Sony COM-2WHITE - Mylo™ Internet Device User manual

COM-2WHITE
mylo® Internet Device
Key Features
Pocket size communicator uses Wi - Fi (IEEE
802.11b/g)
1
Instant message via Yahoo! ® Messenger, Google
Talk™, Skype ® or AOL ® Instant Messenger™
1
Make Skype ® internet voice calls with built - in mic
and speaker
1
1.3 MP camera for video and still image capture
Music player (MP3, WMA, ATRAC ® & AAC codecs)
3
Enhanced web browsing with Adobe ® Flash ®
Lite™3 support
1
Direct upload and download from the device
3.5" high resolution (800 x 480) color LCD
Touchscreen
2
Key Technologies
Shoot Video...Now you're a star Now you can capture video using the built in camera to capture video in MPEG4
in addition to capturing still images. There are many websites where you can upload photos and videos like Flickr™
and YouTube ™as well as social networking websites. Because our device supports uploading and downloading files
mylo Internet Device owners can post content to many of these popular content websites .
1
Enhanced Web Browsing Through its hi - res touch - screen, you can browse many popular websites. Your portable
Internet experience is now closer to the internet experience on a PC. Enhanced Web Browsing combined with Adobe ®
Flash ® Lite 3 support means you now have access to websites like YouTube™ and others. Mylo's upload and download
capability allows you to use popular websites like Facebook ® for posting and commenting . Adobe ® Flash ® Lite
support also means you can play compatible casual Flash games.
1
Instant Messaging. Where and when you want. With the Sony ® mylo ® Internet Device you can always stay in
touch. Instant Message your friends with the most popular messaging software from AOL ® , Yahoo! ® , Google™ and
Skype ® . Send and receive e - mail through AOL ® Mail, Google Gmail™ and Yahoo! ® Mail. And, with COM - 2's new backlit
keyboard you can type wherever you want to regardless of how much light is available.
mylo Widgets A widget is a small application that is generally designed to do one simple thing but to do it really well.
COM - 2 comes with several pre - installed widgets that range from basic like the Google search widget and the
Facebook ® Notifier that tracks activity on your Facebook page to more advanced apps like the My Contacts widget
that works as a consolidated buddy list for all the IM applications on the mylo. In addition to the preinstalled widgets
COM - 2 users will be able to download new widgets from the new COM - 2 product website. And, for the first time, users
will be allowed to register as a developer in order to gain access to the technical resources they will need to build their
own widgets.
Built in Camera With the built in 1.3 Megapixel camera imaging and everything you do online are at your finger tips
. Now you can capture photos, edit them on the built in photo editor and because COM - 2 features upload and
download capability you can post them directly to your blog or even to your Facebook page . All on the mylo without
the need for a PC.
1
1
Voice Calling with Skype ® Skype lets you enjoy free Internet phone calls to and from any Skype enabled device
and PC, anywhere in the world! Or Skype - Out to any phone number for a nominal fee.
Music and Video MP3, ATRAC, WMA (Secured and Un - Secured) and now AAC codecs. Play music you've purchased
from many compatible online music stores. Multi - task: listen to music while you IM or surf the Web . COM - 2 also
supports Windows Media DRM 10 so you can even use your mylo communicator with many popular subscription
music services. The improved video player supports both MPEG4 along with the improved video quality of MPEG4 AVC.
3
1

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 07/15/2008
COM-2WHITE
mylo® Internet Device
Please visit the Dealer Network for current
information at www.sony.com/dn
Specifications
Video
Format(s)Supported: MPEG4 SP/ASP, AVC
Baseline (up to QVGA 30fps, 384/768
kbps)
Audio
Format(s)Supported: MP3, WMA, AAC,
ATRAC ®
Inputs and Outputs
HeadphoneJack: ö 3.5mm jack via remote
controller
HeadsetInputs: 10pin flat jack (16ohms)
USBPort(s): mini USB jack
Power
AC Power: Adapter DC IN 5.2V
Battery Life (Approx.): Up to 6 hours
Internet calling , Up to 20 hours music
playback , Up to 7 hours video playback ,
Up to 6 hours Web Browsing
BatteryType: Removable Lithium - Ion
Rechargeable Battery 3.7V 1200mAh
Dimensions
Weight: 6.8oz (193g) (including
rechargeable battery)
Measurements: 5 1/4 x 27/32 x 2 5/8in
(130.8 x 20.7 x 64.6mm) (excluding
protrusions)
Operating Conditions
OperatingTemperature: 5 to 35 C (41 to
95F)
Software
InstantMessaging: Yahoo! ® Messenger,
Google Talk™ , Skype ® or AIM ®
Internet Voice Calls: Skype ®
Hardware
LCD: 3.5 WVGA (800 x 480 pixels) with
Touch Panel
Keyboard: Backlit slide - out QWERTY
keyboard
Speakers: Built - in
Microphone: Built - in and one - touch answer
remote controller
Camera: 1.3 Megapixel with macro mode
Networking/Modem
WirelessLAN: IEEE 802.11b/g
Security: WEP (128bit/64bit, Open
System/Shared Key), WPA - PSK (TKIP, AES)
Memory
Memory Size: 1GB Internal memory
6
6
6
6
7
7
4
Type: Memory Stick Duo/PRO Duo™
Expansion Slot (up to 8GB Memory Stick
Duo/PRO Duo™supported )
Graphics
Format(s)Supported: JPEG, PNG, BMP
Web Browser
Web Browser Type: Access NetFront™ web
browser with Adobe ® Flash ® Lite 3
Supplied Accessories
One Touch Answer Remote Controller with
Microphone
Headphones
Stylus
Strap
AC Adapter
Rechargeable Battery Pack
Carrying Pouch
USB Cable
Installation CD - ROM (PC required)
Color: White
UPC Code: 027242720824
1.RequirescompatiblewirelessLANaccesspoint(s).Somefeaturesrely
onInternetserviceswhichmayrequireafee.Aswithallwireless
products,actual performance will vary depending onenvironment.
2. Viewable area measured diagonally.
3.myloCOM2supportsmusicinMP3,AAC,WMA(SecuredandUn -
Secured)orATRAC® codecs.DRM(DigitalRightsManagement)
encoded music files must be played from the device ’ sinternal
memory.
4.Actualfreememorymayvaryduetopre - configuration.1GB equals
1024Megabytes,aportion of which is used for data management
functions.
5.mylo™ COM2only supports web - based email from AOL ® Email,
Google ™ Gmail ™ and Yahoo! ® Mail.
6.Actualbatterylifewillvarybasedonnetwork,productsettings,usage
patterns,battery and environmental conditions.
7.Weights and measurements are approximate and mayvary.
8. Editting photo feature can be used on photos up to 1280 x 1024 pixels.
9.To learn more about"MemoryStick,"please visit
www.sony.com/mylo/support.
10.FreethroughDecember31,2010.
©2008SonyElectronics Inc. Reproduction inwholeorin part without
writtenpermissionisprohibited.Allrights reserved. Features and
specificationsaresubjectto change without notice. Sony, Sony logo,
ATRAC,MemoryStick, Memory StickDuo,ATRACand mylo are
trademarksofSony. WAYPORT, the"PoweredbyWayport" logo are
registeredtrademarksortrademarksofWayport,Inc.McDonald ’ sand
theMcDonald ’ sInternetlogo are registered trademarks of McDonald ’ s
Corporationanditsaffiliates,used with permission. Allothertrademarks
arepropertyoftheirrespectiveowners.U.S. and foreign patents licensed
fromDolby Laboratories.
