Sony Projectors.
Presenting Performance Excellence.
SONY®PROJECTORS
Sony projectors are designed with the professional in mind. From high brightness and contrast performance
and flexible multi-input and networking capabilities to fast, automatic set-up, there’s a Sony projector for
virtually every venue, budget and need.
Portable, high quality projectors that offer
the remarkable combination of press-and-play
performance and simple operation.
Sony projectors with superb brightness and
fashionable design for professional presentations.
• Up to 3500 ANSI lumens brightness
• XGA native resolution (1024 x 768)
• Accepts Composite, Component and PC Inputs
• 10 Base-T/100 Base-TX ethernet for LAN connection
• Back-2-front 90 degree tilt capabilities
• SNMP compliant (Simple Network Mgmt. Protocol)
High impact multimedia presentations supported by
Sony’s highest contrast ratios and brightness output
for all lighting conditions.
• Up to 2000 ANSI lumens brightness
• XGA native resolution (1024 x 768)
• Accepts Composite, Component and PC Inputs
• 10 Base-T/100 Base-TX ethernet for LAN connection
• PC Card Slot for Wireless Peer to Peer
• SNMP compliant (Simple Network Mgmt. Protocol)
• Built-in Microsoft®Windows®CE and Web browser
• Up to 2000 ANSI lumens brightness
• Up to XGA native resolution (1024 x 768)
• Automatic set-up (lens, input, tilt, pixel and keystone)
• Accepts Composite, Component and PC Inputs
• Ultra portable and stylish design
• Short focal length zoom lens
SUPERLITE
®
SERIES
SUPERBRIGHT
™
SERIES
SUPERSMART
™
SERIES
If you are a corporate, government or education client,
please visit us at sony.com/projectors for more information.

SUPERLITE
®
SERIES SUPERBRIGHT
™
SERIES SUPERSMART
™
SERIES
Model Number VPL-DS100 VPL-EX1 VPL-CS6 VPL-CX6 VPL-PX35 VPL-PX40 VPL-PX15
ANSI Lumens 1200 1500 1800 2000 2600 3500 2000
Projection System
LCD Panel Type
Projection Lens 1.2 times zoom lens 1.2 times zoom lens 1.2 times zoom lens 1.2 times zoom lens 1.3 times zoom lens 1.3 times zoom lens 1.3 times manual zoom lens
Lamp Type 157W UHP lamp 165W UHP lamp 165W UHP lamp 165W UHP lamp 265W UHP lamp 265W UHP lamp 200W lamp
Screen Size Coverage (diagonally) 40 to 150 inches 40 to 150 inches 40 to 150 inches 40 to 150 inches 40 to 300 inches 40 to 300 inches 40 to 300 inches
Video Resolution 600 lines 750 lines 600 lines 750 lines 750 lines 750 lines 750 lines
PC Native Resolution 800 x 600 1024 x 768 800 x 600 1024 x 768 1024 x 768 1024 x 768 1024 x 768
Audio 1 watt (mono) 1 watt (mono) 1 watt (mono) 1 watt (mono) Stereo Speakers Max. 2W x 2 Stereo Speakers Max. 2W x 2 Stereo Speakers Max. .5W x 2
USB N/A Up (B type female) Up (B type female) Up (B type female) Up (B type female) Up (B type female)
Video Inputs
Input Acceptable Up to XGA resolution, Up to SXGA resolution, Up to SXGA resolution, Up to SXGA resolution, Up to UXGA resolution, Up to UXGA resolution, Up to SXGA resolution,
Composite, Component, HDTV Composite, Component Composite, Component Composite, Component Composite, Component, HDTV Composite, Component, HDTV Composite, Component
PC Inputs HD15 HD15 HD15 HD15 DVI-D, HD15 DVI-D, HD15 HD15
Audio Inputs Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
Video/Audio Out N/A N/A N/A N/A HD15/Stereo Mini Jack HD15/Stereo Mini Jack HD15/Stereo Mini Jack
Monitor Out Yes No No No No No No
Memory Stick®Media N/A N/A N/A Memory Stick PRO™Media N/A N/A N/A
PC Card Slot N/A N/A N/A N/A N/A N/A PC Card Slot Type II
Ethernet Network Connection N/A N/A N/A N/A RJ-45: 10 Base-T/100 Base-TX RJ-45: 10 Base-T/100 Base-TX RJ-45: 10 Base-T/100 Base-TX
Automatic Setup Yes Yes Yes Yes N/A N/A N/A
Tilt Adjust Powered Powered Powered Powered Yes Yes Yes
Auto Sensing Input Yes Yes Yes Yes Yes Yes Yes
Auto Keystone Adjustment Yes Yes Yes Yes Manual Manual Manual
Auto Pixel Adjustment Yes Yes Yes Yes Yes Yes Yes
PJ Net!™Software No No No No Optional Optional Optional
Kensington Security Lock Yes Yes Yes Yes Yes Yes Yes
Power Management: Max. Watts 250W 240W 240W 240W 365W 365W 300W
Power Management: Standby 5W 5W 5W 7W 6W 6W 4.2W
Dimensions (W x H x D) 11.6" x 3.1" x 9.4" 11.3" x 2.8" x 9.0" 11.3" x 2.8" x 9.0" 11.3" x 2.8" x 9.0" 16.6" x 4.6" x 12.5" 16.6" x 4.6" x 12.5" 12.9" x 4.4" x 11.3"
Weight Approx. 6 lbs., 3 oz. Approx. 5 lbs., 15 oz. Approx. 5 lbs., 15 oz. Approx. 5 lbs., 15 oz. Approx. 16 lbs.,10 oz. Approx. 16 lbs., 10 oz. Approx. 11 lbs., 11 oz.
Safety Regulations
Supplied Accessories
Additional Accessories Available
Limited Warranty 2 years parts and labor 2 years parts and labor 2 years parts and labor 2 years parts and labor 2 years parts and labor 2 years parts and labor 2 years parts and labor
Extended Warranty Optional 1 year extension Optional 1 year extension Optional 1 year extension Optional 1 year extension Optional 1 year extension Optional 1 year extension Optional 1 year extension
© 2003 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. Features and specifications are subject to change without notice. All non-metric weights and measures are approximate. Sony, SuperLite, SuperBright, SuperSmart, Remote Commander, Memory
Stick, Memory Stick PRO and Projector Station are trademarks of Sony. Microsoft, the Windows logo and Windows are registered trademarks of Microsoft Corporation. The Mac logo is a registered trademark of Apple, Inc. All other trademarks are the properties of their respective owners. These monitors are
Energy Star Compliant when used with a computer equipped with VESA Display Power Management Signaling (DPMS). As an International Energy Star Partner, Sony has determined that these products merit the International Energy Star Program for energy efficiency. The Energy Star emblem does not represent
EPA endorsement of any product or service. D308
professional. portable. powerful.
3 LCD panels,
1 lens projection system 3 LCD panels,
1 lens projection system 3 LCD panels, 1 lens projection system 3 LCD panels, 1 lens projection system 3 LCD panels, 1 lens projection system 3 LCD panels, 1 lens projection system 3 LCD panels,
1 lens projection system
0.7-inch p-Si TFT LCD panel,
1,440,000 pixels
(480,000 pixels x 3)
0.7-inch p-Si TFT LCD panel with
Micro Lens Array, 2,359,296 pixels
(786,432 pixels x 3)
0.7-inch p-Si TFT LCD panel,
1,440,000 pixels
(480,000 pixels x 3)
0.7-inch p-Si TFT LCD panel with
Micro Lens Array, 2,359,296 pixels
(786,432 pixels x 3)
0.99-inch p-Si TFT Sony LCD
panel 2,359,296 pixels
(786,432 pixels x 3)
0.99-inch p-Si TFT Sony LCD panel
with Micro Lens Array 2,359,296
pixels (786,432 pixels x 3)
0.9-inch p-Si TFT LCD panel with
Micro Lens Array 2,359,296 pixels
(786,432 pixels x 3)
UP (B type female) x 1,
Down (A type female) x 1
Remote Commander®Unit, Signal
Cable SMF-410: HD D-sub 15-pin
to D-sub 15-pin, USB Cable:
A type to B type, Projector Station™
USB Application Software
(CD-ROM), AA size Battery (2)
Air Filter (for replacement),
AC Power Cord, Operation Manual,
Operation Manual for Networking,
Installation Manual for Dealers,
Specified/recommended
PC Card/Wireless LAN Access
Point List, Quick Guide
Remote Commander®Unit,
Monitor Cable (2 m):
HD D-sub 15-pin to HD
D-sub 15-pin, USB Cable
A type to B type (2 m),
AA size Battery (2),
Lens Cap, Air Filter,
Operating Manual,
Installation Manual
for Dealers
Remote Commander®Unit,
Monitor Cable (2 m):
HD D-sub 15-pin to HD
D-sub 15-pin, USB Cable
A type to B type (2 m),
AA size Battery (2),
Lens Cap, Air Filter,
Operating Manual,
Installation Manual
for Dealers
Remote Commander®Unit,
Monitor Cable, Soft Case,
Lithium Battery CR2025 (1),
Air Filter, AC Power Cord,
Operation Manual,
Quick Reference Sheet,
Security Label
Remote Commander®Unit,
Monitor Cable, USB Cable:
A type to B type, Soft Case,
AA size Battery (2),
Air Filter, AC Power Cord,
Operation Manual,
Quick Reference Sheet,
Security Label
Remote Commander®
(RMPJ2) Unit, Monitor Cable,
A type to B type, Soft Case,
AA size Battery (2),
Air Filter, AC Power Cord,
Operation Manual,
Quick Reference Sheet,
CD-ROM (Application Software),
Security Label
Lamp (LMP-C150),
Hand Carry Case (VLC-U20TH),
Ceiling Mount (PSSEC1US)
Lamp (LMP-C150),
Hand Carry Case (VLC-U20TH),
Ceiling Mount (PSSEC1US),
Ceiling Mount (PSS/C5)
Lamp (LMP-C150),
Hand Carry Case (VLC-U20TH),
Ceiling Mount (PSSEC1US),
Ceiling Mount (PSS/C5)
Lamp (LMP-C150),
Hand Carry Case (VLC-U20TH),
Ceiling Mount (PSSEC1US)
Lamp (LMP-P260),
Suspension Pole (PSS-610),
Lens (VPLL-FM22),
Lens (VPL-ZM102)
Lamp (LMP-P260),
Suspension Pole (PSS-610),
Lens (VPLL-FM22),
Lens (VPL-ZM102)
Lamp (LMP-P202), Short Throw
Converter (VPLL-CW10), Long Throw
Converter (VPLL-CT10), Carry Case
(VLC-P15ATACZ), Carry Case
(VLC-SP15CZ), Suspension Pole
(PSS10), Ceiling Mount (PSS-610)
Remote Commander®
(RMPJ2) Unit, Monitor Cable,
USB Cable: A type to B type,
Soft Case, AA size Battery (2),
Air Filter, AC Power Cord,
Operation Manual,
Quick Reference Sheet,
CD-ROM (Application Software),
Security Label
UL, cUL, FCC Class B,
IC Class B, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC
UL, cUL, FCC Class B,
IC Class B, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC
UL, cUL, FCC Class B,
IC Class B, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC
UL, cUL, FCC Class B,
IC Class B, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC
UL, cUL, DHHS, DNHW,
DENAN, FCC Class A, NEMKO,
CE (LVD, EMC), C-Tick,
VCCI, JEITA
UL, cUL, DHHS, FCC Class A,
IC Class A, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC,
VCCI Class B, JEITA
UL, cUL, DHHS, FCC Class A,
IC Class A, NEMKO, CE (LVD),
CE (EMC), C-Tick, CCC,
VCCI Class B, JEITA
Component (BNC),
Composite (BNC), S-Video
Component (HD15),
Composite (RCA), S-Video Component (HD15), Composite (RCA), S-Video Component (HD15), Composite (RCA), S-Video Component (HD15), Composite (RCA), S-Video Component (BNC),
Composite (BNC), S-Video Component (BNC),
Composite (BNC), S-Video
