Sony SRX-T105 User manual

SRX-T110
SRX-T105
SXRD 4K Ultra-high Resolution Projectors
sony.com/sxrd
SONY54859_SRX-Series 1SONY54859_SRX-Series 1 11/5/08 11:28:49 AM11/5/08 11:28:49 AM

2
Bringing More Information and Enabling
Greater Immersion
SONY54859_SRX-Series 2SONY54859_SRX-Series 2 11/5/08 11:28:50 AM11/5/08 11:28:50 AM

The SRX-T110 and SRX-T105 Projectors Offer Ultra-high
4K Resolution and 11K/5.5K Lumens Brightness
Responding to the ever-increasing demand for highly sophisticated
visuals, Sony launched a series of SXRD™ ultra-high resolution projectors
- the SRX-R110/SRX-R105 and the SRX-S110/SRX-S105.
Once launched, these projectors rapidly acquired a great reputation
with many customers due to their outstanding picture quality and
stunning performance.
Now, Sony is proud to introduce the next generation of SXRD 4K
projectors: the SRX-T110 and SRX-T105, advanced projectors designed to
meet the evolving needs for ultimate picture quality.
The SRX-T110 and SRX-T105 are equipped with three Silicon X-tal (crystal)
Reflective Display (SXRD) devices and deliver an amazing resolution
of 4096 x 2160 pixels (H x V) - more than four times the resolution of
consumer HDTV (1920 x 1080). This high-resolution capability allows 2K
(2048 x 1080) images to be displayed simultaneously in four quadrants
or in a twin “side by side” display. The projectors also offer a contrast
ratio of 2500:1. In addition, the SRX-T110 provides a high brightness of
11,000 lumens, while the SRX-T105 offers a brightness of 5,500 lumens.
The use of twin Xenon lamps, combined with multiple gamma curves
of 2.2, 2.6, and user-defined values, means they offer pure, high-quality
color tonal reproduction.
Furthermore, the SRX-T110 and SRX-T105 offer very quiet operation,
thanks to an intelligent cooling fan system.
Sony SXRD 4K projectors are the ultimate tool for projecting images in a
range of applications such as command & control, simulation, computer
visualization, planetarium and museum exhibition, and much more.
3
SONY54859_SRX-Series 3SONY54859_SRX-Series 3 11/5/08 11:28:56 AM11/5/08 11:28:56 AM

4
State-of-the-art Technology for High Picture Quality
Silicon X-tal Reflective Display
(SXRD) Device
The SXRD device used by the SRX-T110 and
SRX-T105 is a 1.55-inch* Liquid Crystal on Silicon-
based display device developed by Sony using
cutting-edge manufacturing technology. High-
quality, accurate visuals are created using this
brilliant display device.
* Measured diagonally.
High Resolution 4K
Sony SXRD display devices deliver the
exceptionally high resolution of 4K x 2K (4096 x
2160, 17:9 widescreen format), more than four
times as many pixels as Full HDTV (1920 x 1080,
16:9 wide screen format).
The SXRD device helps to achieve this resolution
by incorporating nearly 8.85 million pixels per
device at a narrow pitch of 8.5 micrometers.
These high-density pixels, which are one quarter
the size of pixels projected using typical 2K x 1K
resolution projection systems (2.2 million pixels),
provide an amazing picture. Even in multi-screen
mode, full 2K resolution per quadrant can be
achieved.
The resolution available from the Sony SRX-T110
and SRX-T105 enables a new level of visual
projection.
High 2500:1 Contrast Ratio
The SRX-T110 and SRX-T105 offer a high contrast
ratio of 2500:1 through the use of Sony’s unique
SXRD device. The SXRD device itself achieves
a contrast ratio of 4000:1. This stunning picture
quality makes the projectors ideal for applications
in which dynamic range is essential. The high
contrast ratio has been achieved through two key
technologies - the exclusive ‘normally black mode’
system and an extremely thin liquid crystal cell
gap.
‘Normally Black Mode’ System
In every type of projector system, displaying
absolute black is a major issue in order to achieve
a high contrast ratio. In other words, the contrast
ratio of a projector depends on how effectively the
light from the source can be blocked, so it does
not leak through the display device.
All Liquid Crystal Display (LCD) devices control the
amount of light to be projected by applying an
electric field to the liquid crystal gap. In typical
LCD devices, black is produced when an electric
field is applied across the liquid crystal cell gap.
However, molecules near the surface of the glass
substrate may not be accurately controlled due
to the influence of the alignment film. This is not
an issue for bright images but, when displaying
dark images, light may tend to leak from the LCD
device, since the molecules near the surface are
less accurately controlled. This results in a creamy
black instead of a deep black.
The SXRD device does not exhibit these
characteristics. This is because the ‘normally black
mode’ system displays black when the electric
field is not applied and, because all molecules
are in the correct alignment, the polarized light
alignment is also optimized. The direct result is a
far deeper black level, leading to a high contrast
ratio.
Full HDTV
(1920 x 1080,
16:9 widescreen format)
2K x 1K
(2048 x 1080,
17:9 widescreen format)
4K x 2K
(4096 x 2160,
17:9 widescreen format)
SONY54859_SRX-Series 4SONY54859_SRX-Series 4 11/5/08 11:28:57 AM11/5/08 11:28:57 AM

5
Thin Liquid Crystal Cell Gap
Another important factor allowing for the high
contrast of the SRX-T110 and SRX-T105 is the
SXRD device’s ultra thin cell gap of less than 2
micrometers. With conventional ‘vertically aligned
liquid crystal’ systems, a thin cell gap could not
be achieved. Sony has overcome this difficulty
through the use of innovative planarization
technology in the silicon backplane structure
and an advanced silicon wafer-based assembly
process.
The SXRD device also adopts a structure that does
not use “spacers”. These are columns found in
conventional reflective liquid crystal devices to
maintain a constant gap between the liquid cell
floor and the top of the device. Spacers tend to
both scatter and reflect light, which can impair
high contrast pictures. In the spacer-less SXRD
device, these artifacts are no longer seen.
Short Response Time
The thin cell gap structure in SXRD devices also
contributes to an ultra-fast response time of 2.5
milliseconds (for both rise and fall). The SXRD
device reacts promptly to an instantaneous
change of picture content, enabling SXRD-based
projectors to display smoothly. Consequently, the
SRX-T110 and SRX-T105 virtually eliminate motion
blur; a particularly significant benefit for visuals
that include fast-moving objects.
Reliable Display Device
The SRX-T110 and SRX-T105 use high-power, bright
lamps. As a result, special attention has been
paid to the reliability of the SXRD device. The
inorganic materials utilized for the alignment layer
of the SXRD device are resistant to deterioration
or deformities that could occur due to the intense
heat and light generated by the powerful twin
lamp system.
High-Density Pixel Pitch 8.5 μm
• 4 x Full-HDTV (4096 H x 2160 V pixels)
Thin Cell Gap (2.0 μm) Spacer-less
• Short response time < 2.5 ms (for both rise and fall)
• High Device Contrast ratio 4000 : 1
Light
Inorganic
Alignment Layer
• High reliability
Liquid Crystal
Glass Substrate
Silicon Backplane
Narrow Inter-Pixel
Spacing (0.35 μm)
• High fill factor
• High reflectivity
Aluminium Pad
SXRD Cross-Section Diagram
SONY54859_SRX-Series 5SONY54859_SRX-Series 5 11/5/08 11:28:58 AM11/5/08 11:28:58 AM

6
Highly Pure, Superb Color Tonal Reproduction
Xenon Lamp Provides Highly Bright
and Pure Light Source
The SRX-T110 provides a high brightness of 11,000
lumens by employing two 2 kW Xenon lamps,
while the SRX-T105 offers a brightness of 5,500
lumens by using two 1 kW Xenon lamps.
The Xenon lamps utilized by the SRX-T110 and
SRX-T105 achieve a wide color range by dispersing
a very flat and wide light spectrum.
Color Space Conversion (CSC)
Function
The SRX-T110 and SRX-T105 feature a CSC function
to help users easily adjust the projector’s color
space to that defined by the ITU*-R BT.709-3
standards for digital HDTV studio color space,
the DCDM (Digital Cinema Distribution Master)
color space, or the Adobe RGB color space**.
The target color gamut parameters satisfying the
ITU-R BT. 709-3 standards, or DCDM or Adobe RGB
specifications are automatically calculated from
settings on the supplied SRX Controller software,
and then applied to the projector.
The internal test generator simplifies adjustment
and lets the operator align the projector in
minutes. White point and color primary points can
be aligned to either of these standards or to the
customer’s application needs.
* International Telecommunication Union
** The Adobe RGB color space is covered by 95%.
12-bit SXRD Panel Driver
The SRX-T110 and SRX-T105 utilize a 12-bit SXRD
panel driver that reproduces extremely natural-
looking images. This eliminates quantizing and
edge errors that take away from the real resolution
that these projectors can achieve.
Gamma Curve Selection
The SRX-T110 and SRX-T105 provide three preset
gamma curve values. Users can select an
optimum value from 2.2, 2.6, or user-defined values
according to the desired gray scale.
Xenon
TV
CIE Chart
SONY54859_SRX-Series 6SONY54859_SRX-Series 6 11/5/08 11:28:58 AM11/5/08 11:28:58 AM

7
Operational Versatility
Dual-lamp System with Selectable
Lamp Modes
The SRX-T110 and SRX-T105 adopt a unique lamp
system that uses two lamps for reliable, flexible,
and efficient use of light sources. With this dual-
lamp system, users can operate the projector
using both lamps for full brightness, or can select
single-lamp operation.
The dual-lamp mode provides maximum lamp
power, and at the same time enables virtually
fail-safe operation; if one bulb burns out, the other
can keep projecting images.
In single-lamp mode, users can select either of
the two lamps manually, or the projector can
automatically select a lamp based on each
lamp’s operating time.
Another automatic mode is provided to make
the lamps operate alternately at user-defined
intervals selectable from four hours to twelve hours
(in increments of one hour). This feature is useful
when lamp life needs to be maximized. The lamp
power can be set between 100% and 51%, in eight
steps. This function, combined with the selectable
lamp modes, contributes to achieving longer
lamp life.
Variety of Lenses
Five optional zoom lenses and a short throw prime
lens are available for the SRX-T110 and SRX-T105.
They are designed to project images of extreme
resolution and contrast with minimal chromatic
aberration. The short throw lens works in special
applications, such as rear projection, where
minimal space behind the screen is desired.
Zoom/Focus Memory Function
The SRX-T110 and SRX-T105 are equipped with
Zoom and Focus Memory functions that make it
easy to switch the projection between two types of
aspect ratios.
When used with the optional LKRL-Z117 and
LKRL-Z122 Zoom Lenses, any seven zoom and
focus positions can be memorized and instantly
recalled via the SRX Controller software. This allows
full screen display regardless of
the aspect ratio. An electronic
vertical alignment feature is
included in the same memory
to compensate for vertical
changes in the image, should
the projector be mounted at a
down angle.
Multiple Screen Capability
The SRX-T110 and SRX-T105 offer a choice of
single-mode, dual-mode, and quad-mode display.
In quad mode, four quadrants of images are
projected.
At maximum resolution, these four quadrants can
project four different 2K (2048 x 1080) images
simultaneously or a single 4K (4096 x 2160) image
made up of four 2K images*.
* For 4K projection, it is necessary to divide an entire image
into four quadrants, and to input the signals of all quadrants
simultaneously.
Single-mode
Dual-mode
Quad-mode
LKRL-Z122 Zoom Lens
A
A
B
D
A
C
B
Simulated images
SONY54859_SRX-Series 7SONY54859_SRX-Series 7 11/5/08 11:28:58 AM11/5/08 11:28:58 AM

8
Input Signal Flexibility
To increase the configuration flexibility of the
SRX-T110 and SRX-T105, slots are available to
accommodate four different optional boards that
connect to various types of signal formats.
The SRX-T110 and SRX-T105 are pre-installed with
an LKRI-005 HDCP DVI Board, which can accept
DVI signals and provides a digital copy protection
capability. In addition to the standard HDCP DVI
input, three slots are available for the installation
of optional boards. This allows simultaneous
accommodation of up to four input/interface
boards in the side panel of the projector. Users
can select from single, dual, and quad screen
modes, and assign the appropriate signal board
to each quadrant.
•The LKRI-001 Analog Input Board utilizes 5 BNC
connectors that can accept 0.7 volt analog
signal levels as RGBS, RGB sync on G, RGBHV, or
YUV formats.
•The LKRI-002 HD-SDI (4:2:2) Input Board can
accept both SMPTE 259M SD digital 525/625
line video and SMPTE 292M 1080 4:2:2 Y .Pb .Pr
serial picture data. Switching is automatic by
detection of the input signal frequency.
•The LKRI-003 Dual-link HD-SDI Input Board can
accept any of the following signals: SMPTE
372M dual-link HD-SDI (4:4:4), SMPTE 292M HD-
SDI (4:2:2), dual-link DC-SDI (RGB 4:4:4), DC-SDI
(YPbPr 4:2:2), or 12-bit (X’Y’Z’ 4:4:4) signals. With
four LKRI-003 boards, the SRX-T110 and SRX-T105
can project 4096 x 2160 4K images.
•The LKRI-005 HDCP DVI Board can accept DVI
signals up to 2048 x 1080P and offers a digital
copy protection capability compliant with the
HDCP specification to 1920 x 1080P and 1280 x
720P signals.
Installation Flexibility
The SRX-T110 and SRX-T105 can be tilted 90
degrees upward or downward. In addition, they
can turn projected images upside down. This
flexibility allows the projectors to be used in several
different ways, including a rear projection system.
To aid effective cooling at 90-degree tilt
installation, an optional LKRA-001 exhaust duct
adaptor is required, which allows the projectors
to be easily connected to a common 8-inch-type
duct system.
Operational Versatility
Signal Chart for the LKRI-005
Signal Resolution fV (Hz) HDCP
1024 x 768P (XGA) 60 No
1280 x 960P (Quad-VGA) 60 No
1280 x 720P 60 Yes
1280 x 720P 50 Yes
1280 x 1024P (SXGA) 60 No
1400 x 1050P (SXGA+) 60 No
1600 x 1200P (UXGA) 60 No
1920 x 1200P (WUXGA) 60 No
1920 x 1080P 60 Yes
1920 x 1080P 50 Yes
1920 x 1080P 24 Yes
2048 x 1080P 60 No
2048 x 1080P 48 No
2048 x 1080P 24 No
LKRI-001
Analog Input Board
LKRI-002
HD-SDI (4:2:2) Input Board
LKRI-003
Dual-link HD-SDI Input Board
LKRI-005
HDCP DVI Board
Option slots
SONY54859_SRX-Series 8SONY54859_SRX-Series 8 11/5/08 11:29:00 AM11/5/08 11:29:00 AM

9
Quiet Operation by the Intelligent
Cooling Fan System
The SRX-T110 and SRX-T105 adopt an intelligent
cooling system that automatically controls
multiple cooling fans incorporated in the unit. This
system automatically adjusts the rotating speed of
the fans according to the heat generated inside
the unit, which varies depending on the brightness
level of the lamps. In addition, when single-lamp
mode is selected, this system automatically stops
operation of the fans for the unused lamp.
Simple Remote Controller Unit
The SRX-T110 and SRX-T105 are supplied with a
remote controller unit that can perform various
simple functions such as turning the lamp power
on/off, adjusting the zoom/focus, and controlling
the lens shift.
Easy Setup on a PC Using Supplied
Software
The SRX-T110 and SRX-T105 come equipped with
the SRX Controller software that allows easy setup
and adjustments via its intuitive GUIs on a PC*.
These projectors can be controlled through either
Ethernet or RS-232C interfaces, and up to four
projectors can be controlled on the same GUI
from a single PC**.
A comprehensive range of setup parameters
including input configurations, colorimetry controls,
installation adjustments and maintenance settings
can be controlled via this software. These setup
parameters can be saved to a PC as a data
file and reused for another SRX-T110 or SRX-T105
projector.
* System requirements for the setup software OS : Microsoft
Windows XP Professional SP2.
** When using an Ethernet connection.
Easy Maintenance
Special consideration was given to maintenance
issues when developing the SRX-T110 and
SRX-T105. The supplied setup software is a
convenient tool for maintenance that allows
operators to easily verify each lamp’s operating
time. Automatic email alerts from the projector
provide operators with maintenance reminders as
well as error messages.
Colorimety Setting
Mail Report Setting
Installation Setting
Ethernet
SRX-T110/T105 SRX-T110/T105 SRX-T110/T105
Note PC
RS-232C
SRX-T110/T105Note PC
SONY54859_SRX-Series 9SONY54859_SRX-Series 9 11/5/08 11:29:02 AM11/5/08 11:29:02 AM

10
Dimensions
Optional Accessories
LKRL-90
Fixed Focus Lens
Throw ratio*: 0.9:1
LKRL-Z115
Short Focus Zoom Lens
Throw ratio: 1.48:1 to 1.81:1
LKRL-Z117
Middle Focus Zoom Lens
Throw ratio: 1.72:1 to 2.39:1
LKRL-Z119
Middle Focus Zoom Lens
Throw ratio: 1.81:1 to 2.94:1
LKRL-Z122
Middle Focus Zoom Lens
Throw ratio: 2.23:1 to 4.03:1
LKRL-Z140
Long Focus Zoom Lens
Throw ratio: 3.81:1 to 7.12:1
LKRI-001
Analog Input Board
LKRI-002
HD-SDI (4:2:2) Input Board
LKRI-003
Dual-link HD-SDI Input Board
LKRI-005
HDCP DVI Board
LKRX-110
2kW Xenon Lamp Bulb
(for SRX-T110)
LKRX-B110
2kW Xenon Lamp House Unit
(for SRX-T110)
LKRX-105
1kW Xenon Lamp Bulb
(for SRX-T105)
LKRX-B105
1kW Xenon Lamp House Unit
(for SRX-T105)
* The throw ratio denotes the ratio that the projection distance is divided by the screen width.
52 1/4 (1326)
44 (1116) 14 1/8 (357)
27 5/8 (699) 15 5/8 (395)
6 1/2 (164)
29 1/4 (740) 21 3/4 (552)
12 5/8 (320)
19 5/8 (498)
Unit : inches (mm)
LKRA-001
8-inch Exhaust Duct Adaptor
SONY54859_SRX-Series 10SONY54859_SRX-Series 10 11/5/08 11:29:03 AM11/5/08 11:29:03 AM

11
Table of Available Lenses
(all measurements are in inches)
Preset Data of Input Signals
Fixed Focus Lens
LKRL-90
Zoom Ratio -
Throw ratio* 0.9:1
F-number 2.8
70 7/8 61
88 5/8 77 1/8
131 7/8 116 7/8
177 1/5 158 1/4
220 1/2 198
267 3/4 241 3/8
Throwing Distance
Screen width
Short Focus Zoom Lens Middle Focus Zoom Lens Middle Focus Zoom Lens Middle Focus Zoom Lens Long Focus Zoom Lens
LKRL-Z115 LKRL-Z117 LKRL-Z119 LKRL-Z122 LKRL-Z140
Zoom Ratio 1.2x 1.4x 1.6x 1.8x 1.9x
Throw ratio* 1.48:1 to 1.81:1 1.72:1 to 2.39:1 1.81:1 to 2.94:1 2.23:1 to 4.03:1 3.81:1 to 7.12:1
F-number 2.8 2.8 2.8 2.8 2.8
Wide Tele Wide Tele Wide Tele Wide Tele Wide Tele
177 1/5 258 317 1/6 310 7/8 418 5/8 320 526 1/5 402 1/4 700 666 4/5 1,257 3/5
236 2/9 345 3/5 424 2/5 411 555 423 698 2/5 532 3/8 929 7/8 885 8/9 1,673 2/3
315 462 1/3 567 2/5 544 3/8 737 560 1/3 928 706 1,236 1/4 1,178 2,228 1/2
393 5/7 579 710 2/5 677 7/8 918 7/8 697 2/3 1,157 5/8 879 1/2 1,542 3/4 1,470 1/7 2,783 2/7
472 4/9 695 5/6 853 2/5 811 3/8 1,100 3/4 835 1,387 1/4 1,053 1/8 1,849 1/8 – –
630 929 1/3 1,139 3/8 1,078 3/8 1,464 5/8 1,109 3/4 1,846 1/2 1,400 1/4 2,462 – –
* Distance between the center of the projector lens and the screen, divided by the screen width
Throwing Distance
Screen width
Preset Signal fH (kHz) fV (Hz) Aspect Ratio
VIDEO 60 VIDEO 60 15.73 59.94 4:3
VIDEO 50 VIDEO 50 15.63 50.00 4:3
HDTV 1080/60i 1080/60i 33.75 60.00 16:9
1024 x 768 VESA 60 48.36 60.00 4:3
1024 x 768 VESA 70 56.48 70.07 4:3
1024 x 768 VESA 75 60.02 75.03 4:3
1024 x 768 VESA 85 68.68 85.00 4:3
1280 x 960 VESA 60 60.00 60.00 4:3
1280 x 1024 VESA 60 63.97 60.01 5:4
1280 x 1024 VESA 75 79.98 75.03 5:4
1280 x 1024 VESA 85 91.15 85.02 5:4
1600 x 1200 VESA 60 75.00 60.00 4:3
720/60p 720/60p 45.00 60.00 16:9
720/50p 720/50p 37.50 50.00 16:9
1080/48i (24psf) 1080/48i (24psf) 27.00 48.00 16:9
1080/50i 1080/50i 28.13 50.00 16:9
1080/24p 1080/24p 27.00 24.00 16:9
DC2048 x 1080 DC2048 x 1080/48i 27.00 48.00 17:9
DC2048 x 1080 DC2048 x 1080/24p 27.00 24.00 17:9
1400 x 1050 1400 x 1050/60p 65.30 60.00 4:3
1920 x 1080 1920 x 1080/60p 67.50 60.00 16:9
1920 x 1200 1920 x 1200/60p 74.038 60.00 16:10
2048 x 1080 2048 x 1080/48p 54.00 48.00 17:9
2048 x 1080 2048 x 1080/60p 67.50 60.00 17:9
Preset Signal fH (kHz) fV (Hz) Aspect Ratio
VIDEO 60 VIDEO 60 15.73 59.94 4:3
VIDEO 50 VIDEO 50 15.63 50.00 4:3
HDTV 1080/60i 1080/60i 33.75 60.00 16:9
1024 x 768 VESA 60 48.36 60.00 4:3
1024 x 768 VESA 70 56.48 70.07 4:3
1024 x 768 VESA 75 60.02 75.03 4:3
1024 x 768 VESA 85 68.68 85.00 4:3
1280 x 960 VESA 60 60.00 60.00 4:3
1280 x 1024 VESA 60 63.97 60.01 5:4
1280 x 1024 VESA 75 79.98 75.03 5:4
1280 x 1024 VESA 85 91.15 85.02 5:4
1600 x 1200 VESA 60 75.00 60.00 4:3
720/60p 720/60p 45.00 60.00 16:9
720/50p 720/50p 37.50 50.00 16:9
1080/48i (24psf) 1080/48i (24psf) 27.00 48.00 16:9
1080/50i 1080/50i 28.13 50.00 16:9
1080/24p 1080/24p 27.00 24.00 16:9
DC2048 x 1080 DC2048 x 1080/48i 27.00 48.00 17:9
DC2048 x 1080 DC2048 x 1080/24p 27.00 24.00 17:9
1400 x 1050 1400 x 1050/60p 65.30 60.00 4:3
1920 x 1080 1920 x 1080/60p 67.50 60.00 16:9
1920 x 1200 1920 x 1200/60p 74.038 60.00 16:10
2048 x 1080 2048 x 1080/48p 54.00 48.00 17:9
2048 x 1080 2048 x 1080/60p 67.50 60.00 17:9
SONY54859_SRX-Series 11 11/5/08 11:12:47 AM
SONY54859_SRX-Series 11SONY54859_SRX-Series 11 11/5/08 11:29:06 AM11/5/08 11:29:06 AM

Specifications
SXRD Device Main Specifications
Display device SXRD (Silicon X-tal Reflective Display)
Size 1.55-inch across Diagonal
Resolution 4128 (H) X 2176 (V) pixels
Reflectivity 72 %
Contrast (as device) 4000 : 1
Pixel pitch 8.5 μm
Width (between pixels) 0.35 μm
Response speed 2.5 ms (for both rise and fall)
Liquid crystal mode Normally Black Mode
Alignment layer Inorganic Thin Film
Backplane process 0.35 μm MOS Process
Liquid crystal cell gap Less than 2 μm
SRX-T110 SRX-T105
Optical
Projection system 3-SXRD panel, 1 lens projection system
Imaging device SXRD, 1.55-inch (diagonal), 4096(H) x 2160(V) pixels on each chip
(8,847,360 pixels)
Lamp
2 kW Xenon lamp x 2 (not supplied) 1 kW Xenon lamp x 2 (not supplied)
Light output 11,000 lumens 5,500 lumens
General
White reference Xenon white reference
X Y
White reference 0.3140 0.3510
Contrast 2500:1
Resolution 600 TV lines (SDI input/SMPTE-259M)
1920 x 1080 pixels (HD-SDI input, SMPTE-292M)
2048 x 1080 pixels (with LKRI-003 or LKRI-005)
3840 x 2160 pixels (with LKRI-003 x 4 or LKRI-005 x 4)
4096 x 2160 pixels (with LKRI-003 x 4 or LKRI-005 x 4)
Signal specifications Video: Component (Y • Cb • Cr), HD (G • B • R/Y • Pb • Pr)
Computer: XGA, SXGA, UXGA
DVI-D: XGA, Quad-VGA, 1280 x 720, SXGA, SXGA+, UXGA, WUXGA,
1920 x 1080, 2048 x 1080
Power requirements AC 200 to 240 V, 50/60 Hz AC 100 to 240 V, 50/60 Hz
Operating temperature +41 °F to +95 °F (+5 °C to +35 °C)
Storage temperature -4 °F to +140 °F (-20 °C to +60 °C)
Operating humidity 35 % to 85 % (no condensation)
Storage humidity 10 % to 90 %
Dimensions (W x H x D) 29 1/4 x 19 5/8 x 52 1/4 inches (740 x 498 x 1326 mm)
Weight Approx. 265 lb (120 kg) (excluding the optional lamps and lens)
Input/Output
Input A LKRI-005 pre-installed (removable)
Input B Open for optional signal interface board
Input C Open for optional signal interface board
Input D Open for optional signal interface board
Remote interface RS-232C : D-sub 9-pin (female) x 1
10BASE-T/100BASE-TX Ethernet : RJ45 x 1
Input Boards
LKRI-001 BNC x 5, HD/SD analog video input, RGB/Y • Cb • Cr selectable
Analog input board
Computer signals
R 0.7 Vp-p ±2 dB positive, 75 Ω
G 0.7 Vp-p ±2 dB positive, 75 Ω
B 0.7 Vp-p ±2 dB positive, 75 Ω
Sync
HD Horizontal TTL level, high impedance, sync positive/negative
HD Vertical TTL level, high impedance, sync positive/negative
Standard definition video [Y • Cb • Cr]
Y 1.0 Vp-p ±2 dB sync negative, 75 Ω
Cb 0.7 Vp-p ±2 dB positive, 75 Ω
Cr 0.7 Vp-p ±2 dB positive, 75 Ω
High definition video [RGB]
R 0.7 Vp-p ±2 dB positive, 75 Ω
G with sync 1.0 Vp-p ±2 dB, 75 Ω,Tri-level sync: ±0.3 Vp-p /
Bi-level sync: 0.3 Vp-p
B 0.7 Vp-p ±2 dB positive, 75 Ω
High definition video [Y • Pb • Pr]
Y 1.0 Vp-p ±2 dB, 75 Ω,Tri-level sync: ±0.3 Vp-p /
Bi-level sync: 0.3 Vp-p
Pb ±0.35 Vp-p ±2 dB, positive 75 Ω
Pr ±0.35 Vp-p ±2 dB, positive 75 Ω
LKRI-002 BNC x 2 (Input x 1,Loop-through out x 1)
HD-SDI (4:2:2) input board HD-SDI (SMPTE-292M / ITU-R.BT709 / BTA-S004)
SDI (SMPTE-259M / ITU-R.BT601)
LKRI-003 BNC x 4 (Input x 2,Loop-through out x 2)
Dual-link HD-SDI input board HD-SDI (Single-link, HD-SDI/4:2:2,SMPTE-292M):Y • Pb • Pr,
DC-SDI (Single-link, DC-SDI/4:2:2):Y • Pb • Pr,
Dual-link HD-SDI (Dual-link HD-SDI/4:4:4,SMPTE-372M):RGB,
Dual-link DC-SDI (Dual-link DC-SDI/4:4:4):RGB
LKRI-005 XGA, Quad-VGA, 1280 x 720 ,SXGA, SXGA+, UXGA,WUXGA,
DVI Board with HDCP 1920 x 1080, 2048 x 1080
Others
Safety regulations [UL60950 listed], [cUL60950], [FCC Class A], [IC Class A], [VCCI Class A],
[EN60950],[CE Class A], [C-tick], [GB4943], [GB9254], [K60950],
[CISPR22], [CISPR24]
Supplied accessories Remote Commander (1), Size AA (R6) batteries (2), SRX Controller (1),
Ethernet cable (1), M8 screws for lens mounting (4),
Operating Instructions (for SRX-T110/T105) (1),
Operating Instructions (for LKRI-005) (1), Installation Manual (1)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/sxrd
DI-0168 (MK10506V1)
© 2008 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony and SXRD are trademarks of Sony.
All other trademarks are the property of their respective owners.
Printed in USA (10/08)
SONY54859_SRX-Series 12SONY54859_SRX-Series 12 11/5/08 11:29:08 AM11/5/08 11:29:08 AM
