Sony XPERIA Ion LT28at Quick reference guide

White paper
January 2012
S
LT26i
White paper
January 2012
S
LT26i
White paper
Aoba
Ion
LT28at
White paper
January 2012

White paper | Xperia™ ion
2 July 2012
This document is published by Sony Mobile
Communications AB, without any warranty*.
Improvements and changes to this text
necessitated by typographical errors,
inaccuracies of current information or
improvements to programs and/or equipment
may be made by Sony Mobile Communications
AB at any time and without notice. Such changes
will, however, be incorporated into new editions
of this document. Printed versions are to be
regarded as temporary reference copies only.
*All implied warranties, including without
limitation the implied warranties of
merchantability or fitness for a particular
purpose, are excluded. In no event shall Sony or
its licensors be liable for incidental or
consequential damages of any nature, including
but not limited to lost profits or commercial loss,
arising out of the use of the information in this
document.
This White paper is published by:
Sony Mobile Communications AB,
SE-221 88 Lund, Sweden
www.sonymobile.com
© Sony Mobile Communications AB, 2009-2012.
All rights reserved. You are hereby granted a
license to download and/or print a copy of this
document.
Any rights not expressly granted herein are
reserved.
Second released version (January 2012)
Publication number: 1256-1279.1
Purpose of this document
Sony product White papers are intended to give an overview of a product and provide details in relevant
areas of technology.
Document history
Sony Mobile Developer World
For the latest technical documentation and development tools, go to http://developer.sonymobile.com/
wp.
Version
January 2012 Second released version Version 2
July 2012 Third released version Version 3

White paper | Xperia™ ion
1 July 2012
Table of contents
Product overview ........................................................................................................2
Sony Xperia™ ion – Experience Intense Power ....................................................2
Signature features .................................................................................................4
Facts – dimensions, weight, performance and networks ......................................5
Categorised feature list ..........................................................................................7
Technologies in detail .................................................................................................9
Device-to-device communications (local) .............................................................9
Bluetooth™ wireless technology ........................................................................9
Wi-Fi® ...............................................................................................................10
DLNA Certified® (Digital Living Home Alliance)................................................11
Messaging ...........................................................................................................12
MMS (Multimedia Messaging Service)..............................................................12
Email .................................................................................................................12
Positioning – location based services .................................................................13
Provisioning (OMA CP) ........................................................................................13
Multimedia (audio, image and video) ...................................................................14
Synchronisation (OMA DS, EAS, Google Sync™) ...............................................15
Web browser .......................................................................................................16
Trademarks and acknowledgements ..................................................................17

White paper | Xperia™ ion
2 July 2012
Product overview
Sony Xperia™ ion – Experience Intense Power
There’s fast, and then there’s fast. So why wait? Browse the web and download apps at incredible
speeds. Shoot HD videos, take pictures in a snap, and share them all on the stunning 4.6” HD screen. In
just a few clicks, enter a wider world of movies, music, and games. With the Sony Entertainment Network,
boredom is never an option.
Get what you want...fast
Get what you want without the wait. Browse the web, stream music, watch videos. Download your
favorite games and apps. All in an instant. On AT&T’s LTE network and a 1.5 GHz dual processor, the
Xperia™ Ion keeps you connected. Always. And fast.
See every detail
Experience videos, photos and your favorite TV shows in vivid, bright colors on the stunning 4.6” HD
Reality Display with Mobile BRAVIA® Engine. Crisp images. No jagged edges. With reduced light
reflection, the picture stays clear when you're outdoors too. Merely the best entertainment experience in
HD.
Snap your shots in an instant
Some events are too good to miss. Now you don’t have to. Activate your 12MP camera and take your first
shot in just over a second. Keep shooting with only one second between shots. No delays. No missed
moments. Even in low light conditions, the Exmor R™ for mobile camera sensor lightens up any gloomy
day.
Show it like it is
Vacation videos, baby's first steps…record it all in brilliant HD video with one touch of a button. Connect
your Xperia ™ ion to an HD TV and relive those moments from the comfort of your couch. Want to share
moments together? Chat away on the front-facing HD chat-cam. Perfect for video calls.

White paper | Xperia™ ion
3 July 2012
Sony Entertainment Network. Your ultimate source for digital entertainment
Hot tracks, latest films. Enjoy millions of songs and thousands of movies. It’s all on Sony Entertainment
Network services - Music Unlimited™ and Videos Unlimited, exclusive to Xperia™ smartphones. No trips
to the store. No lines. No late fees. Just pure entertainment.
Enjoy everything with one account. It’s the perfect fit for a life full of entertainment.
* Sony Entertainment Network with Video Unlimited™ and Music Unlimited™ are not available in all
markets.

White paper | Xperia™ ion
4 July 2012
Signature features
The sony Xperia™ ion comes with a range of Sony features as standard. Below is a summary of the key
signature features.
Xperia™ Timescape™
Communication made easy
The Timescape™ application manages all your communication with one person in one place. You can
effortlessly browse by category your Facebook™, Twitter™, email and text communications, as well as
view your photos. Now everything is all together and in chronological order, so you don't have to open
different applications to see what's going on.
Xperia™ Infinite button
Everything you want – from everywhere
Tap the infinite button in the Timescape™ application and smart filter each category of communication by
person. For example, when viewing a text message from a friend in Timescape™, tap the infinite button to
view a list of all chat messages with that friend.
Xperia™ Local connectivity
More control over your media
Using Sony Local connectivity, you can exercise more control over how media files get transferred and
stored. For example, you can select MTP mode to transfer files if you want to limit the risk of data corrup-
tion or select MSC mode if you want to have more control over the data storage.
Xperia™ Home screen application
The place you call Home
Customise your Home screen with widgets, shortcuts, folders, themes, wallpaper and other items.
Where’s best for you? Email top right? Music player bottom left? You decide. With four extensions to your
Home screen, you’ve got plenty of space to put things where you want. Just remember to flick left or right
to find them.

White paper | Xperia™ ion
5 July 2012
Facts – dimensions, weight, performance and
networks
Operating system Google™ Android™ 2.3 (Gingerbread)
Processor 1.5 GHz Qualcomm MSM8260 Dual Core
GPU Adreno 220
Size 133 x 68 x 10.8 mm
Weight 144 grams
Available colours Black
SIM card Micro SIM
Main screen
Colours 16,000,000 colour TFT
Resolution 1280x720 pixels
Size (diagonal) 4.55 inches
Scratch-resistant Shatter proof sheet on scratch-resistant glass
Input mechanisms
Text input On-screen QWERTY keyboard
Touch screen Capacitive
Touch gesture Yes – multi-touch, up to 4 fingers supported
Memory
Internal phone storage 1 GB
RAM 1 GB
Flash memory 16 GB eMMC
Expansion slot microSD™ card, up to 32 GB
Camera
Camera resolution 12.1 MP
Digital zoom 16x
Photo flash No
Video recording Yes – HD 1080p
Video chat camera Yes
Front Camera Yes – HD 720p for video chat and 1.3 MP for camera capture
Sensors
Accelerometer Yes

White paper | Xperia™ ion
6 July 2012
* Values are according to GSM Association Battery Life Measurement Technique.
NOTE: Battery performance may vary depending on network conditions and configurations, and phone
usage.
Proximity sensor Yes
Ambient light sensor Yes
Magnetometer Yes
Gyroscope Yes
Networks
LT28at UMTS HSPA+ 850 (Band V), 1900 (Band II), 2100 (Band I)
GSM EDGE 850, 900, 1800, 1900
LTE Band IV and Band XVII
Data transfer speeds
GSM EDGE Up to 237 kbps
UMTS HSPA cat 6 (upload) Up to 5.8 Mbps
UMTS HSPA cat 14(download) Up to 21.1 Mbps
LTE cat3 Up to 50 Mbps (upload), up to 100 Mbps (download)
Talk time (GSM) Up to 10 hours*
Standby time (GSM) Up to 400 hours*
Talk time (UMTS) Up to 4 hours*
Standby time (UMTS) Up to 350 hours*
Music listening time Up to 12 hours*
Video playback time Up to 3 hours*
Embedded Battery 1900 mAh typical
1840 mAh minimum

White paper | Xperia™ ion
7 July 2012
Categorised feature list
Camera
3D Sweep Panorama™
12.1 megapixel camera
16x digital zoom
Auto focus
Face detection
Flash/Pulse LED
Front-facing camera (VGA)
Geotagging
HD video recording (1080p)
Image stabiliser
Red-eye reduction
Self-timer
Scene recognition
Send to web
Smile Shutter™
Sony Exmor R™ for mobile image
sensor
Sweep Panorama™
Sweep Multi Angle
Touch capture
Touch focus
Video light
Video recording
Music
Album art
Bluetooth™ stereo (A2DP)
Music tones (MP3/AAC)
Music Player
Shazam™ service*
xLoud™ Experience
Internet
Bookmarks
Google™ search*
Google Play™
Google Voice™ Search*
Google Maps™ for Mobile with
Navigation, Places and Lati-
tude™*
Pan & zoom
Web browser (WebKit™)
Communication
Call list
Facebook™ application*
Google Talk™ application*
Noise suppression
Polyphonic ringtones
Xperia™ Timescape™
Speakerphone
Twitter™ (Timescape™
integration)*
Xperia™ with Facebook™
Vibrating alert
Messaging
Conversations
Email
Gmail™*
Messaging
Multimedia messaging (MMS)
Predictive text input
Sound recorder
Text messaging (SMS)
Design
Auto rotation
Gesture input
Gyroscope
Keyboard (on-screen, QWERTY)
Reality Display with Sony Mobile
BRAVIA® ENGINE
Screenshot capturing
Wallpaper

White paper | Xperia™ ion
8 July 2012
* This service is not available in all markets.
Entertainment
3D Album
3D games
Accelerated Adobe Flash Video
Google Media Uploader
Media browser
Motion gaming
Radio (FM radio with RDS)
Sony Entertainment Networks*
TV launcher
YPmobile
YouTube™*
Organiser
Airplane mode
AT&T Address book
Alarm clock
Calculator
Calendar
Contacts
Document readers
eCompass™
Infinite button
LiveWare™ manager
Notes
OfficeSuite
Setup guide
Stopwatch
Tasks
Timer
Connectivity
3.5 mm audio jack (CTIA)
aGPS*
ANT+ sports fitness
Bluetooth™ wireless technology
DLNA Certified®
GLONASS*
HDMI support
Media Transfer Protocol support
Micro USB support
Native USB tethering
NFC
USB High speed 2.0 support
USB host
Wi-Fi®
Wi-Fi® Hotspot functionallity

White paper | Xperia™ ion
9 July 2012
Technologies in detail
NOTE: The information outlined below is general and levels of compliance to standards and specifications
may vary between products and markets. For more information, contact Sony Mobile Developer World or
your Sony contact person where applicable.
Device-to-device communications (local)
Bluetooth™ wireless technology
More information:
http://developer.sonymobile.com/wp
www.bluetooth.com
Bluetooth™ profiles supported Advanced Audio Distribution Profile v1.2
Audio/Video Remote Control Profile v1.0
Handsfree Profile v1.5
Headset Profile v1.1
Object Push Profile v1.1
Phonebook Access Profile v1.0
Core version and supported
core features
Advanced Audio 2.1 + EDR
Connectable devices Products supporting at least one of the profiles above.

White paper | Xperia™ ion
10 July 2012
Wi-Fi®
Supported standards IEEE 802.11b/g/n and Wi-Fi®
Connectable devices Wi-Fi®access points
Frequency band 2.4 GHz
Data transfer rate Up to 72 Mbit/s
Security WEP 64 bit
WEP 128 bit
TKIP
CCMP (AES)
Open Authentication
Shared Authentication
EAP-SIM
EAP-TLS
EAP-TTLS/MSCHAPv2
PEAPv0/EAP-MSCHAPv2
PEAPv1/EAP-GTC
WPA Personal and WPA2 Personal
WPA Enterprise and WPA2 Enterprise
Encryption WEP, TKIP and AES
Power save WMM-UAPSD
QoS, WMM

White paper | Xperia™ ion
11 July 2012
DLNA Certified® (Digital Living Home Alliance)
Supported Device Classes M-DMS – Mobile Digital Media Server
Media Types: images
Summary: The digital media server exposes the media
files in your phone to a Wi-Fi® network. The files can
then be accessed from other DLNA Certified® clients.
+PU+
Media Types: image, video and music
Summary: Play media in the phone on another device,
such as a TV or computer using 2 box push technology.
+PU+ is integrated in the Gallery and Music applications.
M-DMP – Mobile Digital Media Player
Media Types: image, video and music
Summary: Play content stored on another device, for
example, a server or a PC, directly on the phone.
Supported Bearers Wi-Fi®
DRM Support The DLNA Certified® implementation does not support
DRM-protected content.

White paper | Xperia™ ion
12 July 2012
Messaging
MMS (Multimedia Messaging Service)
According to OMA Multimedia Messaging Service v1.0 + SMIL
Email
More information:
http://developer.sonymobile.com/wp
www.openmobilealliance.org
Bearer type (IP) GPRS, EGPRS, UMTS
Character sets BIG5 Traditional Chinese
GB18030
ISO-2022-JP Japanese
ISO-8859-1
ISO-8859-2 Eastern Europe
ISO-8859-5 Cyrillic
ISO-8859-7 Greek
ISO-8859-9 Turkish
ISO 8859-11
KOI8-R Cyrillic
Shift_JIS Japanese
USASCII
UTF-16
UTF-8
Windows® 874
Windows® 1251 Cyrillic
Windows® 1252
Windows® 1254 Turkish
Windows® 1258 Vietnamese
Protocols POP3 and IMAP4
Push email Microsoft® Exchange ActiveSync® (EAS)
Secure email SSL/TLS, both port methods (POPS/IMAPS) and START-
TLS
HTML mail Yes (read only)

White paper | Xperia™ ion
13 July 2012
Positioning – location based services
Supported standards:
• OMA Secure User Plane Location (SUPL) v1.0
• 3GPP™ Control Plane location (incl. Emergency location)
• Qualcomm® GPSOneXtra™
Supported satellite systems:
•GPS
• GLONASS*
* NOTE: GPS and GLONASS are used together to calculate the position. Positioning is more robust and
accurate in most conditions, if both systems are active. The benefits of using GLONASS are automatically
available for all applications using the Satellite Positioning API ("GPS Provider" in Android terminology).
Provisioning (OMA CP)
OMA CP version 1.1

White paper | Xperia™ ion
14 July 2012
Multimedia (audio, image and video)
Audio Playback Decoder format Supported in file format
Audio decoding MPEG-1/2/2.5,
audio layer 3
MP3 (.mp3), 3GPP (.3gp),
MP4 (.mp4, .m4a)
AAC, AAC+, eAAC+ 3GPP (.3gp), MP4 (.mp4)
AMR-NB, AMR-WB 3GPP (.3gp)
General MIDI (GM) SMF (.mid)
Linear PCM 16bit WAV (.wav)
OTA OTA (.ota)
Ogg vorbis Ogg vorbis (.ogg)
Audio Recording Encoder format Supported in file format
AMR-NB, AMR-WB 3GPP (.3gp), MP4 (.mp4),
AMR (.amr)
AMR-NB, AMR-WB, AAC-LC
stereo, sample rate 48 kHz bit rate
128 kbps
3GPP (.3gp), MP4 (.mp4)
Image Playback Decoder format Supported in file format
1, 4, 8, 16, 24 and 32 bpp and RLE
encoded formats
BMP (.bmp)
Single and multi-frame, bitmap
mask support (GIF87a format and
GIF89a format)
GIF (.gif)
Joint Photographic Experts Group JPEG (.jpg)
Portable Network Graphics Bitmap
mask support
PNG (.png)
Wireless Bitmap WBMP (.wbmp)
Image Capture Encoder format Supported in file format
Joint Photographic Experts Group JPEG (.jpg)
Video Playback Decoder format Supported in file format
MPEG-4 Simple Profile Level 6,
Advanced Simple Profile Level 5
3GPP (.3gp), MP4 (.mp4)
H.264 High Profile Level 3.2 3GPP (.3gp), MP4 (.mp4)
H.263 Profile 0 Level 70 3GPP (.3gp)

White paper | Xperia™ ion
15 July 2012
Synchronisation (OMA DS, EAS, Google Sync™)
OMA Data Synchronisation protocol versions 1.1.2 and 1.2
OMA Data Formats: vCard 2.1, vCalendar 1.0
Microsoft® Exchange ActiveSync® protocol version 2.5
Microsoft® Exchange ActiveSync® protocol version 12
Microsoft® Exchange ActiveSync® protocol version 12.1
Google Sync™
Related information:
http://developer.sonymobile.com/wp
Video Recording Encoder format Supported in file format
Video H.263 Profile 0, H.264
Baseline Profile
Audio: AAC-LC stereo, sample rate
48 kHz bit rate 128 kbps, AMR-NB
3GPP (.3gp), MP4 (.mp4)
Audio/Video Streaming Streaming transport RTSP according to 3GPP™
HTTP streaming
DRM DRM (Digital Rights Management) –
features the rights and copy
protection of downloaded content
OMA DRM 1.0 Marlin DRM

White paper | Xperia™ ion
16 July 2012
Web browser
* Updates are distributed via Android market™.
Related information:
http://developer.sonymobile.com/wp
Browser version Android 2.3 Browser (Based on WebKit™)
Navigation/rendering Adobe™ Flash™ 11*
Full page PC rendering
Landscape/portrait rendering
Pan & Zoom
Sharing links using NFC
Search Internet Search
Browser compliancy CSS 2.0
CSS 2.1
CSS 3.0
DOM 2.0
DOM 3.0
HTML version. 4.0
HTML version. 5.0
JavaScript 1.7/ECMA-script 262 3rd edition
WebGL 1.0
XHTML Basic version 1.0
XHTML 1.1
Supported Device API Geo-location API
Protocol compliancy Gzip
HTTP/1.1
OMA Download 1.0
TLS 1.0 and SSL 3.0

White paper | Xperia™ ion
17 July 2012
Trademarks and acknowledgements
All product and company names mentioned herein are the trademarks or registered trademarks of their
respective owners. Any rights not expressly granted herein are reserved. All other trademarks are property
of their respective owners.
Visit www.sonymobile.com for more information.
