SERVICE MANUAL
Revision History
Published by Sony Techno Create Corporation
Sony Corporation
LEVEL 3
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
Check the SERVICE NOTE (LEVEL 2) before the service.
983477311.pdf
Digital HD Video Camera Recorder
The components identified by mark
0or dotted line with mark 0are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-834-773-11
Ver. Date History Contents S.M. Rev.
issued
1.0 2014.01 Official Release — —
2014A08-1
© 2014.01
MODEL GROUP
Projector Model: PJ530E/PJ540/PJ540E/PJ610E
Non Projector Model: CX530E/CX535/CX610E
Ver. 1.0 2014.01
Photo: HDR-PJ540/BROWN
US Model
Canadian Model
AEP Model
UK Model
North European Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
HDR-CX530E/CX535/CX610E/PJ530E/
PJ540/PJ540E/PJ610E
Distinguishing MM-102 Boards (HDR-CX610E/PJ610E)
Three types of MM-102 board are used in this unit.
When repairing an MM-102 board, identify its type by the IC model names printed on the surface of IC8101 and IC8201 on the MM-102 board.
IC8101 IC8201
Type A KLMBG4WE4A-A001T01 KLMBG4WE4A-A001T01
Type B THGBM7G8T4JBAIRH10 THGBM7G8T4JBAIRH10
Type C KLMCG8WE4A-A001T01 No Mount
Note:
IC8101 and IC8201 cannot be replaced with any other type of IC. Be sure to replace them with the same type of IC.
When replacing Type A or Type B of IC8101 and IC8201, be sure to replace IC8101 and IC8201 together.

– 2 –
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
1. 注意事項をお守りください。
 サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書き及び取扱説明書等の注
意事項を必ずお守り下さい。
2. 指定部品のご使用を
 セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用して下さい。特に回路図，部
品表に0印で指定されている安全上重要な部品は必ず指定
のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
 安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにして下さい。
4. サービス後は安全点検を
 サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認して下さい。
5. チップ部品交換時の注意
 ・ 取外した部品は再使用しないで下さい。
 ・ タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
 ・ 半田こてのこて先温度は約350℃に設定してください。
 ・ 同一パターンに何度もコテ先を当てないで下さい。（3回
以内）
 ・ パターンに力が加わらないよう注意して下さい。
サービス，点検時には次のことにご注意ください。
– ENGLISH – – JAPANESE –
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350 °C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
 温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
 注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
 無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため, セットに付いている部品と異なる場
合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference num-
ber, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
1-889-592-11 AN-1006 FLEXIBLE BOARD (EXCEPT CX535)
*********************
A-1903-090-A CM-1004 BOARD, COMPLETE
***********************
(CP001 is not supplied, but this is included in CM-1004 COMPLETE BOARD.)
< CAPACITOR >
C6703 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6708 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6709 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6710 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6711 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6712 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6713 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C6714 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6715 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
C6716 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6717 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6718 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6720 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6728 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6729 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C6743 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6745 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
*CN6702 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
< COMPOSITION CIRCUIT BLOCK >
CP001 (Not supplied) IMX167CQL-13
< IC >
IC6703 6-715-211-01 IC MM3404A28URE
< RESISTOR >
R6707 1-218-973-11 METAL CHIP 47K 5% 1/16W
1-887-155-11 FP-2060 FLEXIBLE BOARD (EXCEPT CX530E)
*********************
A-1903-100-A FP-2106 FLEXIBLE BOARD, COMPLETE
(Projector Model)
******************************
< CONNECTOR >
CN5503 1-842-687-11 CONNECTOR, BOARD TO BOARD 42P
A-1919-696-A FP-2125 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
CN0001 1-816-655-61 CONNECTOR, FFC/FPC 8P
CN0002 1-816-655-61 CONNECTOR, FFC/FPC 8P
A-1919-697-A FP-2126 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
*CN0004 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
*CN0005 1-842-269-11 CONNECTOR, FPC (ZIF) 23P
1-889-183-11 FP-2189 FLEXIBLE BOARD
*********************
1-889-185-11 FP-2191 FLEXIBLE BOARD
*********************
1-889-186-11 FP-2192 FLEXIBLE BOARD (Non Projector Model)
*********************
1-889-187-11 FP-2193 FLEXIBLE BOARD (Projector Model)
*********************
1-889-209-11 FP-2200 FLEXIBLE BOARD (EXCEPT CX535)
*********************
A-1992-201-A FP-2214 BOARD, COMPLETE
***********************
(CN002 is not supplied, but this is included in FP-2214 FLEXIBLE COMPLETE
BOARD.)
< CONNECTOR >
CN002 (Not supplied) CONNECTOR (SHOE)
A-2043-894-A JK-1009 BOARD, COMPLETE (SERVICE)
*******************************
(C8830 and IC3000 are not supplied, but they are included in JK-1009 COMPLETE
BOARD (SERVICE).)
(BT4200 is not included in JK-1009 COMPLETE BOARD (SERVICE).)
< BATTERY HOLDER >
BH4200 1-251-928-21 SOCKET, BATTERY
< BATTERY >
BT4200 1-756-134-15 BATTERY, LITHIUM (SECONDARY)
2-2. ELECTRICAL PARTS LIST
Note1 : イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換し
てください。
使用済み電池は，取扱指示に従って処分してください。
Note 2: Replace the battery holder (BH4200) together when replac-
ing the lithium storage battery (BT4200) on the JK-1009
board. (The battery holder removed once cannot be used
again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: JK-1009基板のリチウム蓄電池（BT4200）を交換する場合
はバッテリホルダ（BH4200）も同時に新品に交換して下さ
い。（一度使用したバッテリホルダは再使用できません。）
部品 取り付けの際は， 先にバッテリホルダを取り付けてか
らリチウム電池を装着して下さい。
Note1 : Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
AN-1006 CM-1004 FP-2060 FP-2106 FP-2125 FP-2126 FP-2189 FP-2191 FP-2192 FP-2193 FP-2200 FP-2214 JK-1009
印の部品には、秘密情報が含まれています。
修理の際は、指示に従った対応を行ってください。
交換後の対象基板及び対象ICは、破壊のうえ廃棄してください。
The components identified by mark contain confidential information.
Strictly follow the instructions whenever the components are re-
paired and/or replaced.
Destroy and discard the prescribed board and IC after they are
replaced.
Les composants identifiés par le symbole contiennent des infor-
mations confidentielles.
Suivez scrupuleusement les instructions chaque fois qu'un com-
posant est remplacé et / ou réparé.
Veuillez détruire et éliminer les circuits imprimés et / ou les circuits
intégrés que vous avez remplacés.
标识有 的元件包含机密信息。
更换或维修元件时，请严格遵守指⽰。
更换后的电路板和IC，应予以报废。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

2-2
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
< CAPACITOR >
*C2201 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*C2202 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*C3000 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C3400 1-128-617-91 CERAMIC CHIP 100PF 5% 25V
C3401 1-128-617-91 CERAMIC CHIP 100PF 5% 25V
*C3402 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C3403 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7701 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7702 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C7703 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7704 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7705 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7706 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8830 (Not supplied) CERAMIC CHIP 0.22uF 20% 6.3V
< CONNECTOR >
*CN3001 1-816-647-61 FFC/CONNECTOR, FPC (LIF) 18P
CN4200 1-842-897-11 CONNECTOR, FPC (ZIF) 45P
< FERRITE BEAD >
FB3400 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB3401 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB3402 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB3403 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
*IC2201 6-719-361-01 IC MM3416A28URE
IC3000 (Not supplied) IC TC7SZ32FU, RSONYJ
< JACK >
J3400 1-793-703-21 JACK (DIA. 3.5)
J3401 1-818-055-21 JACK
< TRANSISTOR >
*Q3000 6-552-354-01 TRANSISTOR DRC3144E0L
Q3001 8-729-053-57 TRANSISTOR RN1902FE
*Q3002 6-552-348-01 TRANSISTOR DRC3114E0L
*Q3400 6-552-354-01 TRANSISTOR DRC3144E0L
Q8830 6-550-576-01 TRANSISTOR SSM6E01TU
< RESISTOR >
R3000 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3400 1-694-535-91 SHORT CHIP 0
R3401 1-218-934-11 RES, CHIP 27 (1005)
R3402 1-218-934-11 RES, CHIP 27 (1005)
R8830 1-240-718-91 METAL CHIP 100K 5% 1/20W
R8831 1-240-695-91 METAL CHIP 1K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
*RB3000 1-234-938-21 RES, NETWORK 3.3K (1005X4)
< SENSOR >
SE7701 8-826-002-51 GYRO SENSOR GSU-X370D/N-S (PITCH/YAW)
A-1992-197-A MM-102 BOARD, COMPLETE (CX535/PJ540/PJ540E)
A-1992-199-A MM-102 BOARD, COMPLETE (PJ530E)
A-2011-087-A MM-102 BOARD, COMPLETE (CX610E/PJ610E)
**********************
< CAPACITOR >
C8102 1-118-465-11 CERAMIC CHIP 4.7uF 10% 16V
C8103 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8104 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8202 1-118-465-11 CERAMIC CHIP 4.7uF 10% 16V
(CX610E/PJ610E (Type A, B))
C8203 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(CX610E/PJ610E (Type A, B))
C8204 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(CX610E/PJ610E (Type A, B))
*C8701 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
*CN8101 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
< IC >
*IC8101 6-719-919-01 IC KLMCG8WE4A-A001T01
(CX610E/PJ610E (Type C))
*IC8101 6-720-022-01 IC KLMBG4WE4A-A001T01 (CX535/PJ540/PJ540E)
*IC8101 6-720-022-01 IC KLMBG4WE4A-A001T01
(CX610E/PJ610E (Type A))
*IC8101 6-720-227-01 IC SDIN7DP2-4G-1029T (PJ530E)
*IC8101 6-721-326-01 IC THGBM7G8T4JBAIRH10
(CX610E/PJ610E (Type B))
*IC8201 6-720-022-01 IC KLMBG4WE4A-A001T01
(CX610E/PJ610E (Type A))
*IC8201 6-721-326-01 IC THGBM7G8T4JBAIRH10
(CX610E/PJ610E (Type B))
IC8701 6-716-442-11 IC MM3404A29URE
< RESISTOR >
R8101 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8103 1-218-990-81 SHORT CHIP 0
R8104 1-218-990-81 SHORT CHIP 0
R8105 1-218-990-81 SHORT CHIP 0
R8106 1-218-990-81 SHORT CHIP 0
R8107 1-218-990-81 SHORT CHIP 0
R8108 1-218-990-81 SHORT CHIP 0
R8109 1-218-990-81 SHORT CHIP 0
R8110 1-218-990-81 SHORT CHIP 0
R8112 1-218-990-81 SHORT CHIP 0
R8202 1-218-990-81 SHORT CHIP 0 (CX610E/PJ610E (Type A, B))
< COMPOSITION CIRCUIT BLOCK >
RB8101 1-242-962-21 RES, NETWORK 82 (1005X4)
RB8102 1-242-962-21 RES, NETWORK 82 (1005X4)
A-2011-100-A PD-1030 BOARD, COMPLETE (SERVICE)
(Non Projector Model)
*******************************
< CAPACITOR >
*C4700 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4707 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
C4708 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
*C8040 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8041 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8042 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8043 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8044 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
*C8045 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*C8046 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8047 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8048 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8049 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8050 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8051 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8052 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8053 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
*CN4700 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
*CN4702 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
*CN8040 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
< COIL >
*L4700 1-481-102-21 INDUCTOR 10uH
*L4701 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q8080 6-552-758-01 TRANSISTOR RN4986FE
Q8081 6-552-758-01 TRANSISTOR RN4986FE
< RESISTOR >
R4700 1-218-977-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB4700 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE4700 1-487-118-31 GMR SENSOR
A-2011-101-A PD-1031 BOARD, COMPLETE (SERVICE)
(Projector Model)
*******************************
(IC8010 is not supplied, but this is included in PD-1031 COMPLETE BOARD
(SERVICE).)
< CAPACITOR >
C3750 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
*C4800 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4807 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
C4808 1-118-395-11 CERAMIC CHIP 0.0047uF 10% 50V
*C8040 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8041 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8042 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8043 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C8044 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
*C8045 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*C8046 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8047 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8048 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8049 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8050 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C8051 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8052 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8053 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN3750 1-821-652-11 CONNECTOR, BOARD TO BOARD (REC
*CN4800 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
*CN4802 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
*CN8040 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
< FERRITE BEAD >
FB3750 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC8010 (Not supplied) IC BU79R272-E2
< COIL >
*L4801 1-481-102-21 INDUCTOR 10uH
*L4802 1-481-102-21 INDUCTOR 10uH
< TRANSISTOR >
Q8080 6-552-758-01 TRANSISTOR RN4986FE
Q8081 6-552-758-01 TRANSISTOR RN4986FE
< RESISTOR >
R3756 1-240-683-91 METAL CHIP 100 5% 1/20W
R4800 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4801 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4805 1-218-966-11 METAL CHIP 12K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB4801 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE4800 1-487-118-31 GMR SENSOR
A-1992-196-A PJ-1005 BOARD, COMPLETE (Projector Model)
***********************
(IC8504, IC8605, IC8801 and R8815 are not supplied, but they are included in PJ-1005
COMPLETE BOARD.)
< CAPACITOR >
*C8510 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C8540 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
*C8543 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C8545 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C8547 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
JK-1009 MM-102 PD-1030 PD-1031 PJ-1005

2-3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
C8548 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8549 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8551 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8552 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C8602 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C8603 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C8605 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8606 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C8607 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8609 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8610 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8618 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8619 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8627 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8628 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8701 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8703 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8710 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8801 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8803 1-118-037-11 CERAMIC CHIP 0.22uF 10% 25V
C8804 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C8805 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C8806 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8810 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
*C8814 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C8816 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8817 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8818 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8824 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
*CN8502 1-816-643-51 FFC/CONNECTOR, FPC (LIF) 10P
CN8503 1-822-395-51 CONNECTOR, BOARD TO BOARD 60P
CN8504 1-842-897-11 CONNECTOR, FPC (ZIF) 45P
< DIODE >
D8501 6-503-126-01 DIODE DA2S10100K8
D8801 6-502-934-01 DIODE DB2S31100K8
< IC >
IC8504 (Not supplied) IC MM3411A10URE
IC8605 (Not supplied) IC DPP2601
*IC8606 6-720-178-01 IC W25X40CLPYB1
*IC8701 6-721-275-01 IC W948D6FBHX5E-ER25
IC8801 (Not supplied) IC PAD1000YFFR
< COIL >
L8801 1-481-035-11 INDUCTOR 10uH
L8802 1-457-526-11 INDUCTOR 2.2uH
< TRANSISTOR >
Q301 6-550-576-01 TRANSISTOR SSM6E01TU
< RESISTOR/FERRITE >
R8518 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R8519 1-220-398-11 METAL CHIP 1.5M 5% 1/16W
R8520 1-218-968-11 METAL CHIP 18K 5% 1/16W
R8521 1-218-967-11 METAL CHIP 15K 5% 1/16W
R8522 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8523 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8611 1-218-941-81 METAL CHIP 100 5% 1/16W
R8612 1-250-567-11 METAL CHIP 1M 1% 1/16W
R8620 1-218-935-11 METAL CHIP 33 5% 1/16W
R8621 1-218-935-11 METAL CHIP 33 5% 1/16W
R8633 1-481-984-21 EMI FERRITE (SMD)(1005)
R8702 1-218-971-11 METAL CHIP 33K 5% 1/16W
R8813 1-218-977-11 METAL CHIP 100K 5% 1/16W
R8815 (Not supplied) METAL CHIP 0.1 1% 0.12W
R8818 1-218-953-11 METAL CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB8601 1-234-381-11 RES, NETWORK 100K (1005X4)
RB8603 1-234-381-11 RES, NETWORK 100K (1005X4)
RB8604 1-234-381-11 RES, NETWORK 100K (1005X4)
< VIBRATOR >
X8601 1-814-480-11 QUARTZ CRYSTAL OSCILLATOR (16.66667MHz)
A-1992-249-A VC-1025 BOARD, COMPLETE (SERVICE)
(Non Projector Model)
A-1992-250-A VC-1025 BOARD, COMPLETE (SERVICE)
(Projector Model)
*******************************
(C1105, C1112, C1113, C1116, C1117, C1119, C1120, C1121, C1122, C3509, C4012,
C5102, C5152, C5207, C5500, C5600, C5651, C5652, C5701, C5702, C5703, C5704,
C5712, C5714, C5715, C6801, C6804, C6805, C6808, C6809, C7711, C7715, C8509,
C8510, C8511, C8512, C8513, C8514, C8524, CN0500, ET4012, ET4013, IC5100,
IC5150, IC5500, IC5651, IC5700, IC6000, IC6741, IC6742, IC7711, IC8000, IC8120,
IC8201, IC8501, L5150, R3303, R5100, R5201, R6062, R6120, R6121, R6123, R6124,
R6125, R7711, R7712, R7713, R7714, R7715 and SE7711 are not supplied, but they
are included in VC-1025 COMPLETE BOARD (SERVICE).)
< CAPACITOR >
C0102 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C0104 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C0160 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C0300 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
*C1041 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1061 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1062 1-128-613-91 CERAMIC CHIP 47PF 5% 25V
(Non Projector Model)
*C1081 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1082 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C1101 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C1105 (Not supplied) CERAMIC CHIP 10uF 20% 6.3V
C1112 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1113 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1116 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1117 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1119 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1120 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1121 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1122 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C1400 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1401 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C1402 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C1403 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
*C3351 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C3505 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C3507 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C3509 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
*C3510 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4012 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5100 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5101 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5102 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C5103 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5104 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5105 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5106 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5107 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5108 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5109 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5110 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5111 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5112 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5114 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5116 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C5117 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5118 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5120 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C5151 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5152 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5153 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5154 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
*C5200 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5201 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
*C5202 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5203 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C5204 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5205 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5207 (Not supplied) CERAMIC CHIP 4.7uF 20% 6.3V
C5208 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5209 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5300 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5301 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5500 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5501 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5600 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5630 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5631 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5650 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5651 (Not supplied) CERAMIC CHIP 0.22uF 10% 6.3V
C5652 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5653 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5654 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5655 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5656 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5657 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5658 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5700 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5701 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5702 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5703 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5704 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5705 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5707 1-128-606-91 CERAMIC CHIP 15PF 5% 25V
C5708 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5709 1-128-606-91 CERAMIC CHIP 15PF 5% 25V
C5710 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C5711 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C5712 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5714 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5715 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6002 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6005 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6006 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6007 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6010 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6020 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6022 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6023 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6060 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6061 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6062 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6063 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6065 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6066 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6067 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6102 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6122 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6123 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6124 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6126 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6127 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6128 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6132 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6133 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6140 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C6741 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6742 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C6744 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
*C6800 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6801 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C6802 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6803 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6804 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C6805 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C6806 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6807 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C6808 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6809 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C6814 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6815 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6816 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6817 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6818 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6819 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6843 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
*C7101 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7102 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7711 (Not supplied) CERAMIC CHIP 0.33uF 10% 6.3V
PJ-1005 VC-1025

2-4
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
C7712 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C7713 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7714 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C7715 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C7717 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7718 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C7719 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8120 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8121 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8122 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8123 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8124 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
C8201 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C8203 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8204 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
C8205 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
(Projector Model)
*C8206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8207 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8209 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
*C8211 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
(Projector Model)
C8500 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8501 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8503 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8504 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8505 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8506 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8507 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8508 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8509 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8510 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8511 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8512 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8513 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8514 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8515 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8516 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8517 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8518 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8519 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8520 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8521 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C8522 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C8523 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C8524 (Not supplied) CERAMIC CHIP 0.0047uF 10% 6.3V
C8525 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C8526 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8527 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8630 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8632 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8800 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
*CN0400 1-843-120-21 HEADER ASSEMBRY
CN0500 (Not supplied) SOCKET, USB CONNECTOR
CN3201 1-843-066-11 CONNECTOR, HDMI (Projector Model)
CN4001 1-842-897-11 CONNECTOR, FPC (ZIF) 45P
*CN4003 1-819-781-61 CONNECTOR, FPC (ZIF) 45P
CN4004 1-819-934-61 CONNECTOR, FPC (ZIF) 39P
*CN4005 1-816-644-51 FFC/CONNECTOR, FPC (LIF) 12P
*CN4006 1-816-647-61 FFC/CONNECTOR, FPC (LIF) 18P
CN4007 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN4008 1-770-619-21 PIN, CONNECTOR 2P
CN4009 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN4010 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
CN4011 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
*CN4901 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
*CN4902 1-816-650-51 FFC/CONNECTOR, FPC (LIF) 24P
CN7101 1-843-144-21 CONNECTOR, CARD MSMICRO/SDMICR
CN9000 1-843-066-11 CONNECTOR, HDMI
< DIODE >
D0100 6-503-126-01 DIODE DA2S10100K8
D4010 6-501-216-01 DIODE CL-271HR-C-TS
D5600 8-719-421-71 DIODE MA132WA
D6081 6-503-126-01 DIODE DA2S10100K8
D6082 6-503-126-01 DIODE DA2S10100K8
D8800 6-503-126-01 DIODE DA2S10100K8
*D9000 6-502-988-01 DIODE RB480Y-40T2R
< CONTACT TERMINAL >
ET4012 (Not supplied) IPS-4039T-01Y901
ET4013 (Not supplied) TERMINAL, CONTACT
< FUSE >
F001 1-576-415-31 FUSE (2A/32V)
F002 1-576-415-31 FUSE (2A/32V)
F003 1-576-406-31 FUSE (1.4A/32V)
*F004 1-576-872-31 FUSE (0.25A/50V)
F005 1-523-231-31 FUSE (2.5A/50V)
< FERRITE BEAD >
FB0500 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB0501 1-400-331-11 FERRITE, EMI (SMD) (1005)
*FB1003 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1061 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
(Non Projector Model)
FB1062 1-400-833-21 SMD EMI FERRITE
FB1083 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
*FB1084 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB3300 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
(Projector Model)
FB3350 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3351 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3352 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3353 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3354 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3355 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3356 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3357 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3358 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3359 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3360 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3361 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3362 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3363 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3364 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
FB3365 1-400-921-21 FERRITE, EMI (SMD) (Non Projector Model)
*FB6080 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB6081 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC5100 (Not supplied) IC BD8336GU-E2
IC5150 (Not supplied) IC TPS63060DSCR
IC5200 6-716-945-01 IC BD8331GU-E2
IC5300 6-718-155-01 IC R1207N823B-TR-FE
IC5500 (Not supplied) IC BD2224G-BZTR
IC5600 6-716-783-01 IC BD11600NUX-E2
*IC5630 6-714-833-01 IC TPS2553DBVR-1
IC5651 (Not supplied) IC OZ8072PN-C5-0-TR
IC5700 (Not supplied) IC MB9AF004BGL-G-103-ERE1
IC6000 (Not supplied) IC KSZ4G4G01A
IC6741 (Not supplied) IC DRV8835DSSR
IC6742 (Not supplied) IC LV8417CS-TE-L-H
IC6800 6-716-760-01 IC R2J30503LG
*IC6802 6-719-361-01 IC MM3416A28URE
IC7711 (Not supplied) IC NJM3232MG2 (TE2)
IC8000 (Not supplied) IC BU79T272-E2 (Projector Model)
IC8120 (Not supplied) IC MB8AA4590BGL-G-ERE1 (Projector Model)
*IC8200 6-721-219-01 IC ADV7610BBCZ-RL (Projector Model)
IC8201 (Not supplied) IC MM3416A33URE
*IC8500 6-719-793-01 IC AK4695ECB-L
IC8501 (Not supplied) IC MM3411A28URE
IC8630 6-718-186-01 IC CS48L10-CWZR
< COIL >
*L0101 1-457-858-11 INDUCTOR 4.7uH
L0102 1-460-370-11 INDUCTOR 10uH
L0103 1-460-370-11 INDUCTOR 10uH
L0105 1-460-370-11 INDUCTOR 10uH
L0106 1-460-359-11 INDUCTOR 4.7uH
*L0107 1-457-690-11 INDUCTOR 33uH
L1061 1-469-757-21 INDUCTOR 10uH
L1063 1-414-842-21 INDUCTOR 15nH
L1064 1-414-842-21 INDUCTOR 15nH
L3501 1-400-588-11 INDUCTOR 10uH
L5150 (Not supplied) INDUCTOR 2uH
L5650 1-460-358-11 INDUCTOR 2.2uH
*L9000 1-460-611-11 COMMON MODE CHOKE COIL
*L9001 1-460-611-11 COMMON MODE CHOKE COIL
< LINE FILTER >
LF0400 1-457-223-11 COMMON MODE CHOKE COIL
LF0500 1-457-223-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q0201 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q0202 8-729-055-01 TRANSISTOR RN4984FE
Q0300 6-552-842-01 TRANSISTOR QS8J2FU7TR
*Q1101 6-552-344-01 TRANSISTOR DRA3143T0L
Q3201 6-551-202-01 TRANSISTOR LM6K1FS8T2R
(Projector Model)
Q4010 6-551-626-01 TRANSISTOR RN2110MFV (TL3S
*Q4013 6-552-397-01 TRANSISTOR DSC300100L
*Q5600 6-552-529-01 TRANSISTOR DMC964010R
Q5700 6-552-999-01 TRANSISTOR RW1E025RPT2CR
Q5701 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q5702 6-553-038-01 TRANSISTOR DRA3115T0L
*Q7101 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q8800 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q8801 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
Q9000 6-551-202-01 TRANSISTOR LM6K1FS8T2R
*Q9001 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9002 8-729-055-01 TRANSISTOR RN4984FE
< RESISTOR >
R0160 1-240-711-91 METAL CHIP 22K 5% 1/20W
R0205 1-240-718-91 METAL CHIP 100K 5% 1/20W
*R0207 1-257-309-11 METAL CHIP 1M 1% 1/20W
*R0208 1-257-309-11 METAL CHIP 1M 1% 1/20W
*R0209 1-257-301-11 METAL CHIP 470K 1% 1/20W
*R0210 1-257-301-11 METAL CHIP 470K 1% 1/20W
R0412 1-218-990-81 SHORT CHIP 0
R0413 1-218-990-81 SHORT CHIP 0
R1006 1-240-678-91 METAL CHIP 33 5% 1/20W
*R1062 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R1063 1-218-990-81 SHORT CHIP 0 (Projector Model)
*R1066 1-250-469-11 METAL CHIP 82 1% 1/16W
R1070 1-218-990-81 SHORT CHIP 0
R1080 1-240-679-91 METAL CHIP 47 5% 1/20W
R1081 1-240-679-91 METAL CHIP 47 5% 1/20W
R1082 1-240-707-91 METAL CHIP 10K 5% 1/20W
R1083 1-240-683-91 METAL CHIP 100 5% 1/20W
R1084 1-240-685-91 METAL CHIP 150 5% 1/20W
R1085 1-240-683-91 METAL CHIP 100 5% 1/20W
R1086 1-240-683-91 METAL CHIP 100 5% 1/20W
R1088 1-240-679-91 METAL CHIP 47 5% 1/20W
R1089 1-240-679-91 METAL CHIP 47 5% 1/20W
R1094 1-240-679-91 METAL CHIP 47 5% 1/20W
R1095 1-240-679-91 METAL CHIP 47 5% 1/20W
R1096 1-240-679-91 METAL CHIP 47 5% 1/20W
R1097 1-240-679-91 METAL CHIP 47 5% 1/20W
R1098 1-240-679-91 METAL CHIP 47 5% 1/20W
R1099 1-240-679-91 METAL CHIP 47 5% 1/20W
R1101 1-218-945-11 METAL CHIP 220 5% 1/16W
R1106 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1108 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1109 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1118 1-240-683-91 METAL CHIP 100 5% 1/20W
R1119 1-240-683-91 METAL CHIP 100 5% 1/20W
R1401 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1402 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1416 1-240-714-91 METAL CHIP 47K 5% 1/20W
R3100 1-240-695-91 METAL CHIP 1K 5% 1/20W
R3201 1-218-953-11 METAL CHIP 1K 5% 1/16W
(Projector Model)
VC-1025

Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
2-5E
R3202 1-218-977-11 METAL CHIP 100K 5% 1/16W
(Projector Model)
R3303 (Not supplied) METAL CHIP 240 1% 1/20W
(Projector Model)
R3501 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R4016 1-218-989-11 METAL CHIP 1M 5% 1/16W
R4018 1-218-945-11 METAL CHIP 220 5% 1/16W
R4019 1-218-945-11 METAL CHIP 220 5% 1/16W
R4020 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4021 1-240-695-91 METAL CHIP 1K 5% 1/20W
R4025 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
(Projector Model)
R4025 1-240-707-91 METAL CHIP 10K 5% 1/20W
(Non Projector Model)
R4029 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
R4030 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
(Projector Model)
R4033 1-240-707-91 METAL CHIP 10K 5% 1/20W
R4034 1-240-707-91 METAL CHIP 10K 5% 1/20W
R4901 1-240-711-91 METAL CHIP 22K 5% 1/20W
(Non Projector Model)
R4901 1-694-535-91 SHORT CHIP 0 (Projector Model)
R4904 1-240-714-91 METAL CHIP 47K 5% 1/20W
R4905 1-240-718-91 METAL CHIP 100K 5% 1/20W
(Non Projector Model)
R4907 1-694-535-91 SHORT CHIP 0
R5100 (Not supplied) METAL CHIP 47K 1% 1/20W
*R5150 1-250-546-11 METAL CHIP 130K 1% 1/16W
R5151 1-250-519-11 METAL CHIP 10K 1% 1/16W
R5200 1-218-941-81 METAL CHIP 100 5% 1/16W
R5201 (Not supplied) METAL CHIP 100K 1% 1/20W
*R5202 1-257-273-11 METAL CHIP 33K 1% 1/20W
R5300 1-250-449-11 METAL CHIP 12 1% 1/16W
R5301 1-250-449-11 METAL CHIP 12 1% 1/16W
R5500 1-240-707-91 METAL CHIP 10K 5% 1/20W
R5600 1-240-714-91 METAL CHIP 47K 5% 1/20W
R5630 1-240-711-91 METAL CHIP 22K 5% 1/20W
*R5631 1-257-267-11 METAL CHIP 18K 1% 1/20W
R5650 1-240-679-91 METAL CHIP 47 5% 1/20W
*R5654 1-250-503-11 METAL CHIP 2.2K 1% 1/16W
R5655 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5656 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5701 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R5702 1-240-697-91 METAL CHIP 1.5K 5% 1/20W
R5711 1-240-711-91 METAL CHIP 22K 5% 1/20W
R5712 1-240-677-11 METAL CHIP 27 5% 1/20W
R5713 1-240-677-11 METAL CHIP 27 5% 1/20W
R6001 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6002 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6041 1-240-695-91 METAL CHIP 1K 5% 1/20W
*R6060 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
*R6061 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
R6062 (Not supplied) METAL CHIP 12K 1% 1/20W
R6081 1-240-683-91 METAL CHIP 100 5% 1/20W
R6082 1-240-683-91 METAL CHIP 100 5% 1/20W
R6084 1-240-683-91 METAL CHIP 100 5% 1/20W
R6085 1-240-684-91 METAL CHIP 120 5% 1/20W
R6120 (Not supplied) METAL CHIP 240 1% 1/20W
R6121 (Not supplied) METAL CHIP 240 1% 1/20W
R6123 (Not supplied) METAL CHIP 240 1% 1/20W
R6124 (Not supplied) METAL CHIP 10K 1% 1/20W
R6125 (Not supplied) METAL CHIP 10K 1% 1/20W
R6800 1-240-812-11 METAL CHIP 15K 0.5% 1/20W
R6801 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6802 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6803 1-240-707-91 METAL CHIP 10K 5% 1/20W
R6804 1-240-707-91 METAL CHIP 10K 5% 1/20W
R7101 1-240-729-91 METAL CHIP 1M 5% 1/20W
R7711 (Not supplied) METAL CHIP 15K 1% 1/20W
R7712 (Not supplied) METAL CHIP 150K 1% 1/20W
R7713 (Not supplied) METAL CHIP 10K 1% 1/20W
R7714 (Not supplied) METAL CHIP 22K 1% 1/20W
R7715 (Not supplied) METAL CHIP 22K 1% 1/20W
R8500 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8501 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8502 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R8503 1-208-667-11 METAL CHIP 220 0.5% 1/16W
R8504 1-208-667-11 METAL CHIP 220 0.5% 1/16W
R8505 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R8506 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8507 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8508 1-240-722-91 METAL CHIP 220K 5% 1/20W
R8800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8801 1-250-567-11 METAL CHIP 1M 1% 1/16W
R9000 1-240-712-91 METAL CHIP 27K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
*RB0200 1-234-384-11 RES, NETWORK 1M (1005X4)
RB0500 1-234-381-11 RES, NETWORK 100K (1005X4)
RB1081 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB3100 1-234-380-21 RES, NETWORK 47K (1005X4)
RB3357 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3358 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3359 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3360 1-234-373-21 RES, NETWORK 220 (1005X4)
(Non Projector Model)
RB3502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Projector Model)
RB3503 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Non Projector Model)
*RB4000 1-234-384-11 RES, NETWORK 1M (1005X4)
RB4001 1-234-380-21 RES, NETWORK 47K (1005X4)
*RB4002 1-234-723-21 RES, NETWORK 75 (1005X4)
RB4010 1-234-372-11 RES, NETWORK 100 (1005X4)
(Non Projector Model)
RB4011 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
(Projector Model)
RB5700 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6080 1-200-051-21 RES, NETWORK 150 (1005X4)
RB6082 1-234-372-11 RES, NETWORK 100 (1005X4)
RB8201 1-234-380-21 RES, NETWORK 47K (1005X4) (Projector Model)
RB9000 1-234-375-21 RES, NETWORK 1K (1005X4)
< SENSOR >
*SE4010 1-487-118-31 GMR SENSOR (Projector Model)
*SE4011 1-487-118-31 GMR SENSOR (Non Projector Model)
SE7711 (Not supplied) SENSOR, ANGULAR VELOCITY
< VARISTOR >
VD0500 1-802-090-21 VARISTOR, CHIP
VD0501 1-802-090-21 VARISTOR, CHIP
VD0502 1-802-090-21 VARISTOR, CHIP
VD4018 1-802-090-21 VARISTOR, CHIP
< VIBRATOR >
X5700 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
X5701 1-814-304-11 VIBRATOR, CRYSTAL (12MHz)
*X6000 1-813-403-81 QUARTZ CRYSTAL OSCILLATOR (12MHz)
X8200 1-814-515-11 QUARTZ CRYSTAL OSCILLATOR (28.636363MHz)
(Projector Model)
A-1992-200-A WF-1004 BOARD, COMPLETE (EXCEPT CX535)
***********************
(C7402, CP7300, ET2301 and L2303 are not supplied, but they are included in WF-
1004 COMPLETE BOARD.)
< CAPACITOR >
*C2305 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2307 1-117-730-81 CERAMIC CHIP 1.2PF 0.1PF 16V
C7301 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7302 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7303 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7304 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7305 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C7401 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7402 (Not supplied) CERAMIC CHIP 100PF 1% 50V
< CONNECTOR >
CN2301 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
CN2302 1-794-375-21 PIN, CONNECTOR 2P
< COMPOSITION CIRCUIT BLOCK >
CP7300 (Not supplied) WLAN MODULE
< ON BOARD CONTACT >
ET2301 (Not supplied) ON BOARD CONTACT
< IC >
*IC7401 6-715-114-01 IC CXD9950AK
< COIL >
L2303 (Not supplied) INDUCTOR 3.3nH
< COMPOSITION CIRCUIT BLOCK >
RB7301 1-234-372-11 RES, NETWORK 100 (1005X4)
RB7302 1-234-372-11 RES, NETWORK 100 (1005X4)
VC-1025 WF-1004

4-1
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
SUBL_DINP4 - 7,
SUBL_DINN4 - 7,
SUBL_CLKINP/CLKINN
DOAP - DODP,
DOAM - DODM,
DCKP, DCKM
SENS_VD
SENS_HD
IC_6000_SENSXCS
IC_6000_SENSSI/SENSSO/SENSSCK
PDATA0 - 23 D0±, D1±
CN6702
H15
G15
AH14
AF15
D23
A5
INCK
E1
H3
G1
G2
V29
14
13
3
8, 9,
11, 12
IRIS
(SHUTTER)
LENS BLOCK (1/2) CM-1004 BOARD
CONTROL
SWITCH BLOCK
(PS45300)
FP-2189
FLEXIBLE
BOARD
XVS
XHS
XCLR
SDI, SDO, SCK
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(7/26 - 14/26)
IC6000
(1/3)
IC5700
VC-1025 BOARD (1/3)
CMOS
IMAGER
CP001
VIDEO
SELECTOR
(21/26)
IC8120
AUDIO DSP
(19/26)
IC8630
LCD SERIAL
INTERFACE
TRANSMITTER
(22/26)
IC8000
LCD_XHD
LCD_XVD A4
B4
LCD_CLK
LCD_XHD
LCD_XVD
IC_8120_CLK
LCD_XHD
LCD_XVD
LCD_CLK
LCD_DATEN LCD_DATEN
XCS_IC_8120
MISO_SDA
XCS_IC_8120
AV_SO/SCK
MISO_SDA
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
SDO_KJR SDO_KJR
Q1101
L13
K12
HSYNC_CS
VSYNC_WE G6
F5
PCLK
DATEN_CMD
XCS_LCD
CLK±
IC_6800_IC_6000_CLK
HDMI_RX_PDATA0 - 23 TMDS_DATA0± - 2±
HDMI
RECEIVER
(20/26)
IC8200
L4
L3
HDMI_RX_HSYNC
HDMI_RX_VSYNC F9
E9
TMDS_CLOCK±
DDCSDA_RX
DDCSCL_RX
SDO_IC_8120
BCK_OUT_IC_8120,
LRCK_OUT_IC_8120,
MCK_OUT_IC_8120
E1 XSYS_RST
XSYS_RST
XSYS_RST
XSYS_RST
I2C_SDA/SCK
B6
D1
A6
HDMI_RX_I2S/DE/VCK
HDMI_RX_MCLK/SCLK/LRCK
X6000
12MHz
LCD_R_0 - 7, LCD_G_0 - 7, LCD_B_0 - 7
LCD_R_0 - 7,
LCD_G_0 - 7,
LCD_B_0 - 7 LCD_G_0 - 7, LCD_B_0 - 7
OVERALL (4/4)
(PAGE 4-4)
2
OVERALL (3/4)
(PAGE 4-3)
5
OVERALL (2/4)
(PAGE 4-2)
4
OVERALL (2/4)
(PAGE 4-2)
3
18
17
1
3,5,6,8,9,11
12, 14
HPD
SWITCH
Q3201
CN3201
CN4901
42, 44,
54, 56
48, 50
TP_X
34
AV_SO/SCK
13
I2C_SDA/SCK
AV_SO/SCK
14
KEY_AD1
CN4005
XBB_RST
XBB_RST
7, 11
SDI0_SPDIF_IN_MAG
SDI1_MAG
SDI0_SPDIF_IN_KJR
SDI1_KJR
XCS_IC_8630
18, 21
TP_Y
8
TP_SEL1
30
PANEL_NOR/REV
12
PJ_TEMP_AD
PANEL_NOR/REV
TP_X
TP_Y
TP_SEL2
32
AV_SO/SCK
MISO_SDA
USB SELECT
(5/26)
IC5600
USB ACTIVE
SWITCH
Q5702
CN0500
CN9000
CN0400
MULTI
HDMI
OUT
USB_D+/-_MULTI
USB_D+/-_KJR
USB_SEL
USBVCC
AD_JACK_IN USB_ID, AD_JACK_IN,
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
POWER CONTROL
(3/26)
08
10
USB_ID
4
8
9
COMPO_VIDEOCOMPO_VIDEO
13
15
XRESET_REQ XRESET_REQ
XRESET_REQ
7
2, 311, 122, 3
DEBUG_UART0_TXD DEBUG_UART0_TXD
XPOWER_TACT_SW
XPOWER_TACT_SW
LED DRIVE
Q0201 XCHARG_LED
XCHARG_LED
SYS_DD_SI/SO/SCK
SYS_DD_SI/SO/SCK SYS_DD_SO/SCK
LANC_IC_ON
DC/DC CONVERTER
(1/26)
IC5100
DC/DC CONVERTER,
LANC DRIVER
(1/26)
IC5200
X5701
12MHz L9
L8
H11
G16
V13
X5700
32.768kHz L6
L5
BUILT-IN
USB CABLE
CHARGE
USB_D+/-_DWN
USB_D+/-_DWN
USB_D+/-_DWN
LANC_SI/SO
AV_SO/SCK
OVERALL (4/4)
(PAGE 4-4)
6
OVERALL (3/4)
(PAGE 4-3)
1
AUDIO_L_I/O,
AUDIO_R_I/O
PROJECTOR
IN
HDMI_TXCN/TXCP HDMI_TXCN/TXCP
HDMI_TX0SOP-TX2SOP, HDMI_TX0SON-TX2SON
15
17
18
3,5,6,8,9,11
12, 14
SDA HDMI_SDA
SCL
CEC
HotPlugDetect
HDMI_SCL
HDMI_CEC
HDMI_HPD
LEVEL SHIFT
Q9000
LEVEL SHIFT
Q9001
1 LEVEL SHIFT
Q9002
: VIDEO SIGNAL
: AUDIO SIGNAL
: VIDEO/AUDIO SIGNAL
XPANEL_POWER_ON
4
5
11
2
8, 9
SS
ZOOM_VR_AD
XPOWER_LED
8
6
XCE
14
13
3
9, 11,
12
17, 18,
21, 22,
25, 26,
29, 30,
33, 34
8
6
17, 18,
21, 22,
25, 26,
29, 30,
33, 34
CN4004
CLK_CMOS_IN_IMG
XFLASH_RST
SYS_DD_IC_5200_XCS
SYS_DD_IC_5100_XCS
KEY_AD1, SS,
ZOOM_VR_AD,
XPOWER_LED
TP_SEL1
XCS_LCD
38,39,41,42,44,45,47,48, 50,51,53,54,56,57,59,60
20
21
18
Projector Model
Projector Model
Non Projector Model
Non Projector Model
Non Projector Model
SDO_KJR/IC_8120
BCK_OUT_KJR/IC_8120,
LRCK_OUT_KJR/IC_8120,
MCK_OUT_KJR/IC_8120
PJ_RST, PAD_PROJ_ON,
PJ_TEMP_AD, I2C_SDA/SCK
PJ_RSTZ
PAD_PROJ_ON 36
20
XSYS_RST
PANEL OPEN/CLOSE
DETECT
(25/26)
Q4013
PANEL_O/C_GMR
XCS_DWN
DWN_SI/SO/SCK
XCS_DWN
DWN_SI/SO/SCK
XMSX_INS
XSD_INS
OVERALL (3/4)
(PAGE 4-3)
8
X8200
28.636363MHz
HPA
XPOWER_TACT_SW
XMSX_INS
XSD_INS
Projector Model: SE4010
Non Projector Model: SE4011
B6 XBB_RST

4-2
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-2. OVERALL BLOCK DIAGRAM (2/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
PJ-1005 BOARD
PD-1031 BOARD
FP-2106 FLEXIBLE
BOARD
15
PDATA16 - 23
B3 J14
DMD
CONTROL
(2/4)
IC8605
LCD SERIAL
INTERFACE
RECEIVER
(1/2)
IC8010
LED
DRIVE
(4/4)
IC8801
PDATA8 - 15
PDATA0 - 7
HSYNC_CS
13 VSYNC_WE
19 PCLK
9DATEN_CMD
33
DMD_SAC_BUS
30, 37
DMD_STRB/OEZ
21, 25
DMD_LOADB/SCTRL
19, 29
DMD_DCLK/BUS
LED_SEL0
LED_SEL1
PAD_RESETZ
SPI_CSZ0 FLASH
MEMORY
(2/4)
IC8606
3, 5
7
I2C_SDA/SCL
DMD_D0 - 11
32
29, 36
20, 24
18, 28
1, 2
LED_ANODE
3, 4
RED_CATHODE
9, 10
BLU_CATHODE
7, 8
GRN_CATHODE
6
PJ_TEMP_AD
PJ_TEMP_AD
PJ_TEMP_AD
PJ_TEMP_AD
DMD_D0 - 11
CN5503CN8504
CN8503
16
23, 25,
29, 31,
35, 37,
53, 55
LCD_DR0 - 7
G6
LCD_DG0 - 7
LCD_DG0 - 7
LCD_DB0 - 7
LCD_DB0 - 7
LCD_HD
LCD_HD
14
F5
B6
LCD_VD
LCD_VD
20
LCD_CK
LCD_CK
LCD_DR0 - 7
LCD_DG0 - 7
LCD_DB0 - 7
LCD_HD
LCD_VD
LCD_CK
XCS_LCD
AV_SO/SCK
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
TP_X
TP_Y
TP_R
TP_BOT
10
LCD_DATEN
LCD_DATEN
4, 6
8
I2C_SDA/SCL
I2C_SDA/SCL
CN3750
12
11
10
21 - 28
13 - 20
CN8040
CN8502
PROJECTOR
UNIT
X8601
16.66667MHz
TOUCH
PANEL
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
4
5, 6
CN4802
CN4800
Q8080, Q8081
4
1
2
5
TP_SEL1 TOUCH PANEL
INTERFACE
SE4800
PANEL
NORMAL/REVERSE
DETECT
(2/2)
44
18
40
38
20
39
41, 45
8, 10
31, 34
D0±, D1±
CLK±
XBB_RST_VC
FP-2193 FLEXIBLE
BOARD
PJ_TEMP_AD
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
I2C_SDA/SCL
TP_SEL1
22
D0±, D1±
CLK±
XBB_RST
PANEL_NOR/REV PANEL_NOR/REV
OVERALL (1/4)
(PAGE 4-1)
3
: VIDEO SIGNAL
08
41, 43,
47, 48,
49, 50,
54, 56
24, 26,
30, 32,
36, 38,
42, 44
SDRAM
(3/4)
IC8701
J15
K15
MEM0_CLK_N/P
MEM0_BA0/BA1
MEM0_LDM/UDM
MEM0_LDQS/UDQS
MEM0_CASZ/RASZ/CSZ
MEM0_CKE/WEZ
DPPSPI_DIN,
DPPSPI_DOUT,
DPPSPI_CLK
24, 26,
30, 32,
36, 38,
54, 56
42, 44,
47, 48,
49, 50,
53, 55
23, 25,
29, 31,
35, 37,
41, 43
H13
H14
MEM0_DQ0 - 15
MEM0_A0 - 12
SPI_CSZ1
DPP_CMP_OUT
DPP_CMP_PWM
17
4, 6,
12, 14
32
16
PJ_RSTZ
PAD_PROJ_ON 11
18
12
PJ_RSTZ
PAD_PROJ_ON
PJ_RSTZ
PAD_PROJ_ON_DPP
PJ_RSTZ
PAD_PROJ_ON PAD_PROJ_ON
PAD_PROJ_ON
PJ_RSTZ F4
DPPSPI_DIN,
DPPSPI_DOUT,
DPPSPI_CLK
DPPSPI_DIN,
DPPSPI_DOUT,
DPPSPI_CLK
PD-1030 BOARD
LCD_HD
LCD_VD
LCD_CLK
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
TP_X
TP_Y
TP_R
TP_BOT
12
11
13 - 20,
21 - 28
CN8040
TOUCH
PANEL
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
10
5, 6
CN4702
CN4700
Q8080, Q8081
4
1
2
5
TP_SEL1 TOUCH PANEL
INTERFACE
SE4700
PANEL
NORMAL/REVERSE
DETECT
42
40
28
41
43, 45
34
FP-2192 FLEXIBLE
BOARD
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
TP_SEL1
29
PANEL_NOR/REV PANEL_NOR/REV
3, 4,
6, 7,
9, 10,
12, 13,
15, 16,
18, 19,
21, 22,
24, 25
LCD_G_0 - 7,
LCD_B_0 - 7
LCD_G_0 - 7, LCD_B_0 - 7
33
36
LCD_XHD
LCD_XVD
LCD_CLK
4
OVERALL (1/4)
(PAGE 4-1)
4
Projector Model
Non Projector Model
4, 5,
8, 9,
12, 13,
14, 15,
16, 20,
24, 26
3, 4,
7, 8,
11, 12,
13, 14,
15, 19,
23, 25
DMD_SAC_BUS
DMD_STRB/OEZ
DMD_LOADB/SCTRL
DMD_DCLK/BUS

4-3
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-3. OVERALL BLOCK DIAGRAM (3/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
1
5
3
AUDIO
PROCESSOR
(23/26)
IC8500
Q3400
B3
HP_R_OUT
HP_L_OUT
AUDIO_L_I/O,
AUDIO_R_I/O
(HEADPHONE)
J3401
EXT_MIC_L
INT_MIC_L
INT_MIC_R
INT_MIC_F
EXT_MIC_R
J3400
(L)
PLUG IN
POWER
CN4010
(R)
(F)
SHOE_MIC_FL/FR
MIC901
MICROPHONE
UNIT
AV_SO/SCK
XCS_IC_8500
BEEP_PWM_P
XSYS_RST
HP_JACK_IN
MIC_JACK_IN
SDI1_MAG
BCK_OUT_KRJ/IC_8120,
LRCK_OUT_KRJ/IC_8120,
MCK_OUT_KRJ/IC_8120
SDO_KRJ/IC_8120
SP+/-
SDI0_SPDIF_IN_MAG
AUDIO_L_I/O,
AUDIO_R_I/O
FP-2200
FLEXIBLE
BOARD
WF-1004 BOARD AN-1006 FLEXIBLE
BOARD
CN2301
ET2301
CN2302
CN4902
23
2
187
178
205
214
520
223
421
322
12 - 15
1, 2
10 - 13
WIRELESS LAN
ANTENNA
WIRELESS LAN
MODULE
CP7300
WLAN_SD_CLK
WLAN_SD_CMD
XWLAN_RST
WLAN_SD_D0 - D3
31
NFC
INTERFACE
IC7401
NFC_SCK
NFC_SW
NFC_SEL
NFC_IRQ
XNFC_RFDET
NFC_DATA
NFC_L1/L2
WLAN_ANT_MOD
WLAN_SD_CLK
WLAN_SD_CMD
XWLAN_RST
WLAN_SD_D0 - D3WLAN_SD_D0 - D3
NFC_SCK
NFC_SWNFC_SW
NFC_SELNFC_SEL
NFC_IRQ
XNFC_RFDET
NFC_DATA
ANT901
NFC
ANTENNA
MSX_CLK
CN7101
VC-1025 BOARD (2/3)
D6081
MSX_D0 - 3
MSX_BS
XMSX_INS
XMSX_INS
SD_CLK
D6082
SD_D0 - 3
SD_CMD
XSD_INS
XSD_INS
XMS_ACC_LED
D4010
(ACCESS)
7
1
5
2, 3,
4, 6
16
14
20
08
CN3001
17
8
15
1 - 3
20
22
18
19
1 - 3 14, 16 5, 6
11, 13
IHS_ID1 - ID3 ID1 - ID3
5, 6
EXT_STROBE_ON
X_CONTACT
ST_F3
16
ST_F2
IHS_ID1 - ID3
EXT_STROBE_ON
EXT_STRB_SI/SO
STROBE SWITCH
(3/5)
IC3000
Q3002
EXT_STRB_SCK
EXT_STRB_CONT
LEVEL SHIFT
Q3000, Q3001
MUITI
INTERFACE
SHOE
FP-2214 FLEXIBLE BOARD
CN002
WALN_SD_CMD/AUDIO_L,
XGPS_RST/XWLAN_RST/AUDIO_R
F1/EXT_EVF_SO
X_CONTACT
F2/EXT_EVF_S1
F3/EXT_EVF_SCK
MIC_L_GVIF_SDATA_P,
MIC_L_GVIF_SDATA_N
OVERALL (1/4)
(PAGE 4-1)
1
OVERALL (1/4)
(PAGE 4-1)
5
MEMORY
STICK
MICRO
microSD
: VIDEO SIGNAL
: AUDIO SIGNAL
: VIDEO/AUDIO SIGNAL
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(7/26 - 14/26)
IC6000
(2/3)
12, 13,
18, 19
Q7101
CN4011
SP901
(SPEAKER)
1, 2
CN4003
34
FP-2191
FLEXIBLE
BOARD
AUDIO_L_I/O,
AUDIO_R_I/O
SHOE_MIC_FL/FR
10
4
35
25 - 27
18, 19
34
JK-1009 BOARD
PITCH/YAW
SENSOR
(2/5)
SE7701
PITCH_AD
YAW_AD
CN4200
2
11
35
17
20
31
42
44
10
4
2
11
25 - 27
18, 19
17
20
31
42
44
PITCH_AD
YAW_AD
IHS_ID1 - ID3
EXT_STROBE_ON
EXT_STRB_SI/SO
EXT_STRB_SCK
EXT_STRB_CONT
IHS_ID1 - ID3
EXT_STROBE_ON
EXT_STRB_SI/SO
EXT_STRB_SCK
EXT_STRB_CONT
6, 813, 14
6, 813, 14
AUDIO_L_I/O,
AUDIO_R_I/O
SHOE_MIC_FL/FR
HP_R_OUT
HP_L_OUT
EXT_MIC_L
EXT_MIC_R
OVERALL (4/4)
(PAGE 4-4)
7
NFC_IRQ
XNFC_RFDET
NFC_SCK
NFC_DATA
WLAN_SD_CLK
WLAN_SD_CMD
XWLAN_RST
OVERALL (1/4)
(PAGE 4-1)
8
CONTROL
SWITCH BLOCK
(SK45300: Non Projector Model)
(SK45310: Projector Model)
CN4009
5
XPOWER_TACT_SW
2
3
4
PLAY_SW
PJ_SW
MECAN
XPOWER_TACT_SW
KEY_AD2KEY_AD2
Projector Model
EXCEPT CX535

4-4
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-4. OVERALL BLOCK DIAGRAM (4/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
ROLL SENSOR
AMP
(17/26)
IC7711
PITCH/YAW
MOTOR DRIVE
(15/26)
IC6741
LENS BARRIER
DRIVE
(15/26)
IC6742
STEADYSHOT
PROCESSOR,
FOCUS/ZOOM/IRIS
MOTOR DRIVE
(15/26)
IC6800
ROLL
SENSOR
(17/26)
LENS
BARRIER
UNIT
SE7711
CN4001
VC-1025 BOARD (3/3)
ROLL_AD
08
2
1
IC_6000_VD
XIC_6000_RST
IC_6800_IC_6000_CLK
IC_6800_IC_6000_CLK
I_HALL±, I_DRIVE±, I_BIAS-
IC_6800_SI/SO/SCK
IC_6800_XCS
IC_6800_INT_REQ
CAM_V
XIC_6800_CPU_RST
FC_DIR_A/B
SHUTTER_A
SHUTTER_XA
FC_ENB
MSHUT_EN
IC_6800_P_LIMIT
XSYS_RST
ZM_SENS1A,
FC_SENSE,
LENZ_TEMP_AD
ZM_SENSE1A
LENSV_EN
LENS_COVER_DIR_PWM
E20
K20
L12 E3
F5
D1
OVERALL (1/4)
(PAGE 4-1)
2
OVERALL (1/4)
(PAGE 4-1)
6
32 - 35
24, 29,
38, 40,
41
FOCUS_A/XA/B/XB
25 FC_SENSE
43
42
4 - 6,
16 - 18
7, 10,
13
LENZ_TEMP_AD
PITCH_INA_O,
PITCH_INB_O
PITCH±_BOSS
1 - 3,
19 - 21
YAW_INA_O,
YAW_INB_O
YAW±_BOSS
ZOOM_A/B/XA/XB_BOSS30, 31,
36, 37
PITCH_BIAS-,
PITCH_HALL±
PITCH_BIAS-,
PITCH_HALL±
YAW_BIAS-,
YAW_HALL±
YAW_BIAS-,
YAW_HALL±
VST_C_CHARGE
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(7/26 - 14/26)
IC6000
(3/3)
OVERALL (3/4)
(PAGE 4-3)
7PITCH_AD
YAW_AD
CN4008
8, 11,
12
2 - 9 2 - 9
MM-102 BOARD FP-2060
FLEXIBLE
BOARD
CN8101 CN4006
11
13
11
13
TE1_CLK
TE1_CMD
INTERNAL
MEMORY
(1/2)
IC8101
INTERNAL
MEMORY
(2/2)
IC8201
CX610E/PJ610E
EXCEPT CX530E
TE1_DAT_0 - 7
TE1_DAT_0 - 7
TE1_DAT_0 - 7
TE1_CLK
TE1_CMD
MMC_CLK
MMC_CMD
MMC_DAT_0 - 7
MMC_CLK
MMC_CMD
MMC_DAT_0 - 7
I_HALL±, I_DRIVE±, I_BIAS-
L_TEMP_OUT
FOCUS_A/B/XA/XB
ZOOM_A/B/XA/XB
Z_PI_C
F_PI_C
IRIS
DRIVE
LENS TEMP
SENSOR
M902
(YAW)
M901
(PITCH)
OPTICAL IMAGE
STABILIZER
LENS BLOCK (2/2)
ZOOM
DRIVE
FOCUS
DRIVE
PITCH_HALL±,
PITCH_BIAS -
YAW_HALL±,
YAW_BIAS -
PITCH±
YAW±
FP-2126 FLEXIBLE
BOARD
CN0002
CN0001
FP-2125
FLEXIBLE
BOARD
CN0004
CN0005
PITCH±
YAW±
PITCH_HALL±,
PITCH_BIAS-
YAW_HALL±,
YAW_BIAS-
5-8
1,3,4
5-81,3,4
25,26,
29-31
5 - 8
1 - 4
33
6-818-23 12-171,3,4
35
38
MM
MM

4-5
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-5. POWER BLOCK DIAGRAM (1/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
DC/DC CONVERTER
(1/26)
IC5100
USB POWER
MANAGEMENT
(4/26)
IC5651
POWER CONTROL
(3/26)
IC5700
DC/DC CONVERTER
(1/26)
IC5200
PVDD1A
CORE_UNREG,
IO_UNREG
MT_UNREG
SHOE_UNREG_FUSE SHOE_UNREG_FUSE
MT_UNREG
D_1.0V
E1
PVDD1B
E2
D1LX1A
D2LX1B
D3FB1
L0101
PVDD3A D_1.8V, A_1.8V A1
PVDD3B
B1
A2LX3A
B2LX3B
B2LDO1_FB
C4FB3
L0103
PVDD5A D_3.3V, A_3.3V H5
PVDD5B
G5
H4LX5A
G4LX5B
E3FB5
L0105
PVDD6A MT_5.0V, J_5.0V D8
PVDD6B
D7
E8LX6A
E7LX6B
D5FB6
L0106
PVDD2 D_1.2V
HB_1.2V
C8 B8LX2
C5FB2
A5LDO1_OUT
L0102
LDO1_ENB
LDO1_ON D6
DD_ON
DD_ON1
DD_ON1
SYS_BGL_SDA
SYS_BGL_SCL
F5
LDO2_ENBE5
A6LDO1_SOURCE
B1PVDD_LDO1
B4LDO2_SOURCE
D_1.2V
HB_1.8V
A4LDO2_OUT
C9P5F
E2P2C
G10 P53
G11 P10/AN00
H10 P50/SIN3
H9P51/SOT3
H8P52/SCK3
C10 P17/AN07
F3P33/INT11
E4P2A/INT06
H4P44
B11 VCC_B11
C4P0F/NMIX/WKUP0
L7INITX
A_1.0V_IC_5200
A_1.0V_IC_5200
D_3.3V
D_3.3V
A1LDO1_OUTC1 LDO1_ON
BATTE1
ACVGE3
PVDD_CPH2
AVDD
B7
CSG6
DOUT
E6
DINF6
CLK
SYS_DD_SI
SYS_DD_IC_5100_XCS
CSE3
XPANEL_POWER_ON XPANEL_POWER_ON
08
E8P5B/INT26 XPWR_OFF
SYS_DD_SO
SYS_DD_SCK
D1SYS1
UNREG_IC_5651_OUT
D2SYS2
A2SW100
B6PVBUS
C3SUS
G7
DIND3
CLK
SYS_DD_SO
SYS_DD_SCK
SYS_DD_IC_5200_XCS D4
VTR_UNREGE6
UNREG_IN_DET
F2
A4 PVDD_LDO2 HDMI_5V
A3LDO2_OUT
B6LOAD_IN
D7P08
XLANC_PWR_ONC4
XLANC_PWR_ON
K1P3F/INT15
A5 LDO2_ON
SYS_UNREGIN E4 UNREG_IN
K5P60/INT16 USB_SUSREQ_KJR USB_SUSREQ_KJR
XPWR_OFF
VUC
C1VCC_C1
J11 VCC_J11
L2VCC_L2
F5 VUC
XRST_DWN E5 VUC_RST
MSX_3.3V
MXS_3.3V
A6LOAD_OUT
EVER_3V
EVER_3V
VBUS_5V
VBUS_5V
VBUS_5V
VBUS_5V
USB_SUSREQ_KJR
F6 EVER3
F4VCH
MS_PWR_ON
LDO_3.3V_OUTMT_5.0V
D_1.8V
BATT_LI_3V
B5LOAD_ON
B+
SWITCH
Q5700, Q5701
BATTGE2
B+
SWITCH
Q0300
DC JACK
DETECT
Q0202
5
6
4
2
3
1
BATT_IB
BATT/XEXT
BATT/XEXT
BATT_IB
VC-1025 BOARD (1/3)
BATT_UNREG
UNREG_IC_1101_IN
CN4007
1
15
1
CN0400
CN0500
ACVE4
ACV_UNREG
ACV_UNREG
VBUS1A5
USB_VBUS_STD USB_VBUS_ARM
D_3.3V
D_3.3V
XPOWER_TACT_SW
USB_VBUS_MULTI
VBUS2B5
SDAC6
SCLD6
P24/INT00/WKUP1
C2
P30/INT08
E1
SIO2
J5
P63/INT19
K8
P58/SCK1
F8
F005
F001
F003
F002
P57/SOT1F9
USB_5601_EN
SYS_BGL_SDA
SYS_BGL_SCL
USB_5601_EN
SYS_BATTSENSE
F11 P11/AN01
SYS_ACVSENSE
DD_ON
D3
MULTI
HDMI
RECEIVER
(20/26)
IC8200
19
HDMI_5V
CN9000
HDMI OUT
19
HDMI_5V_RX
CN3201
PROJECTOR
IN
B+ SWITCH
SHOE_UNREG_ON
Q8800, Q8801
D_3.3V
CN4005
EVER_3VEVER_3V 3
CONTROL
SWITCH BLOCK
(PS45300)
POWER (2/3)
(PAGE 4-6)
A
POWER (2/3)
(PAGE 4-6)
E
POWER (2/3)
(PAGE 4-6)
D
BATTERY
TERMINAL
S
DC IN
J901
(DC JACK)
6, 12
3.3V REG
(20/26)
IC8201
VDD
4
CE
1
3VOUT
MT_UNREG
D_1.2V
MT_5.0V, J_5.0V
D_3.3V, A_3.3V
D_1.8V, A_1.8V
MSX_3.3V
EVER_3V
A_1.0V_IC_5200
HB_1.8V
HB_1.2V
D_1.0V
VBUS_5V
POWER (2/3)
(PAGE 4-6)
B
LDO_3.3V_OUT
D_3.3V
D_1.8V, A_1.8V
D_1.2V
MT_5.0V
POWER (3/3)
(PAGE 4-7)
C
BUILT-IN
USB CABLE
CHARGE
D0100
F3VREG5.0V
SHOE_UNREG
A_1.8V
Projector Model
CN4009
5
XPOWER_TACT_SW
CONTROL
SWITCH BLOCK
(SK45300: Non Projector Model)
(SK45310: Projector Model)

4-6
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-6. POWER BLOCK DIAGRAM (2/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
LENS BARRIER
DRIVE
(15/26)
IC6741
PITCH/YAW
MOTOR DRIVE
(15/26)
IC6742
PITCH/YAW
SENSOR
(2/5)
SE7701
IC6800
2.8V REG
(15/26)
IC6802
CN4001
23
JK-1009 BOARD
VDD
IRIS_BIAS+
4
CE
1
3VOUT
ENA
C3
14
PITCH_BIAS+
9
CN7101
8
15
YAW_BIAS+
F_PI_A
IRIS_BIAS+
Z_PI_A
YAW_BIAS+
PITCH_BIAS+
CN4200
Z_PI_A
F_PI_A
XZM_RST_LED
MR_A_2.8V
DC/DC CONVERTER
(2/26)
IC5150
IN
2
EN
3
9VOUT
ROLL SENSOR
AMP
(17/26)
IC7711
AUDIO
PROCESSOR
(23/26)
IC8500
2.8V REG
(23/26)
IC8501
VDD
4
CE
1
3VOUT
VBUS
DETECT
BUS POWER SWITCH
(6/26)
IC5630
EN 3
X_FAULT 4
1IN
K4 SD1_O1
D_1.2V
MT_5.0V
EVER_3.0V
D_3.3V
SD_3.3V
MSX_3.3V
D_3.3V
D_1.8V
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(7/26 - 14/26)
IC6000
BATT_LI_3V
ST_VCC_ON
D4010
(ACCESS)
MR_A_2.8V
LED DRIVE
Q4010
MEMORY
STICK
MICRO
microSD
XCON_7.0V_OUT
XIC_6000_RST
ROLL SENSOR
(17/26)
SE7711
PANEL
OPEN/CLOSE
DETECT
(25/26)
Q4013
XPANEL_POWER_ON
23, 24
37
30
39
32
FP-2191
FLEXIBLE
BOARD
CN4003
23, 24
37
30
39
32
XZM_RST_LED
A_3.3V
MT_UNREG
MT_UNREG
D_1.2V
D_1.2V
MT_5.0V
MT_5.0V, J_5.0V
D_3.3V
D_3.3V, A_3.3V
D_1.8V, A_1.8V
D_1.8V
SD_3.3V
SD_3.3V
MSX_3.3V
MSX_3.3V
EVER_3V
EVER_3V
XPANEL_POWER_ON
BT4200
LITHIUM
BATTERY
SHOE_UNREG
D_3.3V
A_3.3V
BATT_LI_3V
BATT_LI_3V
ST_VCC_ON
A_1.0V_IC_5200
A_1.0V_IC_5200
D_3.3V
A_3.3V
MSX_3.3V
PAD_PROJ_ON
L18 GPIO_S_11
XPWR_OFF
L20 GPIO_S_6
MS_PWR_ON
W25 USB_CHG_HL
USB_SUSREQ_KJR
M19 GPIO_S_5
SD_PWR_ON
M20 GPIO_S_4
MMC_PWR_ON
L7 IRIS1
SHOE_UNREG_ON
AA23 VBUS_EN
VBUS_EN
J_5.0V VOUT 6
W22 USB_OCI
V11 SA_TDI
E20 FRC_RTG_OUT0
VBUS_XOVR_CUR
L17 GPIO_S_13
XVBUS_DET_MULTI
VCC_MMC
WLAN_VOUT_3.3V
D_1.2V
HB_1.2V
HB_1.8V
D_1.0V
HB_1.8V
HB_1.2V
D_1.0V
L1061
Q5600
D5600
E19 GPIO_SB_1
XVBUS_DET_STD_AVBUS_5V
VBUS_5V
Y23 USB_VBUS
XVBUS_DET
USB_VBUS_MULTI
POWER (1/3)
(PAGE 4-5) E
POWER (3/3)
(PAGE 4-7) F
POWER (1/3)
(PAGE 4-5) D
POWER (1/3)
(PAGE 4-5) A
VC-1025 BOARD (2/3)
B+ SWITCH
(1/26)
IC5500
EN 3
1
08
VIN
D_3.3V VOUT 5
POWER (1/3)
(PAGE 4-5)
B
STEADYSHOT
PROCESSOR,
FOCUS/ZOOM/IRIS
MOTOR DRIVE
(15/26)
L3501
A_1.8V
SHOE_UNREG
D_3.3V
PANEL_O/C_GMR
MR_A_2.8V
MT_5.0V
27
44
5PG PGOOD_XC
D_1.8V
FP-2214 FLEXIBLE
BOARD
CN3001
9
B+ SWITCH
Q8830 14
SHOE_UNREG
2.8V REG
(1/5)
IC2201
VDD
4
CE
1
3VOUT
STROBE SWITCH
(3/5)
IC3000
LOGIC_VDD_SHOE
A_2.8V_REG
ND_DIR_A M10
D_3.3V
A_3.3/2.8V
13
17
CN002
LOGIC_VDD
SHOE_UNREG
MULTI
INTERFACE
SHOE
LCD_CABC_PWM
LCD_CABC_PWN
AB12
FP-2189
FLEXIBLE
BOARD
CM-1004 BOARD
CMOS
IMAGER
CP001
CN6702CN4004
CAM_1.2V
39
I/O_1.8V
CMOS_A_3.3V
39
D_1.2V
AVDD18_SUBLA_1.8V
A_3.3V A_2.8V_IMG
2.8V REG
IC6703
VDD
4
CE
1
3VOUT
37
38
37
38
M4 SD1_I0
PJ_RSTZ
Projector Model: SE4010
Non Projector Model: SE4011
CN0005
CN0004
PITCH_BIAS+
YAW_BIAS+
9
2
34
37
28
LENS
BLOCK
FP-2126 FLEXIBLE
BOARD
CN0001
CN0002
2
2
FP-2125
FLEXIBLE
BOARD

HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
4-7E
4-7. POWER BLOCK DIAGRAM (3/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
B+
SWITCH
Q301
PROJECTOR
UNIT
40
32
31
20
2,3,22,23,42,43
D_1.8V
CN5503
14, 164, 6, 8, 10
19
13, 153, 5, 7, 9
DMD_VRST
DMD_VBIAS
DMD_VOFS
P1P8V
P1P8V
FP-2106
FLEXIBLE
BOARD
FP-2193
FLEXIBLE
BOARD
PJ-1005 BOARD
PD-1031 BOARD
LED DRIVE
(4/4)
IC8801
DMD CONTROL
(2/4)
IC8605
FLASH
MEMORY
(2/4)
IC8606
VINA
D7
VINR
A4
VINL
A1
VINL
A2
A_1.8V
CN8503CN3750 CN8504
PJ_SYSPWR
PAD_PROJ_ON
PAD_PROJ_ON
B6CNTR_VRST DMD_VRST
B7VBIAS DMD_VBIAS
C7VOFS DMD_VOFS
A5SWN
A7SWP
L8801 D8801
PROJ_ONE6
A_1.8V
A_1.8V
MT_5.0V
PAD_PROJ_ON_DPP
8
2
CN8040
A_1.8V
PARKZ B8
1.0V REG
(1/4)
IC8504
VDD
4 3VOUT
DC/DC CONVERTER
(1/26)
IC5300
VIN6
VFB 3
5VOUT
4CE
LCD SERIAL
INTERFACE
RECEIVER
(1/2)
IC8010
LCD SERIAL
INTERFACE
TRANSMITTER
(22/26)
IC8000
VIDEO
SELECTOR
(21/26)
IC8120
PANEL
NORMAL/REVERSE
DETECT
(2/2)
SE4800
D_3.3V
LX1
L0107
F004
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
BACKLIGHT
D_3.3V
A_1.8V
D_3.3V
CN4800
BL_L
BL_H
42, 43
28
PAD_PROJ_ON
PAD_PROJ_ON
MT_5.0V
A_1.8V
A_1.8V
D_3.3V
D_3.3V
D_1.8V
D_1.2V
CN4901
26 - 28 9, 10
24
17, 18
FP-2060
FLEXIBLE
BOARD
MM-102 BOARD
CN8101CN4006
15
MEDIA_3.3V
16
TE1_VCC
MMC_PWR_ON1
D_3.3V
VCC_MMC
MMC_PWR_ON
VCC_MMC
MMC_PWR_ON
2.9V REG
(1/2)
IC8701
VDD
4
CE1
3VOUT
INTERNAL MEMORY
(1/2)
IC8101
INTERNAL MEMORY
(2/2)
IC8201
CX610E/PJ610E
17, 18
15
16
FP-2200
FLEXIBLE
BOARD
WF-1004 BOARD
WIRELESS LAN
MODULE
CP7300
CN2301CN4902
7
6
8
EVER_3V
VCC_WLAN_L
WLAN_VCC_H
NFC
INTERFACE
IC7401
9WLAN_VCC_H_OUT
D_3.3V
D_1.8V
LDO_3.3V_OUT
LDO_3.3V_OUT
WLAN_VOUT_3.3V
WLAN_VOUT_3.3V
18
08
19
17
16
USB SELECT
(5/26)
IC5600
MT_5.0V
AUDIO DSP
(19/26)
IC8630
D_3.3V
D_1.8V, A_1.8V
D_1.2V
MT_5.0V
VC-1025 BOARD (3/3)
POWER (1/3)
(PAGE 4-5)
C
POWER (2/3)
(PAGE 4-6)
F
LCD_CABC_PWM
LCD_CABC_PWM
LDO_3.3V_OUT
23
20
L4802
L4801
29
24 - 26
1
PJ_RSTZ PJ_RSTZ
LDO_OUT_3.3V 17 18
11 12
VFLASH
16
PAD_PROJ_ON
LDO_3.3V_OUT
PJ_RSTZ
FP-2192
FLEXIBLE
BOARD
PD-1030 BOARD
8
CN8040
A_1.8V
PANEL
NORMAL/REVERSE
DETECT
SE4700
D_3.3V
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
BACKLIGHT
D_3.3V
A_1.8V
D_3.3V
CN4700
BL_L
BL_H
L4701
L4700
31
38, 39
44
36, 37
BL_H, BL_L BL_H, BL_L
32
SDRAM
(3/4)
IC8701
VSPIB5
RSTZF4
VFLASH
VFLASH
CE
1
A_1.8V
A_1.8V
P1P8V
P1P0V
1,2,21,22,41,42
P1P0V
P1P8V
40
32
31
16, 15
BL_H
BL_L
BL_H, BL_L
MT_5.0V
36
PJ_RSTZ
PJ_RSTZ
7,33,34
7,33,34
2
1
BL_H, BL_L BL_H, BL_L
A_1.8V
D_3.3V
A_1.8V
D_3.3V
Non Projector Model
EXCEPT CX530E
EXCEPT CX535
Projector Model
Projector Model
D_1.2V
D_3.3V
Projector Model

5-1
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
5. FRAME SCHEMATIC DIAGRAMS
5-1. FRAME SCHEMATIC DIAGRAM (1/2)
1
24
124
139
1
39
2
139
38
16
78
34
12
234567891011 12120
131415161718 1219
22
23
24
25
15
67
20
18 2
19 1
21
22
23 20
18 2
19 1
21
22
23
1
244
45 46
47
2145
44
112 1314
118
1920
16
7
8
12
34
16
78
1
260
61
62 63
124 2526
615 16
1718
19
15
CN4004
CN4009
CN4011
CN7101
CN0400
CN3201 CN9000
CN4001
CN4003
CN4005 CN4006
CN4007
CN4008
CN4010
CN4901
CN4902
CN0500
1
38
39
CN6702
2
CM-1004 BOARD
(SIDE A)
CM-1004 BOARD
(SIDE B)
CP001
(Not supplied)
FP-2060
FLEXIBLE
BOARD
118
CN8101
MM-102 BOARD
18
18
1
1
MM
MM
VC-1025 BOARD
(SIDE A)
VC-1025 BOARD
(SIDE B)
IC8201
(Not supplied)
IC8120
(Not supplied)
IC8000
(Not supplied)
IC6742
(Not supplied)
IC6741
(Not supplied) IC5651
(Not supplied)
IC8501
(Not supplied)
IC7711
(Not supplied)
IC6000
(Not supplied)
IC5150
(Not supplied)
IC5100
(Not supplied)
IC5500
(Not supplied)
IC5700
(Not supplied)
HDMI
OUT
Projector Model
Non Projector ModelProjector Model
PROJECTOR
IN
CONTROL
SWITCH
BLOCK
(SK45300)
CONTROL
SWITCH
BLOCK
(SK45310)
WF-1004 BOARD
(SIDE A) WF-1004 BOARD (SIDE B)
AN-1006 FLEXIBLE BOARD
1
24 25
26
CN2301
1
3
2
4
CN2302
ANT901
(NFC ANTENNA)
ET2301
WIRELESS LAN
ANTENNA
MULTI
CONTROL
SWITCH
BLOCK
(PS45300)
MICROPHONE
UNIT
DC IN
BATTERY
TERMINAL
J901
DC JACK
FP-2192
FLEXIBLE
BOARD
(Page 5-2)
B
FP-2193
FLEXIBLE
BOARD
(Page 5-2)
C
Non Projector Model
EXCEPT CX535
EXCEPT CX530E
Projector Model
SP901
(SPEAKER)
FP-2191
FLEXIBLE
BOARD
(Page 5-2)
A
BUILT-IN
USB CABLE
CHARGE
MIC901
2
1
38
39 1
22
23
CN0004 CN0005
81
81
CN0001
CN0002
2
FP-2126
FLEXIBLE BOARD
FP-2200
FLEXIBLE BOARD
FP-2125 FLEXIBLE BOARD
23 1
1
45
LENS BLOCK
M902
(YAW)
M901
(PITCH)
FP-2189
FLEXIBLE BOARD
LENS
BARRIER
UNIT

HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
5-2E
5-2. FRAME SCHEMATIC DIAGRAM (2/2)
FP-2192
FLEXIBLE BOARD
FP-2193
FLEXIBLE BOARD
FP-2191
FLEXIBLE BOARD
MULTI
INTERFACE
SHOE
118
19
20
1
244
45
46 47
CN3001
CN4200
J3400
J3401
SE7701
PITCH/YAW
1
250
51
52 53
16
78
52 53
1
250
51
52 53
1
250
51
1
768
60
59
2
1
52 53
1
250
51
CN4700
CN4702
CN8040
CN4800
CN4802
CN3750
CN8040
CN002
121
23 24
118
22
44 2
CN8504
260
CN8503
10 1
159
45 1
IC8801
(Not supplied)
CN8502
IC8504
(Not supplied)
IC8605
(Not supplied)
IC8010
(Not supplied)
161
161
151
151
1
45
45
1
JK-1009 BOARD
(SIDE A)
JK-1009 BOARD
(SIDE B)
PD-1030 BOARD
PD-1031 BOARD
FP-2214 FLEXIBLE BOARD
PJ-1005 BOARD
(SIDE A)
PJ-1005 BOARD
(SIDE B)
45
1
FP-2106
FLEXIBLE BOARD
PROJECTOR
UNIT
1
2
41
42
43
44
45
46
CN5503
VC-1025
BOARD
(SIDE A)
(Page 5-1)
A
VC-1025
BOARD
(SIDE B)
(Page 5-1)
B
VC-1025
BOARD
(SIDE B)
(Page 5-1)
C
(HEADPHONE)
PLUG IN
POWER
IC3000
(Not supplied)
BT4200
(LITHIUM BATTERY)
LCD901
(LCD MODULE)
3.0 INCH
WIDE COLOR
LCD
TOUCH
PANEL
Non Projector Model
Projector Model
LCD901
(LCD MODULE)
3.0 INCH
WIDE COLOR
LCD
TOUCH
PANEL

6-1
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
– ENGLISH – – JAPANESE –
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
イメージャ交換時の注意
・ イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・ イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
 また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF :
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT →EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
回路図ノート
・ ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・ チップ抵抗で指示のないものは，1/10W以下。
 kΩ＝1000Ω，MΩ＝1000kΩ
・ チップ部品交換時の注意
 取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
 タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・ チップ部品には下記のように表示したものがあります。
 例 C541 L452
  22U 10UH
  TA A 2520
  種類 外形寸法（mm）
  ケースサイズ
・ 抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・ ★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・ 可変抵抗と半固定抵抗で，B特性の表示を省略。
・ 信号名表記について，下記のような場合があります。
 XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
 ：フレキシブル配線板
 見ている面側のパターン。
 ：裏側のパターン
 （他のパターンについては表示されていません）
・ スルーホールは省略。
・ プリント図には，本機で使用していない部品が記載され
ている場合があります。
・ はパネル表示名称。
• Chipparts.
 Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
印の部品には、秘密情報が含まれています。
修理の際は、指示に従った対応を行ってください。
交換後の対象基板及び対象ICは、破壊のうえ廃棄してください。
The components identified by mark contain confidential informa-
tion.
Strictly follow the instructions whenever the components are re-
paired and/or replaced.
Destroy and discard the prescribed board and IC after they are
replaced.
Les composants identifiés par le symbole contiennent des infor-
mations confidentielles.
Suivez scrupuleusement les instructions chaque fois qu'un com-
posant est remplacé et / ou réparé.
Veuillez détruire et éliminer les circuits imprimés et / ou les circuits
intégrés que vous avez remplacés.
标识有 的元件包含机密信息。
更换或维修元件时，请严格遵守指⽰。
更换后的电路板和IC，应予以报废。

6-2
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
6-1. SCHEMATIC DIAGRAMS
FP-2189
FLEXIBLE
LND001
(PAGE 6-29)
XCLR
XVS
INCK
XHS
Note: CP001 is not supplied, but this is included in
CM-1004 COMPLETE BOARD.
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
CM-1004 BOARD
CMOS IMAGER
XX MARK: NO MOUNT
C6729
1u
C6728
1u
C6706
XX
C6714
0.1u
C6707
XX C6712
0.001u C6713
2.2u
C6703
1u
C6718
0.1u
C6701
XX
C6710
1u
C6711
0.1u
C6715
4.7u
C6717
0.1u
C6716
0.1u
C6708
1u
C6709
0.1u
I/O_1.8V
CMOS_A_3.3V
CAM_1.2V
REG_GND
REG_GND
A_2.8V
DOAP
DOBP
DOCM
DOBM
DOAM
A_2.8V
DCKP
DCKM
DODP
DODM
DOCP
R6741
XX
R6707
47k
R6706
XX
R6703
XX
R6701
XX
R6767
XX
R6702
XX CP001
IMX167CQL-13
CMOS IMAGER
A7
VDDHDA
A8
VSSHDA
C1
VDDHCP
C2
VSSHCP
A9
NC5
C11
VDDHCM
A3
NC5
A4
NC5
B3
NC5
B4
NC5
A5
VSSHPX
A6
VDDHPX
B6
NC5
B7
NC5
H2
NC5
H1
VDDSUB1
H11
VDDSUB2
H10
NC5
H9
NC5
C3
NC5
C4
NC5
A1
NC1
A2
NC1
B1
NC1
B2
NC1
E1
XCLR
G2
XVS
G1
XHS
E2
XCE
F2
SCK
F3
SDI
E3
SDO
H3
ICNK
L1
NC2
L2
NC2
M1
NC2
M2
NC2
L4
DOAM
M4
DOAP
L5
DOBM
M5
DOBP
L6
DCKM
M6
DCKP
L7
DOCM
M7
DOCP
L8
DODM
M8
DODP
L10
NC3
L11
NC3
M10
NC3
M11
NC3
D1
TENABLE
D2
TSCANEN
D3
TOUT
C10
NC5
C9
NC5
B9
ASMON
A10
NC4
A11
NC4
B10
NC4
B11
NC4
C8
VBGR
B8
VEXRES
C7
NC5
C6
NC5
C5
VRLS
B5
VRLT
G3
NC5
J3
NC5
K1
VDDLPL
J1
VSSLPL
K3
NC5
K4
NC5
K2
VDDLSC
J2
VSSLSC
K5
NC5
K8
NC5
K9
VDDLSC
J9
VSSLSC
L3
NC5
K7
VDDMLV
K6
VSSMLV
M3
VSSMLV
M9
VSSMLV
L9
NC5
D9
NC5
D10
NC5
D11
NC5
E9
NC5
F1
VDDMIO
E10
NC5
E11
NC5
F9
NC5
F10
NC5
F11
NC5
G9
NC5
G10
NC5
G11
NC5
J10
VSSLCN
J11
VSSLCN
K10
VDDLCN
K11
VDDLCN
C6743
0.001u
DODP
DCKP
DOBP
DCKM
DODM
DOAM
DOBM
DOCP
DOCM
DOAP
SDO
CMOS_A_3.3V
I/O_1.8V
XVS
SCK
CAM_1.2V
SDI
INCK
XHS
XCLR
XCE
LF6712 XX
2
1
34
SCK
SDI
SDO
XCE
CL008
R6708 XX
C6745
0.1u
CL009
CL010
CL007
R6709 XX
REG_GND
CL006
C6746
XX
C6747
XX
C6751
XX
C6752
XX
IC6703
MM3404A28URE
2.8V REG
1
CE
2
GND
OUT
3
IN
4
R6729
XX
C6753
XX
R6705
XX
C6720
0.1u
R6768 XX
R6769 XX
R6770 XX
R6771 XX
R6772 XX
R6773 XX
R6774 XX
R6775 XX
R6776 XX
R6777 XX
CN6702 39P
1REG_GND
2REG_GND
3INCK
4REG_GND
5REG_GND
6XCLR
7REG_GND
8XCE
9SCK
10 REG_GND
11 SDI
12 SDO
13 XHS
14 XVS
15 REG_GND
16 REG_GND
17 DOAM
18 DOAP
19 REG_GND
20 REG_GND
21 DOBM
22 DOBP
23 REG_GND
24 REG_GND
25 DCKM
26 DCKP
27 REG_GND
28 REG_GND
29 DOCM
30 DOCP
31 REG_GND
32 REG_GND
33 DODM
34 DODP
35 REG_GND
36 REG_GND
37 I/F_1.8V
38 CAM_1.2V
39 CMOS_A_3.3V
REG_GND
REG_GND
REG_GND
R6778 XX
CL001
LF6716 XX
2
1
34
LF6713 XX
2
1
34
LF6714 XX
2
1
34
LF6715 XX
2
1
34

6-3
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
XRST_DWN
Note: C5102, C5207, C5500, IC5100, IC5500, R5100 and R5201 are not supplied,
but they are included in VC-1025 COMPLETE BOARD (SERVICE).
E
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-1025 BOARD (1/26)
DC/DC CONVERTER
XX MARK: NO MOUNT
R5203
XX
R5102
XX
R5103
XX
R5104 XX
R5101
XX
C0105
XX
C0106
XX
C0107
XX
R0105
XX
R0104
XX
R0106
XX
R0107
XX
R0103
XX
R0109
XX
R0101
XX
R0108
XX
R0100 XX
IC5200
BD8331GU-E2
DC/DC CONVERTER
CS
E3
CLK
D4
DIN
D3
DD_ON
D2
ACV_UNREG
F1
BATT_UNREG
E1
VTR_UNREG
E6
ACV_ON
E2
BATT_ON
D1
AGND_COMMON
F3
LANC_DC
D6
DATA_IN
B4
DATA_OUT
D5
LANC_SIG
C5
XLANC_PWR_ON
C4
XLANC_ON
C2
AGND_LANC
C6
UNREG_IN_DET
F2
UNREG_IN
E4
VUC
F5
VUC_RST
E5
VCH
F4
EVER3
F6
LDO1_ON C1
PVDD_LDO1 B1
LDO1_OUT A1
LDO1_FB B2
LDO2_ON A5
PVDD_LDO2 A4
LDO2_OUT A3
LDO2_FB B3
LOAD_ON B5
LOAD_IN B6
LOAD_OUT A6
SGND_LDO A2
C5204
1u
C5202
0.1u
C5205
1u
C5207
4.7u
C5203
1u
C5209
1u
C5200 0.1u
C5206
0.1u
C5208
1u
C5201 4.7u
LOAD_ON
VTR_UNREG
GND
UNREG_IN_DET
PVDD_LDO1
PVDD_LDO2
LDO1_OUT
EVER3
LOAD_OUT
DD_ON
VCH
LOAD_IN
LDO2_OUT
VUC
CS
CLK
DIN
ACV_UNREG
BATT_UNREG
ACV_ON
BATT_ON
LANC_DC
DATA_IN
DATA_OUT
LANC_SIG
XLANC_PWR_ON
XLANC_ON
UNREG_IN
VUC_RST
LDO1_ON
LDO2_ON
R5202
33k
R5201
100k
R5200 100
CM0115
C5300
1u
C5301
1u
GND
VIN
BL_H
LX
BL_L
CE
R5300
12
R5301
12
IC5300
R1207N823B-TR-FE
DC/DC CONVERTER
1
LX
2
GND
3
VFB CE
4
VOUT
5
VIN
6
C5500
0.1u
C5501
1u
EN
VIN
GND
VOUT
R5500
10k
IC5500
BD2224G-BZTR
B+ SWITCH
1
VIN
2
GND
3
EN OC
4
VOUT
5
C5104
1u
C5112
2.2u
C5114
2.2u
C5101 0.1u
C5105 1u C5100 1u C5102 0.01u C5106 1u
C5117
10u
C5110
2.2u
C5109
2.2u
C5111
2.2u
C5107
0.1u
C5103 1u
C5120
10u
C5116
22u
C5118
10u
C5108
2.2u
JL5100
CL5102
CL5101
CM0516
CM0517
CM0515
CM0514
CM0519
CM0513
CM0512
CM0518
CH3_OUT
PVDD6
LDO2_ENB
CH2_OUT
CH1_OUT
LDO2_OUT
CH5_OUT
CP_OUT
FB6
LDO1_ENB
LDO1_OUT
CS
CLK
DIN
DOUT
LDO1_SOURCE
LDO2_SOURCE
LX6
LX5
LX4
LX3
LX2
LX1
VO_SEL
REG_GND
DD_ON
FB4
PGND4
PGND6
PVDD4
SLOPE1
PVDD1/2/3
PVDD5/CP/AVDD
VREG5.0V
R5100 47k
IC5100
BD8336GU-E2
DC/DC CONVERTER
TEST1
H1
TEST2
H8
TEST3
A8
DD_ON
F5
ROSC
B5
CS
G6
CLK
G7
DIN
F6
DOUT
E6
PVDD_CP
H2
CP_OUT
G2
CFP
G1
CFN
F1
PGND_CP
F2
LDO1_ENB
D6
LDO1_OUT
A5
LDO1_SOURCE
A6
LDO2_ENB
E5
LDO2_OUT
A4
LDO2_SOURCE
B4
PGND6B F7
PGND6A F8
LX6B E7
LX6A E8
PVDD6B D7
PVDD6A D8
PGND5B G3
PGND5A H3
LX5B G4
LX5A H4
PVDD5B G5
PVDD5A H5
PGND4 G8
LX4 H7
PVDD4 H6
PGND3B B3
PGND3A A3
LX3B B2
LX3A A2
PVDD3B B1
PVDD3A A1
PGND2 A7
LX2 B8
PVDD2 C8
SLOPE1 C3
PGND1B C2
PGND1A C1
LX1B D2
LX1A D1
PVDD1B E2
PVDD1A E1
FB1 D3 FB2 C5 FB3 C4 FB4 E4 FB5 E3 FB6 D5
VO_SEL F4
AGND B6
VREG5.0V F3 VREG3.0V C7
VREF_BG C6
AVDD B7
CM0114
CM0113
CM0112
CM0111
C0104
2.2u
C0100
XX
C0102
10u CM0101
CM0103
CM0102
CM0105
CM0106
CM0107
CM0108
CM0109
CM0110
CM0104
D0100
DA2S10100K8
SYS_DD_SCK
REG_GND
LDO1_ON
LANC_SO
MT_5.0V
SYS_DD_IC_5100_XCS
MS_PWR_ON
I/O_UNREG
SD_PWR_ON
MT_UNREG
DD_ON1
LCD_CABC_PWM
REG_GND
CORE_UNREG
SYS_DD_IC_5200_XCS
SYS_DD_SO
I/O_UNREG
BL_L
D_1.0V
D_1.8V
SD_3.3V
SYS_UNREGIN
BATT_LI_3V
BL_H
LANC_IC_ON
XLANC_PWR_ON
VUC
HB_1.2V
SYS_DD_SI
J_5.0V
HB_1.8V
MT_5.0V
A_3.3V
LANC_DC
HDMI_5V
D_1.2V
D_3.3V
A_1.0V_IC_5200
MSX_3.3V
A_1.8V
EVER_3V
LANC_SI
LANC_SIG
F004
0.25A/50V
L0101
4.7uH
L0106
4.7uH
L0102
10uH
L0105
10uH
L0103
10uH
L0107
33uH
LN0108
LN0101
LN0103
LN0109
LN0100
LN0106
LN0105
LN0102
CM0116

6-4
HDR-CX530E/CX535/CX610E/PJ530E/PJ540/PJ540E/PJ610E_L3
XIC_6000_RST
Note: C5152, IC5150 and L5150 are not supplied,
but they are included in VC-1025 COMPLETE BOARD (SERVICE).
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-1025 BOARD (2/26)
DC/DC CONVERTER
XX MARK: NO MOUNT
C5151
10u
C5153
10u
C5154
10u
C5152
0.1u
XC_EN
XC_UNREG
XC_PGOOD
XC_PGND
XC_AGND
XC_VOUT
L5150
2uH
R5150
130k
R5151
10k
IC5150
TPS63060DSCR
DC/DC CONVERTER
1L1
2IN
3EN
4PS/SYNC
5PG 6
VAUX
7
GND
8
FB
9
VOUT
10
L2
11
PowerPAD
C0160
10u
CM0161
CM0160
D_3.3V
REG_GND
MT_UNREG XCON_7.0V_OUT
PGOOD_XC
R0160
22k
