Sony Walkman NWZ-WH505 User manual

Installing WALKMAN Guide and Media Go (for
Windows)
1Connect your Walkman to a running
computer using the USB cable (supplied).
2 Select the following order with the
computer.
Windows 7 or earlier: Select [Start] – [Computer] or [My Computer]
– [WALKMAN] – [Storage Media] – [FOR_WINDOWS].
Windows 8: Select [Desktop] from [Start screen] to open [File
Explorer]. In the [Computer] list, select [WALKMAN] – [Storage Media]
– [FOR_WINDOWS].
3Double-click [Setup.exe].
The install wizard appears.
When you execute [Setup.exe], the [Setup.exe] file stored in
the [FOR_WINDOWS] folder of your Walkman is copied to
your computer for backup, and WALKMAN Guide and Media
Go are installed to your computer.
If [Setup.exe] does not start, copy the [Setup.exe] file to your
desktop, then double-click it.
4 Follow the on-screen instructions.
After the install wizard finishes, the WALKMAN Guide and
Media Go shortcuts appear on the desktop of your computer.
The Help Guide is included in the WALKMAN Guide.
Contents
Please check the items in the package.
“WALKMAN” (1)
USB cable (1)
Headphones cable (1)
Quick Start Guide (this manual)
About the Operating System
Make sure that the OS is Windows XP*1(Service Pack 3 or later), Windows
Vista*2(Service Pack 2 or later), Windows 7*2(Service Pack 1 or later), or
Windows 8.
*1Excluding 64-bit OS versions.
*2[Compatibility mode] for Windows XP is not supported.
For a Mac computer, make sure that the OS is Mac OS X v10.6 or later.
Not supported by OSs other than above
Installing the Help Guide and the Content Transfer
software (for Mac)
1Connect your Walkman to a running
computer using the USB cable (supplied).
2On the computer, select [WALKMAN] in the
sidebar of Finder, then open the [FOR_MAC]
folder.
3Double-click the installer icon of the desired
software:
To install the Help Guide:[Help_Guide_Installer_for_Mac]
To install the Content Transfer software: [ContentTransfer.pkg]
4Follow the on-screen instructions.
After the installer finishes, the alias (shortcut) of the installed
software (Help Guide or the Content Transfer software)
appears on the desktop of your computer.
Hint
Before you attempt to delete the software from your Walkman, copy the
[FOR_MAC] folder to your Mac computer as a backup if necessary.
OPR lamp
USB cable (supplied)
1Connect your Walkman to a running
computer using the USB cable (supplied).
Charging starts. The OPR (operation) lamp lights up.
Notes on charging by using the computer
Charge the battery when the OPR lamp blinks in green and orange alternately.
When the battery is nearly depleted, the OPR lamp blinks in red and orange
alternately.
While the battery is charging, the lamp indicates the charging status of your
Walkman.
Lights up in orange: Being charged
Turns off: Charged fully or not being charged
Charging time is approx. 2 hours.
When your Walkman has been fully charged, disconnect it from the computer.
For a Mac computer, click the [WALKMAN] eject icon in the sidebar of Finder to
disconnect your Walkman.
How to Install the Supplied Software
About the manuals
This Quick Start Guide only describes the basic operating instructions
and how to install the supplied software.
For detailed information and operating instructions, refer to the Help
Guide (HTML document) included in the supplied software after
installation.
Attaching Your “WALKMAN” to Your Computer and Charging the Battery Parts and Controls
Quick Start Guide
©2013 Sony Corporation
Printed in Malaysia
How to Install the Supplied Software
How to Use Your “WALKMAN”
NWZ-WH505/WH303
RESET button
POWER switch
OUTPUT switch
(headphones)
(built‑in speakers)
Built‑in speakers
Illuminations
OPR (operation) lamp
Micro USB jack
HEADPHONES jack
SOUND/ILLUMINATION
button
SHUFFLE/PLAY LIST button
VOLUME –/+*1button
Jog lever (//)
Press to start/pause
playback. Press and hold for
longer than 1 second during
playback to start ZAPPIN
playback.
Slide to or to skip to the
next or previous song. Slide to
or and hold for longer
than 1 second to skip to the
beginning of the previous or next
folder.
*1There is a tactile dot. Use it to help with volume adjustment operations.
This product is a headphones-type “WALKMAN.”
In addition to transferring music directly to your Walkman and enjoying the
music, you can also use it simply as headphones by turning the POWER
switch to OFF and connecting your Walkman to other music players. This
headphones-type Walkman is referred to as a “Walkman” in this manual.
4-467-857-11(1)
About volume operation (Only for countries/areas
complying with European Directives)
An alarm (beep) and warning “Check the volume level” are meant to
protect your ears when you raise the volume setting beyond a specific
level*1for the first time.
You can cancel the alarm and warning by pressing any button.
Note
You can turn up the volume beyond the specific level*1after canceling the
alarm and warning.
After the initial warning, the alarm and warning repeat for every 20 cumulative
hours that the volume is set beyond the specific level*1; when this happens,
the volume is changed to level [7] automatically.
If the volume is set beyond the specific level*1and you turn off the Walkman,
the volume returns to the specific level*1automatically.
*1Specific level = [17]
If some computer enters a power saving mode such as the Sleep or
Hibernation mode while your Walkman is connected via the USB cable
(supplied), the Walkman may continue to draw power from the battery,
discharging it.
When you use your Walkman for the first time, or if you have not used the
Walkman for a long time, it may take a few minutes to be recognized by the
computer, even if charging has already started (the OPR lamp lights up in
orange). Check that the computer recognizes your Walkman after you have
connected it to the computer for about 10 minutes.
You cannot operate your Walkman while it is charging.
To prevent battery deterioration, charge the battery at least once every six
months or every year.
Access to the online Help Guide (Full version).
For PC or Smart phones
While browsing is free, you may charge the
communication fee according to your carrier
contract.
http://rd1.sony.net/help/dmp/nwzwh300_500/en/

Troubleshooting
If your Walkman does not function as expected, try the following steps to
resolve the issue.
1Find the symptoms of the issue in “Troubleshooting”
in the Help Guide (HTML document), and try any
corrective actions listed.
For details on troubleshooting, see the tables on the right too.
2Connect your Walkman to your computer to charge
the battery.
You may be able to resolve some issues by charging the battery.
3Press the RESET button with a
pen or paper clip, etc.
When you reset your Walkman, please
make sure of the following.
Your Walkman is not connected to your
computer.
Your Walkman is not playing back music.
4Check information on the issue in
the Help of each software.
RESET
button
5Look up information on the issue on one of the
customer support Web sites.
About the customer support Web sites, see “For the latest
information”.
6If the approaches listed above fail to resolve the
issue, consult your nearest Sony dealer.
Symptom Cause/Remedy
Your Walkman cannot
charge the battery. The USB cable is not connected to a USB
connector on your computer properly.
Disconnect the USB cable, and then
reconnect it.
Use the supplied USB cable.
The battery is charged in an ambient
temperature out of the range of 5 °C (41 °F) to
35 °C (95 °F).
Charge the battery in an ambient
temperature of 5 °C (41 °F) to 35 °C (95 °F).
The computer is not on.
Turn on the computer.
Your computer has entered Sleep or
Hibernation status.
Release the computer from Sleep or
Hibernation status.
A USB hub is being used.
Connecting your Walkman via a USB hub
may not work. Connect the Walkman directly
to your computer using the USB cable
(supplied).
The operating system installed on the
computer is not supported by your Walkman.
To charge the Walkman, connect the
Walkman to a computer with the operating
system that is supported by the Walkman.
Symptom Cause/Remedy
The computer does
not recognize your
Walkman.
Your Walkman is not connected to your
computer properly using the USB cable
(supplied).
Disconnect the USB cable, and then reconnect
it properly and firmly both to your Walkman
and your computer.
The remaining battery power is low or
insufficient.
Recharge the battery. When you use your
Walkman for the first time, or if you have not
used the Walkman for a long time, it may
take a few minutes to be recognized by the
computer, even if charging has already
started (the OPR lamp lights up in orange).
Check that the computer recognizes the
Walkman after you have connected it to the
computer for about 10 minutes.
The computer is running another software
other than that used for transferring.
Disconnect the USB cable (supplied), wait for
a few minutes, and reconnect it. If the
problem persists, disconnect the USB cable
(supplied), restart the computer, and then
reconnect the USB cable (supplied).
During playback of a
song, the next song is
suddenly started.
Your Walkman may perform ZAPPIN playback.
For details, refer to the Help Guide.
Precautions
Information on laws and trademarks
For information on laws, regulations and trademark rights, refer to “Important
Information” contained in the supplied software. To read it, install the supplied
software on your computer.
About the headphones
Avoid playing the unit at so loud a volume that extended play might affect
your hearing.
At a high volume outside sounds may become inaudible. Avoid listening to
the unit in situations where hearing must not be impaired, for example, while
driving or cycling.
How to Turn the Power On and Wear
Your Walkman on Your Ears
1Check the left () and right () sides of your
Walkman.
2Slide the POWER switch on the left () side to ON to
turn on your Walkman.
Also make sure that the OUTPUT switch on the left () side is set to
(headphones).
3Wear your Walkman on your ears.
Adjust the slider so that the headphones fit your ears properly.
Wearing Your Walkman around Your
Neck
Wear your Walkman around your neck and listen to music out loud from
the speakers.
1Slide the POWER switch to ON and the OUTPUT switch
to (built-in speakers) on the left () side of your
Walkman.
2Wear your Walkman around your neck with its right
and left sides correctly placed and with the speakers
() facing upwards.
Adjust the slider so that the speakers are in the best position.
Playing Music
Playing songs
Press the button (jog lever) on the right () side.
To pause playback
Press the button (jog lever) on the right () side.
Skipping to the previous/next song
Slide the button (jog lever) to (previous) or (next) direction.
Adjusting the volume
Press VOLUME +/– button on the right () side.
Listening to the Sound from Other
Players
You can listen to music from a smart phone or another player by
connecting it to your Walkman using the headphones cable (supplied).
Note
When used this way, this Walkman works only as headphones, so you cannot
operate player functions on your Walkman. Operate playback functions using
the player.
Sound will not be emitted from the speakers of your Walkman when you are
listening to music from another player connected to your Walkman.
1Slide the POWER switch on the left () side of your
Walkman to OFF/HEADPHONES.
2Connect the headphones cable (supplied) to the
HEADPHONES jack on the left () side.
3Connect the other end of the cable to the player.
4Wear your Walkman on your ears.
Headphones cable
(supplied)
As the supplied headphones are of open-air design, sounds go out through
the headphones. Remember not to disturb those close to you.
About the in-ear headphones
The earbuds seal your ears. Therefore, be aware that there is a risk of
damage to your ears or eardrums if strong pressure is applied to the
earbuds, or the earbuds are suddenly removed from your ears. After use,
be sure to take the earbuds off your ears gently.
About the earpads
Optional earpads for replacement can be ordered from your nearest Sony
dealer. For replacement procedures, please refer to the Help Guide.
For the latest information
If you have any questions or issues with this product, or would like
information on items compatible with this product, visit the following web
sites.
For customers in the USA:
http://www.sony.com/walkmansupport
For customers in Canada:
http://www.sony.ca/ElectronicsSupport/
For customers in Latin America:
http://www.sony-latin.com/index.crp
For customers in Europe:
http://support.sony-europe.com/dna/wm/
For customers in Asia, Oceania, and Africa:
English: http://www.sony-asia.com/support
Korean: http://scs.sony.co.kr/walkman/
Simplified Chinese: http://service.sony.com.cn/KB/
Traditional Chinese: http://service.sony.com.tw/
For customers who purchased overseas models:
http://www.sony.co.jp/overseas/support/
5Start playing back on your player.
