Sony ECM-W2BT Reference guide

Help Guide
Wireless Microphone
ECM-W2BT
Use this Help Guide when you have issues or questions on how to use your wireless microphone.
Compatible cameras
The Wireless Microphone ECM-W2BT (referred to below as “this unit”) is compatible with a camera
that has a Multi Interface Shoe such as a Sony Interchangeable Lens Digital Camera (referred to
below as “camera”).
- Even if your camera has a Multi Interface Shoe, you may be unable to use it with this unit or some
functions may not work.
- The receiver and the microphone are factory-set to communicate with each other. Therefore,
operations usually needed for Bluetooth devices such as pairing and passkey input are not
necessary. Communication is not possible with a receiver and microphone not sold as a pair,
multiple microphones, or any other Bluetooth device such as a smartphone, computer, etc.
For camera models compatible with this unit, view here. (Another window will open.)
Locating parts and controls
Preparations
Unpacking
Charging the receiver
Charging the microphone
Attaching the receiver to a camera
Attaching the microphone to clothing
Attaching the wind screen
Storing the receiver and the microphone all together
Recording
About the mode switch
Recording
Recording with an external microphone
Lamp indications
About this unit
Notes on use
1

5-026-023-11(1) Copyright 2021 Sony Corporation
Bluetooth® Wireless Communication Technology
Specifications
Trademarks
2

Help Guide
Wireless Microphone
ECM-W2BT
Locating parts and controls
Receiver
Slide switch (MIC OUT ANALOG/Power OFF/DIGITAL)
Select “MIC OUT ANALOG” (analog audio output), “OFF” (power off), or “DIGITAL” (digital audio output).
If your camera is compatible with the digital audio interface of the Multi Interface Shoe, set the switch to “DIGITAL.”
This allows the receiver to pass the received audio to the camera with digital signals and provides audio recording
with minimum noise insertion.
When you do not intend to use the receiver, select “OFF” with this switch to conserve the battery power.
1.
Mode switch (RCVR/MIX/MIC)
Before you start recording with the camera, select a receiver mode with this switch to specify the microphone to use
for recording.
2.
Multi Interface foot3.
Power lamp (Green: Powered, Orange: Charging the battery)
Indicates the power state of the receiver or the battery charge state.
While the receiver is turned off, connecting the receiver to a computer with the supplied micro USB cable starts
charging the receiver's built-in battery and turns on the power lamp in orange.
The orange blinking power lamp indicates that battery charging is needed.
4.
LINK lamp
Indicates the connection state between the receiver and the microphone.
5.
Internal microphone6.
Micro USB terminal
Connect the supplied micro USB cable to supply power to the receiver or charge the battery.
7.
Microphone out jack
You can record audio by connecting the receiver to a camera with the supplied recording cable.
To use this jack, be sure to select “MIC OUT ANALOG” with the slide switch.
8.
3

Microphone
Connector protect holder9.
LINK lamp
Indicates the connection state between the receiver and the microphone.
1.
Power lamp (Green: Powered, Orange: Charging the battery)
Indicates the power state of the microphone or the battery charge state.
While the microphone is turned off, connecting the microphone to a computer with the supplied micro USB cable
starts charging the microphone's built-in battery and turns on the power lamp in orange.
The orange blinking power lamp indicates that battery charging is needed.
2.
Internal microphone3.
External microphone input jack
Connecting an external microphone (not supplied) to this jack automatically switches the audio input source to the
connected external microphone.
4.
Power switch
When you do not intend to use the microphone, select “OFF” with this switch to conserve the battery power.
5.
ATT switch
Select the option suitable for the audio recording volume. To record loud sounds while minimizing distortion, select
“20dB.” To record quiet sounds while amplifying the sounds, select “0dB.” “10dB” is the recommended volume level
for recording human voices. It is advised that you determine and specify the level while monitoring the volume level
meter on the camera.
6.
Micro USB terminal
Connect the supplied micro USB cable to supply power to the microphone or charge the battery.
7.
Clip
Use this clip for attaching the microphone to your clothing.
8.
Wind screen9.
4

Related Topic
Charging the receiver
Charging the microphone
Attaching the wind screen
Storing the receiver and the microphone all together
About the mode switch
Recording
Lamp indications
5-026-023-11(1) Copyright 2021 Sony Corporation
Attach the wind screen to the microphone to reduce pop noise caused by breath or strong wind.
5

Help Guide
Wireless Microphone
ECM-W2BT
Unpacking
If you find anything missing, please contact your dealer.
The number in the parentheses indicates the quantity.
Receiver (ECM-W2BT(R)) (1)
Microphone (transmitter) (ECM-W2BT(T)) (1)
Wind screen (1)
Pouch (1)
Recording cable (1)
Micro USB cable (1)
Connector protect holder (1)
Set of printed documentation
5-026-023-11(1) Copyright 2021 Sony Corporation
6

Help Guide
Wireless Microphone
ECM-W2BT
Charging the receiver
Connect the receiver to a computer to charge the receiver's built-in battery.
Note
While charging the battery, keep the receiver turned off. Turning on the receiver while charging makes the receiver ready for
power supply and stops charging.
Do not apply force to the receiver when you connect the receiver to a computer. This may cause damage to the receiver or the
computer.
When you connect the receiver to a notebook computer that is not connected to an AC power source, the battery of the notebook
computer may be depleted rapidly. Do not leave the receiver connected to the computer for a long time.
Charging the battery or the connection with customized or hand-built computers is not guaranteed. Depending on the type of
USB device used, charging may not function properly.
Operation with all computers is not assured.
Related Topic
Lamp indications
Turn off the receiver.
Charging is not possible when the receiver is turned on.
1
Open the connector cover, connect the receiver to an activated computer with the supplied micro USB
cable.
The power lamp lights in orange.
Connector cover
Micro USB cable
Power lamp
2
When charging is finished, disconnect the micro USB cable between the receiver and the computer.
Wait until the power lamp goes out to indicate that charging is finished (the battery is fully charged).
3
7

5-026-023-11(1) Copyright 2021 Sony Corporation
8

Help Guide
Wireless Microphone
ECM-W2BT
Charging the microphone
Connect the microphone to a computer to charge the microphone's built-in battery.
Note
While charging the battery, keep the microphone turned off. Turning on the microphone while charging makes the microphone
ready for power supply and stops charging.
Do not apply force to the microphone when you connect the microphone to a computer. This may cause damage to the
microphone or the computer.
When you connect the microphone to a notebook computer that is not connected to an AC power source, the battery of the
notebook computer may be depleted rapidly. Do not leave the microphone connected to the computer for a long time.
Charging the battery or the connection with customized or hand-built computers is not guaranteed. Depending on the type of
USB device used, charging may not function properly.
Operation with all computers is not assured.
Turn off the microphone.
Charging is not possible when the microphone is turned on.
1
Open the connector cover, connect the microphone to an activated computer with the supplied micro USB
cable.
The power lamp lights in orange.
Connector cover
Micro USB cable
Power lamp
2
When charging is finished, disconnect the micro USB cable between the microphone and the computer.
Wait until the power lamp goes out to indicate that charging is finished (the battery is fully charged).
3
9

Related Topic
Lamp indications
5-026-023-11(1) Copyright 2021 Sony Corporation
10

Help Guide
Wireless Microphone
ECM-W2BT
Attaching the receiver to a camera
Attach the receiver to a camera.
Note
Before attaching the receiver to the camera, charge the receiver's built-in battery sufficiently enough.
Before attaching/removing the receiver to/from the camera, be sure to turn off the receiver and the camera.
To remove the receiver
Slide the receiver in the opposite direction to when attaching.
Related Topic
Charging the receiver
5-026-023-11(1) Copyright 2021 Sony Corporation
Align the Multi Interface foot of the receiver with the Multi Interface Shoe on the camera and attach the
receiver.
Note
Firmly insert the receiver all the way into the Multi Interface Shoe of the camera.
If the built-in flash on the camera is popped up, put it down.
1
11

Help Guide
Wireless Microphone
ECM-W2BT
Attaching the microphone to clothing
Attach the microphone to your clothing.
Note
Before attaching the microphone to your clothing, charge the microphone's built-in battery sufficiently enough.
Note
If you use a medical electrical device such as a pacemaker, do not attach the microphone to your clothes, such as the breast
pocket or inner pocket. Using the microphone near a medical device may adversely affect it.
Related Topic
Charging the microphone
5-026-023-11(1) Copyright 2021 Sony Corporation
Attach the microphone to your desired location on the clothing, such as a breast pocket, with the clip.
Be sure to attach it to the location best-suited for the recording or sound conditions.
1
12

Help Guide
Wireless Microphone
ECM-W2BT
Attaching the wind screen
Attach the wind screen to the microphone to reduce pop noise caused by breath or strong wind.
Note
If the wind screen is wet, remove it from the microphone and let it dry in the shade.
When attaching or removing the wind screen, be sure to hold its chassis.
5-026-023-11(1) Copyright 2021 Sony Corporation
Fit the projected portion of the wind screen into the external microphone input jack on the microphone.
1
13

Help Guide
Wireless Microphone
ECM-W2BT
Storing the receiver and the microphone all together
Using the supplied connector protect holder, you can store the receiver and the microphone all together.
5-026-023-11(1) Copyright 2021 Sony Corporation
Slide the Multi Interface foot of the receiver into the connector protect holder.
1
Attach the microphone to the connector protect holder by hooking the clip of the microphone onto the
other side of the holder from above.
2
14

Help Guide
Wireless Microphone
ECM-W2BT
About the mode switch
Before you start recording with the camera, select a receiver mode with the mode switch.
MIC mode
Only the sound picked up by the microphone is recorded.
Both the surrounding sound of the microphone and the voice of the subject wearing the microphone are clearly
recorded when the camera is located apart from the microphone.
MIX mode
Both the sound picked up by the microphone and the surrounding sound of the camera picked up by the receiver's
internal microphone are recorded while mixed.
RCVR mode
Only the surrounding sound of the camera picked up by the receiver's internal microphone is recorded.
Note
While the receiver is in RCVR mode, the auto power-off function is disabled.
When you are finished with using the receiver, be sure to turn it off.
Related Topic
Recording
Recording with an external microphone
Lamp indications
5-026-023-11(1) Copyright 2021 Sony Corporation
15

Help Guide
Wireless Microphone
ECM-W2BT
Recording
Use the receiver attached to a camera and the microphone attached to the subject's clothing for recording sound.
Note
Depending on your camera, the “DIGITAL” audio output may not be supported. For the camera models that support the
“DIGITAL” audio output, visit our website at:
https://www.sony.net/dics/w2bt/
Turn on the power of the camera and set it in standby mode.
1
Turn on the receiver and the microphone.
Select your desired audio output with the slide switch (MIC OUT ANALOG/Power OFF/DIGITAL) on the receiver.
Select “ON” with the power switch on the microphone.
Immediately after both the receiver and the microphone are turned on, the LINK lamps on both devices start
blinking slowly in blue. This indicates that each of the devices is making a series of attempts to detect, connect to,
and authenticate the other device. When a communication connection is established between the devices and clear
audio recording is available, the LINK lamps on both devices stop blinking and stay lit in blue.
If no connection is established, bring the microphone and the receiver closer to each other for another attempt. The
devices may be under influence of environmental or other factors.
2
Ensure that the LINK lamp on the receiver is lit, and press the record start button on the camera.
3
16

When the audio output that is not supported by your camera is selected by the slide switch on the receiver, a cautionary message
may appear on the camera's finder screen. In such a case, select the supported audio output.
While recording is in progress, changing the receiver mode with the mode switch may cause a failure in switching the receiver
mode, a failure in audio recording due to disconnected communication, or noise in a recording. Before selecting a receiver mode
with the mode switch, be sure to stop the recording.
While recording is in progress, changing the audio recording volume with the ATT switch may cause operation sounds of the
switch to be recorded. Before selecting an audio recording volume with the ATT switch, be sure to stop the recording.
To avoid the possibility of the confirmation beep (Audio signals) at the start of a recording being picked up by this unit, it is
recommended that you set [Audio signals] to [Off] on your camera. For further details, refer to the operating instructions of your
camera.
When using this unit in the MIX mode, if the receiver and microphone pick up the same sound, it causes an echo or clipping
noise. Place the microphone farther away from the receiver not to pick up the same sound.
When using this unit in the MIX mode, if the power of the microphone turns off or the receiver and microphone are not connected
when you start recording, noise or no sound may be recorded. Ensure that the LINK lamps of the receiver and microphone are lit
in blue and connection is established, and then start recording.
The receiver receives power supply from the camera as well. Depending on your camera, however, it may not be capable of
supplying power. For the camera models that support power supply to the receiver, visit our website at:
https://www.sony.net/dics/w2bt/
Related Topic
About the mode switch
Lamp indications
5-026-023-11(1) Copyright 2021 Sony Corporation
17

Help Guide
Wireless Microphone
ECM-W2BT
Recording with an external microphone
Connect an external microphone (not supplied) to the microphone for recording.
Note
When the wind screen is attached to the microphone, remove it from the microphone.
Use an external microphone compatible with the plug-in power. The external microphone is powered by the microphone.
Related Topic
About the mode switch
5-026-023-11(1) Copyright 2021 Sony Corporation
Make sure that the microphone is turned off, and then connect the external microphone to the external
microphone input jack on the microphone.
The internal microphone automatically turns off and the sound picked up by the external microphone is recorded.
External microphone
1
18

Help Guide
Wireless Microphone
ECM-W2BT
Lamp indications
The lamp lights, blinks or goes out according to the status of the devices and communication as follows.
Power lamp
LINK lamp
Related Topic
Locating parts and controls
5-026-023-11(1) Copyright 2021 Sony Corporation
State Receiver Microphone
The power has just been turned on. Lights up in green Lights up in green
Connection is established and sound can be recorded clearly. Lights up in green Lights up in green
The receiver is turned off. Goes out Lights up in green
The microphone is turned off. Lights up in green Goes out
Audio is interrupted due to bad communication conditions. Lights up in green Lights up in green
The built-in battery is running out of power. Blinks in orange Blinks in orange
Battery charging is in progress while the power is turned off. Lights up in orange Lights up in orange
State Receiver Microphone
The power has just been turned on. Blinks in blue slowly (standby
mode)*1 *2
Blinks in blue slowly (standby
mode)*1 *2
Connection is established and sound can be
recorded clearly. Lights up in blue Lights up in blue
The receiver is turned off. Goes out Blinks in blue slowly (standby
mode)*1
The microphone is turned off. Blinks in blue slowly (standby
mode)*1 *2 Goes out
Audio is interrupted due to bad communication
conditions. Blinks in blue quickly Blinks in blue quickly
Battery charging is in progress while the power
is turned off. Goes out Goes out
When this state continues for 5 minutes, the auto power-off function is activated. Turn off the power, and then turn it back on.
*1
While the receiver is in RCVR mode, the auto power-off function is disabled.
*2
19

20
