As a leading manufacturer in the A/V industry, Sony offers a wide range of
public address and sound reinforcement products utilizing sophisticated Sony
audio, wireless and interfacing technologies to provide a comprehensive business
and industrial product line.
In 2002, Sony introduced an innovative all-in-one system concept for multimedia
presentations, the SRP-X700P Digital Powered Mixer. Designed to function as
the central control hub for the integration of video, audio and PC media sources,
this mixer allows for rich content and multimedia presentation systems to be
easily configured, without integrating several separate A/V presentation devices.
Best suited for use with in mid- to large-scale conference rooms, seminar rooms,
and audio-visual rooms, the SPR-X700P is now widely accepted in many different
arenas including education, and the corporate and public sectors.
In 2005, expanding on this all-in-one concept,Sony introduced the SRP-X500P.
This cost-effective mixer is an ideal choice in small to mid-scale presentation
systems that are typically used in conference rooms, corporate boardrooms,
classrooms, and houses of worship.
Soon after the launch of the SRP-X500P, however, system integrators and
installers were confronted with questions: What is the best choice for a specific
application – the SRP-X500P or the SRP-X700P? What are the differences
between these two mixers?
Tohelp answer these questions, this guide provides the following useful
information:
•Using the maximum functionality and performance of the SRP-X500P
•Understanding the differences between the SRP-X500P and the SRP-X700P
•Establishing an effective system using the key features of the SRP-X500P
•Professional audio terminologies related to the SRP-X500P and SRP-X700P
We hope this guide serves as a valuable asset to your SRP Series system
integration activities.
1Introduction

4
SRP-X500P System Integration Guide
2Differences Between
the SRP-X500P and SRP-X700P
2-1. Features
SRP-X700P
The SRP-X700P Digital Powered Mixer has been designed
for multimedia presentation systems that are required to
process material from a wide range of sources including
microphones, video, audio, DVD players, audio tape
recorders, and PCs. It incorporates the functionality of
seven major presentation devices – including a video/RGB
switcher, audio mixer, wireless tuner slots, sound processor,
and two-channel digital power amplifier – in a compact
3U-high chassis. Equipped with a comprehensive remote
control capability,and a variety of interfaces, the SRP-X700P
can easily be configured into a flexible system, and is an
ideal mid- to large-scale presentation system. The main
features of the SRP-X700P are as follows:
• Processes and mixes six microphone inputs (4 MIC,
2MIC/LINE)
(Audio input CH1/CH2 is compatible with wired and
wireless microphones)
• Eight BUS outputs and two REC outputs to configure a
large system
• Built-in high-powered two-channel digital power
amplifier: 150 W + 150 W (8 Ω)
• Support for 5.1-channel surround audio input/output
• Comprehensive remote control of the SRP-X700P and
external peripherals such as a projector via a wide array
of interfaces (USB, RS-232C, Parallel, Control S)
•Supplied SRP-X700P User Control Panel software for
easy system setup and operation from a PC
SRP-X500P
Inheriting rich features from the SRP-X700P, the SRP-X500P
provides a cost-effective solution and is ideal for use in
small to mid-scale presentation systems. For smooth
control over presentations, there is an easy-to-use front-
panel layout, providing instant-access controls. A built-in
four-channel power amplifier eliminates the need for
additional power amplifiers, enhancing the all-in-one
system concept.
The SRP-X500P offers nine system presets (factory default
system settings) in its memory, enabling quick setup of the
audio system by recalling the one best suited for each
venue. The main features of the SRP-X500P are as follows:
• Processes and mixes four microphone inputs
(Audio input CH1/CH2 is compatible with wired and
wireless microphones)
• Built-in four-channel digital power amplifier:
90 W + 90 W + 50 W + 50 W (8 Ω)
• Nine system presets stored in memory – allows simple
system configuration
• Easy-to-use front-panel layout with hardware switches
for projector controls and feedback reducer function
• Supplied front cover to prevent accidental operation
SRP-X500P (two optional tuner units installed)
SRP-X700P (two optional tuner units installed)

5
2Differences Between the SRP-X500P and SRP-X700P
2-2. Comparison Chart
SRP-X500P SRP-X700P
Power amplifier Low-impedance (8 Ω) 90 W x2 + 50 W x2 150 W x2
70V LINE 60 W, Mono 150 W, Mono
5.1CH IN/OUT N/A Yes
VIDEO IN/OUT RGB IN/OUT 2 IN/1 OUT 3 IN/1 OUT
Component switching Yes Yes
S-VIDEO IN/OUT N/A 3 IN/1 OUT
VIDEO IN/OUT 3 IN/1 OUT 3 IN/1 OUT
AUDIO IN MONO 4 6
TRIM (MONO) -60 dBu to -30 dBu -60 dBu to -45 dBu
STEREO 2 2
TRIM (STEREO) -30 dBu to 0 dBu -10 dBu to 0 dBu
AV SELECT 5 6
AUDIO OUT Master 4 8
REC OUT (L/R) N/A* Yes
GUI (setting software) Yes (RS-232C) Yes (USB)
Settings System preset Yes (selectable from front panel) N/A
Routing Yes Yes
Feedback reducer Yes Yes
Comp./Limiter Yes Yes
Parametric equalizer Yes (IN/OUT) Yes (IN/OUT)
Delay Yes Yes
Automatic mixer N/A Yes
Automatic Gain Control (AGC) Yes N/A
Projector control Yes Yes
PROJECTOR POWER ON/STANDBY switch Yes (front panel button) Yes (using SCENE RECALL)
IR remote control Yes (optional) N/A
External AVtransport control No (use optional remote controller) Yes (4 Control S ports supplied)
SCENE RECALL Yes (via parallel port or RS-232C) Yes (via front panel switches, parallel port, and RS-232C)
*LINE OUTPUT CH-3/-4 is set to REC OUT in factory default settings.

6
SRP-X500P System Integration Guide
3-1. Front Panel
1POWER switch
Turns the SRP-X500P on and off.
With the SRP-X500P Manager software,
you can link projector or display monitor
power on/standby control to that of the
SRP-X500P.For more details, refer to
the Projector Control section (5-4.).
2EMG (emergency) indicator
Lights up red when an emergency
broadcast system connected to the
REMOTE PARALLEL connector cuts the
SPEAKER and LINE outputs.
3Wireless microphone slots
(WL1/WL2)
Accommodates up to two WRU-806A/
806B (not supplied) or URX-X1 tuner
module (not supplied) included in the
UWP-X1/X2.
4Remote emitter/sensor
Point an optional remote commander
towards the emitter/sensor.Using an
optional learning-type IR remote
controller,you can wirelessly control
frequently accessed SRP-X500P and
connected projector operations. For
more details, refer to Programming a
Learning-type Remote Commander in
the appendix.
5Input level controls
Rotate to adjust the input signal level:
MIC1/WL1: Adjusts the level of the
signal input from the MIC INPUT 1
connector or the tuner unit installed in
the WL1 slot.
MIC2/WL2: Adjusts the level of the
signal input from the MIC INPUT 2
connector or the tuner unit installed in
the WL2 slot.
MIC3: Adjusts the level of the signal
input from the MIC INPUT 3 connector.
MIC4: Adjusts the level of the signal
input from the MIC INPUT 4 connector.
LINE: Adjusts the level of the signals
input from the LINE IN connectors.
AV/RGB: Adjusts the level of the
signals input from the AV/RGB INPUT
audio connectors, as specified by the 0
AV/RGB SELECT buttons.
6Input indicators
SIGNAL (signal level) indicators:
Lights up green when the signal is
3Panel View
input from each audio connector.
RF (radio frequency) indicators:
Lights up green when the level of the
RF signal input from each tuner unit is
satisfactory.
AF (audio frequency) indicators:
Light up yellow when the signal is input
from each tuner unit.
7SPEAKER OUTPUT indicators
PROTECTION (protection circuit)
indicator: Lights up red when the
protection circuit of the internal power
amplifier is activated.
CLIP (clip) indicators: Lights up red
when the output level of the internal
power amplifier is excessive and the
output signal is distorted.
70V LINE (high-impedance speaker
connection) indicator: Lights up
green when the SPEAKERS CH-3/4
terminals are set to connect high-
impedance speakers (70V LINE).
VU (volume unit) meters: Uses five-
segment LEDs to indicate the signal
output level prior to adjustment by the
!™ SPEAKER OUT controls.
!• !¶ !§ !¢ !£ !™ !¡ !º 98
7654321
!∞

7
3Panel View
8MASTER MUTING indicator
Lights up red when signal output is
muted by a command from a device
connected to the REMOTE PARALLEL or
REMOTE RS-232C connector, or by
operation of an optional remote
commander.
9MASTER control
Adjusts the output level of the assigned
channels. With the SRP-X500P
Manager software, you can specify
which output channels are controlled by
the MASTER control. In the factory-
preset setting, the MASTER control is
assigned to control output from the
SPEAKERS CH-1 to 4 terminals and the
LINE OUTPUT 1/2 connectors. (Note
that the output from the LINE OUTPUT
3/4 terminals cannot be controlled.
However,by using SRP-X500P Manager
software, settings can be customized to
allow LINE OUTPUT 3/4 connectors to
be controlled by the MASTER control
and/or the REMOTE PARALLEL
connector.)
!º AVRGB SELECT buttons (A to E)
Press to select a device connected to the
AV/RGB INPUT audio/video connectors.
The pressed button lights up green.
!¡ LINE AV/RGB input adjustment
section
TRIM (input reference level
adjustment) controls: Adjusts the
reference level for the audio signals
input from the LINE IN connectors and
the AV/RGB INPUT audio connectors.
The adjustable range is -30 dBu to
0dBu.
REF. (reference level) indicators:
Lights up yellow when an audio signal
with a level in excess of the reference
level is input to the LINE IN connectors
and the AV/RGB INPUT audio connectors.
While the audio signal is input,adjust the
TRIM controls so that the REF. indicators
light up yellow intermittently.
!™ SPEAKER OUT controls
Used to attenuate the output level of
the internal power amplifier. Before
adjusting the speaker output level, use
the TRIM controls to specify the
reference level for the audio input
signals, then use the MASTER control to
adjust the overall level. And then use
the SPEAKER OUT controls to adjust
output levels from the SPEAKERS
CH-1/2 terminals and CH-3/4 terminals.
!£ PROJECTOR PROTOCOL selector
Used to select the protocol
corresponding to the model of the
projector or display monitor connected
to the PROJECTOR CONTROL RS-232C
connector or the CONTROL S IN/OUT
connectors. For control of an LCD Data
Projector VPL-PX15, use the CONTROL S
connectors.
!¢ SYSTEM TYPE selector
Select 1 to 9 according to the speaker
configuration of the AVsystem being
used. The setting becomes effective
next time the power is turned on. For
more details, refer to the SYSTEM TYPE
section (4-1.).
!∞ IR OUTPUT MODE (remote
programming) button
Used to program an SRP-X500P
command to an optional learning-type
remote commander. For more details,
refer to Programming a Learning-type
Remote Commander in the appendix.
!§ Microphone input adjustment
section
+48V (48 V DC power supply)
ON/OFF switches: Set to ON to supply
48 V DC power to condenser
microphones connected to the MIC
INPUT 1 to 4 connectors. Before
turning these switches, be sure to fully
turn down all input level controls and
the LINE AV/RGB controls, or turn off
the unit.
TRIM (microphone input reference
level adjustment) controls: Set the
reference level for signals input from the
MIC INPUT 1 to 4 connectors. The
adjustable range is -60 dBu to -30 dBu.
REF. (reference level) indicators:
Lights up yellow when an audio signal
with a level in excess of the reference
level is input to the MIC INPUT 1 to 4
connectors. While the audio signal is
input, adjust the TRIM controls so that
the REF. indicators light up yellow
intermittently.
FEEDBACK REDUCER (howling
suppressor) buttons: Used to turn the
howling noise reducing function on or
off, and to make settings for this
function. The buttons light up green
when the function is turned on. For
more details, refer to the Feedback
Reducer section (4-2.).
!¶ RS-232C indicator
Lights up green when the SRP-X500P
and a PC or external controller are
communicating via the REMOTE
RS-232C connector.
!• PROJECTOR ON/STANDBY
POWER switch
Turns on the projector or display
monitor connected to the SRP-X500P, or
sets the projector to standby status.
Press the switch while it is lit up red
(i.e., the projector is in standby) to turn
on the projector. The switch lights up
green when the projector is turned on.
To turn off the projector, hold down the
switch for more than two seconds. The
switch flashes green while the projector
cools off, and then lights up red when
the projector enters standby.

8
SRP-X500P System Integration Guide
3-2. Rear Panel
1ANT IN a/b connectors
(BNC-type)
Connect antennas for the tuner unit
installed in the SRPX-500P.Only the
supplied antennas or the optional UHF
Antenna AN-820A can be used.
2PROJECTOR CONTROL
CONTROL S IN/OUT connectors
(stereo mini jack)
Used to control the LCD Data Projector
VPL-PX15 exclusively.
3PROJECTOR CONTROL RS-232C
connector (D-sub, 9-pin, male)
Used to control a projector or display
monitor with an RS-232C connector
that is connected to the 6OUTPUT
COMPONENT/RGB or OUTPUT VIDEO
connector of the SRP-X500P.
4REMOTE PARALLEL connector
(D-sub, 25-pin, female)
This connector consists of 10 input pins
and 10 output pins. The SRP-X500P can
be controlled by a switch or volume
controller connected to the input pins.
Connecting these pins to an emergency
broadcast system allows the audio
output of the SRP-X500P to be cut off
during an emergency broadcast.
The following devices can be
connected to this connector:
!¢ !£ !™ !¡ !º 9 8
71 654321
Input pins
Connectable device
Switch -
Volume With 10 kΩ, B-curve
Emergency broadcast system Connected via relay
Output pins
Connectable device
LED 24 V DC or less, 40 mA or less
Relay 24 V DC or less, 40 mA or less

9
3Panel View
5REMOTE RS-232C connector
(D-sub, 9-pin, male)
This is an RS-232C serial connector for
remote control. When a PC is
connected, parameters can be set using
the SRP-X500P Manager software. The
SRP-X500P can be controlled from the
external controller connected to the
REMOTE RS-232C connector.
6OUTPUT connector section
These connectors output the video
signal input from the AV/RGB INPUT
video connectors. Signal format
conversion is not carried out.
COMPONENT/RGB connector
(HD D-sub, 15-pin, female): Outputs
component or RGB signals.
VIDEO connector (phono jack):
Outputs composite signals.
7SPEAKERS CH terminals (1 to 4)
(screw terminal)
These are the output terminals of the
internal power amplifiers. For more
details, refer to Connecting High-
impedance Speakers/Low-impedance
Speakers in the appendix.
8CIRCUIT BREAKER button
The circuit breaker cuts off the main
power when excessive current flows
through the AC IN connector. If the
circuit breaker trips, press the CIRCUIT
BREAKER button to reset the breaker,
but do not use the SRP-X500P. Instead,
turn it off and contact the Sony dealer
from whom you purchased the unit.
9AC IN connector
Connects the supplied AC power cord.
!º LINE OUTPUT connectors (1 to 4)
(phono jack)
Connect to the line input connectors of
apower amplifier, CD/MD recorder, etc.
The LINE OUTPUT 3/4 is set to REC OUT
in factory default settings. SRP-X500P
Manager software settings can be
changed in order to use LINE OUTPUT
3/4 connectors for other purposes.
!¡ AV/RGB INPUT audio connectors
(A to E) (phono jack)
Connect to the audio output connectors
of devices with video output connection
to SRP-X500P !¢ AV/RGB INPUT video
connectors. When connecting a device,
be surethat each output connector on
the device is connected to the AV/RGB
INPUT video and audio connector on
the SRP-X500P with the corresponding
letter (A to E).
!™ LINE IN connectors (phono jack)
Connect to the line output connectors
of a CD player, MD recorder, etc.
!£ MIC INPUT connectors (1 to 4)
(XLR-3-31-type)
Connect wired microphones. When
wired microphones are connected to
the MIC INPUT 1/2 connectors, input
signals from the wireless microphones
take priority from the moment the
tuner units begin receiving the signal.
!¢ AV/RGB INPUT video connectors
(A to C: phono jack; D and E:
HD D-sub, 15-pin, female)
Connect to the video output connectors
of devices with audio output connection
to SRP-X500P !¡ AV/RGB INPUT audio
connectors. When connecting a device,
be sure that each output connector on
the device is connected to the AV/RGB
INPUT video and audio connector on
the SRP-X500P with the corresponding
letter (A to E).

10
SRP-X500P System Integration Guide
4-1. SYSTEM TYPE
What is a “SYSTEM TYPE”?
The SRP-X500P offers nine factory default system settings
called “SYSTEM TYPE” in its memory, enabling efficient
audio adjustment. Depending on the type of room,
speaker locations, and speaker system configurations, you
can quickly configure an audio system by recalling the best-
suited preset for each venue. If your requirements cannot
be managed by one of the nine system presets provided,
you can easily customize all system settings using the
supplied SRP-X500P Manager software.
SYSTEM TYPE 1, 2 (for AV Presentation Rooms)
SYSTEM TYPE 1 and 2 are suitable for AV presentation
rooms. This type of room needs clear voice reproduction
from microphones, and vivid sound from AV equipment
such as DVD and CD players. Satisfying both requirements,
the following may be the best speaker configuration:
• Output microphone audio from ceiling speakers to
enhance clarity
• Output AV equipment audio from the front speakers in
stereo
For ceiling speakers, both multi-connected high-impedance
speakers and high-quality low-impedance speakers can be
used.
The SRP-X500P is equipped with a four-channel digital
power amplifier (SP1 to SP4). Low-impedance speakers can
be connected to SP1 and SP2, while SP3 and SP4 can be
switched between high- and low-impedance modes. This
means you can configure systems as follows:
• SYSTEM TYPE 1: a pair of front speakers and
high-impedance ceiling speakers (70V Line)
• SYSTEM TYPE 2: a pair of front speakers and
low-impedance ceiling speakers (Lo-imp)
4Setting up the SRP-X500P
SP 2
70V LINE
(SP 3-4)
SP 1
SP 2
SP 3 SP 4
SP 1
SP 2
SP 1
SP 2
SP 1 SP 3
SP 4
A
70V LINE
(SP 3-4) SP 1 SP 2 SP 3 SP 4
AV Presentaion Room
SYSTEM TYPE 1 (70V LINE)
SYSTEM TYPE 4 (70V LINE)
SYSTEM TYPE 2 (Lo-imp)
SYSTEM TYPE 5 (Lo-imp)
SYSTEM TYPE 3 SYSTEM TYPE 6 to 9
Conference Room
Audio-Visual Room
SP 2
70V LINE
(SP 3-4)
SP 1
SP 2
SP 3 SP 4
SP 1
SYSTEM TYPE 1 (70V LINE) SYSTEM TYPE 2 (Lo-imp)
LINE,
AV/RGB R
LINE,
AV/RGB L
LINE,
AV/RGB R
LINE,
AV/RGB L
MIC
MIC
MIC
LINE
AV/RGB
MIC
LINE
AV/RGB
SRP-X500P SRP-X500P
SP 1
SP 2
SP 1
SP 2
SP 3-4
(70V LINE)
IN OUT IN OUT
When using high-impedance ceiling speakers
SP 3
(Lo-imp)
SP 4
(Lo-imp)
When using low-impedance ceiling speakers
{ {

11
4Setting up the SRP-X500P
SYSTEM TYPE 4, 5 (for Conference Rooms)
SYSTEM TYPE 4 and 5 are well suited for conference
rooms. This type of room mainly needs clear voice
reproduction from microphones. In these rooms, the
speaker system consists of ceiling speakers. Audio from AV
sources is mixed to monaural, and is output from all power
amplifiers (SP1 to SP4).
• SYSTEM TYPE 4 uses only SP3 and SP4 outputs, and
consists of high-impedance ceiling speakers (70V LINE)
• SYSTEM TYPE 5 uses all outputs from SP1 to SP4, and
consists of low-impedance ceiling speakers (Lo-imp)
SYSTEM TYPE 3, 6, 7, 8, 9
(for Audio-Visual Rooms)
SYSTEM TYPE 3, 6, 7, 8, and 9 settings are suitable for
audio-visual rooms. This type of room mainly needs vivid
audio reproduction from AV equipment such as DVD and
CD players. In these rooms, ceiling speakers are not used.
Audio from microphones is output from front speakers and
satellite speakers. So, speaker output should be adjusted
to be heard evenly anywhere in the room.
In a long length audio-visual room, locating satellite
speakers in the middle of the room is an effective way of
maintaining sufficient sound pressure at the rear of the
room, while suppressing excessive sound pressure close to
the speakers. SYSTEM TYPE 6 to 9 settings fit such rooms,
and are selected depending on the distance between front
speakers and satellite speakers.
By adding delay to satellite speakers according to their
distance from front speakers, users can compensate for
audio delay, allowing clear audio reproduction throughout
the room. For more details on the delay feature, please
refer to the appendix.
SP 2
SP 1
SP 2
SP 1 SP 3
SP 4
A
SYSTEM TYPE 3 SYSTEM TYPE 6 to 9
LINE,
AV/RGB R
MIC
LINE,
AV/RGB L
MIC
LINE,
AV/RGB R
MIC
LINE, AV/RGB R
MIC
LINE,
AV/RGB L
MIC LINE, AV/RGB L
MIC
MIC
LINE
AV/RGB
MIC
LINE
AV/RGB
SRP-X500P SRP-X500P
SP 1
SP 2
SP 1
SP 2 SP 3
(Lo-imp)
SP 4
(Lo-imp)
When using front speakers When using front speakers and satellite speakers
DELAY
SYSTEM TYPE 6 A= 0 m
SYSTEM TYPE 7 A= 5 to 8 m
(16.7 to 26.7 feet)
SYSTEM TYPE 8 A= 8 to 11 m
(26.7 to 36.7 feet)
SYSTEM TYPE 9 A= 11 to 14 m
(36.7 to 46.7 feet)
IN OUT IN OUT
70V LINE
(SP 3-4) SP 1 SP 2 SP 3 SP 4
SYSTEM TYPE 4 (70V LINE) SYSTEM TYPE 5 (Lo-imp)
MIC
LINE
AV/RGB
MIC
LINE
AV/RGB
SRP-X500P SRP-X500P
SP 1
SP 2
SP 3-4
(70V LINE)
When using high-impedance ceiling speakers
SP 3
(Lo-imp)
SP 4
(Lo-imp)
When using low-impedance ceiling speakers
{ {
MIC, LINE,
AV/RGB
MIC, LINE,
AV/RGB
IN OUT IN OUT

12
SRP-X500P System Integration Guide
SYSTEM TYPE 0
SYSTEM TYPE 0 is selected to customize system settings. If
your application does not fit the description of SYSTEM 1
to 9 environments, or if you prefer to individually adjust
various SRP-X500P functions, users can select SYSTEM TYPE
0and set the parameters using the supplied Manager
software. This chart explains when SYSTEM TYPE 0 should
be selected:
NO
YES
YES
YES
YES
NO
NO
NO
You want to configure an AV system
that does not fit into SYSTEM TYPE 1 to 9. Select SYSTEM TYPE 0.
Select SYSTEM TYPE 0.
Select SYSTEM TYPE 0.
Select SYSTEM TYPE 0.
Confirm parameters and select SYSTEM 1 to 9.
You want to finely adjust the
compressor or equalizer.
You want to change the assignment of
MASTER volume or REMOTE FADER.
You want to use Scene Memory.

13
4Setting up the SRP-X500P
4-2. Feedback Reducer
The SRP-X500P is equipped with an independent feedback
reducer function on each microphone channel, helping to
achieve optimum sound quality. In multimedia presentation
systems, it’s not unusual for microphones to be located
within the speaker coverage area (sometimes in front of a
speaker), and howling may occur when the distance
between a speaker and microphone is too close. In the
past, howling has been typically suppressed by making
repeated manual adjustments to a graphic equalizer, but
this manual operation takes a long time as the user must
detect the frequency bands in which howling occurs. Now,
with the SRP-X500P, howling is easily and quickly
suppressed by the built-in feedback reducer function. For
an explanation of howling, please refer to the appendix.
1Adjust the TRIM
volume while
talking on a wired
microphone, or
adjust the audio
attenuator on the
transmitter while talking on a wireless
microphone, so the REF indicator lights up
intermittently.
2Set the INPUT LEVEL to
the 0 dB position.
3Set the MASTER volume to
the 0 dB position.
4Turn up the SPEAKER OUT volume slowly until
speaker output reaches the appropriate level
from anywhere in the room.
5Hold down the FEEDBACK REDUCER button
for two seconds or more. The indicator flashes
during scanning of the frequency band.
Setting is complete once the flashing stops.
2
54 3
1
■Setting

14
SRP-X500P System Integration Guide
5-1. Automatic Gain Control (AGC)
It is often difficult to appropriately adjust microphone
volumes when picking up voice. This is because speaking
volumes differ from person to person, and depend on the
distance between each presenter’s mouth and the
microphone. The Automatic Gain Control (AGC) function
is convenient for maintaining an optimum audio level by
reducing speech volume differences. AGC can be set using
the supplied SRP-X500P Manager software. For more
details on AGC, refer to the appendix.
■Setting
1. Set the overall audio volume. The speaker output
level should be adjusted beforehand so that the audio
can be heard evenly anywhere in the room.
2. Set the AGC to ON. Left click the AGC button on the
OVERVIEW screen to display the AUTO GAIN
CONTROL setting screen. Click the ON button to turn
on the AGC function.
3. Initially set the GATE THRESHOLD level to -50 dB.
4. Adjust the COMPRESSOR THRESHOLD level so that
the GAIN CONTROL meter reads between -5 and
-10 dB when talking on a microphone in a loud voice.
At the same time, adjust the RATIO so that the voice
can be clearly heard. As a rough guideline, set it
between 3:1 and 10:1.
5. Adjust the MAKE GAIN
so that the compressor
characteristics line is at
0dB IN/0 dB OUT.
6. Adjust the GATE THRESHOLD level so that the gate
does not open with the ambient noise level present
during a presentation.
7. Adjust the RANGE level so that the ambient noise is
not completely muted. At the same time, confirm
that the gate opens when you talk into the
microphone. If you lower the volume too much, the
timing to open the gate will be delayed when you
talk on the microphone. This may cause a
momentary microphone off when starting to speak.
8. Adjust the ATTACK, HOLD, and RELEASE times.
ATTACK time means the response time when the gate
opens or the compressor works. As a rough
guideline, set it to 50 ms or less.
HOLD time suppresses the rapid change of gain by
maintaining the condition of the gate and
compressor. 10 ms to 100 ms may be a suitable
value. If you want to eliminate any unnatural sound
that may occur for a short duration just after talking,
set a short HOLD time value. If the gate closes
between words while speaking, set a longer value.
RELEASE time is the response time it takes from the
gate opening and closing, the compressor stopping,
and the gain returning to normal. 100 ms to 300 ms
may be an appropriate value. If the level rapidly
changes and the voice is interrupted, set a longer
RELEASE time. If you are worried about the noise
made by the gate closing, set a shorter time.
9. Setting is now complete, so close the AGC screen.
5Setting up the SRP-X500P Using
Manager Software
AUTO GAIN CONTROL Setting Screen

15
5Setting up the SRP-X500P Using Manager Software
5-2. Delay
The SRP-X500P is equipped with a four-channel power
amplifier. By utilizing all amplifiers, you can configure a
multiple speaker system with the SRP-X500P. When you
select SYSTEM TYPE 0 to configure your audio-visual room,
adelay setting is required to compensate for the distance
between front speakers and satellite speakers. Delays can
be set on the OVERVIEW screen of the supplied SRP-X500P
Manager software.
■Setting
1. Measure the distance between the main speakers and
the satellite speakers (e.g. 10 m).
2. Select meters or feet from the drop-down list in the
UNIT setup box. Then input the value in the SP3 and
SP4 DELAYboxes.
3. By setting the delay parameter a little longer than the
actual measurement, you can get more natural audio
from front speakers. Select ms from the drop-down
list in the UNIT setup box.Then add 10 to 20 ms to
the SP3 and SP4 DELAY value (e.g. 20 ms).
4. Listen to the audio. If it sounds normal, the setting
is complete.
If you find the audio from the front speakers and
satellite speakers is not unified, the delay parameter is
too great. Reduce its value gradually, and check by
listening. If sound is located at the mid-point between
the left and right satellite speakers, the delay parameter
is too small. Increase its value gradually.
Sound source
Rch
DELAY
DELAY
L: distance
Lch

16
SRP-X500P System Integration Guide
5-3. Parallel Remote
When the SRP-X500P is installed in a presentation room,
the external control panel can be used to remotely control
AV equipment.
The PARALLEL REMOTE interface on the rear panel of the
SRP-X500P allows remote control of peripherals from the
external control panel using switches and volume
controls.
Connectable Devices to PARALLEL REMOTE
Input Pins
The following types of device can be connected to the
PARALLEL REMOTE:
• Toggle Switch
The toggle switch is an electric switch operated by
pushing a latching-type lever.Pressing it once turns the
circuit on, and pressing it again turns the circuit off. The
toggle switch controls:
-Muting
- PROJECTOR POWER ON/STANDBY
•Push Switch (momentary-type)
Press the push switch to turn on the circuit.The push
switch controls:
- Input signal selection for the AV/RGB INPUT
- MASTER VOLUME UP
-MASTER VOLUME DOWN
- SCENE RECALL
-PROJECTOR POWER ON
- PROJECTOR POWER STANDBY
• Control Volume
The control volume is used to adjust REMOTE FADER.
Select the control volume with a 10 kΩ B curve. This
can be used to remotely control the volume of REMOTE
FADER LEVEL.
MASTER Volume Muting
The following is an example of muting MIC1 to MIC4
together assigned to the MASTER volume, using a toggle
switch.
■Setting
1. Connect a toggle switch to INPUT 1 of the PARALLEL
REMOTE connector on the SRP-X500P.
2. Click MIC1 to MIC4 in the MASTER line on the
REMOTE FADER screen (Fig. 1).
3. Select MASTER VOLUME MUTING on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1
(Fig. 2).
■Status
The relationship between the switch position and the
muting status is as follows (Fig. 3):
- Pressing the switch once mutes the MASTER volume.
- Pressing the switch once again releases the muting of
the MASTER volume.
Press switch once
Fig. 3 Muting Status
Fig. 1 REMOTE FADER Screen Fig. 2 MASTER VOLUME
MUTING Screen
Press switch again

17
5Setting up the SRP-X500P Using Manager Software
PROJECTOR POWER ON/STANDBY (1)
The following is an example of controlling PROJECTOR
POWER ON/STANDBY using a toggle switch.
■Setting
1. Connect a toggle switch to INPUT 1 of the PARALLEL
REMOTE connector on the SRP-X500P.
2. Select PROJECTOR POWER ON/STANDBY on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1
(Fig. 4).
■Status
The relationship between the switch position and the
projector power status is as follows (Fig. 5):
- Pressing the switch once turns on projector power.
- Pressing the switch once again sets projector power to
standby mode.
PROJECTOR POWER ON/STANDBY (2)
The following is another example of controlling PROJECTOR
POWER ON/STANDBY using two push switches.
■Setting
1. Connect two push switches to INPUT 1 and INPUT 2
of the PARALLEL REMOTE connector on the
SRP-X500P.
2. Select PROJECTOR POWER ON on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1.
Then select PROJECTOR POWER STANDBY on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 2
(Fig. 6).
■Status
The relationship between the switches and the projector
power status is as follows (Fig. 7):
-Pressing the switch assigned to INPUT 1 turns on
projector power.
-Pressing the switch assigned to INPUT 2 sets projector
power to standby mode.
Press switch once
Fig. 5 Projector POWER ON/STANDBY Status
Fig. 4 PARALLEL/PROJECTOR CONTROL Screen
Press switch again
Press switch
Press switch
INPUT 1
(PROJECTOR
POWER ON)
INPUT 2
(PROJECTOR
POWER STANDBY)
Projector
Power
Fig. 7 Switch and Projector Power ON/STANDBY Status
Fig. 6 PARALLEL/PROJECTOR CONTROL Screen

18
SRP-X500P System Integration Guide
Input Signal Selection for the AV/RGB INPUT
Connector
The following is an example of selecting input signals to
the AV/RGB SELECT A to C using three push switches.
■Setting
1. Connect three push switches to INPUT 1, INPUT 2,
and INPUT 3 of the PARALLEL REMOTE connector on
the SRP-X500P.
2. Select AV/RGB SELECT A on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1.
Select AV/RGB SELECT B on the PARALLEL/PROJECTOR
CONTROL screen. This selection appears on a drop-
down list on INPUT 2. And then select AV/RGB
SELECT C on the PARALLEL/PROJECTOR CONTROL
screen. This selection appears on a drop-down list on
INPUT 3 (Fig. 8).
■Status
The relationship between the switches and the input
signals is as follows (Fig. 9):
- Press to select one of the devices connected to the
AV/RGB INPUT connector.
MASTER Volume Control
The following is an example of raising or lowering the
MASTER volume using two push switches.
■Setting
1. Connect two push switches to INPUT 1 and INPUT 2
of the PARALLEL REMOTE connector on the
SRP-X500P.
2. Select MASTER VOLUME UP on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1.
Then select MASTER VOLUME DOWN on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 2
(Fig. 10).
■Status
The relationship between the switches and the input
signals is as follows (Fig. 11):
- Pressing the switch raises or lowers the MASTER
volume.
Press switch
Press switch
Press switch
INPUT 1
(AV/RGB A)
INPUT 2
(AV/RGB B)
INPUT 3
(AV/RGB C)
AV/RGB
SELECT
Fig. 9 Switch and AV/RGB SELECT Status
Fig. 8 Setting of the PARALLEL REMOTE
A
B
C
D
E
A
B
C
D
E
A
B
C
D
E
Press switch
Press switch
StopDownStopUpStop
INPUT 1
(MASTER
VOLUME UP)
INPUT 2
(MASTER
VOLUME DOWN)
MASTER
VOLUME
Fig. 11 Switch and MASTER VOLUME Status
Fig. 10 Setting of the PARALLEL REMOTE

19
5Setting up the SRP-X500P Using Manager Software
Scene Recall
The following is an example of recalling SCENE No.1 and
SCENE No.2 using two push switches.
■Setting
1. Connect two push switches to INPUT 1 and INPUT 2
of the PARALLEL REMOTE connector on the
SRP-X500P.
2. Select SCENE RECALL No.1 on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1.
Then select SCENE RECALL No.2 on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 2
(Fig. 12).
■Status
The relationship between the switches and scene recall is
as follows (Fig. 13):
- Press the switch to recall the relevant scene memory.
Remote Fader Level Control
The following is an example of controlling the level of
MIC1 to MIC4 using the remote fader control volume.
■Setting
1. Connect a control volume to INPUT 1 of the
PARALLEL REMOTE connector on the SRP-X500P.
2. Click MIC1 to MIC4 in the REMOTE1 line on the
REMOTE FADER screen (Fig. 14).
3. Select the REMOTE FADER1 LEVEL on the
PARALLEL/PROJECTOR CONTROL screen. This
selection appears on a drop-down list on INPUT 1
(Fig. 15).
■Operation
By rotating the volume control, the user can adjust the
channel volume assigned to the remote fader. The
adjustable range is between -∞ and 0 dB. The total
volume level is the combination of MIC INPUT volume on
the front panel and REMOTE FADER volume. If MIC
INPUT volume on the front panel is set to -10 dB, the
total volume level is as illustrated in Fig. 16.
Press switch
Press switch
No. 1 No. 2
INPUT 1
(SCENE RECALL
No. 1)
INPUT 2
(SCENE RECALL
No. 2)
Scene Memory
Fig. 13 Switch and SCENE RECALL Status
Fig. 12 Setting of the SCENE RECALL
Total volume
-15dB
-25dB
0dB
+10dB
-10dB
-∞dB
-∞dB
-∞
INPUT 1
(REMOTE FADER 1
LEVEL)
Level of the
MIC INPUT volume
Fig. 16 Position of the Volume and the Result
Fig. 14 REMOTE FADER Screen Fig. 15 REMOTE FADER Setting

20
SRP-X500P System Integration Guide
5-4. Projector Control
Outline
The SRP-X500P is equipped with PROJECTOR CONTROL
RS-232C and CONTROL S interfaces. By pressing the
AV/RGB SELECT buttons on the front panel, an array of
input signal formats - including composite video,
component video, and computer RGB, which are connected
to the AV/RGB inputs – can be seamlessly switched. In
addition, projector power on/standby control and
projector input selection commands are sent via the
PROJECTOR CONTROL RS-232C or CONTROL S interface.
Setting Procedure
The following flow chart indicates the installation and
settings to control a projector from the SRP-X500P.
Completed
Setting the input video signal format and projector
power control (refer to SECTION C)
Cable connection (refer to SECTION B)
Set up the control commands with PROTOCOL SETTING
(refer to SECTION D)
Setting the PROJECTOR PROTOCOL selection switch
(refer to SECTION A)
Specify the video signal format on AV/RGB inputs.
Set the projector power on/off setting whether or
not it is to be synchronized with the power on/off
status of the SRP-X500P.
Connect cables for the video signal and
control signal.
Select PROJECTOR PROTOCOL
from 1 to F when using a Sony
projector or flat panel display.
Refer to the Sony model number
list on the following page.
Select "0" if the model number of the projector
or flat panel display is not one of the supplied presets.
Set the selector in accordance with the model
number using the projector protocol selector on
the SRP-X500P front panel.
