CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
注意
如果电池更换不当会有爆炸危险
只能用同样类型或等效类型的电池来更换
SYSSET
2020/09/0901:17:45(GMT+09:00)

SERVICE MANUAL
Sony CONFIDENTIAL
For Authorized Servicer
WH-1000XM4
WIRELESS NOISE CANCELING STEREO HEADSET
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Chinese Model
Tourist Model
Ver. 1.1 2020.09
SPECIFICATIONS
Except CH: CH:
Headset
Power source:
DC 3.7 V: Built-in lithium-ion rechargeable battery
DC 5 V: When charged using USB
Operating temperature:
0 °C to 40 °C (32 °F to 104 °F)
8 W
Rated power consumption:
Usage hours:
When connecting via the Bluetooth device
Music playback time: Max. 30 hours (NC ON), Max. 22 hours
Communication time: Max. 24 hours (NC ON), Max. 18 hours
(Ambient Sound Mode), Max. 38 hours (NC OFF)
(Ambient Sound Mode), Max. 30 hours (NC OFF)
Standby time: Max. 30 hours (NC ON), Max. 22 hours (Ambient
Sound Mode), Max. 200 hours (NC OFF)
When connecting via the headphone cable with NC ON: Max.
22 hours
Note: Usage hours may be shorter depending on the Codec and the
conditions of use.
Charging time:
(About 5 hours of music playback is possible after 10 minutes
charging.)
Note: Charging and usage hours may be dierent depending on
the conditions of use.
Approx. 3 hours
Charging temperature:
Mass:
Approx. 254 g (8.96 oz)
5 °C to 35 °C (41 °F to 95 °F)
Impedance:
40 Ω (1 kHz) (when connecting via the headphone cable with the
unit turned on)
16 Ω (1 kHz) (when connecting via the headphone cable with the
unit turned o)
Sensitivity:
105 dB/mW (when connecting via the headphone cable with the
unit turned on)
101 dB/mW (when connecting via the headphone cable with the
unit turned o)
Frequency response:
4 Hz - 40,000 Hz (JEITA) (when connecting via the headphone cable
with the unit turned on)
Included items:
Wireless Noise Canceling Stereo Headset (1)
USB Type-C
Headphone cable (approx. 1.2 m (47.25 in.)) (1)
cable (USB-A to USB-C (approx. 20 cm (7.88 in.)) (1)
Carrying case (1)
Plug adaptor for in-flight use (1)1)
1) Depending on the in-flight entertainment services, it may not be
supported.
Communication specification
Communication system:
Bluetooth Specification version 5.0
Output:
Bluetooth Specification Power Class 1
Maximum communication range:
1)
Frequency band (AEP, UK):
2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Line of sight approx. 10 m (30 ft)
Compatible Bluetooth profiles2):
A2DP / AVRCP / HFP / HSP
Supported Codec3):
SBC / AAC / LDACTM
Transmission range (A2DP):
20 Hz - 20,000 Hz (Sampling frequency 44.1 kHz)
20 Hz - 40,000 Hz (Sampling frequency LDAC 96 kHz, 990 kbps)
1) The actual range will vary depending on factors such as obstacles
between devices, magnetic fields around a microwave oven, static
electricity, reception sensitivity, antenna’s performance, operating
system, software application, etc.
2) Bluetooth standard profiles indicate the purpose of Bluetooth
communications between devices.
3) Codec: Audio signal compression and conversion format
Design and specifications are subject to change without notice.
System requirements for battery charge using
USB
USB AC adaptor
A commercially available USB AC adaptor capable of supplying an output
current of 1.5 A or more
Compatible iPhone/iPod models
iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8,
iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s,
iPhone 6 Plus, iPhone 6, iPhone 5s, iPod touch (6th generation)
(As of March 2020)
Operating frequency (AEP, UK):
Bluetooth: 2,400 MHz - 2,483.5 MHz
NFC: 13.56 MHz
Maximum output power:
Bluetooth: < 7 dBm
弨媽壒㝊
弨媽䰉䷭澀
#MVFUPPUI壒㝊䅖㘺
庡℈澀
#MVFUPPUI壒㝊↭䊕䩗䶵
㘎⠵弨媽刑☂澀
壔䷍䶴N
枟䊕㯰㫃
()[㯰㫃
潮()[()[潯
枟䊕刑☂澀
.)[.)[
⋟⬒↭䊕澀
≤E#N&*31
₊⫇䖒#MVFUPPUI恛乼≝媼澀
"%1"73$1)'1)41
㐽㈏䖒两壱䜏╶澀
4#$""$-%"$5.
Ḯ庡刑☂潮"%1潯澀
)[)[潮惕㝅枟䊕L)[潯
)[)[潮惕㝅枟䊕-%"$L)[潲
LCQT潯
⪬敓刑☂⬔◮嫌⠕攂䖒斪䞛䅷Ƞ⺼㯰㾗⍶☂
䖒䟏♈Ƞ晧䑃Ƞ㊳㑄㾃㑝ⶴȠ⠷䷍⼵個Ƞ㏛
Ṫ䰉䷭Ƞ幽ḃⶢ䐶䤙⶝䩗◮䰮会⸐ȡ
#MVFUPPUI㜕󱁵恛乼≝媼㈕䡈嫌⠕ᵘ攂䖒
#MVFUPPUI弨媽䗼䖒ȡ
两壱䜏╶澀朁枟ữ⌅⊙丷⎚幺㉰㝊⸝
嫌媯⎚壒㝊⢐㘗⋦㘂潲⽣ᴚ⋴坚弨䛳ȡ
ẍ䐶64#ᵇ䑃㭮⁓䑃䖒䰉䷭墏㭐
64#ᶱ㱏䑃㶞弐恛╶
個⠭ẩⶢ"ㄤ㘂槦庡℈䑃㱏䖒ⴐ␼64#ᶱ㱏
䑃㶞弐恛╶
₊⫇J1IPOFJ1PE㙈⚙
J1IPOF94.BYJ1IPOF94J1IPOF93J1IPOF9
J1IPOF1MVTJ1IPOFJ1IPOF1MVTJ1IPOF
J1IPOF4&J1IPOFT1MVTJ1IPOFT
J1IPOF1MVTJ1IPOFJ1IPOFT
J1PEUPVDI潮䨺󰶑潯
潮ㄸ儁ⶂ㘖潯
佁㙈
䑃㶞澀
䘂㱏7澀ẍ䐶64#⁓䑃㔄
ⳳṪ㴷ⶴ澀
Ď儁Ď
枫⪨↭伥澀
8
⁓䑃㔄攂澀
䶴⬝㔄
㯶〝澀⁓䑃㔄攂⎚ẍ䐶㔄攂⋽個◮ẍ䐶⿓
⃃会⸐ȡ
⁓䑃㴷ⶴ澀
Ď儁Ď
∓埓ₓ䅷⏏澀
㓮䷍敛╸䧙ṡ⟾佁㙈潮潯
64#5ZQF$®廬㊳䷍潮64#"儁64#$®潯
潮䶴DN潯潮潯
佁㙈廬㊳䷍潮䶴N潯潮潯
ọ㍈䗠潮潯
䐶ᶛ柬㙈ᴗ䖒㋠⡂幺㊳╶潮潯
壔㙈ᴗ⤿ᵝ㘛↯会⪨潲⋽個ᴚ⋥㐽㈏ȡ
嬅∍㋠⁳
㘺㋠⡂弐恛╶嫌媯ᵇ☶柬㙈ᴗẍ䐶ȡ嬅∍⬔₄
廬㊳ℾ䑃㶞㋠ⶵȡ
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
3
Sony CONFIDENTIAL
For Authorized Servicer
1. SERVICING NOTES ................................................ 4
2. DISASSEMBLY
2-1. Disassembly Flow.............................................................. 24
2-2. Earpad Assy ....................................................................... 25
2-3. How to Install the Earpad Assy.......................................... 26
2-4. Screen (R) (R-ch)............................................................... 27
2-5. Battery Wire Connector (R-ch).......................................... 28
2-6. Ornament R Assy (R-ch).................................................... 29
2-7. THM R Board (R-ch)......................................................... 30
2-8. Lithium Ion Storage Battery (R-ch)................................... 31
2-9. SUB R Board-1 (R-ch) ...................................................... 32
2-10. SUB R Board-2 (R-ch) ...................................................... 33
2-11. SUB R Board-3 (R-ch) ...................................................... 34
2-12. Housing (R) Block, Aori Cushion (R-ch) .......................... 35
2-13. Screen (L) (L-ch) ............................................................... 36
2-14. Ornament L Assy (L-ch) .................................................... 37
2-15. How to Install the Ornament L Assy (L-ch) ...................... 38
2-16. NFC L Board (L-ch) .......................................................... 39
2-17. MAIN L Board-1 (L-ch) .................................................... 40
2-18. MAIN L Board-2 (L-ch) .................................................... 41
2-19. MAIN L Board-3 (L-ch) .................................................... 42
2-20. Housing (L) Block, Aori Cushion-1 (L-ch) ....................... 43
2-21. Housing (L) Block, Aori Cushion-2 (L-ch) ....................... 44
3. EXPLODED VIEWS
3-1. Earpad Section ................................................................... 45
3-2. Right Ornament Section..................................................... 46
3-3. Left Ornament Section....................................................... 47
3-4. Right Housing Section ....................................................... 48
3-5. Left Housing Section ......................................................... 49
3-6. Headband Section .............................................................. 50
4. ACCESSORIES .......................................................... 51
TABLE OF CONTENTS
Trademarks
ŞApple, iPhone, iPod and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
ŞUse of the Made for Apple badge means that an accessory has been
designed to connect specifically to the Apple product(s) identified in
the badge, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards.
ŞAndroid is a trademark of Google LLC.
ŞThe Bluetooth® word mark and logos are registered trademarks owned
by the Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license.
ŞThe N-Mark is a trademark or registered trademark of NFC Forum, Inc. in
the United States and in other countries.
ŞThe LDAC name and logo are trademarks of Sony Corporation.
ŞUSB Type-C® and USB-C® are registered trademarks of USB
Implementers Forum.
ŞOther trademarks and trade names are those of their respective
owners.
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
4
Sony CONFIDENTIAL
For Authorized Servicer
SECTION 1
SERVICING NOTES
The SERVICING NOTES contains important information for servicing. Be sure to read this section before repairing the unit.
ABOUT REUSE OF THE LITHIUM ION STORAGE BAT-
TERY
When removing the lithium ion storage battery from adhesive sheet
fixing the battery, the lithium ion storage battery cannot be reused.
Be sure to replace them with new parts.
CHECKING THE NEW LITHIUM ION STORAGE BAT-
TERY FOR BEFORE USE AND NOTES ON HANDLING
• Checking before use
When replacing the lithium ion storage battery to the new parts, be
sure to check the exterior condition before installing the new lithium
ion storage battery in this unit.
• No external wound such as scratches
• No swell
etc.
If there are some abnormality with the exterior, do not use that lith-
ium ion storage battery.
• Notes on handling
When handling the new lithium ion storage battery, handle with
notes of the following.
• Do not drop it
If it drops accidentally, do not use that lithium ion storage bat-
tery.
• Do not scratch with tweezers or other sharp objects
If it scratches accidentally, do not use that lithium ion storage
battery.
ABOUT THE TYPE OF THE LITHIUM ION STORAGE
BATTERY
There are two types of the lithium ion storage battery of built-in to
this unit (Refer to figure below).
However, the repair parts of the lithium ion storage battery is one
type.
Therefore, the shape of the lithium ion storage battery before re-
placement and the lithium ion storage battery after replacement may
be different, but it can be used without problems.
Type-A
There is repair parts for this
lithium ion storage battery.
Type-B
There is no repair parts for this
lithium ion storage battery.
It will be replaced for Type-A.
DESTINATION ABBREVIATIONS
The following abbreviations for model destinations are used in this
service manual.
Note: The destination code is used when setting the destination.
Abbrevia-
tion
Country or region indicated by
Abbreviation
Destina-
tion code
US, CND,
LA
US, Canadian and Latin American
area models UC
AEP, UK
European area, East European area,
CIS area (Moldova, Ukraine) and
Middle East area (Israel) models
CE7
E, AUS,
JE, RU
CIS area (Except for Moldova,
Ukraine), Middle East area (Except for
Israel), South East Asian area (Except
for India), East Asian area (Except for
China), Oceania area, African area
and Tourist models
E
CH Chinese model CN
IND Indian model IN
MODEL IDENTIFICATION
Refer to the model number engraved on the left inside of the head-
band.
Also, the serial number is displayed at the bottom of model number
engraved.
Note 1: The contents of model number might be changed in the midway of
production.
Note 2: Use the notation in the angle brackets (< >) in the figure below
when writing the noise canceling adjustment value and initial set-
ting information at the MAIN L board replacement.
Note 3: “XXXXXXX” at the
bottom of model nunber
indicates the serial
number.
(US, CND, LA) <UC>
(AEP, UK) <CE7>
(E, AUS, JE, RU, IND) <E> <IN>
(CH) <CN>
COLOR VARIATIONS
US, CND, LA : (B) Black, (S) Platinum Silver, (L) Blue
Except US, CND, LA: (B) Black, (S) Platinum Silver
Ver. 1.1
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
5
Sony CONFIDENTIAL
For Authorized Servicer
RESETTING METHOD
If this unit does not operate properly, perform the reset of this unit
with following procedure.
Note 1: Even if this work is performed, device pairing information is not
deleted.
Resetting procedure:
1. Connect this unit to a booted PC or optional USB AC adaptor
using the supplied USB Type-C®cable, set the charge status.
2. After connecting, check that the right channel side indicator lights
up in red.
Note 2: When charging is completed, the right channel indicator lights up in
red for a few seconds and then turns off.
3. Press the [1] button and [CUSTOM] button simultaneously.
4. This unit be reset.
Note 3: After resetting, when charging this unit, disconnect the USB Type-
C®cable from this unit and connect it again.
Connection:
or
[CUSTOM]
button
[1] button
Red
INITIALIZING METHOD
After completion of repairs, be sure to perform the following proce-
dure to initialize this unit.
Note 1: When this work is performed, all device pairing information is
deleted and settings return to factory defaults.
Initializing procedure:
1. Check that the USB Type-C®cable is not connected to this unit,
and press the [1] button for about 2 seconds to turn the power
off.
Note 2: If already power is turned off, check the USB Type-C®cable is not
connected, perform the work from step 2.
about 2
seconds
Blue Light off
2. Press the [1] button and [CUSTOM] button simultaneously for
about 7 seconds or longer, then the left channel side indicator
(blue) flashes 4 times and the settings automatically return to
factory defaults.
Press simultaneously for
about 7 seconds or longer.
[CUSTOM]
button
[1] button
Note 3: When this unit is initialized, it might not be able to connect to
iPhone or PC. In that case, delete the registration of this unit on
iPhone or PC, register the device again.
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
6
Sony CONFIDENTIAL
For Authorized Servicer
NFC CONNECTION CHECKING METHOD
Preparation:
• NFC compatible device (smartphone or music player etc.)
Procedure:
1. Turn on the NFC function of the NFC compatible device.
(For details, refer to the instruction manual of NFC compatible
device. The figure below is a reference example)
2. Press the [1] button for about 2 seconds to turn the power on.
about 2
seconds
Light off Blue
3. Touch the N-mark part of the NFC compatible device to the
N-mark part of this unit, the left channel side indicator (blue)
flashing changes from slow to fast, and the connection is com-
pleted.
(After connection is complete, the left channel side indicator
(blue) flashing is return to slow)
Note 1: If the screen of the NFC compatible device is locked, unlock it and
then touch it.
(slow)
(slow)
(fast)
(N-mark touch)
(connected)
Blue
4. Attach this unit and then the audio playback from the NFC com-
patible device, and check that the sound is output normally from
the left and right.
or
double
taps
5. Touch the N-mark part of this unit with N-mark of the NFC
compatible device again to disconnect the connection, and com-
plete the operation check.
Note 2: Before returning this unit to the customer, refer to “INITIALIZING
METHOD” on page 5 and delete the Bluetooth device pairing in-
formation.
NOTE FOR REPLACING THE MAIN L BOARD
When the MAIN L board is replaced with a new board, it is neces-
sary to write the necessary information to the MAIN L board and
NFC L board always.
Do the work according to the contents below.
Note 1: Just replacing the MAIN L board, this unit do not operate normally.
Note 2: It is not possible to replace the MAIN L board only. When replacing
the MAIN L board, be sure to replace the MAIN L board and NFC
L board simultaneously. In addition to the MAIN L board, the NFC
L board and NFC L board connection wire are included in the repair
parts of MAIN L board.
1. Prepare the Equipment
Prepare the following equipment.
a. Windows PC
b. NFC compatible smartphone
(Android phone: Android OS 8.0 or later) (See Note 1)
c. USB cable for the smartphone
d. NVDM Writing Application (HP Value Writer.zip) (See Note 2)
e. NFC Tag Data Writing Application (nfc_tag_writer_2.0.3.zip)
(See Note 2, 3)
Note 1: Install the file manager application (ASTRO file manager, File Ex-
port, etc.) in advance to the smartphone.
Note 2: Confirm the method of obtaining the each application and its latest
version with the each service headquarter.
Note 3: “2.0.3” in the file name indicates the version of NFC Tag Data Writ-
ing Application. Always use the latest version of the NFC Tag Data
Writing Application.
Example: nfc_tag_writer_2.0.3.apk
version
a. PC b. NFC compat-
ible Smartphone
c. USB cable for
the smartphone
Android
d. NVDM Writing
Application
e. NFC Tag Data
Writing
Application
HP Value
Writer.zip
nfc_tag_writer
_2.0.3.zip
Notes on the use of the NFC Tag Data Writing Application
• The NFC Tag Data Writing Application may be updated ir-
regularly.
Always use the latest version of the NFC Tag Data Writing
Application.
The version of NFC Tag Data Writing Application is repre-
sented by the file name of NFC Tag Data Writing Application.
Example: nfc_tag_writer_2.0.3.apk
version
• Be sure to uninstall older versions of the NFC Tag Data Writ-
ing Application before installing the latest version.
• The NFC Tag Data Writing Application is also used in mod-
els other than the headphone category, and there are multiple
types. If multiple NFC Tag Data Writing Applications are in-
stalled on a smartphone, do not launch more than one at the
same time.
• The NFC Tag Data Writing Application varies depending on
your model.
Be sure to use the specified NFC Tag Data Writing Application.
Use of not specified NFC Tag Data Writing Application is
strictly prohibited.
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
7
Sony CONFIDENTIAL
For Authorized Servicer
2. Write Each Information and Value to the MAIN L Board
(Serial Number, Color Information, Destination Informa-
tion, IR Calibration Value, Noise Canceling Adjustment
Value)
2-1. Check the Information of Repairing Model
It is necessary to check the information of repairing model in ad-
vance.
Check the following information.
Model name:
WH-1000XM4
WH-1000XM4
Serial number:
Note 1: Refer to following “Checking Procedure of Serial Number”.
• Checking Procedure of Serial Number
Check the serial number
that is engraved on the
left inside of the
headband.
Check the first number
of serial number.
Check the serial number
at the time of purchase
to the customer.
Record the serial
number.
The first
number is
not “9”.
The MAIN L board
cannot be replaced.
Replace the headphones
assy with a new part.
Record the serial
number (first number “9”)
that is engraved on this
unit.
The serial
number at
time of
purchase
is unknown.
Replace the
headphones
assy.
The first
number
is “9”.
Discriminate the whether
headband assy
replacement or
headphones assy
replacement at inside
of service side.
Checking the
serial number
at the time of
purchase is
complete.
Record the serial
number at the time of
purchase that you
checked to the customer.
Replace the
headband
assy.
– Continued on upper right –
Main unit color:
Select from the following color names.
Black (Black), Silver (Platinum Silver), Blue (Blue)
Destination code:
Select the correct destination from the following destination code.
UC (US, CND, LA), CE7 (AEP, UK), E (E, AUS, JE, RU), CN
(CH), IN (IND)
Note 2: When checking the destination, refer to “MODEL IDENTIFICA-
TION” on page 4.
2-2. Obtaining the Noise Canceling Adjustment Value and
Initial Setting Information of Repairing Model
Send the model information that prepared in the “2-1. Checking the
Information of Repairing Model” on this left to the service head-
quarter by e-mail, refer to returned e-mail from the service head-
quarter, and obtain the noise canceling adjustment value and initial
setting information.
Description example of e-mail sent to the service head-
quarter:
Note 1: The following is a description example.
Note 2: Do not insert spaces between all characters, and enter all alphanu-
meric characters.
Subject [Request]Sony_Headphones_MB_value
Body Modelname:WH-1000XM4
SerialNumber:1300108
Color:Black
Destination:CE7
Contents example of e-mail that will be returned from the
service headquarter:
Note 3: The following is a description example. The order of description
might be different.
Body Model_Name
CE7
Black
Destination
-1.2
FF_Gain_L
0
FF_Gain_R
0.8
FB_Gain_L
1.6FB_Gain_R
0700IR Calibration
Serial Number
Color
WH-1000XM4
1300108
Ver. 1.1
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
8
Sony CONFIDENTIAL
For Authorized Servicer
2-3. Transfer the NVDM Writing Application from the PC
to the Smartphone and Install it
Install the NVDM Writing Application for writing the each informa-
tion and value to the MAIN L board to the smartphone, and prepare
the smartphone.
Procedure:
1. Unzip the NVDM Writing Application (HP Value Writer.zip)
prepared in the “1. Prepare the Equipment” on page 6 on the PC,
and check that there are “nvdm-writer_0.0.6.apk” in the folder.
HP Value Writer.zip HP Value Writer
nvdm-writer_0.0.6.apk
Unzip
2. Using the USB cable for the smartphone, connect the smart-
phone and the PC.
USB cable
3. Transfer the “nvdm-writer_0.0.6.apk” prepared in step 1 from
the PC to the root directory of smartphone.
nvdm-writer
_0.0.6.apk
4. Disconnect the smartphone from the PC.
USB cable
– Continued on upper right –
5. Start the file manager application on the smartphone, and open
the location where “nvdm-writer_0.0.6.apk” is stored.
nvdm-writer_0.0.6.apk
nvdm-writer_0.0.6.apk
file manager
application
6. Tap the “nvdm-writer_0.0.6.apk”, and install it to the smartphone.
Note 1: The installing method might be different depending on Android OS
version. If you do not know how to install, confirm with the each
service headquarter.
Note 2: When it cannot be installed, tap the “Settings” →“Security”, check
the “Unknown sources” checkbox, and then install it.
Also, after completing the installation, be sure to uncheck the “Un-
known sources” checkbox.
(Depending on the version of Android OS, this setting might not
exist)
nvdm-writer_0.0.6.apk
nvdm-writer_0.0.6.apk
7. Press the [1] button on the headset for about 7 seconds, and
release your finger while the indicator next to [1] button repeats
flashing twice in blue to set the pairing mode.
Note 3: For detailed method on setting the headset to pairing mode, refer to
operating instructions of headset.
about 7
seconds
Blue repeat
flashing
twice
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
9
Sony CONFIDENTIAL
For Authorized Servicer
8. Pairing the smartphone that installed the “nvdm-writer_0.0.6.apk”
with headset. (Bluetooth connection)
Note 4: For Bluetooth connection method, refer to instruction manual of
smartphone to be used or operating instructions of headset.
Note 5: It cannot be made NFC connection at this point.
Bluetooth
WH-1000XM4
Bluetooth
WH-1000XM4
9. Tap the “NVDM Writer” icon displayed on the smartphone screen
to start the application.
NVDM Writer
10. Perform the initial setting by operating the screen displayed on the
smartphone screen in the following order.
Note 6: Fig. 1 to Fig. 4 might or might not be displayed. If it is displayed,
operate in the following order and do not change the settings.
Tap the [OK]. Tap the [NEXT]. Tap the [LATER].
(Do not tap the [USE])
Tap the [GO TO THE
DASHBOARD].
Note 7: “Black”and “UC”are displayed, but
they are the default display and have
nothing to do with headset information.
Fig. 1 Fig. 2 Fig. 3
Fig. 5 Fig. 4
This completes the preparation of smartphone to use for NVDM writing.
In this state, proceed to the “2-4. Write the Serial Number, Color In-
formation, Destination Information, IR Calibration Value and Noise
Canceling Adjustment Value” on this right.
2-4. Write the Serial Number, Color Information, Destina-
tion Information, IR Calibration Value and Noise Can-
celing Adjustment Value
Write the each information and value to the MAIN L board of head-
set by using the NVDM Writing Application.
Procedure:
Note 1: The values shown in each figure are reference examples.
1. Tap the [READ] displayed on the center left side of application
screen in the state of step 10 in “2-3. Transfer the NVDM Writ-
ing Application from the PC to the Smartphone and Install it” on
this left.
Note 2: “Black” in the “Color setting” column and “UC” in the “Destina-
tion” column are displayed, but these display disappears by tapping
the [READ].
2. Check that the values are displayed in the “BDA Value” column
and “Hash Value” column on the application screen.
Note 3: The values are not displayed in columns other than the “BDA Value”
and “Hash Value”.
Check
Check
045D4B7D67BD
3. Tap the “Serial Number” column on the application screen, enter
the 7 digits serial number prepared in “2-1. Check the Infor-
mation of Repairing Model” on page 7 to the displayed pop-up
screen and tap the [OK].
Note 4: Before tapping the [OK], make sure that entered serial number is
correct.
Note 5: After tapping the [OK], the “Serial Number” column is automati-
cally given 9 digits 0, and the total 16 digits serial number is dis-
played.
045D4B7D67BD
Input
045D4B7D67BD 045D4B7D67BD
Check
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
10
Sony CONFIDENTIAL
For Authorized Servicer
4. Tap the “Color Setting” column on the application screen, select
and tap the main unit color of headset from the displayed lists.
Note 6: When the main unit color is black, select the “Black”. When the
main unit color is platinum silver, select the “Silver”. When the
main unit color is blue, select the “Blue”.
045D4B7D67BD
045D4B7D67BD
Check
045D4B7D67BD
5. Tap the “Destination” column on the application screen, select
and tap the destination of headset prepared in “2-1. Check the
Information of Repairing Model” on page 7 from the displayed
lists.
Note 7: When checking the destination, refer to “MODEL IDENTIFICA-
TION” on page 4 and check the destination.
045D4B7D67BD
045D4B7D67BD 045D4B7D67BD
Check
6. Tap the “IR calib” column on the application screen, enter the
4 digits IR calibration value prepared in “2-1. Check the Infor-
mation of Repairing Model” on page 7 to the displayed pop-up
screen and tap the [OK].
Note 8: Before tapping the [OK], make sure that entered IR calibration
value is correct.
045D4B7D67BD
Input
045D4B7D67BD 045D4B7D67BD
Check
– Continued on upper right –
7. Tap the “FB_L” column on the application screen, enter the
FB_L value of noise canceling adjustment value prepared in “2-
1. Check the Information of Repairing Model” on page 7 to the
displayed pop-up screen and tap the [OK].
Note 9: Input the FB_L value to one decimal place. However, if one digit
after the decimal point is “0”, input is not required.
(There is no problem when enter “0” for one decimal place)
Note 10: Before tapping the [OK], make sure that entered FB_L value is
correct.
Input Check
045D4B7D67BD
-1.2
045D4B7D67BD
045D4B7D67BD
8. Tap the “FB_R” column on the application screen, enter the
FB_R value of noise canceling adjustment value prepared in “2-
1. Check the Information of Repairing Model” on page 7 to the
displayed pop-up screen and tap the [OK].
Note 11: Input the FB_R value to one decimal place. However, if one digit
after the decimal point is “0”, input is not required.
(There is no problem when enter “0” for one decimal place)
Note 12: Before tapping the [OK], make sure that entered FB_R value is
correct.
045D4B7D67BD
-1.2
CheckInput
-1.2
0
045D4B7D67BD
-1.2
045D4B7D67BD
9. Tap the “FF_L” column on the application screen, enter the
FF_L value of noise canceling adjustment value prepared in “2-
1. Check the Information of Repairing Model” on page 7 to the
displayed pop-up screen and tap the [OK].
Note 13: Input the FF_L value to one decimal place. However, if one digit
after the decimal point is “0”, input is not required.
(There is no problem when enter “0” for one decimal place)
Note 14: Before tapping the [OK], make sure that entered FF_L value is
correct.
045D4B7D67BD
0
-1.2
CheckInput
-1.2
0
0.8
045D4B7D67BD
0
-1.2
045D4B7D67BD
– Continued on next page –
Ver. 1.1
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
11
Sony CONFIDENTIAL
For Authorized Servicer
10. Tap the “FF_R” column on the application screen, enter the
FF_R value of noise canceling adjustment value prepared in “2-
1. Check the Information of Repairing Model” on page 7 to the
displayed pop-up screen and tap the [OK].
Note 15: Input the FF_R value to one decimal place. However, if one digit
after the decimal point is “0”, input is not required.
(There is no problem when enter “0” for one decimal place)
Note 16: Before tapping the [OK], make sure that entered FF_R value is
correct.
045D4B7D67BD
0.8
CheckInput
-1.2
0
0.8
-1.2
0
0.8
1.6
045D4B7D67BD
0.8
-1.2
0
045D4B7D67BD
11. Tap the [CALCULATE2] on the application screen, check that
the automatically calculated values are displayed on the right
side of “FB_L”, “FB_R”, “FF_L” and “FF_R”.
0.80.8 Values calculated
automatically are
displayed.
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
-1.2
0
1.6
045D4B7D67BD
0.80.8
-1.2
0
1.6
045D4B7D67BD
045D4B7D67BD
12. Check that the entered values is correct, and tap [WRITE] on the
top side of application screen to write the information.
Note 17: The pop-up screen in process is displayed on the application
screen, when the display disappears, writing is completed.
The pop-up screen where the
process is being executed is
displayed, and the process
is completed when pop-up
screen disappears.
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
Check
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
XXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXX.
045D4B7D67BD
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
045D4B7D67BD
045D4B7D67BD045D4B7D67BD
– Continued on upper right –
13. Scroll the application screen to the top, tap the [OK] on the pop-
up screen displayed by tapping the [POWER OFF] button on the
center side of application screen.
Check that headset has turned the power offand that application
screen has switched to the connection screen.
Light offLight off Blue
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2CB8
133C79A1
045D4B7D67BD
-1.2
0
0.8
1.6
0DEF7784
10000000
118B2C B8
133C79A1
045D4B7D67BD
045D4B7D67BD 045D4B7D67BD
14. End the NVDM Writer Application (NVDM Writer).
15. Turn the power on by pressing the [1] button for about 2 sec-
onds until the blue indicator on the left channel side of headset
flashes, start the NVDM Writing Application (NVDM Writer) of
smartphone.
Note 18: The smartphone and headset automatically make Bluetooth con-
nection.
NVDM Writer
about 2
seconds
Light off Blue
Start the application.
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
12
Sony CONFIDENTIAL
For Authorized Servicer
16. Tap the [READ] displayed on the center left side of application
screen, check that displayed information are correct values.
Note 19: If there is a mistake in the displayed information, perform the ap-
plicable steps from step 3 to step 11, and tap the [WRITE] dis-
played on the top of application screen.
0DEF7784
10000000
118B2CB8
133C79A1
Check that correct
values are displayed.
Check that values
are displayed.
Values of these columns
is not displayed.
045D4B7D67BD
17. Record the value displayed in “BDA Value” column on the cen-
ter of application screen in the memo etc..
Note 20: The BDA value (Bluetooth address) recorded in this process is
written to the NFC L board in next process.
Note 21: Record the value without mistake. If an incorrect value is written
to the NFC L board, the NFC function cannot be used.
Record
045D4B7D67BD
0DEF7784
10000000
118B2CB8
133C79A1
045D4B7D67BD
18. End the NVDM Writer Application (NVDM Writer).
This completes the writing work of necessary each information and
value after replacing the MAIN L board.
Continuously, refer to “3. Write the Bluetooth Address to the NFC L
Board” on this right, and perform the work.
3. Write the Bluetooth Address to the NFC L Board
3-1. Transfer the NFC Tag Data Writing Application from
the PC to the Smartphone and Install it
Install the NFC Tag Data Writing Application for writing the Blue-
tooth address to the NFC L board to the smartphone.
If the NFC Tag Data Writing Application is already installed,
check the following, and proceed to the “3-2. Write the Bluetooth
Address” on page 13.
• Be absolutely sure that the NFC Tag Data Writing Application
supports your model.
• Confirm that the NFC Tag Data Writing Application is the lat-
est version.
The version of NFC Tag Data Writing Application is repre-
sented by the file name.
Example: nfc_tag_writer_2.0.3.apk
version
Procedure:
Note 1: The each figure is a reference example or an image figure.
1. Unzip the NFC Tag Data Writing Application (nfc_tag_writer_
2.0.3.zip) prepared in the “1. Prepare the Equipment” on page
6 on the PC.
Note 2: Be absolutely sure that the NFC Tag Data Writing Application sup-
ports your model and that it is the latest version.
nfc_tag_writer
_2.0.3.zip
nfc_tag_writer
_2.0.3.apk
Unzip
2. Using the USB cable for the smartphone, connect the smart-
phone and the PC.
USB cable
3. Transfer the “nfc_tag_writer_2.0.3.apk” prepared in step 1 from
the PC to the root directory of smartphone.
nfc_tag_writer
_2.0.3.apk
4. Disconnect the smartphone from the PC.
USB cable
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
13
Sony CONFIDENTIAL
For Authorized Servicer
5. Start the file manager application on the smartphone, and open
the location where “nfc_tag_writer_2.0.3.apk” is stored.
nfc_tag_writer_2.0.3.apk
nfc_tag_writer_2.0.3.apk
file manager
application
6. Tap the “nfc_tag_writer_2.0.3.apk”, and install it to the smart-
phone.
Note 3: The installing method might be different depending on Android OS
version. If you do not know how to install, confirm with the each
service headquarter.
Note 4: When it cannot be installed, tap the “Settings” →“Security”, check
the “Unknown sources” checkbox, and then install it.
Also, after completing the installation, be sure to uncheck the “Un-
known sources” checkbox.
(Depending on the version of Android OS, this setting might not
exist)
nfc_tag_writer_2.0.3.apk
nfc_tag_writer_2.0.3.apk
7. Complete the installation of NFC Tag Data Writing Application
(MDR NFC Writer).
NFC Tag Data
Writing Application
This completes the installing the NFC Tag Data Writing Application.
Proceed to the “3-2. Write the Bluetooth Address” on this right.
3-2. Write the Bluetooth Address
Write the Bluetooth address to the NFC L board of headset with us-
ing the NFC Tag Data Writing Application.
Procedure:
Note 1: The each figure is a reference example or an image figure.
Procedure:
1. Prepare the Bluetooth address recorded in step 16 of “2-4. Write
the Serial Number, Color Information, Destination Information,
IR Calibration Value and Noise Canceling Adjustment Value”
on page 12.
2. Turn on the NFC function of the smartphone used in “3-1. Transfer
the NFC Tag Data Writing Application from the PC to the Smart-
phone and Install it” on page 12.
Note 2: Locations and names with settings may differ depending on the ver-
sion of Android OS. Refer to the instruction manual of smartphone
for more details.
Put a
check
3. Tap the icon of “MDR NFC Writer” on the smartphone screen to
start the application.
4. Tap the [Write] button on the application screen.
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
14
Sony CONFIDENTIAL
For Authorized Servicer
5. Tap the [List] button on the application screen and select the
model name (WH-1000XM4) of applicable headset from the
displayed list, or tap the “Bluetooth Local Name” and directly
input the model name (WH-1000XM4) with the keyboard on the
smartphone.
When selecting the
model name.
When input to directly
with the keyboard.
Do not tap [Write]
button in this step.
6. Tap the “Bluetooth Device Address” on the application screen
and directly input the Bluetooth address (BD_ADDR) prepared
in step 1 with the keyboard on the smartphone.
Note 3: In the case of this unit, [QR] button is not used.
Not used
When input to directly
with the keyboard.
Do not tap [Write]
button in this step.
WH-1000XM4
7. Check that “Read-only” checkbox on the application screen is
unchecked, and then tap the [Write] button, check that “Writ-
able” is displayed.
Unchecked
Tap
Check
WH-1000XM4
WH-1000XM4
– Continued on upper right –
8. Press the [1] button for about 2 seconds until the blue indicator
of left channel side on the headset flashes, and turn the power on.
Note 4: If power of headset is already turned on, proceed to next step.
Note 5: When the battery level of headset is low, the red indicator flashes
for about 15 seconds. In that case, press the [1] button for about
2 seconds to turn offthe power of headset, connect the headset to a
USB AC adapter or a PC with a USB Type-C cable, and charge for
a while.
about 2
seconds
Blue
9. In the state of step 7 for the smartphone, touch the N-mark part
of the smartphone to the N-mark part of headset.
10. Check that “Success!” is displayed on the application screen,
and tap the [OK] button.
Note 6: When “Success!” is not displayed, refer to “3-3. Error Display” on
page 16.
Check
11. End the NFC Tag Data Writing Application (MDR NFC Writer).
12. Check the connection between the smartphone and the headset
several times using the NFC function to check there is no prob-
lem.
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
15
Sony CONFIDENTIAL
For Authorized Servicer
13. Start the NFC Tag Data Writing Application (MDR NFC Writer)
again.
14. Tap the [Write] button on the application screen.
15. Check the “Read-only” checkbox on the application screen, tap
the [Write] button, and check that “Read-only” is displayed.
Put a
check
Tap
Check
WH-1000XM4
WH-1000XM4
16. In the state of step 15 for the smartphone, touch the N-mark part
of the smartphone to the N-mark part of headset.
– Continued on upper right –
17. Check that “Success!” is displayed on the application screen,
and tap the [OK] button.
Note 7: When “Success!” is not displayed, refer to “3-3. Error Display” on
page 16.
Check
18. Tap the [Read] button on the application screen.
19. In the state of step 18 for the smartphone, touch the N-mark part
of the smartphone to the N-mark part of headset.
20. Check that “BD_ADDR” displayed on the smartphone screen
matches the Bluetooth address (BD_ADDR) checked in step 1
and the “MODE” column is “0000 (Read-only)”.
Check
21. End the NFC Tag Data Writing Application (MDR NFC Writer).
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
16
Sony CONFIDENTIAL
For Authorized Servicer
Refer to the following as necessary.
“3-3. Error Display” (this right)
“3-4. Check Method of the NFC Tag Data” (page 17)
“3-5. The Factor that One Touch Connection (NFC function) is Im-
possible” (page 18)
This completes the writing work of necessary each information and
values after replacing the MAIN L board.
This completes the writing work of Bluetooth address for NFC L
board.
3-3. Error Display
When the writing of NFC tag data has failed, “Error” is displayed on
the smartphone screen.
When “Error” is displayed, operate according to the procedure be-
low.
Error display screen
(reference example)
Procedure:
1. Tap the [OK] button of “Error” display screen.
When error is displayed in
step 10 of “3-2. Write the
Bluetooth Address”.
When error is displayed in
step 17 of “3-2. Write the
Bluetooth Address”.
WH-1000XM4
WH-1000XM4
2. When error is displayed in step 10 of “3-2. Write the Bluetooth
Address” on page 14, operate from step 9 on page 14 again, also
when is displayed in step 17 of “3-2. Write the Bluetooth Ad-
dress” on page 15, operate from step 16 on page 15 again.
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
17
Sony CONFIDENTIAL
For Authorized Servicer
3. If “Error” is displayed again in step 10 of “3-2. Write the Blue-
tooth Address” on page 14 or step 17 of “3-2. Write the Blue-
tooth Address” on page 15, after tapping the [OK] button on
“Error” display screen, tap the “ ” (or “g” etc.) of smartphone
twice and return to the first screen.
(The figure below is a reference example when error is displayed
in step 10 on page 14)
twice
WH-1000XM4
4. Tap the [Read] button on the application screen.
5. In the state of the above step 4 for the smartphone, touch the N-
mark part of the smartphone to the N-mark part of headset.
6. Check that the “MODE” column displayed on the application
screen is other than “0000 (Read-only)”.
Note: If “MODE” column is displayed as “0000 (Read-only)”, NFC tag data
cannot be written. Prepare another new MAIN L board (Including NFC L
board) again, and restart from the “2-4. Write the Serial Number, Color
Information, Destination Information, IR Calibration Value and Noise
Canceling Adjustment Value” on page 9.
(The NFC L board indicated as “0000 (Read-only)” cannot be used)
Check
3-4. Check Method of the NFC Tag Data
If you want to check the NFC tag data of headset after completing
writing NFC tag data, check to the following procedure.
Procedure:
1. Press the [1] button for about 2 seconds until the blue indicator
of left channel side on the headset flashes, and turn the power on.
Note 1: If power of headset is already turned on, proceed to next step.
Note 2: When the battery level of headset is low, the red indicator flashes
for about 15 seconds. In that case, press the [1] button for about
2 seconds to turn offthe power of headset, connect the headset to a
USB AC adapter or a PC with a USB Type-C cable, and charge for
a while.
about 2
seconds
Blue
2. Touch the N-mark part of the smartphone to the N-mark part of
headset.
3. Tap the “NVDM Writer” icon on the smartphone screen to start
the application.
NVDM Writer
4. Tap the [READ] displayed on the center left side of application
screen, record the value displayed in “BDA Value” column in
the memo etc..
Record
045D4B7D67BD
5. End the NVDM Writing Application (NVDM Writer).
– Continued on next page –
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
18
Sony CONFIDENTIAL
For Authorized Servicer
6. Tap the “MDR NFC Writer” icon on the smartphone screen to
start the application.
MDR NFC
Writer
7. Tap the [Read] button on the application screen.
8. In the state of step 7 for the smartphone, touch the N-mark part
of the smartphone to the N-mark part of headset.
– Continued on upper right –
9. Check that the alphanumeric characters of “BD_ADDR” dis-
played on the application screen matches the value recorded in
step 4.
Note 3: If “0000 (Read-only)” is displayed in the “MODE” column on
the application screen, NFC tag data has been written without any
problem and cannot be changed.
Check
match 045D4B7D67BD
MDR NFC Writer screen Value recorded
in step 4
10. End the NFC Tag Data Writing Application (MDR NFC Writer).
11. Press the [1] button for about 2 seconds until the blue indicator
of left channel side on the headset lights offto turn the power off,
and then perform the “INITIALIZING METHOD” on page 5 to
delete the connection history.
about 2
seconds
Blue Light off
Perform the
initialization
3-5. The Factor that One Touch Connection (NFC function) is Impossible
The four following factors are considered as the factor that one touch connection (NFC function) is impossible.
Guess and check the defective factor by each checking result.
Note: The four failure factors are examples.
Factor Bluetooth manual con-
nection check by user NFC tag data check Bluetooth manual connec- tion check by servicing
NFC one touch connection
check with smartphone
1Left channel side
defect NG ―NG NG
2 NFC L board defect OK NG OK NG
3NFC tag data writing
failure OK NG OK NG
4 Smartphone trouble OK OK OK NG
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
19
Sony CONFIDENTIAL
For Authorized Servicer
4. Check the Operation of Headset
After completing the writing of each information to the MAIN L
board and NFC L board, be sure to check the operation of headset
according to the following.
Procedure:
Note 1: When the headphone exclusive application (Headphones Connect)
is not installed on the smartphone, installing the headphone exclu-
sive application (Headphones Connect) in advance, and then check
it.
Note 2: If already power is turned on, turn the power offonce, and then
check it.
1. Attach the headset.
2. Press the [1] button on the headset for about 2 seconds until the
blue indicator of left channel side flashes, turn the power on, and
check the language of voice guidance.
Note 3: When the battery level is low, the red indicator flashes for about
15 seconds. In that case, press the [1] button for about 2 seconds
to turn offthe power of headset, connect the headset to a USB AC
adapter or a PC with a USB Type-C cable, and charge for a while.
Press the [1] button
for about 2 seconds.
Voice guidance
When set to “CN” : Chinese
When set to other than “CN” : English
Note 4: If you cannot hear the voice guidance
in the above language, the correct
destination information has not been
written. Write each information again.
3. Turn on the NFC function of the NFC compatible smartphone
installed the headphone exclusive application (Headphones Con-
nect).
(For details, refer to the instruction manual of NFC compatible
smartphone. The figure below is a reference example)
– Continued on upper right –
4. Touch the N-mark part of the NFC compatible smartphone to
the N-mark part of headset, the left channel side indicator (blue)
flashing changes from slow to fast, and the connection is com-
pleted.
(After connection is complete, the left channel side indicator
(blue) flashing is return to slow)
Note 5: If the smartphone screen is locked, unlock it and then touch it.
(slow)
(slow)
(fast)
(N-mark touch)
(connected)
Blue
5. Start the headphone exclusive application (Headphones Con-
nect) on the smartphone, and check that headset of same color as
the main unit color is displayed on the smartphone screen.
same
color
6. Press the [CUSTOM] button repeatedly to change the noise can-
celing function ON or OFF, and check that noise canceling ef-
fect is fully obtained and that there is no difference in the noise
canceling effect between the left and right channels.
Note 6: Adjust the amount of noise canceling with Headphones Connect,
and check the effect.
[CUSTOM]
button
7. Remove the headset from your ears, initialize the headset.
Note 7: Refer to “INITIALIZING METHOD” on page 5 for initializing
method.
This thoroughly completes the writing of necessary information af-
ter replacing the MAIN L board.
SYSSET
2020/09/0901:17:45(GMT+09:00)

WH-1000XM4
20
Sony CONFIDENTIAL
For Authorized Servicer
DISASSEMBLY PROHIBITION AND PARTS REPLACEMENT
THAT AFFECT THE NOISE CANCELING FUNCTION
The precise noise canceling function of this unit is adjusted in the
production process.
Therefore, it is not possible to disassemble the portion affecting the
adjustment of the noise canceling function or to replace the single
parts affecting it.
Be sure to refer to the below before disassembling this unit.
• Disassembly Prohibition of Front Plate Portion
Do not disassemble the left and right front plate portion.
If disassembling the front plate portion, malfunction will occur in
adjustment value of the noise canceling function.
Note 1: Do not touch the rear resistor (left).
Noise canceling performance etc.
might be affected.
Note 2: Do not touch the rear resistor (right).
Noise canceling performance etc.
might be affected.
– Left front plate interior
(internal side) –
Disassembly of parts other
than ornament, MAIN L
board and NFC L board
are prohibited.
– Right front plate interior
(internal side) –
Disassembly of parts other
than ornament, SUB R board,
THM R board and lithium ion
storage battery are prohibited.
– Left front plate interior
(front side) –
Disassembly of parts other
than earpad, screen and
ornament fixing screw are
prohibited.
– Right front plate interior
(front side) –
Disassembly of parts other
than earpad, screen and
ornament fixing screw are
prohibited.
• Parts Replacement
It is not possible for replacement of left and right front plate portion,
or replacement of electret cap microphone only.
When the left and right front plate portion or electret cap micro-
phone is defective, replace with the SV headphones assy (EXPLOD-
ED VIEWS: Ref. No. HPN1) including them.
front plate portion (L-ch) front plate portion (R-ch)
– Left front plate inner view – – Right front plate inner view –
electret cap
microphone
electret cap
microphone
SV headphones assy
(EXPLODED VIEWS: Ref. No. HPN1)
– L-ch –
– R-ch –
(Refer to “COMPONENT PARTS OF SV HEADPHONES ASSY”
on page 22 for component parts of SV headphones assy)
SYSSET
2020/09/0901:17:45(GMT+09:00)
