Sony Walkman ICF-C763 User manual

ICF-C763/C763L
SERVICE MANUAL
ICF-763
FM/AM PLL SYNTHESIZED CLOCK RADIO
ICF-763L
FM/MW/LM PLL SYNTHESIZED CLOCK RADIO
SPECIFICATIONS
US Model
Canadian Model
ICF-C763
AEP Model
ICF-C763/C763L
UK Model
ICF-C763L
Ver 1.0 2004.05
9-877-783-01
2004E02-1
© 2004.05
Sony Corporation
Personal Audio Company
Published by Sony Engineering Corporation
Time display
UK, North and South America 12-hour system
Other countries/regions 24-hour system
Frequency range
Model for North and South America
Band ICF-C763 Channel step
FM 87.5 - 108 MHz 0.1 MHz
AM 530 - 1 710 kHz 10 kHz
Model for other countries/Regions
Band ICF-C763 ICF-C763L Channel step
FM 87.5 - 108 MHz 87.5 - 108 MHz 0.05 MHz
AM (MW) 531 - 1 602 kHz 531 - 1 602 kHz 9 kHz
LW —153 - 279 kHz 3 kHz
Speaker
Approx. 5.7 cm (2 1/4inches) dia. 4 Ω
Power output
200 mW (at 10 % harmonic distortion)
Power requirements
North and South American model : 120 V AC, 60 Hz
Other model : 230 V AC, 50 Hz
Dimensions
Approx. 115.5 x 105 x 110.6 mm (w/h/d) (4 5/8x 4 1/4x 4 3/8inches)
including projecting parts and controls
Mass
Approx. 665 g (1 lb 7.5 oz)
Approx. 675 g (1 lb 7.8 oz): ICF-C763L (UK model)
Approx. 600 g (1 lb 5.2 oz): ICF-C763 (North and South America model)
Design and specifications are subject to change without notice.

ICF-C763/C763L
2
TABLE OF CONTENTS
Specifications ........................................................................... 1
1. GENERAL
Location and Function of Controls .................................... 3
2. ELECTRICAL ADJUSTMENTS............................. 4
3. DIAGRAMS
3-1.IC Block Diagrams ...................................................... 6
3-2. IC Pin Function Descriptions ..................................... 7
3-3. Printed Wiring Board – Main section – ...................... 8
3-4. Schematic Diagram – Main section–.......................... 9
3-5. Printed Wiring Board – Contrd section – ................. 10
3-6. Schematic Diagram – Contrd section – ................... 11
3-7. Printed Wiring Board – Power section – .................. 12
3-8. Schematic Diagram – Power section – ..................... 12
4. EXPLODED VIEW
4-1.Cabinet (Upper) Section ............................................ 13
5. ELECTRICAL PARTS LIST................................... 14
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICALTO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
• HOWTO CHANGETHE CERAMIC FILTER
This model is used two ceramic filters of CF2 and CF3.
You must use same type of color marked ceramic filters in
order to meet same specifications.
Therefore, the ceramic filter must change two pieces together
since it's supply two pieces in package as a spare parts.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
Checkthe antenna terminals,metal trim,“metallized”knobs,screws,
and all other exposed metal parts forAC leakage. Check leakage as
described below.
LEAKAGE
The AC leakage from any exposed metal part to earth Ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers).
Leakage current can be measured by any one of three methods.
1. Acommercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. Abattery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOMor battery-operatedAC voltmeter. The “limit”indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples
of a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2VAC range are suitable. (See
Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
0.15µF
To Exposed Metal
Parts on Set
1.5kΩAC
voltmeter
(0.75V)
Earth Ground
mark mark
CF3
CF2
no mark
blue
orange
black
white
10.70MHz
10.67MHz
10.73MHz
10.64MHz
10.76MHz
Mark Center
frequency

ICF-C763/C763L
3
SECTION 1
GENERAL
LOCATION AND FUNCTION OF CONTROLS
This section is extracted from
instruction manual.
OFF ON
NIGHT LIGHT MODE
STANDBY
A
RADIO
SLEEP
FM12
MW
AM
LW
PM
MHz kHz
RADIO B
SOUND 12345
WAKE UP
PRESET
PRESETOFF
RADIO
ON
BAND
SLEEP
VOLUME
BRIGHTNESS TUNE/TIME SET
CLOCK D.S.T./ ALARM MODEALARM
AB
54321
NAP
ENTER SELECTPRESET
SNOOZE/
SLEEP OFF
P
U
S
H O P
E
N
SNOOZE/SLEEP OFF
AC power cord
The PRESET 3 button andVOLUME have a tactile dot.

ICF-C763/C763L
4
AM IF ADJUSTMENT
Adjust for a maximum reading on level meter.
T1
450 kHz
AM FREQUENCY COVERAGE
ADJUSTMENT
Frequency Display 530 kHz [531 kHz] 1,710 kHz [1,602 kHz]
Reading on Digital voltmeter 3.0 ±0.1 V 10.0 ±1.0V[9.0 ±1.0V]
Adjustment Part L4 <confirmation>
AM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 CT1
530 kHz [531kHz] 1.490 kHz [1.404kHz]
MW IF ADJUSTMENT
Adjust for a maximum reading on level meter.
T1
450 kHz
MW FREQUENCY COVERAGE
ADJUSTMENT
Frequency Display 531 kHz 1.602 kHz
Reading on Digital voltmeter 2.75 ±0.1 V 9.0 ±1.0 V
Adjustment Part L4 <confirmation>
MW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 CT1
621 kHz 1.404 kHz
LW FREQUENCY COVERAGE
ADJUSTMENT
Frequency Display 153 kHz 279 kHz
Reading on Digital voltmeter 2.3 ±0.3 V 9.0 ±0.1 V
Adjustment Part <confirmation> CT4
LW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 CT2
162 kHz 243 kHz
• ICF-C763/C763L
FM FREQUENCY COVERAGE
CONFIRMATION
Frequency Display 87.5 MHz 108 MHz
Reading on Digital voltmeter 3.2 ±0.3 V 10.0 ±1.5 V
Adjustment Part <confirmation> <confirmation>
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L2 CT3
87.5 MHz 108 MHz
SECTION 2
ELECTRICAL ADJUSTMENTS
< > : ICF-C763L
TUNER SECTION 0 dB = 1 µV
• FM Section
Setting:
BAND button:FM
Put the lead-wire
antenna close to
the set.
AM RF signal
generator
30% amplitude
modulation by
400 Hz signal
• AM Section
Setting:
BAND button: AM <MW and LW>
TP (ANT)
FM RF signal
generator
0.01
µ F
set
22.5 kHz frequency
deviation by 400 Hz signal
output level : as low as possible
• Connecting Level Meter (FM, AM<MW and LW>)
32 Ω
SPK+
level meter
(range 0.5-5V AC)
digital
voltmeter
100 kΩ
TP (VT)
• Connecting Digital Voltmeter (FM, AM <MW and LW>)
• Repeat the procedures in each adjustment several times, and the
frequency coverage and tracking adjustments should be finally
done by the trimmer capacitors.
Adjustment and Connect Location: See page 5.
• ICF-C763 [ ] : Italian model
• ICF-C763L

ICF-C763/C763L
5
L2 : FM tracking
adjustment
CT2 : LW
tracking
adjustment
L1 : AM (MW)
tracking
adjustment
CT1 : AM (MW)
tracking
adjustment
MAIN BOARD (Component Side)
L4 : AM (MW)
Frequency coverage
adjustment
CT4 : LW
Frequency coverag
e
adjustment
CT3 : FM tracking
adjustment
L1 : LW tracking
adjustment
T1 : AM (MW)
IF adjustment
JC1
C14
C44 C20
R8
R9
R6
C4
JW1
JW12
C22
C2
C8
C9
C30
C11
C10
JC1 C26
C28
C15
E
E B
E B C
E B C
C B
C B E
C B E
JC
C
R
JW4
R22
R14
C23
R15
C24
C29
L3
C33
C36
C34
C32
R3
C12 C13
JW9
R7 CT4
CT1
CT2 CT3
C43
D103
D104
C7:C763
JC7:C763L
C763
C763L
C763L
C763L
C6
JW8 C5
R5
C1
R2
R4
C3
D2
R18
R20 C40
R17
R16 C37 T1
CF1
C31
SPK+
C3
C39
R13
C27
R21
JC2
D3
L2
L4
BPF1 CF2
C25
US,CND
IT,UK
IT,AEP
JW110 JW3
R19
C41
R1
Q1
D4
Q4
Q6
Q7
Q2
D1 IC1
12
12
1
14 15
28
TP(ANT)
TP(VT)
MAIN BOARD (Conductor Side) MAIN BOARD (Conductor Side)
TP (VT) TP (ANT)
SPK+
Adjustment and Connect Location

ICF-C763/C763L
6
SECTION 3
DIAGRAMS
•Circuit Boards Location
Note:
•All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or
less are not indicated except for electrolytics and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise specified.
•A: B+ Line.
•H: adjustment for repair.
•Voltages are dc with respect to ground under no-signal conditions.
no mark : FM
():AM
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production toler-
ances.
•Signal path.
F: FM
f: AM
• Abbreviation
CND : Canadian model
IT : Itarian model
Note:
•X: parts extracted from the component side.
•: Pattern from the side which enables seeing.
3-1. IC Block Diagrams
IC1 CXA1019M
GND GND
FM DISCRI
NF
VOL
AM OSC
AFC
FM OSC
REG OUT
FM RF
AM RF IN
N. C
FM RF IN
FE GND
MIX OUT
21222324252627
2829
30
235
4678910
111 12 13 14 15
16
17
18
1920
AF POWER AMP
AM IF DET AGC
AM FE
FM
DISCRIMINATOR
FM FE
TUNING
METER
FM IF
GND GND AF OUT Vcc RIPPLE FILTER AF IN DET OUT AFC AGC AFC AGC IF GND METER N. C FM IF IN AM IF IN FM/AM BAND SELECT
Note:
The components identi-
fied by mark 0or dotted
linewithmark 0arecriti-
cal for safety.
Replace only with part
number specified.
Note:
Lescomposants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.

7
7
ICF-C763/C763L
Pin No. Pin Name I/O Description
1, 2 BACK LIGHT1, 2 O Back light LED
3, 4 ILLUMINATION1, 2 O Illumination LED
5 to 9 KS0 to 4 O Key source
10 to 13 KR0 to 3 I Key return (Pull-down resistor: ON setting)
14 ILLUMINATION 2 O Illumination LED
15 MUTE O Mute output
16, 17 BAND1, 2 O Band output
18 GND – Ground
19 EO O Output for charge pump for PLL frequency synthesizer
20 VCOL I VCO input on AM band
21 VCOH I VCO input on FM band
22 REG0 – Voltage regulator for PLL output
23 VDD – Power supply (+3V)
24 XOUT O Connected to crystal oscillator for system clock (75kHz)
25 XIN I Connected to crystal oscillator for system clock (75kHz)
26 REG1 – Voltage regulator for oscillation circuit output
27 REGLCD0 – LCD drive power supply terminal
28, 29 CAPLCD0, 1 – Connected to the capacitor for doubler circuit
30 REGLCD1 – LCD drive power supply terminal
31 to 34 COM0 to 3 O LCD common output
35 to 49 LCD0to 14 O LCD segment output
50 CE I Chip enable signal input
51 INT I Door open/close detect input
52 BEEP O BEEP output
53 MELODY ST O Melody IC starts playing
54 MELODY CK O Melody IC serial clock
55 MELODY DATA O Melody IC serial data
56 INTIAL O Initial output
3-2. IC Pin Function Descriptions
•IC100 SYSTEM CONTROL (MPD17072GB-573-1A7)

ICF-C763/C763L
8
8
3-3. PRINTED WIRING BOARD – MAIN SECTION –
A
POWER
BOARD
(Page 12)
1
2
7
6
MAIN BOARD
R109
R100
C112
R112
R113
D100 D101
D102
C110
C137
JC104
JC103
R122
JC102
C14
C44 C20
R8
R9
R6
C4
JW1
JW12
C22
C2
C8
C9
C30
C11
C10
JC1 C26
C28
R128
JW7
C15
C125C19
C124
C132
C133
C107 C111
R125
C106
R107
R117
R105 R106
C105
E B C
E B C
E B C
E B C
C B E
C B E
C B E
C B E
C B E
C B E
C B E
C129 C134 C128 C135
JC8 JC9
C21
R12
R132
R25
JW4
R22
R14
C23
R15
C24
C29
L3
C33
C36
C34
C32
C38
R3
C12 C13
C117
C115
JW9
C114
R130
C119 C120
R124
R110
C118
C113
C116
R7 CT4
CT1
CT2 CT3
C43
CN2
D103
D104
C7:C763
JC7:C763L
C763
C763
C763L
C763L
C763L
C763L
C763L
C763L
C6
JW8 C5
R5
C1
R2
R4
C3
D2
R18
R20 C40
R17
R16 C37 T1
CF1
C31
SPK+
C35
C39
R13
C27
CF3
R123
R21
C126
C127
C131
C130
IC100
JW103
JW107 JW113
X101
JW102
JW101 1
118
14 15
28
29
43 42
56
JW105
LCD101
D100 - 102
(BACK LIGHT)
R129
C108
C109
IC101
R115
R111
R11 CN1
CN3
Q3
R26
JC106
JC107
C103
R108
R103
R104
R101
R102
C104
R127
R126
JC105
R114
C42
R131
C136
C18
JC2
D3
L2
L4
L4
BPF1 CF2
C25
US,CND
US,CND
IT,UK
IT,AEP
JW110
JW6
JW3
JW111
R19
C41
R1
Q1
D4
Q5
Q4
Q6
Q7
Q2
Q102
Q103 D106
D105
Q100
Q101
D1
IC1
C122
C123
C16
C17 R10
R118
R119
R120
R121
11
(11)
1-861-853-
C
KEY
BOARD
(Page 10)
12
54
B
KEY
BOARD
(Page 10)
12
14
13
K
1
45
8
1
14 15
28
TP(ANT)
TP(VT)
L1
LW/MW
FERRITE-BAR
ANTENNA
L1
AM
FERRITE-BAR
ANTENNA
23 4 5 6
A
1
B
C
D
E
D1 D-2
D2 D-3
D3 D-3
D4 D-2
D100 B-2
D101 B-3
D102 B-5
D103 D-1
D104 D-1
D105 B-5
D106 B-5
IC1 D-4
IC100 B-3
IC101 B-4
Q1 C-2
Q2 C-3
Q3 C-5
Q4 C-3
Q5 C-3
Q6 C-3
Q7 D-5
Q100 A-5
Q101 A-5
Q102 B-4
Q103 B-5
Ref. No. Location
zSemiconductor
Location

9
9
ICF-C763/C763L
3-4. SCHEMATIC DIAGRAM – MAIN SECTION –
D2
D3
D100 D101 D102
D103
D104
D105 D106
Q102
Q103
IC1
C1 C3
C4
C5
C6
C8
C9
C10
C11
C12 C14
C21
C22
C23
C24
C25
C42
C27
C28
C29
C30
C31
C33
C34
C35
C36
C37
C38
C39
C40
CF1
CF2
T1
C41
JC8
JC9
JW4
C15
C16
C17
C18
C19
C20
C103
C104 C105
C106
C107
C108
C109
C110
C111 C137
C112
C118
JW110
C119
C120
C122
C123
C124
C125
JW111
JW112
JW7
C126
C127
C128
C129
C134
C135
C136
C131
C132
JW101
JW102
JW103
JW108
JW104
JW105
JW113
JW107
JW109
R1
R2
R3
R4 R5
JC7
L4
CT4
R6
R7
R12
JW2
R13
C26
R14
R15
R17
R18 BPF1
R16 JW3
R25
R21
R22
CF3
R19
R20
R26
R8 R9
R10
R11
R100 R101 R102
R103 R104 R105 R106
R107 R108
R109
R110
R111
R117
R115
R113
R114
R123
R130
R131
R125
R126
R127
R129
X101
CN1
CN2
CN3
R128
JW6
JC102
CT2
LCD101
JC2
JC105
JC106
JC107
JC103
D1
JW1
JW8
C44
JC1
CT3
L2
D4
C43
JW9
R124
C130
C13
R118
R119
R120
R121
R122
C113 C114 C115 C116 C117
C32
JC104
L3
C7
IC100
IC101
C2
CT1
C133
Q4
Q5
Q6
Q100 Q101
Q3
Q2
Q1
Q7
R132
R112
HVU202ATRU
HVU202ATRU
SLP-WH118A-51-SW SLP-WH118A-51-SW SLP-WH118A-51-SW
1SS355TE-17
1SS355TE-17
1SS133T-77 1SS133T-77
2SA1576A
DTC144EUA
CXA1019M
470p
0.047
1000p
220p
220p
1000p
10p
5p
0.01
47p 100p
0.01
0.01
3p
10p
1000p
100p
0.01
1
0.01
22
25V
220
10V
1
2.2
10
50V
0.22
0.022
10
50V
4.7
50V
0.01
100p
470p
0.1
0.22
1000p
220
25V
0.01
100p
0.022 0.022
0.01
1000p
0.01
47
10V
1000p
1000p 0.01
0.01
1000p
0.01
1000p
0.01
0.01
1000
6.3V
0.1 0.1
0.1
22p
10p
8p
22p
2.2
0.1
0.01
2.2k
2.2M
10k
100k 2.2M
100k
4.7k
100k
470
0.1
22k
4.7k
1k
10k
10
1k
47
100
2.2k
470
100k
10k 100k
10k
2.2k
2.2 2.2 2.2
10 10 220 220
2.2k 2.2k
4.7k
4.7k
4.7k
4.7k
10
47k
100k
4.7k
10k
47
4.7k
470k
470k
10k
75kHz
7P 14P
5P
10k
KV1563M
220p
KV1610S
100p 10k
0.1
220p
4.7k
4.7k
4.7k
4.7k
4.7k
470p 470p 470p 470p 470p
470
6.3V
82nH
2200p
-573-1A7
SM1125-AWV-E2
100p
0.1
2SC4081-R
BAND SELECT
SWITCH
2SC4081-R
L.P.F
2SC4081-R
L.P.F
2SC4081-R
LED DRVER
2SC4081-R
LED DRVER
2SA1576A
MUTE
SWITCH
2SC3931-C
IF BUFFER
2SC3931-C
BAND SELECT
SWITCH
DTC144EUA
BAND SELECT
SWITCH
22
220k
COM0
COM1
COM2
COM3
COM0
COM1
COM2
COM3
LCD0
LCD1
LCD2
LCD3
LCD4
LCD5
LCD6
LCD7
LCD0
LCD1
LCD2
LCD3
LCD4
LCD5
LCD6
LCD7
LCD8
LCD9
LCD10
LCD11
LCD12
LCD13
LCD13
LCD12
LCD11
LCD10
LCD9
LCD8
SYSTEM
CONTROL
ILLUMI3
LIGHT1
LIGHT2
ILLUMI1
CLCD1
RLCD1
CE
INT
BEEP
INITIAL
CLCD0
RLCD0
REG1
XIN
XOUT
VDD
REG0
VCOH
VCOL
EO
GND
BAND2
BAND1
MUTE
KR3
KR2
KR1
KR0
KS4
KS3
KS2
KS1
KS0
COM0
COM1
COM2
COM3
LCD0
LCD1
LCD2
LCD3
LCD4
LCD5
LCD6
LCD7
LCD8
LCD9
LCD10
LCD11
LCD12
LCD13
LCD14
LIQUID
CRYSTAL
DISPLAY
US/CND
US/CND
C763L
C763L
C763
C763L
C763
C763L
FM
TRACKING
CT3,L2
AM IF :C763
:C763L
MW IF
ANTENNA
FERRITE-BAR
AM
FERRITE-BAR
ANTENNA
L1
L1
MW/LW
TRACKING
TRACKING
CT1,L1
MW
CT2,L1
LW
TRACKING
CT1,L1
AM
BACK LIGHT
D100-102
MELODYDATE
MELODYCK
MELODYST
TP
(ANT)
TP
(VT)
FREQUENCY
COVERAGE
L4
FREQUENCY
COVERAGE
MW
LW
CT4
Q102,103
ILLUMI2
IT,AEP
IT,UK
AC-F-CLOCK DETECT
MELODY

ICF-C763/C763L
10
10
3-5. PRINTED WIRING BOARD – CONTROL SECTION –
11
(11)
1-861-854-
SP1
SPEAKER
B
MAIN
BOARD
(Page8) C
MAIN
BOARD
(Page8 )
15
1
3
11
1
2
5
14
11
(11)
1-861-857-
1
3
VOLUME
N
1
5
11
(11)
1-861-855-
KEY BOARD
R95
R94
C88
Q84
E C B
D85
Q85
E C B
C89
R88
R89
R90
R91
C91
C90
R97 CN86
D87
JW92
W82 W83
JW91
S82
W84
5
S95
ALARM MODE
S92
ALARM B
S91
ALARM A
S94
D.S.T/CLOCK
S84
BRIGHTNESS
S89
NAP
S90 TUNE/TIMESET -
S93 TUNE/TIMESET +
S87
4
S83
D84
3
S88
SNOOZE/
SLEEP OFF
SNOOZE/
SLEEP OFF
S81
(DOOR)
S86
2
S85
1
C93
C92
R99
R98
R96
JC81
R93 R92
D88
W85 VOLUME BOARD
R71
RV1
W85
SUB KEY BOARD
D89
S99
PRESET
S97
RADIO ON/OFF
S96
BAND
S98
SLEEP
D86
W84
23 4 5 6 7
A
1
B
C
D
E
D84 C-1
D85 D-2
D86 D-5
D87 E-2
D88 E-3
D89 D-6
Q84 E-1
Q85 E-1
• Semiconductor
Location
Ref. No. Location

11
11
ICF-C763/C763L
3-6. SCHEMATIC DIAGRAM – CONTROL SECTION –
S98
S97
S99
S96
D86
D89
SP1
R71
S94
S91
S88
S85
S82
S95
S92
S89
S86
S83
S93
S90
S87
S84
R91
R90
R95
R94
R89
R88
R93
R92
C88
C89
JW91
C93
C92
C91
C90
JW92
R97
R96
R99
R98
JC81
D87
D88
D84
D85
CN86
RV1
WS
S81
W82 W83
W84
W85
Q84
Q85
DAP202U
1SS355TE
10k
220
220
4.7k
4.7k
10
10
2.2k
2.2k
0.022
0.022
1000p
1000p
1000p
1000p
10k
10k
10k
10k
1SS355TE-17
1SS355TE-17
SLP-OH81A-51
DAP202U
2P
50k
(DOOR)
2SC4081-R
LED DRIVER
2SC4081-R
LED DRIVER
PRESET
SLEEP
BAND
RADIO
ON/OFF
5
1
CLOCK
3
2
NAP
BRIGHTNESS
4
-
+
TUNE/
TIME SET
ALARM B
ALARM A
D.S.T/
ALARM MODE
TUNE/
TIME SET
SNOOZE/
SLEEP OFF
SNOOZE/
SLEEP OFF
VOLUME
W84
W85

ICF-C763/C763L
12
12
11
(11)
1-861-856-
STANDBY ON OFF
tt
A
MAIN
BOARD
(Page 8)
1
7
W81
T80
POWER
UNIT
POWER BOARD
R86
Q80
YEL
BLK
Q81
JW82
JW85
Q83
Q82
B C E B C E
B C E
B C E
R84
R85
C87
JW89
D82 C82
R80R81
S80
NIGHT LIGHT MODE
R82
C85 D83
C86
JW83
D81
JW88
L82
PATTERN COIL
L81
PATTERN COIL
C83
C84
D80
C81
L80
C80
JW81
23 4
A
1
B
C
D
E
R80 R81
JW83
R85
R86
R84
JW85
C87
C86 JW89
JW88
C85
R82
JW81
D83
D80 D81
D82
C81 C82
C83
C84
S80
L81
L82
C80
JW82
L80
W81
Q82
Q83
Q81
Q80
470 470
4.7k
100k
10k
0.1
0.1
0.01
1k
1SS133T
MTZJ-4.7C RD5.1ESB2
1N4002B
470
6.3V
470
6.3V
1000
10V
470
16V
10
50V
2SC4081-R
+B SWITCH
2SA1576A
+B SWITCH
2SC2001TP-K1K2
+4.4V
REGULATOR
2SC2001TP-K1K2
+4.1V
REGULATOR
PATTERN COIL
PATTERN COIL
NIGHT LIGHT MODE
ON
OFF STANDBY
POWER
T80
UNIT
3-7. PRINTED WIRING BOARD – POWER SECTION – 3-8. SCHEMATIC DIAGRAM – POWER SECTION –
D80 B-3
D81 C-2
D82 B-2
D83 A-3
Q80 B-3
Q81 C-2
Q82 D-3
Q83 D-3
• Semiconductor
Location
Ref. No. Location

ICF-C763/C763L
13
SECTION 4
EXPLODED VIEW
NOTE :
•-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
•The mechanical parts with no reference
number in the exploded views are not
supplied.
•Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
4-1. CABINET (UPPER) SECTION
2
3
1
4
5
27
27
27
27
11
1
1
6
71
89
1
10
12
1
11
13
14
26
28
25
27
32
33
30
29
31
34
35
16
17
SP1
#1
18
19
20
20
21
#2
#2
22
23
24
24
T80
13-252-827-01 SCREW (B2.6), (+) BV TAPPING
2A-4547-466-A POWER BOARD, COMPLETE (C763)
2A-4547-481-A POWER BOARD, COMPLETE (C763L)
33-265-388-01 KNOB (LIGHTMODE)
43-265-381-01 CHASSIS (LOWER)
5A-4547-454-A MAIN PC BOARD ASSY (IT)
5A-4547-472-A MAIN PC BOARD ASSY (US, CND)
5A-4547-476-A MAIN PC BOARD ASSY (UK)
5A-4547-484-A MAIN PC BOARD ASSY (AEP)
6X-2023-066-1 CABINET (FRONT) SUB ASSY
7A-4547-463-A SUB, KEY BOARD, COMPLETE
83-265-382-01 CHASSIS (UPPER)
9A-4547-470-A VOLUME (HAND) BOARD, COMPLETE
10 3-265-387-01 KNOB (VOL)
11 A-4547-459-A KEY BOARD, COMPLETE
12 3-265-396-01 SPRING (SHAFT)
13 3-265-376-01 HOLDER (SHAFT)
14 X-2023-067-1 CABINET (UPPER) SUB ASSY
16 3-265-379-01 BUTTON (POWER)
17 3-265-370-01 CABINET (REAR)
18 3-265-385-01 GUIDE (STAND)
19 3-265-384-01 COVER (STAND)
20 3-265-398-01 SPRING (STAND)
21 3-265-386-01 PLATE (STAND), CLICK
22 3-252-830-01 SCREW (B3), (+) PWH TAPPING
23 3-265-383-01 STAND
24 3-265-401-01 FOOT
25 3-252-828-01 SCREW (B2.6), (+) PWH TAPPING
26 3-254-058-01 SCREW
27 3-254-081-01 SCREW
28 3-265-372-01 WINDOW (LCD)
29 3-265-375-01 SHAFT
30 3-265-377-01 LID
31 3-265-378-01 PLATE, CLICK
32 3-265-393-01 PANEL (C763)
32 3-265-393-11 PANEL (C763L)
33 3-265-394-01 CUSHION (SNOOZE)
34 3-265-397-01 SPRING (CLICK)
35 3-265-402-01 RING, O
SP1 1-544-517-51 SPEAKER
0T80 1-468-672-21 POWER UNIT (US, CND)
0T80 1-468-673-21 POWER UNIT (UK)
0T80 1-468-674-21 POWER UNIT (IT, AEP)
#1 7-626-314-11 SPRING PIN 2X8
#2 7-671-113-01 STEEL, BALL 3
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model
IT : Itarian model
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.

ICF-C763/C763L
14
NOTE :
•Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
•Items marked “ *”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
•SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
•CAPACITORS
uF : µF
•COILS
uH : µH
• Abbreviation
CND : Canadian model
IT : Itarian model
When indicating parts by reference num-
ber, please include the board.
SECTION 5
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
A-4547-459-A KEY BOARD, COMPLETE
******************
< CAPACITOR >
C88 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C89 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C90 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C91 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C92 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C93 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN86 1-580-181-11 SOCKET, CONNECTOR 2P
< DIODE >
D84 6-500-921-01 DIODE SLP-OH81A-51 (SNOOZE/SLEEP OFF)
D85 8-719-941-09 DIODE DAP202U
D87 8-719-988-61 DIODE 1SS355TE-17
D88 8-719-988-61 DIODE 1SS355TE-17
< SHORT >
JC81 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q84 8-729-905-35 TRANSISTOR 2SC4081-R
Q85 8-729-905-35 TRANSISTOR 2SC4081-R
< RESISTOR >
R88 1-216-797-11 METAL CHIP 10 5% 1/10W
R89 1-216-797-11 METAL CHIP 10 5% 1/10W
R90 1-216-813-11 METAL CHIP 220 5% 1/10W
R91 1-216-813-11 METAL CHIP 220 5% 1/10W
R92 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R93 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R94 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R95 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R96 1-216-833-11 METAL CHIP 10K 5% 1/10W
R97 1-216-833-11 METAL CHIP 10K 5% 1/10W
R98 1-216-833-11 METAL CHIP 10K 5% 1/10W
R99 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S81 1-570-953-11 SWITCH, PUSH (1 KEY) (DOOR)
S82 1-771-550-11 SWITCH, TACTILE (5)
S83 1-771-550-11 SWITCH, TACTILE (3)
S84 1-771-550-11 SWITCH, TACTILE (BRIGHTNESS)
S85 1-771-550-11 SWITCH, TACTILE (1)
S86 1-771-550-11 SWITCH, TACTILE (2)
S87 1-771-550-11 SWITCH, TACTILE (4)
S88 1-554-937-11 SWITCH, TACTILE (SNOOZE/SLEEP OFF)
S89 1-771-550-11 SWITCH, TACTILE (NAP)
S90 1-771-550-11 SWITCH, TACTILE (TUNE/TIME SET -)
S91 1-771-550-11 SWITCH, TACTILE (ALARM A)
S92 1-771-550-11 SWITCH, TACTILE (ALARM B)
S93 1-771-550-11 SWITCH, TACTILE (TUNE/TIME SET +)
S94 1-771-550-11 SWITCH, TACTILE (D.S.T/CLOCK)
S95 1-771-550-11 SWITCH, TACTILE (ALRM MODE)
< FLAT CABLE >
W82 1-829-128-11 CABLE, FLEXIBLE FLAT (14 CORE)
W83 1-829-130-11 CABLE, FLEXIBLE FLAT (5 CORE)
W84 1-829-127-11 CABLE, FLEXIBLE FLAT (5 CORE)
W85 1-829-126-11 CABLE, FLEXIBLE FLAT (3 CORE)
*************************************************************
A-4547-454-A MAIN PC BOARD ASSY (IT)
A-4547-472-A MAIN PC BOARD ASSY (US, CND)
A-4547-476-A MAIN PC BOARD ASSY (UK)
A-4547-484-A MAIN PC BOARD ASSY (AEP)
*********************
3-265-380-01 HOLDER (LCD)
3-265-391-01 HOLDER (ANT)
< BAND PASS FILTER >
BPF1 1-236-022-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(C763L)
C2 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(C763L)
C3 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C4 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C6 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C7 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(C763)
C8 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C10 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
KEY
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.

ICF-C763/C763L
15
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(C763L)
C12 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(C763L)
C13 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(C763L)
C14 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(C763L)
C15 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C16 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C17 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C18 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C19 1-104-666-11 ELECT 220uF 20% 25V
C20 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C24 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C25 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C28 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C29 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C30 1-128-551-11 ELECT 22uF 20% 63V
C31 1-126-934-11 ELECT 220uF 20% 16V
C32 1-104-655-91 ELECT 470uF 20% 6.3V
C33 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C34 1-135-834-91 CERAMIC CHIP 2.2 6PF 6.3V
C35 1-126-964-11 ELECT 10uF 20% 50V
C36 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C37 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C38 1-126-964-11 ELECT 10uF 20% 50V
C39 1-126-963-11 ELECT 4.7uF 20% 50V
C40 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C41 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C42 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C43 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(US, CND)
C44 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(US, CND)
C103 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C104 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C105 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-126-947-11 ELECT 47uF 20% 35V
C110 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C111 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C113 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C114 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C115 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C116 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C117 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C118 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C120 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C122 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(C763L)
C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-126-916-11 ELECT 1000uF 20% 6.3V
C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C129 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C133 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C134 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C135 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C136 1-135-834-91 CERAMIC CHIP 2.2 6PF 6.3V
C137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< FILTER >
*CF1 1-577-319-11 FILTER, CERAMIC (C763)
CF1 1-578-677-21 FILTER, CRYSTAL (C763L)
CF2 1-577-324-11 FILTER, CERAMIC
CF3 1-577-324-11 FILTER, CERAMIC
< CONNECTOR >
CN1 1-770-638-11 CONNECTOR, FFC/FPC 7P
CN2 1-770-644-11 CONNECTOR, FFC/FPC 14P
CN3 1-770-636-11 CONNECTOR, FFC/FPC 5P
< TRIMMER >
CT1 1-141-304-21 CAP, CERAMIC TRIMMER 10PF
(AM TRACKING)
CT2 1-141-459-11 CAP, TRIMMER (SEAL TYPE) 45PF
(LW TRACKING)(C763L)
CT3 1-141-304-21 CAP, CERAMIC TRIMMER 10PF
(FM TRACKING)
CT4 1-141-459-11 CAP, TRIMMER (SEAL TYPE) 45PF
(LW FREQUENCY COVERAGE)(C763L)
< DIODE >
D1 8-719-023-99 DIODE KV1563M-3 (C763L)
D2 8-719-084-67 DIODE HVU202ATRU
D3 8-719-084-67 DIODE HVU202ATRU
D4 6-500-169-01 DIODE KV1610STL1-2 (C763)
D100 6-500-915-01 DIODE SLP-WH118A-51-SW
D101 6-500-915-01 DIODE SLP-WH118A-51-SW
D102 6-500-915-01 DIODE SLP-WH118A-51-SW
D103 8-719-988-61 DIODE 1SS355TE-17 (IT, UK)
D104 8-719-988-61 DIODE 1SS355TE-17 (IT, AEP)
D105 8-719-991-33 DIODE 1SS133T-77
D106 8-719-991-33 DIODE 1SS133T-77
< IC >
IC1 8-752-050-16 IC CXA1019M
IC100 6-804-219-01 IC uPD17072GB-573-1A7
IC101 6-701-907-01 IC SM1125-AWV-E2
< SHORT >
JC1 1-216-864-11 SHORT CHIP 0
JC2 1-216-864-11 SHORT CHIP 0
JC7 1-216-864-11 SHORT CHIP 0 (C763L)
JC8 1-216-864-11 SHORT CHIP 0
JC9 1-216-864-11 SHORT CHIP 0
JC102 1-216-864-11 SHORT CHIP 0
JC103 1-216-864-11 SHORT CHIP 0
JC104 1-216-864-11 SHORT CHIP 0

ICF-C763/C763L
16
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN POWER
JC105 1-216-864-11 SHORT CHIP 0
JC106 1-216-864-11 SHORT CHIP 0
JC107 1-216-864-11 SHORT CHIP 0
< COIL >
L1 1-428-951-11 COIL, FERRITE-ROD ANTENNA (MW)
(AM TRACKING) (C763)
L1 1-428-952-11 COIL, FERRITE-ROD ANTENNA
(LW/MW TRACKING) (C763L)
L2 1-406-922-11 COIL, AIR-CORE (FM TRACKING)
L3 1-414-690-21 INDUCTOR 82nH
L4 1-406-485-11 COIL (OSC)
< LIQUID CRYSTAL DISPLAY >
LCD101 1-805-589-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q1 8-729-423-52 TRANSISTOR 2SC3931-C (C763L)
Q2 8-729-423-52 TRANSISTOR 2SC3931-C
Q3 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q4 8-729-905-35 TRANSISTOR 2SC4081-R (C763L)
Q5 8-729-905-35 TRANSISTOR 2SC4081-R
Q6 8-729-905-35 TRANSISTOR 2SC4081-R
Q7 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q100 8-729-905-35 TRANSISTOR 2SC4081-R
Q101 8-729-905-35 TRANSISTOR 2SC4081-R
Q102 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q103 8-729-029-14 TRANSISTOR DTC144EUA-T106
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
(C763L)
R3 1-216-833-11 METAL CHIP 10K 5% 1/10W
(C763L)
R4 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5 1-216-861-11 METAL CHIP 2.2M 5% 1/10W
R6 1-216-845-11 METAL CHIP 100K 5% 1/10W
R7 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(C763L)
R8 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9 1-216-845-11 METAL CHIP 100K 5% 1/10W
R10 1-216-833-11 METAL CHIP 10K 5% 1/10W
R11 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R12 1-216-845-11 METAL CHIP 100K 5% 1/10W
R13 1-216-817-11 METAL CHIP 470 5% 1/10W
R14 1-216-837-11 METAL CHIP 22K 5% 1/10W
R15 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R16 1-216-797-11 METAL CHIP 10 5% 1/10W
R17 1-216-821-11 METAL CHIP 1K 5% 1/10W
R18 1-216-833-11 METAL CHIP 10K 5% 1/10W
R19 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R20 1-216-817-11 METAL CHIP 470 5% 1/10W
R21 1-216-805-11 METAL CHIP 47 5% 1/10W
R22 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-821-11 METAL CHIP 1K 5% 1/10W
R26 1-216-845-11 METAL CHIP 100K 5% 1/10W
R100 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R101 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R102 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R103 1-216-797-11 METAL CHIP 10 5% 1/10W
R104 1-216-797-11 METAL CHIP 10 5% 1/10W
R105 1-216-813-11 METAL CHIP 220 5% 1/10W
R106 1-216-813-11 METAL CHIP 220 5% 1/10W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R108 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R110 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R112 1-216-849-11 METAL CHIP 220K 5% 1/10W
R113 1-216-841-11 METAL CHIP 47K 5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-216-797-11 METAL CHIP 10 5% 1/10W
R117 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R119 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R120 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R121 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R122 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R123 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R124 1-216-833-11 METAL CHIP 10K 5% 1/10W
R125 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R126 1-216-853-11 METAL CHIP 470K 5% 1/10W
R127 1-216-853-11 METAL CHIP 470K 5% 1/10W
R128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R129 1-216-833-11 METAL CHIP 10K 5% 1/10W
R130 1-216-833-11 METAL CHIP 10K 5% 1/10W
R131 1-216-805-11 METAL CHIP 47 5% 1/10W
R132 1-216-801-11 METAL CHIP 22 5% 1/10W
< TRANSFORMER >
T1 1-404-790-11 TRANSFORMER, IF
< VIBRATOR >
X101 1-767-388-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
A-4547-466-A POWER BOARD, COMPLETE (C763)
A-4547-481-A POWER BOARD, COMPLETE (C763L)
**************************
< CAPACITOR >
C80 1-126-964-11 ELECT 10uF 20% 50V
C81 1-126-935-11 ELECT 470uF 20% 16V
C82 1-126-935-11 ELECT 470uF 20% 16V
C83 1-126-926-11 ELECT 1000uF 20% 10V
C84 1-126-935-11 ELECT 470uF 20% 16V
C85 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C86 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C87 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< DIODE >
D80 8-719-921-40 DIODE MTZJ-4.7C
D81 8-719-109-85 DIODE RD5.1ESB2
D82 8-719-063-79 DIODE 1N4002B
D83 8-719-991-33 DIODE 1SS133T-77
< COIL >
L80 1-410-294-31 INDUCTOR 38uH
< TRANSISTOR >
Q80 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2

ICF-C763/C763L
17
Ref. No. Part No. Description Remark
Q81 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
Q82 8-729-905-35 TRANSISTOR 2SC4081-R
Q83 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
< RESISTOR >
R80 1-216-817-11 METAL CHIP 470 5% 1/10W
R81 1-216-817-11 METAL CHIP 470 5% 1/10W
R82 1-216-821-11 METAL CHIP 1K 5% 1/10W
R84 1-216-833-11 METAL CHIP 10K 5% 1/10W
R85 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R86 1-216-845-11 METAL CHIP 100K 5% 1/10W
< SWITCH >
S80 1-554-061-00 SWITCH, SLIDE (NIGHT LIGHT MODE)
< FLAT CABLE >
W81 1-829-129-11 CABLE, FLEXIBLE FLAT (7 CORE)
*************************************************************
A-4547-463-A SUB KEY BOARD, COMPLETE
*********************
< DIODE >
D86 8-719-941-09 DIODE DAP202U
D89 8-719-988-61 DIODE 1SS355TE-17
< SWITCH >
S96 1-771-550-11 SWITCH, TACTILE (BAND)
S97 1-771-550-11 SWITCH, TACTILE (RADIO ON/OFF)
S98 1-771-550-11 SWITCH, TACTILE (SLEEP)
S99 1-771-550-11 SWITCH, TACTILE (PRESET)
*************************************************************
A-4547-470-A VOLUME BOARD, COMPLETE
*********************
< RESISTOR >
R71 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-227-482-11 RES, VAR, CARBON 50K
(wVOLUME)
************************************************************
MISCELLANEOUS
*************
SP1 1-544-517-51 SPEAKER
0T80 1-468-672-21 POWER UNIT (US, CND)
0T80 1-468-673-21 POWER UNIT (UK)
0T80 1-468-674-21 POWER UNIT (IT, AEP)
******************************************************
ACCESSORIES
***********
3-266-173-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH,
GERMAN) (EXCEPT US)
3-266-173-21 MANUAL, INSTRUCTION (ENGLISH) (US)
3-266-173-31 MANUAL, INSTRUCTION
(ITALIAN, DUTCH, PORTUGUESE,
SWEDISH, FINNISH) (IT, AEP)
POWER VOLUME
SUB KEY
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.

ICF-C763/C763L
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2004.05 New
