Sony Xperia Z2 Quick reference guide

White paper
July 2014
XperiaTM Z2
Note: Screen images are simulated.

White paper | Xperia™ Z2
2 July 2014
This document is published by Sony Mobile
Communications AB, without any warranty*.
Improvements and changes to this text
necessitated by typographical errors,
inaccuracies of current information or
improvements to programs and/or equipment
may be made by Sony Mobile Communications
AB at any time and without notice. Such changes
will, however, be incorporated into new editions
of this document. Printed versions are to be
regarded as temporary reference copies only.
*All implied warranties, including without
limitation the implied warranties of
merchantability or fitness for a particular
purpose, are excluded. In no event shall Sony or
its licensors be liable for incidental or
consequential damages of any nature, including
but not limited to lost profits or commercial loss,
arising out of the use of the information in this
document.
This White paper is published by:
Sony Mobile Communications AB,
SE-221 88 Lund, Sweden
www.sonymobile.com
© Sony Mobile Communications AB, 2009-2014.
All rights reserved. You are hereby granted a
license to download and/or print a copy of this
document.
Any rights not expressly granted herein are
reserved.
First released version (March 2014)
Publication number: 1279-8999.1
Purpose of this document
Sony product White papers are intended to give an overview of a product and provide details in relevant
areas of technology.
Document history
Sony Mobile Developer World
For the latest technical documentation and development tools, go to www.sonymobile.com/developer.
Version
March 2014 First released version Version 1
July 2014 Second released version Version 2

White paper | Xperia™ Z2
1 July 2014
Table of contents
Product overview ........................................................................................................2
Xperia™ Z2 L50u ...................................................................................................2
Facts – dimensions, weight, performance and networks ......................................3
Categorised feature list ..........................................................................................6
Technologies in detail .................................................................................................9
Device-to-device communications (local) .............................................................9
ANT+™ wireless technology...............................................................................9
Bluetooth® wireless technology .......................................................................10
WLAN ................................................................................................................11
DLNA Certified® (Digital Living Network Alliance) ............................................12
Messaging ...........................................................................................................13
MMS (Multimedia Messaging Service)..............................................................13
Email .................................................................................................................13
Positioning – location based services .................................................................14
Provisioning (OMA CP) ........................................................................................14
Multimedia (audio, image and video) ...................................................................15
Synchronisation (OMA DS, EAS) .........................................................................17
Trademarks and acknowledgements ..................................................................18

White paper | Xperia™ Z2
2 July 2014
Product overview
Xperia™ Z2 L50u
• A large 1/2.3 inch 20.7 MP Exmor RS™ for mobile image sensor, Sony’s G Lens, and intelligent
BIONZ™ for mobile image processing engine. Video mode in 4K resolution with Steadyshot™ technol-
ogy.
• Scratch resistant glass and a high level of waterproofing (IP58 and IP55). Durable, sleek and super styl-
ish.
• 5.2 inch Full HD TRILUMINOS™ display with Live Colour LED and X-Reality for mobile.
• Qualcomm Snapdragon Quad-core 2.3 GHz processor, 3 GB RAM and a high capacity 3200 mAh bat-
tery with STAMINA mode
The new waterproof* Xperia™ Z2 combines new video modes such as Timeshift video, Steadyshot™, and
4K recording with the large 1/2.3 inch 20.7 MP Exmor RS™ for mobile image sensor, Sony’s award-
winning G Lens and intelligent BIONZ™ for mobile processing engine. It also features an expanded range
of Xperia™ Camera apps that provide new and creative ways to record and share content.
The all new 5.2 inch display is built with the latest Sony technologies, including TRILUMINOS™ Display for
mobile with Live Colour LED and X-Reality for mobile, for a stunning viewing experience, as close to reality
as possible. To match the display, we have also added new and improved stereo speakers and support
for noise cancelling headphones to give you an experience that only Sony can offer.
Powered by the latest Snapdragon Quad-core processor and a high capacity battery, the Xperia™ Z2
makes sure you don't get left behind. Perform faster and smarter than ever before.
* In compliance with IP55 and IP58, this smartphone is protected against the ingress of dust and is
waterproof. Provided that all ports and covers are firmly closed, the phone is (i) protected against low
pressure jets of water from all practicable directions in compliance with IP55; and/or (ii) can be kept under
1.50 metres of freshwater for up to 30 minutes in compliance with IP58. Find out more at
www.sonymobile.com/testresults.

White paper | Xperia™ Z2
3 July 2014
Facts – dimensions, weight, performance and
networks
Operating system Google™ Android™ 4.4 (KitKat)
Processor 2.3 GHz Qualcomm MSM8974AB Quad Core
GPU Adreno 330
Size 149 x 73.3 x 8.2 mm
Weight 163 grams
Available colours Black
White
SIM card micro SIM
Main screen
Colours 16,777,216 colour TFT
Resolution Full HD 1920x1080 pixels
Size (diagonal) 5.2 inches
Input mechanisms
Text input On-screen QWERTY keyboard
Touch screen Capacitive
Touch gesture Yes – multi-touch, up to 10 fingers supported
Memory
RAM 3 GB
Flash memory Up to 16 GB*
Expansion slot microSD™ card, up to 128 GB (SDXC supported)
Camera
Camera resolution 20.7 MP
Digital zoom 8x
Photo light Yes – Pulsed LED
Video recording Yes – 4K2K
Front Camera Yes – HD 1080p for video chat and 2.2 MP for camera capture
ISO ISO 3200 maximum in manual mode
Minimum Focus distance 100 mm
Sensors
Accelerometer Yes

White paper | Xperia™ Z2
4 July 2014
* Memory comprises approximately 4GB of firmware, plus 12GB of “Internal storage” for music, pictures
and movies, and downloaded applications and their data. For more details about memory, see “Trade-
marks and acknowledgements” on page 18.
Ambient light sensor Yes
Barometer sensor Yes
Game rotation vector Yes
Geomagnetic rotation vector Yes
Gyroscope Yes
Magnetometer Yes
Step counter Yes
Step detector Yes
Significant motion detector Yes
Proximity sensor Yes
Networks
L50u TD-LTE Band 41 (China Unicom)
FDD-LTE Band 1 and 7 (roaming only)
UMTS HSPA+ Bands 1, 2, 8
GSM GPRS/EDGE 850, 900, 1800, 1900 MHz
Data transfer speeds
GSM GPRS Up to 107 kbps
GSM EDGE Up to 296 kbps
HSUPA (upload) Cat 6, up to 5.8 Mbps
HSDPA (download) Cat 24, up to 42 Mbps
LTE (upload) Cat 4, up to 50 Mbps
LTE (download) Cat 4, up to 150 Mbps
Talk time (GSM) Up to 15 hours**
Standby time (GSM) Up to 690 hours**
Talk time (UMTS) Up to 19 hours**
Standby time (UMTS) Up to 740 hours**
Standby time (LTE) Up to 640 hours**
Music listening time Up to 120 hours**
Video playback time Up to 10 hours**
Battery (Embedded) 3200 mAh minimum

White paper | Xperia™ Z2
5 July 2014
** Values are according to GSM Association Battery Life Measurement Technique as performed in con-
trolled laboratory conditions. Actual time may vary.
NOTE: The battery performance may vary depending on network conditions and configurations, and
device usage.
NOTE: Performance metrics were all measured under laboratory conditions.

White paper | Xperia™ Z2
6 July 2014
Categorised feature list
Camera
20.7 MP camera with Sony Exmor
RS® for mobile image sensor
8x digital zoom
Auto focus
Burst mode
HDR for photos and movies
Face detection
Flash/Pulsed LED
Flash/Photo light
Front-facing camera (2.2 MP
1080p) with Sony Exmor R® for
mobile image sensor
Geotagging
Image stabiliser
Object tracking
Picture Effect
Quick Launch
Red-eye reduction
Scene recognition
Self-timer
Send to web
Smile Shutter™
SteadyShot™
Superior Auto
Sweep Panorama
Touch capture
Touch focus
Video recording (4K2K)
White balance
Music
3D Surround Sound (VPT)
Album art
Bluetooth® stereo (aptX®, A2DP)
ClearAudio+
Clear Bass™
Clear Phase™
Clear stereo
Dynamic normaliser
High definition audio
Low power audio playback***
Music tones (MP3/AAC)
PlayNow™ service*
SensMe™
Stereo speakers
TrackID™ music recognition*
“WALKMAN” application
xLoud™ Experience
Internet
Baidu search
Baidu for Sony
Baidu cloud album
Bookmarks
Info-eye™*
Pan & zoom
Sony Select
Xperia™ Home
Web browser (WebKit™)*

White paper | Xperia™ Z2
7 July 2014
Communication
Call list
Noise suppression
Polyphonic ringtones
Sina Weibo
Slow talk
Smart call
Speakerphone
Talk equaliser
Voice enhancement
Xperia™ Socialife*
Messaging
Conversations
Email
Handwriting recognition
Instant messaging*
Multimedia messaging (MMS)
Predictive text input
Sound recorder
Text messaging (SMS)
Design
Auto rotation
Battery STAMINA mode
Direct touch
Face Unlock
Gesture input
IPX5 and IPX8 (waterproof)**
IP5X (Dust protected)
On-screen QWERTY keyboard
Stylus pen support
Screenshot capturing
Throw
X-Reality™ for mobile
Touch screen
Triluminos™
Voice input
Wallpaper

White paper | Xperia™ Z2
8 July 2014
* This service is not available in all markets.
** In compliance with IP55 and IP58, this smartphone is protected against the ingress of dust and is
waterproof. Provided that all ports and covers are firmly closed, the phone is (i) protected against low
pressure jets of water from all practicable directions in compliance with IP55; and/or (ii) can be kept under
1.50 metres of freshwater for up to 30 minutes in compliance with IP58. Find out more at
www.sonymobile.com/testresults.
*** This feature is only available when you play music using the "WALKMAN" application.
Entertainment
3D games
Media browser
Motion gaming
Radio (FM radio with RDS)
Reader mode
SensMe™ slideshow
TV launcher
Video streaming
Organiser
Airplane mode
Alarm clock
Calculator
Calendar
Contacts
Document readers
eCompass™
Setup guide
Sketch
Stopwatch
Tasks
Timer
Connectivity
3.5 mm audio jack Digital Noise
Cancelling (DNC)
ANT+™ sport, fitness,
health support
aGPS*
Bluetooth® 4.0 wireless
technology
DLNA Certified®
GLONASS
MHL 3.0 support + 5-pin support
Media Go™
Media Transfer Protocol support
Micro USB support
Native USB tethering
NFC
PC Companion
Screen mirroring
Smart Connect
Synchronisation via SyncML™
Synchronisation via Exchange
ActiveSync®
USB charging
USB High speed 2.0 support
USB Host
Xperia Link™
WLAN
WLAN Hotspot functionality
WLAN Miracast

White paper | Xperia™ Z2
9 July 2014
Technologies in detail
NOTE: The information outlined below is general and levels of compliance to standards and specifications
may vary between products and markets. For more information, contact Sony Mobile Developer World or
your Sony contact person where applicable.
Device-to-device communications (local)
ANT+™ wireless technology
Connectable devices ANT+™ devices require download of a supporting application
Frequency band 2.4 GHz
Data transfer rate Up to 60 Kbps
Encryption AES-128
Topologies One To Many, Many to One, Peer to Peer, Star, Practical Mesh

White paper | Xperia™ Z2
10 July 2014
Bluetooth® wireless technology
More information:
www.sonymobile.com/developer
www.bluetooth.com
Bluetooth® profiles supported Advanced Audio Distribution Profile v1.2
Audio/Video Remote Control Profile v1.3
Device Identification Profile v1.3
Generic Attribute Profile Client/Server over LE
Handsfree Profile v1.6 (Wide band speech)
Headset Profile v1.2
Health Device Profile v1.1
HID over GATT Profile v1.0
Human Interface Device Profile, Host role v1.1
Messaging Access Profile v1.0
Object Push Profile v1.1
Personal Area Networking Profile v1.0
Phonebook Access Profile v1.1
Serial Port Profile v1.1
Core version and supported
core features
Version 4.0
Bluetooth Low Energy
Other supported features aptX® CD quality audio streaming over Bluetooth®
connection
Connectable devices Products support at least one of the Bluetooth® profiles
listed above.
Bluetooth® 4.0 accessories generally require installation
of a supporting application.

White paper | Xperia™ Z2
11 July 2014
WLAN
Supported standards IEEE 802.11 b/g/n and WLAN
Wi-Fi Direct™, Wi-Fi Protected Setup, Wi-Fi Certified
Passpoint, Wi-Fi Certified Miracast
Connectable devices WLAN access points
Wi-Fi Direct compatible devices
Frequency band 2.4 GHz
Data transfer rate Up to 433 Mbit/s
Security Open Authentication
Shared Authentication
EAP-SIM
EAP-AKA
EAP-TLS
EAP-TTLS/MSCHAPv2
PEAPv0/EAP-MSCHAPv2
PEAPv1/EAP-GTC
WPA Personal and WPA2 Personal
WPA Enterprise and WPA2 Enterprise
Encryption WEP 64 bit, WEP 128 bit, TKIP and CCMP (AES)
Power save WMM-UAPSD
QoS WMM

White paper | Xperia™ Z2
12 July 2014
DLNA Certified® (Digital Living Network Alliance)
Supported Device Classes M-DMS – Mobile Digital Media Server
Media Types: images, music and video
Summary: The digital media server exposes the media
files in your device to a WLAN network. The files can
then be accessed from other DLNA Certified® clients.
+PU+
Media Types: image, video and music
Summary: Play media in your device on another device,
such as a TV or a PC using 2 box push technology. +PU+
is integrated in the Album, Movies and "WALKMAN"
applications.
M-DMP – Mobile Digital Media Player
Media Types: image, video and music
Summary: Play content stored on another device, for
example, a server or a PC, directly on your device.
+DN+
Media Types: video and music
Summary: Download content stored on another device,
for example, a server or a PC, and play the downloaded
content directly on your device.
Supported Bearers WLAN
WLAN Direct
DRM Support The DLNA Certified® implementation does not support
DRM-protected content.

White paper | Xperia™ Z2
13 July 2014
Messaging
MMS (Multimedia Messaging Service)
According to OMA Multimedia Messaging Service v1.0 + SMIL
Email
More information:
www.sonymobile.com/developer
www.openmobilealliance.org
Bearer type (IP) GPRS, EGPRS, UMTS
Character sets BIG5 Traditional Chinese
GB18030
ISO-2022-JP Japanese
ISO-8859-1
ISO-8859-2 Eastern Europe
ISO-8859-5 Cyrillic
ISO-8859-7 Greek
ISO-8859-9 Turkish
ISO 8859-11
KOI8-R Cyrillic
Shift_JIS Japanese
US-ASCII
UTF-16
UTF-8
Windows® 874
Windows® 1251 Cyrillic
Windows® 1252
Windows® 1254 Turkish
Windows® 1258 Vietnamese
Protocols POP3 and IMAP4
Push email Microsoft® Exchange ActiveSync® (EAS)
Secure email SSL/TLS, both port methods (POPS/IMAPS) and
STARTTLS
HTML mail Yes (read only)

White paper | Xperia™ Z2
14 July 2014
Positioning – location based services
Supported standards:
• OMA Secure User Plane Location (SUPL) v1.0 & v2.0
• 3GPP™ Control Plane location (incl. Emergency location)
• Qualcomm® GPSOneXtra™
Supported satellite systems:
•GPS
• GLONASS
NOTE: GPS and GLONASS are used together to calculate the position. Positioning is more robust and
accurate in most conditions if both systems are active. The benefits of using GLONASS are automatically
available for all applications using the Satellite Positioning API (referred to as "GPS Provider" in Android
terminology).
Provisioning (OMA CP)
OMA CP version 1.1

White paper | Xperia™ Z2
15 July 2014
Multimedia (audio, image and video)
Audio Playback Decoder format Supported in file format
AAC (AAC-LC, AAC+, eAAC+
AAC-ELD)
3GPP (.3gp, 3gpp), MP4 (.mp4,
.m4a), ADTS (.aac)
AMR-NB, AMR-WB 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4a), AMR (.amr, .awb)
FLAC FLAC (.flac), Matroska (.mka)
MIDI SMF (.mid), XMF (.xmf), Mobile
XMF (.mxmf), OTA (.ota), RTTTL
(.rtttl), RTX (.rtx), iMelody (imy)
MP3 MP3 (.mp3)
PCM WAV (.wav)
Vorbis OGG (.ogg), Matroska (.mkv)
WMA ASF (.wma)
Audio Recording Encoder format Supported in file format
AAC (AAC-LC, AAC+, AAC-ELD) 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4a)
AMR (AMR-NB, AMR-WB) 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4a), AMR (.amr)
Image Playback Decoder format Supported in file format
BMP BMP (.bmp)
GIF GIF (.gif)
JPEG JPEG (.jpg, .jpeg)
PNG PNG (.png)
WebP WebP (.webp)
Windows bitmap BMP (.bmp)
Image Capture Encoder format Supported in file format
JPEG JPEG (.jpg)

White paper | Xperia™ Z2
16 July 2014
Video Playback Decoder format Supported in file format
MPEG-4 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4v)
Matroska (.mkv), AVI (.avi), Xvid
(.xvid)
H.263 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4v)
H.264 3GPP (.3gp, .3gpp), MP4 (.mp4,
.m4v), Matroska (.mkv)
VP8 WebM (.webm), Matroska (.mkv)
VP9 WebM (.webm)
Video Recording Encoder format Supported in file format
MPEG-4 3GPP (.3gp), MP4 (.mp4)
H.263 3GPP (.3gp), MP4 (.mp4)
H.264 3GPP (.3gp), MP4 (.mp4)
Audio/Video Streaming Streaming transport HLS
HTTP progressive streaming
MPEG-DASH
RTSP
DRM DRM (Digital Rights Management) –
features the rights and copy
protection of downloaded content
OMA DRM v1.0
Marlin DRM
Widevine Level 3
PlayReady DRM (available in
specific regions)

White paper | Xperia™ Z2
17 July 2014
Synchronisation (OMA DS, EAS)
OMA Data Synchronisation protocol versions 1.1.2 and 1.2
OMA Data Formats: vCard 2.1, vCalendar 1.0
Microsoft® Exchange ActiveSync® protocol version 2.5
Microsoft® Exchange ActiveSync® protocol version 12
Microsoft® Exchange ActiveSync® protocol version 12.1
Microsoft® Exchange ActiveSync® protocol version 14
Microsoft® Exchange ActiveSync® protocol version 14.1
Related information:
www.sonymobile.com/developer

White paper | Xperia™ Z2
18 July 2014
Trademarks and acknowledgements
All product and company names mentioned herein are the trademarks or registered trademarks of their
respective owners. Any rights not expressly granted herein are reserved. All other trademarks are property
of their respective owners.
Visit www.sonymobile.com for more information.
