Sony UWP-C1 User manual

2-347-712-11(1)
2003 Sony Corporation
Operating Instructions
Before operating the unit, please read this manual thoroughly and
retain it for future reference.
Note
The supplied CD-ROM includes operating instructions for the UWP
series wireless microphone packages (English, Japanese, French,
German, Italian, and Spanish versions) and Sony Wireless
Microphone System Frequency Lists (English, French, German, and
Spanish versions). For details, see “Using the CD-ROM Manual” on
page 19.
UWP-C1/C2
UWP-S1/S2
UWP-X1/X2
Wireless
Microphone Package

2
For UTX-B1 and UTX-H1
Transmitters
Owner’s Record
The model and serial numbers are
located at the rear or on the bottom of
the unit. Record the model and serial
numbers in the space provided below.
Refer to these numbers whenever you
call upon your Sony dealer regarding
this product.
Model No. _____________________
Serial No. _____________________
Notice for customers in the
U.S.A.
Use of Sony wireless devices is
regulated by the Federal
Communications Commission as
described in Part 74 subpart H of the
FCC regulations and users authorized
thereby are required to obtain an
appropriate license.
You are cautioned that any changes or
modifications not expressly approved
in this manual could void your
authority to operate this equipment.
IMPORTANT NOTE: To comply
with the FCC RF exposure compliance
requirements, no change to the
antenna or the device is permitted.
Any change to the antenna or the
device could result in the device
exceeding the RF exposure
requirements and void user’s authority
to operate this device.
Notice for customers in Canada:
Use of Sony wireless devices is
regulated by the Industry Canada as
described in their Radio Standard
Specification RSS-123.
A licence is normally required. The
local district office of Industry Canada
should therefore be contacted. When
the operation of the device is within
the broadcast band, the licence is
issued on no-interference, no-
protection basis with respect to
broadcast signals.
Operation of this device is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any
interference, including interference
that may cause undesired operation of
the device.
The term “IC:” before the radio
certification number only signifies that
Industry Canada technical
specifications were met.
Remarque à l’intention des
utilisateurs au Canada:
L’usage des appareils sans fil Sony est
réglementé par l’Industrie Canada
comme décrit dans leur Cahier des
Normes Radioélectriques CNR-123.
Une licence est normalement requise.
Le bureau de l’Industrie Canada doit
être contacté. Lorsque le
fonctionnement de l’appareil respecte
les limites de la bande de
radiodiffusion, la licence est accordée
sur la base d’une non-interférence,
non-protection pour les signaux de
radiodiffusion.
L’utilisation de cet appareil est
soumise aux deux conditions
suivantes: (1) cet appareil ne peut
causer d’interférences, et (2) cet

3
appareil doit accepter toutes les
interférences, y compris les
interférences capables de provoquer
un fonctionnement non souhaité de
l’appareil.
L’expression <<IC:>> avant le
numéro d’homologation/
enregistrement signifie seulement que
les spécifications techniques de
l’Industrie Canada ont été respectées.
Notice for customers in Europe
Notification aux clients
européens
Hinweis für die Kunden in
Europa
Avvertenza per gli utilizzatori in
Europa
Aviso para los clientes de
Europa
Nota para utilizadores da
Europa
Mededeling voor de klanten in
Europa
Att observera för kunder i
Europa
Meddelelse til kunderne i
Europa
Huomautus Euroopassa asuville
asiakkaillemme
U.K. 854.125 - 862 MHz
Germany 790 - 814 MHz
Norway 800 - 820 MHz
Luxembourg 800 - 830 MHz,
854.125 - 862 MHz
Belgium 854.125 - 862 MHz
Denmark 800.100 - 819.900
MHz
France 798 - 830 MHz
Italy 800 - 820 MHz
Sweden 800 - 820 MHz
Switzerland 800 - 820 MHz
Finland 800.100 - 819.900
MHz
Iceland 800 - 814 MHz
Hereby, Sony Corporation declares
that this UTX-B1/UTX-H1 is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
For details, please access the
following URL:
http://www.compliance.sony.de/
Note:
In some countries additional
frequency bands may be used with the
agreement of the national authority.
Sony Corporation déclare par ces
présentes que le UTX-B1/UTX-H1 est
conforme aux exigences essentielles et
aux dispositions applicables de la
Directive 1999/5/CE. Pour les détails,
accédez à l’URL suivante:
http://www.compliance.sony.de/

4
Remarque:
Dans certains pays, des bandes de
fréquences additionnelles pourront
être utilisées avec l’accord des
autorités nationales.
Hiermit erklärt Sony Corporation,
dass die vorliegende Einheit UTX-B1/
UTX-H1 den wesentlichen
Anforderungen und anderen
relevanten Bestimmungen der
Richtlinie 1999/5/EC entspricht. Für
Einzelheiten siehe folgende URL:
http://www.compliance.sony.de/
Hinweis:
In manchen Ländern ist mit
Genehmigung der zuständigen
Behörden u.U. die Nutzung weiterer
Frequenzbänder möglich.
Con questo Sony Corporation dichiara
che questo UTX-B1/UTX-H1 è in
conformità con i requisiti essenziali e
altri provvedimenti in materia della
Direttiva 1999/5/CE. Per dettagli, si
prega di accedere alla seguente URL:
http://www.compliance.sony.de/
Nota:
In alcuni paesi possono essere usate
bande di frequenza supplementari con
il permesso delle autorità nazionali.
Sony Corporation declara aquí que
este modelo, UTX-B1/UTX-H1,
cumple los requisitos esenciales y
demás provisiones pertinentes de la
Directiva 1999/5/EC.Con respecto a
los detalles, realice el acceso a la
URL:
http://www.compliance.sony.de/
Nota:
En algunos países pueden utilizarse
bandas de frecuencia adicionales de
acuerdo con la autoridad nacional.
A Sony Corporation declara que o
modelo UTX-B1/UTX-H1 está em
conformidade com as exigências
essenciais e outras provisões
pertinentes da Directiva 1999/5/EC.
Mais informações neste endereço da
Internet:
http://www.compliance.sony.de/
Obs.:
Em alguns países uma faixa adicional
de frequências pode ser utilizada com
autorização do governo nacional.
Sony Corporation verklaart hierbij dat
de UTX-B1/UTX-H1 voldoet aan de
primaire vereisten en andere relevante
voorschriften van de Europese
Bepaling 1999/5/EC. Nadere
bijzonderheden vindt u op de volgende
website:
http://www.compliance.sony.de/
Opmerking:
In bepaalde landen kan er gebruik
gemaakt worden van aanvullende
frequentiebanden, mits toegestaan
door de nationale instanties.
Sony Corporation förkunnar härmed
att denna UTX-B1/UTX-H1 uppfyller
de huvudsakliga kraven och andra
relevanta villkor i direktivet 1999/5/
EC. Se följande URL för närmare
detaljer:
http://www.compliance.sony.de/

5
Observera:
I vissa länder kan det hända att
ytterligare frekvensband används efter
överenskommelse med det landets
myndigheter.
Sony Corporation erklærer herved, at
denne UTX-B1/UTX-H1 er i
overensstemmelse med de essentielle
krav og andre relevante bestemmelser
i direktiv 1999/5/EC. Åbn venligst den
følgende URL angående detaljer:
http://www.compliance.sony.de/
Bemærk:
I nogle land kan yderligere
frekvensbånd blive anvendt med de
nationale autoriteters samtykke.
Sony Corporation julistaa täten, että
tämä UTX-B1/UTX-H1 vastaa
direktiivin 1999/5/EC olennaisia
vaatimuksia ja muita asiaankuuluvia
määräyksiä. Katso tarkemmat tiedot
osoitteesta:
http://www.compliance.sony.de/
Huom!
Joissakin maissa lisätaajuuskaistoja
voidaan käyttää viranomaisten
suostumuksella.
Note for customers in
Switzerland:
Before use, a request of concession for
a wireless microphone (Frequency
Class 3) has to be submitted to
Bakom.
Note concernant les utilisateurs
en Suisse:
Une demande de concession de
microphone sans fil (fréquence classe
3) doit être présentée au Bakom avant
d’utiliser l’appareil.
Hinweis für Kunden in der
Schweiz:
Vor Inbetriebnahme ist eine
Konzessionsanforderung für ein
drahtloses Mikrofon (Frequenzklasse
3) bei Bakom einzureichen.
Note for customers in Finland:
To own and use, it is necessary to
obtain an individual licence of the
Telecommunications Administration
Center.
Huomautus Suomessa asuville
asiakkaillemme
Omitusta ja käyttöä varten on tarpeen
hankkia henkilökohtainen lupa
tietoliikennehallintokeskuksesta.

6
Note for customers in
Luxembourg:
Before any use of an equipment, the
frequencies required have to be, if
necessary according to the regulations
in force, assigned prior to usage by the
“ILT”.
Remarque pour les clients au
Luxembourg:
Avant tout emploi de cet appareil, si
nécessaire conformément à la
réglementation en vigueur, les
fréquences requises doivent être
assignées, avant l’usage par le “ILT”.
Hinweis für Kunden in
Luxemburg:
Vor Inbetriebnahme eines Geräts
müssen die Frequenzen
gegebenenfalls nach den geltenden
Vorschriften vor dem Gebrauch von
der „ILT“ zugewiesen werden.
Note for customers in Italy:
The use of this product within Italy is
subject to article 334 of the Postal and
Telecommunications regulations.
Nota per i clienti in Italia:
L’uso del prodotto sul territorio
italiano è soggetto alle
regolamentazioni del Codice Postale e
delle Telecomunicazioni art. 334.
Note for customers in Belgium:
Using this transmitter with 30 mW RF
output power is not allowed. Be sure
to set the RF output power to 5 mW.
Note concernant les utilisateurs
en Belgique:
L’emploi de ce transmetteur avec une
puissance de sortie RF de 30 mW
n’est pas autorisé. Bien régler la
puissance de sortie RF à 5 mW.
Hinweis für Kunden in Belgien:
Der Einsatz des Senders mit einer HF-
Ausgangsleistung von 30 mW ist
verboten. Betreiben Sie den Sender
ausschließlich mit einer HF-
Ausgangsleistung von 5 mW.
Mededeling voor de klanten in
België:
Het is niet toegestaan deze zender te
gebruiken met een RF
uitgangsvermogen van 30 mW. Zorg
dat het RF uitgangsvermogen is
ingesteld op 5 mW.
Note for customers in Norway:
Using this transmitter requires the
Individual License.
Hinweis für Kunden in
Deutschland:
Vor Inbetriebnahme muss bei der
zuständigen Außenstelle der
Regulierungsbehörde (Reg TP) eine
Kanalzuweisung beantragt werden.
Note for customers in Iceland:
Using this transmitter requires the
Individual License.
Note for customers in Sweden:
Using this transmitter requires the
Individual License.
Att observera för kunder i
Sverige:
För att använda denna sändare krävs
Individuell Licens.

7
For URX-P1, URX-M1, and URX-R1
Tuners
Owner’s Record
The model and serial numbers are
located at the rear or on the side of the
unit. Record the model and serial
numbers in the space provided below.
Refer to these numbers whenever you
call upon your Sony dealer regarding
this product.
Model No. _____________________
Serial No. _____________________
Notice for customers in the
U.S.A.
You are cautioned that any changes or
modifications not expressly approved
in this manual could void your
authority to operate this equipment.
Declaration of Conformity
Trade Name: SONY
Model No.: URX-P1
URX-M1
URX-R1
Responsible Party:
Sony Electronics
Inc.
Address: 680 Kinderkamack
Road, Oradell, NJ.
07649 U.S.A.
Telephone No.: 201-930-6972
This device complies with Part 15
of the FCC Rules. Operation is
subject to the following two
conditions:
(1) This device may not cause
harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause
undesired operation.
If you have any questions about this
product, you may call:
Sony’s Business Information
Center (BIC)
at 1-800-686-SONY (7669)
or write to:
Sony Customer Information
Services Center
6900-29 Daniels Parkway, PMB
330 Fort Myers, Florida 33912
Notice for customers in Canada:
Use of Sony wireless devices is
regulated by the Industry Canada as
described in their Radio Standard
Specification RSS-123.
A licence is normally required. The
local district office of Industry Canada
should therefore be contacted. When
the operation of the device is within
the broadcast band, the licence is
issued on no-interference, no-
protection basis with respect to
broadcast signals.
Operation of this device is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any
interference, including interference
that may cause undesired operation of
the device.
The term “IC:” before the radio
certification number only signifies that
Industry Canada technical
specifications were met.

8
Remarque à l’intention des
utilisateurs au Canada:
L’usage des appareils sans fil Sony est
réglementé par l’Industrie Canada
comme décrit dans leur Cahier des
Normes Radioélectriques CNR-123.
Une licence est normalement requise.
Le bureau de l’Industrie Canada doit
être contacté. Lorsque le
fonctionnement de l’appareil respecte
les limites de la bande de
radiodiffusion, la licence est accordée
sur la base d’une non-interférence,
non-protection pour les signaux de
radiodiffusion.
L’utilisation de cet appareil est
soumise aux deux conditions
suivantes: (1) cet appareil ne peut
causer d’interférences, et (2) cet
appareil doit accepter toutes les
interférences, y compris les
interférences capables de provoquer
un fonctionnement non souhaité de
l’appareil.
L’expression <<IC:>> avant le
numéro d’homologation/
enregistrement signifie seulement que
les spécifications techniques de
l’Industrie Canada ont été respectées.
Notice for customers in Europe
Notification aux clients
européens
Hinweis für die Kunden in
Europa
Avvertenza per gli utilizzatori in
Europa
Aviso para los clientes de
Europa
Nota para utilizadores da
Europa
Mededeling voor de klanten in
Europa
Att observera för kunder i
Europa
Meddelelse til kunderne i
Europa
Huomautus Euroopassa asuville
asiakkaillemme
U.K. 854.125 - 862 MHz
Germany 790 - 814 MHz
Norway 800 - 820 MHz
Luxembourg 800 - 830 MHz,
854.125 - 862 MHz
Belgium 854.125 - 862 MHz
Denmark 800.100 - 819.900
MHz
France 798 - 830 MHz
Italy 800 - 820 MHz
Sweden 800 - 820 MHz
Switzerland 800 - 820 MHz
Finland 800.100 - 819.900
MHz
Iceland 800 - 814 MHz
Hereby, Sony Corporation declares
that this URX-P1/M1/R1 is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
For details, please access the
following URL:
http://www.compliance.sony.de/

9
Sony Corporation déclare par ces
présentes que le URX-P1/M1/R1 est
conforme aux exigences essentielles et
aux dispositions applicables de la
Directive 1999/5/CE. Pour les détails,
accédez à l’URL suivante:
http://www.compliance.sony.de/
Hiermit erklärt Sony Corporation,
dass die vorliegende Einheit URX-P1/
M1/R1 den wesentlichen
Anforderungen und anderen
relevanten Bestimmungen der
Richtlinie 1999/5/EC entspricht. Für
Einzelheiten siehe folgende URL:
http://www.compliance.sony.de/
Con questo Sony Corporation dichiara
che questo URX-P1/M1/R1 è in
conformità con i requisiti essenziali e
altri provvedimenti in materia della
Direttiva 1999/5/CE. Per dettagli, si
prega di accedere alla seguente URL:
http://www.compliance.sony.de/
Sony Corporation declara aquí que
este modelo, URX-P1/M1/R1 cumple
los requisitos esenciales y demás
provisiones pertinentes de la Directiva
1999/5/EC. Con respecto a los
detalles, realice el acceso a la URL:
http://www.compliance.sony.de/
A Sony Corporation declara pela
presente que o modelo URX-P1/M1/
R1 está em conformidade com as
exigências essenciais e outras
provisões pertinentes da Directiva
1999/5/EC. Mais informações neste
endereço da Internet:
http://www.compliance.sony.de/
Sony Corportion verklaart hierbij dat
de URX-P1/M1/R1 voldoet aan de
primaire vereisten en andere relevante
voorschriften van de Europese
Bepaling 1999/5/EC. Nadere
bijzonderheden vindt u op de volgende
website:
http://www.compliance.sony.de/
Sony Corporation förkunnar härmed
att denna URX-P1/M1/R1 uppfyller
de huvudsakliga kraven och andra
relevanta villkor i direktivet 1999/5/
EC. Se följande URL för närmare
detaljer:
http://www.compliance.sony.de/
Sony Corporation erklærer herved, at
denne URX-P1/M1/R1 er i
overensstemmelse med de essentielle
krav og andre relevante bestemmelser
i direktiv 1999/5/EC. Åbn venligst den
følgende URL angående detaljer:
http://www.compliance.sony.de/
Sony Corporation julistaa täten, että
tämä URX-P1/M1/R1 vastaa
direktiivin 1999/5/EC olennaisia
vaatimuksia ja muita asiaankuuluvia
määräyksiä. Katso tarkemmat tiedot
osoitteesta:
http://www.compliance.sony.de/

Table of Contents
10
Table of Contents
Configuration of the
Packages ........................... 11
UWP-C1................................... 11
UWP-C2................................... 12
UWP-S1 ................................... 13
UWP-S2 ................................... 14
UWP-X1 .................................. 15
UWP-X2 .................................. 16
Features .................................. 17
Using the CD-ROM Manual.... 19
CD-ROM system
requirements............................. 19
Preparations ............................. 19
To read the operating
instructions ............................... 19
To read the Sony Wireless
Microphone System
Frequency List ......................... 19
Precautions............................. 21
Parts Identification ................. 22
Body-pack transmitter
(UTX-B1)................................. 22
Hand-held microphone
(UTX-H1) ................................ 23
Portable diversity tuner
(URX-P1) ................................. 24
Half-rack size diversity tuner
(URX-R1) ................................ 26
Diversity tuner module
(URX-M1) ............................... 27
Power Supply ......................... 29
Inserting the batteries ............... 29
Attachment and Installation
Procedures ........................ 32
Attaching the supplied
accessories to the body-pack
transmitter (UTX-B1) .............. 32
Attaching the supplied
accessory to the hand-held
microphone (UTX-H1) ............ 33
Attaching the supplied
accessories to the portable
diversity tuner (URX-P1)......... 33
Installing the diversity tuner
module (URX-M1) .................. 34
Settings ................................... 37
Setting the transmission
channel ..................................... 37
Setting the reception channel ... 38
Setting the attenuation level
of the audio input ..................... 39
Resetting the accumulated
battery use time indication ....... 40
Setting the RF output level ...... 41
Setting the monitor level
(portable diversity tuner
(URX-P1) only) ....................... 41
Operation ................................ 42
System Configurations .......... 43
Error Messages ...................... 46
Troubleshooting ..................... 47
Specifications ......................... 49

11
Configuration of the Packages
This operation manual is for the UWP-C1/C2/S1/S2/X1/X2
wireless microphone packages. The contents of each package
are described below.
UWP-C1
The UWP-C1 consists of a body-pack transmitter (UTX-B1)
and a portable diversity tuner (URX-P1). When used in
conjunction with a compact camcorder, the UWP-C1 makes a
mobile system for ENG (Electronic News Gathering) or EFP
(Electronic Field Production) purposes.
Body-pack transmitter
(UTX-B1) (1) Portable diversity tuner
(URX-P1) (1)
Supplied accessories
• Omni-directional lavalier microphone
(1) • Wind screen (1)
• XLR-BMP conversion cable (1)
• Holder clip (1)
• Shoe mount adapter (1) • Belt clip (2)
• Microphone stand adapter (1)
• Operation manual (1)
• CD-ROM (1) (For the U.S.A. and Europe
models only)
• Sony Wireless Microphone System
Frequency List (1) (Australia model only)
• Warranty booklet (1)

Configuration of the Packages
12
UWP-C2
The UWP-C2 consists of a hand-held microphone (UTX-H1)
and a portable diversity tuner (URX-P1). When used in
conjunction with a compact camcorder, the UWP-C2 makes a
mobile system for ENG (Electronic News Gathering) or EFP
(Electronic Field Production) purposes.
Hand-held microphone
(UTX-H1) (1) Portable diversity tuner
(URX-P1) (1)
Supplied accessories
• Microphone holder (1) • Belt clip (1)
• Shoe mount adapter (1) • XLR-BMP conversion cable (1)
• Microphone stand adapter (1) • Operation manual (1)
• CD-ROM (1) (For the U.S.A. and Europe
models only)
• Sony Wireless Microphone System
Frequency List (1) (Australia model only)
• Warranty booklet (1)

13
UWP-S1
The UWP-S1 consists of a body-pack transmitter (UTX-B1)
and a half-rack size diversity tuner (URX-R1). The UWP-S1 is
suitable for constructing a wireless system for AV
presentations.
Body-pack transmitter
(UTX-B1) (1) Half-rack size diversity tuner (URX-R1) (1)
Supplied accessories
• Unidirectional lavalier
microphone (1) • Wind screen (1) • Holder clip (1)
• AC adapter (1) • Belt clip (1) • Operation manual (1)
• CD-ROM (1) (For the U.S.A.
and Europe models only)
• Sony Wireless Microphone
System Frequency List (1)
(Australia model only)
• Warranty booklet (1)
– AC-S906T (for U62 and U66 models)
– AC-S906 (for CE62 model)
– AC-S911 (for CE67 model)
– AC-E90HG (for AU66 model)

Configuration of the Packages
14
UWP-S2
The UWP-S2 consists of a hand-held microphone (UTX-H1)
and a half-rack size diversity tuner (URX-R1). The UWP-S2 is
suitable for constructing a wireless system for AV
presentations.
Hand-held microphone
(UTX-H1) (1) Half-rack size diversity tuner
(URX-R1) (1)
Supplied accessories
• Microphone holder (1) • AC adapter (1)
• Operation manual (1)
• CD-ROM (1) (For the U.S.A. and Europe
models only)
• Sony Wireless Microphone System
Frequency List (1) (Australia model only)
• Warranty booklet (1)
– AC-S906T (for U62 and U66 models)
– AC-S906 (for CE62 model)
– AC-S911 (for CE67 model)
– AC-E90HG (for AU66 model)

15
UWP-X1
The UWP-X1 consists of a body-pack transmitter (UTX-B1)
and a diversity tuner module (URX-M1). By installing the tuner
module into a tuner base unit or a powered mixer, the system
construction to meet the desired purpose of use and required
system scale becomes possible.
Body-pack transmitter
(UTX-B1) (1) Diversity tuner module (URX-M1) (1)
Supplied accessories
• Unidirectional lavalier
microphone (1) • Wind screen (1) • Holder clip (1)
• Belt clip (1) • Operation manual (1)
• CD-ROM (1) (For the U.S.A. and Europe
models only)
• Sony Wireless Microphone System
Frequency List (1) (Australia model only)
• Warranty booklet (1)

Configuration of the Packages
16
UWP-X2
The UWP-X2 consists of a hand-held microphone (UTX-H1)
and a diversity tuner module (URX-M1) . By installing the
tuner module into a tuner base unit or a powered mixer, the
system construction to meet the desired purpose of use and
required system scale becomes possible.
Hand-held microphone
(UTX-H1) (1) Diversity tuner module
(URX-M1) (1)
Supplied accessories
• Microphone holder (1) • Operation manual (1)
• CD-ROM (1) (For the U.S.A. and Europe
models only)
• Sony Wireless Microphone System
Frequency List (1) (Australia model only)
• Warranty booklet (1)

17
Features
Each of the UWP-C1/C2/S1/S2/X1/
X2 wireless microphone packages
(referred to as the UWP series
hereafter) combines a transmitter
(body-pack transmitter (UTX-B1) or
hand-held microphone (UTX-H1)) and
a receiver (portable diversity tuner
(URX-P1), half-rack size diversity
tuner (URX-R1), or diversity tuner
module (URX-M1)). The UWP series
can be used with a compact camcorder
for ENG (Electronic News Gathering)
purposes, and with a powered mixer
for AV presentations or as a PA
(public address) system.
Note
The UWP series is not compatible
with conventional WRT series
transmitters, WRR series tuners, or
WRU series tuner units.
The features of each package are
described below.
UWP-C1
Body-pack transmitter (UTX-B1)
This is a small and lightweight
transmitter with a crystal-controlled
PLL (phase lock loop) synthesized
system and a BMP-type microphone
input connector. The RF power output
can be set at 30 mW or at 5 mW.
Portable diversity tuner
(URX-P1)
This tuner employs a space diversity
system with little signal dropout and
two angle-adjustable antennas. It
comes with an adapter for mounting
the tuner on the compact camcorder
(DSR-PDX10/PDX10P/PD150/
PD150P, etc.).
UWP-C2
Hand-held microphone (UTX-H1)
This microphone is equipped with a
built-in antenna and a unidirectional
dynamic microphone unit. The RF
power output can be set at 30 mW or
at 5 mW.
Portable diversity tuner
(URX-P1)
This tuner employs a space diversity
system with little signal dropout and
two angle-adjustable antennas. It
comes with an adapter for mounting
the tuner on the compact camcorder
(DSR-PDX10/PDX10P/PD150/
PD150P, etc.).
UWP-S1
Body-pack transmitter (UTX-B1)
This is a small and lightweight
transmitter with a crystal-controlled
PLL (phase lock loop) synthesized
system and a BMP-type microphone
input connector. The RF power output
can be set at 30 mW or at 5 mW.

Features
18
Half-rack size diversity tuner
(URX-R1)
This tuner employs a space diversity
system with little signal dropout and
two angle-adjustable antennas. It
comes with two types of audio
connectors (1/4-inch jack and XLR
type) on the rear panel.
UWP-S2
Hand-held microphone (UTX-H1)
This microphone is equipped with a
built-in antenna and a unidirectional
dynamic microphone unit. The RF
power output can be set at 30 mW or
at 5 mW.
Half-rack size diversity tuner
(URX-R1)
This tuner employs a space diversity
system with little signal dropout and
two angle-adjustable antennas. It
comes with two types of audio
connectors (1/4-inch jack and XLR
type) on the rear panel.
UWP-X1
Body-pack transmitter (UTX-B1)
This is a small and lightweight
transmitter with a crystal-controlled
PLL (phase lock loop) synthesized
system and a BMP-type microphone
input connector. The RF power output
can be set at 30 mW or at 5 mW.
Diversity tuner module
(URX-M1)
This tuner module can be incorporated
into the MB-806A Tuner Base Unit or
SRP-X700P Powered Mixer.
UWP-X2
Hand-held microphone (UTX-H1)
This microphone is equipped with a
built-in antenna and a unidirectional
dynamic microphone unit. The RF
power output can be set at 30 mW or
at 5 mW.
Diversity tuner module
(URX-M1)
This tuner module can be incorporated
into the MB-806A Tuner Base Unit or
SRP-X700P Powered Mixer.

19
Using the CD-ROM Manual
The supplied CD-ROM includes
operating instructions for the UWP
series wireless microphone packages
(English, Japanese, French, German,
Italian, and Spanish versions) and
Sony Wireless Microphone System
Frequency Lists (English, French,
German, and Spanish versions).
CD-ROM system
requirements
The following are required to access
the supplied CD-ROM disc.
• Computer: PC with MMX Pentium
166 MHz or faster CPU
— Installed memory: 64 MB or
more
— CD-ROM drive: ×8 or faster
• Monitor: Monitor supporting
resolution of 800 ×600 or higher
When these requirements are not met,
access to the CD-ROM disc may be
slow, or not possible at all.
Preparations
Adobe Acrobat Reader Version 4.0 or
higher must be installed on your
computer in order to use the
documents contained in the CD-ROM
disc.
Adobe Acrobat Reader 4.0 or higher
may be downloaded from the
following URL:
http://www.adobe.com/products/
acrobat/ readstep.html
To read the operating
instructions
To read the operating instructions
contained in the CD-ROM disc, do the
following.
1Insert the CD-ROM disc in your
CD-ROM drive.
A cover page appears
automatically in your browser.
If it does not appear automatically
in the browser, open My
Computer, access the CD-ROM
drive, and double-click the
index.htm file.
2Select and click the operating
instructions that you want to read.
A PDF file of the operating
instructions opens.
To read the Sony
Wireless Microphone
System Frequency List
The frequency lists for U62 and U66
models (for the U.S.A.) and CE62 and
CE67 models (for Europe) are
contained in the CD-ROM disc. To
read the frequency lists, do the
following.
1Insert the CD-ROM disc in your
CD-ROM drive.
A cover page appears
automatically in your browser.

Using the CD-ROM Manual
20
2Select and click the frequency list
that you want to read.
A PDF file of the frequency list
opens.
Note
If you lose the CD-ROM disc or
become unable to read its content, for
example, because of a hardware
failure, contact a Sony service
representative.
• MMX and Pentium are registered
trademarks of Intel Corporation or its
subsidiaries in the United States and
other countries.
• Adobe and Acrobat are registered
trademarks of Adobe Systems
Incorporated in the United States
and/or other countries.
