Sony ICF-J1 User manual

SERVICE MANUAL
Ver 1.0 2000. 12
FM/SW/MW 3 BAND RADIO
E Model
ICF-J1
SPECIFICATIONS
Frequency range:
FM: 87.5 – 108 MHz
SW: 4.75 – 18.0 MHz
MW: 530 – 1 605 kHz
Speaker
Approx. 9.2 cm (3 5/8 i ches) dia., 8 Ω
Output
v jack (ø 3.5 mm mi ijack)
Power output
350 mW (at 10 % harmo ic distortio )
Power requirements
3 V DC, two R20 (size D) batteries
Dimensions
Approx. 233 × 119.2 × 56 mm (w/h/d)
(9 1/4 × 4 3/4 × 2 1/4 i .) i cl. projecti g parts
a d co trols
Mass
Approx. 815 g (29 oz) i cl. batteries
Supplied accessories
(Middle Eastern model only)
Case (1)
Ha d strap (1)
Desig a d specificatio s are subject to cha ge
without otice.
Battery life (approx. hours)
When using FM SW/MW
So y alkali e 240 250
LR20 (size D) batteries
So y 120 130
R20 (size D) batteries
Features
• High power sou d
• Lo g battery life with two R20 (size D)
batteries
• High se sitivity
• Easy tu i g with the tu i g i dicator

– 2 –
TABLE OF CONTENTS
1. GENERAL ................................................................... 2
2. DISASSEMBLY ......................................................... 3
3. ASSEMBLY................................................................. 7
4. ELECTRICAL ADJUSTMENTS......................... 9
5. DIAGRAMS
5-1. Block Diagram ................................................................ 11
5-2. Printed Wiring Board ...................................................... 13
5-3. Schematic Diagram ......................................................... 15
6. EXPLODED VIEWS................................................ 17
7. ELECTRICAL PARTS LIST ............................... 19
SECTION 1
GENERAL
This section is extracted from
instruction manual.
Insert the #side of the battery first.
Inserte en primer lugar la parte #de la pila.
R 20 (size D) ×2
pila R20 (tamaño D) ×2
Pass the strap through the buckle.
Pase la correa a través de la hebilla.
Telescopic antenna
Antena telescópica
indicator
indicador
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
CF
3
CF1
mark
Mark Center frequency
red 10.70 MHz
blue 10.67 MHz
orange 10.73 MHz
black 10.64 MHz
white 10.76 MHz
HOWTO CHANGETHE CERAMIC FILTERS
This model is used two ceramic filters of CF1 and CF3.
You must used same type of color marked ceramic filters in order
to meet same specifications.
Therefore, the ceramic filter must changed two pieces together
since it's supply two pieces in one package as a spare parts.

– 3 –
SECTION 2
DISASSEMBLY
• This set can be disassemble in the order shown below.
Note: Follow the disassembly procedure in the numerical order given.
LID, BATTERY CASE
Set Lid, Battery Case
“Knob (Tuning)”, “Knob (Volume)”
Chassis Section Main Board Chassis
Antenna, Ferrite-Red (MW) (L1)
Speaker (9.2 cm) (SP1)
“Antenna, Telescopic (FM/SW) (ANT1)”, “Cabinet (Rear)”
1 Open the battery case lid.
2 boss
2 boss
3 lid, battery cas
e
2 tuning, spring
knob (volume)
hole
variable resistor (RV1)
Note: Insert the knob (volume) into
the variable resistor (RV1),
meeting both shapes of the hole
in the knob and the shaft of RV1 as shown.
3 knob (tuning
)
1
4
6 knob (volume)
5 O ring, P-9
“KNOB (TUNING)”, “KNOB (VOLUME)”

– 4 –
“ANTENNA, TELESCOPIC (FM/SW) (ANT1)”, “CABINET (REAR)”
CHASSIS SECTION
antenna, wire
Note: Arrange the antenna,
wire to the 4 slots.
2 claw
5 lug, 3
2 claw
3
4
screw
(P2.6
× 8)
1 five screws
(BTP3
× 12)
7 cabinet (rear)
6 antenna, telescopic
(FM/SW) (ANT1)
2 terminal (+),
battery
3 terminal (–),
battery
4 chassis section
1 Remove two solders
of speaker lead wires.
MAIN Board
speaker lead wire (RED)
battery terminal (–)
lead wire (WHT)
SP
3
SP #
GND
+ B
battery terminal (+)
lead wire (WHT/RED)
speaker lead wire
(WHT)
• LEAD WIRE COLOR INDICATION
ON MAIN BOARD.
terminal (–),
battery terminal (+),
battery
Note: When mounting the battery terminals (+) and (–), engage the lead wires
to the hook on the cabinet (front) and route them as shown.
hook
cabinet (front)

– 5 –
Note: For the mounting position
of the antenna, ferrite-rod (MW) (L1),
refer to the “ANTENNA,
FERRITE-ROD (MW) (L1)”
in DISASSEMBLY.
7 claw
slider
7 claw
8 MAIN board
Note: On installation MAIN board
adjust the S1, S2 and
slider, knob (POWER).
5 gear (tuning capacitor)
Including “spring (gear)”,
“gear (B), tuning capacitor”.
Note: When the gear (tuning
capacity), spring (gear),
and the turning capacitor
gear(B) were removed
and then, they are mounted
on the main board,
refer to the “GEAR
(TUNING CAPACITOR)”,
“SPRING (GEAR)”, “GEAR
(B), TUNING CAPACITOR”in
ASSEMBLY on page 8.
6 Remove LED LN21RPL (TUNE)
(D2) by raising in the arrow direction,
not giving an excessive force.
knob
(POWER)
S2
S1
2 screw
(BTP3
× 12)
2 screw
(BTP3
× 12)
1 Remove three solders
of ferrite-rod (MW)
antenna (L1) leads.
4 screw
(B2.6
× 5)
3 holder (gear)
()
MAIN BOARD
ANTENNA, FERRITE-ROD (MW) (L1)
2 Remove five portions bond
SC-12N.
Note: When mounting the antenna,
ferrite-rod (MW) (L1), route the lead wires
as shown and apply the bond SC-12N
to the removed portion.
4 antenna, ferrite-rod
(MW) (L1)
3 four claws
1 Remove three solders of
ferrite-rod (MW) antenna (L1)
lead wires.
• FERRITE-ROD ANTENNA LEAD WIRE
COLOR INDICATION ON MAIN BOARD.
black lead wire
natural lead wire
red lead wire
MAIN board
BLK
NATURAL
RED

– 6 –
SPEAKER (9.2 cm) (SP1)
2 claw
3 Remove speaker (SP1) in the
direction of arrow
A .
speaker lead wire (RED)
speaker lead wire
(WHT)
cabinet (front) claw
speaker (9.2 cm)
(SP1)
A
3
#
1 Remove shaded portion bond SC-108.
Note: When installing the speaker (SP1),
set it in the position as shown, and apply
the bond SC-108 to the removed portion.
CHASSIS
9 two claws
0 pointer
qa plate, back
qs rack
qd chassis
3 slider
Note: When assembling the chassis,
refer to the “DIAL POINTER SETTING”
in ASSEMBLY.
2 two claws
2 two claws
7 two claws
8 shaft, tuning
5 knob (power)
4
4
1
knob (band)
6 gear, midwa
y

– 7 –
SECTION 3
ASSEMBLY
Note: Follow the assembly procedure in the numerical order given.
DIAL POINTER SETTING
•RACK
• MAIN BOARD
4 pointer
3 Mount the back plate,
meeting with two bosses of
the chassis.
1 rack
6 gear, midway
5 shaft, tuning
boss chassis
boss
2 Meet the portion of
the rack with the mark
of the chassis.
chassis
mark
a
a
b
b
rack
2 claw
3 LED LN21RPL (TUNE) (D2)
4 screw
(BTP3
× 12
)
1 MAIN board
2 claw

– 8 –
• “GEAR (TUNING CAPACITOR)”, “SPRING (GEAR)” AND “GEAR (B), TUNING CAPACITOR”
“GEAR (TUNING CAPACITOR)”, “SPRING (GEAR)” AND “GEAR (B), TUNING CAPACITOR” SETTING
gear, midway
1 Turn variable condenser (CV1)
shaft fully to the arrow direction
(ant1-clok wise). Note: Make sure that two tuning capacitor gears
are meshing with the midway gear.
gear, midway
triangle mark
triangle mark
3 screw (B2.6 × 5)
Note: Secure screw.
5 screw (BTP3 × 12)
4 holder (gear)
2 gear (tuning capacitor)
Including “spring (gear)”,
“gear (B), tuning capacitor”.
Note: Adjust so that the triangle
marked is at the position
shown and install.
()
gear (tuning capacitor)
1 Insert the spring (gear)
into a hole in the gear
(tuning capacitor).
2 Fit the tuning capacitor gear (B)
to the gear (tuning capacitor),
and then turn the tuning capacitor gear (B)
in the A direction.
A
3 Engage the spring (gear)
to the hook of the tuning
capacitor gear (B) as shown.
hook
spring (gear)

– 9 –
AM IF ADJUSTMENT
Adjust for a maximum reading on level meter
T1 455 kHz
MW FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter
L5 516.5 kHz
CT1-4 1,631.5 kHz
MW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L1 600 kHz
CT1-1 1,400 kHz
SW FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter
L6 4.7 MHz
CT6 18.5 MHz
SW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L2 4.75 MHz
CT5 18 MHz
FM FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter
L4 87.35 MHz
CT1-3 108.25 MHz
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L3 87.5 MHz
CT1-2 108 MHz
Adjustment Location: MAIN board (See page 10)
SECTION 4
ELECTRICAL ADJUSTMENTS
0 dB=1 µV
[MW]
Setting:
Band switch: MW
[SW]
Setting:
Band switch: SW
[FM]
Setting:
Band switch: FM
• Repeat the procedures in each adjustment several times, and the
frequency coverage and tracking adjustments should be finally
done by the trimmer capacitors.
• Remove FM/SW antenna in SW and FM adjustments.
AM RF signal
generator
30% amplitude
modulation by
400 Hz signal
Output level: as low as possible
Put the lead-wire
antenna close to
the set.
+
–
level mete
r
set
8 Ω
TP9 (SP –)
TP8 (SP +)
AM RF signal
generator
30% amplitude
modulation by
400 Hz signal
Output level: as low as possible
+
–
level mete
r
TP9 (SP –)
TP8 (SP +)
TP1
(ANT IN)
set
8 Ω
12 pF
FM RF signal
generator
22.5 kHz frequency
deviation by 400 Hz
signal
Output level: as low as possible
+
–
level meter
TP9 (SP –)
TP8 (SP +)
TP1
(ANT IN)
set
8 Ω
0.01 µ F

– 10 –
Adjustment Location:
L1 CT1-1
MW Tracking
Adjustment L3 CT1-2
FM Tracking Adjustment
T1
AM IF Adjustment
SW Tracking
Adjustment
L2 CT5
– MAIN BOARD (Component Side) –
MW Frequency
Coverage
Adjustment
CT1-4 L5
SW Frequency Coverage
Adjustment
CT6 L6
CT1-3 L4
FM Frequency Coverage
Adjustment
–MAIN BOARD (Conductor Side) –
TP1 (ANT IN)
TP2 (GND)
TP9 (SP –)
TP8 (SP +)

ICF-J1
– 11 – – 12 –
SECTION 5
DIAGRAMS
5-1. BLOCK DIAGRAM
13 15 18 24
16
3
BPF
BPF1
L2
SW ANT
CT5
ANT1
FM/SW
TELESCOPIC
ANTENNA
FM
FRONT-END
FM ANT
11 AM
FRONT-END
AM ANT
MIX OUT
+ +
L5
MW OSC
L6
SW OSC
CT1 – 4
CV1 – 1
S1 – 3
S1 – 4
CT1 – 1
10 8
CV1 – 2 CT1 – 3
CT1 – 2 CV1 – 3
FM RF
FM OSC
FM TRACKING
CT1 – 2, L3 CT1 – 3, L4
L3
FM RF
L4
FM OSC
FM FREQUENCY
COVERAGE
CT5, L2
SW
TRACKING
CT1 – 1, L1
MW
TRACKING
L1
MW
FERRITE-ROD
ANTENNA
CV1 – 4
S1 – 5 S1 – 6
CT1 – 4, L5
MW FREQUENCY
COVERAGE
CT6, L6
SW FREQUENCY
COVERAGE
CT6
BAND
FM
MW
SW
S1
6
AM OSC
FM/AM FRONT-END,
FM/AM IF AMP, DET, AGC
IC1
T1
AM IF
CF3
CF2
17
FM
DISCRIMINATOR
FM IF
AMP
AM IF,
DET, AGC
FM
IFIN
AM
IFIN
TUNING METER
DISCRI
CF1
20
LED
TUNE
D2
HIGH CUT
SWITCH
Q1
DET
OUT
BAND
SW
VOLUME
RV1
S1 – 2
13 11
POWER
AMP
INVERTER
AMP
POWER
AMP 863
PWR
OUT1
PWR
OUT2
INV
OUT IN2
IN1
SP1
(SPEAKER)
1517
RIPPLE FILTER
Q2
RIPPLE
FILTER
BASE OUT
REF IN
POWER
S2
ON
OFF
BATT B+
DRY BATTERY
SIZE “D”
(IEC DESIGNATION R20)
2PCS. 3V
v
J1
IC2
POWER AMP,
RIPPLE FILTER
05
• SIGNAL PATH
: FM
: MW/SW
S1 – 1
AM IF
FOR
MW/SW

ICF-J1
– 13 – – 14 –
5-2. PRINTED WIRING BOARD
Q1
BCE
Q2
IC2
IC1
BCE
L7
JW6
C34
+
C37
+
JW3
C29
+
C23
+
C26
BPF1
+
C25
+
JW7 JW8
JW15
JW9
T1
AM IF
CF3
CF2
C13C14C15
+ + +
C19
+
C9
+
L4
FM OSC
L5
MW OSC
L6
SW OSC
D2
L2
SW ANT
CT5
S2
CF1
RV1
JW13
JW12 JW10
JW11
C38
+
J1
C28
R10
R9
C39
C31
JC6
JC7
R7
C44
C32
C24
C27
C30
R8
C22
C36
C40
C35
C33
R2
C12
R1
C11
C10
C45
R16
C3
R3
JC4
S1
C1
C41
C4
C18
C16
C17
R11
C20
C21
R4
JC8
R6 R5
C5
C6
CT6
JW2
L3
FM RF
MAIN BOARD
05
JC5
C2
115
1630
123 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
TUNE
JC2
C7
–6
–5
–4
–3
–2
–1
BAND
FM MW SW
TP1 (ANT IN)
TP2 (GND)
JW1
ANT1
FM/SW
TELESCOPIC
ANTENNA
L1
MW FERRITE-ROD ANTENNA
BLK
NATURAL
RED
1
3
CT1-1CT1-4
CV1-1CV1-4
CT1-2CT1-3
CV1-2CV1-3
POWER
VOLUME
OFF
ON
TP8 (SP+)
v
18 10
91 JW4
JW5 TP9 (SP –)
SP1
DRY BATTERY
SIZE “D”
(IEC DESIGNATION R20)
2PCS. 3V
RED
WHT
WHT
WHT/RED
1-680-291-
11
(11)
• Semiconductor
Location
Ref. No. Location
D2 A-3
IC1 F-4
IC2 F-7
Q1 G-4
Q2 E-7
Note on Printed Wiring Board:
•X: parts extracted from the component side.
•Y: parts extracted from the conductor side.
•W: indicates side identified with part number.
•f: internal component.
•: Pattern from the side which enables seeing.

ICF-J1
– 15 – – 16 –
5-3. SCHEMATIC DIAGRAM
• IC Block Diagrams
IC1 CXA1019S
12 3 45 6 7 8 9 10 15141312
11
FM
DISCRIMINATOR
AF POWER AMP AM FE FM IF
TUNING
METER
AM IF DET AGC
FM FE
23 22 21 202425 19 18 17 1629 28 27 2630
GND GND AF OUT VCC RIPPLE FILTER AF IN DET OUT AFC AGC AFC AGC IF GND METER N.C FM IF IN AM IF IN FM/AM BAND SELECT
FM/AM
IF OUT
FE GND
N.C
AM RF IN
FM RF
REG OUT
FM OSC
FM RF IN
AFC
AM OSC
VOL
NF
FM DISCRI
GND GND
IC2 BA6640F-E2
18 17 16 15 14 13 12 11 10
1 2 3 4 5 6 7 8 9
+
–
+
–
+
–
BIAS RF OUT RFC BASE OUT MUTE OUT1 IN1 NF1 PWR OUT1 VCC
STNBY
PWR MUTE
INVOUT
NFB
MUTE OUT2
IN2
NF2
PWR OUT2
GND
RIPPLE FILTER
MUTE
PWR1
PWR2
INV
Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
•f: internal component.
•C: panel designation.
•A: B+ Line.
•U: B+ Line.
•H: adjustment for repair.
• Power voltage is dc 3V and fed with regulated dc power
supply from battery terminal.
• Voltages are dc with respect to ground under no-signal
(detuned) conditions.
no mark : FM
( ) : MW
〈〈 〉〉 : SW
• Voltagesare takenwith aVOM (Input impedance10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Signal path.
F: FM
f: MW/SW

SECTION 6
EXPLODED VIEWS
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Accessories and packing materials are given
in the last of the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
(1) CABINET SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1 X-3380-322-1 CABINET (FRONT) SUB ASSY
2 3-223-773-01 TERMINAL (+), BATTERY
3 3-223-774-01 TERMINAL (-), BATTERY
4 3-223-756-01 CABINET (REAR)
5 3-223-775-01 TERMINAL (+ -), BATTERY
6 3-227-727-01 CUSHION (BATTERY TERMINAL)
7 3-223-760-01 LID, BATTERY CASE
8 3-227-729-01 TUNING, SPRING
9 3-223-763-01 KNOB (TUNING)
10 3-223-762-01 KNOB (VOLUME)
ANT1 1-754-159-11 ANTENNA, TELESCOPIC (FM/SW)
SP1 1-529-884-11 SPEAKER (9.2cm)
#1 7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
#2 7-623-508-01 LUG, 3
#3 7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
#4 7-624-209-01 O RING, P-9
1
23
10
9
8
SP1
#4
#1 #2
#3
#3
not supplied
ANT1
chassis section
4
5
6
7
– 17 –

– 18 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
51 3-223-764-01 KNOB (POWER)
52 3-223-767-01 POINTER
53 3-223-772-01 PLATE, BACK
54 3-223-766-01 RACK
*55 3-223-758-01 CHASSIS
56 3-223-765-01 SLIDER
57 3-223-761-01 KNOB (BAND)
58 3-223-768-01 GEAR (TUNING CAPACITOR)
59 3-369-213-01 SPRING (GEAR)
60 3-369-208-01 GEAR (B), TUNING CAPACITOR
61 3-364-941-11 SCREW (+B) (2.6X5), NYLOK
62 3-223-759-01 HOLDER (GEAR)
*63 A-3683-250-A MAIN BOARD, COMPLETE
64 3-223-770-01 GEAR, MIDWAY
65 3-223-769-01 SHAFT, TUNING
D2 8-719-042-69 LED LN21RPL (TUNE)
L1 1-754-132-11 ANTENNA, FERRITE-ROD (MW)
#3 7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
52
53
51
65
54
55
L1
#3
D2
#3
56 57
64
58 59 60 61
62
63
(2) CHASSIS SECTION

– 19 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
*A-3683-250-A MAIN BOARD, COMPLETE
*********************
< BAND PASS FILTER >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C2 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C3 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C4 1-117-402-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-164-392-11 CERAMIC CHIP 390PF 5% 50V
C6 1-102-951-00 CERAMIC 15PF 5% 50V
C7 1-162-979-11 CERAMIC CHIP 0.0027uF 10% 50V
C9 1-126-964-11 ELECT 10uF 20% 50V
C10 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C11 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C13 1-126-963-11 ELECT 4.7uF 20% 50V
C14 1-126-963-11 ELECT 4.7uF 20% 50V
C15 1-126-964-11 ELECT 10uF 20% 50V
C16 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C17 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C18 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C19 1-104-665-11 ELECT 100uF 20% 10V
C20 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C23 1-128-551-11 ELECT 22uF 20% 25V
C24 1-115-156-11 CERAMIC CHIP 1uF 10V
C25 1-126-935-11 ELECT 470uF 20% 6.3V
C26 1-126-964-11 ELECT 10uF 20% 50V
C27 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C28 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C29 1-126-961-11 ELECT 2.2uF 20% 50V
C30 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C31 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C32 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C33 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C34 1-126-961-11 ELECT 2.2uF 20% 50V
C35 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C36 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C37 1-126-935-11 ELECT 470uF 20% 6.3V
C38 1-104-664-11 ELECT 47uF 20% 10V
C39 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C40 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C41 1-117-402-11 CERAMIC CHIP 10PF 0.5PF 50V
C44 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C45 1-117-402-11 CERAMIC CHIP 10PF 0.5PF 50V
< CERAMIC FILTER >
CF1 1-579-632-51 FILTER, CERAMIC
CF2 1-795-157-21 FILTER, CERAMIC
CF3 1-579-632-51 FILTER, CERAMIC
< TRIMMER >
CT5 1-141-601-21 CAP, ADJ
CT6 1-141-601-21 CAP, ADJ
< VARIABLE CAPACITOR >
CV1-4 1-141-612-11 CAP, VER
< LED >
D2 8-719-042-69 LED LN21RPL (TUNE)
< IC >
IC1 8-752-037-02 IC CXA1019S
IC2 8-759-650-96 IC BA6640F-E2
< JACK >
J1 1-563-836-21 JACK (v)
< RESISTOR >
JC2 1-216-864-11 METAL CHIP 0 5% 1/16W
JC4 1-216-864-11 METAL CHIP 0 5% 1/16W
JC5 1-216-864-11 METAL CHIP 0 5% 1/16W
JC6 1-216-864-11 METAL CHIP 0 5% 1/16W
JC7 1-216-864-11 METAL CHIP 0 5% 1/16W
JC8 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L2 1-419-895-11 COIL, RF (SW)
*L3 1-422-320-11 COIL, AIR-CORE
L4 1-460-135-11 COIL (WITH CORE) (RF)
L5 1-406-092-11 COIL, OSC (MW)
L6 1-419-894-11 COIL, OSCILLATION (SW)
MAIN

– 20 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
L7 1-410-294-11 INDUCTOR 38uH
< TRANSISTOR >
Q1 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2 8-729-904-87 TRANSISTOR 2SB1197K-R
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R2 1-216-815-11 METAL CHIP 330 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R6 1-216-817-11 METAL CHIP 470 5% 1/16W
R7 1-216-821-11 METAL CHIP 1K 5% 1/16W
R8 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R9 1-216-821-11 METAL CHIP 1K 5% 1/16W
R10 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R11 1-216-805-11 METAL CHIP 47 5% 1/16W
R16 1-216-819-11 METAL CHIP 680 5% 1/16W
< VARIABLE RESISTOR >
RV1 1-227-290-11 RES, VAR, CARBON (VOLUME)
< SWITCH >
S1 1-771-748-21 SWITCH, SLIDE (BAND)
S2 1-771-905-11 SWITCH, SLIDE (POWER)
< TRANSFORMER >
T1 1-435-886-11 TRANSFORMER, IF
***********************************************************
MISCELLANEOUS
**************
ANT1 1-754-159-11 ANTENNA, TELESCOPIC (FM/SW)
D2 8-719-042-69 LED LN21RPL (TUNE)
L1 1-754-132-11 ANTENNA, FERRITE-ROD (MW)
SP1 1-529-884-11 SPEAKER (9.2cm)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
3-224-872-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
3-227-343-01 CASE, CARRYING (Saudi Arabia)
3-227-344-01 STRAP (Saudi Arabia)
ICF-J1
Sony Corporation
Audio Entertainment Group
9-873-037-11 2000L0516-1
Printed in Japan C2000. 12
Published by General Engineering Dept.
