Sony RM-TP503 User manual

3-867-704-11(1)
Remote
Commander
 1999 by Sony Corporation
RM-TP503
Operating Instructions
Mode d’emploi
Manual de instrucciones
Manual de instruções
ES
PT
GB
FR

2GB
Understanding the 2 way remote system
This commander operates under a 2 way remote system.
With the 2 way remote system, the component responds
to signals sent from the commander by sending additional
signals (information about the status of the component,
text data, etc.) back to the commander. Thus, operations
are performed as a result of communication between the
commander and the component.
When using a home entertainment system comprised of
several components compatible with the 2 way remote
system, please restrict 2 way remote system operation to a
single component. Generally, the 2 way remote system is
turned off on all components except for the receiver/
amplifier.
If you would like to turn off the receiver/amplifier’s 2
way remote system, refer to “Setting up the 2 way
remote” in the operating instructions supplied with the
receiver/amplifier.
Precautions
CAUTION (Lithium battery)
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent
type recommended by the manufacturer. Discard
used batteries according to the manufacturer’s
instructions.
On operation
Before connecting other components, be sure to turn off and
unplug the receiver/amplifier.
On cleaning
Clean the cabinet, panel and controls with a soft cloth slightly
moistened with a mild detergent solution. Do not use any type of
abrasive pad, scouring powder or solvent such as alcohol or
benzine.
If you have any question or problem concerning your
commander, please consult your nearest Sony dealer.
Component
Commander
About This Manual
• The following icon is used in this manual:
zIndicates hints and tips for making the task easier.
Before You Use the
Commander

3GB
TABLE OF CONTENTS
Preparations 4
Compatible Components and Functions 4
Preparing the Commander 5
Screen Hierarchy 8
Location of Parts and Basic
Operations 9
Front panel 9
Rear panel 10
Operation 11
Basic Operations 11
Example: Operating a CD Player 13
Example: Operating the Tuner 14
Example: Recording from CD to MD 15
Performing Several Commands in Sequence
Automatically (Macro Play) 16
Using a command that has been learned 17
Selecting a source to listen to using SUB ROOM 17
Selecting Sound Fields 18
Adjusting Sound Fields 21
Adjusting the Commander’s Operating
Environment 24
Additional information 31
Precautions during use 31
Troubleshooting 32
Specifications 33
Index 33
Special Remarks
pAbout the LCD
Depending on the brightness of the room and the angle at
which the commander is viewed, the LCD may be
difficult to see. When this occurs, changing the angle of
the commander or adjusting the CONTRAST of the LCD
may make the LCD easier to see. When fingerprints (etc.)
get on the LCD, wipe the LCD with a soft, dry cloth. It is
recommended to use the touch pen supplied with the
commander.
pAbout batteries
Life span of the batteries
This commander is different from conventional remotes in
that it makes use of a large LCD and is capable of 2 way
communication. Because of this, the batteries become
exhausted more quickly than with conventional remotes.
Under normal conditions, the batteries should last
approximately 2.5 months*. However, depending on how
the remote is used and the initial voltage of the batteries,
the actual period of use may be shorter or longer than that
mentioned above.
* This value is based on 60 key operations a day with the
backlight on. If the backlight is turned off, the batteries should
last much longer. In order to extend the life of the batteries, it is
recommended to keep the backlight off when operating the
commander in a well lit area.
GB

4GB
Preparations
This chapter describes how to prepare
the remote commander for operation.
Be sure to read this section before
operating.
Compatible Components
and Functions
This unit is a remote control system that utilizes infrared
rays to control a receiver/amplifier and AV components
connected to the receiver/amplifier.
Compatible Components
This unit can be used to operate Sony AV components as
well as AV components made by other manufacturers.
Setup is necessary in order to operate components made
by other manufacturers (see page 24).
Note
Depending on the component, control may not be possible using
this unit.
Functions
This unit is a 2 way remote commander. Not only does it
transmit infrared rays for operation of the receiver/
amplifier, it also receives infrared rays emitted by the
receiver/amplifier to display characters and other
information from components connected to the receiver/
amplifier with a CONTROL A1 cord.

5GB
Preparations
]
]
}
}
]
}
]
}
Please be sure to carry out the procedures described in
“Setting up the commander” on page 6 after inserting the
batteries.
Inserting batteries into the commander
Insert the four size-AA (LR6) alkaline batteries (for
commander operation) and the lithium battery (for
preservation of the commander’s internal memory).
1Remove the battery compartment cover.
2Insert the alkaline batteries.
3Insert the lithium battery.
After wiping the lithium battery thoroughly with a
dry cloth, insert it into the compartment with the
positive (+) pole side facing up.
Preparing the Commander
4Close the battery compartment cover.
After inserting the batteries, touching the touch panel
turns on the light and displays the touch panel (LCD)
adjustment screen. Follow the procedure on the next
page for touch panel adjustment and initial
communication.
Notes
• The LCD lights up when touched.
• VOL +/–, MUTING and SLEEP can be used even when the
LCD is not lit.
• Pressing BACK LIGHT/COMMANDER OFF turns the
backlight on or off. Holding it down for about 2 seconds turns
the LCD off.
• If the commander is not used for 10 seconds, the LCD turns off
automatically (Auto Off function).
Push in direction of
arrow
Always insert the negative (–) pole
side of batteries first.
Size-AA alkaline batteries
Coin shaped lithium
battery CR2032
Positive (+) pole side up

6GB
Preparations
Touch panel adjustment
3Adjust the position of the touch panel’s LCD.
Touch the center of each of the 4 dots with the touch
pen. When all 4 dots have been touched “Adjusted”
appears, a buzzer sounds, and the initial
communication screen appears.
Caution
Touch panel adjustment must be carried out for proper panel
operation. If used without adjustment, the ”Touch Panel
Adjustment” screen appears each time the LCD lights up.
Initial communication
4Press 1/u on the receiver/amplifier to turn on the
receiver/amplifier.
5Point the commander’s transmitter/receiver section
toward the receiver/amplifier’s display, and touch
OK.
Once initial communication with the receiver/
amplifier has been established, the commander is
ready to operate the receiver/amplifier.
Setting up the commander
Please be sure to carry out the following 5 steps for
preparation of the commander.
The commander’s panel is touch sensitive and can be
operated by simply touching it.
1Remove the touch pen.
When returning the touch pen, always slide it in tip
first.
Caution
Use only the touch pen provided with this unit or the soft tip
of your finger to operate the touch panel. Using a
commercially available writing utensil may damage the panel
and make correct operation impossible. If the tip of the touch
pen is damaged, or the touch pen is lost, please consult your
nearest Sony dealer.
2Turn CONTRAST to adjust brightness of the LCD.
Touch the 4 dots with the touch pen.
Preparing the Commander
Pen holder
Remove by sliding out
CONTRAST control

7GB
Preparations
Notes
• To ensure good communication conditions, carry out initial
setup from directly in front of, and close to the receiver/
amplifier.
• Do not move the unit during initial setup.
If a communication error occurs during setup
An error message will be displayed.
• Touching OK will return to the step 5 setup screen.
• Touching SKIP goes to the regular screen without
carrying out initial setup. Although operation is
possible in this condition, functions not included on the
receiver/amplifier will be displayed, and some buttons
will not be operable. Also, the initial setup screen will
appear each time the touch panel is turned on.
Note
The commander receives and displays data transmitted from the
receiver/amplifier. Communication errors may occur if the
commander’s transmitter/receiver section is not directed
properly toward the receiver/amplifier’s display.
Be sure to point the commander’s transmitter/receiver section
towards the receiver/amplifier’s display.
When replacing the batteries
To ensure preservation of the commander’s internal
memory when replacing batteries, be sure to observe the
following cautions.
When to replace batteries
When the batteries become weak, a warning sounds and a
message is displayed. Replace batteries as instructed by
the message.
How to remove the lithium battery
Notes
• Disc titles and song titles downloaded from the CD changer are
memorized in the commander. The lithium battery is used for
preservation of this memory. If the unit is used with an
exhausted battery, the settings memorized in the commander
will be erased. Please replace the battery as soon as the “Battery
Low” message appears.
• Replace the alkaline batteries with new batteries as soon as
their charge is exhausted. If the unit is used with exhausted
batteries, exhaustion of the lithium battery used to maintain
memory will be quickened and the memorized settings may be
erased.
• The life span of batteries may be shortened depending on the
conditions in which the commander is used.
• If the alkaline batteries and lithium battery become exhausted
at the same time, replace the alkaline batteries first. Replacing
the lithium battery first will erase the data memorized in the
commander.
• When replacing the alkaline batteries, always replace all 4
batteries with new ones.
• After replacing batteries, be sure to carry out touch panel
adjustment (page 6).
1 m ~ 2 m
Replace alkaline
batteries. Replace lithium
battery.

8GB
Preparations
The following diagram shows the basic composition of this unit’s screen hierarchy.
FUNCTION screen
Screen Hierarchy
Normally, the FUNCTION screen is displayed.
To display a different screen, touch the left side of the LCD.
SOUND FIELD screen
SETUP screen
Screen for selection and
adjustment of the sound
fields (pages 18~23).
Screen for setting up the
operation environment and
control of components made
by other manufacturers
(pages 24~30).
Touch when the song titles of a CD or MD being played back are not
displayed correctly.
Screens for selection
and operation of
components
connected to the
receiver/amplifier.
Screen for recording
audio and video from
one component to
another (page 15).
RELOAD...
Screen for performing
several commands in
sequence
automatically (page
16).
Screen for selecting a
source to listen to
using SUB ROOM
(page 17).
Screen for setting
remote control codes
that are not stored in
the commander (page
17).

9GB
Location of Parts and Basic Operations
Front panel
1BACK LIGHT/COMMANDER OFF
Press to turn the backlight on or off. Hold down for
about 2 seconds to turn the LCD off. When the LCD is
off, press to turn on the LCD and backlight.
• To prolong use of the batteries, the LCD automatically
turns off if there are no commands entered in the touch
panel for 10 seconds.
• To view the LCD display without turning on the backlight,
touch the touch panel when both the backlight and LCD
are off.
2Touch panel
Touch to operate. The commander turns on
automatically.
3VOL +/– buttons
Use to adjust the volume of the receiver/amplifier.
4JOG DIAL control
Rotate to scroll through items in a list (etc.).
Push to select the highlighted item.
5SYSTEM STANDBY button
Normally used to turn off all Sony components. Can
also be used to turn the receiver/amplifier on or off
depending on the settings made in the SETUP screen
(see page 30).
6MUTING button
Use to mute the sound of the receiver/amplifier.
7CONTRAST control
Use to adjust the contrast of the LCD.
8SLEEP button
Use to operate the receiver/amplifier’s sleep function.
The sleep settings appear in the receiver/amplifier’s
display, not the commander’s LCD.
123
4
5
6
7
8
Location of
Parts and Basic
Operations
This chapter provides information
about the locations and functions of
the buttons and controls on this unit.

10GB
Location of Parts and Basic Operations
Rear panel
1Transmitter/receiver section
Transmits and receives infrared signals to and from
the receiver/amplifier.
2Battery cover
3Touch pen
4SYSTEM STANDBY button
Normally used to turn off all Sony components. Can
also be used to turn the receiver/amplifier on or off
depending on the settings made in the SETUP screen
(see page 30).
5Remote code receiver section
When using the Learning function, this section
receives the remote codes from other remote controls.
6Touch pen holder
Pull out and insert touch pen when not in use.
12
3
4
65

11GB
Operation
Basic Operations
Operation
This chapter explains how to operate
the receiver/amplifier and connected
audio/video components.
FUNCTION
Displaying the FUNCTION screen
To operate components connected to the receiver/
amplifier, first display the FUNCTION screen, then select
the component you wish to operate (CD, MD, etc.).
Normally, the FUNCTION screen is displayed. If it is not
displayed, touch FUNCTION to display it.
Touch FUNCTION in the LCD.
The FUNCTION screen appears.
Composition of the FUNCTION screen is shown on the
next page.
zYou can change the functions displayed in the FUNCTION
screen
You can set all functions, except TUNER and REC EDIT, to be
displayed or not, using the FUNCTION HOOK UP screen (see
page 25).

12GB
Operation
Basic Operations
FUNCTION screen hierarchy
The following diagram shows the composition of the FUNCTION screen hierarchy.
The types of icons that can be displayed on the FUNCTION screen can be set using FUNCTION HOOK UP in the SETUP
screen. (For details on FUNCTION HOOK UP, see page 25.)

13GB
Operation
To operate other functions
Touch SUB or use the JOG DIAL to scroll. Another set of
buttons is displayed and ready for use.
To view the LIST
Touch LIST to view the song titles in a Sony CD changer
(5/50/200/300 CD) or MD deck connected by a
CONTROLA1 cord. In this case, the information must be
downloaded from the receiver/amplifier (see page 25 for
details).
The LIST screen can only be displayed when the
FUNCTION is set to CD or MD/DAT.
• Touch the disc number to start playing that disc. appears
next to the disc being played.
• Use the JOG DIAL or touch 4or $to scroll up or down the list.
• Touch NUMBER to sort in numerical order or touch TITLE to
sort in alphabetical order.
• Touch FUNCTION to return to the FUNCTION screen at any
time.
This section describes how to operate a CD player
connected to the receiver/amplifier. Other components
can also be operated in the same way.
For details concerning CD player operation, please refer
to your CD player’s operating instructions.
The screens used in the following example are the screens
that appear when using a SONY CD changer with a
CONTROLA1 terminal.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
The receiver/amplifier’s function switches to CD and
the CD screen appears.
• Long titles can be read by touching the scroll icon ( ) to
scroll along the title.
* Only displayed when a Sony CD changer (5/50/200/300 CD) or
CD player compatible with CD text is connected to the receiver/
amplifier by a CONTROL A1 cord.
3Touch (to start playback.
zWhen the song number or song title is not displayed
correctly
Point the commander toward the receiver/amplifier and touch
RELOAD.
Disc title*
Song title*
Example: Operating a CD Player
Selected maker and
category (see page 24).

14GB
Operation
This section describes how to operate the tuner.
For details on tuner operation, please refer to the
operating instructions provided with the receiver/
amplifier.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
The receiver/amplifier’s function switches to TUNER
and the tuner screen appears. However, preset station,
station name, band, and frequency do not appear in
the display of the amplifier.
• Touch FM/AM to change the band.
• Touch FM MODE to switch the FM reception mode to
AUTO or MONO. If the FM stereo reception is poor, select
MONO. You will not be able to enjoy the stereo sound
effect, but the sound will be less distorted.
• Touch PRESET + or – to search for preset stations.
• Touch TUNING + or – to search for stations that can be
received.
• Touch SHIFT to switch memory pages (A, B, C).
• Touch TUNING MODE to switch the tuning mode to
AUTO or MANUAL.
• During display of any of the screens, touching FUNCTION
returns to the FUNCTION screen.
zWhen broadcast stations or frequencies are not displayed
properly
Point the commander at the receiver/amplifier and touch
RELOAD.
To operate other functions
Touch SUB or use the JOG DIAL to scroll to display the
icons used for memorizing broadcast stations and station
names.
• To receive manually, touch DIRECT and input the
frequency.
• When memorizing a received broadcast station, memorize
after touching MEMORY.
Viewing the LIST
Touch LIST to view the names of the broadcast stations
downloaded from the receiver/amplifier (see page 25 for
details).
The LIST screen can only be displayed when the
FUNCTION is set to TUNER.
Preset station
Frequency
Band
Station name
Example: Operating the Tuner

15GB
Operation
4Touch to select the recorder component (MD/DAT
in this example).
When MD/DAT is touched, the REC EDIT operation
screen appears.
5Touch rin RECORDER: MD/DAT, then touch (in
PLAYER: CD.
Recording starts.
The FUNCTION screen returns once the recording
finishes.
To stop recording at any time
Although recording stops automatically in the above
example, recording can also be stopped at any time by
touching pin RECORDER.
To stop the recording procedure at any time
Touch FUNCTION to display the FUNCTION screen.
During steps 2 to 3, touching EXIT will also stop the
recording procedure.
This section describes how to record audio from a CD to
an MD as an example of recording audio/video.
Other operations
Recording from a DVD to a video deck is basically the same
procedure. For details on the buttons used in recording, refer to
the operating instructions supplied with the receiver/amplifier
and other components.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
The REC EDIT screen appears.
3Touch to select the player component (CD in this
example).
Because CD is not displayed, Use the JOG DIAL or
touch $to scroll downward through the list. If you
scroll to far, touch 4to scroll back up.
When PLAYER is selected, the receiver/amplifier’s
function automatically switches to the PLAYER
component.
Touching 4moves list up
Touching $moves list down
PLAYER
Example: Recording from CD to MD
Starts playback from the CD player
Starts recording on the MD deck.

16GB
Operation
The Macro Play function lets you link several IR codes in
sequential order as a single command. The remote
provides 3 macro lists (MACRO 1, 2 and 3). You can
specify up to 10 IR commands for each macro list.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
The MACRO screen appears.
When does not appear in the FUNCTION screen,
use the JOG DIAL to scroll through the list until it is
displayed, and then touch it.
• Touch SEND to operate Macro Play. The current command
is displayed in black. The finished commands are grayed
out.
• To cancel Macro Play, touch CANCEL. When Macro Play is
not operating, touching CANCEL returns to the
FUNCTION screen.
Performing Several Commands in Sequence Automatically
(Macro Play) Notes
• For some models, the receiver/amplifier cannot operate the
Macro Play commands as the time between each command is
too short. In this case, set “WAIT TIME” between each
command. To set “WAIT TIME”, refer to “Macro Play setting”
on page 26 and 27.
• For some makers other than Sony, there are some commands
that cannot be used in Macro Play.
BOX Number Send key
Category
Command Condition
SENDING: Outputting the
command
Done!: Outputting is
finished

17GB
Operation
By using the Learning function, it is possible for this
commander to perform learned operations. For details on
how to learn the operation codes of other components
using the Learning function, see page 29.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
When does not appear in the screen, use the JOG
DIAL to scroll the screen until it is displayed, and then
touch it.
3Touch the appropriate area from A to J
corresponding to the learned command.
4Touch the box containing the code you want to
send.
A mark (■) appears in the box when it has already
learned a command.
Select a source that you would like to enjoy listening to in
another room. You can switch the audio output to the 2nd
AUDIO OUT on the receiver/amplifier. For details, please
refer to the operating instructions supplied with your
receiver/amplifier.
1Touch FUNCTION.
The FUNCTION screen appears.
2Touch .
When does not appear on the screen, use the JOG
DIAL to scroll the screen until it is displayed, and then
touch it.
3Touch the source that you want to listen to in
another room.
The audio output on the receiver/amplifier changes.
Using a command that has
been learned Selecting a source to listen to using SUB ROOM

18GB
Operation
These sections describe how to select and make
adjustments to the sound fields.
For details concerning sound fields, please refer to the
operating instructions supplied with the receiver/
amplifier.
Displaying the SOUND FIELD screen
Touch SOUND FIELD.
The SOUND FIELD screen appears.
The SOUND FIELD screen hierarchy is shown on the
right.
Selecting Sound Fields
SOUND FIELD
CUSTOM
LEVEL
SURR EDIT
EQ EDIT
SP SETUP
S.F. PRESET
Sound Field Mode
EQ BANK
SOUND FIELD screen hierarchy

19GB
Operation
Selecting the sound field
For details concerning which sound fields can be selected,
please refer to the operating instructions supplied with
the receiver/amplifier.
1Touch SOUND FIELD.
The SOUND FIELD screen appears.
2Touch Sound Field Mode.
The Sound Field Mode screen appears.
3Use the JOG DIAL or touch 4or $to scroll through
the list.
4Push the JOG DIAL to select the highlighted sound
field or touch the sound field you desire.
A check (✔) will appear next to the selected sound
field, and the sound field will change.
Selected
sound field
Cursor
Selecting the sound field preset
1Touch SOUND FIELD.
The SOUND FIELD screen appears.
2Touch PRESET.
The SOUND FIELD PRESET screen appears.
3Touch one of the sound field presets (PRESET 1~5).
A check (✔) will appear next to the selected sound
field, and the sound field will change.
Selected PRESET
Cursor

20GB
Operation
Selecting Sound Fields
Selecting the equalizer
1Touch SOUND FIELD.
The SOUND FIELD screen appears.
2Touch EQ BANK.
The EQ BANK screen appears.
3Touch one of the equalizer presets (EQ PRESET
1~5).
Touch EQ OFF to turn the receiver/amplifier’s
equalizer off.
A check (✔) will appear next to the selected equalizer,
and the equalizer settings will change.
Cursor
Note
If EQ OFF is selected, EQUALIZER screen settings cannot be
changed.
Selected
equalizer
Setting the sound field preset
1Touch SOUND FIELD.
The SOUND FIELD screen appears.
2Touch PRESET.
The SOUND FIELD PRESET screen appears.
3Touch PRESET SETUP.
The SOUND FIELD PRESET SETUP screen appears.
4Use the JOG DIAL or touch 4or $to scroll through
the list.
5Push the JOG DIAL to select the highlighted sound
field or touch the sound field you desire.
A check (✔) will appear next to the selected sound
field, and the sound field will change.
Selected
preset sound
Cursor
