Sony STR-KM5 User manual

SERVICE MANUAL
Sony Corporation
Audio & Video Business Group
Published by Sony EMCS (Malaysia) PG Tec
STR-KM5/KM7
MULTI CHANNELAV RECEIVER
9-890-588-07
2014C80-1
© 2014.03
US Model
E Model
STR-KM5
Argentina Model
Saudi Arabia Model
South African Model
STR-KM5/KM7
Australian Model
Singapore Model
STR-KM7
Ver. 1.6 2014.03
• STR-KM5 is the receiver section in HT-M5.
• STR-KM7 is the receiver section in HT-M7.
– Continued on next page –
Photo: STR-KM7
This receiver incorporates Dolby* Digital and Pro Logic Surround and the DTS** Digital Surround System.
* Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.
** Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535 & other U.S. and worldwide patents issued & pending.
DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS Digital Surround | 96/24 is a trademark of DTS, Inc. Product
includes software. © DTS, Inc. All Rights Reserved.
This receiver incorporates High-Definition Multimedia Interface (HDMITM) technology.
HDMI, the HDMI logo, and HDMI High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
“x.v.Color (x.v.Colour)” and “x.v.Color (x.v.Colour)” logo are trademarks of Sony Corporation.
“BRAVIA” is a trademark of Sony Corporation.
“PlayStation” is a registered trademark of Sony Computer Entertainment Inc.
MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.
“WALKMAN” is a registered trademark of Sony Corporation.
MICROVAULT is a trademark of Sony Corporation.
Windows media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is
prohibited without the appropriate license(s) from Microsoft.
SPECIFICATIONS
Amplifier section
Power Output
• STR-KM7
Argentina model
Stereo mode output (rated) (6 ohms, 1 kHz, THD 1%)
120 W + 120 W1)
Surround mode output2) (reference) (6 ohms, 1 kHz,
THD 30%)
RMS output
FRONT: 255 W per channel1)
CENTER: 255 W1)
SURROUND: 255 W per channel1)
SURROUND BACK: 255 W per channel1)
Surround mode2) (reference) (4 ohms, 100 Hz,
THD 30%)
SUBWOOFER: 280 W per channel1)
Other models
Stereo mode output (rated) (6 ohms, 1 kHz, THD 1%)
120 W + 120 W1)
Surround mode output2) (reference) (6 ohms, 1 kHz,
THD 10%)
RMS output
FRONT: 216 W per channel1)
CENTER: 216 W1)
SURROUND: 216 W per channel1)
SURROUND BACK: 216 W per channel1)
Surround mode2) (reference) (4 ohms, 100 Hz,
THD 10%)
SUBWOOFER: 250 W per channel1)
1)Measured under the following conditions:
Area Power requirements
SAF, SP 240 VAC, 50 Hz
EA 127 VAC, 60 Hz
AUS, AR 230 VAC, 50 Hz
2) Reference power output for front, center, surround,
surround back speakers and subwoofers.
Depending on the sound field settings and the source,
there may be no sound output.
• STR-KM5
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
(US model only)
Front L + Front R:
With 6 ohm loads, both channels driven, from
50 Hz – 20,000 Hz; rated 100 watts per channel
minimum RMS power, with no more than 0.2%
total harmonic distortion from 250 milliwatts to
rated output.
US, Latin America andArgentina models
Stereo mode output (rated) (6 ohms, 1 kHz, THD 1%)
120 W + 120 W3)
Surround mode output4) (reference) (6 ohms, 1 kHz,
THD 30%)
RMS output
FRONT: 255 W per channel3)
CENTER: 255 W3)
SURROUND: 255 W per channel3)
Surround mode4) (reference) (4 ohms, 100 Hz,
THD 30%)
SUBWOOFER: 280 W per channel3)
Other models
Stereo mode output (rated) (6 ohms, 1 kHz, THD 1%)
120 W + 120 W3)
Surround mode output4) (reference) (6 ohms, 1 kHz,
THD 10%)
RMS output
FRONT: 216 W per channel3)
CENTER: 216 W3)
SURROUND: 216 W per channel3)
Surround mode4) (reference) (4 ohms, 100 Hz,
THD 10%)
SUBWOOFER: 250 W per channel3)

STR-KM5/KM7
2
SAFETY-RELATED COMPONENT WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
Design and specifications are subject to change without notice.
• Abbreviation
E12 : 220 - 240V AC area in E model
E51 : Chilean and Peruvian models
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
Ver. 1.5
Inputs
Analog Sensitivity: 800 mV/
50 kilohms
Digital (Coaxial) Impedance: 75 ohms
Outputs (Analog)
AUDIO OUT Voltage: 800 mV/
1 kilohm
Tone
Gain levels ±6 dB, 1 dB step
Reproduction frequency range:
28 Hz – 20,000 Hz
FM tuner section
Tuning range 87.5 MHz – 108.0 MHz
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Tuning range
Antenna (aerial) Loop antenna (aerial)
Video section
(HT-M7/HT-M5)
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
PB: 0.7 Vp-p, 75 ohms
PR: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
USB section
(except SAF, AR)
Supported bit rate* MP3 (MPEG 1 Audio
Layer-3):
32 kbps – 320 kbps, VBR
WMA: 48 kbps – 192 kbps
AAC: 48 kbps – 320 kbps
Area Tuning scale
10 kHz step 9 kHz step
USA, E51, AR 530 kHz –
1,710 kHz
531 kHz –
1,710 kHz
EA, SAF, AUS,
TH, E12, SP
– 531 kHz –
1,602 kHz
Supported USB device
Mass Storage Class
Maximum current 500 mA
following conditions:
240 V AC, 50 Hz
3)Measured under the
4)Reference power output for front, center, surround
speakers and subwoofers. Depending on the sound
field settings and the source, there may be no
sound output.
Area Power requirements
USA 120 V AC, 60 Hz
SAF, E51, E12
EA
AR, TH
127 V AC, 60 Hz
230 V AC, 50 Hz
Sampling frequencies*
MP3 (MPEG 1 Audio
Layer-3): 32 kHz/
44.1 kHz/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
* Compatibility with all encoding/writing
software, recording devices and recording
media cannot be guaranteed.
Transfer speed Full-speed
General
Power requirements
Area Power requirements
Power consumption (during standby mode)
0.3 W (When
“CTRL.HDMI” is set to
“CTRL OFF”)
Dimensions (width/height/depth) (Approx.)
430 mm × 178 mm ×
336 mm
(17 in × 7 1/8in ×
13 1/4in)
SAF, TH, SP 230 V AC – 240 V AC,
50/60 Hz
E51 120/220/240 V AC,
50/60 Hz
AR 220 V AC – 230 V AC,
50/60 Hz
EA 120 V AC – 127/220/230 V
AC – 240 V AC, 50/60 Hz
AUS 230 V AC, 50 Hz
E12 220 V AC – 240 V AC,
50/60 Hz
Power consumption 185 W (STR-KM7)
175 W (STR-KM5)
including projecting parts
and controls
Mass (Approx.)
(STR-KM7/STR-KM5)
10.2 kg (22 lb 8 oz)
USA 120 V AC, 60 Hz

STR-KM5/KM7
3
1. SERVICING NOTES................................................. 4
2. DISASSEMBLY
2-1. Disassembly Flow.............................................................. 6
2-2. Case.................................................................................... 6
2-3. Front Panel Block .............................................................. 7
2-4. Back Panel Block............................................................... 7
2-5. Main Block, SUB RECTIFIER Board............................... 8
2-6. Heatsink Block, MAIN Board,
SURR BACK AMP Board................................................. 9
3. TEST MODE.............................................................. 10
4. ELECTRICAL CHECK........................................... 12
5. DIAGRAMS
5-1. Block Diagram - TUNER/AUDIO Section -................... 13
5-2. Block Diagram - DIGITAL Section -............................... 14
5-3. Block Diagram - VIDEO Section -.................................. 15
5-4. Block Diagram - HDMI Section -.................................... 16
5-5. Block Diagram - KEY/DISPLAY/USB Section -............ 17
5-6. Block Diagram - POWER KEY Section -....................... 18
5-7. Printed Wiring Board
- DIGITALAUDIO Board (Side A) -.............................. 20
5-8. Printed Wiring Board
- DIGITALAUDIO Board (Side B) -.............................. 21
5-9. Schematic Diagram
- DIGITALAUDIO Board (1/4) -.................................... 22
5-10. Schematic Diagram
- DIGITALAUDIO Board (2/4) -.................................... 23
5-11. Schematic Diagram
- DIGITALAUDIO Board (3/4) -.................................... 24
5-12. Schematic Diagram
- DIGITALAUDIO Board (4/4) -.................................... 25
5-13. Printed Wiring Board - MAIN Board -............................ 26
5-14. Schematic Diagram - MAIN Board (1/4) -...................... 27
5-15. Schematic Diagram - MAIN Board (2/4) -...................... 28
5-16. Schematic Diagram - MAIN Board (3/4) -...................... 29
5-17. Schematic Diagram - MAIN Board (4/4) -...................... 30
5-18. Printed Wiring Board
- HDMI RE PC Board (Side A) -..................................... 31
5-19. Printed Wiring Board
- HDMI RE PC Board (Side B) -..................................... 32
5-20. Schematic Diagram - HDMI RE PC Board (1/2) -.......... 33
5-21. Schematic Diagram - HDMI RE PC Board (2/2) -.......... 34
TABLE OF CONTENTS
5-22. Printed Wiring Board - POWER AVIDEO Board -......... 35
5-23. Schematic Diagram - POWER AVIDEO Board -............ 36
5-24. Printed Wiring Board
- DISPLAY Board (Suffix-12) -....................................... 37
5-25. Printed Wiring Board
- DISPLAY Board (Suffix-21) -....................................... 37
5-26. Schematic Diagram
- DISPLAY Board (Suffix-12/-21) - ................................ 38
5-27. Printed Wiring Board - DCDC Board - ........................... 39
5-28. Schematic Diagram - DCDC Board - .............................. 40
5-29. Printed Wiring Board - LED BAR Board -...................... 41
5-30. Schematic Diagram - LED BAR Board - ........................ 41
5-31. Printed Wiring Board
- USB Board (EXCEPT SAF, AR) -................................ 42
5-32. Schematic Diagram
- USB Board (EXCEPT SAF, AR) -................................ 43
5-33. Printed Wiring Board
- SURR BACK AMP Board (KM7) -.............................. 44
5-34. Schematic Diagram
- SURR BACK AMP Board (KM7) -.............................. 45
5-35. Printed Wiring Board - TUNER1 Board - ....................... 46
5-36. Schematic Diagram - TUNER1 Board -.......................... 46
5-37. Printed Wiring Board - SUB RECTIFIER Board -.......... 47
5-38. Schematic Diagram - SUB RECTIFIER Board - ............ 47
5-39. Printed Wiring Board - POWER KEY Board -................ 48
5-40. Schematic Diagram - POWER KEY Board - .................. 48
5-41. Printed Wiring Board - THERMAL Board - ................... 48
5-42. Schematic Diagram - THERMAL Board - ...................... 48
6. EXPLODED VIEWS
6-1. Case Section..................................................................... 58
6-2. Front Panel Section.......................................................... 59
6-3. Back Panel Section .......................................................... 60
6-4. Chassis Section ................................................................ 61
6-5. Heatsink Section .............................................................. 62
7. ELECTRICAL PARTS LIST................................ 63
Ver. 1.5

STR-KM5/KM7
4
NOTE OF REPLACING THE IC2036 AND IC2811 ON
THE DIGITAL AUDIO BOARD
IC2036 and IC2811 on the DIGITAL AUDIO board cannot
exchange with single. When these parts on the DIGITAL AUDIO
board are damaged, exchange the entire mounted board.
NOTE OF REPLACING THE IC3500 AND IC3501 ON
THE HDMI RE PC BOARD
IC3500 and IC3501 on the HDMI RE PC board cannot exchange
with single. When these parts on the HDMI RE PC board are
damaged, exchange the entire mounted board.
SECTION 1
SERVICING NOTES
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscou-s (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
Special Component Notice
The components identified by mark 9contain confidential
information.
Strictly follow the instructions whenever the components are
repaired and/or replaced.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Ver. 1.5
Note: Refer to SUPPLEMENT-1 for adding SERVICING NOTES
(TROUBLESHOOTING)
MODEL IDENTIFICATION
–BACK PANEL–
Part No.
Model Part No.
KM7: SAF 4-299-205-0[]
KM7: EA 4-299-205-1[]
KM7: AUS 4-299-205-2[]
KM7: SP 4-299-205-4[]
KM7: AR 4-299-205-5[]
KM5: SAF 4-409-904-0[]
KM5: TH 4-409-904-1[]
KM5: EA 4-409-904-2[]
KM5: E12 4-409-904-3[]
KM5: E51 4-409-904-4[]
KM5: AR 4-409-904-5[]
KM5: US 4-409-904-6[]
DISPLAY BOARD DISCRIMINATION
In this set, the DISPLAY board has two suffix number.
The Suffix-12 is for KM5: E12, SAF, EA, TH, E51, AR / KM7
models. While Suffix-21 is for KM5: US model.
Repair after distinguishing each DISPLAY board suffix number to
doing the repair referring to the following.
– DISPLAY Board (Component Side) –
SUFFIX-12 : 1-885-352-12
SUFFIX-21 : 1-885-352-21
• Abbreviation
E12 : 220 - 240V AC area in E model
E51 : Chilean and Peruvian models
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model

STR-KM5/KM7
5
HDMI RE PC board
Extension jigs
(A-1870-129-A)
DCDC board
DIGITAL AUDIO board
Connect jig to the HDMI RE PC board (CN3510 (5P)),
DCDC board (CN1503 (13P)) and
DIGITAL AUDIO board (CN2502 (8P))
Connect jig to the POWER AVIDEO board (CN271 (12P)),
and DIGITAL AUDIO board (CN2103 (12P))
Connect jig to the MAIN board (CN300 (14P)), (CN301 (14P)) and
DIGITAL AUDIO board (CN2105 (14P)), (CN2104 (14P))
POWER AVIDEO board
Connect RCA cord/audio cord to the
DIGITAL AUDIO board (J2301
(DIGITAL COAXIAL BD/DVD IN)) and
POWER AVIDEO board (J210
(MONITOR VIDEO OUT))
MICOM (IC2105) ON DIGITAL AUDIO BOARD SERVICE POSITION
• In checking the MICOM (IC2105) on the DIGITAL AUDIO board, prepare a set of extension jigs (A-1870-129-A) which consists of
three extension cables and one RCA cord/audio cord (for grounding purpose).

STR-KM5/KM7
6
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
Note: Follow the disassembly procedure in the numerical order given.
2-2. CASE
3two screws
(+BVTP 3 u8)
4
4
2two screws
(+BVST 4 u8)
5case
1two screws
(+BVST 4 u8)
2-2. CASE
(Page 6)
2-3. FRONT PANEL BLOCK
(Page 7) 2-4. BACK PANEL BLOCK
(Page 7)
2-5. MAIN BLOCK, SUB RECTIFIER BOARD
(Page 8)
2-6. HEATSINK BLOCK, MAIN BOARD,
SURR BACK AMP BOARD
(Page 9)
SET

STR-KM5/KM7
7
1CN2504 (13P)
3wire (flat type)
(15 core) (CN2503)
2saranet cushion
4one screw
(+BVTP 3 u8)
4one screw
(+BVTP 3 u8)
5one screw
(+BVTP 3 u8)
5one screw
(+BVTP 3 u8)
6five screws
(+BVTP 3 u8)
9front panel block
8claw
8claw
7one screw
(+BVTP 3 u8)
(except SAF, AR)
(except SAF, AR)
2-3. FRONT PANEL BLOCK
2-4. BACK PANEL BLOCK
• Abbreviation
AR : Argentina model
SAF : South African model
• Abbreviation
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
1CN2501 (4P)
2CN1501
(3P)
3CN911 (4P)
4CNP902 (4P)
6five screws
(+BVTP 3 u8) 7one screw
(+BVTP 3 u8)
8seven screws
(+BVTP 3 u8)
qs back panel block
qa CN2104 (14P)
0CN2105 (14P)
(KM7)
9one screw
(+BVTP 3 u8)
(KM7)
5CNP903 (3P)
(KM5: E51, EA)
(KM7: EA)
Ver. 1.5

STR-KM5/KM7
8
2-5. MAIN BLOCK, SUB RECTIFIER BOARD
1two screws
(+BVTP 3 u8)
2two screws
(+BVTP 3 u8)
qd one screw
(+BVTP 3 u8)
qg two screws
(+BVTP 3 u8)
8two screws
(+BVTP 3 u8)
9SUB RECTIFIER board
0LOCK board
qk MAIN block
5CN932
(6P)
6CN931
(6P)
7CNP931 (5P)
qa CN951
(5P)
qs CN950
(5P)
qh two screws
(+BVTP 3 u8)
qj one screw
(+BVTP 3 u8)
qf clamp
3bracket, fan
4fan, DC
Ver. 1.4

STR-KM5/KM7
9
2-6. HEATSINK BLOCK, MAIN BOARD, SURR BACK AMP BOARD
Note: This illustration sees the MAIN board, SURR BACK AMP board from back side.
qs heatsink block
0two screws
(+BVTP 3 u8)
7two screws
(+BVTP 3 u8)
8bracket (L)
1CN405
(4P)
2CN953
(6P) 3CN954 (5P)
6SURR BACK AMP board
8bracket (L)
5two screws
(+BVTP 3 u8)
qa MAIN board
9Remove the
forty-two solders.
4Remove the
twelve solders.
(KM7)
(KM7)
(KM7)
I
I
G
G
H
H
Ver. 1.4

STR-KM5/KM7
10
SECTION 3
TEST MODE
FL CHECK MODE
All fluorescent segments are tested. When this test is activated, all
segments turn on at the same time, then each segment turns on one
after another.
Procedure:
1.
When pressing the [SURROUND SPEAKER] and [M-TURBO]
buttons, press the [?/1] button to turn on the main power.
2. All segments turn on.
L C R
SL S SR
SBL SB SBR
LH RH SW COAX OPT
HDMILFE DTS -ES NEO:6 USB
96/24
DTS-HD MSTR HI RES LBR LPCM
RDS
AAC
TrueHD
SLEEP
D.RANGE
ST
D
PL II
+ EX
MHz ft.
k Hz m
x z
dB
3. Turn the [INPUT SELECTOR] dial.
4. Test pattern 1 turn on.
LCR
SL SSR
SBL SB SBR
LH RH SW COAX OPT
HDMILFE DTS -ES NEO:6 S-AIR
96/24
DTS-HD MSTR HI RES LBR LPCM AAC
TrueHD
SLEEP
D.RANGE
PL+
ft.
k m
z
dB
5. Turn the [INPUT SELECTOR] dial once again.
6. Test pattern 2 turn on.
L R
S
SBL SBR
LH RH SW COAX OPT
HDMILFE DTS -ES NEO:6 USB
96/24
DTS-HD MSTR HI RES LBR LPCM
RDS
TrueHD
SLEEP
D.RANGE
ST
D
PL IIEX
MHz
Hz
x
7. Turn the [INPUT SELECTOR] dial once again. All segments
and LED turn off.
8. Every turning of the [INPUT SELECTOR] dial turns on each
segment one after another on the same order.
S.F. CLEAR MODE
The preset sound filed is cleared when this mode is activated. Use
this mode before returning the product to clients upon completion
of repair.
Procedure:
1. While pressing the [MUSIC] button, press the [?/1] button to
turn on the main power.
2. The message “S.F. CLEAR” appears and initialization is per-
formed.
PROTECTOR AUTO OFF
Procedure:
1. While depressing the [MOVIE] and the [GAMING]
buttons simultaneously, press the power [?/1] button to
turn on the main power.
2. “PROTEVER” appears.
HISTORY MODE
The state that the set is used is memorized.
Procedure:
1. While depressing the [SURROUND SPEAKER] and the
[GAMING] buttons simultaneously, press the [?/1] button to
turn on the main power.
2. “HISTORY” appears.
3. Each time the [↑] / [↓] buttons on the remote commander is
pressed, the item is switched in order as follows.
Items Display
Protector Count COUNT xx
Total Single Power On Time xxxxxHxx 01
Surround Speaker Position SURPOS X
Sound Field SND FLD
Input Function FUNCTION
Input Mode INP MODE
Digital Select DIG IN
Stream Information STREAM
Signal Configuration CO xxxxx
Headphone HP xxx
Volume VOL xx
Bass BASS xxx
Treble TREB xxx
Level FL/FR F xxxxxx
Level SL/SR S xxxxxx
Level CT/SW CWxxxxxx
Level BL/BR B xxxxxx
Total Power ON Time xxxxxHxx 02
Muting MUTE xxx
Power ON Counter (Rebox Test Mode) REBXxxxx
Protector Type PROTxxxx
Temperature Record TEM xxxx
VACS Step VACS xx
USER INITIALIZE MODE
All preset contents are cleared when this mode is activated. Use
this mode before returning the product to clients upon completion
of repair.
Procedure:
1. Hold the [?/1] for 5 seconds.
2. The message “CLEARING” appears on the display.
3. After a few seconds, “CLEARED” appears.
Ver. 1.1

STR-KM5/KM7
11
SOFTWARE VERSION DISPLAY MODE
The software version is displayed.
Procedure:
1. While pressing the [SURROUND SPEAKER] and [MUSIC]
buttons, press the [?/1] button to turn on the main power.
2.
The message “M5**Mx.xx” appears. This is main micropro-
cessor version (KM5).
The message “M7**Mx.xx” appears. This is main micropro-
cessor version (KM7).
**: destination, x.xx: software version
3. Press the [DISPLAY] button on the remote commander,
DSP firmware version
“S. VER x.xx” appears.
Sound tuning version
“M5 ST x.xx” appears (KM5).
“M7 ST x.xx” appears (KM7).
Tuner Version
“T.VER x.xx” appears.
SPDIF UPDATE MODE
User plays the CD that contains u-com/DSP data with CD/DVD
player.
Update u-com/DSP etc. firmware from SPDIF input.
Connection:
CD/DVD
player
DIGITAL board
COAXIAL BD/DVD IN jack (J2301)
set
Procedure:
Normal case
1. While pressing [MOVIE] and [M-TURBO] buttons, press the
[?/1] button to turn on the main power.
2. The messages “UPDATE” and “PLAY.DISC” are displayed
alternately every one second.
After this step, all user operation is prohibited except power
off. To cancel this mode, power off or AC power cord pull out
is required.
3. Connect CD player to COAXIAL BD/DVD IN jack (J2301 on
the DIGITAL board), and play update CD.
Update is started when DSP detect update signal. The message
“UPDATING” is displayed blinks every one second.
From this step, all user operation is prohibited. Power off is
also prohibited.
4. While main u-com is being updated, fluorescent indicator tube
is blacked out.
5. When update data error is detected or disc is not matched with
target model, error messages “DISC ERR” and “PLAY.DISC”
are displayed to restart playing valid CD.
When flash writing error is happened, error messages
“UPT. ERR” and “PLAY.DISC” are displayed to restart play-
ing CD.
6. When all update is finished, set is reboot automatically. After
reboot, complete message “COMPLETE” is displayed (dis-
played continuously until any user operation).
Procedure:
After update is abnormal exit, and set is power on again
1. Enter update mode automatically after power on.
2. The messages “UPDATE” and “PLAY.DISC” are displayed
alternately every one second.
From this step, all user operation is prohibited. Power off is
also prohibited.
If main u-com was failed to update, nothing is displayed.
3. Connect CD player to COAXIAL BD/DVD IN jack (J2301 on
the DIGITAL board), and play update CD.
Update is started when DSP detect update signal. From this,
same as normal case.
SPDIF UPDATE VERSION MODE
Function that displays the version number to check whether SPDIF
update is necessary or not.
Procedure:
1. While pressing [MOVIE] and [MUSIC] buttons, press the
[?/1] button to turn on the main power.
2. The message “VER X.XXX” is displayed. “X.XXX” is calcu-
lated by adding all firmware version.
Example:
(MAIN ver. + DSP ver. + SOUND TUNE ver. + 7)/10 =
Displayed version
MAIN = 1.02, DSP = 1.01, SOUND TUNE = 1.00
↓
(1.02 + 1.01 + 1.00 + 7)/10 = 1.003
1.003 = X.XXX

STR-KM5/KM7
12
SECTION 4
ELECTRICAL CHECK
FM AUTO STOP CHECK
signal
generator set
Procedure:
1. Turn on the set.
2. Input the following signal from signal generator to FM an-
tenna input directly.
Carrier frequency: A = 87.5 MHz, B = 98 MHz, C = 108 MHz
Deviation : 75 kHz
Modulation : 1 kHz
Note: Use 75 ohm coaxial cable to connect signal generator and the set.
You cannot use video cable for checking.
Use signal generator whose output impedance is 75 ohm.
3. Set to FM tuner function and scan the input FM signal with
automatic scanning.
4. Confirm that input frequency of A, B and C are detected and
automatic scanning stops.
When the station signal is received in good condition, automatic
scanning stops.

5-1. BLOCK DIAGRAM – TUNER/AUDIO Section –
SECTION 5
DIAGRAMS
C-CH
SR-CH
FR-CH
SL-CH
FL-CH
R-IN
L-IN
SW
SEL
C
SEL
SB
SEL
SL
SEL
R-CH
INR2
INL2
ROUT
LOUT
R-CH
R-CH
DIR
FUNCTION SELECT
IC300
VCCVEE
+7V
SEL
SW
MCU
I/F
-7V
SW OUT
SBL
SBR
C OUT
SLOUT
FLOUT
SYSTEM
CONTROL
IC2105 (1/5)
FM RECEIVER
IC101
CN102
CN104
CN103
EVOL_DATA
EVOL_CLK 98
97
12 8
10
62
11
75
14
13
18
17
SBR-CH
R-CH 19
SW-CH
16
7166 70 68 69
SR OUT
FR OUT
72 73 67
54
53
50
49
58
57
42
41
46
45
SBL-CH
20
15
76
25
26
L
SEL
14
6115
FRF1
ARF1
4
6
ARF2
7
X101
32.768kHz
19 18
X2 X1
+3.3V
+5V
+3.3V
REG 43
IC102
J301 (1/2) J300
-1 -2 -4 -5
-4 -5 -7 -8 J301 (2/2)
-1 -2
SA-CD/CD
AUDIO IN
L R
TV
AUDIO IN
L R
-7 -8
PORTABLE
AUDIO IN
L R
L R
VIDEO
AUDIO IN
L R
SAT/CATV
AUDIO IN
L R
VIDEO
AUDIO OUT
FM
AM
AM
&2$;,$/
FM
AM
ANTENNA EXCEPT KM5:US
KM5:US
6LJQDOSDWK
: TUNER (FM/AM)
: TUNER
5FKLVRPLWWHGGXHWR
VDPHDV/FK
DIGITAL
SECTION
(Page 14)
DIGITAL
SECTION
(Page 14)
POWER KEY
SECTION
(Page 18)
A
B
C
Ver. 1.5
STR-KM5/KM7
STR-KM5/KM7
1313

5-2. BLOCK DIAGRAM – DIGITAL Section –
Ver. 1.1
TUNER/
AUDIO
SECTION
(Page 13)
C
HDMI
SECTION
(Page 16) D
TUNER/
AUDIO
SECTION
(Page 13) AL-IN
R-IN
3 - 5
14 - 16
19 - 21
75, 97,103
6 - 9
74, 95,101
6LJQDO SDWK
: TUNER (FM/AM)
: DVD (DIGITAL)
R-FK LV RPLWWHG GXH WR
VDPH DV L-FK
R-CH
COAXIAL
BD/DVD IN
DIGITAL
OPTICAL
6AT/CATV
IN
J2301
OPTICAL
GAME IN X2800
25MHz
CN2508
12
13
16
11
14
7
9
10
21
18
15
44 13 45
73
94
86
X2801
24576MHz
CLKIN
6BL/6BRBOUT
6L/6RBOUT
C/6:1BOUT
L/RBOUT
24
XTAL2
25
92
BCLKBOUT
MCLKBIN 98
LRCLKBOUT
6PICLK
Y0
B0 Y3
Y1
6EL
MO6I
MI6O
IRQ/GPIO FLAG1 FLAG2
99
70 71 68
31
32
88 89
37 38
INPUT DATA
DEMODULATOR
PD,PEDETECTION LOCK
DETECTION
MICROPROCE66OR
I/F
C ELW DETECTION
15
1
OUT
1
8
96
CKA
Q4B
DIGITAL OPTICAL
RECEIVE
IC2352
DIGITALAUDIO
INTERFACE RECEIVER
IC2806 (1/2)
23
:AVE 6HAPER
IC2303
IC2010
81
18
33V
REG
12V VDDI
33VVDDE
33V
TEMPB6EN6ORB1
VDD
33V +4V
+11V REG
IC2813
+11V +4V
VOUT VIN
D6P
IC2801 (1/2)
COMBCLK
57
HDMIB6CL
COMBDATA
6CK COMBCLK
6I COMBDATA
63
58
TH251
6ELECTOR
IC3527
28
+33V
RE6ET 6IGNALGENERATOR
IC2034
12
+33V
D2722
D2723
TH252
26
TEMPB6EN6ORB2
27
XOUT
RXIN1
COAXIAL
RXIN6
OPTICAL6AT/ CATV
D6P LRCKLRCKOUT
1
OUT
IN2 OUT3
DIGITAL OPTICAL
RECEIVE
IC2351
59
RXIN5
OPTICALGAME
XIN
6Y6TEM
CONTROL
IC2105 (2/5)
1114
94
18
19
20
652
95
MUTE
LAT
MUTE M/LAT
12
MC/CLK
13
MD/DATA
DIN3
DIN4
FLOUT
R-CH
VO3L
VO3R
VO2L
VO2R
VO1L
VO1R
926
25
7
2MCK
3BCK
LRCK
4
D/ACONVERTER
IC2123
DAC
DIN2 C OUT
R-CH
23
DAC
DIN1 6L OUT
21
6: OUT
22
DAC
DAC
D6P
69
RXIN3 HDMI 6PDIF
ADINR
ADINL
D6P MCK MCKOUT
CEC 6:ITCH
IC2811
134
135
136
13 3
11
10
8
6
4
1
2
10 DAC VO4L
VO4R 20
19 6BLOUT
8
2
5
1
6CHMITTRIGGER
IC2009
6IGNAL
6ELECTOR
IC2032 (1/2)
EEPROM
IC2802
CN2506
4
5
6
FLA6H
PROGRAMMING
CN2509
4
5
6
FLA6H
PROGRAMMING
12
4
7
1
3
3Y
9
3A
11
CECBIN
CEC CECBOUT 2
1
4
MUTING
IC2804
BINARY
COUNTER
IC2007
3
3
61
RXIN4ARC 6PDIF
60
4746
HDMIBCECIN
HDMIBCECOUT
D6PBMI6O
D6PBMO6I
D6PB6PICLK
6EL
NPCM
ERROR
INT
F6RATE
60
6O
61
FLA6HBCLK
62
UARTB6EL
59
6I
88
38
39
40
UARTBOUT 49
UARTBIN 50
6CK
6I
6O
173
RE6ET A3 Y0
Y3
Y1
Y2
A2
A1
A0
B0
CK D
Q
6IGNAL6ELECTOR
IC2805
MUTE
6:ITCH
Q2706
1
6ELECT
24
STR-KM5/KM7
STR-KM5/KM7
1414

5-3. BLOCK DIAGRAM – VIDEO Section –
14
13
5
7
1
75ȍ
DRIVER
6dBAMP
15
75ȍ
DRIVER
6dBAMP
COMPO_SW2
V_SEL2
V_MUTE
V_SEL1
COMPO_SW2
V_SEL2
V_MUTE
V_SEL1
SYSTEM CONTROL
IC2105 (3/5)
-5V -5V-3
+5V +5V-3
VOUT1
VOUT2
VIN1
VIN4
VIN3
V_SEL2 SW1
2
SW5
10
SW2
INPUT SELECT
IC210
CH1 IN2
CH2 IN2
CH3 IN2
CH1 IN3
CH2 IN3
CH3 IN3
4SW2
COMPO_SW2
6dBAMP
6dBAMP
6dBAMP
23
PS
V_MUTE
COMPONENT VIDEO SELECT
IC220
83
84
85
86
V_SEL1
D202
3
5
10
15
13
12
CH1 OUT
CH2 OUT
CH3 OUT
24
22
20
V-1,-2 -5V-3
V+1,+2+5V-3
75ȍ
DRIVER
75ȍ
DRIVER
75ȍ
DRIVER
Y
PB
PR
Y
PB
PR
J220 (1/2)
BD/DVD
IN
GAME
IN
COMPONENT
VIDEO
5
6
7
-1
-2
-3
J211 (1/2)
J210 (1/2)
Y
PR
PB
J220 (2/2)
MONITOR
OUT COMPONENT
VIDEO
9
10
11
J210 (2/2)
J211 (2/2)
VIDEO
VIDEO IN
SAT/CATV
VIDEO IN
MONITOR
VIDEO OUT
VIDEO
VIDEO OUT
-3
-1
-3
-1
SLJQDO SDWK
: VIDEO
STR-KM5/KM7
STR-KM5/KM7
1515

5-4. BLOCK DIAGRAM – HDMI Section –
125 R1X2+
DATA2+
DATA2–
DATA1+
DATA1–
DATA0+
DATA0–
CLOCK+
CLOCK–
SCL(5V)
SDA(5V)
HOT PLUG DET
CEC
+5V POWER
DATA2+
DATA2–
DATA1+
DATA1–
DATA0+
DATA0–
CLOCK+
CLOCK–
SCL(5V)
SDA(5V)
HOT PLUG DET
CEC
+5V POWER
DATA2+
DATA2–
DATA1+
DATA1–
DATA0+
DATA0–
CLOCK+
CLOCK–
SCL(5V)
SDA(5V)
HOT PLUG DET
CEC
+5V POWER
R1X2-
R1X1+
R1X1-
Q0
I
Q35
D0
I
D35
R1X0+
R1X0-
R1XC+
R1XC-
DSCL1
124
123
122
121
120
119
118
35
134 R2X2+
R2X2-
R2X1+
R2X1-
R2X0+
R2X0-
R2XC+
R2XC-
133
132
131
130
129
128
127 DSCL2
DSDA2
39
40 HPD2
R3X2+
R3X2-
R3X1+
R3X1-
R3X0+
R3X0-
R3XC+
R3XC-
DSCL3
DSDA3
HPD3
38
TX2+
TX2-
TX1+
TX1-
TX0+
TX0-
TXC+
TXC-
DSCL
DSDA
HPD
40
39
37
36
34
33
31
30
46
47
51
DSDA1
HPD1
36
34
DE
73
VSYNC 74
73
HSYNC 75
SCK/DCLK 100
WS/DR0 99
SD0/DL0 101
SD1/DR1 102
SD2/DL1 103
SD3/DR2 104
SPDIF/DL2 106
1
DE
VSYNC
HSYNC
DL2
48 CSCL
CSDA
49
21
MCLK
5
DR2
20
DL1
19
DR1
18
DL0
17
DCLK
15
DR0
16
R1PWR5V33
R2PWER5V37
R3PWR5V41
IC3500
HDMI RECEIVER
IC3501
HDMI TRANSMITTER (1/2)
23
24
IC3501
HDMI TRANSMITTER
(2/2)
CSDA
CSCL
DATA2+
DATA2–
DATA1+
DATA1–
DATA0+
DATA0–
CLOCK+
CLOCK–
SCL(5V)
SDA(5V)
HOT PLUG DET
CEC
+5V POWER
8 2
+4V REG
IC1500
1 8
+1.83V
REG
IC3530
+1.8V
1 6
+3.3V
REG
IC3532
+3.3V
+5V
+13V
143
142
141
140
139
138
137
136
43
44
42
96-88,
85-77,
70-62,
59-51
98-90,
86-77,
75-67,
63-56
4
5
XTALOUT
XTALIN X3501
27MHz
1
4
5
IC3533
+5V REG
2
8
IC1600
+6 REG
+5V
+13V
+5V
5
4
IC3509
+5V REG
CN3512
DIGITAL
SECTION
(Page 14)
7
8
9
10
11
12
13
15
1
18
A6
7
A7
8
A2
3
A3
4
A4
5
A5
6
A8
9
A1
Y1
Y8
2
IC3507
BUFFER
18
17
16
15
14
13
12
11
3
1
2
DCCPWR5V
45
D3529
1 8
+1.2V
REG
IC3531
+1.2V D3515
CN3503
4
6
1
3
7
9
10
12
15
16
19
13
18
CN3502
4
6
1
3
7
9
10
12
15
16
19
13
18
CN3500
4
6
1
3
7
9
10
12
15
16
19
13
18
TV OUT
ARC
CN3501
4
6
1
3
7
9
10
12
15
16
19
13
18
HDMI
SAT/CATV
IN
GAME
IN
BD/DVD
IN
WS
10
SCK
11
SD0
9
SD1
8
SD2
7
SD3
6
SPDIF
4
6LJQDOSDWK
: DVD (DIGITAL)
: VIDEO
D
STR-KM5/KM7
STR-KM5/KM7
1616

5-5. BLOCK DIAGRAM – KEY/DISPLAY/USB Section –
92
FL DISPLAY DRIVER
IC100
14
I
29

31
93
99
100
5
6
30
12
11
51
53
54
X1(X_OUT)
X0(X_IN)
E2P_SDA
E2P_SCL
POWER_KEY
MD2
MD0
RST
SDA
SCL
EEPROM
IC2106
SIRCS
22
FL_DATA 7DIN
21
FL_LAT 9STB
23
FL_CLK 8CLK
GRID1
I
GRID11
SEG1
I
SEG17
VOL_JOG
INPUT_JOG
AD_KEY_2
AD_KEY_1
31
2REMOTE
CONTROL
SIGNAL
RECEIVER
IC102
OUT
SIRCS
+6.3V DCDC
SYSTEM
CONTROL
IC2105 (4/5)
MD2
MD0
RESET
61
60 FLASH_CLK
SO
59 SI
CLK
SO
SI
41
2
34
36
RESET SWITCH
IC2019
DSP
IC2801 (2/2)
42
I
32
30
VEE
1
SW1
2
SW2
3
SW3
OUTIN
IN
Q2006
1
37
VOUT
USB_OVC
EXCEPT SAF, AR
REGISTOR CONTROL
IC4102
62
RXIN2 USB SPDIF
DIGITALAUDIO
INTERFACE RECEIVER
IC2806 (2/2)
64 Vout
1
Vin
FAULT
USB POWER SWITCH
IC4101
1
2
OUT
VDD RESET SIGNAL
GENERATOR
IC2020
41 OUT_YGate
2In
MAIN RESET SWITCH
IC2033
DATAPROCESSOR
IC4100
44
MD
47
RESET_MAIN
SPDIF
33
USB-DM 34
40
53
41
USB-DP
XIN-PLL
IRPTO,
KEY-ROW1/MCHNG,
KEY-ROW3/SCL,
KEY-ROW4/SDA
USB_IPOD_REQ, USB_MCHNG, USB_SDA, USB_SCL
XOUT-PLL
13,12,10,8
39,48 - 50
IC4161
+3.3V
REG
+3.3V
+3.3V
STBY
+6.3V
DCDC
IC101
+3.3V
REG
+3.3V
CN4101
4
X2101
4MHz
X4102
16.9344MHz
CN2509
8
9
3
4
5
6
S100
_/1
SW NETWORK
S103-105
SW NETWORK
S101-102
T100
DC CONVERTER
TRANSFORMER
Q100
SWITCHING
TRANSISTOR
D120
D121
RV101
MASTER
VOLUME
2
3
RV100
INPUT
SELECTOR
2
3
ND100
VACUUM
FLUORESCENT
DISPLAY
D122
D123
SWITCHING
DIODE
INPUT LED
Q101 D100, D102 - D103,
D105, D107, D109
VOLUME LED
Q102 D139, D141 - D142,
D144, D146 - D147
BAR LED
Q103 D130, D132 - D133,
D135, D136, D138
FLASH
PROGRAMMING
D2019
3
4
2
D-
Vbus
D+
DATA
SWITCH
VD4170-
VD4171
D4107
E
ET4100
AbbUeYiation
SAF : SoutKAIUiFan PoGeO
AR :AUJentina PoGeO
STR-KM5/KM7
STR-KM5/KM7
1717

5-6. BLOCK DIAGRAM – POWER KEY Section –
62
3
DRIVE
PRE DRIVER
IC701
IN 1 +VOUT1
-VOUT2
812
11
IN 2 +VOUT2
-VOUT2
FL-CH
FR-CH
FL-CH
FR-CH
SL-CH
SW-CH
SR-CH
SL-CH
SR-CH
+3.3V
(STBY)
+5V
-5V
-7V
+7V
1
62
3
DRIVE
PRE DRIVER
IC601
IN 1 +VOUT1
-VOUT2
812
11
IN 2 +VOUT2
-VOUT2
25
+5V
(STBY)
-5V
REG
IC202
+3.3V
REG
IC2107
-15V
+15V
+7V
REG
IC951
+5V
REG
IC2812
-7V
REG
IC950
+5V
REG
IC201
+5V
+12V
REG
IC600
FRONT_SPK_A_RY SBL-SBR_RY C/SL-SR_RY PREOUT_SW_RY
PROTECTOR
IO_EX_CLK
IO_EX_LAT
IO_EX_DATA
IO_EX_OE
FUSE_DET
FAN_CTRL
82
SYSTEM
CONTROL
IC2105 (5/5)
PRE
DRIVE
62
3
DRIVE
PRE DRIVER
IC401 IN 1 +VOUT1
-VOUT2
812
11
IN 2 +VOUT2
-VOUT2
SBL-CH
SBR-CH
PRE
DRIVE
C-CH 62
3
DRIVE
PRE DRIVER
IC501
IN 1 +VOUT1
-VOUT2
PRE
DRIVE
PRE
DRIVE
62
3
DRIVE
PRE DRIVER
IC801
IN 1 +VOUT1
-VOUT2
812
11
IN 2 +VOUT2
-VOUT2
PRE
DRIVE
VOLTAGE
DETECTION
IC2421
SBL-CH
SBR-CH
2-4,15
11-14
10-8,3
SHIFT REGISTER
IC2036
R
L
L
CENTER
SURROUND
SUBWOOFER
R
TB355
TB353
TB354
FRONT
SPEAKERS
T901
POWER TRANSFORMER
(MAIN)
F901
F902
POWER TRANSFORMER
(SUB)
T902 AC IN ~
RECT
D952
F952
F953
F954
F955
RY901
D904
F950
F951
F911
F912
RECT
D953-956
RECT
D912
PROTECTOR
D862-863
Q863-867
D520 -
523
POWERAMP
Q700-703,
Q750-753
POWERAMP
Q401-404,
Q451-454
POWERAMP
Q500-503,
Q550-553
POWERAMP
Q600-603,
Q650-653
POWERAMP
Q800-803
RY353
RY354
RY351
RELAY
DRIVER
Q354
RELAY
DRIVER
Q351
RELAY
DRIVER
Q353
R
L
TB351
SURROUND
BACK
RY950
RELAY
DRIVER
Q950
D2110,
2302,
2303
RY355
RELAY
DRIVER
Q355
2
1
TB352
RY352
RELAY
DRIVER
Q352
CURRENT
DETECT
Q761,762
CURRENT
DETECT
Q711,712
CURRENT
DETECT
Q405,406
CURRENT
DETECT
Q455,456
CURRENT
DETECT
Q811,812
CURRENT
DETECT
Q561,562
CURRENT
DETECT
Q511,512
CURRENT
DETECT
Q661,662
CURRENT
DETECT
Q611,612
RELAY
DRIVER
Q901
Q280,
Q697,
Q699
FAN DRIVER
CN1501
CN1502
AC IN
DETECT
Q902
RECT
D902,D903
RECT
D932
F933
F932
F931
F934
RY931
230 - 240V
220V
120 - 127V
R
R
S901
VOLTAGE SELECTOR
RELAY
DRIVER
Q931
6LJQDOSDWK
: TUNER (FM/AM)
5FKLVRPLWWHGGXHWR
VDPHDV/FK
4
4
73
1
5 4
5 4
4 2
POWER_RY
80
STOP
TUNER/
AUDIO
SECTION
(Page 13)
B
SIGNAL
SELECTOR
IC2032 (2/2)
M1
(FAN)
M
M2
(FAN)
M
KM7
KM5: E51, EA
KM7: EA
$EEUHYLDWLRQ
E51 : &KLOHDQDQG3HUXYLDQPRGHOV
EA : 6DXGL$UDELDPRGHO
Ver. 1.5
STR-KM5/KM7
STR-KM5/KM7
1818

For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF)
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in and 1/4W or less unless otherwise
specified.
• f: internal component.
• 2: nonflammable resistor.
• 5: flusible resistor.
• C: panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
• A: B+ Line.
• B: B– Line.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : TUNER
• Voltages are taken with a VOM (Input impedance 10 M).
Voltage variations may be noted due to normal production
tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F: TUNER (FM/AM)
f: TUNER
E: VIDEO
J: DVD (DIGITAL)
• Abbreviation
E12 : 220-240V AC area in E model
E51 : Chilean and Peruvian model
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
For Printed Wiring Boards.
Note:
• X: Parts extracted from the component side.
• Y: Parts extracted from the conductor side.
• f: Internal component.
• : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• Indication of transistor.
C
BThese are omitted. E
Q
CEBThese are omitted.
Note: The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replace only with part number specified.
Caution:
Pattern face side:
(SIDE B)
Parts face side:
(SIDE A)
Parts on the pattern face side seen from
the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
Caution:
Pattern face side:
(Conductor Side)
Parts face side:
(Component
Side)
Parts on the pattern face side seen from
the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
• Abbreviation
E12 : 220-240V AC area in E model
E51 : Chilean and Peruvian model
AR : Argentina model
AUS : Australian model
EA : Saudi Arabia model
SAF : South African model
SP : Singapore model
TH : Thai model
• Circuit Boards Location
• Abbreviation
AR : Argentina model
SAF : South African model
SUB RECTIFIER board
POWER KEY board
LED BAR board
USB board
(except SAF, AR)
DISPLAY board
POWER AVIDEO board
SURR BACK AMP board
(KM7)
DCDC board
TUNER1 board
HDMI RE PC board
DIGITAL AUDIO boar
d
MAIN board
THERMAL board
Ver. 1.5
STR-KM5/KM7
STR-KM5/KM7
1919

STR-KM5/KM7
STR-KM5/KM7
2020
5-7. PRINTED WIRING BOARD – DIGITAL AUDIO Board (Side A) – • See page 19 for Circuit Boards Location. • : Uses unleaded solder.
Ver. 1.5
1
A
B
C
D
E
F
G
H
I
J
K
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
IC2106
IC2812
1100 8180
51
30
31
IC2105
50
IC2804
IC2036
IC2421
IC2007 IC2805
IC2123
IC2009
114
1528
IC2351 IC2352
IC2806
116
17
32
3348
49
64
IC2303
IC2813
133
132 88 89
45
44
1761
IC2801
177
IC2019
IC2033
IC2020
IC2802
IC2010
VCC O VCC O
R2860
R2861
R2863
R2864
R2865
R2866
R2867
R2868
R2099
R2872
R2875
R2876
RB2010
R2880
R2881
R2882
R2886
R2889
R2895
R2897
R2898
R2899
112
CN2103
CN2104
CN2105 111414
C2101
1
113
4
CN2501
18
CN2502
1215
14
CN2503
CN2504
16
CN2506
1221
20
CN2508
C2114
CN2509
19
C2501
C2119
C2502
C2503
C2504
C2507
C2121
C2125
C2126
C2127
R2100
C2128
C2512
R2105
R2107
X2800
C2130
R2109
X2801
C2901
C2131
D2302
D2303
D2110
C2136
C2137
C2909
R2111
R2112
R2116 C2140
C2912
C2913
FB2603 FB2604
R2311
C2917
FB2608
C2918
R2124
R2125
FB2031
FB2032 C2920
R2129
C2923
R2321 R2322
R2132
R2327
C2351
R2906
FB2043
D2717
C2354
D2719
C2355
C2358
C2359
D2720
D2721
D2722
R2912
D2723
D2724
C2361
R2725
R2919
R2726
R2727
R2728
R2729
C2370
R2925
R2732
R2733
R2540
R2158
R2735
R2541
R2159
R2929
R2736
R2351 R2354
R2930
R2932
R2356
R2933
R2357
R2358
C2961
C2962
C2963
C2964
C2965
C2966
C2967
R2940
C2968
R2941
C2969
R2172
R2173
R2945
R2947
R2948
C2970
R2949
C2972
C2973
C2974
C2975
R2759
C2976
C2977
C2978
R2957 R2958
R2959
R2960
R2962
R2963
RB2102
R2392
RB2103
RB2104
RB2105
RB2107
RB2109
FB2884
R2979
FB2885
FB2889
R2983
R2984
FB2890
R2985
FB2891
RB2119
R2986
FB2892
R2987
FB2893
FB2894
R2989
RB2121
RB2123
RB2124
RB2125
RB2126
R2992
RB2127
R2993
R2997
R2998
R2999
C2001
JL2808
JL2809
X2101
JL2811
JL2812
C2203
C2011
C2206
C2013
J2301
C2402
C2022
C2023
FB2101
C2413
C2609
R2006
R2007 C2418
C2421
C2422
D2018
C2424
R2015
C2619
FB2501
FB2502
C2814
R2211
C2815
C2816
C2818
R2601
R2602
R2607
C2823
C2248
R2220
C2825
C2826
R2802
R2610
R2809
R2615
R2421
R2617
R2618
R2619
C2838
C2069
R2815
R2621
R2622
R2816
C2070
C2841
C2459
R2626
C2842
C2266
C2072
C2074
C2846
C2847 C2849
R2052
R2824
R2825
R2249
C2465
R2826
C2466
C2273
R2058
C2274
C2468
R2829
R2059
C2469
C2858
C2470
R2831
R2834
R2835
R2837
R2838
C2860
C2861
C2863
C2864
C2865
C2866
C2096
C2868 C2869
R2843
R2846
R2847
R2849
C2873
C2875
C2876
C2877
R2851
R2852
R2854
R2855
R2856
R2857
R2858
R2859
C2881
C2883
R2002
FB2896
FB2801
291 8
CN2505
FB2033
FB2898
FB2899
R2620
A2001
R2157
C2853
DIGITAL
AUDIO
BOARD
(SIDE A)
1-885-324- 11
(11)
(CHASSIS)
(CHASSIS)
COAXIAL
BD/DVD IN
FLASH
PROGRAMMING
OPTICAL
SAT/
CATV
IN
OPTICAL
GAME
IN
DIGITAL
I
MAIN BOARD
CN300
(Page 26) H
MAIN BOARD
CN301
(Page 26)
A
TUNER1
BOARD
CN101
(Page 46)
B
LED BAR
BOARD
CN104
(Page 41)
C
THERMAL
BOARD
CN250
(Page 48)
D
USB
BOARD
CN4100
(Page 42)
E
DCDC BOARD
CN1503
(Page 39)
F
POWER
AVIDEO BOARD
CN271
(Page 35)
G
HDMI RE PC
BOARD
CN3512
(Page 31)
X2101
FLASH
PROGRAMMING
Note: IC2036 on the DIGITAL AUDIO board cannot exchange
with single. When this part on the DIGITAL AUDIO board is
damaged, exchange the entire mounted board.
