SERVICE MANUAL
Published by Sony EMCS (Malaysia) PG Tec
Sony Corporation
HOME THEATRE SYSTEM
9-890-590-01
2012B80-1
© 2012.02
Ver. 1.0 2012.02
• HT-M2/M3 is composed of following models.
As service manuals are issued for each component model, please
refer to them.
COMPONENT MODEL NAME
HT-M2 HT-M3
Package STR-K2SW STR-K3SW
Multi Channel AV Receiver STR-KM2 STR-KM3
Subwoofer SS-WP3M SS-WP3M
Package SS-CRP2M SS-CRP3M
Front Speaker SS-MSP2M SS-MSP3M
Center Speaker - SS-CNP7M
Surround Speaker SS-SRP7M SS-SRP7M
HT-M2/M3
STR-K2SW/K3SW
• STR-K2SW is composed of STR-KM2 and SS-WP3M.
• STR-K3SW is composed of STR-KM3 and SS-WP3M.
• SS-CRP2M is composed of SS-MSP2M and SS-SRP7M.
• SS-CRP3M is composed of SS-CNP7M, SS-MSP3M and SS-SRP7M.
E Model
HT-M2/M3
Australian Model
Mexican Model
Singapore Model
Saudi Arabia Model
Thai Model
HT-M3
SPECIFICATIONS
Design and specifications are subject to
change without notice.
• Abbreviation
AR : Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
SAF : South African model
SP : Singapore model
TH : Thai model
Power requirements
Area Power requirements
SAF, TH, SP
230 V AC – 240 V AC, 50/60 Hz
MX 127 V AC, 60 Hz
E51 120/220/240 V AC, 50/60 Hz
AR
220 V AC – 230 V AC, 50/60 Hz
EA 120 V AC – 127/220/230 V
AC – 240 V AC, 50/60 Hz
AUS 230 V AC, 50 Hz
Power consumption 175 W (HT-M3)
155 W (HT-M2)
Power consumption (during standby mode)
0.3 W (When
“CTRL.HDMI” is set to
“CTRL OFF” (HT-M3))
Dimensions (width/height/depth) (Approx.)
430 mm × 178 mm ×
336 mm
including projecting parts
and controls
Mass (Approx.) 8.1 kg (HT-M3)
8.0 kg (HT-M2)
The HT-M3 consists of:
• Receiver STR-KM3
• Speaker system
– Front speaker SS-MSP3M (2)
– Center speaker SS-CNP7M (1)
– Surround speaker SS-SRP7M (2)
– Subwoofer SS-WP3M (2)
The HT-M2 consists of:
• Receiver STR-KM2
• Speaker system
– Front speaker SS-MSP2M (2)
– Surround speaker SS-SRP7M (2)
– Subwoofer SS-WP3M (2)
General ACCESSORIES
Ref. No. Part No. Description Remark
1-490-171-11 REMOTE COMMANDER (RM-AAU135)
(including BATTERY LID) (EXCEPT SAF, AR)
1-490-172-11 REMOTE COMMANDER (RM-AAU136)
(including BATTERY LID) (SAF, AR)
1-754-060-21 ANTENNA (FM) (FM wire antenna)
(EXCEPT MX)
1-754-741-11
LOOP ANTENNA (AM loop antenna (aerial))
1-756-988-21
BATTERY, MANGANESE (R6)
1-782-366-21 CORD, CONNECTION
(Audio cord with stereo mini-plug) (AUS)
1-793-184-51 CONNECTOR (F TYPE ADAPTOR)
(FM wire antenna) (MX)
2-655-032-01 CUSHION (FOOT) (8 pieces, 1 set)
(FOR SURROUND) (HT-M2)
2-682-469-01 FOOT (SW) (4 pieces, 1 set)
(FOR SUBWOOFER, FRONT) (HT-M2)
4-415-788-12 INSTRUCTION MANUAL (ENGLISH)
(HT-M2: E51, SAF)
4-415-788-22 INSTRUCTION MANUAL (SPANISH)
(HT-M2: E51, AR)
4-415-789-12 INSTRUCTION MANUAL (ENGLISH)
(HT-M3: E51, SAF, EA, AUS, SP)
4-415-789-22 INSTRUCTION MANUAL (SPANISH)
(HT-M3: E51, AR)
4-415-789-32
INSTRUCTION MANUAL
(FRENCH, ARABIC) (EA)
4-415-789-41 INSTRUCTION MANUAL (THAI) (TH)
4-415-789-52
INSTRUCTION MANUAL (SPANISH) (MX)
4-415-789-71 INSTRUCTION MANUAL
(TRADITIONAL CHINESE) (SP)
sOperating Instructions
sQuick Setup Guide (1)
sFM wire antenna (aerial) (1)
–MX
– Other models
sAM loop antenna (aerial) (1)
sSpeaker cords
– HT-M3 (2, red/white)
sAudio cord with stereo mini-plug
(AUS) (1)
sFoot pads
– Subwoofers (Big) (8) (HT-M3)
– Front speakers and subwoofers (Big) (16) (HT-M2)
– Surround speakers (Small) (8) (HT-M2)
– Speakers (Small) (12) (HT-M3)
sRemote control (1)
– RM-AAU136
(SAF, AR)
– RM-AAU135 (Other models)
sR6 (size AA) batteries (2)
Supplied accessories
