Sony HAP-Z1ES User manual

HAP-Z1ES
HDD AUDIO PLAYER Quick Start Guide GB
快速入门指南 CS

2GB
About manuals
Quick Start Guide (this manual)
Explains procedures for setting up the unit to transfer music files
on the computer automatically and play them back.
Visit the website below for more information on the unit.
Help Guide (online manual)
Provides information on how to use the unit.
• Detailed information is included on how to use functions such as
DSEE.
• Quickly access the latest information and other information you
want by utilizing the “Troubleshooting” section or searching by
keyword.
HAP-Z1ES:
http://rd1.sony.net/help/ha/hapz1es/
HAP Music Transfer/HDD Audio Remote:
http://rd1.sony.net/help/ha/hap1/
Reference Guide
Includes information on specifications and notes on use for the
unit.
Supplied accessories
Remote control (1) R03 (size-AAA) batteries (2) AC power cord (mains lead) (1)
LAN cable (1) Audio cord (1) IR blaster (1) Monaural mini-plug
cable (1)

3GB
Table of Contents
Features
------------------------------------------------------------------------------------------------------------------------------------
4
Prep. 1 Connecting an amplifier --------------------------------------------------------------------- 5
Prep. 2 Connecting to a network with a LAN cable
------------------------- 6
Prep. 3 Plugging in the unit
-------------------------------------------------------------------------------- 7
Prep. 4 Configuring the initial settings of the unit
--------------------------- 8
Prep. 5 Configuring the settings of your computer to use
HAP Music Transfer
------------------------------------------------------------------------------- 10
Enjoying music
-------------------------------------------------------------------------------------------------------------- 12
Troubleshooting
----------------------------------------------------------------------------------------------------------- 14
GB
Trademarks
•iPhone, iPad and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App
Store is a service mark of Apple Inc.
•Google Play™, Android™ and their respective logos are trademarks of Google Inc.
For more details on how to use ----------------------------- See the
Help Guide (online manual)
introduced on the previous page.

4GB
Features
You can transfer various types of audio files to the hard disk drive of the
unit from a computer connected to the same network.
Storing audio files in the unit allows you to enjoy high-quality sound
playback unaffected by the network environment. You can enjoy High-
Resolution Audio files such as DSD (Direct Stream Digital) audio and
192kHz/24bit and compressed audio with more natural and expansive
sound.
Computer (not supplied)
Amplifier/Speaker (not supplied)
Router (not supplied)
Internet
HDD AUDIO PLAYER
You need to connect the unit to the same
network as your computer.
PlayTransfer
Modem
(not supplied)

5GB
Connecting an amplifierPrep. 1
Hint
You can also connect the unit to the amplifier using XLR balanced cords (not supplied).
Using an
Audio cord
(supplied)
Amplifier (not supplied)

6GB
Hint
You need to connect the unit to the same network (router) as your computer.
Connected to the same router
Router
Connected to different routers
Router Router
When transferring large volumes of data
Using a wired network is especially recommended.
A wired network connection enables you to transfer
music files more quickly.
Using a wireless network (Wi-Fi) connection
A network cable connection is not required.
Skip to the next page.
Using the
LAN cable
(supplied)
Router (not supplied)
LAN cable (not supplied)
Connecting to a network with a LAN cable
Prep. 2 (only when using a wired network)

7GB
Connect the
AC power
cord
(supplied)
Plugging in the unitPrep. 3

8GB
1Press to turn on the unit.
The power lamp lights up in green.
2Turn the jog dial to select the item following the instructions on the screen, and
then press ENTER.
Configure the initial settings in the following order:
•Language
•Network Standby Settings
•Internet Settings
– Wired Setup If you are not sure what to do in the [Wireless Setup]
screen, check the example of a wireless network
connection on the next page.
– Wireless Setup
Configuring the initial settings of the unitPrep. 4
Setting
by the
screen
Jog dialPower lamp
ENTER
(Power)

9GB
1Press to turn on the unit.
The power lamp lights up in green.
2Turn the jog dial to select the item following the instructions on the screen, and
then press ENTER.
Configure the initial settings in the following order:
•Language
•Network Standby Settings
•Internet Settings
– Wired Setup If you are not sure what to do in the [Wireless Setup]
screen, check the example of a wireless network
connection on the next page.
– Wireless Setup
Example of a wireless network connection
This is a sample of settings when you select [Wireless Setup] for the [Internet
Settings] in step 2 on the previous page.
1Ready the network name (SSID) and security
key of the wireless router/access point to
which your computer is connected.
Router
(not supplied)
SSID
Security key
Hint
The name for the “security key (password)” of a router differs depend on its manufacturer.
(“WPA key”, “security key”, “KEY”, “WEP key”, “passphrase” or “network key”, etc.)
2Select [Wireless Setup].
3Select [Select access point].
4Select the network name (SSID) found in step 1.
If it does not appear in the list of available network
names, select [Add a new access point].
5Enter the security key.
Follow the instructions on the screen to complete
configuration of the settings.

10GB
You can transfer music files managed on your computer to the unit using HAP Music Transfer.
HAP Music Transfer allows you to start transferring music files to the unit automatically when
new music files are added to the designated folder on your computer.
Transfer
Router (not supplied)
1Install HAP Music Transfer on your computer from the following website:
http://www.sony-asia.com/support
2Start HAP Music Transfer on your computer and check that the network device
name of the unit appears on the top left of the display.
If the network device name of the unit
does not appear
The unit and computer are not
connected to the network correctly.
Check the next page and make so the
unit name appears.
3Transfer music files to the unit using HAP Music Transfer.
For details on the operations of HAP Music Transfer, refer to the HAP Music Transfer Help.
Configuring the settings of your computer
to use HAP Music Transfer
Prep. 5
