPSED
00:00:12
SINGLE REMAIN
00:04:45
TOTAL ELAPSED
00:06:32
TOTAL REMAIN
00:41:15
OFF
