Sony STR-DE325 User Manual Addendum User guide

1/4 inch = 1 inch Scale 4:1
STR-DE325/425 DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
FRONT VIEW
SIDE VIEW
Receiver
16 7/8" x 5 11/16" x 10 1/2 "
22 lbs 4oz
120
V
60
H
355
WattsM
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone]
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
BACK VIEW
SWITCHED
5 11/16"
1/2"
1 7/8 " 12 1/8" 1 7/8 "
16 7/8"
1"
4 11/16"
Audio/Video Control Center
R
1/2"
1 3/4 "1" 1/2" 5"
12 "
10 1/2 "
AC CORD
VIDEO
OUT
CD
DAT/MD
AM.
ANTENNA
FRONT SPEAKERS
TV
VIDEO
MONITOR
SURROUND SPEAKERS
WOOFER
AC OUTLET
FM102.4 70MHZ A3
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
1 7/8 "
5.1/DVD INPUTS
