■High Audio Quality
The metal body of Sony’s ECM-FT5 offers increased
durability and improved audio quality by blocking
vibration and resonance.Another advantage of the
metal construction is it shields the microphone,
blocking RF noise interference.
■Easy to Hide
The slim 4.9-mm profile of the ultra-miniature
ECM-FT5 is designed to be easily concealed under
clothing, and its sleek contours help prevent noise
pick-up from garments.
■Water-resistant Design
A moisture-repellent screen covers the mic aperture to help prevent
sweat and dampness from entering the case.
■Reliable Interface Options
The ECM-FT5 offers two
connection types for use with
Sony’s wireless transmitters.
A new flat-shape lavalier microphone,
omni-directional and ultra-miniature
MAIN FEATURES
■Supplied Accessories
The supplied accessories support a variety of
uses.
Tie Clip:
Use to attach the mic to clothing by clipping
on a pocket, button hole, or other suitable
parts of a garment
Taping Mount:
Use to attach the mic directly to fabric
surfaces
Wind Screen:
Use to suppress strong wind noise
Carrying Case:
Use to carry the ECM-FT5 and accessories
ECM-FT5 BMP
For the UWP Series
ECM-FT5 BC
For the DWX & WL-800
Series
ECM-FT5
Electret Condenser Microphone

©2012 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Features and specifications are subject to change without notice.
Sony; the Sony make.believe logo are trademarks of Sony Corporation.
All other trademarks are the property of their respective owners.
The ECM-FT5 are produced at Sony Taiyo,
which has received ISO14001, the Environmental
Management System certification.
Specifications
0°
0 dB
-10
-20
30°
60°
90°
120°
150°
30°
60°
90°
120°
150°
180°
100 Hz/1 kHz
4 kHz
10 kHz
0°
90°
180°
-30
-20
-10
0
+10
+20
20 50 100 200 500 1 k 2 k 5 k 10 k 20 k
Frequency (Hz)
Response (dB)
ECM-FT5
General
Type Back electret condenser microphone
Voltage 1.1-10 V
Power consumption 0.2 mA or less
Output connector ECM-FT5BC: Sony SMC9-4P type
ECM-FT5BMP:TRS connector
(3.5 dia.) with lock
Dimensions 7/32 x 5/16 x 9/16 in. (4.9 x 7.6 x 14 mm) (microphone unit)
Weight 0.06 oz. (1.7 g) (excluding cable and connector)
Supplied accessories Wind screen (1),Tie clip (1),Taping mount (1), Carrying case (1), Operating instructions (1)
Performance
Frequency response 40 Hz to 20 kHz
Directivity Omni-directional
Output impedance 1.2 kΩ ±20%, unbalanced
Sensitivity -43 dB (0 dB=1 V/Pa, 1 kHz)
Signal-to-noise ratio 68 dB (typ) (IEC 179 A-weighted, 1 kHz, 1 Pa)
Inherent noise 26 dB SPL (typ) (0 dB SPL=2x10-5 Pa)
Wind noise* 45 dB SPL or less (with wind screen)
65 dB SPL or less (without wind screen)
Maximum input sound pressure level 134 dB SPL (typ)
(input level for 3% waveform distortion at 1 kHz, converted into equivalent input sound pressure level: 0 dB SPL=2x10-5 Pa)
Dynamic range 108 dB (typ)
Operating temperature 32 °F to 122 °F (0 °C to +50 °C)
Storage temperature -4 °F to +140 °F (-20 °C to +60 °C)
* Wind noise is the value measured by applying a wind velocity of 2 m/sec. (6.6 ft./sec.) to the microphone from all directions.
The mean value is taken and converted to the equivalent sound pressure level.
(0 dB SPL=2x10-5 Pa)
Design and specifications are subject to change without notice.
