Sony STR-DE400 User manual

SERVICE MANUAL
Sony Corporation
Home Audio Division
Published by SonyTechno Create Corporation
AEP Model
UK Model
E Model
Australian Model
MULTI CHANNEL AV RECEIVER
9-887-233-03
2007H16-1
© 2007.08
Ver. 1.2 2007.08
SPECIFICATIONS
STR-DE400
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of
Dolby Laboratories.
“DTS” and “DTS Digital Surround” are registered trademarks of
Digital Theater Systems, Inc.
— Continued on next page —
Amplifier section
Models of area code AEP, UK, TW, AUS
Stereo Power Output1), Reference Power
Output1)2)
6 ohms 20 Hz – 20 kHz, THD 0.09%
55 W + 55 W, 80 W/ch
6 ohms 1 kHz, THD 0.7%
90 W + 90 W, 100 W/ch
6 ohms 1 kHz, THD 10%
120 W + 120 W, 140 W/ch
Models of area code TH
Models of area code RU
Stereo Power Output1), Reference Power
Reference Power
Output1)2)
Output1)2)
6 ohms 20 Hz – 20 kHz, THD 0.09%
40 W + 40 W1),
35 W + 35 W3), 60 W/ch
6 ohms 1 kHz, THD 0.7%
65 W + 65 W1),
60 W + 60 W3), 80 W/ch
6 ohms 1 kHz, THD 10%
85 W + 85 W1),
6 ohms 1 kHz, THD 10%
100 W/ch
75 W + 75 W3), 100 W/ch
Models of area code KR
Stereo Power Output1), Reference Power
Output1)2)
6 ohms 20 Hz – 20 kHz, THD 0.09%
55 W + 55 W1),
50 W + 50 W3), 80 W/ch
6 ohms 1 kHz, THD 0.7%
90 W + 90 W1),
80 W + 80 W3), 100 W/ch
6 ohms 1 kHz, THD 10%
120 W + 120 W1),
100 W + 100 W3),
140 W/ch
1)Measured under the following conditions:
2)Reference power output for front, center and
surround. Depending on the sound field settings
and the source, there may be no sound output.
3)Measured under the following conditions:
Frequency response
Analog 10 Hz – 70 kHz
+0.5/–2 dB (with sound
field and tone bypassed)
Inputs
Analog Sensitivity: 800 mV/
50 kohms
S/N4): 96 dB
(A, 800 mV5))
Digital (Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
Digital (Optical)S/N: 100 dB
(A, 20 kHz LPF)
Outputs (Analog)
AUDIO OUT Voltage: 800 mV/
10 kohms
SUB WOOFER Voltage: 2 V/1 kohm
Tone
Gain levels ±6 dB, 1 dB step
4)INPUT SHORT (with sound field and tone
bypassed).
5)Weighted network, input level.
Area code Power requirements
AEP, UK, KR,
TH, RU 230 V AC, 50 Hz
AUS 240 V AC, 50 Hz
TW 110 V AC, 60 Hz
Area code Power requirements
KR, TH 220 V AC, 50 Hz

2
STR-DE400
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscou-s (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
MODEL IDENTIFICATION
– Rear Panel –
Model Part No.
AEP, UK models 2-662-058-0[]
AUS model 2-662-058-1[]
Taiwan model 2-662-058-2[]
Korean model 2-662-058-3[]
Thai model 2-662-058-4[]
Russian model 2-662-058-5[]
Parts No.
General
Power requirements
Power consumption
Power consumption (during standby mode)
0.2 W
Dimensions (w/h/d) (Approx.)
430 ×145 ×300 mm
including projecting parts
and controls
Mass (Approx.) 7.8 kg
Design and specifications are subject to
change without notice.
Area code Power requirements
AEP, UK, RU 230 V AC, 50/60 Hz
AUS 240 V AC, 50 Hz
KR, TH 220 – 230 V AC,
50/60 Hz
TW 110 V AC, 60 Hz
Area code Power consumption
AEP, UK, AUS,
KR, RU 190 W
TH 170 W
TW 400 W
FM tuner section
Tuning range 87.5 - 108.0 MHz
Intermediate frequency
10.7 MHz
Useable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono/Stereo 76 dB/70 dB
Harmonic distortion at 1 kHz
Mono/Stereo 0.3%/0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
AM tuner section
Tuning range
Intermediate frequency
450 kHz
Usable sensitivity 50 dB µ/m
Video section
Inputs/Outputs
Video: 1 Vp-p/75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p/75 ohms
PB/CB/B-Y: 0.7 Vp-p/
75 ohms
PR/CR/R-Y: 0.7 Vp-p/
75 ohms
80 MHz HD Pass Through
Area code Tuning scale
10 kHz step 9 kHz step
AEP, UK, AUS,
TW, KR, TH, RU –531 – 1,602 kHz
About area codes
The area code of the receiver you purchased is
shown on the lower right portion of the rear panel
(see the illustration below).
Any differences in operation, according to the area
code, are clearly indicated in the text, for example,
“Models of area code AA only”.
SURROUND
SPEAKERS
LR
LR
+ +
CENTER FRONT
LR
LR
+ +
Area code
•Abbreviation
AUS:Australian model
KR : Korean model
RU : Russian model
TH :Thai model
TW :Taiwan model
Ver. 1.1

3
STR-DE400
TABLE OF CONTENTS
1. GENERAL ................................................................... 4
2. TEST MODE ............................................................... 10
3. DIAGRAMS
3-1. Block Diagram – MAIN Section –.................................. 14
3-2. Block Diagram – DISPLAY/POWER Section – ............. 15
3-3. Printed Wiring Board – DIGITAL Board (Side A) –...... 16
3-4. Printed Wiring Board – DIGITAL Board (Side B) –...... 17
3-5. Schematic Diagram – DIGITAL Board (1/3) – .............. 18
3-6. Schematic Diagram – DIGITAL Board (2/3) – .............. 19
3-7. Schematic Diagram – DIGITAL Board (3/3) – .............. 20
3-8. Printed Wiring Board – MAIN Board – ......................... 21
3-9. Schematic Diagram – MAIN Board (1/3) – ................... 22
3-10. Schematic Diagram – MAIN Board (2/3),
HEADPHONE Board –................................................... 23
3-11. Schematic Diagram – MAIN Board (3/3),
ADCC Board, STANDBY Board – ................................. 24
3-12. Printed Wiring Boards
– ADCC Board, HEADPHONE Board – ........................ 25
3-13. Printed Wiring Board – STANDBY Board – ................. 26
3-14. Printed Wiring Board – DISPLAY Board – ................... 27
3-15. Printed Wiring Boards
– TUNING Board, POWER Board – .............................. 28
3-16. Schematic Diagram – DISPLAY Board,
TUNING Board, POWER Board – ................................. 29
3-17. Printed Wiring Board – VIDEO Board –........................ 30
3-18. Schematic Diagram – VIDEO Board – .......................... 31
4. EXPLODED VIEWS
4-1. Front Panel Section ......................................................... 39
4-2. Chassis Section................................................................ 40
5. ELECTRICAL PARTS LIST .................................. 41
SERVICING NOTE
Note on replacement POWER AMPLIFIER IC
There are two kinds of sets by POWER AMPLIFIER IC (IC501,
IC601, IC701: on MAIN board) used with this model.
Type1 : 6-600-450-01 IC STK350-530-E
Type2 : 6-710-828-01 IC STK350-530T-E
Ref. No. Type1 : STK350-530-E Type2 : STK350-530T-E Wiring Board
Location
C504 1-102-233-00 CERAMIC 33PF 10% 500V 1-101-810-00 CERAMIC 100PF 5% 500V D-6
C554 1-102-233-00 CERAMIC 33PF 10% 500V 1-101-810-00 CERAMIC 100PF 5% 500V D-7
C604 1-102-233-00 CERAMIC 33PF 10% 500V 1-101-810-00 CERAMIC 100PF 5% 500V D-7
C654 1-102-233-00 CERAMIC 33PF 10% 500V 1-101-810-00 CERAMIC 100PF 5% 500V D-8
C704 1-102-233-00 CERAMIC 33PF 10% 500V 1-101-810-00 CERAMIC 100PF 5% 500V F-3
IC501 6-600-450-01 IC STK350-530-E 6-710-828-01 IC STK350-530T-E E-6
IC601 6-600-450-01 IC STK350-530-E 6-710-828-01 IC STK350-530T-E E-8
IC701 6-600-450-01 IC STK350-530-E 6-710-828-01 IC STK350-530T-E F-3
As for the set of type1 and type2, the parts on the Main board in the
table below are different.
When repairing, please confirm the type name printed on IC at the
beggining and use the parts corresponded to the table below.
Ver. 1.2

4
STR-DE400 SECTION 1
GENERAL This section is extracted
from instruction manual.
Front panel
AUTO CAL MIC
PHONES
MEMORY
FM MODE TUNING
+
PRESET TUNING
VIDEO 1 VIDEO 2 DVD SA-CD/CD FM AM
AMP MENU ENTER MASTER
VOLUME
INPUT MODE
+
DISPLAY DIMMER 2CH A.F.D. MOVIE MUSIC
?/1
1 5 64 qa9 q; qs qd
qf
8
qlw; qk qgqh
23 7
qj
Name Function
A?/1Press to turn the receiver
on or off.
BAUTO CAL MIC
jack Connects to the supplied ECM-AC2 optimizer
microphone for the Auto
Calibration function.
CMEMORY Press to store a station.
DPRESET TUNING
+/– Press to select a preset station.
EDISPLAY Press to selectinformation
displayed on the display.
FDIMMER Press to adjust the
brightness of the display.
GRemote sensor Receives signals from
remote commander.
Name Function
HDisplay The current status of the
selected component or a
list of selectable items
appears here.
IAMP MENU Press to display the menu
of the receiver.
JENTER Press to store a station or
enter the selection when
selecting the settings.
K2CH Press to select 2CH
STEREO mode.
LA.F.D. Press to select A.F.D.
mode.
MMOVIE,
MUSIC Presstoselect soundfields (MOVIE, MUSIC).
NMASTER
VOLUME Turn to adjust the volume level of all speakers at the
same time.
OINPUT MODE Press to select the input
mode when the same
componentsareconnected
to both digital and analog
jacks.
PI/i/U/uAfter pressing AMP
MENU (I), press Ior i
and Uor uto select the
settings.
QInput buttons Press one of the button to
select the component you
want to use.
RTUNING +/– Press to scan a station.
SFM MODE Press to select FM
monaural or stereo
reception.
TPHONES jack Connects to a headphone.

5
STR-DE400
About the indicators on the display
MEMORY
L C R
SL S SR
SW
LFE
SP RDS
STEREO MONOD.RANGE SLEEP OPT COAX
DIGITAL ; DTS ;
PRO LOGIC II
q; 9
qd
qf
qaqs
214356 7
8
Name Function
ASW Lights up when sub woofer
selection is set to “YES”
and the audio signal is output
from the SUB WOOFER jack.
BLFE Lights up when the disc being
played back contains an LFE
(Low Frequency Effect)
channel and the LFE channel
signal is actually being
reproduced.
CSP Lights up when the receiver is
turned on. This indicator does
not light up if a headphone is
connected to the PHONES jack.
D;DIGITAL Lights up when Dolby Digital
signals are input.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections
and that INPUT MODE is not
set to “ANALOG”.
Name Function
E;PRO
LOGIC (II) Lights up when the receiver applies Pro Logic processing to
2 channel signals in order to
output the center and surround
channel signals. “; PRO
LOGIC II” lights up when the
Pro Logic II Movie/Music
decoder is activated.
However, both indicators do not
light up if both the center and
surround speakers are set to
“NO” and “A.F.D. AUTO”,
“DOLBY PL”, “PLII MV”, or
“PLII MS” is selected.
Note
Dolby Pro Logic and Dolby Pro
Logic II decoding do not
function for DTS format
signals.
FDTS Lights up when DTS signals are
input.
Note
When playing a DTS format
disc, be sure that you have made
digital connections and that
INPUT MODE is not set to
“ANALOG”.
GMEMORY Lights up when a memory
function, such as Preset
Memory, etc., is activated.
HPreset
station
indicators
Lights up when using the
receiver to tune in radio stations
you have preset. For details on
presetting radio stations.
ITuner
indicators Lights up when using the receiver to tune in radio stations,
etc.
Note
“RDS” appears for models of
area code AEP, UK only.
JD.RANGE Lights up when dynamic range
compression is activated.
KCOAX Lights up when INPUT MODE
is set to “AUTO” and the source
signal is a digital signal being
input through the COAXIAL
jack, or when INPUT MODE is
set to “COAX IN”.
LOPT Lights up when INPUT MODE
is set to “AUTO” and the source
signal is a digital signal being
input through the OPTICAL
jack, or when INPUT MODE is
set to “OPT IN”.
MSLEEP Lights up when the sleep timer
is activated.
NPlayback
channel
indicators
L
R
C
SL
SR
S
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
the letters vary to show how the
receiver downmixes the source
sound (based on the speaker
settings).
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Example:
Recording format (Front/
Surround): 3/2.1
Outputchannel:Whensurround
speaker is set to“NO”.
Sound Field: A.F.D. AUTO
L C R
SL SR
SW

6
STR-DE400
*Youcan watch the selected input image when you
connecttheMONITOROUTjackto aTV monitor.
Rear panel
432 5 61
DVD IN
DIGITAL
OPTICAL
VIDEO 2
IN
VIDEO 1
IN
COAXIAL
SA-CD/CD
AUDIO IN
DVD
AUDIO IN
VIDEO 2
AUDIO IN
VIDEO IN VIDEO IN
AM
ANTENNA
SURROUND
SPEAKERS
LR
LR
+ +
CENTER FRONT
LR
LR
+ +
R
L
R
L
R
L
AUDIO
OUT
VIDEO 1
COMPONENTVIDEO
AUDIO IN
VIDEO IN
AUDIO OUT
VIDEO OUT VIDEO OUT
DVD
IN VIDEO 2 IN MONITOR OUT
SUB
WOOFER
MONITOR
Y
P
B /C B
/B–Y
P
R /C R
/R–Y
ADIGITAL INPUT section
OPTICAL
IN jack ConnectstoaDVD player, etc. The
COAXIAL jack
provides a better
quality of loud
sound.
COAXIAL IN
jack
BAUDIO INPUT section
AUDIO IN/
OUT jack ConnectstoanMD deck or CD player,
etc.
CANTENNA section
FM
ANTENNA Connects to the FM wire antenna
supplied with this
receiver.
AM
ANTENNA Connects to the AM loop antenna
supplied with this
receiver.
White (L)
Red (R)
DVIDEO/AUDIO INPUT/OUTPUT
section
AUDIO IN/
OUT jack Connectsthevideo and audio jacks of
a VCR or a DVD
player.
VIDEO IN/
OUT jack*
ECOMPONENT VIDEO INPUT/
OUTPUT section
COMPONENT
VIDEO
INPUT/
OUTPUT
jack*
ConnectstoaDVD
player, TV, or a
satellite tuner. You
can enjoy high
quality image.
FSPEAKER section
Connects to
speakers.
Connects to sub
woofer.
White (L)
Red (R)
Yellow
Green
Blue
Red

7
STR-DE400
You can operate the receiver with the supplied
remote. You can also use the remote to control
the Sony audio/video components that the
remote is assigned to operate.
RM-AAU006
Remote commander
AV ?/1
(on/standby) switch
TV ?/1, ?/1
( on/standby) switch
123
46
78
0/10 ENTER
9
SYSTEM STANDBY
TV/VIDEO
SLEEP AUTO CAL AV
?/1
VIDEO 1 VIDEO 2 DVD SA-CD/CD
2CH A.F.D.
RETURN/EXIT
TV CH –
PRESET – TV CH + PRESET +
TUNING –
TV
TUNING +
REPLAY ADVANCE
MENU
MOVIE MUSIC
MEMORY DVD MENU
CLEAR
TOOLSDISPLAY MUTING
TV VOL
MASTER VOL
FM MODE
D.TUNING
D.SKIP
DUAL MONO
TUNER AMP MENU
TV ?/1
?/1
>10/
-
F
Gg
f
.
HmM
Xx
< <
>
5
1
3
2
wf
wg
5
6
7
8
q;
9
qs
qd
qf
qg
qj
qk
qh
ql qa
4
w;
wa
ws
wd
Name Function
AAV ?/1Press to turn on or off the
Sonyaudio/videocomponents
that the remote is assigned to
operate.
If you press ?/1(B) at the
same time, it will turn off the
receiver and other
components (SYSTEM
STANDBY).
Note
The function of the AV ?/1
switch changes automatically
each time you press the input
buttons (C).
BTV ?/1Press TV ?/1and TV (P) at
the same time to turn the TV
on or off.
?/1Press to turn thereceiveronor
off.
To turn off all components,
press ?/1and AV ?/1(A) at
the same time (SYSTEM
STANDBY).
CInput buttons Press one of the buttons to
select the component you
want to use. When you press
any of the input buttons, the
receiver turns on. The buttons
are factory assigned to control
Sony components as follows.
You can change the button
assignments following the
steps in “Changing button
assignments”.
DAMP MENU Press to display the menu of
the receiver. Then, use the
control buttons to perform
menu operations.
EMOVIE,
MUSIC Press to select sound fields for movie or music.
Button Assigned Sony
component
VIDEO 1 VCR (VTR mode 3)
VIDEO 2 VCR (VTR mode 2)
DVDDVD player
SA-CD/CD Super Audio CD/CD
player
TUNER Built-in tuner

8
STR-DE400
FDUAL MONO Press to select the language
you want during digital
broadcast.
GFM MODE Press to select FM monaural
or stereo reception.
HD.TUNING Press to enter direct tuning
mode.
D.SKIP Press to skip disc of the CD
player or DVD player (multi-
disc changer only).
IENTER Press to enter the value after
selecting a channel, disc or
track using the numeric
buttons.
MEMORY Press to store a station.
JDVD MENU Press to display the menu of
the DVD player on the TV
screen. Then, use the control
buttons to perform menu
operations.
KTOOLS Press to display options
applicable to the entire disc
(e.g.disc protection),recorder
(e.g. audio settings during
recording), or multiple items
on a list menu (e.g. erasing
multiple titles).
LMUTING Press to mute the sound.
MTV VOL
+
a)
/– Press TV VOL +/– and TV (P)at the sametimetoadjust
the TV volume level.
MASTER
VOL +
a)
/– Press to adjust the volume level of all speakers at the
same time.
NMENU Press to display the menus of
the VCR, DVD player, or
satellite tuner on the TV
screen. Then, use the control
buttons to perform menu
operations.
Name Function Name Function
O./>Press to skip tracks of the CD
player, DVD player, MD
deck, or tape deck.
REPLAY /
ADVANCE Press to replay the previous scene or fast forward the
current scene of the VCR or
DVD player.
m/MPress to
–searchtracks in the forward/
backward direction of the
DVD player.
–fast forward/rewind of the
VCR, CD player, MD deck,
or tape deck.
H
a)
Press to start playback of the
VCR,CDplayer,DVDplayer,
MD deck, or tape deck.
XPress to pause playback or
recording of the VCR, CD
player, DVD player, MD
deck, or tape deck. (Also
starts recording with
components in recording
standby.)
xPress to stop playback of the
VCR,CDplayer,DVDplayer,
MD deck, or tape deck.
TV CH +/– Press TV CH +/– and TV (P)
at the same time to select
preset TV channels.
PRESET +/– Press to select
–preset stations.
–preset channels of the VCR
or satellite tuner.
TUNING +/– Press to scan a station.
PTV To activate the buttons with
orange printing, press TV and
the button with orange
printing simultaneously.
QRETURN/
EXIT OPress to –return to the previous menu.
–exitthemenuwhile the
menu or on-screen guide of
the VCR, DVD player, or
satellite tuner is displayed
on the TV screen.
<
<

9
STR-DE400
a)The number 5, MASTER VOL +, TV VOL +, and
Hbuttonshavetactiledots.Usethetactiledots as
references when operating the receiver.
Notes
Some functions explained in this section may not
work depending on the model.
The above explanation is intended to serve as an
example only. Therefore, depending on the
component, the above operation may not be
possible or may operate differently than described.
Name Function
RControl
buttons After pressing AMP MENU (D), DVD MENU (J), or
MENU(N),press the control
button V, v, Bor bto select
the settings. When you press
DVDMENUorMENU,press
the control button to enter the
selection.
SDISPLAY Press to
–selectinformation displayed
on the receiver’s display (for
TUNER input only).
–selectinformation displayed
on the TV screen of the
VCR, satellite tuner, CD
player, DVD player, or MD
deck.
T-/-- Press -/-- and TV (P) at the
same time to select the
channel entry mode, either
one or two digits of the TV.
>10/xPress to select
–tracknumbers over 10 of the
VCR, satellite tuner, CD
player or MD deck.
–channelnumbers of the
Digital CATV terminal.
CLEAR Press to
–clear a mistake when you
press the incorrect numeric
button.
–return to continuous
playback,etc.ofthesatellite
tuner or DVD player.
UNumeric
buttons
(number 5a))
Press to
–preset/tune to preset
stations.
–select track numbers of the
CD player, DVD player or
MD deck. Press 0/10 to
select track number 10.
–select channel numbers of
the VCR or satellite tuner.
Press the numeric buttons and
TV (P) at the same time to
select the TV channels.
V2CH Press to select 2CH STEREO
mode.
WA.F.D. Press to select A.F.D. mode.
XAUTO CAL Press to activate the Auto
Calibration function.
Name Function
YTV/VIDEO Press TV/VIDEO and TV
(P)atthe same timeto select
the input signal (TV input or
video input).
SLEEP Press to activate the Sleep
Timer function and the
duration which the receiver
turns off automatically.

10
STR-DE400
FACTORY PRESET MODE
All preset contents are reset to the default setting.
Procedure:
1. While depressing the PRESET TUNING – and the
DIMMER buttons simultaneously, press the power ?/1
button to turn on the main power.
2. The message “FACTORY” appears and the present contents
are reset to the default values.
AM CHANNEL STEP 9 kHz/10 kHz
SELECTION MODE
Either the 9 kHz step or 10 kHz step can be selected for the AM
channel step.
Procedure:
1. Set the FUNCTION to AM. Turn off the main power.
2. While depressing the TUNING + button, press the power
?/1 button to turn on the main power.
3. Eitherthe message “9 k STEP” or “10 kSTEP” appears. Select
the desired step.
FLUORESCENT INDICATORTUBETEST MODE
All fluorescent segments are tested. When this test is activated, all
segments turn on at the same time, then each segment turns on one
after another.
Procedure:
1. While depressing the PRESET TUNING – and the AM
buttons simultaneously, press the power ?/1 button to turn
on the main power.
2. All segments turn on.
3. Press either of the VIDEO1 or VIDEO2 or DVD or
SA-CD/CD or FM or AM button.
4. Press either of the VIDEO1 or VIDEO2 or DVD or
SA-CD/CD or FM or AM button once again.
5. Press either of the VIDEO1 or VIDEO2 or DVD or
SA-CD/CD or FM or AM button once again.All segments
turn off.
SOUND FIELD CLEAR MODE
The preset sound field is cleared when this mode is activated. Use
this mode before returning the product to clients upon completion
of repair.
Procedure:
1. While depressing the 2CH button, press the power ?/1
button to turn on the main power.
2. The message “SF. CLR.” appears and initialization is
performed.
SOFTWARE VERSION DISPLAY MODE
The software version is displayed.
Procedure:
1. While depressing the PRESET TUNING – and the < buttons
simultaneously, press the power ?/1 button to turn on the
main power.
2. The model name, destination and the software version are
displayed.
KEY CHECK MODE
Button check
Procedure:
1. While depressing the < and the A.F.D. buttons simulta-
neously, press the power ?/1 button to turn on the main
power.
“REST 25” appears.
2. Every pressing of any button other than ?/1 counts down
the buttons. The buttons which are already counted once are
not counted again.
3. When all buttons are pressed “REST 00” appears.
SHIPMENT MODE
All preset contents are reset to the default setting.
Procedure:
1. While depressing the AM and the A.F.D. buttons simulta-
neously, press the power ?/1 button to turn on the main
power.
2. “CLEARING” t“CLEARED” appears and switch off the
set.
PROTECTOR
Procedure:
1. While depressing the PRESET TUNING – and the 2CH
buttons simultaneously, press the power ?/1 button to turn
on the main power.
2. “PROT. EVER” appears and switch off the set.
DECODE AUTO ALL
Procedure:
1. While depressing the PRESET TUNING – and the Ubut-
tons simultaneously, press the power ?/1 button to turn on
the main power.
2. “DEC. TEST” appears and switch off the set.
L
SW
CR
SL S SR
SBL SB SBR
LFE SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
dB
kHz
mft.
MHz
MEMORY
DIRECT
L
SW
R
S
SB
LFE SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
dB
kHz
mft.
MHz
MEMORY
DIRECT
C
SL SR
SBL SBR
SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
kHz
mft.
MHz
MEMORY
DIRECT
SECTION 2
TEST MODE

11
STR-DE400
SWAP ALL MODE
Procedure:
1. While depressing the PRESET TUNING – and the A.F.D.
buttons simultaneously, press the power ?/1 button to turn
on the main power.
2. “SWP.ALL” appears. (No change while displayed.)
ADCC FACTORYTEST MODE
ADCC Factory Test mode have two stages:
1. ADCC DSP Data Line Checking
2. ADCC AUTO CAL MIC board Checking
Factory Test System Setup
1. When power off :
Press the three buttons < + DISPLAY + ?/1 .
(If it doesn’t operate, please press DISPLAY again afetr 2
seconds.)
Afterward, press the DIMMER to start DCAC factory test
mode.
1. ADCC DSP Data Line Checking
After press the DIMMER , DCAC Factory test mode will start,
below display will show:
“DCAC[][][]x” x = 1, 2, 3
If there is error happen, below display will show:
“ERR[]SD0x” x = 1 → D1112 or R1198 or C1523 problem
x = 2 →D1113 problem
x = 3 →D1114 problem
2. ADCC AUTO CAL MIC board Checking
Connect front left speaker of the receiver and AUTO CAL
microphone. Turn MASTERVOLUME jog, there will be test tone
sound output from front left speaker, and the display will change
accordingly.
“AD[]-[]xxx” xxx = 0 to 255(dependson loudness of test tone)
DSP Data Line
Check
Start Pass Pass
Auto Cal Mic
Check END
SPK Front Left
ADCC MIC
Receiver

12
STR-DE400
For Schematic Diagrams.
Note:
•All capacitors are in µF unless otherwise noted. (p: pF)
50WV or less are not indicated except for electrolytics and
tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
• % : indicates tolerance.
• f: internal component.
•2: nonflammable resistor.
•5: fusible resistor.
•C: panel designation.
•A: B+ Line.
•B: B– Line.
•Voltages and waveforms are dc with respect to ground un-
der no-signal (detuned) conditions.
No mark : FM
•Voltages are taken with aVOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
•Waveforms are taken with a oscilloscope.
•Circled numbers refer to waveforms.
•Signal path.
F: FM
J: ANALOG
c: DIGITAL
I: VIDEO
•Abbreviation
AUS:Australian model
KR : Korean model
RU : Russian model
TH :Thai model
TW :Taiwan model
For PrintedWiring Boards.
Note:
•X: parts extracted from the component side.
• a: Through hole.
• f: internal component.
•: Pattern from the side which enables seeing.
•Indication of transistor.
THIS NOTE IS COMMON FOR PRINTEDWIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
Caution:
Pattern face side: Partsonthe pattern facesideseenfrom
(Side B) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(Side A) the parts face are indicated.
SECTION 3
DIAGRAMS
Note: The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replace only with part number specified.
C
BThese are omitted. E
Q
B
These are omitted.
CE
Ver. 1.1

1313
STR-DE400
STR-DE400
•Waveforms
– DIGITAL Board –
1 IC1501 9 (MCLK1)
1 V/DIV, 40 ns/DIV
72 ns 3.4 Vp-p
2 IC1101 id (X1)
1 V/DIV, 20 ns/DIV
41.6 ns4.2 Vp-p
3 IC1301 ws (XIN)
1 V/DIV, 40 ns/DIV
81 ns 4.4 Vp-p
•Circuit Boards Location
DIGITAL board
VIDEO board
MAIN board
DISPLAY board
HEADPHONE board
POWER board
ADCC board
TUNING board
STANDBY board

1414
STR-DE400
STR-DE400
3-1. BLOCK DIAGRAM – MAIN SECTION –
• Signal Path
: FM
: ANALOG
: DIGITAL
: VIDEO
• R-CH is omitted due to same as L-CH.
AUDIO IN
AUDIO IN
AUDIO IN
AUDIO IN
PROCESSOR
49
LOUT
40
SLOUT
33
COUT
DATA
24
CLK
25
21
VOL_CLK
VOL_DATA_LATCH
SDA SCL
22
IC1101(2/3)
DVD
IN
VIDEO 2
IN
J1301
35
62
IC1303(1/2)
DIGITAL AUDIO
I/F RECEIVER
IC1301
L
+7V
DISPLAY/
POWER
SECTION
(Page 15)
DIN2
5
DO
35
DI
36
CLK
38
CE
37
ERROR
34
XSTATE
17
XMODE
48
13
CK OUT
20
XMCK
14
BCK
15
LRCK
16
DATAO
IC1303(2/2)
57
31
IC2000(1/2) IC2000(2/2)
X1301
12.288MHz
AUDIO DSP
IC1503
SELECTOR
IC1501
KFSI0
SYSCLK
LRCK
BCK
DOUT
22
16
13
14
15
SDI2
30
LRCK0
19
HCLK
34
HCS
36
HACN
32
PM
113
BST
56
XRST
2
23
SDO1
24
SDO2
25
SDO3
BCKI2
29
LRCKI2
28
BCKII
17
LRCKII
15
IC1502
SRAM
AUDIO CODEC
IC1452
AD CONVERTER
IC1401
SCK1
38
RST
37
ML
36
MC
35
MDI
34
MDO
33
10
VOUT5
BCK
40
LRCK
41
DATA3
47
DATA1
45
DATA2
46
14
VOUT1
12
VOUT3
11
VOUT4
ANALOG SOUND
SL
ADIFL
13
LIN
16
19
20
21
SL
C
56
RECL1
SW
SLIN
CIN
SWIN
A
98 97 95 96 99 100 94 1
DO
DI
CLK
CE
ERROR
XSTATE CKSEL1
DATA0
92
LRCK_SW
20
HCLK
4
HCS
SW1 SW2 SW3
5
HACN
7
PM
3
BST
6
XRST
8
GP12
10
PCM1608_RST
ADCC_DSP_IN
45
ADCC_ANA_OGUE_IN
12
PCM1608_ML
13
PCM1608_MC
14
PCM1608_MDI
15
PCM1608_MDO
5 6
29 30
J401(2/1)
J2000
J400
VIDEO 1
VIDEO 2
SA-CD/CD
DVD
OPTICAL
IN
IC1353
DIN1
4
22 21
XIN XOUT
93
XMODE
CKSEL1
47
GP9
68
HD OUT
35
HD IN
33
2
GP9
18
HD OUT
19
HD IN
9
MCLK1
12
MCLK2
X1502
13.9MHz
14
SCK OUT
1
LIN
6
RST
20
BCKO
19LRCKO
18SDI1
24
6
1 5
2
AUDIO GP8
69
EXLOCK
59
GP12
37
INL1
10
TN1
TUNER PACK
FM
75 Ω
COAXIAL
AM
R-CH
ST-DI
ST-DO
CLK
CE
STEREO
TUNED
MUTING
FM
AM
R CH
L CH
TUNER +10V10V SYSTEM CONTROLLER
SYSTEM CONTROLLER
IC1101(1/3)
DO
73
SLATCH
74
TUNER-DATA
17
T.SERIAL CLK
16
STEREO
76
TUNED
75
MUTE
78
FM SIG OUT RDS_SIG
43
RDS_INT RDS_CLK
52
RDS_DATA RDS_DATA
53
COAXIAL
OPTICAL
DIGITAL VIDEO 1
IN
OPTICAL
IN
IC1352
DIN0
3
OPTICAL
ANTENNA
AUTO CAL MIC
D1301
D1113 D1114
D1112
IC400
SDA SCL
EEPROM
IC1131
Q471
+3.3V REG
INL4
4
INL5
2
26
DVDD
SB
AY
INL3
6
INL2
8
9
PCM1800_RST
57
AEP,UK, RU
IC203
VIDEO AMP
IC807
+5V REG
11
12
M
V3
4
S2
2
S2
13
888786
S1
VIDEO IN
J201
(1/2)
J202
(1/2)
VIDEO 1
VIDEO IN
VIDEO 2 VIDEO IN
DVD 1V1
3V2
10
MON MONITOR
+ V
J201(2/2)
VIDEO OUT
8
+5V
IC804
-5V REG - V
14
-5V
J251
(1/2)
Y
PR/CR/R-Y
PB/CB/B-Y
Y
DVD
IN
VIDEO 2
IN
COMPONENT
VIDEO
PR/CR/R-Y
PB/CB/B-Y
CH1 IN2
3
CH2 IN2
9
CH3 IN2
14
CH1 IN3
5
CH2 IN3
11
CH3 IN3
12
SW1
2
SW2
4
CH1 OUT 22
CH2 OUT 20
CH3 OUT 18
Y
PR/CR
/R-Y
PB/CB
/B-Y
MONITOR
OUT
CONPONENT
VIDEO
J251
(2/2)
VIDEO AMP
IC251
5
VOUT VIDEO 1
J202(2/2)
VIDEO OUT
VIDEO 1
J401(2/2)
AUDIO OUT
32
SWOUT
IC1403
31
IC1405
57
IC1404
31
IC1404
57
Ver. 1.2

1515
STR-DE400
STR-DE400
3-2. BLOCK DIAGRAM – DISPLAY/POWER SECTION –
• R-CH is omitted due to same as L-CH.
• Signal Path
: FM
IN2
8
12
+V OUT2
POWER AMP
IC501
POWER AMP
IC601
9
NF2
LIMITER
Q501,502
11
-V OUT2
IN2
12
+V OUT2
9
NF2
11
-V OUT2
BOOSTER
Q503
BOOSTER
Q504 CURRENT
DETECT
Q505,506
AF POWER
PROTECT
Q507
LIMITER
Q601,602
BOOSTER
Q603
BOOSTER
Q604 CURRENT
DETECT
Q605,606
IN2
8
12
+V OUT2
POWER AMP
IC701
9
NF2
LIMITER
Q701,702
11-V OUT2
BOOSTER
Q703
BOOSTER
Q704 CURRENT
DETECT
Q705,706
D883
PROTECT
SWITCH
Q881-883
RELAY
DRIVE
Q509
RY502
RELAY
DRIVE
Q508
RY501
RELAY
DRIVE
Q608
RY601
RELAY
DRIVE
Q708
RY701
L
RR-CH
R-CH
PHONES
TM600(1/2)
TM600(2/2)
61
PROTECTOR
62
HP RY
66
FRONT RY
68
REAR RY
67
C/SW RY
RV102
ENCODER
3 1
VOL_ENC(B)
65
VOL_ENC(A)
64
POWER KEY
56
?/1
S152
77
RSTX
48
STOP
54
SIRCS
63
FUSE DETECT
REMOTE
CONTROL
RECEIVER
1
IC102
D910-913
AC
IN
T902
RY901
D915D914
RELAY
DRIVE
Q901
D920-923
23
VCC5
84
VCC3
–7V
REG
3 2
+7V
REG
1 3
AUDIO
+7V
IC821
IC822
POWER RY
58
RELAY
+B
D804-807
82 83
X0
X1
X1101
24MHz
F1
F2
L
SLSL
C
A
SW
J700
FLUORESCENT
INDICATOR TUBE
FL101
59
FL_DATA
60
FL_CLK
47
FL_LAT
7
DIN
8
CLK
9
STB
14 29
SEG1-16
42 31
GRID1-12
F1 F2
FL DRIVE
IC100
FUNCTION
KEY
A/D0
38
S100-108
S131-139
FUNCTION
KEY
A/D1
39
S110-116
FUNCTION
KEY
A/D2
40
SYSTEM CONTROLLER
IC1101(3/3)
AF POWER
PROTECT
Q607
AF POWER
PROTECT
Q707
IC850(1/2)
21
FRONT
R
L
R-CH
TM602
SURROUND
IC850(2/2)
57
55
HP DETECT
BUFFER
IC101
35
AVCC
+3.3V
REG
3 1
IC1904
AUDIO
–7V
+10V
REG
3 1
TUNER
+10V
IC1902
+3.3V
REG
3 1
TUNER
+3.3V
IC1071
T901
Q911
AC DET
1 2
IC1111
D811
R803
+B
–B
–B
SWITCH
Q851,852
–20V REG
Q801
FL101
–20V
POWER AMP
–B
+5V
REG
3 1
IC1031
+5V
+2.5V
REG
5
+2.5V
+3.3V
REG
2
4
IC1901
+3.3V
+5V
REG
3 1
IC1001
AUDIO
+5V
SPEAKERS
IMPEDANCE USE 6-16Ω
MASTER
VOLUME
8
RESET
+3.3V(STBY)
MAIN
SECTION
(Page 14)
CENTER
RELAY
DRIVE
Q560
RY702
AUDIO OUT
J403
SUB WOOFER
AEP,UK, RU
Ver. 1.1

1616
STR-DE400
STR-DE400
3-3. PRINTEDWIRING BOARD – DIGITAL BOARD (SIDE A) – :Uses unleaded solder.
• See page 13 for Circuit Boards Location.
IC1301
IC1303
IC1502
IC1101
IC1111
IC1131
IC1503
IC1401
IC1452
IC1501
VIDEO
BOARD
CNS250
(Page 30)
IC1403 IC1405
IC1404
112
36
37
25
48
24
13
1
45
81
4
5
81
45
8
AEP,UK,RU
AEP,UK,RU
KR,TH,TW,
AUS
1
5
1
12
36
25
13 24
48
37
1
30
31
90
91
120
61
60
13
45
12
A
B
C
D
E
34567
M
CNS509
R1318
R1316 R1315
R1313
R1312
R1311
C1251 C1253
C1063
C1913
R1520 R1522 R1518
R1135
R1068
R1113
R1134
R1140
R1067
R1119
R1042
X1101
R1554 R1553 R1525 R1526
R1150
R1065
R1537
R1044
R1551 R1550 R1549 R1548
FB1308
R1112
R1175
R1059
R1107
R1035
C1107
R1108
R1524
R1109
R1547
R1544
R1545
R1542
R1572
R1571
R1539
R1538
R1534
R1533
R1540
R1536
R1535
R1136
R1041
R1115
D1001
R1058
R1127
R1105
R1106
R1097
R1083
R1636
C1605
R1072
R1073
R1459
R1458
R1179
R1159
R1186
R1122
R1123
R1129
R1124
R1094 R1095
R1190 R1128
R1076
R1088
R1635
R1082
R1071
R1078
R1180
C1123
C1124
C1122
C1620
C1495 R1077
C1516
R1546
X1301
C1315
R1352
R1353
C1302 C1301
R1304
R1303
R1301
D1302
R1305 JR1511
FB1306
R1358
C1360
R1359
R1307
R1308
C1522
R1501
C1521
R1541
C1511
R1515
R1521 R1519 R1517 R1552
R1574
R1573
FB1502
FB1305
R1360 R1306
JR1020
C1310
C1309
R1356
C1361
C1357
R1357
R1502
R1504
C1405
R1402
R1470
R1471
R1484
C1487
R1472
R1475
C144
R1426
R1436
R1466
R1425
R1445
FB1405
R1407
R1403
C1408
R1474
C1401
R1556
R1401
R1461
C1002
FB1452
C1566
R1476
C1432
R1464
C1422 R1168
C1147
C1148
R1446 R1486
R1460
R1503
R1509
R1523
R1531
R1506
R1505
FB1503
C1494
JR1502 R1555
R1155
R1161
R1162
R1435
R1508
R1510
R1151
R1149
R1160
R1154 R1152 R1153
R1143
R1144
R1121
R1142
R1137
R1120
R1570
R1528
R1527
R1543
R1511
R1532
R1066
C1303
C1304 R1310
R1309
X1502
D1301
R1362
R1363
Ver. 1.2
• Semiconductor
Location
Ref. No. Location
D1001 C-5
D1301 C-3
D1302 C-2
IC1101 D-5
IC1111 D-6
IC1131 E-5
IC1301 C-2
IC1303 D-2
IC1401 E-2
IC1403 E-3
IC1404 E-4
IC1405 E-4
IC1452 E-3
IC1501 D-4
IC1502 C-4
IC1503 E-4

1717
STR-DE400
STR-DE400
3-4. PRINTEDWIRING BOARD – DIGITAL BOARD (SIDE B) –
• Semiconductor
Location
Ref. No. Location
D1003 D-7
D1004 D-7
D1107 C-3
D1110 C-3
D1111 C-3
D1112 D-6
D1113 D-6
D1114 D-7
IC1001 F-6
IC1031 B-3
IC1071 B-5
IC1352 C-7
IC1353 C-7
IC1901 C-3
IC1902 B-4
IC1904 C-3
:Uses unleaded solder.
• See page 13 for Circuit Boards Location.
D E
STANDBY
BOARD
CNP801
(Page 26)
G
MAIN
BOARD
CNP501
(Page 21)
F
C
MAIN
BOARD
CNP502
(Page 21)
DISPLAY
BOARD
CNS100
(Page 27)
B
MAIN
BOARD
CNP503
(Page 21)
A
MAIN
BOARD
CNP503
(Page 21)
MAIN
BOARD
CN504
(Page 21)
TN1
TUNER UNIT
IC1901
IC1904
IC1031 IC1902
IC1353
IC1352
IC1001
IC1071
VIDEO 2
IN
VIDEO 1
IN
DVD IN
COAXIAL
DIGITAL
OPTICAL
1
2
3
5
1
1
4
5
AEP,UK,RU
AEP,UK,RU
3
1
KR,TH,TW,AUS
1
5
6
8
12
A
B
C
D
E
F
3456789
11
1
3
3
1
3
3
3
1
3
1
C1905
C1031
CNP505
C1914
JR1202
R1201
C1908
C1906
D1107
D1110
D1111
C1021
C1032
C1022
C1103
C1102
C1137
C1138
R1189
C1299
C1255
C1130
C1129
R1039
C1604
C1120
R1099
C1525
C1502
R1493
R1463
R1473
R1444
R1492
CNS501
C1428
R1495
R1434
C1403
C1404
J1301
C1504
C1506
R1513
C1491
C1513
R1514
C1509
C1517
C1518 C1312
R1302
C1308
C1306
C1358
C1353
C1355
C1510
C1519
C1064
CNS508
R1252
R1251
R1260
R1261
FB1302
FB1501
C1515
FB1453
C1005
C1473
R1494
R1424
C1254
C1206
R1163
CNS502
C1142
R1096
R1187
FB1101
CNS505
CNP504
C1108
C1140 C1100
C1568 C1462
C1463
C1423
C1567
C1569
C1468
C1438
C1547
C1454
C1450
C1460
C1472
C1433
R1491
R1483
C1483
C1481
C1442
C1448
C1458
R1164
R1167
C1418
C1121
R1118
C1139
C1149
R1193
R1157
R1156
C1119
R1194 C1118
R1117
R1049
C1501
C1514
R1512
D1114
R1198
C1520
C1252
C1313
R1314
C1314
C1352
C1305
C1359
D1004
D1112
D1113
C1004
D1003
R1355
C1362
C1356
C1409
C1402
C1457
C1001
C1406
C1407
C1507
C1505
C1503
C1508
CNP503
Ver. 1.2

1818
STR-DE400
STR-DE400
3-5. SCHEMATIC DIAGRAM – DIGITAL BOARD (1/3) – • See page 13 forWaveforms. • See page 32 for IC Block Diagrams.
19
20
20
No mark : FM
1
2
X1301
R1574
R1517
R1518
R1519
R1520
R1521
R1522
R1525
R1526
R1546
R1547
R1548
R1549
R1550
R1551
R1552
R1553
R1554
R1514
R1508
R1503
R1356
R1358
R1357
R1307
R1309
R1303
R1301
R1528
R1527
R1355
C1310
C1304
C1302
C1360
R1556
C1359
C1517
R1313
R1304
R1501
R1502
R1504
R1505
R1506
R1509
R1149
R1044
R1161
R1160
R1121
R1310
R1515
R1318
C1357
R1302
C1356
C1306
TP1003
TP1005
TP1018
C1314
C1315
C1301
C1303
C1305
C1362
C1308
C1516
C1518
C1520
C1519
C1510
C1501
C1503
C1506
C1504
C1505
C1355
C1511
X1502
JR1502
R1305
R1306
C1004
C1005
IC1501
JR1511
R1353
IC1353
R1311
TP1004
R1308
R1360
FB1302
R1544
C1313 R1316
FB1502
R1315
R1312
R1314
C1312
FB1306
C1358
C1309
FB1305
FB1501
R1512
C1522
C1521
R1523
R1513
R1198
R1555
TP1009
TP1008
TP1010
TP1012
TP1015
R1510
C1525
R1534
C1507
R1573
R1531
R1545
C1508
R1543
R1542
R1571
R1572
R1570
R1136
C1515
C1513
C1514
R1041
R1042
R1140
R1134
R1135
C1353
C1361
R1359
R1150
R1541
C1502
R1511
R1533
R1532
C1509
R1540
R1539
R1538
R1537
R1536
R1535
C1352
J1301
IC1301
D1004
D1003
IC1303
D1302
D1301
JR1020
IC1502
IC1503
FB1503
D1112 D1113 D1114
R1363
TP1011
12.288MHz
10k
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
10k
100
220
1k
560k
22k
100
100
33k
5.6k
220
220
75
18p
0.01
0.01
47p
100
1000
6.3V
470
10V
100
100
100
100
100
100
100
100
100
100
100
100
100
1M
1M
10k
1p
4.7k
0.01
47
16V
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
C1206
0.022
0.1
0.1
0.1
22
25V
0.1
13.9MHz
0
680
22
0.1
0.1
CXD9862R
0UH
100
R1362
100
R1352
100
TORX147L
IC1352
TORX147L
100
100
100
220
100p 100
100
100
10k
0.1
0.1
18p
1k
27p
27p
220
10k
100k
220
100
470
10V
220
0.1
10k
220
220
0.1
220
220
10k
10k
10k
100
470
10V
0.1
0.1
100
100
100
100
100
0.1
0.1
100
100
220
0.1
100
220
220
0.1
220
220
220
220
220
220
0.1
LC89056W-E
1SS367-T3SONY
1SS367-T3SONY
TC7WU04F(TE12R)
1SS355WTE-17
1SS355WTE-17
0
IS61LV6416-10TLT
TC7WH157FU (TE12R)
1SS367-T3
SONY 1SS367-T3
SONY 1SS367-T3
SONY
100
Ver. 1.2

1919
STR-DE400
STR-DE400
3-6. SCHEMATIC DIAGRAM – DIGITAL BOARD (2/3) – • See page 32, 33 for IC Block Diagrams.
22
20
18
No mark : FM
C1001
C1002
C1460
C1457
C1403
C1407
C1491
R1474
TP1
R1403 R1407
C1454
C1494
C1405
C1408
C1409
R1402
R1401
C1404
C1402
FB1405
C1401
FB1452
C1450
FB1453
CNS501
R1475
R1472
R1471
R1493
R1494
R1495
IC1452
IC1401
IC1001
C1406
470
10V
0.1
10
50V
10
50V
10 50V
4.7
50V
10
50V
10k
10k
R1460 0
R1492 6.8k
R1461 0
R1491 6.8k R1470 6.8k
100
0.1
0.1
470p
470p
0.1
2.2k
1k
0.1
47
16V 0.1
0.1
15P
PCM1602APT
PCM1800E/2K
TA7805S
4.7
50V
0
0
0
6.8k
6.8k
6.8k
R1424
R1463
R1434
R1444
R1483
C1438
C1428
C1458
C1418
C1448
R1486
R1446
R1436
R1466
R1426
C1487
C1547
C1566
C1569
C1568
C1567
R1445
R1435
R1464
R1425
C1423
C1422
C1463
C1462
C1433
C1432
C1442
C1441
C1483
C1481 R1473
C1473
C1472
IC1403
IC1404
IC1405
R1476 C1468 R1484
6.8k
6.8k
6.8k
6.8k
6.8k
10
50V
10 50V
10 50V
10 50V
10
50V
22
22
1k
1k
22
0.0022
0.0022
0.0022
0.0022
0.0022
0.0022
0
0
00
330p
680p
330p
680p
330p
680p
330p
680p
680p
330p 6.8k
330p
680p
NJM4565M(TE2)
NJM4565M(TE2)
NJM4565M(TE2)
1k 10 50V 0
Ver. 1.2

2020
STR-DE400
STR-DE400
3-7. SCHEMATIC DIAGRAM – DIGITAL BOARD (3/3) – • See page 13 forWaveform. • See page 32 for IC Block Diagram. • See page 36 for IC Pin Function Description.
18
19
31
23
18
24
24
23
29
22
VIDEO
CNS250 M
No mark : FM
8
+3.3V REG
IC 1071 TA78033LS AEP,UK,RU
KR,TH,TW,AUS
AEP,UK,RU
AEP,UK,RU
AEP,UK,RU
AEP,UK,RU
AM
FM
COAXIAL
75Ω
IC1071
∗
∗
KR,TH,TW,AUS
TN1
R1118
R1187
R1251R1252
R1049
R1119
R1159
C1255
C1137
C1032
C1022
R1097
R1162
R1144
R1143
R1152
R1153
R1154
R1155
R1122
R1123
R1129
R1077
R1078
R1190
R1189
C1914
R1524
C1252
C1253
C1021
C1031
C1905
C1107
C1108
C1102
C1605
C1604
C1118
C1122
C1123
C1139
JR1202
R1108
IC1031
FB1308
R1076
C1254
R1082
C1147
C1148
C1495
CNS508
CNS505
R1164
R1194
R1186
R1105
R1156
R1157
C1129 C1130
R1071
C1119
C1120
R1072 R1073
R1117
C1124
R1107
R1109
C1251
R1106
R1083 R1095
R1115
R1124
FB1101
R1128
R1127
CNP504
R1094
C1138
C1140 R1039
X1101
C1299
C1149
R1096
CNP503
R1112
CNP505
R1201
R1113
R1261
R1120
R1137
R1142
R1151 R1168
C1121
C1142
C1620
R1636
C1103
R1035
CNS502
R1167
D1107
D1111
D1110
IC1902
C1913
IC1901
C1906
C1908
IC1904 D1001
R1635
R1179 R1459
R1458
R1180
R1088
IC1131
R1163
IC1111
IC1101
R1260
C1100
1k
10k
39k39k
10k
1k
3.3k
220p
0.01
470
10V
470
10V
100k
100
100
100
100
100
100
100
100
100
100
100
100
10k
10k
47
C1063
0.1 16V
C1064
16V
0
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
2.2k
TA7805LS
100
R1175 100
220p
100
220p
220p
220p
19P
10k
10k
0
0
0.01 0.01
3.3k
R1193
47k
0.1
4.7
0.01
3.3k 3.3k
1k
0.1
2.2k
2.2k
0.1
100
10k
100
100
100
100
5P
0.1
0.1
10k
24MHz
0.1
220p
10k
5P
CNS509
5P
100
8P
22k
100
R1059
220
R1058
220
1k
1k
100
R1065 100
R1066 100
R1067 100
R1068 100
100
100
100
0.1
0.1
0.1
2.2k
47 16V
2.2k
10P
100
1SS355WTE-17
1SS355WTE-17
1SS355WTE-17
TA7809S
0.1
SI-3008KWFE
470 10V
470 10V
BA33BCOT 1SR154-400TE-25
2.2k
10k 10k
10k
10k
10k
BR24L16F-WE2
S-80929CNMC
-G8ZT2G
MB90488BPF-G
-216E1
1k
0.1
0
10k
10k
47k
R1194 2.2k:AEP,UK,RU
4.7k:KR,TH,TW,AUS
CNS508
11P:KR,TH,
TW,AUS
15P:AEP,UK,RU
47
∗
∗
Ver. 1.2
